Miele K 31242 UiF – Refrigeration User Manual

Operating and installation

instructions

Refrigerators

To avoid the risk of accidents or damage to the appliance it is essen-

tial to read these instructions before it is installed and used for the

first time.

en-GB M.-Nr. 10 838 150

Contents

Warning and Safety instructions...................................................................... 5

Caring for the environment .............................................................................. 14

Saving energy .................................................................................................... 15

Guide to the appliance...................................................................................... 17

Control panel....................................................................................................... 17

Accessories ......................................................................................................... 19

Accessories supplied ..................................................................................... 19

Optional accessories...................................................................................... 19

Switching on and off ......................................................................................... 21

Before using for the first time.............................................................................. 21

Cleaning the appliance................................................................................... 21

Switching off for longer periods of time .............................................................. 22

The correct temperature................................................................................... 23

...in the refrigerator section ................................................................................ 23

...in the freezer compartment ............................................................................. 23

Temperature display ............................................................................................ 24

Setting the temperature....................................................................................... 24

Freezer compartment ..................................................................................... 24

Using Super cool ............................................................................................... 25

SuperCool function ............................................................................................. 25

Door alarm ......................................................................................................... 26

Door alarm........................................................................................................... 26

Switching the door alarm off early ................................................................. 26

Selecting further settings ................................................................................. 27

Settings mode ..................................................................................................... 27

Activating or deactivating the lock ................................................................. 27

Storing food in the refrigerator section........................................................... 28

Different storage zones ....................................................................................... 28

Food which is not suitable for storage in the refrigerator section ....................... 29

Notes on buying food.......................................................................................... 30

Storing food correctly.......................................................................................... 30

Adjusting the interior fittings............................................................................ 31

Adjusting the door shelf/bottle shelf ................................................................... 31

Moving the shelves.............................................................................................. 31

Adjusting the bottle holder .................................................................................. 31

Moving the charcoal filters .................................................................................. 32

Contents

Freezing and storing food (depending on model) .......................................... 33

Using the freezer compartment........................................................................... 33

Freezing fresh food.............................................................................................. 33

Storing frozen food.............................................................................................. 33

Home freezing ..................................................................................................... 34

Before placing food in the appliance ............................................................. 35

Placing frozen goods in the freezer ................................................................ 35

Approx. 24hours after placing fresh food in the freezer compartment ......... 35

Storage time for frozen food................................................................................ 35

Defrosting frozen goods ...................................................................................... 36

Cooling drinks ..................................................................................................... 36

Using accessories ............................................................................................... 36

Defrosting........................................................................................................... 37

Before defrosting............................................................................................ 37

To defrost ....................................................................................................... 38

After defrosting............................................................................................... 38

Cleaning and care ............................................................................................. 39

Cleaning agents................................................................................................... 39

Preparing the refrigeration appliance for cleaning .............................................. 40

Cleaning the interior and accessories ................................................................. 41

Cleaning the door seal ........................................................................................ 42

Cleaning the ventilation gaps .............................................................................. 42

After cleaning ...................................................................................................... 42

Replacing the charcoal filters .............................................................................. 43

Problem solving guide ...................................................................................... 44

Noises................................................................................................................. 50

Service................................................................................................................ 51

Contact in the event of a fault ............................................................................. 51

EPREL database ................................................................................................. 51

Warranty .............................................................................................................. 51

Installation.......................................................................................................... 52

Installation ........................................................................................................... 52

Side-by-side installation................................................................................. 52

Location.......................................................................................................... 53

Ventilation....................................................................................................... 54

Furniture door panel ....................................................................................... 54

Before installing the appliance ....................................................................... 56

Contents

Building-in dimensions ....................................................................................... 57

Installation dimensions................................................................................... 57

Changing the door hinging.................................................................................. 59

Adjusting the appliance door hinges................................................................... 62

Limiting the opening angle of the appliance door............................................... 62

Installing the appliance........................................................................................ 63

To install the appliance, you will need the following tools:............................. 63

Parts required for installation ......................................................................... 63

Preparing the appliance ................................................................................. 63

Positioning the refrigeration appliance ........................................................... 65

Aligning the refrigeration appliance................................................................ 66

Fitting a continuous furniture plinth facing..................................................... 67

Securing the appliance in the niche ............................................................... 68

Fitting the furniture door................................................................................. 68

Electrical connection ........................................................................................... 73

Warning and Safety instructions

This refrigeration appliance complies with current safety require-

ments. Inappropriate use can, however, lead to personal injury and

material damage.

Please read the operating and installation instructions carefully be-

fore using the refrigeration appliance for the first time. They con-

tain important information on safety, installation, use and mainten-

ance. This is to protect yourself from injury, and from damaging

your refrigeration appliance.

In accordance with standard IEC60335-1, Miele expressly and

strongly advises that you read and follow all information provided

on installing the refrigeration appliance, as well as the safety notes

and warnings.

Miele cannot be held liable for injury or damage caused by non-

compliance with these instructions.

Keep these operating and installation instructions in a safe place

and pass them on to any future owner.

Correct application

 This refrigeration appliance is intended for use in the home and in

similar environments, for example

– in shops, offices and similar work settings

– by the guests in hotels, motels, bed & breakfasts and other typical

home settings.

This refrigeration appliance is not intended for outdoor use.

 This appliance is intended for domestic use only for cooling and

storing food and drink as well as for storing deep frozen food, freez-

ing fresh food and for making ice.

Any other usage is not supported by the manufacturer and could be

dangerous.

Warning and Safety instructions

 This refrigeration appliance is not suitable for storing and keeping

cool medicines, blood plasma, laboratory preparations or similar

substances or products that are subject to the Medical Device Dir-

ective. Incorrect use of the refrigeration appliance for such purposes

may cause deterioration of the items stored. The refrigeration appli-

ance is also not suitable for use in areas where there is a risk of ex-

plosion.

Miele cannot be held liable for damage caused by improper or incor-

rect use or operation of the appliance.

 The appliance can only be used by people with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge,

if they are supervised whilst using it, or have been shown how to use

it in a safe way and recognise and understand the consequences of

incorrect operation.

Safety with children

 Children under 8 years of age must be kept away from the refri-

geration appliance unless they are constantly supervised.

 Children 8 years and older may only use the appliance unsuper-

vised if they have been shown how to use it in a safe way and recog-

nise and understand the consequences of incorrect operation.

 Children must not be allowed to clean or maintain the appliance

unsupervised.

 Please supervise children in the vicinity of the appliance and do

not let them play with it.

 Danger of suffocation! Whilst playing, children could become en-

tangled in packaging (such as plastic wrapping) or pull it over their

head and suffocate. Keep packaging material away from children.

Warning and Safety instructions

Technical safety

 The coolant circuit has been checked for leaks. The refrigeration

appliance complies with statutory safety requirements and the ap-

propriate EU directives.

 This refrigeration appliance contains the refrigerant isobutane

(R600a), a natural gas which is environmentally friendly but flam-

mable. The refrigerant does not damage the ozone layer and does

not contribute to the greenhouse effect.

The use of this refrigerant has, however, led to a slight increase in

the noise level of the appliance. In addition to the noise of the com-

pressor, you might be able to hear the refrigerant flowing around the

cooling circuit. Unfortunately, this cannot be avoided, but it does not

affect the performance of the refrigeration appliance.

When transporting and installing the refrigeration appliance, ensure

that no parts of the cooling circuit are damaged. Splashes of refri-

gerant can damage the eyes.

In the event of damage:

- Avoid naked flames or anything which creates a spark.

- Disconnect the refrigeration appliance from the mains electricity

supply.

- Ventilate the room where the refrigeration appliance is located for

several minutes.

- Contact the Miele Customer Service Department.

 The more coolant there is in a refrigeration appliance, the larger

the room it should be installed in. In the event of a leakage, if the ap-

pliance is in a small room, there is the danger of a combustible gas/

air mixture building up. For every 11g of coolant at least 1m

room space is required. The amount of coolant in the refrigeration

appliance is stated on the data plate inside the appliance.

Warning and Safety instructions

 To avoid the risk of damage to the appliance, make sure that the

connection data (fuse rating, frequency and voltage) on the data

plate corresponds to the household supply.

Check that this is the case before connecting the appliance. Consult

a qualified electrician if in any doubt.

 The electrical safety of this appliance can only be guaranteed

when correctly earthed. It is essential that this standard safety re-

quirement is met. If in any doubt please have the electrical installa-

tion tested by a qualified electrician.

 Reliable and safe operation of this appliance can only be assured

if it has been connected to the mains electricity supply.

 If the electrical connection cable is faulty it must only be replaced

by a Miele authorised service technician to protect the user from

danger.

 Do not connect the appliance to the mains electrical supply by a

multi-socket adapter or extension lead. These are a fire hazard and

do not guarantee the required safety of the appliance.

 If moisture gets into electrical components or into the mains con-

nection cable, it could cause a short circuit. Therefore, do not oper-

ate this refrigeration appliance in areas which are exposed to mois-

ture (e.g in a garage or utility room).

 This appliance must not be used in a non-stationary location (e.g.

on a ship).

 Do not use a damaged appliance. It could be dangerous. Check

the appliance for visible signs of damage.

 For safety reasons, this appliance may only be used after it has

been built in.

 The appliance must be isolated from the electricity supply during

installation, maintenance and repair work.

Warning and Safety instructions

 Unauthorised installation, maintenance and repairs can cause

considerable danger for the user.

Installation, maintenance and repairs must only be carried out by a

Miele authorised technician.

