Fig. 1 — Sizes 09K - 24K
NOTES: Read the entire instruction manual before starting the
installation.
Images are for illustration purposes only. Actual models
may differ slightly.
TABLE OF CONTENTS
SAFETY CONSIDERATIONS .....................................................................2
PARTS LIST................................................................................................3
SYSTEM REQUIREMENTS........................................................................4
WIRING .......................................................................................................4
DIMENSIONS - INDOOR ............................................................................5
CLEARANCES - INDOOR ..........................................................................8
INSTALLATION TIPS..................................................................................9
ELECTRICAL DATA....................................................................................12
CONNECTION DIAGRAMS ........................................................................12
FINAL TUBING CHECK ..............................................................................14
WIRELESS REMOTE CONTROL INSTALLATION ....................................14
START-UP ..................................................................................................15
SYSTEM CHECKS.....................................................................................16
TROUBLESHOOTING ................................................................................16
Installation Instructions
40MHH
High Wall Ductless System
Sizes 09 to 24
