BFR630DX-BFR630DB-GN1406220ZX
BFR615DDX-BFR622PX
EN
57 8374 0000/AS -EN
Refrigerator
User Manual
Please read this manual before using the product!
Dear Customer,
We'd like you to make the best use of our product, which has been manufactured in modern facilities
with care and meticulous quality controls.
Thus, we advice you to read the entire user manual before you use the product. In case the product
changes hands, do not forget to hand the guide to its new owner along with the product.
This guide will help you use the product quickly and safely.
• Please read the user guide carefully before installing and operating the product.
• Always observe the applicable safety instructions.
• Keep the user guide within easy reach for future use.
• Please read any other documents provided with the product.
Keep in mind that this user guide may apply to several product models. The guide clearly indicates any
variations of different models.
C
Important information and useful
tips.
A
Risk of life and property.
B
Risk of electric shock.
The product’s packaging is made of
recyclable materials, in accordance
with the National Environment
Legislation.
2 / 29 EN
Refrigerator / User Manual
1. Safety and environment instructions 3
2 Your Refrigerator 6
2 Your Refrigerator 7
3 Installation 8
3.1 Appropriate location for installation . . . . . . . .8
3.2 Installing the plastic wedges . . . . . . . . . . . . .8
3.3* Adjusting the feet . . . . . . . . . . . . . . . . . . . .9
3.4 Electric connection . . . . . . . . . . . . . . . . . . .10
4 Preparation 11
4.1 Things to be done for saving energy . . . . .11
4.2 Recommendations about the fresh food
compartment. . . . . . . . . . . . . . . . . . . . . .11
4.3 Initial use. . . . . . . . . . . . . . . . . . . . . . . . .12
5 Operating the product 13
5.1 Indicator panel . . . . . . . . . . . . . . . . . . . . . .13
5.2 Indicator panel. . . . . . . . . . . . . . . . . . . . .18
5.3 Freezing fresh food. . . . . . . . . . . . . . . . . . .21
5.4 Recommendations for preserving the frozen
food . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
5.5 Deep-freeze information . . . . . . . . . . . . . . .21
5.6 Placing the food . . . . . . . . . . . . . . . . . . . . .22
5.7 Door open warning . . . . . . . . . . . . . . . . . . .22
5.8 Frost Free Chill compartment . . . . . . . . . . .22
5.9 Crisper. . . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.10 Humidity-controlled crisper . . . . . . . . . . . .22
Everfresh+(R) . . . . . . . . . . . . . . . . . . . . . . . . . .22
5.11 Egg tray . . . . . . . . . . . . . . . . . . . . . . . . . .23
5.12 Movable Middle Section . . . . . . . . . . . . . .23
5.13 Multizone Compartment . . . . . . . . . . . . .23
5.15 Odour filter. . . . . . . . . . . . . . . . . . . . . . . .23
5.16 Use of internal water dispenser and water
dispenser at the door . . . . . . . . . . . . . . . .24
5.17 Dispensing water . . . . . . . . . . . . . . . . . . .24
5.18 Maintaining water dispenser . . . . . . . . . . .25
5.19 Icematic . . . . . . . . . . . . . . . . . . . . . . . . .26
5.20 Icematic and ice storage container . . . . . .26
6 Maintenance and Cleaning 27
7. Troubleshooting 28
3 / 29 EN
Refrigerator / User Manual
1. Safety and environment instructions
This section provides the safety instructions
necessary to prevent the risk of injury and material
damage. Failure to observe these instructions will
invalidate all types of product warranty.
Intended use
A
WARNING:
Keep ventilation openings, in the
appliance enclosure or in the built-
instructure, clear of obstruction.
A
WARNING:
Do not use mechanical
devices or other means to
accelerate the defrosting process,
other than those recommended by
the manufacturer.
A
WARNING:
Do not damage the refrigerant
circuit.
A
WARNING:
Do not use electrical
appliances inside the food
storage compartments of the
appliance, unless they are of
the type recommended by the
manufacturer.
This appliance is intended to be used in household
and similar applications such as
– staff kitchen areas in shops, offices and other
working environments;
– farm houses and by clients in hotels, motels and
other residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications.
1.1. General safety
• This product should not be used by
persons with physical, sensory and
mental disabilities, without sufficient
knowledge and experience or by
children. The device can only be used
by such persons under supervision
and instruction of a person responsible
for their safety. Children should not be
allowed to play with this device.
• In case of malfunction, unplug the
device.
• After unplugging, wait at least 5
minutes before plugging in again.
• Unplug the product when not in use.
• Do not touch the plug with wet hands!
Do not pull the cable to plug off, always
hold the plug.
• Do not plug in the refrigerator if the
socket is loose.
• Unplug the product during installation,
maintenance, cleaning and repair.
• If the product will not be used for a
while, unplug the product and remove
any food inside.
• Do not use the product when the
compartment with circuit cards located
on the upper back part of the product
(electrical card box cover) (1) is open.
1
1
• Do not use steam or steamed cleaning
materials for cleaning the refrigerator
and melting the ice inside. Steam may
contact the electrified areas and cause
short circuit or electric shock!
