SEARS
CRRFTSMRN°
Tool Storage Chest
PROFESSIONAL SERIES
1-Drawer 706.654001
2-Drawer 706.65321 653311 653331
3-D_wer 706.653251 653301 653371
653380 653921 653941
653951 654081 657620
657721 658040 657660
4-Drawer 706.652240 652260 652520
655850 654070
8-Drawer 706.650750 657560 657570
7-Drawer 706.652270 657510 657751
B-Drawer 706.650770 652280 656971
656981 657550 657580
658660
_-Drawer 706.651691 652370
lO-Drawer 706.657380 657590 657740
12-Drawer 706.657390 657521 657540
657610 657791
14-Drawer 706.657350
3AUTION: Readand follow allSafety Rules
_ndOperatingInstructionsbeforefirst useof
hisproduct.
_ears, Roebuckand Co.
-IoffmanEstates,IL 60179 U.S.A.
Spring
Made in the U.S.A.
F888A1
)IVIDER INSTALLATION:
Dependant on Model No.)
Hold springclipto the sideof drawer.
Placethe dividerend intospringclip.
Swingthe dividerintoposition,the
springclipwillholditin place.
The dividermay be cuttofitfrom the
fronttothe backof thedrawer.
J
SAFETY RULES AND WARNINGS:
• DO NOT stand onthis product. You may fall which may cause personal injury.
• WEAR SAFETY GLASSES AND GLOVES when cuttingthe bandingmaterial.The
bandsmay snapwhichmay causepersonalinjury.
• Stackedproductsshouldbe boltedtogether.The productscouldbecomeunstableand
tip,whichmay cause personalinjuryor productdamage.
• WEAR SAFETY GLASSES when removingor repositioningtheslides.The toolcould
slipwhichmay cause personalinjury.
• When the coverisopened,be surethe coverstop isinthe lockedposition.Thiswill
preventaccidentalclosureand personalinjury.
• BECAREFUL when closingthecover.Remove handsbeforethecovercloses
completelytopreventpersonalinjury.
• BE CAREFUL when openingmorethan one drawer.The productmay become unstable
and tip,whichmay cause personalinjuryor productdamage.
• DO NOT mountthis producton a truckbed or anyothermovingobject.Thismay cause
personalinjuryor productdamage.
• DO NOT stepin the drawers.You may fall whichmay cause personalinjury.
• Appropriately securethisproductbeforemovingitwitha forklift.
• Close the cover and lockthe drawersand doorsbeforemovingthisproduct.The
drawersor doorscouldcomeopenand make the productunstableand tip,whichmay
cause personalinjuryor productdamage.
• DO NOT alter this productinany manner.Forexample, do notweld externalIockbarsor
attachelectri#_.a|equipment.Thismay cause productdamage or personalinjury.
• Removethework surface,ifprovided,from the cart beforemountingthechest. Failure
todo so may cause thechesttoslideoff,whichmay cause personalinjuryor product
damage.
° WEAR SAFETY GLASSES AND BE CAREFUL when movingthe coverrods. The rod
couldspringoutofthe hole,whichmay cause personalinjury.
• When lockingthisproduct,closethedrawersbeforeclosingthecoverfor Iockbarsto
work properly.
• Spreadtheweightoutevenly inthetotetrays. Ifthe weightis notspreadevenly,the
contentscouldshiftandfall out,whichmaycause personalinjury,and/ordamage tothe
contentsor totetray.
• The maximumweightfor each drawershouldbe no morethan 50 pounds.
Call 1-800-366-7278 for Service Parts
Refer to Service Parts Drawing for full listing of Service Parts
DRAWER REMOVAL:
= Fully extend the drawer. Push it back a quarter of
an inch.
• Insert a screwdriver into the slot in the slide and push
in on the stop until it clears the lance. Repeat the
procedure on the other slide and remove the drawer.
Slot _ Stop
__bricate __
° To reinstall thedrawer, pry thestopfar enoughout to engage thelance andpush the
drawerontothe slidesuntilthe stopspassover thelances.
LUBRICATIO.N. Lubricate the top and bottom channels of the drawer slides at least
twice a year.
REPOSITIONING THE COVER RODS: The cover rod can be repositioned for
customized storage needs.
• Hold the rod firmly at both ends. Slide the rod to one end and flex the center portion of
the rod until its end is free of the hole.
• Insert the rod into an alternate hole location and reverse this procedure. WEAR
SAFETY GLASSES and use extreme caution during this procedure.
