807650601 February 2013
EN FREEZER / REFRIGERATOR
FR RÉFRIGÉRATEUR / CONGÉLATEUR
ES REFRIGERADOR CON CONGELADOR
USE AND CARE GUIDE
GUIDE D’UTILISATION ET D’ENTRETIEN
GUIA DE USO Y CUIDADO
2
Finding Information
Please read and save this guide
Thank you for choosing Electrolux, our new premium
brand in home appliances. This Use & Care Guide is
part of our commitment to customer satisfaction and
product quality throughout the service life of your new
appliance.
Purchase date
Electrolux model number
Electrolux serial number
Keep a record for quick
reference
Finding Information .............................................. 2
Safety ............................................................... 3
Feature Overview ................................................. 5
Installation ......................................................... 6
Removing the Doors ............................................11
Installing Door Handles ........................................13
Connecting the Water Supply ..................................14
Controls ...........................................................15
Automatic Ice & Water Maker/Dispenser ....................20
Automatic Ice Maker - Freezer ................................22
Storage Features ................................................23
Storing Food and Saving Energy ..............................28
Normal Operating Sounds ......................................29
Changing the Water and Air Filters ...........................30
Care and Cleaning ...............................................32
Solutions to Common Problems ...............................35
Warranty ..........................................................39
Table of contents
Questions?
For toll-free telephone support in the U.S. and Canada:
1-877-4ELECTROLUX (1-877-435-3287)
For online support and product information visit
http://www.electroluxappliances.com
NOTE
Registering your product with Electrolux enhances
our ability to serve you. You can register online at
www.electroluxappliances.com or by sending your
Product Registration Card in the mail.
Doors
Handles are secure and tight
Door seals completely to cabinet on all sides
Freezer drawer is level across top
Leveling
Refrigerator is level, side-to-side and tilted ¼
(6mm) front-to-back
Toe grille is properly attached to refrigerator
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker
House water supply connected to refrigerator
No water leaks present at all connections -
recheck in 24 hours
Ice maker is turned ON
Ice & water dispenser operates correctly
Front filter must be flush with filter housing
(select models)
Final Checks
Shipping material removed
Fresh food and freezer temperatures set
Crisper humidity controls set
Registration card sent in
Installation Checklist
3
Safety
Important safety instructions
General Safety
Safety Precautions
Do not attempt to install or operate your unit until
you have read the safety precautions in this manual.
Safety items throughout this manual are labeled with a
Danger, Warning, or Caution based on the risk type.
Definitions
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
• Donotstoreorusegasolineorotherammable
liquids near this or any other appliance.
Read product labels for warnings regarding
flammability and other hazards.
• Donotoperatetherefrigeratorinthepresenceof
explosive fumes.
• Avoidcontactwithanymovingpartsofthe
automatic ice maker.
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
IMPORTANT
Indicates installation, operation, or maintenance
information which is important but not hazard-related.
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
WARNING
Please read all safety instructions before using
your new refrigerator.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
• Removeallstaplesfromthecartontoavoid
injury. Staples can also damage finishes if
they come in contact with other appliances or
furniture.
Child Safety
Packing Materials:
• Packingcartonscoveredwithrugs,bedspreads,
plastic sheets, or stretch wrap may become
airtight chambers and can quickly cause
suffocation.
• Destroyorrecycletheproduct’scarton,plastic
bags, and any other exterior wrapping material
immediately after the refrigerator is unpacked.
Children should never play with these items.
Child Entrapment and Suffocation:
• Theseproblemsarenotlimitedtothepast.
Whether junked, abandoned, or temporarily
stored (even for a few hours), unattended
refrigerators and freezers are dangerous. Please
take the precautions listed below.
Proper Disposal of Refrigerators/Freezers
We strongly encourage responsible appliance recycling/
disposal methods. Check with your utility company or
visit www.energystar.gov/recycle for more information
on recycling your old refrigerator.
Before you recycle or dispose of your old refrigerator/
freezer:
• Removethedoors.
• Leavetheshelves
and baskets in place
so children may not
easily climb inside.
• Haverefrigerant
and compressor
oil removed by a
qualified service
technician.
4
• The refrigerator must be plugged into its own
dedicated 115 Volt, 60 Hz, AC-only non-GFCI
electric outlet. The power cord of the appliance
is equipped with a three-prong grounding plug for
your protection against electrical shock hazards.
It must be plugged directly into a properly
grounded three-prong receptacle. The receptacle
must be installed in accordance with local codes
and ordinances. Consult a qualified electrician.
Do not use an extension cord or adapter plug.
• Ifthepowercordisdamaged,itshouldbe
replaced by the manufacturer, service technician,
or a qualified person.
• Neverunplugtherefrigeratorbypullingonthe
powercord.Alwaysgriptheplugrmlyand
pull straight out from the receptacle to prevent
damaging the power cord.
• Toavoidelectricalshock,unplugtherefrigerator
before cleaning and before replacing a light bulb
or LED light.
• Performancemaybeaffectedifthevoltagevaries
by 10% or more. Operating the refrigerator with
insufficient power can damage the compressor.
Such damage is not covered under your warranty.
• Donotplugtheunitintoanoutletcontrolledbya
wall switch or pull cord to prevent the refrigerator
from being turned off accidentally.
Electrical information
Grounding type wall receptacle
Power cord with 3-prong
grounded plug
Do not, under any
circumstances,
cut, remove, or
bypass the
grounding prong.
Safety
WARNING
You must follow these guidelines to ensure
that your refrigerator’s safety mechanisms are
operating correctly.
IMPORTANT
To turn off power to your refrigerator, unplug the
power cord from the wall outlet.
5
Feature Overview
Understanding features and terms
Your Electrolux refrigerator is designed for optimal convenience and storage flexibility. The illustration below is
provided to assist you with familiarizing yourself with product features and terminology.
NOTE
*Features may vary according to model. Model is shown without freezer drawer cover.
*Wire Shelf
(inside freezer drawer)
IMPORTANT
Features not included with your refrigerator can be
purchased at www.electroluxappliances.com or by
calling 1-877-435-3287.
Luxury-Glide
TM
Crisper
Drawer
Luxury-Design
TM
Shelves
*Special
Items Mat
(Inside PTD)
LED Lights
Water Filter
Removable
Ice Bin
Soft-Closing *Perfect Temp
TM
Drawer (PTD) or Deli Drawer
(with humidity slides)
Freezer Baskets
with organizers
*LED Light
*Soft
Freeze
Bin
Toe Grille
*Tilt
Can Bin
Luxury-Design
TM
Shelves
Flipper Mullion
*Air Filter
*LED Light
Flipper GuideIce Maker
Ice Bin
*Freezer Ice Maker
Luxury-Glide
TM
Crisper
Drawer
6
Installation
This Use & Care Guide provides general installation
and operating instructions for your model. We
recommend using a service or kitchen contracting
professional to install your refrigerator. Use the
refrigerator only as instructed in this Use & Care
Guide. Before starting the refrigerator, follow these
important first steps.
Location
• Chooseaplacethatisnearagrounded,non-
GFCI, electrical outlet. Do Not use an extension
cord or an adapter plug.
• Ifpossible,placetherefrigeratoroutofdirect
sunlight and away from the range, dishwasher, or
other heat sources.
• Therefrigeratormustbeinstalledonaoorthat
is level and strong enough to support a fully
loaded refrigerator.
• Considerwatersupplyavailabilityformodels
equipped with an automatic ice maker.
Installation
• Allowthefollowingclearancesforeaseof
installation, proper air circulation, and plumbing
and electrical connections:
Sides & Top ⅜ inch (9.5 mm)
Back 1 inch (25.4 mm)
Door opening
Your refrigerator should be positioned to allow easy
access to a counter when removing food. For best
use of refrigerator drawers and freezer baskets, the
refrigerator should be in a position where both can be
fully opened.
CAUTION
DO NOT install the refrigerator where the
temperature will drop below 55° F (13° C) or rise
above 110° F (43° C). The compressor will not be
able to maintain proper temperatures inside the
refrigerator.
DO NOT block the toe grille on the lower front
of your refrigerator. Sufficient air circulation
is essential for the proper operation of your
refrigerator.
NOTE
If your refrigerator is placed with the door hinge
against a wall, you may have to allow additional space
so the door can be opened wider.
NOTE
The refrigerator doors are designed to shut by
themselves within a 20 degree opening.
Phillips™
Head or
#2 Square Drive
Head
(OR)
AND OR
Socket
Wrench Set
Adjustable
Wrench
OR
Tools Necessary:
3/8" Fixed
Wrench
Top Hinge
Cover Front
Screw
Top Hinge
Cover Rear
Screw
Lower
Hinge
Screw
Top
Hinge
Screw
Components Provided:
Required Tools
You will need the following tools:
7
Installation
Toe Grille Must
Fit in Slot on
Anti-tip Bracket
Screw/Washer
Assembly
(3) Retaining Clips
Freezer Drawer Alignment (if necessary)
To level the cabinet using the front rollers:
1 Slightly open freezer drawer. Lift the toe grille and
gently pull forward (see illustration).
2 You can raise or lower each door. Use a ⅜ inch
socket wrench to turn the adjustment screws
(1 per side).
1 Check gasket seal around top, bottom, and sides
of freezer drawer.
2 If gasket is not sealed, open drawer and slightly
loosen four drawer screws (two on each side) to
allow drawer to rotate.
3 Close drawer and recheck the seal on the gasket
(A).Openthedrawergrabbingbythesidesinthe
center (B). Be careful not to rotate the drawer.
4 Tighten four drawer screws.
5 Recheck gasket seal.
Push
Against
Freezer
Drawer
Grab
Drawer
At Center
From
Both
Sides
Then
Pull Drawer
Out
A B
Cabinet Leveling & Refrigerator
Door Alignment (if necessary)
Guidelines for final positioning of your refrigerator:
• Allfourcornersofthecabinetmustrestrmlyon
the floor.