• Do not wash the product by spraying or
pouring water on it! Danger of electric
shock!
• In case of malfunction, do not use the
product, as it may cause electric shock.
Contact an authorised service agent
before doing anything.
4 / 29 EN
Refrigerator / User Manual
Important instructions regarding safety and environment
• Plug the product into an earthed socket.
Earthing must be done by a qualified
electrician.
• If the product has LED type lighting,
contact and authorised service agent for
replacing or in case of any problem.
• Do not touch frozen food with wet hands!
It may adhere to your hands!
• Do not place liquids in bottles and cans
into the freezer compartment. They may
explode.
• Place liquids in upright position after
tightly closing the lid.
• Do not spray flammable substances near
the product, as it may burn or explode.
• Do not keep flammable materials and
products with flammable gas (sprays,
etc.) in the refrigerator.
• Do not place containers holding liquids
on top of the product. Splashing water
on an electrified part may cause electric
shock and risk of fire.
• Exposing the product to rain, snow,
sunlight and wind will cause electrical
danger. When relocating the product, do
not pull by holding the door handle. The
handle may come off.
• Take care to avoid trapping any part of
your hands or body in any of the moving
parts inside the product.
• Do not step or lean on the door, drawers
and similar parts of the refrigerator. This
will cause the product to fall down and
cause damage to the parts.
• Take care not to trap the power cable.
• When positioning the appliance, ensure
the supply cord is not trapped or
damaged.
• Do not locate multiple portable socket-
outlets or portable power supplies at
the rear of the appliance.
• To avoid contamination of food, please
respect the following instructions:
• Opening the door for long periods can
cause a significant increase of the
temperature in the compartments of
the appliance.
• Clean regularly surfaces that can come
in contact with food and accessible
drainage systems.
• Clean water tanks if they have not been
used for 48 h; flush the water system
connected to a water supply if water
has not been drawn for 5 days.
• Store raw meat and fish in suitable
containers in the refrigerator, so that it
is not in contact with or drip onto other
food.
• Two-star frozen-food compartments
are suitable for storing pre-frozen
food, storing or making icecream and
making ice cubes.
• One-, two- and three-star
compartments are not suitable for the
freezing of fresh food.
• If the refrigerating appliance is left
empty for long periods, switch off,
defrost, clean, dry, and leave the door
open to prevent mould developing
within the appliance.
1.1.1 HC warning
If the product comprises a cooling system using
R600a gas, take care to avoid damaging the
5 / 29 EN
Refrigerator / User Manual
Important instructions regarding safety and environment
cooling system and its pipe while using and
moving the product. This gas is flammable. If the
cooling system is damaged, keep the product
away from sources of fire and ventilate the room
immediately.
C
The label on the inner left side
indicates the type of gas used in
the product.
1.1.2 For models with
water dispenser
• Pressure for cold water inlet shall be
maximum 90 psi (620 kPa). If your
water pressure exceeds 80 psi (550
kPa), use a pressure limiting valve in
your mains system. If you do not know
how to check your water pressure, ask
for the help of a professional plumber.
• If there is risk of water hammer effect
in your installation, always use a water
hammer prevention equipment in
your installation. Consult Professional
plumbers if you are not sure that there
is no water hammer effect in your
installation.
• Do not install on the hot water inlet.
Take precautions against of the
risk of freezing of the hoses. Water
temperature operating interval shall
be 33°F (0.6°C) minimum and 100°F
(38°C) maximum.
• Use drinking water only.
1.2. Intended use
• This product is designed for home use.
It is not intended for commercial use.
• The product should be used to store
food and beverages only.
• Do not keep sensitive products
requiring controlled temperatures
(vaccines, heat sensitive medication,
medical supplies, etc.) in the
refrigerator.
• The manufacturer assumes no
responsibility for any damage due to
misuse or mishandling.
• Original spare parts will be provided
for 10 years, following the product
purchasing date.
1.3. Child safety
• Keep packaging materials out of
children’s reach.
• Do not allow the children to play with
the product.
• If the product’s door comprises a lock,
keep the key out of children’s reach.
1.4. Compliance with WEEE Directive
and Disposing of the Waste Product
This product complies with EU WEEE
Directive (2012/19/EU). This product bears a
classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been manufactured
with high quality parts and materials
which can be reused and are suitable
for recycling. Do not dispose of the
waste product with normal domestic
and other wastes at the end of its
service life. Take it to the collection
center for the recycling of electrical and electronic
equipment. Please consult your local authorities to
learn about these collection centers.
1.5. Compliance with RoHS Directive
• This product complies with EU WEEE Directive
(2011/65/EU). It does not contain harmful and
prohibited materials specified in the Directive.
1.6. Package information
Packaging materials of the product are
manufactured from recyclable materials in
accordance with our National Environment
Regulations. Do not dispose of the packaging
materials together with the domestic or other
wastes. Take them to the packaging material
collection points designated by the local authorities.
6 / 29 EN
Refrigerator / User Manual
C
Figures in this user manual are schematic and may not match the product exactly. If the subject parts
are not included in the product you have purchased, then those parts are valid for other models.
