User manual of Whirlpool DU1055XTSS2 (44 pages)
file thumbnail

W10073760B

DISHWASHER

For questions about features. operation/performance. parts. accessories or service. call: 1-800-263-1301 or visit our website at www.whirlpooLcom

In Canada. for assistance. installation or service. call: 1-800-807-6777 or visit our website at

LAVE.VAISSELLE

$i =] =ii) L!I!_¸ iE

Au Canada. pour assistance. installation ou service. composez le 1-800-807-6777

Table of Contents/Table des matieres. 2

Models/ModUles DU1015.

DU1055.

DU1061.

DUll00.

DUll01.

DUl145.

DUl148.

DU1200.

DU1201.

DU1245.

DU1248.

DUL240

DISHWASHERSAFETY

Your safety and the safety of others are very important.

We have provided many important safety messages in this manual and on your appliance.

Always read and obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to potential hazards that can kill or hurt you and others.

All safety messages will follow the safety alert symbol and either the word "DANGER" or "WARNING." These words mean:

You can be killed or seriously injured if you don't immediately follow instructions.

You can be killed or seriously injured if you don't follow instructions.

All safety messages will tell you what the potential hazard is. tell you how to reduce the chance of injury. and tell you what can happen if the instructions are not followed.

(MPORTANT SAFETY (NSTRUCTmONS

WARNmNG: When using the dishwasher. follow basic precautions. including the following:

_. Read all instructions before using the dishwasher. _. Do not tamper with controls.

_. Use the dishwasher only for its intended function.

_. Use only detergents or rinse agents recommended for use in a dishwasher. and keep them out of the reach of children.

_. When loading items to be washed:

1) Locate sharp items so that they are not likely to damage the door seal; and

2) Load sharp knives with the handles up to reduce the risk of cut-type injuries.

_. Do not wash plastic items unless they are marked "dishwasher safe" or the equivalent.

For plastic items not so marked. check the manufacturer's recommendations.

_. Do not touch the heating element during or immediately after use.

_. Do not operate the dishwasher unless all enclosure panels are properly in place.

_. Do not abuse. sit on. or stand on the door. lid. or dish racks of the dishwasher.

_. To reduce the risk of injury. do not allow children to play in or on the dishwasher.

_. Under certain conditions. hydrogen gas may be produced in a hot water system that has not been used for two weeks or more. HYDROGEN GAS IS EXPLOSIVE.

If the hot water system has not been used for such a period. before using the dishwasher turn on all hot water faucets and let the water flow from each for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable. do not smoke or use an open flame during this time.

_. Remove the door or lid to the washing compartment when removing an old dishwasher from service or discarding it.

SAVE THESE (NSTRUCTmONS

Tip Over Hazard

Do not use dishwasher until completely installed.

Do not push down on open door°

Do}rig so can resuJt in serious injury or cuts.

Emectrical Shock Hazard

Electrically ground dishwasher.

Connect ground wire to green ground connector in terminal box.

Do not use an extension cord°

Failure to foltow these instructions can result in death. fire. or electr}ca shock.

Install where dishwasher is protected from the elements.

Protect against freezing to avoid possible rupture of fill valve.

Such ruptures are not covered by the warranty. See "Storing" section for winter storage information.

Install and level dishwasher on a floor that will hold the weight. and in an area suitable for its size and use.

Remove all shipping plugs from hoses and connectors (such as the cap on the drain outlet) before installing.

See Installation Instructions for complete information.

GROUNDING INSTRUCTIONS

For a grounded. cord-connected dishwasher:

The dishwasher must be grounded.

In the event of a malfunction or breakdown. grounding will reduce the risk of electric shock by providing a path of least resistance for electric current.

The dishwasher is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes and ordinances.

WARNING: Improper connection of the equipment-grounding conductor can result in a risk of electric shock.

Check with a qualified electrician or service representative if you are in doubt whether the dishwasher is properly grounded.

Do not modify the plug provided with the dishwasher; if it will not fit the outlet. have a proper outlet installed by a qualified electrician.

For a permanently connected dishwasher:

The dishwasher must be connected to a grounded metal. permanent wiring system. or an equipment grounding conductor must be run with the circuit conductors and connected to the equipment grounding terminal or lead on the dishwasher.

SAVE THESE INSTRUCTIONS

PARTSANDFEATURES

This manual covers several different models.

The dishwasher you have purchased may have some or all of the parts and features listed below.

A. Upper level wash B. Top rack C. Lower spray arm D. Bottom rack

E. Fold-down tines (on some models) F Model and serial number label

G. Heating element H. Water inlet opening (in tub wall)

L Silverware basket (on some models) J. ANYWARE TM PLUS silverware basket (on some models) K. Detergent dispenser L. Vent M. Top spray arm N. Filter module

O. Overfill protection float R Rinse aid dispenser

Other features your dishwasher may have

Light item clips Side clips

Utensil clips Two position adjusters Cup shelves

DU1015

STATUS

Washing Dlyiny Clean

SEAR1/ CANCEL/ RESUME DRAIN

CYCLES OPTIONS + 8 00o

ROTS& NORMAL RINSE NIoTE/aP NEATED PANS ONLY WASH DRY

4 HOURDELAY

DELAY 1

DU1055. DU1061

Washing Dlying Clea Sanitized0 STATUS

I CANCEL/ RESUME DRAIN CYCLES OPTUONS

0000 000o

ROTS& NORMAL LIGHT RINSE HIRMR SANI HEATED PANS ON WASH RINSE DRY

DELAY

DU1100. DU1101. DUL240

CYCLES

QQQQ

POTS& NORMAL EIGHT RINSE PANE ONEv

S0akiflgWashnDrying Clean Sanitized S T A T U S SenwIg C)

OPTmONS O O O

+. 3c.

SOAK& HIMEMP SANI HEAPED DELAY START/ SCOUR WAS RINSE DRY RESUME

DUl145

CYCLES

QQQQ

POTS& NORMAL LIGHT RINSE PANS ONLY

SmlsmgWasMnR DIying Clean Sanitized

OPTIONS O0

HIUEMP PANI HEATED DELA START/ WASH RINSE DRY RESUME

DU1148. DU1200. DU1201. DU1245. DU1248

CYCLES

00000

POTS& NORMAL LIGHT GMS. RINSE PANS XPNS ONLY

SeosiT1g WashngDrying Clean SaMtzed S T A T g

OPTIONS QO O O

+ cs'u

HI-TRMP SANI HEATED DELAY START/ WASH RINSE DRY RESUME

START-UPGUIDE

Before using your dishwasher. remove all packaging materials.