• Thesidesshouldtilt¼ inch (6 mm) from front
to back (to ensure that doors close and seal
properly).
• Doorsshouldalignwitheachotherandbelevel.
Most of these conditions can be met by raising or
lowering the adjustable front rollers.
Raise
Lower
Anti-tip
Leg
Door
Door
To raise: turn adjustment screw clockwise.
To lower: turn adjustment screw counterclockwise.
3 Ensure both doors are bind-free with their seals
touching the cabinet on all four sides and that
cabinet is stable.
4 Afterunitisleveled,loweranti-tipleguntilit
contacts the floor.
5 Install the toe grille by fitting into place.
Remove Hex
Head Drawer
Screw
Remove
Hex Head
Drawer
Screw
Do Not Remove
Other Screws
Remove Hex
Head Drawer
Screw
Remove
Hex Head
Drawer
Screw
8
Installation
To adjust the door stop:
Door stop is adjustable between 85 to 145 degrees.
1 Open door to provide access to screw.
2 Loosen screw.
3 Adjustdoortodesiredlocation.
4 Rotate door stop until it makes contact with the
lower hinge.
5 Re-tighten screw.
Open
Door
90
Degrees
Loosen or Remove
Screw
Bottom of Door
Loosen/Remove Screw (where applicable)
6 Ensure door stops in desired location before
resuming normal use.
To level the doors using the adjustable lower hinge
(select models):
1 Remove all food items from door bins on door
being adjusted.
2 Open doors to 90 degrees.
3 Loosen or remove screw.
Rotate
Door to Desired
Location
Adjusting Door
Rotate
Door
Stop
Re-tighten
Screw
Re-tighten Screw
NOTE
View shown is looking up at the bottom of the
refrigerator door.
Adjustable Door Stop
Door
Stop
Screw
Lower
Hinge
Min
Open
Max
Open
NOTE
Adjustablehingeshouldonlybeusedafterdoors
have been leveled with rollers.
9
Installation
Screw
Flipper
Mullion
Hinge
Flipper
Mullion
Adjusting Flipper Mullion Screw
To adjust the flipper mullion:
1 Loosen the screw located on the flipper mullion
hinge.
2 Adjustippermullionheight.Forproper
connection with the flipper mullion guide, there
should be a separation about the thickness of a
coin (0.060 inches, or 1.5 mm) between the guide
and flipper mullion.
3 Re-tighten screw.
4 Lift the door while adjusting the washer. To
raise the door, rotate washer clockwise (when
viewed from the bottom). To lower door, rotate
washer counter-clockwise (when viewed from the
bottom).
5 Re-tighten the screw (where applicable), ensuring
it is between the spokes of the washer. Screw
will not be tight, just insert until it is flush with the
hinge.
Flipper
Mullion
Mullion
Guide
Thickness
of a Coin
Adjusting Flipper Mullion Height
Screw (where applicable)
Raising/Lowering Door
NOTE
If after adjusting doors higher the door makes a
popping/clicking sound, remove screw and replace
with the longer one supplied in the handle package.
Re-tighten Screw
Hinge
Washer Spokes
Screw
Lower
Door
Hinge
Washer
Raise
Door
Door
10
Installation
Installing Shelves
Your refrigerator was shipped with the shelf hanger
and shelf locking clip installed in their shipping position.
Below are the instructions to install the shelves in your
desired locations.
1 Remove shelf from its locked position by pulling
the slide mechanism toward you.
2 Lift the hanger directly upwards and pull toward
you to remove it from the ladder.
3 Place top hooks of the hanger into the desired
slot, and lower straight down until lower hooks
rest on the ladder.
4 Relock shelf by pushing the slide mechanism
away from you.
6 Gently set the shelf onto the hanger once the
back is secured by the hanger.
5 While holding shelf at a 45-degree angle with the
gray handle facing you, push the shelf into the
back of the hanger.
CAUTION
Shelves must be removed prior to moving the
refrigerator.
11
Approximately
5 Feet
Water
Line
Press
Press
2 Disconnect the harness by grasping both sides of
the connector firmly, depress the latch, and pull
apart. Remove the two screws from the top hinge.
Lift the door off of the bottom hinge and set it aside.
3 Detach the water tube from the connector located
behind the refrigerator and pull the tube back out
to the front of the unit. The connector releases
when you press inward on the outer sleeve while
pushing the tube toward the connector then while
continuing to hold in the sleeve, pull the tube away.
4 Unscrew the three lower hinge screws and hinge
if necessary.
Removing the Doors
Getting through narrow spaces
If your refrigerator will not fit through an entrance area,
you can remove the doors. Check first by measuring the
entrance.
To prepare for removing the doors:
1 Make sure the electrical power cord is unplugged
from the wall outlet.
2 Open the freezer drawer and remove the toe
grille (see Installation section).
3 Remove any food from the door shelves and
close the doors.
To remove the top hinge covers:
1 Remove the two screws from each cover over the
top door hinges.
2 Lift inside edge of hinge cover and tilt back.
NOTE
DO NOT remove the ground screw from hinge.
Rear
Cover
Screw
Ground
Screw
Top
Hinge
Top Hinge
Cover
Hinge
Screws
Multi-wire
Cables
Leave
Hinge
With
Door
Front
Cover Screw
Water
Line
Rear
Cover
Screw
Top
Hinge
Ground
Screw
Front
Cover Screw
Top Hinge
Cover
Hinge
Screws
Two Wire
Cables
Leave
Hinge
With
Door
NOTE
Use care while pulling the water tube from the unit to
be sure that you do not kink the tube.
To remove the refrigerator doors:
1 Tracelightlyaroundthedoor’stophingeswitha
pencil. This makes reinstallation easier.
12
Removing the Doors
Once both doors are in place, ensure they are aligned
with each other and level (Please see the Installation
section for more details), and replace the top hinge cover.
CAUTION
Be sure doors are set aside in a secure position
where they cannot fall and cause personal injury,
or damage to the doors or handles.
NOTE
You will be pulling approximately five feet of water
tube from the back of the refrigerator.
Lower Hinge Removal
To reinstall the right door, reverse the above steps.
Removing Freezer Drawer
1 Open freezer drawer.
2 Remove drawer screws on right and left sides
(two screws on each side).
3 Lift drawer up and out to remove.
Installing Freezer Drawer
1 With lower slides pulled out, hang drawer onto
slide brackets ensuring pins on each side are
fully inserted into slots on each side.
CAUTION
Drawer is heavy. Use caution when lifting.
6 Tighten four drawer screws.
7 Recheck gasket seal.
8 Install the toe grille by fitting into place.
2 Reinstall four drawer screws (two per side),
tighten down, and close drawer (C).
Push
Against
Freezer
Drawer
Grab
Drawer
At Center
From
Both
Sides
Then
Pull Drawer
Out
A B
Assembly
Pin
Slot
Cabinet
Fully Extend
Drawer Slides
3 Check gasket seal around top, bottom, and sides
of freezer drawer.
4 If gasket is not sealed, open drawer and slightly
loosen four drawer screws (two on each side) to
allow drawer to rotate.
5 Close drawer and recheck the seal on the gasket
(A).Openthedrawergrabbingbythesidesinthe
center (B). Be careful not to rotate the drawer.
Install Hex
Head
Drawer
Screws
NOTE
When reinserting the water tube and replacing the top
hinge cover, use care to be sure you do not kink the
tube.
13
Installing Door Handles
Door Handle
Mounting
Instructions
1 Remove handles from
protective packaging.
2 Position fresh food handle
endcaps(A)overupperand
lower pre-installed shoulder
bolts (B) that are fastened
into door, ensuring the holes
for the set screws are facing
towards the opposite door.
3 While holding handle firmly
against door, fasten upper
andlowerAllensetscrews
(C)withsuppliedAllen
wrench.
4 Repeat steps 2 and 3 to
install opposite handle.
Ensure the holes for the set
screws are facing towards the
first door.
5 Position freezer handle end
caps over left and right pre-
installed shoulder bolts that
are fastened to the drawer,
ensuring the holes for the set
screws are facing down.
6 While holding handle firmly
against drawer, fasten left and
rightAllensetscrews(C)with
suppliedAllenwrench.
End
Cap
End
Cap
End
Cap
End
Cap
Mounting Refrigerator Handles
End
Cap
End
Cap
Mounting Freezer Handle
NOTE
To ensure that handles are flush with doors/drawer, make sure that set screws are completely tightened.
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
14
Connecting the Water Supply
Before installing the water supply line, you will need:
1. Basic Tools: adjustable wrench, flat-blade
screwdriver, and Phillips
TM
screwdriver
2. Accesstoahouseholdcoldwaterlinewithwater
pressure between 30 and 100 psi.
3. Awatersupplylinemadeof¼inch(6.4mm)OD,
copper or stainless steel tubing. To determine the
length of tubing needed, measure the distance
from the ice maker inlet valve at the back of
the refrigerator to your cold water pipe. Then
add approximately 7 feet (2.1 meters), so the
refrigerator can be moved out for cleaning (as
shown).
4. Ashutoffvalvetoconnectthewatersupplyline
to your household water system. DO NOT use a
self-piercing type shutoff valve.
5. Do NOT reuse compression fitting or use thread
seal tape.
6. Acompressionnutandferrule(sleeve)for
connecting a copper water supply line to the ice
maker inlet valve.
To connect water supply line to ice maker inlet valve:
1. Disconnect refrigerator from electric power source.
2. Place end of water supply line into sink or bucket.
Turn ON water supply and flush supply line until
water is clear. Turn OFF water supply at shutoff valve.
