사용 전
Before Use
사용 후
After Use
색상이 까맣게 변하면 진공청소기 등으로 먼지를 흡입하여
주시면 재사용이 가능합니다.
e-나노 필름 필터는 영구 정전기력을 가지고 있기 때문에 청소 후
재사용이 가능하나 사용전의 색상으로 돌아오지는 않습니다.
장시간 사용하실 경우 필터의 교체가 필요할 수도 있습니다.
필터를 세척하기 위해 표백제나 유해 세제를 사용하지 마십시오.
Filter can be reused by vacuuming and/or
washing with clean water when the color changes to black.
As the e-nano film filter has a permanent
electrostatic force, it can be reused after
washing, however filter may remain dark.
It is recommended to replace the filter
after a long period of use (12~15 months).
Please do not use bleach or harmful
detergent to wash the filter.
▶필터 청소방법 (Filter Cleaning Method)
▶제품구성 (Product Composition)
▶작동 터치 방법 (How to Use Touch Panel)
가볍게 터치~!
Soft Touch~!
제품본체
Product Body
※별매품
※ option
유에스비 케이블
USB Cable
본체 거치대
Stand
사용설명서
Instruction Manual
가정용 USB아답터
USB Adapter
1 2
4
3
5
터치메뉴
1회 터치 - 터보 (LED : RED)
2회 터치 - 일반 (LED : BLUE)
3회 터치 - 취침 (LED : 소등)
4회 터치 - 종료 (모든전원 OFF)
1 touch (Turbo Mode) LED color will be red
2 touch (Silence Mode) LED color will be blue
3 touch (Sleeping Mode) Without LED light.
4 touch (Recharging or OFF Mode) Power OFF
Touch Menu
본체에 동봉된 전용 USB Cable을 이용하여 전원을 연결합니다.
제품 상단 캐릭터 부분을 가볍게 터치해주시면 공기청정기가 작동 됩니다.
▶사용방법 (How to Use)
Connect the power using the USB with the product. Touch the
upper character of the product lightly, the air purifier will work.
MV - AL - IR - AI
MV - AL - CA - AI
▶테크놀로지 (Filter Technology)
본 제품은 세계적 발명 특허품인 나노 필름 필터를 이용한 공기청정기 입니다.
세상의 모든 질량을 가진 물질은 극성 (+,-)을 가진다는 전제하에 발명된
e-나노 필름 필터는 지그재그식의 공기 통로를 만들어 공기가 필터 내에서
머무는 시간을 최대화 하여 그 안에 극성(+,-)의 정전기를 인가하여 공기가
통과하는 동안에 각종 먼지와 냄새가 포집되는 공간을 만든 세계적 발명품 입니다.
This is an air Purifier with E-nano film filter which is a world-
famous patented technology. “E-nano film filter” is invented
under the premise that every material with weight has “+,-“
polarity. There is air passages as zigzag form to maximize the
time of the air staying inside the filter. Through this way, the
polarized (+,-) static electricity inside the passages create a
space where various dusts and smells are piled up.
▶필터 교체방법 (How to replace the Filter)
1. 제품을 가볍게 잡고 상단 케이스를 시계 반대 방향으로 돌려줍니다.
2. 필터 상단에 끼워져 있는 고무링을 제거합니다.
3. 사용한 필터를 제거 후 새로운 필터로 교체합니다.
4. 고무링을 원상태로 끼운 후, 제품의 상부 커버와 홈을 맞추어
시계 방향으로 돌려줍니다. (1번과 반대방향)
1. Hold the product with both hands and twist it in a
counterclockwise direction to open.
2. Remove the rubber ring on the filter.
3. After removing the used filter, replace it with a new one.
4. Fit the rubber ring in its original place. Match the under
and upper part of the product and twist it in a
clockwise direction to fasten it
MV - AL - IR - AI
MV - AL - CA - AI