Read this entire Use and Care Guide. You will find important safety information and useful operating tips.

Scrape large food soil and hard items (toothpicks or bones) from dishes.

Properly load the dishwasher. (See "Dishwasher Loading.") Make sure nothing keeps the spray arm(s) from spinning freely.

Add detergent and check the rinse aid dispenser. Add rinse aid if needed. (See "Dishwasher Use.")

Push door firmly closed. The door latches automatically.

Run hot water at the sink nearest your dishwasher until the water is hot. (See "Dishwasher Efficiency Tips.") Turn off water.

Press the desired cycle and option selections.

Press START/RESUME.

NOTE: If the door is opened during a cycle or the power is interrupted. the Start/Resume indicator flashes. The cycle will not resume until the door is closed. and Start/Resume is pressed.

DISHWASHERLOADING

Remove leftover food. bones. toothpicks and other hard items from the dishes.

It is not necessary to rinse the dishes before putting them into the dishwasher.

The wash module removes food particles from the water. The module contains a chopping device which will reduce the size of food items.

NOTE: If hard items such as fruit seeds. nuts. and eggshells enter the wash module. you might hear chopping. grinding. crunching. or buzzing sounds. These sounds are normal when hard items enter the module.

To avoid damage to the dishwasher. do not let metallic items (such as pot handle screws) get into the wash module.

It is important for the water spray to reach all soiled surfaces.

Load dishes so they are not stacked or overlapping. if possible.

For best drying. water must be able to drain from all surfaces.

Make sure pot lids and handles. pizza pans. cookie sheets. etc. do not interfere with the spray arm rotation.

Run a rinse cycle to keep dishes moist if you do not plan to wash them soon.

Foods such as eggs. rice. pasta. spinach. and cooked cereals may be hard to remove if they are left to dry over a period of time.

Quiet operating tips

To avoid thumping/clattering noises during operation:

Make sure lightweight load items are secured in the racks.

Make sure pot lids and handles. pizza pans. cookie sheets. etc. do not touch interior walls or interfere with the rotation of the spray arm.

Load dishes so they do not touch one another.

NOTE: For built-in models. keep sink drain plugs closed during dishwasher operation to avoid noise transfer through drains.

The top rack is designed for cups. glasses. and smaller items.

Many items. up to 9" (22 cm). fit in the top rack. (See recommended loading patterns shown.)

NOTE: The features on your dishwasher rack may vary from the drawings shown.

You can stop your dishwasher anytime during a cycle.

Open the door slightly.

Wait for the spraying action to stop. Then open the door all the way. if needed.

Close the door and press START/RESUME to continue the cycle.

OR

Press CANCEL/DRAIN.

A 2-minute drain starts.

10 place setting

12placesetting Placeitemssoopenendsfacedownforcleaningand draining. Loadglassesintoprackonly.Thebottomrackisnot designed forglasses.Damagecanoccur. themoverthetinescanleadtobreakage andwaterspots. China. rystal. ndotherdelicateitemsmustnottoucheach otherduringdishwasher operation.Damagemayoccur. Loadlightweight plasticitemsinthetoprackonly.Only plasticitemsmarked"dishwasher safe"arerecommended. themduringthecycle. Toavoidchipping. onotletstemware touchotheritems. Smallbowls. ans. ndotherutensilscanbeplacedinthe

Cup shelves (on some models}

Fold down the extra shelf on the left-hand or right-hand side of the top rack to hold additional cups. stemware or long items such as utensils and spatulas.

NOTE: The features on your dishwasher may vary from those shown below.

Light item clips (on some models)

The light item clips hold lightweight plastic items such as cups. lids. or bowls in place during washing.

To move a clip

Pull the clip up and off the tine.

Reposition the clip on another tine.

Side clip (on some models)

The side clip holds lightweight plastic items such as cups. lids. or bowls in place during washing.

To move a clip

Pull the clip up and off horizontal rack wire.

Reposition the clip on another horizontal rack wire.

Utensil clip (on some models)

The utensil clip holds specialty cooking items (wooden spoons. spatulas. and similar items).

To move a clip

Pull the clip up and off horizontal rack wire.

Reposition the clip on another horizontal rack wire.

Adjustable 2-position top rack (on some models}

You can raise or lower the top rack to fit tall items in either the top or bottom rack. Raise the top rack to accommodate items up to 9" (22 cm) in the top rack and 13" (33 cm) in the bottom rack. or lower the top rack to accommodate items up to 11" (28 cm) in both the top and bottom racks. Two adjusters are located on each side of the top rack. Each adjuster has 2 preset positions.

The high and low positions are marked on the adjuster.

To adjust the top rack

Hold the top rack with one hand near the adjuster.

With the other hand. pull out the top of the adjuster.

Raise or lower the rack to one of the preset positions.

Release the adjuster.

Repeat the steps for the remaining adjusters.

NOTE: The top rack must be level.

The bottom rack is designed for plates. pans. casseroles. and utensils.

Many items. up to 13" (33 cm) tall. fit in the bottom rack. (See recommended loading patterns shown.)

NOTE: The features on your dishwasher rack may vary from the drawings shown.

Load cookie sheets. cake pans. and other large items at the sides and back. Loading such items in front can keep the water spray from reaching the detergent dispenser.

10 place setting

12 place setting

Do not load glasses. cups. or plastic items in the bottom rack. Load small items in the bottom rack only if they are secured in place.

Load plates. soup bowls. etc. between tines.

Overlap the edges of plates for large loads.

Load soup. cereal. and serving bowls in the rack in a variety of ways depending upon their size and shape. Load bowls securely between the rows of tines. Do not nest bowls because the spray will not reach all surfaces.

Mixed load

Secure heavily soiled cookware face down in the rack.

Make sure pot handles and other items do not stop rotation of the spray arm(s). The spray arm(s) must move freely.

Do not load items between the bottom rack and the side of the dishwasher tub because they might block the water inlet opening.

Fold-down tines (on some modems}

You can fold down one row of tines at the back of the bottom rack.

Grasp the tip of the tine that is in the tine holder.

Gently pull the tine out of the tine holder.

Lay the row of tines down in the rack to make room for larger dishes. bowls. pots. pans or roasters.

