User Manual
ZFT519X
ZFT516X
EN User Manual
Cooker Hood
VISIT OUR WEBSITE TO:
Get usage advice, brochures, trouble shooter, service and repair information:
www.zanussi.com/support
SAFETY INFORMATION AND INSTALLATION
WARNING!
Refer to the separate Installation Instructions
booklet for Safety Information and Installation. Read
carefully the Safety chapters before any use or
maintenance of the appliance.
PRODUCT DESCRIPTION
CONTROL PANEL OVERVIEW
4321
1
Lamp
2
First motor speed / Off
3
Second motor speed
4
Third motor speed
DAILY USE
USING THE HOOD
Check the recommended speed according to the
table below.
While heating up food, cooking with covered pots.
While cooking with covered pots on multiple cooking zones
or burners, gentle frying.
While boiling, frying big quantities of food without a lid,
cooking on multiple cooking zones or burners.
2
It is recommended to leave the hood
operating for approximately 15 minutes
after cooking.
To operate the hood:
1. Press the first speed button
to switch on
the appliance.
2. If needed, press the light button to
illuminate the cooking surface.
3. If needed, change the speed by pressing the
desired button.
To turn off the appliance press the first speed
button again.
CARE AND CLEANING
CLEANING THE GREASE FILTER
Each filter must be cleaned at least once a month.
Filters are mounted with the use of clips and pins
on the opposite side.
To clean the filter:
1. Press the handle of the mounting clip on the
filter panel underneath the hood (1).
1
2
2. Slightly tilt the front of the filter downwards (2),
then pull.
Repeat the first two steps for all filters.
3. Clean the filters using a sponge with non
abrasive detergents or in a dishwasher.
The dishwasher must be set to a low
temperature and a short cycle. The
grease filter may discolour, it has no
influence on the performance of the
appliance.
4. To mount the filters back follow the first two
steps in reverse order.
Repeat the steps for all filters if applicable.
REPLACING THE CHARCOAL FILTER
WARNING! The charcoal filter is non-
washable!
The time of saturation of the charcoal filter varies
depending on the type of cooking and the regularity
of cleaning the grease filter.
To replace the filter:
1. Remove the grease filters from the appliance.
Refer to "Cleaning the grease filter" in this chapter.
2. press the tab (1) and slightly tilt the front of the
filter.
11
3. To install a new filter, perform the same steps in
reverse order.
In any case, it is necessary to replace the filters at
least every four months.
REPLACING THE LAMP
This appliance is supplied with a LED lamp and
separate control gear (LED driver). These parts can
be replaced by a technician only. In case of any
malfunction refer to "Service" in the "Safety
Instructions" chapter.
ENVIRONMENTAL CONCERNS
Recycle materials with the symbol . Put the
packaging in relevant containers to recycle it. Help
protect the environment and human health by
recycling waste of electrical and electronic
appliances. Do not dispose of appliances marked
with the symbol with the household waste.
Return the product to your local recycling facility or
contact your municipal office.
3
*
