FF7WBIIF
33.25" x 23.63" x 23.5" (H x W x D)
Commercially listed built-in undercounter all-refrigerator for
general purpose use, auto defrost w/integrated door frame
for overlay panels and white cabinet
Highlights:
Commercially approved for use in food service
establishments
Flexible design allows built-in or freestanding use in 24"
spaces
Customizable door front accepts full overlay panels for a
seamless look that can blend into cabinetry
Product Features:
Commercially approved ETL-S listed to NSF-7 Standards for use in commercial establishments
Slim undercounter dimensions Less than 24 inches wide, with a generous 5.5 c.f. of storage capacity
Built-in capable Make the best use of space by installing your appliance under the counter and flush with
other cabinetry
Integrated door frame Customize the front by mounting an overlay panel over the door; seamless look can blend
into other cabinetry with no exposed frame. Handle not included (panel size: 23 5/16" W x 28
1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
Adjustable shelves Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for
a simple clean-up
Automatic defrost Reduced user maintenance with automatic defrost
Deep shelf space Interior can accommodate large trays up to 19 1/2" x 15 1/2"
One piece interior liner Simple cleanup with a seamless liner that won't hold a mess in hidden crevices
Hidden evaporator Cold wall design with hidden evaporator and seamless interior
SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified
770 Garrison Avenue Bronx, NY 10474 USA TEL 718-893-3900 FAX 844-478-8799 inf[email protected] www.summitappliance.com
background
FF7WBIIF Specifications:
Overview
Height of Cabinet 32.63" (83 cm)
Height to Hinge Cap 33.25" (84 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Depth with door at 90° 46.0" (117 cm)
Capacity 5.5 cu.ft. (156 L)
Defrost Type Automatic
Door Panel-Ready
Cabinet White
US Electrical Safety ETL
Canadian Electrical
Safety
ETL-C
Sanitation ETL-S
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 100.0 lbs. (45 kg)
Shipping Weight 105.0 lbs. (48 kg)
Estimated Time to Ship 2 to 4 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Factory Reversible
Shelf Type Wire
Shelf Qty 3
Adjustable Shelves Yes
Thermostat Type Dial
Fan Type Exterior
Refrigerant Type R600a
Refrigerant Amount 0.64oz.
High Side PSI 180.0
Low Side PSI 80.0
Level Legs Qty 4
Interior Light Yes
Dimensions
Interior Height 27.75" (70 cm)
Interior Width 20.0" (51 cm)
Interior Depth 17.5" (44 cm)
Compressor Step Height 7.0" (18 cm)
Compressor Step Width 20.0" (51 cm)
Compressor Step Depth 6.0" (15 cm)
SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified
770 Garrison Avenue Bronx, NY 10474 USA TEL 718-893-3900 FAX 844-478-8799 inf[email protected] www.summitappliance.com
