BPV-SERIES
100V Outdoor Speakers
User Manual
BP3V
75mm (3”), 60Wmax
White
952.810
Black
952.811
BP4V
100mm (4”), 70Wmax
White
952.812
Black
952.813
BP5V
130mm (5.25”), 90Wmax
White
952.814
Black
952.815
BP6V
165mm (6.5”), 120Wmax
White
952.816
Black
952.817
Introduction
Thank you for choosing the BC-series indoor speakers. These speakers have been designed to offer high
quality sound for low impedance installations. Please read and follow the
instructions in this manual to achieve the best results and avoid damage through
misuse.
Installation
The BC-series speakers are each supplied with a wall-mounting bracket which
allows 90° lateral adjustment. When fixing to a wall or ceiling, use the bracket to
mark out the fixing points and use appropriate fixings for the substrate that the
speaker will be attached to, ensuring that the fixing is strong enough to bear the weight.
Once the bracket is fitted, support the speaker in position and attach top and bottom using the supplied
screw caps and adjust to the required angle. Further mounting points are available at the rear of the
speaker, should it be preferred to use different mounting methods (e.g. 129.130 – 129.124UK)
Note: Do not over-tighten the screw caps as this can cause the threaded inserts to fail.