 While the appliance is under warranty, repairs should only be un-

dertaken by a Miele authorised service technician. Otherwise the

warranty is invalidated.

 Faulty components must only be replaced with genuine Miele ori-

ginal spare parts. Miele can only guarantee the safety standards of

the appliance when Miele replacement parts are used.

 This refrigeration appliance is supplied with a special lamp to

cope with particular conditions (e.g. temperature, moisture, chemical

resistance, abrasion resistance and vibration). This lamp must only

be used for the purpose for which it is intended. The lamp is not suit-

able for room lighting. Replacement lamps may only be fitted by a

Miele authorised technician or by the Miele Customer Service De-

partment. This refrigeration appliance contains several light sources

with at least energy efficiency classG.

Warning and Safety instructions

Correct use

 This refrigeration appliance is designed for use within specific am-

bient temperatures (climate range). Do not use in ambient temperat-

ures for which it is not designed. The climate range is stated on the

data plate in the interior cabinet of the refrigeration appliance. A

lower ambient temperature will cause the compressor to switch off

for longer periods, meaning that the refrigeration appliance is unable

to maintain the required temperature.

 Do not cover or block the air vents as this could impair the effi-

ciency of the appliance, increase the electricity consumption and

could cause damage to the components.

 If storing food which contains a lot of fat or oil in the appliance or

the door, make sure that it does not come into contact with plastic

components as this could cause stress cracks or break the plastic.

 Risk of fire and explosion. Do not store explosive materials in the

refrigeration appliance or any products containing propellants (e.g.

spray cans). Electrical components can cause flammable mixes of

gases to ignite.

 Danger of explosion. Do not operate any electrical equipment (e.g.

an electric ice-cream maker) inside the refrigeration appliance.

Danger of sparking and explosion.

 Danger of injury and damage to the appliance. Do not store cans

or bottles containing carbonated drinks or liquids which could freeze

in the freezer compartment. Otherwise they could burst.

 Danger of injury and damage to the appliance. When chilling

drinks in the freezer section, make sure that bottles are not left in for

more than one hour. Otherwise they could burst.

 Danger of injury. Never handle frozen food or the metal parts of

the appliance with wet hands. Your hands may freeze to the frozen

food or to the metal.

Warning and Safety instructions

 Danger of injury. Do not take ice cubes out with your bare hands

and never place ice cubes or ice lollies in your mouth straight from

the freezer compartment.

The very low temperature of the frozen food could cause frost burn

to the lips and tongue.

 Do not refreeze partially or fully defrosted food. Consume defros-

ted food as soon as possible, as it will lose its nutritional value and

spoil if left for too long. Defrosted food may only be re-frozen after it

has been cooked.

 Observe the manufacturer's “use-by” dates and storage instruc-

tions given on food to avoid the risk of food poisoning. Storage times

will depend on several factors, including the freshness and quality of

the food, as well as the temperature at which it is stored.

Accessories and spare parts

 Only use genuine original Miele accessories and spare parts with

this appliance. Using accessories or spare parts from other manu-

facturers will invalidate the warranty, and Miele cannot accept liabil-

ity.

 Miele will guarantee to supply functional spare parts for a min-

imum of 10years and up to 15years following the discontinuation of

your refrigeration appliance.

Warning and Safety instructions

Cleaning and care

 Do not use any oils or grease on the door seals, as these will

cause the seals to deteriorate and become porous with time.

 Do not use a steam cleaning appliance to clean or defrost this ap-

pliance.

Steam could reach electrical components and cause a short circuit.

 Sharp edged or pointed objects will damage the evaporator, caus-

ing irreversible damage to the appliance. Do not use sharp edged or

pointed objects to

- remove frost and ice,

- separate frozen food or remove ice trays.

 Do not place electric heaters or candles in the appliance to de-

frost it. These can damage the plastic parts.

 Do not use defrosting sprays or de-icers, as they could contain

substances which could damage the plastic parts or which might

cause the build-up of gases and pose a danger to health.

Transport

 Always transport the appliance in an upright position and in its ori-

ginal transport packaging to avoid damage in transit.

 Danger of injury and damage to the appliance. The refrigeration

appliance is very heavy and must be transported by two people.

Warning and Safety instructions

Disposal of your old appliance

 If your old refrigeration appliance has a door lock, destroy it. This

will prevent the risk of children playing accidentally locking them-

selves in and endangering their lives.

 Splashes of coolant can damage the eyes. Be careful not to dam-

age any part of the pipework whilst awaiting disposal, e.g. by

- puncturing the coolant channels in the condenser,

- bending any pipework, or

- scratching the surface coating.

Symbol on the compressor (depending on model)

This information is only relevant for recycling. There is no risk during normal oper-

ation.

 The oil in the compressor can be fatal if swallowed or if it penet-

rates the airways.

Caring for the environment

Disposal of the packing mater-

ial

The packaging is designed to protect

the appliance from damage during

transportation. The packaging materials

used are selected from materials which

are environmentally friendly for disposal

and should be recycled.

Recycling the packaging reduces the

use of raw materials in the manufactur-

ing process and also reduces the

amount of waste in landfill sites.

Disposing of your old appli-

ance

Electronic and electrical appliances

contain many valuable materials. They

also contain certain materials, com-

pounds and components which were

essential for their correct functioning

and safety. These could be hazardous

to your health and to the environment if

disposed of with general waste or if

handled incorrectly. Please do not,

therefore, dispose of your old appliance

with general waste.

Instead, please make use of officially

designated collection and disposal

points to dispose of and recycle elec-

trical and electronic appliances in your

local community, with your dealer or

with Miele. By law, you are solely re-

sponsible for deleting any personal data

from the appliance prior to disposal.

Take care not to damage your refrigera-

tion appliance’s pipework before or dur-

ing transportation to an authorised col-

lection depot.

This is to ensure that coolant in the

cooling circuit and oil in the compressor

is contained, and will not leak into the

environment.

Please ensure that your old appliance

poses no risk to children while being

stored prior to disposal. For further in-

formation, see “Warning and Safety in-

structions” in these operating and in-

stallation instructions.

Saving energy

Normal energy consump-

tion

Increased energy con-

sumption

Installation /

Maintenance

In a ventilated room. In an enclosed, unventilated

room.

Protected from direct sun-

light.

In direct sunlight.

Not near to a heat source

(radiator, oven).

Near to a heat source (radi-

ator, oven).

Where the ideal ambient

room temperature is approx.

20°C.

Where the ambient room

temperature is above 25°C.

Ventilation gaps uncovered

and dusted regularly.

Ventilation gaps covered or

dusty.

Temperature

setting

Refrigerator section 4 to

5°C

The lower the temperature,

the higher the energy con-

sumption.

Freezer compartment -18°C

Saving energy

Normal energy consump-

tion

Increased energy con-

sumption

Use Drawers and shelves ar-

ranged as they were when

the appliance was delivered.

Only open the door when

necessary and for as short a

time as possible. Store food

in an organised way.

Frequent opening of doors

for long periods will cause a

loss of coldness. The appli-

ance will try to cool down

and the compressor will run

for longer periods.

Take an insulated cool bag

when shopping, and load

food in the appliance as

soon as possible.

Replace any food removed

as quickly as possible, be-

fore it warms up too much.

Allow hot food and drinks to

cool down before placing

them in the appliance.

Hot food or food at room

temperature raises the tem-

perature inside the appli-

ance. The appliance will try

to cool down and the com-

pressor will run for longer

periods.

Store food well packaged or

covered.

The evaporation or condens-

ation of liquids in the refri-

gerator section will cause a

loss of coldness.

Place frozen food in the refri-

gerator to defrost.

Do not over-fill the appliance

to allow air to circulate.

Poor air circulation will

cause a loss of coldness.

Defrosting Defrost the freezer compart-

ment when a layer of ice 0.5

cm (max.) thick has built up.

A build-up of ice slows

down the cooling process.

Guide to the appliance

Control panel

Button for switching the refrigeration appliance on/off

Button for switching the SuperCool function on/off

Display with temperature indicator

Menu symbol (Settings mode: for switching the safety lock on/off)

SuperCool symbol

Lock symbol

Temperature display

Button for setting the temperature

Alarm off button

Guide to the appliance

Control panel with display

Egg tray/door shelf

Freezer compartment (depending on model)

Interior lighting

Adjustable shelf

Condensate channel and drain hole

Fruit and vegetable drawer

Bottle shelf with bottle holder

Ventilation grille

Guide to the appliance

Accessories

Accessories supplied

Bottle holder

The flexible ribs grip the bottles se-

curely when the door is opened and

closed.

Egg tray

Ice cube tray(depending on model)

Optional accessories

A range of useful Miele accessories and

care products are available for your ap-

pliance.

Accessories are available to order via

the Miele Webshop, from Miele dir-

ectly (see back cover for contact de-

tails) or from your Miele dealer.

Bottle rack

Bottles can be stored horizontally using

the bottle rack to save space.

The bottle rack can be placed at differ-

ent positions in the appliance.

Guide to the appliance

KKF-FF charcoal filter with holder

(Active AirClean)

Charcoal filters neutralise unpleasant

odours in the fridge zone for improved

air quality.

KKF-RF replacement filters

(ActiveAirClean)

Replacement filters to the fit the holder

are available. We recommend replacing

the charcoal filters every 6months.

Multi-purpose microfibre cloth

The microfibre cloth is suitable for re-

moving fingerprints and light soiling

from surfaces such as stainless steel,

glass, plastic and chrome without the

use of chemicals.