3. Remove plastic cap from water valve inlet and
discard cap.
4. If you use copper tubing - Slide brass
compression nut, then ferrule (sleeve) onto water
supply line. Push water supply line into water
valveinletasfarasitwillgo(¼inch/6.4mm).
Slide ferrule (sleeve) into valve inlet and finger
tighten compression nut onto valve. Tighten
another half turn with a wrench; DO NOT over
tighten. See Figure 1.
If you use stainless steel tubing - The nut and
ferrule are already assembled on the tubing.
Slide compression nut onto valve inlet and finger
tighten compression nut onto valve. Tighten
another half turn with a wrench; DO NOT over
tighten. See Figure 2.
5. With steel clamp and screw, secure water
supply line (copper tubing only) to rear panel of
refrigerator as shown.
6. Coil excess water supply line (copper tubing
only), about 2½ turns, behind refrigerator as
shown and arrange coils so they do not vibrate or
wear against any other surface.
7. Turn ON water supply at shutoff valve and tighten
any connections that leak.
8. Reconnect refrigerator to electrical power source.
9. To turn ice maker on, lower wire signal arm (freezer
icemaker)orsettheicemaker’sOn/Offpower
switch to the On position (fresh food ice maker).
Figure 2Figure 1
WARNING
To avoid electric shock, which can cause death or
severe personal injury, disconnect the refrigerator
from electrical power before connecting a water
supply line to the refrigerator.
CAUTION
To Avoid Property Damage:
• CopperorStainlessSteelbraidedtubingis
recommended for the water supply line. Water
supply tubing made of ¼ inch plastic is not
recommended to be used. Plastic tubing greatly
increases the potential for water leaks, and the
manufacturer will not be responsible for any
damage if plastic tubing is used for the supply
line.
• DONOTinstallwatersupplytubinginareas
where temperatures fall below freezing.
• Chemicalsfromamalfunctioningsoftener
can damage the ice maker. If the ice maker
is connected to soft water, ensure that the
softener is maintained and working properly.
IMPORTANT
Ensure that your water supply line connections
comply with all local plumbing codes.
NOTE
Check with your local building authority for recommendations on water lines and associated materials prior to installing
your new refrigerator. Depending on your local/state building codes, Electrolux recommends for homes with existing
valves its Smart Choice
®
water line kit 5305513409 (with a 6 ft. Stainless Steel Water Line) and for homes without an
existing valve, Electrolux recommends its Smart Choice
®
water line kit 5305510264 (with a 20 ft. Copper Water Line
with self-tapping saddle valve). Please refer to www.electroluxappliances.com for more information.
Plastic Water Tubing
to Ice Maker
Fill Tube
Steel
Clamp
Brass
Compression
Nut
Ferrule
(Sleeve)
Copper
water line
Water Valve
Bracket
Valve Inlet
Water Valve
Copper water line
from household
water supply
(Include enough tubing in loop to allow
moving refrigerator out for cleaning)
Plastic water tubing
to ice maker
fill tube
Stainless
steel
water line
Water valve
bracket
Valve inlet
Water valve
6 ft. stainless steel water line
from household water supply
15
Controls
Wave-Touch
TM
IQ-Touch
TM
16
Controls
Wave-Touch
TM
(select models)
Your refrigerator is equipped with a Wave-Touch
TM
control panel display. It is only necessary to gently
touch the glass. There are three levels of display.
1
st
Level: Sleep Mode
Sleep Mode displays only the WATER, CUBES and
CRUSHED options. Touch an icon to activate the
desired dispenser mode. The active dispenser mode is
more brightly illuminated.
2
nd
Level: Awakened Display Mode
The control panel is awakened by touching anywhere
on the glass where there is an indicator. Black space
willnotawakenthedisplay.After10secondsof
inactivity, the control panel will return to the Sleep mode.
The following dispenser options are illuminated:
ice off Press and hold for three seconds to turn the ice
maker ON or OFF. The ice maker is OFF when the
LED above the Ice Off icon is illuminated. If there is
no indicator, then the ice maker is ON. Turning the
ice maker OFF disables the ice dispensing feature.
Neither CUBES nor CRUSHED will operate with the
ice maker OFF.
fast freeze Activates a faster rate for freezing food and
increased ice production.
3
rd
Level: User Variable Options
Touching the options icon displays the following options:
vacation mode Conserves energy by increasing the time
between automatic defrost. This feature is auto-
matically activated during long periods between
door openings. Vacation mode is manually
activated when the indicator is lit.
water filter Touch to display filter condition status. Press
and hold for three seconds to reset after filter
change.
air filter Touch to display filter status. Press and hold for
three seconds to reset after filter change.
temp display When active, it allows the display of the freezer
and fridge temps during Sleep Mode. The tem-
perature is displayed when the indicator is lit.
temp mode Touch to toggle display from Fahrenheit to
Celsius.
mute sounds Tones emitted by each keypress can be turned
off based on user preference. The sounds are
muted when the indicator is lit. Warning signals
will stay active.
factory default Resets all refrigerator settings such as temp,
temp display, and alarm tones to their factory
default settings.
on off Press and hold for three seconds to turn off the
cooling system to clean the refrigerator. It also
turns off the ice maker, all dispenser functions,
and the Perfect Temp
TM
drawer (select models).
The temperature display will read OFF.
IMPORTANT
Pressing the system on/off icon does not turn off
power to your refrigerator. You must unplug the power
cord from the wall outlet.
IMPORTANT
When the ice maker is turned off, the ice in the bucket
should be transferred to the freezer or discarded to
prevent it from melting.
(Fresh Food
Ice Maker)
NOTE
Refer to Automatic Ice Maker-Freezer section for
freezer ice maker controls.
dispenser light On / Off
control lock Press and hold for three seconds to activate and
deactivate. This restricts undesired changes to
the refrigerator’s settings and prevents use of
the ice and water dispenser.
17
Controls
Alarms
Door Ajar If the door has been left open for an extended
period of time, an alarm will sound and the door
ajar indicator will display on the center of the
display. The alarm is turned off by closing the
door. The alarm off key will blink to prompt the
reset of any pending alarms. Press this key to
reset any system alarms.
High Temp In the event of a high temperature condition,
the temperature display will blink and display
HI. After 20 minutes, the high temp alert will be
displayed and the alarm off icon will illuminate
until pressed, acknowledging the alarm, at which
time the highest temperature reached will be dis-
played and the refrigerator will resume normal
operation. All other modes are turned off until
the alarm is acknowledged.
Power Fail In the event of a power failure, the power fail
alert will be displayed and the alarm off key
will blink until the alarm off icon is pressed,
acknowledging the alarm. Other modes may
be turned off until the alarm is acknowledged.
When the power fail alert is turned off, the
refrigerator will resume normal operation. The
high temp alarm may also be illuminated until
a safe operating range temperature has been
reached.
Setting cooling temperatures
1 Touch the glass panel to illuminate the 2
nd
level of
display.
2 Select the options icon.
Plus (+) and minus (-)
indicators will appear on
either side of the displayed
temperatures.
3 Press the + or – indicator
to adjust the temperature to the desired setting.
The temperature display will begin to blink with
thersttouch.Aftervesecondsofinactivity,the
display will beep to accept the new temperature.
After10seconds,thedisplaytimesoutand
returns to the basic display.
The Sabbath Mode is a feature that disables portions of
the refrigerator and its controls for both Wave-Touch
TM
and IQ-Touch
TM
, in accordance with observance of
the weekly Sabbath and religious holidays within the
Orthodox Jewish community.
Wave-Touch
TM
/ IQ-Touch
TM
Sabbath Mode
Sabbath Mode is turned on and off by pressing and
holding both the outermost – and + indicators for five
seconds for both the Wave-Touch
TM
and IQ-Touch
TM
modes. The display shows Sb while in Sabbath mode.
In the Sabbath Mode, the high temp alarm is active for
health reasons. If a high temp alarm is activated during
this time, for example due to a door left ajar,
the alarm will sound intermittently for about
10 minutes. The alarm will then silence on
its own and a high temp icon will display.
The high temp icon will continue to display, even if the
door is closed, until the Sabbath mode is exited and the
icon reset. The refrigerator will function normally once
the door is closed, without any violation of the Sabbath/
Holidays.
For further assistance, guidelines for proper usage and
a complete list of models with the Sabbath feature,
please visit the web at http:\\www.star-k.org.
NOTE
While in Sabbath Mode, neither the lights, dispenser,
nor the control panel will work until Sabbath Mode is
deactivated.
Refrigerator stays in Sabbath Mode after power failure
recovery. It must be deactivated with the buttons on
the control panel.
NOTE
While in Sabbath Mode, the Wave-Touch
TM
model will
only illuminate the –/+ keys used to turn the Sabbath
Mode Off.
18
Controls
NOTE
AlthoughyouhaveenteredtheSabbathMode,theice
maker will complete the cycle it had already initiated.
The ice cube compartment will remain cold and new
ice cubes can be made with standard trays.
Sabbath Mode and the Perfect Temp
TM
Drawer
The Perfect Temp
TM
Drawer should be turned off for the
Sabbath/Holidays. Before putting the refrigerator into
the Sabbath mode, turn the Perfect Temp
TM
Drawer off
by pressing the drawer on/off button. The display will
show OFF and the drawer will turn off. Then enter the
Sabbath mode function on the main refrigerator display.
(See Wave-Touch/IQ-Touch Sabbath Mode section.)
When in Sabbath mode, the display will not illuminate
and the drawer will remain off. The drawer can still be
used as a non-temp controlled drawer in this mode.
When the refrigerator is taken out of Sabbath mode, the
Perfect Temp
TM
Drawer will have to be turned back on.