2 Your Refrigerator
*2
*3
4
5
6
7
*8
9
1
10
11
5
1- Control and indicator panel
2- Butter & Cheese section
3- 70 mm moving door shelf
4- Fridge compartment glass shelf
5- Fridge compartment crisper
6- Gallon door shelf
7- Chiller compartment
8- Icebox drawer
9- Multizone compartment glass shelf/cooler
10- Freezer compartment drawers
11- Multizone Compartment's drawer
* OPTIONAL
7 / 29 EN
Refrigerator / User Manual
C
Figures in this user manual are schematic and may not match the product exactly. If the subject parts
are not included in the product you have purchased, then those parts are valid for other models.
2 Your Refrigerator
1- Control and indicator panel
2- Butter & Cheese section
3- 70 mm moving door shelf
4- Fridge compartment glass shelf
5- Fridge compartment crisper
6- Large door shelf
7- Chiller compartment
8- Icebox drawer
9- Multizone compartment glass shelf/cooler
10- Freezer compartment drawers
11- Inner Water Dispenser
* OPTIONAL
*2
*3
4
5
6
7
*8
9
1
10
5
11
8 / 29 EN
Refrigerator / User Manual
3.1 Appropriate location
for installation
In order to prepare the product for use, refer the
information in the user manual and ensure that
electrical installation and water installation are
appropriate. If not, call a qualified electrician and
plumber to arrange the utilities as necessary.
B
WARNING: Manufacturer shall not
be held liable for damages that may
arise from procedures carried out by
unauthorised persons.
B
WARNING: Product must not be plugged
in during installation. Otherwise, there is
the risk of death or serious injury!
A
WARNING: : If the door clearance of the
room where the product shall be placed is
so tight to prevent passing of the product,
remove the door of the room and pass the
product through the door by turning it to
its side; if this does not work, contact the
authorised service agent.
•Placetheproductonalevelfloorsurfaceto
prevent jolts.
•Installtheproductatleast30cmawayfrom
heat sources such as cooktops, heater cores
and stoves and at least 5 cm away from
electrical ovens.
•Productmustnotbesubjectedtodirectsunlight
and kept in humid places.
•Appropriateairventilationmustbeprovided
around your product in order to achieve an
efficient operation. If the product is to be placed
in a recess in the wall, pay attention to leave at
least 5 cm distance with the ceiling and side
walls.
•Donotinstalltheproductinplaceswherethe
temperature falls below -5°C.
3 Installation
3.2 Installing the plastic wedges
Plastic wedges supplied with the product are
used to create the distance for the air circulation
between the product and the rear wall.
1.
To install the wedges, remove the screws on the
product and use the screws supplied together with the
wedges.
2.
Insert the 2 plastic wedges onto the rear ventilation
cover as illustrated in the figure.
9 / 29 EN
Refrigerator / User Manual
Installation
3.3* Adjusting the feet
If the product stands unbalanced after installation,
adjust the feet on the front by rotating them to the
right or left.
* If your product does not have a wine
compartment or is not a glass door, your product
does not have adjustable stands, the product has
fixed stands.
To adjust the doors vertically,
Loosen the fixing nut located at the bottom.
Rotate the adjusting nut according to the position
of the door (clockwise/counter-clockwise).
Tighten the fixing nut in order to fix the position.
To adjust the doors horizontally,
Loosen the fixing nut located at the top.
Rotate the side adjusting nut according to the
position of the door (clockwise/counter-clockwise).
Tighten the fixing nut which is at the top in order to
fix the position.
adjusting nut
fixing nut
fixing nut
adjusting nut
10 / 29 EN
Refrigerator / User Manual
Installation
3.4 Electric connection
A
WARNING: Do not make connections via
extension cables or multi-plugs.
B
WARNING: Damaged power cable must
be replaced by the Authorised Service
Agent.
C
If two coolers are to be installed side
by side, there should be at least 4 cm
distance between them.
• The manufacturer shall not be liable for any
damages that will arise when the product
is used without grounding and electrical
connection in accordance with the national
regulations.
• Power cable plug must be within easy reach
after installation.
• Do not use extension cords or cordless multiple
outlets between your product and the wall
outlet.
-Upper hinge group is fixed with 3 screws.
-The hinge cover is attached after the sockets are
installed.
- Then the hinge cover is fixed with two screws.
11 / 29 EN
Refrigerator / User Manual
4 Preparation
C
Temperature of the room where your
refrigerator is located should at least
be
10ºC /50°F. Operating your
refrigerator under cooler conditions is not
recommended with regard to its efficiency.
C
Inside of your refrigerator must be cleaned
thoroughly.
C
If two coolers are to be installed side
by side, there should be at least 4 cm
distance between them.
4.2 Recommendations about the
fresh food compartment
• Make sure that the food does not touch the
temperature sensor in fresh food compartment.
To allow the fresh food compartment to keep
its ideal storage temperature, the sensor must
not be hindered by food.
• Do not place hot foods or beverages inside the
product.
4.1 Things to be done for
saving energy
A
Connecting your refrigerator to systems
that save energy is dangerous as they may
cause damage on the product.