Utensil load

Load the silverware basket while it is in the dishwasher or take the basket out for loading on a counter or table top.

Style I (on some models)

Mix items in each section of the basket with some pointing up and some down to avoid nesting. Spray cannot reach nested items.

IMPORTANT: Always load items (knives. skewers. etc.) pointing down.

Use suggested loading patterns as shown to increase the washability of your silverware. if your silverware basket has these covers.

If your silverware basket does not have covers. or when covers are up. mix items in each section of the basket with some pointing up and some down to avoid nesting. Spray cannot reach nested items.

IMPORTANT: Always load items (knives. skewers. etc.) pointing down.

The silverware basket can be hung on the door or on the bottom rack (see illustration).

NOTES:

Do not load silver or silver-plated silverware with stainless steel. These metals can be damaged by contact with each other during washing.

Some foods (such as salt. vinegar. milk products. fruit juices. etc.) can pit or corrode silverware.

Run a rinse cycle if you do not have a full load to wash immediately.

Unload or remove the basket before unloading the racks to avoid spilling water droplets onto the silverware.

Style 2 (on some models) ANYWARE TM PLUS silverware basket

To open the silverware basket Unlock the latch.

NOTE: Be sure the cover is completely latched before pulling out the bottom rack and before closing the dishwasher door.

Place small items such as baby bottle caps. jar lids. corncob holders. etc. in the section(s) with hinged cover(s). Close the cover to hold small items in place.

The silverware basket can also be placed inside the bottom rack.

To remove the basket from the door

Grasp the silverware basket by the handle. Slide it toward the top of the door.

Lift the basket off the holding buttons.

To replace the basket in the door

Set the silverware basket on the holding buttons.

Slide the basket toward the bottom of the door until it locks into place.

NOTES:

Do not load silver or silver-plated silverware with stainless steel. These metals can be damaged by contact with each other during washing.

Some foods (such as salt. vinegar. milk products. fruit juices. etc.) can pit or corrode silverware.

Run a rinse cycle if you do not have a full load to wash immediately.

Unload or remove the basket before unloading the racks to avoid spilling water droplets onto the silverware.

DISHWASHERUSE

The detergent dispenser has two sections.

The smaller Pre-Wash section empties detergent into the dishwasher when you close the door. The larger Main Wash section automatically empties detergent into the dishwasher during the wash. (See the "Cycle Selection Charts.")

Filling the dispenser

If the dispenser cover is closed. open the cover by moving the cover latch to the right.

A. Cover latch B. Main Wash section C. Pre-Wash section

Use automatic dishwashing detergent only. Other detergents can produce excessive suds that can overflow out of the dishwasher and reduce washing performance.

Add detergent just before starting cycle.

Store tightly closed detergent in a cool. dry place. Fresh automatic dishwasher detergent results in better cleaning.

NOTE: Do not use detergent with a rinse cycle.

Add the correct amount of detergent to the Main Wash section of the dispenser according to the chart below. If you are using a tablet detergent. it must be placed in the Main Wash section. (See "How much detergent to use.")

Add the correct amount of detergent to the Pre-Wash section of the dispenser. if needed. according to the chart below.

Close the dispenser cover.

It is normal for the cover to open partially when dispensing detergent.

NOTE: See the "Cycle Selection Charts" for which section to fill depending on the cycle selected.

How much detergent to use

The amount of detergent to use depends on the soil level of your dishes. hardness of your water. and the type of detergent.

If you use too little. dishes will not be clean. If you use too much in soft water. glassware will etch.

Water hardness can change over a period of time. Find out your water's hardness by asking your local water department. water softener company. or county extension agent.

Detergent Dispenser fill recommendations per dish load soil level and water hardness

Light Soil or Prerinsed Normal Soil Heavy Soil Water Hardness Pre-Wash Main Wash Pre-Wash Main Wash Pre-Wash section

Empty 6 tsp (30 mL) 2 tsp (10 mL) 9 tsp (45 mL) 7 tsp (35 mL) Fill above the Fill to Soft Water Fill cup Soft Water line line completely

2 tsp (10 mL) 6 tsp (30 mL) 4 tsp (20 mL) 9 tsp (45 mL) 7 tsp (35 mL) Fill to Soft Water Fill above the Fill to Hard Water Fill cup line Soft Water line line completely

Soft (0-2 grains per U.S. gallon)

Medium (2-6 grains per U.S. gallon)

Hard (7 grains per U.S. gallon and above)

Main Wash section

4 tsp (20 mL) Fill to Soft Water line

6 tsp (30 mL) Fill above the Soft Water line

8 tsp (40 mL) Fill to Hard Water line

4 tsp (20 mL) Fill to Hard Water line

9 tsp (45 mL) Fill cup completely

7 tsp (35 mL) Fill cup completely

9 tsp (45 mL) Fill cup completely

7 tsp (35 mL) Fill cup completely

NOTE: Fill amounts shown are for standard powdered detergent.

Amounts may vary if you use liquid or concentrated powdered detergent.

Tablet detergents should be placed in the main wash section of the detergent dispenser with the cover closed.

Follow instructions on the package when using liquid dishwasher detergent. concentrated powdered detergent or tablet detergent.

¸&iildii

IMPORTANT: Your dishwasher is designed to use a liquid rinse aid. The use of rinse aids greatly improves drying by allowing water to drain from the dishes after the final rinse. They also keep water from forming droplets that can dry as spots or streaks. Do not use a solid or bar-type rinse aid.

Clean up any spilled rinse aid with a damp cloth.

Filling the dispenser

Place the knob back into the opening and turn to the "Lock"

The rinse aid dispenser holds 5 oz (150 mL) of rinse aid. Under normal conditions. this will last for about 1 to 3 months.

Make sure the dishwasher door is fully open.

Turn the dispenser knob to "Open" and lift it out.

USERINSEAiDFOR BETTERDRYING Lock

A. Dispenser knob B. Indicator C. Indicator window

Rinse aid setting

The amount of rinse aid released into the final rinse can be adjusted.

For most water conditions. the factory setting of 2 will give good results. If you have hard water or notice rings or calcium spots on your glasses or dishes. try a higher setting.

Lock

Open

Pour rinse aid into the opening until the indicator points to "Full." Do not overfill. (When the rinse aid indicator drops to the "Add" level. add more rinse aid.)

Full

To adjust the setting

Remove the dispenser knob.