NOTE
If the Perfect Temp
TM
Drawer is not turned off prior
to putting the unit into Sabbath Mode, it will continue
to adjust itself to maintain the set point even if the
display does not illuminate to show that it is still on.
IQ-Touch
TM
(select models)
Your refrigerator is equipped with a glass touch control
panel. It is only necessary to gently touch the glass.
There are three dispenser modes:
1 Water
2 Ice Cubes
3 Crushed Ice
Anindicatorlightwillbeilluminatedabovetheactive
feature.
Touch the icon to activate the options below.
ice off Press and hold for three seconds to turn the ice
maker ON or OFF. The ice maker is OFF when the
LED above the Ice Off icon is illuminated. If there is
no indicator, then the ice maker is ON. Turning
the ice maker OFF disables the ice dispensing
feature. Neither CUBES nor CRUSHED will oper-
ate with the ice maker OFF.
fast freeze Activates a faster rate for freezing food and
increased ice production.
(Fresh Food
Ice Maker)
NOTE
Refer to Automatic Ice Maker-Freezer section for
freezer ice maker controls.
dispenser light On / Off
control lock Press and hold for three seconds to activate and
deactivate. This restricts undesired changes to
the refrigerators settings and prevents use of the
ice and water dispenser.
vacation mode Conserves energy by increasing the time
between automatic defrost. This feature is auto-
matically activated during long periods between
door openings. Vacation mode is manually
activated when the indicator is lit.
water filter Touch to display filter condition status. Press
and hold for three seconds to reset after filter
change.
air filter Touch to display filter status. Press and hold for
three seconds to reset after filter change.
19
Controls
Setting cooling temperatures
1 Touch the control panel to illuminate plus (+)
and minus (–) indicators on either side of the
temperatures displays.
2 Press the + or – indicator to adjust the
temperature to the desired setting.
The temperature display will begin to blink with
the first touch. The display will time out after a
minute and returns to the basic display.
IMPORTANT
Pressing the system on/off icon does not turn off
power to your refrigerator. You must unplug the power
cord from the wall outlet.
IMPORTANT
When the ice maker is turned off, the ice in the bucket
should be transferred to the freezer or discarded to
prevent it from melting.
temp display Touch to toggle the freezer and fridge temp
display on and off.
Touch and hold temp display to toggle display
from Fahrenheit to Celsius.
mute sounds Tones emitted by each key press can be turned
off based on user preference. The sounds are
muted when the indicator is lit. Warning signals
will stay active.
factory default Resets all refrigerator settings such as temp,
temp display, and ring tones to their factory
default settings.
on off Press and hold for three seconds to turn off the
cooling system to clean the refrigerator. It also
turns off the ice maker and all dispenser func-
tions. The temperature display will read OFF.
Door Ajar If the door has been left open for an extended
period of time, an alarm will sound and the door
ajar indicator will display on the right side of the
control panel. The alarm is turned off by closing
the door. The mute sounds key will blink to
prompt the reset of any pending alarms. Press
this key to reset any system alarms.
High Temp In the event of a high temperature condition,
the temperature display will blink and display
HI. After 20 minutes, the high temp alert will be
displayed and the alarm off icon will illuminate
until pressed, acknowledging the alarm, at which
time the highest temperature reached will be dis-
played and the refrigerator will resume normal
operation. All other modes are turned off until
the alarm is acknowledged.
Power Fail In the event of a power failure, the power fail
alert will be displayed and the temperature
display will blink until the mute sounds icon is
pressed, acknowledging the alarm. Other modes
may be turned off until the alarm is acknowl-
edged. The power fail alert is turned off and the
refrigerator will resume normal operation. The
high temp alarm may also be illuminated until
a safe operating range temperature has been
reached.
Alarms
20
Automatic Ice & Water Maker/Dispenser
Priming the water supply system
1 Begin filling the tank by pressing and holding a
drinking glass against the water dispenser paddle.
2 Keep the glass in
this position until
water comes out
of the dispenser. It
may take about
1½ minutes.
3 Continue
dispensing water for
about three minutes
to flush the system
and plumbing
connections of any impurities (stopping to empty
the glass as necessary).
Ice maker operation & care
Aftertherefrigeratorisinstalledproperlyandhas
cooled for several hours, the ice maker can produce
ice within 24 hours. The ice maker will fill the ice bin
from the rear. You must dispense some ice to force
the ice forward in the bin. This will allow the bin to fill
completely.
Turning the fresh food ice maker on and off
Iceproductioniscontrolledbytheicemaker’sOn/Off
icon on the control panel. Press and hold the Ice Off
icon for three seconds to turn the ice maker ON or OFF.
If there is no indicator, then the ice maker is ON.
IMPORTANT
Your ice maker is turned on at the factory so it can work
as soon as you install your refrigerator. If you cannot
connectawatersupply,settheicemaker’sOn/Officon
to Off and turn off the water supply valve; otherwise, the
icemaker’sllvalvemaymakealoudchatteringnoise
when it attempts to operate without water.
CAUTION
For proper dispenser operation, recommended
water supply pressure should fall between 30 psi
and 100 psi. Excessive pressure may cause water
filter to malfunction.
NOTE
The water dispenser has a built-in device that shuts
off the water flow after three minutes of continuous
use. To reset this shutoff device, simply release the
dispenser paddle.
NOTE
The ice maker also has a built-in plastic signal bale
arm that automatically stops ice production when the
ice bin is full. This signal arm should not be used to
manually stop the ice maker.
IMPORTANT
Turning off the ice maker will result in existing ice
melting in the bin.
IMPORTANT
Turning off the ice maker will disable the ice
dispenser. You will still be able to dispense water.
Using the ice maker after installation
Before making ice for the first time, be sure to prime
thewatersupplysystem.Airinnewplumbinglines
can result in two or three empty ice maker cycles.
Furthermore, if the system is not flushed, the first ice
cubes may be discolored or have an odd flavor.
IMPORTANT
On occasion, unusually small ice cubes may be
noticed in the bucket or in dispensed ice. This could
occur in normal operation of the ice maker. If you start
seeing these more frequently, it may be an indication
of low water pressure or the water filter needs to
bereplaced.Asthewaterlternearstheendofits
useful life and becomes clogged with particles, less
water is delivered to the ice maker during each cycle.
Remember,ifit’sbeensixmonthsorlongersinceyou
last changed your water filter, replace the water filter
with a new one. Poor quality household water may
require the filter to be changed more frequently.
21
Automatic Ice & Water Maker/Dispenser
Removing Ice Bin
Ice maker/dispenser tips
• Ifyourrefrigeratorisnotconnectedtoawater
supply or the water supply is turned off, turn off
the ice maker by holding the On/Off soft-touch
icon for three seconds.
• Thefollowingsoundsarenormalwhentheice
maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• Whendispensingice,youwillhearasnapping
or clicking sound when the ice chute opens and
closes.
• Ifyouneedalargequantityoficeatonetime,itis
best to get cubes directly from the ice bin.
• Icecubesstoredtoolongmaydevelopanodd
flavor. Empty the ice bin as explained below.
• Whendispensingcubedice,itisnormaltohave
a small quantity of little pieces along with the
whole cubes.
CAUTION
If the water supply to your refrigerator is softened,
be sure the softener is properly maintained.
Chemicals from a water softener can damage the
ice maker.
Cleaning the ice maker
Clean the ice maker and ice bin at regular intervals,
especially prior to vacation or moving.
1 Turn off the ice
maker.
2 Remove the ice bin
by pulling straight
out.
3 Empty and carefully
clean the ice bin
with mild detergent.
Do not use harsh or
abrasive cleaners.
Rinse with clear
water.
4 Allowtheicebintodrycompletelybefore
replacing in the freezer.
5 Replace the ice bin. Turn the ice maker on.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This could damage
the ice bin.
To loosen stuck ice, use warm water. Before
replacing the ice bin, make sure it is completely
dry.
Adjusting Ice Bin Auger
Auger
IMPORTANT
When removing or replacing the ice bin, DO NOT
rotate the auger in the ice bin. If the auger is
accidentally rotated, you must realign the auger by
turning it in 45 degree turns (see below) until the ice
bin fits into place with the drive mechanism. If the
auger is not properly aligned when replacing the ice
bin, the refrigerator will not dispense ice. The fresh
food door also may not close properly causing warm
air to leak into the fresh food compartment.
Remove and empty the ice bin if:
• Anextendedpowerfailure(onehourorlonger)
causes ice cubes in the ice bin to melt and freeze
together, jamming the dispenser mechanism.
• Youdonotusetheicedispenserfrequently.Ice
cubes will freeze together in the bin, jamming the
dispenser mechanism.
Remove the ice bin and shake to loosen the cubes or
clean as explained above.
NOTE
Most models allow for an additional freezer ice
maker to be installed. Call your local dealer for more
information.
22
Automatic Ice Maker - Freezer
Ice maker operation & care
(select models)
Aftertherefrigeratorisinstalledproperly,theicemaker
can produce ice within 24 hours. It can completely fill an
ice bin in about three days.
When using the ice maker for the first time and in order
for the ice maker to work properly, it is necessary to
clear air from water filter tubing. Once ice maker begins
making ice, allow the bucket to fill completely, then
discard the first TWO FULL buckets of ice. It will take at
least two days to completely fill the bucket on regular
ice making mode or 1½ days on fast ice mode.
The ice maker produces approximately four pounds of
ice every 24 hours depending on usage conditions.
IMPORTANT
Your ice maker is turned on at the factory so it can
work as soon as you install your refrigerator. If you
cannotconnectawatersupply,lifttheicemaker’s
wire signal arm to turn it off. Otherwise, the ice
maker’sllvalvemaymakealoudchatteringnoise
when it attempts to operate without water.