• Do not leave the doors of your refrigerator open
for a long time.
• Do not put hot food or drinks in your
refrigerator.
• Do not overload the refrigerator. Cooling
capacity will fall when the air circulation in the
refrigerator is hindered.
• Do not place the refrigerator in places subject
to direct sunlight. Install the product at least 30
cm away from heat sources such as cooktops,
ovens, heater units and stoves and at least 5
cm away from electrical ovens.
• Pay attention to store your food in refrigerator
in closed containers.
• To be able store maximum food in the freezer
compartment of your refrigerator, the upper
drawer has to be removed and placed on top
of glass shelf. Power consumption stated for
your refrigerator has been determined after
removing the icematic and the upper drawers
as to allow maximum loading. It is strongly
recommended to use the lower drawers in the
freezer and the multizone compartment while
loading.
• Since hot and humid air will not directly
penetrate into your product when the doors
are not opened, your product will optimize
itself in conditions sufficient to protect your
food. Functions and components such as
compressor, fan, heater, defrost, lighting,
display and so on will operate according to
the needs to consume minimum energy under
these circumstances.
• Airflow should not be blocked by placing
foods in front of the freezer and the multizone
compartment fans. Foods should be loaded by
leaving minimum 5 cm space in front of the
protective fan grid.
• Thawing the frozen foods in the fridge
compartment both saves energy and reserves
the quality of the foods.
12 / 29 EN
Refrigerator / User Manual
Preparation
4.3 Initial use
Before using the product, make sure that all
preparations have been made in accordance
with the instructions given in the "Important
instructions regarding safety and environment" and
"Installation" chapters.
• Clean the interior of the refrigerator as
recommended in the “Maintenance and
cleaning” section. Before you start the
refrigerator, make sure that the interior is dry.
• Plug the refrigerator in a grounded socket. The
interior illumination is lit when the door of the
refrigerator is opened.
• Operate the refrigerator for 6 hours without
placing any food in it and do not open its door
unless it is necessary.
C
You will hear a noise when the compressor
starts up. The liquids and gases sealed
within the refrigeration system may also
give rise to noise, even if the compressor is
not running and this is quite normal.
C
Front edges of the refrigerator may
feel warm. This is normal. These areas
are designed to be warm to avoid
condensation.
13 / 29 EN
Refrigerator / User Manual
5 Operating the product
C
Figures in this user manual are schematic and may not match the product exactly. If the subject parts
are not included in the product you have purchased, then those parts are valid for other models.
5.1 Indicator panel
Touch-controlled indicator panel allows you to set the temperature and control the other functions of the
product. Just press the relevant buttons for function settings.
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
1
2 3
4
5 6
9
10 11
12
13
14
15
16
1718
19
20
27
28
29
30
31
32
33
*34.1
*34.2
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
7
*8
22
21
23
24
*25
26
14 / 29 EN
Refrigerator / User Manual
Operating the product
1. Quick cooling function indicator
It turns on when the quick cool function is
activated.
2. Fridge compartment temperature indicator
Temperature of the fridge compartment is shown;
it can be set to 8,7,6,5,4,3,2,1.
3. Fahrenheit indicator
It is a Fahrenheit indicator. When the Fahrenheit
indication is activated, the temperature set values
are shown in Fahrenheit and the relevant icon
turns on.
4. Key lock
Press key lock button simultaneously for 3 sec-
onds. Key lock symbol
will light up and key lock mode will be activated.
Buttons will not function if the Key lock mode is
active. Press key lock button simultaneously for 3
seconds again. Key lock symbol will turn off and
the key lock mode will be exited.
Press the key lock button if you want to prevent
changing of the temperature setting of the
refrigerator.
5. Power failure/High temperature / error
warning
This indicator illuminates during power failure, high
temperature failures and error warnings. During
long-term power failures, the highest temperature
value that the freezer compartment reaches will
blink on the digital display. After checking the food
located in the freezer compartment, press the
alarm off button to clear the warning.
Please refer to "solutions recommended for
troubleshooting" section on your manual if you
observe that this indicator is illuminated.
6. Filter reset icon
This icon turns on when the filter needs to be
reset.
7. Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
8. Multizone freezer icon
Hover over the multizone freezer icon using the FN button;
the icon will start to flash. When you press the OK key,
multizone cabin freezer icon turn on and operates as a
freezer.
9. Freezer compartment temperature
indicator
Temperature of the fridge compartment is shown;
it can be set to -18, -19, -20, -21, -22, -23, -24.
10. Quick freeze function indicator
It turns on when the quick freeze function is
activated.
11. Fahrenheit indicator
It is a Fahrenheit indicator. When the Fahrenheit
indication is activated, the temperature set values
are shown in Fahrenheit and the relevant icon
turns on.
12. Quick freeze function button
Press this button to activate or deactivate the quick
freeze function. When you activate the function,
the freezer compartment will be cooled to a
temperature lower than the set value.
C
Use the quick freeze function when you
want to quickly freeze the food placed
in freezer compartment. If you want
to freeze large amounts of fresh food,
activate this function before putting the
food into the product.