MicroCloth Kit

The MicroCloth Kit contains a universal

cloth, a glass cloth and a polishing

cloth.

These cloths are extremely resistant to

tearing and very robust. Thanks to very

fine microfibres these cloths achieve an

excellent cleaning performance.

Switching on and off

Before using for the first time

Packaging material

 Remove all packaging material from

the inside of the appliance.

Removing the protective foil

The stainless steel trim to the interior

shelves and the door shelves has a

layer of protective foil to prevent dam-

age during transportation.

 Carefully remove the protective film

from the stainless steel trim.

Cleaning the appliance

Please refer to the relevant instruc-

tions in “Cleaning and care”.

 Clean the inside of the appliance and

the accessories.

Switching the appliance on

To enable the temperature to get suffi-

ciently cold inside the appliance, allow

the appliance to run for some time be-

fore placing food in it for the first time.

 Press the button.

The appliance will start to cool and the

temperature required will appear in the

temperature display. The interior lighting

will come on when the door is opened.

Switching off the appliance off

 Press the button until the display

goes out.

If this does not work, the safety lock is

activated (see “Selecting further set-

tings – To deactivate the lock”).

The interior lighting goes out and cool-

ing is turned off.

Switching on and off

Switching off for longer peri-

ods of time

If, during a long absence, the refri-

geration appliance is switched off

but not cleaned and the door(s) left

shut, there is a risk of mould forming

inside the appliance.

It is essential to clean the refrigera-

tion appliance.

If the refrigeration appliance is not go-

ing to be used for a longer period of

time, observe the following:

 Switch the refrigeration appliance off.

 Switch the appliance off at the wall

socket and pull the plug out of the

socket, or disconnect the fuse.

 Defrost the freezer compartment (de-

pending on model).

 Clean the refrigeration appliance and

leave the door ajar to air the appli-

ance and avoid odours building up in-

side.

The correct temperature

It is very important to set the correct

temperature for storing food in the ap-

pliance. Bacteria will cause food which

is not stored at the correct temperature

to deteriorate rapidly. Temperature influ-

ences the growth rate of these bacteria.

Reducing the temperature reduces their

growth rate.

The temperature in the refrigeration ap-

pliance will rise:

- The more often the appliance door is

opened and the longer it is kept open

- The more food that is stored in it

- The warmer the food is which is be-

ing put into it

- The higher the ambient temperature

surrounding the refrigeration appli-

ance. This refrigeration appliance is

designed for use within specific am-

bient temperatures (climate range).

Do not use in ambient temperatures

for which it is not designed.

...in the refrigerator section

We recommend a temperature of 4°C

in the refrigerator section.

...in the freezer compartment

(depending on model)

To freeze fresh food and to store frozen

food for long periods, a temperature of

-18°C is required. At this temperature

the growth of bacteria is generally hal-

ted. As soon as the temperature rises

above -10°C, the bacteria become act-

ive in the food again so it cannot be

kept as long. For this reason, partially

defrosted or defrosted food must not be

re-frozen. Food may be re-frozen once it

has been cooked, as the high temperat-

ures achieved when cooking destroy

most bacteria.

The correct temperature

Temperature display

In normal operation the temperature

display shows the required temperat-

ure.

Setting the temperature

If the appliance door is opened very of-

ten, or if large quantities of food are be-

ing stored in the appliance, or if there is

a high ambient temperature, it is advis-

able to set the temperature between

3°C and 5°C.

The temperature can be adjusted from

9°C to 2°C.

The higher or lower the temperature in

the refrigerator section, the higher or

lower it is in the freezer compartment.

 Press the  button repeatedly until

the temperature you want is shown in

the temperature display.

The first time you press the button the

last temperature set will flash in the dis-

play.

The temperature value will then change

until the setting for 9°C is reached. It

will then drop back to the 2°C setting.

After a short while the newly selected

temperature is automatically set and will

appear in the display.

The temperature in the appliance will

now adjust slowly to the newly set tem-

perature.

Freezer compartment

The average temperature in the freezer

compartment will be approx.-18°C.

If using a thermometer or other device

to measure the temperature in the

freezer compartment be aware that the

air temperature measured can fluctuate.

Using Super cool

SuperCool function

The SuperCool function can be used to

rapidly reduce the temperature in the

fridge zone and the freezer compart-

ment (depending on the model) to its

lowest setting (depending on the room

temperature).

Switching on SuperCool

Switch SuperCool on before placing

food in the appliance:

- To rapidly cool large amounts of fresh

food or drink.

- To freeze food in the freezer compart-

ment (depending on the model).

 Press thebutton.

The SuperCool symbol will light up.

The refrigeration appliance will work at

full power to lower the temperature in

the fridge zone.

Switching off SuperCool

The SuperCool function will switch itself

off automatically after approx. 12hours.

The SuperCool symbol will go out

and the refrigeration appliance will run

at normal power again.

To save energy, the SuperCool function

can be switched off once food and

drinks are sufficiently chilled.

 Press thebutton so that

thesymbol goes out.

The refrigeration appliance will continue

running at normal power.

Door alarm

The appliance is fitted with a warning

system to avoid increased energy con-

sumption if the door is left open.

Door alarm

An alarm will sound if the appliance

door has been left open for longer than

60seconds.

It will stop as soon as the door is

closed.

Switching the door alarm off early

If the noise disturbs you, you can

switch the alarm off if you wish.

 Press the button.

The alarm will stop.

The alarm tone cannot be switched off

early if you are in settings mode.

Selecting further settings

Settings mode

The alarm can be activated or deactiv-

ated in settings mode.

Activating or deactivating the

lock



Settings mode is indicated by the menu

symbol  in the display.

See below for instructions on how to

activate and deactivate the lock.

Activating or deactivating the lock

The safety lock function can be activ-

ated to prevent the appliance being

switched off by mistake.

– To activate the lock

 Press the button for approx.

5seconds.

The menu symbol  lights up and 

flashes in the display.

Settings mode is now active.

 Press the button briefly to access

the lock function.

 will appear in the display.

 Press the button briefly to activate

the lock.

The lock symbol lights up.

 To quit settings mode press the

button.

The temperature will appear in the dis-

play.

– To deactivate the lock

 Press the button for approx.

5seconds.

The lock symbol and the Menu sym-

bol will light up and will start flash-

ing in the display.

Settings mode is now active.

 Press the button briefly to access

the lock function.

 will appear in the display.

 Press the button briefly to deactiv-

ate the lock.

The lock symbol will go out.

 To quit settings mode press the

button.

The temperature in the refrigerator sec-

tion will appear in the display.

Storing food in the refrigerator section

 Risk of explosion due to flam-

mable mixes of gases.

Electrical components can cause

flammable mixes of gases to ignite.

Do not store explosive materials in

the refrigeration appliance or any

products containing propellants (e.g.

spray cans).

 Risk of damage due to greasy or

oily food.

If storing food which contains a lot of

fat or oil in the refrigeration appliance

or the appliance door, make sure

that it does not come into contact

with plastic components as this

could cause stress cracks or break

the plastic.

Make sure that no fat or oil leaks

onto the plastic parts of the refrigera-

tion appliance.

Different storage zones

Due to natural air circulation, there are

different temperature zones in the refri-

gerator section.

Cold, heavy air sinks to the lowest sec-

tion of the refrigeration section. Make

use of the different zones when placing

food in the appliance.

Tip: To allow air to circulate efficiently,

do not pack food too closely together in

the appliance.

If there is insufficient air circulation,

the cooling performance will de-

crease and energy consumption will

increase.

Do not cover the fan in the rear wall

of the appliance.

Tip: Do not store food in such a way

that it touches the rear wall of the refri-

gerator section as it may freeze to the

rear wall.

Storing food in the refrigerator section

Warmest area

The warmest area in the refrigerator

section is at the top in the front area

and in the door. Use this for storing but-

ter and cheese.

Coldest area

The coldest area in the fridge zone is

directly above the fruit and vegetable

drawer and at the back of the appli-

ance.

Use these areas to store all delicate and

highly perishable food such as:

- Fish, meat, poultry

- Cold cuts, ready meals

- Dishes or baked goods containing

eggs or cream

- Fresh dough, cake mixtures, pizza or

quiche dough

- Raw milk cheese and other raw milk

products

- Pre-packed vegetables

- Other fresh food (with a label stating

it should be kept at a temperature of

approx. 4°C)

Food which is not suitable for

storage in the refrigerator sec-

tion

Not all food is suitable for refrigeration

at temperatures below 5°C, because it

may be sensitive to cold. Depending on

the type of food, the appearance, con-

sistency, flavour and/or vitamin content

may be altered if stored at too cold a

temperature.

Food which is sensitive to cold in-

cludes:

- Pineapples, avocados, bananas,

pomegranates, mangoes, melons,

papayas, passionfruit, citrus fruit

such as lemons, oranges, mandarins,

grapefruit

- Fruit (which is not yet ripe)

- Aubergines, cucumbers, potatoes,

peppers, tomatoes, courgettes

- Hard cheeses (e.g. Parmesan, moun-

tain cheese)

Storing food in the refrigerator section

Notes on buying food

The freshness of the food when it is first

placed in the appliance is the most im-

portant factor for how long it stays

fresh.

Take into account the use-by date and

the correct storage temperature.

Time out of the refrigerator, e.g. trans-

porting food in a warm car, should be

kept to a minimum.

Storing food correctly

Ensure that food stored in the fridge

zone is covered or wrapped properly.