Turning the ice maker on and off
Ice production is controlled by lifting/lowering the ice
maker’swire signal arm. To gain access to the ice
maker, pull the freezer drawer out. Lift the wire signal
arm to turn the ice maker OFF and lower the wire signal
arm to turn it ON.
Ice maker tips
• Ifyourrefrigeratorisnotconnectedtoawater
supply or the water supply is turned off, turn off
the ice maker by lifting wire signal arm.
Cleaning the ice maker
Clean the ice maker and ice bin at regular intervals,
especially prior to vacation or moving.
1 Turn off the ice maker.
2 Remove the ice bin.
3 Empty and carefully clean the ice bin with mild
detergent. Do not use harsh or abrasive cleaners.
Rinse with clean water.
4 Allowtheicebintodrycompletelybefore
replacing in the freezer.
5 Replace the ice bin. Turn the ice maker on.
Remove and empty the ice bin if:
• Anextendedpowerfailure(onehourorlonger)
causes ice cubes in the ice bin to melt and freeze
together.
Remove the ice bin and shake to loosen the cubes or
clean as explained above.
CAUTION
If the water supply to your refrigerator is softened,
be sure the softener is properly maintained.
Chemicals from a water softener can damage the
ice maker.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This could damage
the ice bin.
To loosen stuck ice, use warm water. Before
replacing the ice bin, make sure it is completely
dry.
• Thefollowingsoundsarenormalwhentheice
maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• Icecubesstoredtoolongmaydevelopanodd
flavor. Empty the ice bin as explained below.
Fast Ice Function
Your refrigerator is equipped with a “Smart” Fast Ice
Function, that will, if activated at your user interface,
allow an increase in ice production. You do not need to
deactivate it, if not needed, your refrigerator will operate
on normal conditions.
Wire
Signal Arm
OFF
ON
23
Storage Features
CAUTION
To avoid personal injury or property damage,
handle tempered glass shelves carefully. Shelves
may break suddenly if nicked, scratched, or
exposed to sudden temperature change. Allow
the glass shelves to stabilize to room temperature
before clearing. Do not wash in dishwasher.
NOTE
Features may vary according to model.
Shelf features
To change the position of a shelf:
1 Remove shelf from its locked position by pulling
the slide mechanism toward you.
3 Place top hooks of the hanger into the desired
slot, and lower straight down until lower hooks
rest on the ladder.
4 Relock shelf by pushing the slide mechanism
away from you.
6 Gently set the shelf onto the hanger once the
back is secured by the hanger.
CAUTION
Shelves must be removed prior to moving the
refrigerator.
5 While holding shelf at a 45-degree angle with the
gray handle facing you, push the shelf into the
back of the hanger.
2 Lift the hanger directly upwards and pull toward
you to remove it from the ladder.
24
Storage Features
Opening Crisper Drawer
Adjusting Crisper Humidity
(varies by model)
Higher
Humidity
Lower
Humidity
Humidity Control
Drawers
Your refrigerator includes a variety of storage drawers.
These drawers are located in fixed positions at the
bottom of the fresh food compartment.
Luxury-Glide
TM
Crispers
Crisper drawers are designed for storing fruits,
vegetables, and other fresh produce. They feature
a smooth-glide, ball-bearing system and soft-close
functionality so as not to bruise your fruits and
vegetables.
Special item mat (select models)
The innovative design of the special item mat allows
you to store four bottles of wine or soft drink bottles, or
any item that you want to prevent moving around.
Cool Zone Drawer (select models)
Some models are equipped with a drawer for short-
term storage of bulk items. This drawer includes sliding
controls for adjusting the humidity inside.
Removing Crisper Drawer
To remove the Crisper Drawer for cleaning:
1 Pull the drawer out until it stops.
2 Lift the front slightly and remove the drawer.
Special Item
Mat
NOTE
Anymeattobekeptlongerthantwodaysshouldbe
frozen. If you store fruits or vegetables in this drawer,
set it to a higher humidity.
Crisper humidity control
Crisper drawers include a sliding control for adjusting
the humidity inside the crisper. Leafy vegetables keep
best when stored with the Humidity Control set on
Higher Humidity. Fresh fruits keep best when stored
with the Humidity Control set on Lower Humidity.
25
Storage Features
The Perfect Temp
TM
Drawer is designed to keep food items at a precise temperature whether cooler, warmer, or the
same as the fresh food section of the refrigerator. This drawer features a smooth-glide, ball-bearing system and soft-
close functionality so as not to bruise your fruits and vegetables. The thaw setting holds a temperature for thawing
frozenfoodsfor12hours.Attheendofthattime,itthenswitchestothesnackssettingtostorethethawedfood.
Perfect Temp
TM
Drawer (select models)
To operate:
1 Toturnonandoff,pressthedrawer’sOn/Off
button. The numeric display will show a temperature
between 28° F and 42° F when on and OFF when
off.
2 Press F/C if you prefer to display Fahrenheit (F),
or Celsius (C).
3 Press either the up ∧ or down ∨ scroll buttons to
illuminate the desired item.
4 Once an option is selected, the drawer will adjust
and maintain the temperature for the setting
selected.
5 When turned off, the Perfect Temp
TM
Drawer
functions as a standard meat pan. The Perfect
Temp
TM
Drawer is best used for packaged food
products. Leafy vegetables and unpackaged fruits
are best kept in one of the crisper drawers.
6 The three favorite selections provide flexibility to
set and store personal temperature selections.
The temperature is adjusted up by pressing the
+ or – buttons. The drawer will store the selected
temperature setting until it is changed.
7 The control buttons can be locked to prevent
accidental changes by pressing the control lock
button for three seconds. Deactivate by pressing
for three seconds again.
Opening the Drawer
To remove the Perfect Temp
TM
Drawer for cleaning:
1 Pull the drawer out until it stops.
2 Lift the front slightly and remove the drawer.
Removing the Drawer
IMPORTANT
DO NOT clean the display area of the Perfect Temp
TM
Drawer with abrasive or caustic cleaners. Wipe clean
with a moist sponge.
CAUTION
The Perfect Temp
TM
Drawer and cover can
be removed for cleaning but the control unit,
attached to the right side of the fridge, cannot
be removed. Do not immerse the Perfect Temp
TM
Drawer cover in water or put it in a dishwasher.
Clean with a damp cloth or sponge.
NOTE
When the refrigerator is turned off by pressing the
main Wave-Touch
TM
or IQ-Touch
TM
on/off button, the
Perfect Temp
TM
Drawer will also be turned off. When
the refrigerator is turned back on, the Perfect Temp
TM
Drawer will resume operations at the temp setting that
was set before the refrigerator was turned off.
26
Storage Features
Doors
Storage bins
The doors to your fresh food compartment use a
systemofmodularstoragebins.Allofthesebinsare
removable for easy cleaning. Some of them have fixed
positions, while others can be adjusted to your needs.
Door bins are ideal for storing jars, bottles, cans, and
large drink containers. They also enable quick selection
of frequently used items.
To change the position of an adjustable door bin:
1 Remove all food
from bin.
2 Grip the bin firmly
with both hands
and lift it upward.
3 Remove the bin.
4 Place the bin just
above desired
position.
5 Lower the bin
onto supports until
locked in place.
Adjustable Door Bin
Accessories (varies by model)
Tall bottle retainer
The tall bottle
retainer keeps
tall containers
in the bin from
falling forward
when opening
or closing the
refrigerator door.
To install, insert
the ends of the
retainer into the holes.
Tilt can bins
The can bins
allow you to
efficiently and
securely store
up to eight
12-ounce
canned
beverages.
Tall
Bottle
Retainer
Tilt Can Bin
Freezer Features (varies by model)
To Remove Middle Basket
1 Remove all items from basket.
2 Remove basket by pulling basket out to its full
extension and lift out.
To reinstall middle basket, position basket onto the
retainer clips making sure the front of the basket rests
in the retainer clips on the stabilizer bar.
To Remove Lower Basket
1 Remove all items from basket.
2 Remove the basket by tilting it forward and lifting
it from the retainer clips.
To reinstall lower basket, insert basket into retainer clips.
NOTE
If basket is not resting on stabilizer bar retainer clips,
the drawer will not close properly.
Freezer Baskets
Stabilizer Bar
Basket
Retainer
Clips
Removing Lower Basket
Basket
Retainer
27
Storage Features
Soft Serve Bin
The soft serve bin in the upper right corner is designed
to maintain temperatures a few degrees above the
freezer temperature. This is perfect for storing items
that need a softer texture in order to easily serve, items
such as ice cream.
Dividers Removal
Lift up on the front of the middle divider and pull out.
Squeeze handle and lift up in the center of the divider to
move it side-to-side. (The divider cannot be removed.)
Wire Middle Basket Divider
Middle Basket
Divider
Retainers
Stabilizer
Bar
Plastic Lower Basket Divider
Lower Basket
Divider
28
Ideas for storing foods
Fresh food storage
• Keepthefreshfoodcompartmentbetween34°F
and40°Fwithanoptimumtemperatureof37°F.
• Avoidovercrowdingtherefrigeratorshelves,
which reduces air circulation and causes uneven
cooling.
Fruits and vegetables
• Storefruitsandvegetablesincrisperdrawers,
where trapped moisture helps preserve food
quality for longer time periods.
• Washitemsandremoveexcesswater.
• Wrapanyitemsthathavestrongodorsorhigh
moisture content.
Meat
• Wraprawmeatandpoultryseparatelyand
securely to prevent leaks and contamination of
other foods or surfaces.
• UsetheCoolZonedrawerorPerfect Temp
TM
drawer and set to meat/poultry setting for short-
termstorage.Anymeattobekeptlongerthan
two days should be frozen.
Frozen food storage
• Keepthefreezercompartmentat0°Forlower.
• Afreezeroperatesmostefcientlywhenitisat
least ⅔ full.