C
If you do not cancel it, Quick Freeze
will cancel itself automatically after 4
hours at the most or when the fridge
compartment reaches to the required
temperature.
C
This function is not recalled when
power restores after a power failure.
13. Filter reset
The filter is reset when the quick freeze button is
pressed for 3 seconds. Filter reset icon goes off.
15 / 29 EN
Refrigerator / User Manual
Operating the product
14. FN button
Using this key, you can switch between the
functions that you want to select. Upon pressing
this key, the icon, whose function is required to be
activated or deactivated, and this icon's indicator
starts flashing. The FN button gets deactivated if
not pressed for 20 seconds. You need to press this
button to change the functions again.
15. Celsius indicator
It is a Celsius indicator. When the Celsius indication
is activated, the temperature set values are shown
in Celsius and the relevant icon turns on.
16. OK button
After navigating the functions using the FN button,
when the function is cancelled via the OK button,
the relevant icon and the indicator flashes. When
the function is activated, it remains on. The
indicator continues to flash in order to show the
icon it is on.
17. Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
18. Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
19. Set increasing button
Select the relevant cabin with the select button;
the cabin icon representing the relevant cabin will
start to flash. If you press the set increasing button
during this process, the set value gets increased. If
you keep pressing it in a loop, the set value returns
to the beginning.
20. Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
21. Setting the Celsius and Fahrenheit
indicator
Hover over this key using the FN key and select
Fahrenheit and Celsius via the OK key. When
the relevant temperature type is selected, the
Fahrenheit and Celsius indicator turns on.
22. Ice machine off icon
Press the FN key (until it reaches the ice icon and
the lower line) to switch off the ice machine. The
ice machine off icon and the ice machine function
indicator start flashing when you hover over them,
thus you can understand whether the ice machine
will be turned on or off. When you press the OK
button, the ice machine icon lights continuously
and the Indicator continues to flash during this
process. If you do not press any button after 20
seconds, the icon and the indicator remains on.
Thus, the ice machine is switched off. In order to
switch on the ice machine again, hover over the
icon and the indicator; thus, both the ice machine
off icon and the indicator will start flashing. If you
do not press any button within 20 seconds, the
icon and the indicator will go off and thus the ice
machine will be switched on again.
C
Indicates whether the icematic is
on or off.
C
Water flow from water tank
will stop when this function is
selected. However, ice made
previously can be taken from the
icematic.
23. Eco fuzzy function icon
Press the FN key (until it reaches the letter e
icon and the lower line) to activate the eco fuzzy.
When you hover over the eco fuzzy icon and the
eco fuzzy function indicator, they start flashing.
Thus, you can understand whether the eco fuzzy
function will be activated or deactivated. When you
press the OK button, the eco fuzzy function icon
lights continuously and the Indicator continues to
flash during this process. If you do not press any
button after 20 seconds, the icon and the indicator
remains on. Thus, the eco fuzzy function is
activated. In order to cancel the eco fuzzy function,
16 / 29 EN
Refrigerator / User Manual
Operating the product
hover over the icon and the indicator again and
press the OK key. Thus, both the eco fuzzy function
icon and the indicator will start flashing. If you do
not press any button within 20 seconds, the icon
and the indicator will go off and the eco fuzzy
function will be cancelled.
24. Vacation function icon
Press the FN key (until it reaches the umbrella
icon and the lower line) to activate the vacation
function. When you hover over the vacation
function icon and the vacation function indicator,
they start flashing. Thus, you can understand
whether the vacation function will be activated or
deactivated. When you press the OK button, the
vacation function icon lights continuously and thus
the Vacation function is activated. The Indicator
continues to flash during this process. Press the
OK key to cancel the vacation function. Thus, both
the vacation function icon and the indicator will
start flashing and the vacation function will be
cancelled.
25. Multizone fridge icon
When you select the multizone fridge icon using
the FN button and press the OK key, the multizone
cabin turns into a fridge cabin and operates as a
cooler.
26. Celsius indicator
It is a Celsius indicator. When the Celsius indication
is activated, the temperature set values are shown
in Celsius and the relevant icon turns on.
27. Set decreasing function
Select the relevant cabin with the select button;
the cabin icon representing the relevant cabin
will start to flash. If you press the set decreasing
button during this process, the set value gets
decreased. If you keep pressing it in a loop, the set
value returns to the beginning.
28. Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
29. Temperature change cabin icon
Indicates the cabin whose temperature is to be
changed. When the temperature change cabin icon
starts flashing, it is understood that the relevant
cabin has been selected.
30. Key lock
Press key lock button simultaneously for 3 sec-
onds. Key lock symbol
will light up and key lock mode will be activated.
Buttons will not function if the Key lock mode is
active. Press key lock button simultaneously for 3
seconds again. Key lock symbol will turn off and
the key lock mode will be exited.
Press the key lock button if you want to prevent
changing of the temperature setting of the
refrigerator.
31.Select button
Use this button to select the cabin whose tem-
perature you want to change. Switch between
the cabins by pressing this button. The selected
cabin can be understood from the cabin icons
(7,17,18,20,28,29). Whichever cabin icon is flash-
ing, the cabin, whose temperature set value you
want to change, is selected. Then, you can change
the set value by pressing the cabin set value
decreasing button (27) and the cabin set value in-
creasing button (19). If you do not press the select
button for 20 seconds, the cabin icons will go off.