This will prevent food odours from af-

fecting other foods, stop food from dry-

ing out and also prevent any cross-con-

tamination of bacteria. This is particu-

larly important when storing meat

products. Make sure that food such as

raw meat and fish in particular does not

come into contact with other food.

By ensuring that the temperature set-

tings are correct and by taking appro-

priate hygiene measures you can pro-

long the storage life of your food con-

siderably and avoid food waste.

Fruit and vegetables

Fruit and vegetables can be stored

loose in the fruit and vegetable drawer.

Protein-rich food

Please note that food rich in protein de-

teriorates faster than other types of

food. Shellfish, for example, deterior-

ates faster than fish, and fish deterior-

ates faster than meat.

Adjusting the interior fittings

Adjusting the door shelf/bottle

shelf

Tip: Only move door shelves/bottle

shelves in the appliance door when they

are empty.

 Push the door shelf/bottle shelf up-

wards, then remove it by pulling it for-

wards.

 Replace the shelf at the required

height. Ensure that it is securely

pushed back into position.

Moving the shelves

The shelves can be adjusted according

to the height of the food.

 Raise the shelf, and pull it forwards

slightly until the notch at the side is in

line with the shelf support. It can then

be raised or lowered to the required

level.

The raised edge on the protective strip

at the back must face upwards to pre-

vent food from touching the back of the

appliance and freezing to it.

Stoppers prevent the shelves from be-

ing dislodged by mistake.

Adjusting the bottle holder

The bottle holder can be moved left or

right to create more room for drink car-

tons.

The bottle holder can be removed com-

pletely (e.g. for cleaning):

 Push the bottle shelf upwards, then

remove it by pulling it forwards

 Pull the bottle holder upwards to re-

move it from the rear edge of the

bottle shelf.

Adjusting the interior fittings

Moving the charcoal filters

Charcoal filters and a KKF-FF (Active

AirClean) holder are available as op-

tional accessories (see “Accessories -

optional accessories”).

When storing very strong smelling

food (e.g. very ripe cheese):

- Place the holder with the charcoal fil-

ters on the shelf where this food is

kept.

- Change the filters sooner if neces-

sary.

- Use more charcoal filters (with hold-

ers) in the appliance (see “Accessor-

ies – Optional accessories”).

The holder for the charcoal filters sits

on the protective strip at the back of the

shelf.

 To move the charcoal filters, pull the

holder upwards to remove it from the

protective strip.

 Refit the holder on the protective strip

of the shelf you wish to use it on.

Freezing and storing food (depending on model)

Using the freezer compartment

Use the freezer compartment to:

- store frozen food,

- make ice cubes,

- freeze small quantities of fresh food.

Up to 2kg of food can be frozen in

24hours.

Freezing fresh food

Fresh food should be frozen as quickly

as possible. This way the nutritional

value of the food, its vitamin content,

appearance and taste are not impaired.

Food which takes a long time to freeze

will lose more water from its cells,

which then shrink. During the defrosting

process, only some of this water is re-

absorbed by the cells. What this means

in practice is that the food loses more

moisture. You can see this in the large

amount of water that collects around

the food when it defrosts.

If food is frozen quickly, the cells have

less time to lose moisture, so they

shrink less. As there is not so much

moisture loss, it is easier for the food to

reabsorb it during the defrosting pro-

cess, and very little water collects

around the defrosted food.

Storing frozen food

Never re-freeze partially or fully de-

frosted food. Defrosted food may

only be re-frozen after it has been

cooked.

When buying frozen food to store in

your freezer, check:

- That the packaging is not damaged

- The use-by date

- The temperature at which the frozen

food is being stored in the shop.

The length of time food can be kept

is reduced if it has been stored at a

temperature warmer than -18°C.

 Buy frozen food once you have fin-

ished the rest of your shopping and

wrap it in newspaper or use a cool

bag or cool box to transport it.

 Put it into the freezer as soon as pos-

sible.

Freezing and storing food (depending on model)

Home freezing

Only freeze fresh food which is in a

good condition.

Hints on home freezing

- The following types of food are suit-

able for freezing:

Fresh meat, poultry, game, fish, ve-

getables, herbs, fresh fruit, dairy

products, cakes, leftovers, egg yolks,

egg whites and a range of pre-

cooked meals.

- The following types of food are not

suitable for freezing:

Grapes, lettuce, radishes, soured

cream, mayonnaise, eggs in their

shells, onions, whole raw apples and

pears.

- To retain colour, taste, aroma and vit-

amin C, vegetables should be

blanched before they are frozen. To

do so place them portion by portion

into boiling water for 2–3minutes.

Remove, and plunge into ice-cold

water to cool quickly. Drain and pack

ready for freezing.

- Lean meat freezes better than fatty

meat, and can be stored for consid-

erably longer.

- Separate chops, steaks, cutlets etc.

with a sheet of plastic freezer film.

This prevents them from freezing to-

gether in a block.

- Do not salt or season raw food or

blanched vegetables before freezing.

Cooked food should only be lightly

salted and seasoned. Some herbs in-

tensify the taste of food when frozen.

- Placing hot foods or drinks in the

freezer causes food that is already

frozen to partially thaw and increases

energy consumption. Allow hot foods

and drinks to cool down before pla-

cing them in the freezer.

Packaging food for freezing

 Freeze food in portions.

–Suitable packing material

- Plastic freezer bags

- Tubular polythene freezer bags

- Aluminum foil

- Freezer containers

–Unsuitable packing material

- Wrapping paper

- Greaseproof paper

- Cellophane

- Bin bags

- Plastic carrier bags

 Expel as much air as possible from

the packaging.

 Close the packaging tightly with

- Rubber bands

- Plastic clips

- String

- Freezer tape

Tip: Freezer bags may also be sealed

using home heat sealing kits.

 Make a note of the contents and the

date of freezing on the packaging.

Freezing and storing food (depending on model)

Before placing food in the appliance

 Set the temperature to 4°C or colder

for approx. 4hours before placing

food in the freezer compartment and

switch on the Super cool function.

This helps create a cold reserve in food

which is already stored in the freezer.

Placing frozen goods in the freezer

Unfrozen food should not touch

frozen food as this will cause frozen

food to begin to thaw.

 To open the freezer compartment,

press the handle upwards and then

pull the door open.

 Make sure that the packaging and

containers are dry to prevent them

sticking together when frozen.

 Place the frozen goods flat on the

bottom of the freezer compartment or

in contact with the interior side walls,

so that they freeze through to the

core as quickly as possible.

Approx. 24hours after placing fresh

food in the freezer compartment

The freezing process is complete.

 Set the temperature back to the one

you want for the refrigerator section.

We recommend a refrigerator temper-

ature of 4°C.

Storage time for frozen food

The storage life of food is very variable,

even at a constant temperature of

-18°C. Decomposition processes also

take place in frozen food, albeit at a

very reduced speed. For example, fat

can become rancid from contact with

oxygen in the air. This is why lean meat

can be stored approx. twice as long as

fatty meat.

The storage times quoted are guide val-

ues for the storage life of different food

groups in the freezer zone.

Food group Storage

time

(Months)

Ice cream 2to6

Bread, baked goods 2to6

Cheese 2to4

Fish, oily 1to2

Fish, lean 1to5

Sausage, ham 1to3

Game, pork 1to12

Poultry, beef 2to10

Vegetables, fruit 6to18

Herbs 6to10

For standard freezing results, follow the

advice on packaging.

By keeping the freezer compartment at

a constant temperature of -18°C and

taking appropriate hygiene measures

you can maximise the storage life of

your food and avoid food waste.

Freezing and storing food (depending on model)

Defrosting frozen goods

Never re-freeze partially or fully de-

frosted food. Defrosted food may only

be re-frozen after it has been cooked.

Frozen goods can be defrosted in differ-

ent ways:

- In a microwave oven

- In an oven using “Fan heat” or the

“Defrost” setting

- At room temperature

- In the refrigerator zone (the cold

given off by the frozen food helps to

keep the other food cold)

- In a steam oven

Flat pieces of partially thawed meat

or fish can be placed directly into a hot

frying pan.

Meat and poultry (e.g. mince, chicken,

fish fillets) should not come into contact

with other foods while defrosting. Catch

the liquid from defrosting and dispose

of it carefully.

Fruit should be defrosted at room tem-

perature in its packaging, or in a

covered bowl.

Most vegetables can be cooked while

still frozen. Just put straight into boiling

water or hot fat. The cooking time is

slightly less than that of fresh veget-

ables due to changes in the cell struc-

ture.

Cooling drinks

 To cool drinks quickly, place them in

the refrigerator section, and switch on

the Super cool function.

When cooling drinks quickly in the

freezer compartment, make sure

bottles are not left in for more than

one hour; otherwise they could

burst.

Using accessories

Making ice cubes

 Fill the ice cube tray three quarters

full of water and place it on the bot-

tom of the freezer compartment.

 Once frozen, use a blunt instrument,

for example a spoon handle, to re-

move the ice tray from the freezer if it

is stuck.

Tip: Ice cubes can be removed easily

from the tray by holding it under running

water for a short time.

Defrosting

Refrigerator section

The refrigerator section defrosts auto-

matically.

Condensate and frost can build up on

the back wall of the refrigerator section

whilst the compressor is running. You

do not need to remove this, as it will de-

frost and evaporate automatically with

the warmth generated by the com-

pressor.

The condensate drains through a chan-

nel and drain pipe into an evaporation

system at the back of the refrigeration

appliance.

Keep the condensate channel and

drain hole clean to enable this. Con-

densate must be able to drain away

unhindered at all times.