Turn the arrow adjuster inside the dispenser to the desired setting by either using your fingers or inserting a flat-blade screwdriver into the center of the arrow and turning.

Replace the dispenser knob.

Hot water dissolves and activates the dishwashing detergent.

Hot water also dissolves grease on dishes and helps glasses dry spot free. For best dishwashing results. water should be 120°F (49°C) as it enters the dishwasher.

Loads may not wash as well if the water temperature is too low. Water that is too hot can make some soils harder to remove and cause certain detergent ingredients not to function.

If your water heater is located far from the dishwasher. it may be necessary to run the hot water at the faucet closest to the dishwasher to minimize the amount of cold water in the water line.

To check water temperature Additional efficiency tips

Run hot water at the faucet closest to your dishwasher for at least 1 minute.

Place a candy or meat thermometer in a glass measuring cup.

Check the temperature on the thermometer as the water is running into the cup.

To save water and energy and time. do not rinse dishes before putting them into the dishwasher.

Use a low energy. quick. or short cycle whenever possible.

These cycles use less hot water and energy than a normal cycle.

Use a delay feature (on some models) to run your dishwasher during off-peak hours. Local utilities recommend avoiding heavy usage of energy at certain times of day.

During the summer. run your dishwasher at night. This reduces daytime heat buildup in the kitchen.

Use the energy-saving dry option whenever possible.

Allow longer drying times (overnight) when using these options. Use a rinse aid to improve drying.

Use cycles or options that add extra heat to the wash or rinse portion of the cycle only when needed.

Run your dishwasher with full loads.

Run a rinse cycle after meals until the dishwasher is full.

If your home is equipped with a water softener. you may want to avoid starting the dishwasher during the regeneration of the softener. since this may contribute to poor wash performance.

Select the wash cycle and options desired and press START/ RESUME. The dishwasher starts filling once you press START/ RESUME. unless you select a delay wash. You can change cycles and options as the machine is filling.

After completing a wash cycle. the dishwasher remembers the cycle and options.

It uses the same cycle and options again in the next wash cycle. if you press only START/RESUME.

NOTE: If the door is opened during a cycle or the power is interrupted. the Start/Resume indicator flashes. The cycle will not resume until the door is closed and Start/Resume is pressed.

A "O" shows what steps are in each cycle. Your model may have some or all of the cycles shown.

Display time is for models with the dual digit display on the console.

These models meet the ENERGY STARguidelines for energy efficiency.

Temperatures indicate where extra heat is added.

The cycle countdown (on some models) pauses at these points until water reaches the temperature.

Water usage is shown in U.S. gallons/liters.

Pots & Pans

Use this cycle for hard-to-clean. heavily soiled pots. pans. casseroles. and regular tableware.

During the wash. the wash action will repeatedly pause for several seconds.

Initial display time after rotating clock pattern: 92-99 min.

Use both detergent dispenser sections.

Pre Main Rinse Wash

O°F (6O°C)

Final Dry Mini Water Heated mum Usage Rinse Time (gal/L) (min)

6.9-7. / 140°F Light 26.1-29.6 (60°C) soil

Normal

Use this cycle for loads with normal amounts of food soil. (The energy-usage label is based on this cycle.) During the wash. the wash action will repeatedly pause for several seconds.

Initial display time after rotating clock pattern: 64-84 min.

Use both detergent dispenser sections.

Pre Main Purge Rinse Final Dry Mini Water Wash Heated mum Usage Rinse Time (gal/L) (min)

5.6-6. / 120°F 140°F Light 21.2-25.7 (49°0) (6O°C) soil

Light (on some models)

Use this cycle for lightly soiled items or china and crystal.

During the wash. the wash action will repeatedly pause for several seconds.

Initial display time after rotating clock pattern: 68-81 min.

Use main detergent dispenser section.

Rinse Main Purge Rinse Final Dry Mini Water Wash Heated mum Usage Rinse Time (gal/L) (min)

5.9-6. / 120°F 135°F cycled Light 22.3-25.7 (49°0) (57°C) soil

GLASS XPRESS TM cycle (on some models)

Use this cycle to quickly wash prerinsed glasses or dish loads.

This cycle does not dry.

NOTE: Time and water use do not vary in this cycle.

Initial display time after rotating clock pattern: 29 min.

Use main detergent dispenser section.

Pre Main Rinse Final Dry Mini Water Wash Heated mum Usage Rinse Time (gal/L) (min)

6.9/26.0

Rinse Only

Use this rinse cycle for rinsing dishes. glasses. and silverware that will not be washed right away.

Initial display time after rotating clock pattern: 3 min.

Do not use detergent with this cycle.

Pre Main Rinse Final Dry Time Water Wash Heated (min) Usage Rinse (gal/L)

1.8-/6.8

+If the incoming water is less than the recommended temperature or food soils are heavy. the cycle will automatically compensate by adding time. heat. and water as needed.

Anytime during a cycle. press CANCEL/DRAIN.

Your dishwasher starts a 2-minute drain. if needed. and clears all indicators.

NOTE: If your dishwasher does not need draining. the dishwasher stops and clears all indicators.

To stop the drain

You can press CANCEL!DRAIN again to stop the drain immediately.

Be sure to drain the dishwasher before starting a new cycle.

To clear the indicators

Press CANCEL!DRAIN before starting the dishwasher to clear all options and cycles.

During the first fill of a cycle

Press a new cycle and/or options.

Check the detergent dispensers.

They must be filled properly for the new cycle.

Press START/RESUME.

After the first fill of a cycle

Press CANCEL!DRAIN.

Your dishwasher starts a 2-minute drain. if needed. and clears all indicators.

NOTE: If your dishwasher does not need draining. the dishwasher stops and clears all indicators.

Check the detergent dispensers.

They must be filled properly for the new cycle.

Press a new cycle and/or options.

Press START/RESUME. (The door must be closed.)

You can add an item anytime before the main wash starts. Open the door and check the detergent dispenser.

If the cover is still closed. you can add items.

To add items

Lift up the door latch to stop the cycle. Wait for the spraying action to stop before opening the door.

Open the door. If the detergent dispenser cover is still closed. add the item.

Close the door firmly until it latches.

Press START/RESUME.

The dishwasher resumes the cycle after a 5-second pause.

You can customize your cycles by pressing an option.

If you change your mind. press the option again to turn off the option. or select a different option if desired.

You can change an option anytime before the selected option begins. For example. you can turn off the drying option anytime before drying begins.