You need to press this key to select a cabin again.
32. Alarm off warning
In case of power failure/high temperature
alarm, after checking the foods in the freezer
compartment, press the alarm off button to clear
the warning.
33. Quick cooling function button
The button has two functions. To activate or
deactivate the quick cool function, press it briefly.
Quick Cool indicator will turn off and the product
will return to its normal settings.
17 / 29 EN
Refrigerator / User Manual
Operating the product
C
Use quick cooling function when you
want to quickly cool the food placed
in the fridge compartment. If you want
to cool large amounts of fresh food,
activate this function before putting the
food into the product.
C
If you do not cancel it, quick cooling
will cancel itself automatically after 8
hours at the most or when the fridge
compartment reaches to the required
temperature.
C
If you press the quick cooling button
repeatedly with short intervals, the
electronic circuit protection will be
activated and the compressor will not
start up immediately.
C
This function is not recalled when
power restores after a power failure.
34. Multizone temperature indicator
Temperature set values of the multizone cabin are
displayed.
18 / 29 EN
Refrigerator / User Manual
Operating the product
5.2 Indicator panel
Touch-control indicator panel allows you to set the temperature and control the other functions related to
the refrigerator. Just press the relevant buttons for function settings.
C
Figures in this user manual are schematic and may not match the product exactly. If the subject parts
are not included in the product you have purchased, then those parts are valid for other models.
1-On/Off function
Press the On/Off button for 3 seconds to turn off
or turn on the fridge.
2. Quick freeze function button
Press this button to activate or deactivate the
quick freeze function. When you activate the
function, the freezer compartment will be cooled
to a temperature lower than the set value.
C
Use the quick freeze function when you
want to quickly freeze the food placed
in freezer compartment. If you want
to freeze large amounts of fresh food,
activate this function before putting the
food into the product.
C
If you do not cancel it, Quick Freeze
will cancel itself automatically after 4
hours at the most or when the fridge
compartment reaches to the required
temperature.
C
This function is not recalled when
power restores after a power failure.
3.Select button
Use this button to select the compartment
whose temperature you want to change. Switch
between the compartment pressing this button.
The selected compartment be compartment
from the compartment icons (6, 25, 26) hichever
compartment is compartment the temperature set
value you want to change, is selected. Then, can
then the set value by pressing the compartment
value Temperature Adjustment button (4)
4.Temperature Adjustment / Temperature
Decrease
When pressed, decreases the temperature of the
selected compartment.
5-Quick freeze Indicator
This icon lits when the Quick freeze function is
active.
6. Fridge compartment indicator
When this indicator is active, the temperate
of the fridge compartment is displayed on the
temperature value indicator.Fridge compartment
can be set to 8, 7, 6, 5, 4, 3, 2 or 1°C / 46, 45,
44, 43, 42, 41, 40,39,38,37,36,35,34 or 33°F by
pressing Temperature Adjustment button (4).
2
1
6
7
5
8
*9
24
12
23
14
15
17
18 19
3
4
13
22
21
*20
*11
10
16
26
25
19 / 29 EN
Refrigerator / User Manual
Operating the product
7. Temperature value indicator
Shows the temperature value of the selected
compartment.
8. Fahrenheit indicator
It is a Fahrenheit indicator. When the Fahrenheit
indication is activated, the temperature set values
are shown in Fahrenheit and the relevant icon
turns on.
9. Multizone fridge icon
When you select the multizone fridge icon using
the FN button (16) and press the OK button (17)
the multizone cabin turns into a fridge cabin and
operates as a cooler.
10. Multizone cabin icon
It shows multizone cabin icon.
11. Multizone freezer icon
When you select the multizone freezer icon using
the FN button (16) and press the OK button (17)
the multizone cabin turns into a freezer cabin and
operates as a freezer.
12. Power failure/High temperature / error
warning
This indicator illuminates during power failure, high
temperature failures and error warnings. During
long-term power failures, the highest temperature
value that the freezer compartment reaches will
blink on the digital display. After checking the food
located in the freezer compartment, press the
alarm off button (19) to clear the warning.
13.Setting the Celsius and Fahrenheit
indicator
Hover over this key using the FN key and select
Fahrenheit and Celsius via the OK key. When
the relevant temperature type is selected, the
Fahrenheit and Celsius indicator turns on.
14. Vacation function icon
Press the FN key (until it reaches the umbrella
icon) to activate the vacation function. When you
hover over the vacation function icon, it starts
flashing. Thus, you can understand whether the
vacation function will be activated or deactivated.
When you press the OK button, the vacation
function indicator lights continuously and thus the
Vacation function is activated. Press the OK key
to cancel the vacation function. Thus, the vacation
function indicator will start flashing and the
vacation function will be cancelled.
15. Quick cooling function indicator
It turns on when the quick fridge function is
activated.
