Café
™
36" Wall-Mount Glass Canopy
Chimney Hood
CVW73614MWM / CVW73613MDS / CVW73612MSS
Keep your kitchen smelling fresh and ready for guests with a
350-CFM venting system with boost that removes smoke, grease,
odors and moisture.
Add a conversation-starter to your kitchen with electronic backlit
controls that look great and are easy to use.
Clearly watch the progress of preparing your favorite meals with dual
halogen cooktop lighting that brightly illuminates the cooking surface.
See your way through midnight snacking with a night light that softly
illuminates the cooktop and surrounding areas.
Fill the kitchen with fresh air with two convertible venting options:
recirculating or external venting.
Share favorite stories without interruption, thanks to an optional remote
control that can change lighting and fan speed settings from anywhere
in the kitchen.
Keep conversations flowing without interruption thanks to an auto-o
feature that deactivates the vent after 15 minutes.
Simplify clean-up with a dishwasher-safe filter that removes grease
and can be cleaned alongside dishes too.
FEATURES & BENEFITS
FEATURES
Control Location Front
Control Type Backlit
Cooktop Lighting Halogen
Ducting Vertical Only
Exhaust Options
Vented to Outside
Recirculating
Fan Speed Control 4-Speed
Filter Cleaning Dishwasher Safe
Removable Grease Filter(s) Ye s
6" Round Duct Ye s
CFM/ Sones Rating
350/6.1 (Boost Speed)
330/5.4 (High Speed)
160/.9 (Working Speed)
Light Controls On/O/Night
Optional Accessories
CX10DC73WM / CX10DC73DS /
CX10DC73SS - 10 (ft.) Ceiling Duct Cover Kit
JXCF71 - Charcoal Filter
UXRC70 - Remote Control
ECONOMICAL / QUIET
Venting Type Convertible
TECHNICAL DETAILS
Amp Rating at 120V 5.3
WEIGHTS & DIMENSIONS
Approximate Shipping Weight 54 lb.
Net Weight 46 lb.
Cabinet Width 36 in
Overall Depth 18-1/2 in
Overall Height 1-3/4 in
Overall Width 36 in
APPEARANCE
Blower / Light Switch Color Backlit
CVW73613MDS
Matte Black
CVW73612MSS
Stainless
ALSO
AVAILABLE IN
Café
™
36" Wall-Mount Glass Canopy
Chimney Hood
CVW73614MWM / CVW73613MDS / CVW73612MSS
24" Min
18-1/2"
10-3/16"
11-3/4"
36"
*Height
to
Ceiling
1-3/4"
36" models require a 36"-wide opening
*The supplied duct cover fits 7'-5" to 9'-3" ceiling heights
(10' with optional high ceiling kit JX10DC73)
The vent hood must be installed 24" min. above the cooking surface. For optimal performance, installing the
hood more than 36" above the cooking surface is not recommended. The hood installation height above the
cooking surface depends upon ceiling height. The telescopic duct cover conceals the ductwork running from
the top of the hood to the ceiling.
NOTE: Installation height should be measured from the cooking surface to the lowest part
of the hood. This hood may be installed onto a wall and vented to the outdoors, or it can be installed
for recirculating operation. Parts for recirculating operation are supplied with the hood. However, when
installed for recirculating operation, the optional charcoal Filter JXCF71 will need to be purchased separately.
PVW7361SJ_EJ
24" Min
18-1/2"
10-3/16"
11-3/4"
36"
*Height
to
Ceiling
1-3/4"
36" models require a 36"-wide opening
*The supplied duct cover fits 7'-5" to 9'-3" ceiling heights
(10' with optional high ceiling kit JX10DC73)
The vent hood must be installed 24" min. above the cooking surface. For optimal performance, installing the
hood more than 36" above the cooking surface is not recommended. The hood installation height above the
cooking surface depends upon ceiling height. The telescopic duct cover conceals the ductwork running from
the top of the hood to the ceiling.
NOTE: Installation height should be measured from the cooking surface to the lowest part
of the hood. This hood may be installed onto a wall and vented to the outdoors, or it can be installed
for recirculating operation. Parts for recirculating operation are supplied with the hood. However, when
installed for recirculating operation, the optional charcoal Filter JXCF71 will need to be purchased separately.
PVW7361SJ_EJ
© 2018 GE Appliances PC90238 05/18
For answers to your Café™ product questions, visit our website at cafeappliances.com.
WARRANTY
Parts warranty Limited 1-year entire appliance
Labor warranty Limited 1-year entire appliance
Warranty notes See written warranty for full details
DIMENSIONS AND INSTALLATION
INFORMATION
Installation Information:
Before installing, consult Use & Care/installation instructions
packed with product for current dimensional data.
Optional Accessories
CX10DC73WM/DS/SS – 10(ft.) Ceiling Duct Cover Kit
For 30" distance from counter to hood:
7'-5" – 8'-9" ceiling height - no duct cover required
8'-10" and above ceiling height – CX10DC73WM/DS/SS
Refer to Installation Instructions for exact specifications
UXRC70 – Remote Control
JXCF71 – Charcoal Filter
(needed if used in recirculation mode)
36" Models Require a 36"-Wide Opening
*The supplied duct cover fits 7'-5" to 9'-3"
ceiling heights (10' with optional high ceiling
kit CX10DC73)
24" Min
18-1/2"
10-3/16"
11-3/4"
36"
*Height
to
Ceiling
1-3/4"
36" models require a 36"-wide opening
*The supplied duct cover fits 7'-5" to 9'-3" ceiling heights
(10' with optional high ceiling kit JX10DC73)
The vent hood must be installed 24" min. above the cooking surface. For optimal performance, installing the
hood more than 36" above the cooking surface is not recommended. The hood installation height above the
cooking surface depends upon ceiling height. The telescopic duct cover conceals the ductwork running from
the top of the hood to the ceiling.
NOTE: Installation height should be measured from the cooking surface to the lowest part
of the hood. This hood may be installed onto a wall and vented to the outdoors, or it can be installed
for recirculating operation. Parts for recirculating operation are supplied with the hood. However, when
installed for recirculating operation, the optional charcoal Filter JXCF71 will need to be purchased separately.
PVW7361SJ_EJ
AMP RATING
120V 5.3
