P/N YRL-PBINSTL-FUL Rev D
1
Yale Real Living Assure Lock
®™
Push Button Deadbolt
Installation and Programming Instructions
(YRD216)
®
x3
#8-32 x 5/16"
Machine screws
x4
#7 wood & #8-32
machine x 20mm
Combination screws
x2
M6x59.5mm
Long through bolt
FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN DAMAGE TO
THE PRODUCT AND VOID THE FACTORY WARRANTY
Optional
Network Module