16. FN button
Using this key, you can switch between the
functions that you want to select. Upon pressing
this key, the icon, whose function is required to be
activated or deactivated, and this icon’s indicator
starts flashing. The FN button gets deactivated if
not pressed for 20 seconds. You need to press this
button to change the functions again.
17. OK button
After navigating the functions using the FN button,
when the function is cancelled via the OK button,
the relevant indicator flashes. When the function is
activated, it remains on. The indicator continues to
flash in order to show the icon it is on.
18. Quick cooling function button
The button has two functions. To activate or
deactivate the quick cool function, press it briefly.
Quick Cool indicator will turn off and the product
will return to its normal settings.
19. Alarm off warning
In case of power failure/high temperature
alarm, after checking the foods in the freezer
compartment, press the alarm off button to clear
the High temperature warning icon (12).
20. Filter reset
The filter is reset when the alarm off button (19) is
pressed for 3 seconds. Filter reset icon goes off.
21. Eco fuzzy function icon
Press the FN key (until it reaches the letter e
icon) to activate the eco fuzzy. When you hover
over the eco fuzzy icon it start flashing. Thus,
you can understand whether the eco fuzzy
function will be activated or deactivated. When
you press the OK button, the eco fuzzy function
icon lights continuously during this process. If you
do not press any button after 20 seconds, the
icon remains on. Thus, the eco fuzzy function is
20 / 29 EN
Refrigerator / User Manual
Operating the product
activated. In order to cancel the eco fuzzy function,
hover over the icon again and press the OK key.
Thus, the eco fuzzy function icon will start flashing.
If you do not press any button within 20 seconds,
the icon will go off and the eco fuzzy function will
be cancelled.
22. Ice machine off icon
Press the FN key (until it reaches the ice icon) to
switch off the ice machine. The ice machine off
icon start flashing when you hover over it, thus you
can understand whether the ice machine will be
turned on or off. When you press the OK button,
the ice machine icon lights continuously during
this process. If you do not press any button after
20 seconds, the icon and the indicator remains on.
Thus, the ice machine is switched off. In order to
switch on the ice machine again, hover over the
icon. The ice machine off icon will start flashing. If
you press ok button, the icon will go off and thus
the ice machine will be switched on again.
C
Indicates whether the icematic is
on or off.
C
Water flow from water tank
will stop when this function is
selected. However, ice made
previously can be taken from the
icematic.
23. Filter reset icon
This icon turns on when the filter needs to be
reset.
24. Celsius indicator
It is a Celsius indicator. When the Celsius indication
is activated, the temperature set values are shown
in Celsius and the relevant icon turns on.
25. Multizone compartment indicator
When this indicator is active, the temperate
of the multizone compartment is displayed
on the temperature value indicator. Multizone
compartment set values change by pressing
Temperature Adjustment button (4).
26. Freezer compartment indicator
When this indicator is active, the temperate of
the freezer compartment is displayed on the
temperature value indicator.Freezer compartment
can be set to -18, -19, -20, -21, -22, -23 and -24
°C /0, -2, -4, -6, -8, -10 and -12°F by pressing
Temperature Adjustment button (4).
21 / 29 EN
Refrigerator / User Manual
Operating the product
5.3 Freezing fresh food
• In order to preserve the quality of the food, it
shall be frozen as quickly as possible when it is
placed in the freezer compartment, use the fast
freezing feature for this purpose.
• You may store the food longer in freezer
compartment when you freeze them while they
are fresh.
• Ensure food to be frozen is packed well in air-
tight containers or packaging.
• Ensure that you pack your food before putting
them in the freezer. Use freezer containers,
foils and moisture-proof papers, plastic
bags and other packing materials instead of
traditional packing papers.
• Label each pack of food by adding the date
before freezing. You may distinguish the
freshness of each food pack in this way when
you open your freezer each time. Store the food
frozen before in the front side of compartment
to ensure that they are used first.
• Frozen food must be used immediately after
they are thawed and they should not be re-
frozen.
• Do not freeze too large quantities of food at
one time.
5.4 Recommendations for
preserving the frozen food
Compartment shall be set to -18°C at least.
1. Put packages in the freezer as quickly as
possible after purchase without allowing the
to thaw.
2. Check whether the "Use By" and "Best
Before" dates on the packaging are expired or
not before freezing it.
3. Ensure that the package of the food is not
damaged.
5.5 Deep-freeze information
According to IEC 62552 standards, the product
shall freeze at least 4.5 kg of food at 25°C
ambient temperature to -18°C or lower within 24
hours for every 100-litres of freezer volume.
It is possible to preserve the food for a long time
only at -18°C or lower temperatures.
You can keep the freshness of food for many
months (at -18°C or lower temperatures in the
deep freeze).
Foods to be frozen should not be allowed to come
in contact with the previously frozen items to
prevent them from getting thawed partially.
Freezer
Compartment
Setting
Fridge
Compartment
Setting
Remarks
-18°C 4°C This is the normal recommended setting.
-20, -22 or
-24°C
4°C
These settings are recommended when the ambient temperature
exceeds 30°C.
Quick Freeze 4°C
Use when you wish to freeze your food in a short time. Your product
will return to its previous mode when the process is over.