Freezer compartment

The freezer compartment does not de-

frost automatically.

In normal use, ice and frost will form in

the freezer compartment, e.g. on the in-

ternal walls. How much ice and frost

accumulates in the appliance will de-

pend on the following:

- whether the freezer compartment

door has been opened frequently or

left open for a while.

- whether a large quantity of food has

been placed in the freezer at once.

- whether the humidity in the room has

increased.

In certain circumstances, too thick a

layer of ice can prevent the freezer

compartment door from closing prop-

erly. Too thick a layer of ice also re-

duces cooling performance and thus in-

creases energy consumption.

 The freezer compartment should be

defrosted from time to time. It must

be defrosted if a layer of ice approx.

0.5cm thick has accumulated.

Tip: It is best to defrost when only very

little or no frozen food at all is left in the

freezer compartment or the humidity

level and the ambient temperature in

the room are low.

 Risk of damage from an incor-

rect defrosting process.

When defrosting the freezer, make

sure that you do not damage the

evaporator as this would cause irre-

versible damage to the refrigeration

appliance.

Do not scrape off ice and frost. Do

not use sharp objects.

Do not use any mechanical or other

types of aids which are not recom-

mended by the manufacturer to ac-

celerate the defrosting process.

Before defrosting

 Remove the frozen goods and wrap

them in several layers of newspaper

or cloths.

Tip: You could also place the frozen

goods in a cool box or bag.

 Store it in a cool place until the

freezer compartment is ready for use

again.

Defrosting

To defrost

 The longer the frozen goods are

left out at room temperature, the

faster they deteriorate.

Carry out the defrosting procedure

as quickly as possible.

 Steam from a steam cleaning ap-

pliance could reach the electrical

components and cause a short cir-

cuit.

Do not use a steam cleaning appli-

ance to defrost the appliance.

 Do not place electric heaters or

candles in the appliance to defrost it.

These can damage the plastic parts.

 Do not use defrosting sprays or

de-icers. These could contain sub-

stances which could damage the

plastic parts or which might cause a

build-up of explosive gases and

pose a danger to health.

 Switch the appliance off.

The cooling system will be switched off.

 Switch off at the wall and withdraw

the plug from the socket, or discon-

nect the mains fuse.

 Leave the freezer compartment door

open.

Tip: To speed up defrosting, two bowls

of hot water (not boiling), with plates

underneath them, can be placed in the

freezer section. Closing the door in this

instance will help retain the warmth and

speed up the defrosting process.

 Remove any loose pieces of ice.

 Use a sponge or towel to soak up the

defrosted water as often as neces-

sary.

After defrosting

 Clean and dry the freezer compart-

ment.

Cleaning water must not get into the

defrosting drain hole.

 Reconnect to the mains and switch

the appliance back on.

 Once the temperature in the freezer

compartment has reached the re-

quired temperature, place the frozen

goods back into the freezer compart-

ment.

Cleaning and care

Do not let water get into the elec-

tronic module or the lighting.

 Risk of damage due to moisture

ingress.

The steam from a steam cleaner can

damage plastic and and electrical

components.

Do not use a steam cleaner to clean

the refrigeration appliance.

Cleaning water must not get into the

drain hole.

The data plate located inside the in-

terior cabinet of the refrigeration appli-

ance must not be removed. It contains

information which is required in the

event of a fault.

Cleaning agents

Cleaning and conditioning agents

used inside the appliance must be

food safe.

To avoid damaging all the surfaces of

your appliance, do not use:

- cleaning agents containing soda, am-

monia, acids or chlorides

- cleaning agents containing descaling

agents

- abrasive cleaning agents, e.g.

powder cleaners and cream cleaners

- solvent-based cleaning agents

- stainless steel cleaning agents

- dishwasher cleaner

- oven sprays

- glass cleaning agents

- hard, abrasive sponges and brushes,

e.g. pot scourers

- melamine eraser blocks

- sharp metal scrapers

We recommend using a clean sponge,

lukewarm water with a little washing-up

liquid to clean surfaces of the appli-

ance.

The following pages contain important

information on cleaning.

Cleaning and care

Preparing the refrigeration ap-

pliance for cleaning

 Switch the refrigeration appliance off.

The display goes out and the cooling

function is switched off.

 Take any food out of the refrigeration

appliance and store it in a cool place.

 Defrost the freezer compartment (see

“Defrosting”, section “Freezer com-

partment”).

 Remove the shelves and bottle shelf

from the door.

 Take out all other removable parts for

cleaning.

Dismantling an adjustable shelf

 Place the shelf on a worktop covered

with a soft material (e.g. a tea towel).

 Remove the trim:

1. Pull the stainless steel trim off the

shelf beginning at one side.

2. Then pull the protective strip off.

 After cleaning the shelf reattach the

trim and the protective strip.

Cleaning and care

Cleaning the interior and ac-

cessories

The refrigeration appliance should be

cleaned regularly (at least once a

month).

Remove soiling immediately to pre-

vent it from drying on.

 Clean the interior with a clean

sponge, lukewarm water and a little

washing-up liquid.

 After cleaning, wipe with clean water

and dry with a soft cloth.

Remove the stainless steel parts be-

fore cleaning the adjustable shelves in

a dishwasher.

The following parts cannot be cleaned

in a dishwasher:

- the stainless steel trim

- the fruit and vegetable drawer

 These accessories should all be hand

washed.

 Risk of damage as a result of ex-

cessively high dishwasher temperat-

ures.

Parts of the refrigeration appliance

may become unusable, e.g. deform,

if they are washed in the dishwasher

at more than 55°C.

For dishwasher-safe parts, only use

dishwasher programmes with a max-

imum temperature of 55°C.

Contact with natural dyes from car-

rots, tomatoes and ketchup, etc., may

discolour the plastic parts in the dish-

washer. This discolouration does not

affect the stability of the parts.

The following parts can be cleaned in

the dishwasher:

- the bottle holder, egg tray, ice cube

tray (depending on model)

- the shelves and bottle shelf in the

door

- the adjustable shelves (with the trim/

strips removed and without the print-

ing)

- the holder for the charcoal filter

(available as an optional accessory)

 Clean the condensate channel and

drain hole frequently so that con-

densate can drain away unhindered.

Use a straw or similar to clear the

drain if necessary.

 Leave the door open to air the appli-

ance for a short while and to prevent

odours building up.

Cleaning and care

Cleaning the door seal

If the door seal is damaged or has

slipped out of its groove, the appli-

ance door may not close properly

and cooling performance will be re-

duced. As a result, condensate will

build up in the interior cabinet and

this can cause a build-up of ice.

Do not damage the door seal and

ensure it does not slip out of its

groove.

 Risk of damage as a result of in-

correct cleaning.

If you treat the door seal with oils or

grease, it can become porous.

Do not use any oils or grease on the

door seal.

 The door seal should be cleaned reg-

ularly with clean water and then

wiped dry with a cloth.

Cleaning the ventilation gaps

A build-up of dust will increase the en-

ergy consumption of the appliance.

 The ventilation gaps should be

cleaned on a regular basis with a

brush or vacuum cleaner (you could

use a Miele vacuum cleaner dusting

brush, for example).

After cleaning

 Replace all shelves and accessories

in the appliance.

 Switch the refrigeration appliance on.

 Switch on the Super cool function for

a while so that the refrigerator section

can cool down quickly.

 Place food in the refrigerator section

and close the door.

 Place food in the freezer compart-

ment when it is cold enough and

close the appliance door.

Cleaning and care

Replacing the charcoal filters

Charcoal filters and a KKF-FF (Active

AirClean) holder are available as op-

tional accessories (see “Accessories -

optional accessories”).

Replace the charcoal filters in the

holder every 6months.

Replacement KKF-RF charcoal filters

can be obtained from the Miele Cus-

tomer Service Department, from your

retailer or from Miele's website.

Tip: The charcoal filter holder is dish-

washer-safe.

 Pull the charcoal filter holder upwards

to remove it from the adjustable shelf.

When in position, the charcoal filters

must not touch the rear wall of the

refrigeration appliance as the mois-

ture could cause them to stick to it.

Insert the new charcoal filters deep

enough in the holder to ensure that

they do not protrude over the edge

of the holder.

 Remove both charcoal filters and

place the new filters with the sur-

rounding edge pointing downwards in

the holder.

 Place the holder in the middle of the

raised edge at the back of the ad-

justable shelf, so that it clicks into po-

sition.

Problem solving guide

Many malfunctions and faults that can occur in daily operation can be easily

remedied. Time and money will be saved because a service call will not be

needed.

The following guide may help you to find the reason for a malfunction or a fault,

and to correct it.

To prevent unnecessary loss of temperature it is advisable not to open the door

while waiting for the appliance to be serviced.

Problem Cause and remedy

The appliance is not

getting cold, the interior

lighting does not come

on when the door is

opened, and the display

is not lit up.

The appliance is not switched on and the mains con-

nection symbol is lit up in the display.

 Switch the appliance on.

The plug is not inserted in the socket correctly.

 Insert the plug correctly into the socket. The mains

connection symbol appears in the display

when the appliance is switched off.

Check whether the mains fuse has tripped. There

could be a fault with the appliance, the household

electrical wiring or another electrical appliance.

 Contact a qualified electrician or Miele.

The compressor is

switching on more fre-

quently and for longer

periods of time. The

temperature in the refri-

geration appliance is

too low.

The ventilation gaps have been covered or become

too dusty.

 Do not block the ventilation gaps.

 Dust the ventilation gaps regularly.