After a wash cycle. the dishwasher remembers the options used.

It uses the same options in the next wash cycle. if you press only START/RESU M E.

Soak & Scour (on some models)

Select this option to presoak your dishes for 4 hours in your dishwasher instead of presoaking them in the sink. When you select Soak & Scour. the dishwasher fills and then sprays for 8 minutes.

It will then pause for 16 minutes while dishes soak. and then spray for 90 seconds to keep dishes wet. Pausing for 16 minutes and spraying for 90 seconds are repeated for 4 hours.

At the end of the 4 hours. the dishwasher drains and then starts the cycle you have selected.

The Main Wash heating time will be extended to allow the water temperature to reach 145°F (63°C).

This presoaking uses only one additional fill of water and does not require special detergent.

Use standard detergent according to cycle recommendations.

Hi-Temp Wash

Select this option to increase the target water temperature during the wash portions of the cycle. Hi-Temp Wash raises the target water temperature to 145°F (63°C) in the main wash. Heating the water helps improve washing results. Hi-Temp Wash is useful when loads contain baked-on food.

This option adds heat. wash time and water to the cycle.

NOTE: Hi-Temp Wash is an option with Pots & Pans and Normal cycles. Selecting Hi-Temp Wash with the Sani Rinse option has no effect. as it already raises the main wash to 145°F (63°C).

Sani Rinse

Select this option to raise the water temperature in the final rinse to approximately 155°F (68°C). The Sani Rinse option adds heat and time to the cycle. The Main Wash heating time will be extended to reach 145°F (63°C). In the Pots & Pans and Normal cycles. this high-temperature rinse sanitizes your dishes and glassware in accordance with NSF/ANSl Standard 184 for Residential Dishwashers.

Certified residential dishwashers are not intended for licensed food establishments.

NOTE: Use the Sani Rinse option with Pots & Pans and Normal cycles. Only these sanitization cycles have been designed to meet the NSF/ANSl requirements.

Heated Dry

Select this option to dry dishes with heat.

Switching off Heated Dry skips the dry period. This is useful when loads contain plastic dinnerware that may be sensitive to high temperatures.

The dishes take longer to dry and some spotting may occur. Some items (such as plastics) may need towel drying.

For best drying. use a liquid rinse aid.

NOTE: Heated Dry is an option with all cycles. except GLASS XPRESS TM and Rinse Only cycles.

Heated Dry begins automatically with all cycles unless you switch it off.

Lock

Use the lock to avoid unintended use of the dishwasher.

You can also use the lock feature to avoid unintended cycle or option changes during a cycle.

HATD DRY

When the lock is lit. all buttons are disabled.

NOTES:

The dishwasher door can be opened while the controls are locked.

You can turn on the lock while the dishwasher is running. If you open the door. unlock the controls and press START/ RESUME to restart. You can lock controls again. if desired.

To turn on the lock Press and hold HEATED DRY for 4 seconds.

The lock glows.

If you press any pad while your dishwasher is locked. the light flashes 3 times and the selection is ignored.

To turn off the lock Press and hold HEATED DRY for 4 seconds.

The light turns off.

Delay start

Select this option to run your dishwasher at a later time or during off-peak hours. You can add items to the load anytime during the delay countdown.

After adding items. close the door firmly until it latches. The delay countdown will not continue if the door is not latched.

Press START/RESUME.

If the door is unlatched. the Start/Resume indicator flashes. The delay countdown stops until you latch the door and press START/RESUME.

Models with 4 Hour Delay To delay the start

Press DELAY for a 4-hour delay. The number above or to the left of the 4 Hour Delay pad glows.

Select a wash cycle and option or skip to Step 3 to use the cycle and options selected for last cycle.

Press START/RESUME. (The door must be closed.) The delay countdown starts. and the cycle will begin after 4 hours.

NOTES:

To cancel the delay and cycle. press CANCEL/DRAIN.

To cancel the delay and start the cycle. press START/ RESUME.

Models with 2-4-6 hour Delay To delay the start

Press DELAY 1 time for a 2-hour delay. 2 times for a 4-hour delay. or 3 times for a 6-hour delay. The number glows above the Delay pad.

Select a wash cycle and option or skip to Step 3 to use the cycle and options selected for last cycle.

Press START/RESUME. (The door must be closed.) The Delay countdown starts. and the cycle will begin after the selected number of hours.

NOTES:

To cancel the delay and cycle. press CANCEL!DRAIN.

To cancel the delay and start the cycle. press START/ RESUME.

Follow the progress of your dishwasher with the Cycle Status indicators.

SensingWashingDrying CleanSanitized O---O----O----O----O

NOTE: Your model may have some or all of the indicators shown above.

Sensing (on some models)

Sensing glows during the Sensing part of the cycle. Your dishwasher senses soil level during soil sensing intervals and water temperature during water heating pause intervals.

Washing continues while Sensing occurs.

Clean

Clean glows when a cycle is finished. The light turns off when you open and close the door or press any button.

Sanitized

If you select the Sani Rinse option.

Sanitized glows when the Sani Rinse cycle is finished.

If your dishwasher did not properly sanitize your dishes. the light flashes at the end of the cycle. This can happen if the cycle is interrupted. or the water could not be heated to the required temperature.

The light goes off when you open and close the door or press any button.

This dishwasher is equipped with an optical sensor wash that detects water temperature and the amount of soil and detergent.

Wash cycles are adjusted based on what is sensed.

The dishwasher "senses" wash water quality during a series of pauses in the wash cycle. The sensor monitors water temperature and the amount of soil and detergent appearing in the wash water. It automatically adjusts the wash cycle for the best wash. Lightly soiled dishes will use less water and energy.

Heavily soiled dishes will get more water and increased temperature and wash time. This dishwasher will automatically adjust the sensor approximately once a year to your water quality.

IMPORTANT: The very first wash cycle after installation in your home will be adjusted to include an additional 2 rinses. This cycle must not be interrupted for proper sensor adjustment.

If this adjustment cycle is canceled or stopped before the Clean light comes on at the end of the cycle. the next wash cycle will repeat this sensor adjustment.

During drying. you can see steam escaping through the vent at the upper left corner of the door. This is normal as the heat dries your dishes.

IMPORTANT: The vapor is hot. Do not touch the vent during drying.

The overfill protection float (in the front right corner of the dishwasher tub) keeps the dishwasher from overfilling.

It must be in place for the dishwasher to operate.

