CHECK FOR CONCEALED DAMAGE
FILE CL
AIM WITH DELIVERING FREIGHT CARRIER
Sinks manufactured by ADVANCE TABCO
®
are designed and constructed for the use of
liquid containment. Suggested applications include Food Preparation, Manufacturing, Cooking,
Laboratory and Service and the like. ADVANCE TABCO
®
does not recommend product use for activities
employing harsh and active chemicals. Please consult factory regarding unusual applications.
Installation Instructions for
BUDGET SINKS
Step 4:
Complete plumbing connection to drain and water supply.
Remove aerator to “flush” system then reconnect. Check
connection for leaks.
200 Heartland Boulevard, Edgewood, NY 11717-8380
© ADV
ANCE T
ABCO, JUNE 2005
• (1) Laundry/Utility Sink
• (4) legs with Adjustable Feet
• (1) Drain Assembly
• (4) Set Screws
• 5/32” Allen Wrench
• Pipe Wrench
• Adjustable Wrench
• Level
Step 1:
Remove legs and drain located in bottom carton. Turn Sink
upside down and remove the “Red Cap” where set screws can be
found (Illustration 1).
Step 2:
Insert legs into Gusset (Illustration 2), and secure with
Set Screws
(Illustration 2a).
Step 3:
Turn Sink to upright
position. Pre-Plumb
Drain and Faucet.
Position Sink at desired
location and level by
turning adjustable Bullet
Feet (Illustration 3).
CONTENTS INCLUDE:
TOOLS REQUIRED:
Illustration 1
“RED CAP”
Located in Leg Gusset
Illustration 2
Illustration 2a
Illustration 3
Continued >>