The appliance door and the freezer compartment

door have been opened too frequently, or a large

amount of fresh food has been placed in the appli-

ance or frozen at the same time.

 Only open the appliance door or freezer compart-

ment door when necessary and for as short a time

as possible.

After a while, the temperature will return to normal by

itself.

The appliance door and/or the freezer compartment

door is not closed correctly.

A thick layer of ice may have already formed in the

freezer compartment.

 Close the appliance doors.

Problem solving guide

Problem Cause and remedy

After a while, the temperature will return to normal by

itself.

If a thick layer of ice has already formed, this will af-

fect cooling and increase energy consumption.

 Defrost the freezer compartment and clean it.

The ambient room temperature is too high. The

higher the ambient temperature, the longer the com-

pressor has to run.

 See the information in “Installation” – “Installation

site”.

The temperature setting in the refrigeration appliance

is too low.

 Correct the temperature setting.

A large amount of food is being frozen at once.

 See “Freezing and storing food”.

The SuperCool function is still switched on.

 You can switch off the SuperCool function earlier

to save energy.

The compressor comes

on less and less often

and for shorter periods

of time. The temperat-

ure in the refrigeration

appliance rises.

This is not a fault. The temperature setting is too

high.

 Correct the temperature setting.

 Check the temperature again after 24hours.

The frozen food begins to defrost.

The room temperature is too low for this refrigeration

appliance.

If the room temperature is too low, the compressor

will run less frequently. This may cause the freezer to

become too warm.

 See the information in “Installation – Installation

site”.

 Increase the temperature of the room.

A buzzer is sounding. The door alarm has been activated (also see “Door

alarm”).

 Close the appliance door.

The alarm will stop.

Problem solving guide

Problem Cause and remedy

The door seal is dam-

aged or needs to be re-

placed.

No tools are required to change the door seal.

 Change the door seal. A replacement is available

from Miele or from specialist retailers.

Ice or condensation has

built up inside the refri-

geration appliance. The

appliance door may not

close correctly.

The door seal has come out of its groove.

 Check that the door seal is correctly positioned in

the groove.

The door seal is damaged.

 Check whether the door seal is damaged.

An LED indicator light is

flashing at the back of

the refrigeration appli-

ance at the bottom near

the compressor (de-

pending on model).

The electronic unit for

the compressor is

equipped with an oper-

ation and fault dia-

gnosis LED indicator

light.

The indicator light flashes several times every

5seconds.

A fault has occurred.

 Call the Miele Customer Service Department.

The indicator light flashes regularly every

15seconds.

Not a fault. This flashing is normal.

Problem solving guide

Display warnings

Message Cause and remedy

The  symbol lights up

in the display, the appli-

ance does not get cold,

although the controls

and the interior lighting

are working.

Demo mode is switched on. This allows the appli-

ance to be presented in the showroom without the

cooling system being switched on. Do not activate

this setting for domestic use.

 Contact the Miele Service Department for informa-

tion on deactivating Demo mode.

“F0toF9” appears in

the display.

There is a fault.

 Call the Miele Service Department.

The  symbol lights up

in the display. You can-

not switch the appli-

ance off.

The safety lock has been activated.

 Completely deactivate the safety lock (see “Select-

ing further settings – Activating and deactivating

the safety lock”).

Problem solving guide

The interior lighting is not working.

Problem Cause and remedy

The interior lighting is

not working.

The refrigeration appliance has not been switched

on.

 Switch the refrigeration appliance on.

To avoid overheating, the lighting switches itself off

automatically after approx. 15minutes if the appli-

ance door is left open. If this is not the case, then

there is a fault.

 Risk of electric shock due to exposed, live

electrical components.

When removing the lighting cover, there is a risk of

coming into contact with live electrical compon-

ents.

Do not remove the lighting cover. The LED lighting

may only be repaired or replaced by the Miele

Customer Service Department.

 Risk of injury from LED lighting.

This lighting corresponds to risk group RG2. If the

cover is defective, there is a risk of eye injury.

If the lighting cover is defective, do not look from a

close range directly into the lighting with optical in-

struments (e.g. magnifying glass or similar).

 Call the Miele Customer Service Department.

Problem solving guide

Other problems

Problem Cause and remedy

The floor of the refriger-

ator section is wet.

The condensate drain hole is blocked.

 Clean the condensate channel and drain hole.

Food has frozen to-

gether.

The food packaging was not dry when placed in the

freezer.

 Use a blunt instrument, e.g. a spoon handle or

plastic scraper, to prise it apart carefully.

The external walls of

the appliance feel

warm.

This is not a fault. The heat created by the evapor-

ator is used to prevent condensation.

Noises

Normal

noises

What causes them

Brrrrr ... A humming noise is made by the motor (compressor). This noise

can get louder for brief periods when the motor switches on.

Blubb,

blubb ...

A gurgling noise can be heard when coolant is circulating

through the pipes.

Click ... Clicking sounds are made when the thermostat switches the

motor on and off.

Crack ... A cracking sound can be heard when materials expand inside

the appliance.

Remember that the noise of the compressor and the coolant circulating in the

system is unavoidable.

Noises Cause and remedy

Rattling, vi-

brating

The appliance is uneven. Realign the appliance using a spirit

level. Do so by raising or lowering the screw feet underneath the

appliance or place something underneath it.

The appliance is touching another appliance or piece of fur-

niture. Move it away.

Drawers or shelves are unstable or sticking. Check all removable

items and refit them correctly.

Bottles or containers are touching each other. Separate them.

The transport cable clips are hanging loose at the back of the

appliance. Remove them.

Service

Contact in the event of a fault

In the event of any faults which you

cannot remedy yourself, please contact

your Miele dealer or the Miele Customer

Service Department.

You can book a Miele Customer Ser-

vice Department call-out online at

www.miele.com/service.

Contact information for the Miele Cus-

tomer Service Department can be

found at the end of this document.

Please quote the model identifier and

serial number of your appliance (Fabr./

SN/Nr.) when contacting the Miele Cus-

tomer Service Department. This inform-

ation can be found on the data plate.

Please note that telephone calls may be

monitored and recorded for training

purposes and that a call-out charge will

be applied to service visits where the

problem could have been resolved as

described in this booklet.

The data plate can be found inside the

appliance.

EPREL database

From 1 March 2021, information on en-

ergy labelling and ecodesign require-

ments will be available in the European

Product Database (EPREL). You can

find the product database at the follow-

ing link https://eprel.ec.europa.eu/. You

will be asked to enter the model identi-

fier.

The model identifier can be found on

the data plate.

SN-ST

R600a:

XXXXXX

Nr. XX/ XXXXXXXXX.

XXX l

XXg

Warranty

The appliance warranty is valid for 2

years from date of purchase. In the UK,

you must activate your cover by calling

0330 160 6640 or registering online at

www.miele.co.uk.

For more information on country-spe-

cific warranty terms and conditions,

please contact Miele Customer Service.

Installation

*INSTALLATION*

Installation

 Danger of damage and injury

due to the refrigeration appliance tip-

ping over.

This refrigeration appliance is very

heavy and can tip forwards when the

appliance door is open.

Keep the appliance door(s) shut until

the refrigeration appliance has been

built in and secured in its housing in

accordance with these operating and

installation instructions.

 Fire risk and danger of damage

from appliances which give off heat.

Appliances which give off heat can

catch fire and set fire to the refrigera-

tion appliance.

This refrigeration appliance must not

be installed underneath a hob.

 Fire risk and danger of damage

from open flames.

Open flames can set fire to the refri-

geration appliance.

Keep open flames (e.g. a candle)

away from the refrigeration appli-

ance.

Side-by-side installation

 Risk of damage due to condens-

ation on external appliance panels.

In environments with high humidity,

condensation can build up on ex-

ternal appliance panels, which can

cause corrosion.

Do not place different refrigeration

appliance models directly next to or

on top of one other.

Your refrigeration appliance must not be

installed “side-by-side” because it is

not equipped with built-in heating units

in the side panels.

This refrigeration appliance can, how-

ever, be installed next to certain models

that are equipped with integrated heat-

ing in their side wall, as long as they are

installed in separate building-in niches.

The refrigeration appliance must be in-

stalled to the left of the freezer.

Please contact your dealer for specific

information about which combinations

will work with your appliance.

Installation

*INSTALLATION*

Location

This appliance should be installed in a

dry, well-ventilated room.

When deciding where to install your re-

frigeration appliance please bear in

mind that it will use more energy if in-

stalled near to a heater, a cooker or

other appliance that gives off heat. Dir-

ect sunlight should also be avoided.

The higher the room temperature, the

longer the compressor runs and the

higher the energy consumption is.

When installing the appliance, please

note:

- The socket must be easily accessible

in an emergency, not concealed be-

hind the appliance.

- The plug and cable must not touch

the rear of the appliance as they

could be damaged by vibrations from

the appliance.

- Do not plug in other appliances be-

hind this appliance.

 Risk of damage due to high hu-

midity.

In environments with high humidity,

condensation can build up on ex-

ternal refrigeration appliance panels,

which can cause corrosion.

Install the refrigeration appliance in a

dry and/or air-conditioned room with

sufficient ventilation.

After installation, make sure that the

appliance door closes properly, the

ventilation gaps are not covered and

that the refrigeration appliance has

been installed in accordance with the

operating and installation instruc-

tions.

Climate range

This refrigeration appliance is designed

for use within specific ambient temper-

atures (climate range). Do not use in

ambient temperatures for which it is not

designed. The climate range is stated

on the data plate in the interior cabinet

of the refrigeration appliance.