Check under the float for objects that may keep the protector from moving up or down.

WASHINGSPECIALITEMS

If you have doubts about washing a particular item. check with the manufacturer to see if it is dishwasher safe.

Material Dishwasher Safe?/Oomments Material Dishwasher Safe?/Oomments

Aluminum Yes Pewter. Brass.

No High water temperature and detergents Bronze High water temperatures and detergent can affect finish of anodized aluminum. can discolor or pit the finish.

Disposable Aluminum

Do not wash throwaway aluminum pans in the dishwasher. These might shift during washing and transfer black marks to dishes and other items.

Bottles and Cans No

Wash bottles and cans by hand. Labels attached with glue can loosen and clog the spray arms or pump and reduce washing performance.

Disposable No Plastics Cannot withstand high water temperatures and detergents.

Plastics Yes

Always check manufacturer's recommendations before washing.

Plastics vary in their capacity to withstand high temperatures and detergents.

Load plastics in top rack only.

Cast Iron No

Seasoning will be removed. and iron will rust.

China/ Yes

Stoneware Always check manufacturer's recommendations before washing.

Antique. hand-painted. or over-the-glaze patterns may fade. Gold leaf can discolor or fade.

Crystal Yes

Always check manufacturer's recommendations before washing.

Some types of leaded crystal can etch with repeated washing.

Stainless Steel Yes

Run a rinse cycle if not washing immediately.

Prolonged contact with food containing salt. vinegar. milk products. or fruit juice can damage finish.

Sterling Silver or Silver Plate

Run a rinse cycle if not washing immediately.

Prolonged contact with food containing salt. acid. or sulfide (eggs. mayonnaise. and seafood) can damage finish.

Tin No

Can rust.

Gold No

Gold-colored flatware will discolor.

Glass Yes

Milk glass yellows with repeated dishwasher washing.

Hollow-Handle No Knives Handles of some knives are attached to the blade with adhesives which can loosen if washed in the dishwasher.

Wooden Ware No

Wash by hand. Always check manufacturer's instructions before washing.

Untreated wood can warp. crack. or lose its finish.

DISHWASHERCARE

Cleaning the exterior

In most cases. regular use of a soft. damp cloth or sponge and a mild detergent is all that is necessary to keep the outside of your dishwasher looking nice and clean.

If your dishwasher has a stainless steel exterior. a stainless steel cleaner is recommended.

Cleaning the interior

Hard water minerals can cause a white film to build up on the inside surfaces. especially just beneath the door area.

Do not clean the dishwasher interior until it has cooled. You may want to wear rubber gloves.

Do not use any type of cleanser other than dishwasher detergent because it may cause foaming or sudsing.

To clean interior

Make a paste with powdered dishwasher detergent on a damp sponge and clean.

OR

Use liquid automatic dishwasher detergent and clean with a damp sponge.

OR

See the vinegar rinse procedure in "Spotting and filming on dishes" in "Troubleshooting."

NOTE: Run a normal cycle with detergent after cleaning the interior.

Check the drain air gap anytime your dishwasher isn't draining well.

Some state or local plumbing codes require the addition of a drain air gap between a built-in dishwasher and the home drain system.

If a drain is clogged. the drain air gap protects your dishwasher from water backing up into it.

The drain air gap is usually located on top of the sink or countertop near the dishwasher.

To order a drain air gap. contact your local dealer; or call us or your designated service center and ask for Part Number 300096.

For more information. see "Assistance or Service."

NOTE: The drain air gap is an external plumbing device that is not part of your dishwasher.

The warranty provided with your dishwasher does not cover service costs directly associated with the cleaning or repair of the external drain air gap.

To clean the drain air gap

Clean the drain air gap periodically to ensure proper drainage of your dishwasher.

Follow the cleaning instructions provided by the manufacturer.

With most types. you lift off the chrome cover.

Unscrew the plastic cap. Then check for any soil buildup.

Clean if necessary.

Storing for the summer

Protect your dishwasher during the summer months by turning off the water supply and power supply to the dishwasher.

Winterizing your dishwasher

Protect your dishwasher and home against water damage due to freezing water lines. If your dishwasher is left in a seasonal dwelling or could be exposed to near freezing temperatures. have your dishwasher winterized by authorized service personnel.

TROUBLESHOOTING

First try the solutions suggested here and possibly avoid the cost of a service call

Dishwasher is not operating properly

Dishwasher does not run or stops during a cycle

Is the Start/Resume indicator flashing?

Opening the door or interrupting the power stopped the cycle. Close the door and press START/RESUME.

Does the Start/Resume indicator flash 3 times when you press START/RESUME?

The dishwasher is waiting for you to open the door after the last cycle. Open and close the door. then press START/RESUME.

Is the door closed tightly and latched?

(NOTE: On models with a dual-digit display. the control displays "- -" during a cycle if it believes the door is not latched.)

Is the right cycle selected?

Refer to the "Cycle Selection Charts."

Is there power to the dishwasher?

Has a household fuse blown. or has a circuit breaker tripped?

Replace the fuse or reset the circuit breaker. If the problem continues. call an electrician.

Has the motor stopped due to an overload?

The motor automatically resets itself within a few minutes.

If it does not restart. call for service.

Is the water shutoff valve (if installed) turned on?

It is normal for certain cycles to repeatedly pause for several seconds during the main wash.

Clean light is flashing

The dishwasher has malfunctioned.

Call for service to check heater circuit.

Dishwasher will not fill

Is the overfill protection float able to move up and down freely? Press down to release.

Dishwasher seems to run too long

Is the water supplied to the dishwasher hot enough?

The dishwasher runs longer while heating water. Refer to the "Dishwasher Efficiency Tips" section.

A delay automatically occurs in some wash and rinse cycles until the water reaches the proper temperature.

Water remains in the dishwasher

Is the cycle complete?

Detergent remains in the covered section of the dispenser

Is the cycle complete?

Is the detergent lump-free?

Replace detergent if necessary.

White residue on the front of the access panel

Was too much detergent used? Refer to the "Detergent Dispenser" section.

Is the brand of detergent making excess foam? Try a different brand to reduce foaming and eliminate buildup.

Odor in the dishwasher

Are dishes washed only every 2 or 3 days? Run a rinse cycle once or twice a day until you have a full load.

Does the dishwasher have a new plastic smell? Run a vinegar rinse as described in "Spotting and filming on dishes" later in this Troubleshooting guide.