Packaging foods for freezing
• Tominimizefooddehydrationandquality
deterioration, use aluminum foil, freezer wrap,
freezer bags, or airtight containers. Force as
much air out of the packages as possible and
seal them tightly. Trapped air can cause food to
dry out, change color, and develop an off-flavor
(freezer burn).
• Wrapfreshmeatsandpoultrywithsuitable
freezer wrap prior to freezing.
• Donotrefreezemeatthathascompletely
thawed.
Loading the freezer
• Priortogroceryshopping,activatefast freeze
so that on your return you can ensure your newly
purchased food designated for the freezer will be
preserved as quickly as possible.
• Activatingfast freeze also will help your
freezer more efficiently maintain the selected
temperature after placing new purchases with
pre-existing frozen foods.
Storing Food and Saving Energy
• Avoidaddingtoomuchwarmfoodtothefreezer
at one time. This overloads the freezer, slows the
rate of freezing, and can raise the temperature of
frozen foods.
• Leaveaspacebetweenpackages,socoldair
can circulate freely, allowing food to freeze as
quickly as possible.
Ideas for saving energy
Installation
• Locatetherefrigeratorinthecoolestpartof
the room, out of direct sunlight, and away from
heating ducts or registers.
• Donotplacetherefrigeratornexttoheat-
producing appliances such as a range, oven, or
dishwasher. If this is not possible, a section of
cabinetry or an added layer of insulation between
the two appliances will help the refrigerator
operate more efficiently.
• Leveltherefrigeratorsothatthedoorsclose
tightly.
Temperature settings
• RefertotheControls section for procedures on
temperature settings.
Food storage
• Avoidovercrowdingtherefrigeratororblocking
cold air vents. Doing so causes the refrigerator to
run longer and use more energy.
• Coverfoodsandwipecontainersdrybefore
placing them in the refrigerator. This cuts down
on moisture build-up inside the unit.
• Organizetherefrigeratortoreducedoor
openings. Remove as many items as needed at
one time and close the door as soon as possible.
• Donotplaceahotcontainerdirectlyonacold
shelf. Remember, such an extreme temperature
change may damage the glass.
29
Normal Operating Sounds
Understanding the sounds you
may hear
Your new, high-efficiency refrigerator may introduce
unfamiliar sounds. These sounds normally indicate
your refrigerator is operating correctly. Some surfaces
on floors, walls, and kitchen cabinets may make these
sounds more noticeable.
The following is a list of major components in your
refrigerator and the sounds they can cause:
A Evaporator Refrigerant through the evaporator
may create a boiling or gurgling sound.
B Evaporator fan You may hear air being forced
through the refrigerator by the evaporator fan.
C Defrost heater During defrost cycles, water
dripping onto the defrost heater may cause a
hissingorsizzlingsound.Afterdefrosting,a
popping sound may occur.
D Automatic ice maker When ice has been
produced, you will hear ice cubes falling into the
ice bin. Ice maker fan, water valve activation, and
refrigerant gas fluid may create sounds from its
operation.
E Electronic control & automatic defrost control
These parts can produce a snapping or clicking
sound when turning the cooling system on and
off.
F Condenser fan You may hear air being forced
through the condenser.
G Compressor Modern, high-efficiency
compressors run much faster than older models.
The compressor may have a high-pitched hum or
pulsating sound.
H Water valve Makes a buzzing sound each time it
opens to fill the ice maker.
I Drain pan (not removable) You may hear water
dripping into the drain pan during the defrost
cycle.
J Condenser May create minimal sounds from
forced air.
K Motorized Perfect Temp
TM
drawer damper May
produce a light humming during operation.
L Ice dispensing paddle When dispensing ice,
you will hear a snapping, clicking, or popping
sound when the solenoid opens and closes the
ice chute.
M Motorized damper May produce a light
humming during operation.
NOTE
During automatic defrost cycle, a red glow in the back
wall vents of your freezer compartment is normal.
NOTE
Energy efficient foam in your refrigerator is not a
sound insulator.
N Perfect Temp
TM
drawer fan Turns off when door
opens or Perfect Temp
TM
drawer is turned off.
30
Changing The Water and Air Filters
Your refrigerator is equipped with separate water and
air filtering systems. The water filter system filters all
dispensed drinking water, as well as the water used to
produce ice. The air filter removes odors and impurities
from the refrigerator compartment.
Replacement
Water Filter
Remove Two
Protective Caps
Push Water Filter Button
Water Filter
Button
Water Filter
Cartridge
NOTE
The control panel includes controls to monitor the
status of your water and air filters. See the Controls
section for more information.
About your advanced water filter
The PureAdvantage
TM
NGFC 2000 ice and
water filter system is tested and certified by
NSFInternationaltoNSF/ANSIStandards42
and 53 for the reduction of claims specified on
the performance data sheet.
Water filter
The water filter is located at the lower left side of the
fresh food compartment.
Replacing your PureAdvantage
TM
water filter
In general, you should change the water filter every six
months to ensure the highest possible water quality. The
Water Filter Status light on the Touch Panel prompts
you to replace the filter after a standard amount of water
(400 gallons)
has flowed through the system.
If your refrigerator has not been used for a period of
time (during moving for example), change the filter
before reinstalling the refrigerator.
It is not necessary to turn the water supply off to
change the filter. Be ready to wipe up any small
amounts of water released during the filter replacement.
1 Turn Off the ice maker on the control panel.
2 Push the filter release button above the cartridge
to disconnect it.
3 Slide the old water filter cartridge straight out of
the housing and discard it.
4 Unpack the new filter cartridge and remove the
two protective caps covering the inlet and exit of
the filter. Slide the filter gently into the housing
until it stops against the snap-in connector at the
back of the housing.
Do not use with water that is microbiologically unsafe or of
unknown quality without adequate disinfection before or after
the system. Systems certified for cyst reduction may be used
on disinfected waters that may contain filterable cysts.
• RatedCapacity-400gallonsfor
PureAdvantage
TM
ice and water filter
• Ratedserviceow-.5gallonsperminute
• MaximumRatedPressure-100poundsper
square inch
• RecommendedMinimumOperatingPressure:30
pounds per square inch
• OperatingTemp.:Min.33°F,Max.100°F
5 Push firmly until the cartridge snaps into
place (you should hear two clicks). When fully
engaged, the front of the filter cartridge should be
flush with the filter release button.
Reinstall Water Filter
Push-In
Until
Two Clicks
6 Turn On the ice maker at the control panel.
7 Press a drinking glass against the water
dispenser while checking for any leaks at the filter
housing. Spurts and sputters may occur as the
system purges air out of the dispenser system.
8 Prime the water supply system as described
previously.
9 Press and hold the Filter Status button on the control
panel for three seconds. When the display changes
from Replace to Good, the status has been reset.
31
Changing The Water and Air Filters
Ordering replacement filters
Order new filters by calling 877-808-4195, online at
www.electroluxappliances.com, or through the dealer
where you bought your refrigerator. You may want to
consider ordering extra filters when you first install your
refrigerator.
Water Filter
FC-300 PureAdvantage
TM
Replacement Cartridge
#EWF01
Air Filter
Replacement cartridge, part #EAFCBF
Air filter
The air filter is located under the utility bin and/or on the
inside of the left door above the ice maker chute.
Replacing your PureAdvantage
TM
air filter
To ensure optimal filtering of refrigerator odors, you
should change the air filter every six months (the filter
status light on the Touch Panel prompts you to replace
the filter after six months).
1 Open the air filter door.
2 Remove the old filter and discard it.
3 Unpack the new filter and slide it into the housing.
4 To close the air filter door, push the top and
bottom to lock the door closed.
5 Press and hold the Air Filter Reset button on the
control panel for three seconds. When the display
changes from Replace to Good, the status has
been reset.
6 The Air Filter Reset will turn itself off after a few
seconds.
Filter located under the utility bin
32
Care and Cleaning
Protecting your investment
Keeping your refrigerator clean maintains its appearance and prevents odor build-up. Wipe up any spills
immediately and clean the freezer and fresh food compartments at least twice a year.
• Removeadhesivelabelsbyhand.Donotuserazorbladesorothersharpinstrumentswhichcanscratchthe
appliance surface.
• Donotremovetheserialplate.Removalofyourserialplatevoidsyourwarranty.
• Beforemovingyourrefrigerator,raisetheanti-tipbracketssotherollerswillworkcorrectly.Thiswillprevent
the floor from being damaged.
Refer to the guide on the next page for details on caring and cleaning specific areas of your refrigerator.
• Neverusemetallicscouringpads,brushes,abrasivecleaners,orstrongalkalinesolutionsonanysurface.
• NeveruseCHLORIDEorcleanerswithbleachtocleanstainlesssteel.
• Donotwashanyremovablepartsinadishwasher.
• Alwaysunplugtheelectricalpowercordfromthewalloutletbeforecleaning.
IMPORTANT
If you store or move your refrigerator in freezing temperatures, be sure to completely drain the water supply
system. Failure to do so could result in water leaks when the refrigerator is put back into service. Contact a
service representative to perform this operation.
CAUTION
• Pulltherefrigeratorstraightouttomoveit.Shiftingitfromsidetosidemaydamageooring.Be
careful not to move the refrigerator beyond the plumbing connections.
• Dampobjectssticktocoldmetalsurfaces.Donottouchrefrigeratedsurfaceswithwetordamphands.
NOTE
If you set your temperature controls to turn off cooling, power to lights and other electrical components will
continue until you unplug the power cord from the wall outlet.
NOTE
Do not use abrasive cleaners such as window sprays, scouring cleansers, flammable fluids, cleaning waxes,
concentrated detergents, bleaches, or cleansers containing petroleum products on plastic parts, interior doors,
gaskets, or cabinet liners. Do not use paper towels, scouring pads, or other abrasive cleaning materials.