Climate range Ambient temper-

ature

SN +10to +32°C

N +16to +32°C

ST +16to +38°C

T +16to +43°C

A lower ambient temperature leads to

the compressor switching off for longer

periods. This can cause the internal

temperature in the refrigeration appli-

ance to rise with the risk of food deteri-

orating and going off.

Installation

*INSTALLATION*

Ventilation

 Risk of fire and damage due to

insufficient ventilation.

If the refrigeration appliance is not

ventilated sufficiently, the com-

pressor will run more frequently and

for longer periods. This will result in

increased energy consumption and a

higher operating temperature for the

compressor. This may, in turn, cause

damage to the compressor.

Please ensure that there is adequate

ventilation around the refrigeration

appliance.

It is essential to observe the required

ventilation gaps.

The ventilation gaps must not be

covered or blocked in any way.

They must also be regularly dusted.

Ventilation takes place through a vent-

ilation grille in the refrigeration appli-

ance plinth.

Furniture door panel

–Gap

Depending on the style of kitchen fur-

niture, the thickness and edge radius of

the furniture door and the gap that runs

around the door, vertically and horizont-

ally, are specified.

It is essential to pay attention to the fol-

lowing:

If the gap between the refrigeration

appliance furniture door panel and the

adjoining housing unit door or wall on

the hinged side is too small, the appli-

ance door could collide with the ad-

joining housing unit door or wall when

opened.

It may be necessary to adjust the

size of this gap to suit the thickness

and edge radius of the appliance fur-

niture door.

Tip: This must be taken into considera-

tion when planning your kitchen and

when replacing an old refrigeration ap-

pliance with a new one to ensure the in-

stallation conditions required are met.

Installation

*INSTALLATION*

Appliance

furniture

door

thickness

A [mm]

Gap X [mm]

for different

edge radiiB

R0 R1.2 R2 R3

≥16–19 min. 3

20 5 4 4 3.5

21 5.5 5 4.5 4

22 6.5 6 5.5 5

Adjoining kitchen furniture front

A=Furniture front thickness

B=Edge radius

X=Gap

Adjoining side wall

A=Furniture front thickness

B=Edge radius

X=Gap

Tip: Fit a spacer between the housing

unit carcase and the side wall. This way

you will get a sufficiently wide gap.

Weight of the furniture door

 If the furniture door panel is too

heavy, this can cause damage.

Fitting a furniture door panel which is

heavier than the maximum permitted

weight could damage the hinges.

This can cause subsequent func-

tional problems.

Before fitting a furniture door, ensure

that the weight of the door does not ex-

ceed the maximum permitted:

Appliance Maximum weight

of furniture door in

K 31222 Ui 10kg

K 31242 UiF 10kg

Installation

*INSTALLATION*

Before installing the appliance

 Take the accessory pack which in-

cludes installation parts and other ac-

cessories out of the appliance.

 Remove the cable clip from the back

of the appliance.

 Open the appliance door and remove

the red safety catch  (depending on

model).

Installation

*INSTALLATION*

Building-in dimensions

Installation dimensions

Appliance dimensions

Installation

*INSTALLATION*

Dimensions for ventilation

Installation

*INSTALLATION*

Changing the door hinging

The refrigeration appliance is supplied

with hinges on the right. If left-hand

hinging is required, the hinges must be

changed.

 Danger of injury and damage

when changing the door hinging.

There is an increased danger of in-

jury and damage if the refrigeration

appliance is installed by a single per-

son.

Always change the door hinging with

the help of a second person.

If the door seal is damaged or has

slipped out of its groove, the appli-

ance door may not close properly

and cooling performance will be re-

duced. Condensate will build up in

the interior cabinet and this can

cause a build-up of ice.

Do not damage the door seal and

ensure it does not slip out of its

groove.

Preparing to change the door hinging

To change the door hinging, you will

need the following tools:

 Place a suitable cover on the floor in

front of the appliance to protect the

appliance door and your floor from

damage.

 Lift off the covers, and.

Installation

*INSTALLATION*

 Slightly loosen screws and on

the hinges.

 Push the appliance door outwards

and take it off its hinges.

 Remove the screws completely

and loosely screw them in on the op-

posite side.

 Remove the screws completely

and loosely screw them in on the op-

posite side.

Refitting the door

 Place the appliance door with the

outer side upwards on a stable sur-

face.

 Danger of injury from folding

door hinges.

The hinges can snap closed.

Leave them open.

 Remove the screws completely.

 Replace the hinges in their diagonally

opposite corners.

Installation

*INSTALLATION*

 Hang the appliance door onto the

pre-fitted screws and, and se-

curely tighten the screws and.

 Replace the covers:, and.

Installation

*INSTALLATION*

Adjusting the appliance door

hinges

If you would like the appliance door to

be cushioned so that it opens more

softly, the spring tension on the appli-

ance door can be adjusted:

To do this, use an Allen key to adjust

the door hinges.

To reduce the appliance door open-

ing angle:

 Turn the Allen key clockwise.

This tightens the hinges and makes it

harder to open the door wide.

To open the appliance door fully:

 Turn the Allen key anti-clockwise.

The hinge is looser, making it easier to

open the door.

Limiting the opening angle of

the appliance door

The door hinges are set ex works to en-

able the appliance door to be opened

wide.

However if the opening angle of the ap-

pliance door needs to be limited for any

reason, the hinge can be adjusted to

accommodate this.

If the appliance door hits an adjacent

wall when opened, for example, the

opening angle can be limited toapprox.

90°:

The locking pins for limiting the door

opening must be fitted before the refri-

geration appliance is installed.

 Insert the locking pins supplied for

limiting the door opening into the

hinges from above.

The appliance door opening angle is

now limited to approx. 90°.

Installation

*INSTALLATION*

Installing the appliance

To install the appliance, you will need

the following tools:

Parts required for installation

All installation parts are number coded.

This coding is also used in the installa-

tion instructions.

Preparing the appliance

 Position the refrigeration appliance in

front of the niche.

 Hold the plinth facing at the side and

pull it forwards and off.

You have a choice of two different

ways of securing your appliance:

1. Secured at the top

This method is suitable for securing

the appliance underneath a worktop,

e.g. a laminated one). The worktop

must be suitable for screwing a

bracket on to.

With the appliance feet fully extended

the appliance should sit lightly ten-

sioned between the floor and the

worktop.

2. Secured at the side

This method is suitable for securing

the appliance underneath a solid

worktop, e.g. a granite one). The fur-

niture side walls to the right and left

of the refrigeration appliance must be

suitable for screwing brackets to.

With the feet fully extended the refri-

geration appliance will sit lower than

the worktop.

Installation

*INSTALLATION*

1.Secured at the top

 Fit the bracket in the aperture in the

appliance lid.

 Bend the bracket at the perforated

position.

2.Secured at the side

Both ends of the bracket must be

bent.

 Fit the bracket in the aperture in the

appliance lid.

 Bend the bracket at the perforated

position.

 Remove the bracket from the aper-

ture and insert the straight end of the

bracket.

 Now bend this end of the bracket at

the perforated position.

Installation

*INSTALLATION*

Positioning the refrigeration appli-

ance

 Risk of damaging the power

cable.

When pushing the refrigeration appli-

ance into its niche, the power cable

can get trapped and damaged.

Carefully push the refrigeration appli-

ance into the niche.

 Risk of damaging the floor.

Moving the refrigeration appliance

can cause damage to the floor.

Move the refrigeration appliance

carefully on floors that are sensitive

to scratching.

 Risk of damaging the appliance

feet.

The appliance feet can break off.

The feet should be almost fully

screwed in when you push the refri-

geration appliance into the niche.

Tip: Before pushing the appliance into

the niche the two rear feet should be

loosened by half a turn. After pushing it

into the niche, the feet will be easier to

adjust from the front (see “Aligning the

refrigeration appliance”).

 Position the power cable so that the

refrigeration appliance can be con-

nected easily once installed.

Tip: To help you push it into position, tie

a piece of string around the plug to

“lengthen” the power cable.

Then pull the power cable by the end of

the string through the housing unit.

If the refrigeration appliance is

pushed too far into the niche, the ap-

pliance door may not close properly

once the furniture panel has been fit-

ted. This can cause ice to build up,

condensate to accumulate and lead

to faults in the appliance. These can

all lead to increased energy con-

sumption.

Push the refrigeration appliance into

the niche, making sure a gap of

42mm is maintained all round

between the appliance carcase and

the front of the housing unit side

walls.

 Push the refrigeration appliance into

the niche until the front edges of the

hinges at the top and bottom are

flush with the front edge of the hous-

ing unit side wall.

This will create a gap all round of

42mm to the front edges of the hous-

ing unit side walls.

Installation

*INSTALLATION*

On furniture with door fittings (e.g.

stubs, seals, etc.), the dimension of

these must be taken into account to

ensure there is a gap all round of

42mm.

 Pull the refrigeration appliance for-

wards by the appropriate dimension.

 Check again to make sure there is a

gap of 42mm to the front edges of

the door fittings.

Tip: If possible, remove the door fittings

and push the refrigeration appliance

into the niche until all fixing brackets at

the top and bottom are touching the

front edge of the housing unit side wall.

Aligning the refrigeration appliance

When securing the refrigeration appli-

ance in the niche at the top, it should

sit lightly tensioned between the floor

and the worktop.

 Adjust the front and rear feet altern-

ately according to the height of the

niche and make sure the refrigeration

appliance is correctly aligned.