Condensation on the kitchen counter (built-in models)

Is the dishwasher aligned with the countertop?

Moisture from the vent in the dishwasher console can form on the counter.

Refer to the Installation Instructions for more information.

Dishes are not completely clean

Food soil left on the dishes

Is the dishwasher loaded correctly?

Refer to the "Dishwasher Loading" section.

Is the water temperature too low? For best dishwashing results. water should be 120°F (49°C) as it enters the dishwasher.

Refer to the "Dishwasher Efficiency Tips" section.

Did you use the correct amount of fresh detergent?

Use recommended dishwasher detergents only. Refer to the "Detergent Dispenser" section.

Detergent must be fresh to be effective.

Store detergent in a cool. dry area. Heavy soil and/ or hard water generally require extra detergent.

Do you have hard water? You may need to increase the amount of detergent you are using. Refer to the "Detergent Dispenser" section.

Also. you may need to switch to a detergent with a phosphorus content of 8.7%.

Is detergent caked in dispenser?

Use fresh detergent only. Do not allow detergent to sit for several hours in a wet dispenser.

Clean dispenser when caked detergent is present.

Is the pump or spray arm clogged by labels from bottles and cans?

Is the home water pressure high enough for proper dishwasher filling? Home water pressure should be 20 to 120 psi (138 to 828 kPa) for proper dishwasher fill. If you have questions about your water pressure. call a licensed. qualified plumber.

Are high suds slowing the wash arm? Do not use soap or laundry detergents.

Use recommended dishwasher detergents only.

Spots and stains on dishes

Spotting and filming on dishes

Is your water hard or is there a high mineral content in your water? Conditioning the final rinse water with a liquid rinse aid helps eliminate spotting and filming.

Keep the rinse aid dispenser filled.

Is the water temperature too low? For best dishwashing results. water should be 120°F (49°C) as it enters the dishwasher.

Refer to the "Dishwasher Efficiency Tips" section.

Did you use the correct amount of effective detergent?

Use recommended dishwasher detergents only. Refer to the "Detergent Dispenser" section.

Detergent must be fresh to be effective.

Store detergent in a cool. dry area. Heavy soil and/ or hard water generally require extra detergent.

Is the home water pressure high enough for proper dishwasher filling? Home water pressure should be 20 to 120 psi (138 to 828 kPa) for proper dishwasher fill. If you have questions about your water pressure. call a licensed. qualified plumber.

NOTE: To remove spots and film from dishes. try a white vinegar rinse. This procedure is intended for occasional use only. Vinegar is an acid. and using it too often could damage your dishwasher.

Wash and rinse dishes. Use an air-dry or an energy saving dry option.

Remove all silverware or metal items.

Put 2 cups (500 mL) white vinegar in a glass or dishwasher-safe measuring cup on the bottom rack.

Run the dishwasher through a complete washing cycle using an air-dry or an energy saving dry option.

Do not use detergent.

Vinegar will mix with the wash water.

Silica film or etching (silica film is a milky. rainbow colored deposit; etching is a cloudy film)

Sometimes there is a water/chemical reaction with certain types of glassware.

This is usually caused by some combination of soft or softened water. alkaline washing solutions. insufficient rinsing. overloading the dishwasher. and the heat of drying. It might not be possible to avoid the problem. except by hand washing.

To slow this process use a minimum amount of detergent but not less than 1 tb (15 g) per load. Use a liquid rinse aid and underload the dishwasher to allow thorough rinsing. Silica film and etching are permanent and cannot be removed.

Do not use heated drying.

White spots on cookware with nonstick finish

Has the dishwasher detergent removed cookware seasoning?

Reseason cookware after washing in the dishwasher.

Brown stains on dishes and dishwasher interior

Does your water have high iron content?

Rewash dishes using 1-3 tsp (5-15 mL) of citric acid crystals added to the covered section of the detergent dispenser. Do not use detergent.

Follow with a Normal wash cycle with detergent.

If treatment is needed more often than every other month. the installation of an iron removal unit is recommended.

Black or gray marks on dishes

Are aluminum items rubbing dishes during washing?

Disposable aluminum items can break down in the dishwasher and cause marking. Hand wash these items.

Remove aluminum markings by using a mild abrasive cleaner.

Orange stains on plastic dishes or dishwasher interior

Are large amounts of tomato-based foods on dishes placed in the dishwasher?

Stains gradually fade over time. Regular use of heated drying will slow fading. Stains will not affect dishwasher performance.

Regular use of a rinse cycle and an air-dry or energy-saving dry option will reduce the likelihood of staining.

Dishes do not dry completely

Dishes are not dry

Did you load your dishwasher to allow proper water drainage?

Do not overload.

Refer to the "Dishwasher Loading" section.

Use a liquid rinse aid to speed drying.

Are the plastics wet? Plastics often need towel drying.

Is the rinse aid dispenser empty?

Refer to the "Rinse Aid Dispenser" section.

Did you use an air-dry or energy-saving dry option?

Use a heated drying option for dryer dishes.

Dishes are damaged during a cycle

Chipping of dishes

Did you load the dishwasher properly?

Load the dishes and glasses so they are stable and do not strike together from washing action. Minimize chipping by moving the rack in and out slowly.

NOTE: Antiques. feather-edged crystal. and similar types of china and glassware might be too delicate for automatic dishwashing.

Wash by hand.

Noises

Grinding. grating. crunching or buzzing sounds

A hard object has entered the wash module (on some models). When the object is ground up. the sound should stop. If the noise persists after a complete cycle. call for service.

ASSISTANCEORSERVICE

Before calling for assistance or service. please check "Troubleshooting." It may save you the cost of a service call. If you still need help. follow the instructions below.

When calling. please know the purchase date and the complete model and serial number of your appliance.

This information will help us to better respond to your request.

If you need replacement parts

If you need to order replacement parts. we recommend that you use only FSP° replacement parts. These parts will fit right and work right because they are made with the same precision used to build every new WHIRLPOOL ®appliance.

To locate FSP replacement parts in your area. call us or your nearest designated service center.

In Canada. call 1-800-807-6777. or your nearest designated service center.

Call the Whirlpool Customer eXperience Center toll free: 1-800-253-1301.

Our consultants provide assistance with:

Features and specifications on our full line of appliances.

Installation information.

Use and maintenance procedures.

Accessory and repair parts sales.

Specialized customer assistance (Spanish speaking. hearing impaired. limited vision. etc.).