Vacation and moving tips
Occasion Tips
Short Vacations •Leave refrigerator operating during vacations of three weeks or less.
• Use all perishable items from refrigerator compartment.
• Turn automatic ice maker off and empty ice bucket, even if you will only be gone a few days.
Long Vacations • Remove all food and ice if you will be gone one month or more.
• Turn the cooling system off (see Controls section for location of On/Off button) and disconnect power cord.
• Turn water supply valve to closed position.
• Clean interior thoroughly.
• Leave both doors open to prevent odors and mold build-up. Block doors open if necessary.
Moving • Remove all food and ice.
• If using a handcart, load from the side.
• Adjust rollers all the way up to protect them during sliding or moving.
• Pad cabinet to avoid scratching surface.
33
Care and Cleaning
Care and cleaning tips
Part Cleaning Agents Tips and Precautions
Interior & Door
Liners
• Soap and water
• Baking soda and
water
• Use two tablespoons of baking soda in one quart of warm water.
• Be sure to wring excess water out of sponge or cloth before cleaning around controls, light
bulb or any electrical part.
Door Gaskets • Soap and water • Wipe gaskets with a clean soft cloth.
Drawers & Bins •Soap and water • Use a soft cloth to clean drawer runners and tracks.
• Do not wash any removable items (bins, drawers, etc.) in dishwasher.
Glass Shelves • Soap and water
• Glass cleaner
• Mild liquid
sprays
• Allow glass to warm to room temperature before immersing in warm water.
Toe Grille • Soap and water
• Mild liquid
sprays
• Vacuum
• Remove toe grille (see Installation Instructions).
• Vacuum both sides and wipe with sudsy cloth or sponge. Rinse and dry.
Exterior &
Handles
• Soap and water
• Non abrasive
glass cleaner
• Do not use commercial household cleaners containing ammonia, bleach or alcohol to clean
handles.
• Use a soft cloth to clean smooth handles.
• Do not use a dry cloth to clean smooth doors.
Exterior &
Handles
(Stainless Steel
Models Only)
• Soap and water
• Stainless steel
cleaners
• Never use CHLORIDE or cleaners with bleach to clean stainless steel.
• Clean stainless steel front and handles with non-abrasive soapy water and a dishcloth.
Rinse with clean water and a soft cloth.
• Use a non-abrasive stainless steel cleaner. These cleaners can be purchased at most home
improvement or major department stores. Always follow manufacturer’s instruction. Do not
use household cleaners containing ammonia or bleach.
• NOTE: Always clean, wipe and dry with grain to prevent scratching.
• Wash the rest of the cabinet with warm water and mild liquid detergent. Rinse well and
wipe dry with a clean soft cloth.
Ice Chute Extension
The ice chute extension is
designed to better direct ice
flow into containers.
Push Upward Until The
Extension Snaps In Place
Pull Down
Press Here
Firmly
Removing the Ice Chute Extension For
Cleaning
1 Turn the
refrigerator
off using the
button on
the control
panel (refer
toOwner’s
Manual).
2 Press inward
firmly on the
front of the chute
and pull down.
3 Turn your refrigerator back on.
Installing the Ice Chute Extension
1 Turn the refrigerator
off using the button
on the control panel
(refertoOwner’s
Manual).
2 Aligntheextension
with the ice chute so
that the snap clips
are just inside the
front edge of the
chute.
3 Push upward until
the extension snaps into place.
4 Turn your refrigerator back on.
34
Care and Cleaning
Replacing LED Lights
Both the freezer and fresh food compartments of your
refrigeratorincludeLEDlights.AlwaysuseElectrolux
parts for replacement.
To replace LED Lights:
1 Unplugyourrefrigerator’spowercord.
2 Remove light cover by pushing up and out.
3 Hold the LED cover with one hand and pull the
connector with the other hand while pressing the
connector latch.
4 Replace LED light and snap in place assuring the
light is facing in toward the unit (inside fresh food
and freezer).
Ordering Replacement LED Lights
Order new LEDs by calling 877-808-4195, online at
www.electroluxappliances.com, or through the dealer
where you bought the refrigerator. Here is the product
number to request when ordering:
LED Light, Part #241891102
LED Light Harness Removal
LED Light Removal
NOTE
LED lights are in series so if one is bad or unplugged,
several lights may not light up.
35
Solutions to Common Problems
Before you call...
If you experience a problem with your refrigerator or notice a product behavior or condition that you do not
understand, you can usually avoid a call to your service representative by referring to this section for an answer.
Beginning with the following table, this information includes common concerns, causes, and suggested solutions.
Automatic Ice Maker
Concern Potential Cause Common Solution
Ice maker is not making
any ice.
• Ice maker is turned off.
• Refrigerator is not connected to water line or
water valve is not open.
• The water supply line is kinked.
• The water filter is not seated properly.
• The water filter may be clogged with foreign
material.
• Saddle valve on cold water pipe is clogged or
restricted by foreign material.
• Turn on ice maker. For the fresh food ice maker, press
and hold the Ice Off button for four seconds until the
indicator turns off. For the freezer ice maker, lower the
wire signal arm.
• Connect the unit to the household water supply and
ensure the supply valve is open.
• Ensure that the supply line does not kink when the refrig-
erator is pushed into place against the wall.
• Remove and re-install the water filter. Be sure to push
the filter firmly so that you hear it lock solidly into posi-
tion.
• If water dispenses slowly or not at all, or if the filter is six
months old or older, it should be replaced.
• Turn off household water line valve. Remove valve. En-
sure that valve is not a self-piercing saddle valve. Clean
valve. Replace valve if necessary.
Ice maker is not making
enough ice.
• Ice maker is producing less ice than you
expect.
• The water filter may be clogged with foreign
material.
• The water supply line is kinked.
• Saddle valve on cold water pipe is clogged or
restricted by foreign material.
• The fresh food and freezer ice makers will each produce
approximately 2.5 pounds of ice every 24 hours
depending on usage conditions.
• If water dispenses slower than normal, or if the filter is
six months old or older, it should be replaced.
• Ensure that the supply line does not kink when the refrig-
erator is pushed into place against the wall.
• Turn off household water line valve. Remove valve. En-
sure that valve is not a self-piercing saddle valve. Clean
valve. Replace valve if necessary.
Freezer ice maker will not
stop making ice.
• Ice maker wire signal arm is being held down
by some package in the freezer that has fallen
against the ice maker.
• Move the item and release wire signal arm. Remove any
ice cubes that may have frozen together over the wire
signal arm.
Ice cubes are freezing
together.
• Ice cubes are not being used frequently
enough.
• Ice cubes are hollow (shells of ice with water
inside). The hollow cubes break open in the
bin and leak their water onto existing ice,
which causes it to freeze together.
• Remove ice container and discard ice. The ice maker will
produce fresh supply. Ice should be used at least twice
weekly to keep the cubes separated.
• This generally occurs when the ice maker does not get
enough water. This is usually the result of a clogged
water filter. Replace the water filter.
36
Solutions to Common Problems
Ice Dispenser
Concern Potential Cause Common Solution
Dispenser will not
dispense ice.
•Water supply is not connected.
•Ice storage bin is empty.
•Household water line valve is not open.
•Fresh Food door is not closed.
•Ice dispensing paddle has been held in for
more than four to five minutes.
•Connect water supply (see Connecting The Water
Supply section).
•Ensure ice maker is turned on. When the first supply
of ice is dropped into the bin, the dispenser should
operate.
•Open household water line valve. Allow sufficient time
for the ice to be made. When ice is made, the dispenser
should operate.
•Ensure Fresh Food door is closed. (See Problem
Section, Opening/Closing of Doors/Drawers)
•Motor is overloaded. Motor overload protector will
reset in approximately three minutes. Ice can then be
dispensed.
Ice dispenser is jammed. •Ice has melted and frozen around auger due
to infrequent use, temperature fluctuations,
and/or power outages.
•Ice cubes are frozen together.
•Ice cubes are smaller than normal.
•Remove ice bin, thaw, and empty the contents. Clean
bin, wipe dry, and replace in proper position. When new
ice is made, dispenser should operate.
•Use the dispenser often so that cubes do not freeze
together.
•The ice & water filter cartridge could be clogged.
Replace the filter cartridge. Dispensing system operates
best at 30-100 psi water pressure. Well water pressures
should fall within this range.
Light Is Not On
Concern Potential Cause Common Solution
Light is not on. •Light bulb is burned out or LED light is
damaged.
• No electric current is reaching refrigerator.
• Control system has disabled lights because
one or both doors were left open too long.
• See Replacing Light Bulbs or LED lights in Care and
Cleaning section.
• See Problem section, Running Your Refrigerator.
• Close and reopen door(s) to enable lights.
Odors In Refrigerator
Concern Potential Cause Common Solution
Interior is dirty.
Odors.
• Interior needs to be cleaned.
• Food with strong odors is stored in
refrigerator.
• See Care & Cleaning Tips.
• Cover food tightly. Turn on air filtration system. Air filter
may need to be changed more frequently if foods with
strong odors are routinely stored in refrigerator.
Opening/Closing Of Doors/Drawers
Concern Potential Cause Common Solution
Door(s) will not close. • Refrigerator is not level. It rocks on the floor
when moved slightly.
• Ensure floor is level and solid, and can adequately
support the refrigerator. Contact a carpenter to correct a
sagging or sloping floor.
Drawers are difficult to
move.
• Food is touching shelf on top of drawer.
• Drawer is overloaded
• Keep less food in drawer.
• Remove or redistribute food.
37
Solutions to Common Problems
Running Your Refrigerator
Concern Potential Cause Common Solution
Compressor does not
run.
• Cooling system is turned Off.
• Refrigerator is in defrost cycle.