Proceed as follows:

 Adjust both rear feet with appropriate

screws at the front right and left in the

appliance plinth using a flat-headed

screwdriver.

 Use an Allen key to unscrew both

front feet.

Tip: As soon as the feet have been un-

screwed slightly, you can adjust them

with a screwdriver at the bottom of the

foot (see small illustration).

Installation

*INSTALLATION*

The foam ensures the airflow is

separated to prevent malfunctioning

of the appliance.

 Insert the piece of foam supplied.

 Refit the plinth facing, but do not

secure it in position yet.

Without a continuous plinth facing:

 Pull the plinth facing forwards until

the ventilation slats are in alignment

with adjacent cabinet plinth facings.

 Hold the plinth facing securely and

attach it to the right and left using the

bolts supplied.

With a continuous plinth facing:

 Push the plinth facing right up

against the refrigeration appliance,

and attach it to the right and left us-

ing bolts.

Fitting a continuous furniture plinth

facing

Ventilation takes place through a

ventilation grille in the appliance

plinth.

The ventilation grille must never be

obstructed.

If a continuous plinth facing is to be

fitted, a suitable ventilation gap will

need to be made in it for the ventila-

tion grille of the appliance:

 Trim the furniture plinth facing (U) to

the correct height.

 Adjust the height (V) along the niche

width (W) underneath the appliance

plinth facing.

Installation

*INSTALLATION*

Securing the appliance in the niche

1.Secured at the top

2.Secured at the side

 Screw the appliance into position on

the right and the left.

Fitting the furniture door

If fitted in a run of units make sure that

the top edge of the furniture door is at

the same height as neighbouring unit

doors.

The furniture door must be fitted cor-

rectly and not under tension.

The next section gives instructions on

how to fit a furniture door that is at

least 16–19 mm thick.

Ensure that the plinth facing is refitted

correctly.

 The distance between the appliance

door and the fixing bracket is set to

8mm at the factory. Check this dis-

tance and adjust it if necessary.

 Push the fitting aids up to the

height of the furniture door: the lower

edge X of the fitting aids must be at

the same height as the upper edge of

the furniture door being fitted (see

in diagram).

Installation

*INSTALLATION*

Tip: Push up the fitting aids with the

furniture front until they are the same

height as the doors of adjacent kitchen

units.

 Undo the nuts and take the fixing

bracket off together with the fitting

aids.

 Using a pencil, lightly mark a line

down the centre of the inside of the

furniture door .

 Hang the fixing bracket with the

fitting aids onto the inside of the fur-

niture door. Align the fixing bracket

centrally.

 Attach the fixing bracket securely us-

ing at least 6 short chipboard

screws. (On cassette doors only

use 4 screws on the edges). Drill

holes into the furniture door if neces-

sary.

 Pull the fitting aids upwards to re-

move them .

Turn them around and fit them into

the middle slots on the fixing bracket

for safe keeping.

Installation

*INSTALLATION*

 Fit the side cover to the fixing bracket

on the opposite side of the hinge.

 Turn the furniture door over and at-

tach the handle (if required).

 Open the appliance door.

 Hang the furniture door onto the ad-

justing bolts.

 Loosely attach the nuts on the ad-

justing bolts.

 Close the door and check the dis-

tance between the door and neigh-

bouring furniture doors.

 Align to match neighbouring doors if

necessary:

Side adjustments X are made by slid-

ing the furniture door, and height ad-

justments Y by turning adjusting

bolts with a screwdriver.

Installation

*INSTALLATION*

 Whilst counterholding adjusting

bolts with a screwdriver, tighten

nuts on the appliance door with

screwdriver.

 Attach the appliance door and the

furniture door using screws through

fixing brackets:

- Drill holes in the furniture door (mark

the position of the holes first).

- Screw in the short chipboard

screws (4x14mm).

 Align the furniture door along the

depth plane Z: loosen the screws in

the long slots at the top of the appli-

ance door as well as under the ap-

pliance door. By moving the fur-

niture door, create a gap of 2mm

between the furniture door and the

front edge of the niche. Align accord-

ing to the adjacent furniture doors.

 Close the door, check it is secured

correctly, and align it with adjacent

furniture doors.

 Tighten all the screws again.

Installation

*INSTALLATION*

 Fit the cover in position.

To make sure the appliance is cor-

rectly fitted:

- The door must close properly.

- The door must not touch the housing

unit.

- The seal at the top edge of the

handle side must fit properly.

 To double check place a torch in the

appliance and close the door.

Turn the lights out in the room. If you

can see any light shining out from the

sides double check the installation.

Installation

*INSTALLATION*

Electrical connection

The appliance is supplied with a mains

cable and moulded plug ready for con-

nection to an AC single-phase 220–

240V50Hz supply.

The fuse rating must be at least 10A.

This appliance must be connected to a

suitable switched socket. The electrical

installation must be in compliance with

current local and national safety regula-

tions, (e.g. VDE0100 in Germany / BS

7671 in the UK). We recommend the

use of a suitable RCD .

The socket must not be concealed be-

hind the appliance and must be easily

accessible so that the appliance can be

quickly disconnected from the electrical

supply in case of an emergency.

If the socket is no longer accessible

after installation, an additional means of

disconnection must be provided for all

poles. Suitable means of disconnection

include switches with an all-pole con-

tact gap of at least 3mm. These in-

clude miniature circuit breakers, fuses

and contactors (EN60335).

The mains plug and mains connection

cable must not come into contact with

the back of the appliance as vibrations

can cause damage to these compon-

ents. This could result in a short circuit.

Do not plug in other appliances behind

this appliance.

Do not connect the appliance to the

mains electricity supply by an extension

lead. Extension leads do not guarantee

the required safety of the appliance

(e.g. danger of overheating).

Do not connect the appliance to a

stand-alone inverter such as those used

with an autonomous energy source e.g.

solar power.

When the appliance is switched on,

power surges could result in a safety

switch-off. This could damage the elec-

tronic module. The appliance must not

be used with so-called energy saving

devices either. These reduce the

amount of energy supplied to the appli-

ance, causing it to overheat.

If the mains cable needs to be replaced,

this must be performed by a qualified

electrician.

United Kingdom

Miele Co. Ltd., Fairacres, Marcham Road, Abingdon, Oxon, OX14 1TW

Tel: 0330 160 6600, Internet: www.miele.co.uk/service, E-mail: [email protected]

Australia

Miele Australia Pty. Ltd.

ACN 005 635 398

ABN 96 005 635 398

1 Gilbert Park Drive

Knoxfield, VIC 3180

Tel: 1300 464 353

Internet: www.miele.com.au

Miele Electrical Appliances Co., Ltd.

1-3 Floor, No. 82 Shi Men Yi Road

Jing' an District

200040 Shanghai, PRC

Tel: +86 21 6157 3500

Fax: +86 21 6157 3511

E-mail: [email protected],

Internet: www.miele.cn

China Mainland

Miele (Hong Kong) Ltd.

41/F - 4101, Manhattan Place

23 Wang Tai Road

Kowloon Bay, Hong Kong

Tel: (852) 2610 1025

Fax: (852) 3579 1404

Email:

[email protected]

Website: www.miele.hk

Hong Kong, China

Miele India Pvt. Ltd.

1st Floor, Copia Corporate Suites,

Commercial Plot 9,

Mathura Road, Jasola,

New Delhi - 110025

E-mail: customercare@miele.in

Website: www.miele.in

India

Miele Ireland Ltd.

2024 Bianconi Avenue

Citywest Business Campus

Dublin 24

Tel: (01) 461 07 10

Fax: (01) 461 07 97

E-Mail: [email protected]

Internet: www.miele.ie

Ireland

Malaysia

Miele Sdn Bhd

Suite 12-2, Level 12

Menara Sapura Kencana

Petroleum

Solaris Dutamas No. 1

Jalan Dutamas 1

50480 Kuala Lumpur, Malaysia

Phone: +603-6209-0288

Fax: +603-6205-3768

Miele New Zealand Limited

IRD 98 463 631

8 College Hill

Freemans Bay, Auckland 1011

New Zealand

Tel: 0800 464 353

Internet: www.miele.co.nz

New Zealand

Miele Pte. Ltd.

29 Media Circle

#11-04 ALICE@Mediapolis

Singapore 138565

sTel: +65 6735 1191

Fax: +65 6735 1161

E-Mail: [email protected]

Internet: www.miele.sg

Singapore

Miele (Pty) Ltd.

63 Peter Place

Bryanston 2194

P.O. Box 69434

Bryanston 2021

Tel: (011) 875 9000

Fax: (011) 875 9035

E-mail: [email protected]

Internet: www.miele.co.za

South Africa

Miele Appliances Ltd.

Showroom 1

Eiffel 1 Building

P.O. Box 114782 - Dubai

Tel. +971 4 3044 999

Fax. +971 4 3418 852

800-MIELE (64353)

E-Mail: [email protected]

Website: www.miele.ae

United Arab Emirates

Manufacturer:

Miele & Cie. KG, Carl-Miele-Straße 29, 33332 Gütersloh, Germany

Thailand

Miele Appliances Ltd.

BHIRAJ TOWER at EmQuartier

43rd Floor Unit 4301-4303

689 Sukhumvit Road

North Klongton Sub-District

Vadhana District

Bangkok 10110, Thailand

Sheikh Zayed Road, Umm Al Sheif

M.-Nr. 10 838 150 / 03en-GB

K 31222 Ui, K 31242 UiF

Miele K 31242 UiF – Refrigeration

Product's Documents

User Manual

Specifications

Miele K 31242 Questions and Answers