Referrals to local dealers. repair parts distributors. and service companies.

Whirlpool designated service technicians are trained to fulfill the product warranty and provide after warranty service. anywhere in the United States.

To locate the Whirlpool designated service company in your area. you can also look in your telephone directory Yellow Pages.

For further assistance

If you need further assistance. you can write to us with any questions or concerns at:

Whirlpool Brand Home Appliances Customer eXperience Center 553 Benson Road Benton Harbor. M149022-2692

Please include a daytime phone number in your correspondence.

Call our Whirlpool Canada LP Customer Interaction Centre toll free: 1-800-807-6777.

Our consultants provide assistance with:

Features and specifications on our full line of appliances.

Warranty information.

Use and maintenance procedures.

Accessory and repair parts sales.

Referrals to local dealers. repair parts distributors. and service companies.

Whirlpool Canada LP designated service technicians are trained to fulfill the product warranty and provide after-warranty service. anywhere in Canada.

For further assistance

If you need further assistance. you can write to us with any questions or concerns at: Customer Interaction Centre Whirlpool Canada LP 1901 Minnesota Court Mississauga.

Ontario L5N 3A7

Please include a daytime phone number in your correspondence.

WHIRLPOOLCORPORATIONMAJORAPPLIANCEWARRANTY

ONE YEAR LIMITED WARRANTY

For one year from the date of purchase. when this major appliance is operated and maintained according to instructions attached to or furnished with the product.

Whirlpool Corporation or Whirlpool Canada LP (hereafter "Whirlpool") will pay for Factory Specified Parts and repair labor to correct defects in materials or workmanship.

Service must be provided by a Whirlpool designated service company.

This limited warranty applies only when the major appliance is used in the country in which it was purchased.

ITEMS WHIRLPOOL WILL NOT PAY FOR

Service calls to correct the installation of your major appliance. to instruct you how to use your major appliance. to replace or repair house fuses or to correct house wiring or plumbing.

Service calls to repair or replace appliance light bulbs. air filters or water filters. Those consumable parts are excluded from warranty coverage.

Repairs when your major appliance is used for other than normal. single-family household use.

Damage resulting from accident. alteration. misuse. abuse. fire. flood. acts of God. improper installation. installation not in accordance with electrical or plumbing codes. or use of products not approved by Whirlpool.

Any food loss due to refrigerator or freezer product failures.

Replacement parts or repair labor costs for units operated outside the United States or Canada.

Pickup and delivery. This major appliance is designed to be repaired in the home.

Repairs to parts or systems resulting from unauthorized modifications made to the appliance.

Expenses for travel and transportation for product service in remote locations.

10. The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed in accordance with published installation instructions.

11. Replacement parts or repair labor costs when the major appliance is used in a country other than the country in which it was purchased.

DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES CUSTOMER'S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR AS PROVIDED HEREIN. IMPLIED WARRANTIES.

INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW. WHIRLPOOL SHALL NOT BE LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES.

SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES. OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS. SO THESE EXCLUSIONS OR LIMITATIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER RIGHTS. WHICH VARY FROM STATE TO STATE OR PROVINCE TO PROVINCE.

Outside the 50 United States and Canada. this warranty does not apply. Contact your authorized Whirlpool dealer to determine if another warranty applies.

If you need service. first see the "Troubleshooting" section of the Use & Care Guide. After checking "Troubleshooting. additional help can be found by checking the "Assistance or Service" section or by calling Whirlpool.

In the U.S.A. call f-800-253-1301.

In Canada. call 1-800-807-6777.

12/o5

Keep this book and your sales slip together for future reference.

You must provide proof of purchase or installation date for in-warranty service.

Write down the following information about your major appliance to better help you obtain assistance or service if you ever need it.

You will need to know your complete model number and serial number. You can find this information on the model and serial number label located on the product.

Dealer name

Address

Phone number

Model number

Serial number

Purchase date

DU1015

STATUS

Washing Dlyiny Clean

SEAR1/ CANCEL/ RESUME DRAIN

CYCLES OPTIONS + 8 00o

ROTS& NORMAL RINSE NIoTE/aP NEATED PANS ONLY WASH DRY

4 HOURDELAY

DELAY 1

DU1055. DU1061

Washing Dlying Clea Sanitized0 STATUS

I CANCEL/ RESUME DRAIN CYCLES OPTUONS

0000 000o

ROTS& NORMAL LIGHT RINSE HIRMR SANI HEATED PANS ON WASH RINSE DRY

DELAY

DU1100. DU1101. DUL240

CYCLES

QQQQ

POTS& NORMAL EIGHT RINSE PANE ONEv

S0akiflgWashnDrying Clean Sanitized S T A T U S SenwIg C)

OPTmONS O O O

+. 3c.

SOAK& HIMEMP SANI HEAPED DELAY START/ SCOUR WAS RINSE DRY RESUME

DUl145

CYCLES

QQQQ

POTS& NORMAL LIGHT RINSE PANS ONLY

SmlsmgWasMnR DIying Clean Sanitized

OPTIONS O0

HIUEMP PANI HEATED DELA START/ WASH RINSE DRY RESUME

DU1148. DU1200. DU1201. DU1245. DU1248

CYCLES

00000

POTS& NORMAL LIGHT GMS. RINSE PANS XPNS ONLY

SeosiT1g WashngDrying Clean SaMtzed S T A T g

OPTIONS QO O O

+ cs'u

HI-TRMP SANI HEATED DELAY START/ WASH RINSE DRY RESUME

W10073760B

+ 2007 Whirlpool Corporation.

All rights reserved. ® Registered Trademark/TM Trademark of Whirlpool.

U. .. Whirlpool Canada LP Licensee in Canada Tous droits reserves. ® Marque depose/TM Marque de commerce de Whirlpool.

U.S.A. emploi sous licence par Whirlpool Canada LP au Canada

2/07 Printed in U. . .

Imprim aux E. U.



Newest Added: WDT910SSYB1 GMC305PDQ5 ED5VBEXTL00 RBS277PVQ02 WFG361LVB1

Whirlpool DU1055XTSS2 | Pages: 44 | File type: PDF | Filename: 60805674_du1055xtss2.pdf | Size: 5.07 MB | Language: English | Other documents: 1 files.

Download User Manual

Contact us

Whirlpool in United States

1-866-698-2538 Monday-Friday: 8:00 AM to 8:00 PM EST