• Plug at wall outlet is disconnected.
• House fuse is blown or a tripped circuit
breaker.
• Power outage.
• Electronic control system keeps the
refrigerator at a constant temperature.
• Turn cooling system On. See Controls Section for
location of cooling system On/Off button.
• This is normal for a fully automatic defrost refrigerator.
The defrost cycle occurs periodically, lasting about 30
minutes.
• Ensure plug is tightly pushed into outlet.
• Check/replace fuse with a 15 amp time-delay fuse.
Reset circuit breaker.
• Check house lights. Call local Electric Company.
• This is normal. Refrigerator goes on and off to keep
temperature constant.
Refrigerator runs too
much or too long.
• Room or outside weather is hot.
• Refrigerator has recently been disconnected
for a period of time.
• Automatic ice maker is operating.
• Doors are opened too frequently or too long.
• Refrigerator/freezer door may be slightly
open.
• Freezer control is set too cold (control found
in fresh food section).
• Fresh food/freezer gasket is dirty, worn,
cracked, or poorly fitted.
• This model is provided with a high-efficiency,
variable-speed compressor.
• It’s normal for the refrigerator to work longer under
these conditions.
• It takes 8-12 hours for the refrigerator to cool down
completely.
• Ice maker operation causes refrigerator to run slightly
more.
• Warm air entering the refrigerator causes it to run more.
Open doors less often.
• Ensure refrigerator is level. Keep food and containers
from blocking door. See Problem section, Opening/
Closing of Doors/Drawers.
• Set freezer control to warmer setting until refrigerator
temperature is satisfactory. Allow 24 hours for
temperature to stabilize.
• Clean or change gasket. Leaks in door seal will cause
refrigerator to run longer in order to maintain desired
temperatures.
• It is normal for the compressor to run for long periods
of time.
Digital temperature
displays are flashing.
• Electronic control system has detected a
performance problem.
• Call your Electrolux service representative, who can
interpret any messages or number codes flashing on
the digital displays.
Temperatures Are Too Cold
Concern Potential Cause Common Solution
Freezer temperature
too cold. Refrigerator
temperature is
satisfactory.
• Freezer control is set too cold.
• Ice maker is on.
• Set freezer control to a warmer setting. Allow 24 hours
for temperature to stabilize.
• It is normal for the freezer compartment to over cool
while automatic ice maker is on.
Refrigerator temperature
too cold. Freezer
temperature is
satisfactory.
• Refrigerator control is set too cold. • Set refrigerator control to a warmer setting. Allow 24
hours for temperature to stabilize.
Food stored in drawers
freezes.
• Refrigerator control is set too cold. • See solution above.
Food stored in Meat
Keeper freezes (select
models).
• Meat Keeper temperature control is set too
cold.
• Adjust Meat Keeper temperature control to a warmer
setting. Meat should be stored at a temperature just
below the freezing point for maximum fresh storage
time. It is normal for ice crystals to form due to the
moisture content of meat.
38
Solutions to Common Problems
Temperatures Are Too Warm
Concern Potential Cause Common Solution
Freezer/Refrigerator
temperature is too warm.
• Doors are opened too frequently or too long.
• Door is slightly open.
• Warm air enters the refrigerator whenever the door is
opened. Open the door less often.
• See Problem section, Opening/Closing of Doors/Drawers.
Freezer temperature is
too warm. Refrigerator
temperature is satisfactory.
• Freezer control is set too warm. • Set freezer control to a colder setting. Allow 24 hours
for temperature to stabilize.
Refrigerator temperature
is too warm. Freezer
temperature is satisfactory.
• Refrigerator control is set too warm. • Set refrigerator control to a colder setting. Allow 24
hours for temperature to stabilize.
Temperature in the
Cool Zone Drawer
TM
or Perfect Temp
TM
Drawer is too warm
(select models).
• Temperature control is set too warm. • Adjust temperature control to a colder setting.
Water Dispenser
Concern Potential Cause Common Solution
Dispenser will not
dispense water.
•Water supply is not connected.
•Household water line valve is not open.
•Ice & water filter cartridge is clogged.
•Connect water supply (see Connecting The Water
Supply section).
•Open household water line valve. See Problem section
Ice Maker Is Not Making Ice.
• Replace filter cartridge being sure to remove protective caps.
Water has an odd taste
and/or odor.
•Water has been in the tank for a period of
time.
•Unit not properly connected to cold water line.
•Tubing used in the household water supply and
installation may affect water taste and odor.
•Water has a high mineral content.
•Draw and discard 10-12 glasses of water to freshen the
supply and completely rinse out the tank.
•Connect unit to cold water line that supplies water to the
kitchen faucet.
•For best results, use copper tubing for water
connections.
•Contact water treatment plant for help in checking water
supply source.
Water pressure is
extremely low.
•Cut-off and cut-on pressures are too low (well
systems only).
•Reverse osmosis system is in regenerative
phase.
•Have someone turn up the cut-off and cut-on pressure
on the water pump system (well systems only).
•It is normal for a reverse osmosis system to be below
20 psi during the regenerative phase.
Water/Moisture/Frost Inside Refrigerator
Concern Potential Cause Common Solution
Moisture collects on
inside of refrigerator
walls.
• Weather is hot and humid.
• Door is slightly open.
• Door is opened too often or too long.
• Open containers.
• The rate of frost buildup and internal sweating increases.
• See Problem section, Opening/Closing of Doors/Drawers.
• Open door less often to allow internal temperature to stabilize.
• Keep containers covered.
Water collects on bottom
side of drawer cover.
• Vegetables contain and give off moisture. • Moisture on the bottom side of the cover is not unusual.
• Move humidity control (select models) to lower setting.
Moisture collects in
bottom of drawer.
• Washed vegetables and fruit drain while in the
drawer.
• Fruits and vegetables are kept past their
prime.
• Dry items before putting them in the drawer. Water
collecting in bottom of drawer is normal.
• Routinely clean out old fruits and vegetables especially
if they begin to break down.
Moisture collects on
outside of refrigerator or
between doors.
• Weather is humid.
• Door is slightly open, causing cold air from
inside refrigerator to meet warm air from
outside.
• This is normal in humid weather. When humidity is
lower, the moisture should disappear.
• See Problem section, Opening/Closing of Doors/
Drawers.
39
Warranty
Major Appliance Warranty Information
Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will repair or
replace any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used, and
maintained in accordance with the provided instructions. In addition, the cabinet liner and sealed refrigeration system (compressor,
condenser, evaporator, dryer or tubing) of your appliance is covered by a two through five year limited warranty. During the 2nd through
5th years from your original date of purchase, Electrolux will repair or replace any parts in the cabinet liner and sealed refrigeration
system which prove to be defective in materials or workmanship when such appliance is installed, used, and maintained in accordance
with the provided instructions.
Exclusions
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. ProductthathasbeentransferredfromitsoriginalownertoanotherpartyorremovedoutsidetheUSAorCanada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not in ordinary
household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which are not a
part of the appliance when it is shipped from the factory.
10. Service calls to repair or replace appliance light bulbs, air filters, water filters, other consumables, or knobs, handles, or other
cosmetic parts.
11. Pickup and delivery costs; your appliance is designed to be repaired in the home.
12. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges, or mileage
expenseforservicecallstoremoteareas,includingthestateofAlaska.
13. Damages to the finish of appliance or home incurred during transportation or installation, including but not limited to floors,
cabinets, walls, etc.
14. Damages caused by: services performed by unauthorized service companies; use of parts other than genuine Electrolux
parts or parts obtained from persons other than authorized service companies; or external causes such as abuse, misuse,
inadequate power supply, accidents, fires, or acts of God.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’SSOLEANDEXCLUSIVEREMEDYUNDERTHISLIMITEDWARRANTYSHALLBEREPAIRORREPLACEMENT
ASPROVIDEDHEREIN.CLAIMS BASED ON IMPLIED WARRANTIES, INCLUDING WARRANTIES OF MERCHANTABILITY OR
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW,
BUT NOT LESS THAN ONE YEAR.ELECTROLUXSHALLNOTBELIABLEFORCONSEQUENTIALORINCIDENTALDAMAGES
SUCHASPROPERTYDAMAGEANDINCIDENTALEXPENSESRESULTINGFROMANYBREACHOFTHISWRITTENLIMITED
WARRANTYORANYIMPLIEDWARRANTY.SOMESTATESANDPROVINCESDONOTALLOWTHEEXCLUSIONORLIMITATION
OFINCIDENTALORCONSEQUENTIALDAMAGES,ORLIMITATIONSONTHEDURATIONOFIMPLIEDWARRANTIES,SOTHESE
LIMITATIONSOREXCLUSIONSMAYNOTAPPLYTOYOU.THISWRITTENWARRANTYGIVESYOUSPECIFICLEGALRIGHTS.
YOUMAYALSOHAVEOTHERRIGHTSTHATVARYFROMSTATETOSTATE.
If You Need Service
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period should service be required.
If service is performed, it is in your best interest to obtain and keep all receipts. Service under this warranty must be obtained by
contacting Electrolux at the addresses or phone numbers below.
ThiswarrantyonlyappliesintheUSA,PuertoRicoandCanada.IntheUSAandPuertoRico,yourapplianceiswarrantedbyElectrolux
MajorAppliancesNorthAmerica,adivisionofElectroluxHomeProducts,Inc.InCanada,yourapplianceiswarrantedbyElectrolux
Canada Corp. Electrolux authorizes no person to change or add to any obligations under this warranty. Obligations for service and parts
under this warranty must be performed by Electrolux or an authorized service company. Product features or specifications as described
or illustrated are subject to change without notice.
USA
1-877-435-3287
ElectroluxMajorAppliancesNorthAmerica
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1-800-265-8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada L5V 3E4