-18°C or colder 2°C
Use these settings if you think that your fridge compartment is not
cold enough because of the hot ambient conditions or frequent
opening and closing of the door.
22 / 29 EN
Refrigerator / User Manual
Operating the product
Boil the vegetables and drain their water in order
to store vegetables for a longer time as frozen.
After draining their water, put them in air-proof
packages and place them inside the freezer. Food
such as bananas, tomatoes, lettuce, celery, boiled
eggs, potatoes are not suitable for freezing. When
these foods are frozen, only their nutritional value
and taste shall be affected negatively. They shall
not be spoiled so that they would create a risk for
human health.
5.6 Placing the food
Freezer
compartment
shelves
Various frozen food such
as meat, fish, ice cream,
vegetables and etc.
Refrigerator
compartment
shelves
Food in pans, covered plates
and closed containers, eggs (in
closed container)
Door shelves
of fridge
compartment
Small and packaged food or
beverage
Crisper Vegetables and fruits
Fresh zone
compartment
Delicatessen (breakfast food,
meat products that shall be
consumed in a short time)
5.7 Door open warning
(This feature is optional)
An audio warning signal will be given when the
door of your product is left open for 1 minute. This
warning will be muted when the door is closed or
any of the display buttons (if any) are pressed.
5.8 Frost Free Chill compartment
Frost Free Chill compartments allow you to prepare
the food for freezing. You can also use these
compartments to store your food at a temperature
a few degrees below the fridge compartment.
You can increase the inner volume of your
refrigerator by removing any of the chiller
compartments:
1. Pull the compartment towards yourself until it
stops.
2. Lift the compartment about 1 cm up and pull
towards yourself to remove it from its seating.
5.9 Crisper
Crisper of the refrigerator is designed specially
to keep the vegetables fresh without losing their
humidity. For this purpose, cool air circulation is
intensified around the crisper in general. Remove
the door shelves that stand against the crisper
before removing the crisper.
5.10 Humidity-controlled crisper
Everfresh+(R)
Humidity rates of fruits and vegetables are kept
under control thanks to the humidity-controlled
crisper and thus the food is ensured to stay fresh
for a longer period.
We recommend that you place leafy vegetables
such as lettuce and spinach and vegetables sensi-
tive to humidity loss as horizontally as possible
when putting them in the crisper; not in a horizon-
tal position on their roots.
While the vegetables are being stored, their spe-
cific weights should be taken into consideration.
Heavy and hard vegetables must be placed at the
bottom of the crisper and light and soft vegetables
must be on the upper part.
23 / 29 EN
Refrigerator / User Manual
Operating the product
Never leave the vegetables in their plastic bags in
the crisper. If they are left in their plastic bags, this
will cause them to decompose in a short period
of time. If you prefer the vegetqbles do not get in
contact with other vegetables for hygienic reasons,
use perforated paper or similar material instead
of plastic bags.Do not place pears, apricots,
peaches etc., especially those fruits that generate
large amounts of ethylene, in the same crisper
with other fruits and vegetables. The ethylene gas
emitted by these fruits cause other fruits to ripen
sooner and to rot in a shorter span of time.
5.11 Egg tray
You can install the egg holder to the desired door
or body shelf.
Never keep the egg holder in the freezer
compartment.
In some models, the egg holder is the upper
drawer of the water tank. Eggs can be kept there.
3-Movable middle section is closed when the left
door of the fridge compartment is opened.
4-It must not be opened manually. It moves under
the guidance of the plastic part on the body while
the door is closed.
5.13 Multizone Compartment
The compartment is set as freezer as factory
default, and it is set as cooler upon pressing the
Mode button for 3 seconds.
The Multizone Compartment of your refrigerator
may be used in any desired mode by adjusting it
to fridge (2/4/6/8 °C) or freezer (-18/-20/-22/-
24) temperatures. You can keep the compartment
at the desired temperature with the Multizone
Compartment's Temperature Setting Button. The
temperature of the Multizone Compartment may
be set to 0 and 10 degrees in addition to the fridge
compartment temperatures and to -6 degrees in
addition to the freezer compartment temperatures.
0 degree is used to store the deli products longer,
and -6 degrees is used to keep the meats up to 2
weeks in an easily sliceable condition.
The feature of switching to a Fridge or Freezer
compartment is provided by a cooling element
located in the closed section (Compressor
Compartment) behind the refrigerator. During
operation of this element, sounds similar to the
sound of seconds heard from an analogue clock
may be heard. This is normal and is not a fault.
5.14 Blue light
The crispers of the refrigerator are illuminated
with a blue light. Foodstuff stored in the crisper
continue their photosynthesis by means of the
wavelength effect of blue light and thus, preserve
their freshness and increase their vitamin content.
5.15 Odour filter
Odour filter in the air duct of the fridge
compartment prevents build-up of unpleasant
odours in the refrigerator.
5.12 Movable Middle Section
Movable middle section is intended to prevent
the cold air inside your refrigerator from escaping
outside.
1- Sealing is provided when the gaskets on the
door presses on the surface of the movable middle
section while the fridge compartment doors are
closed.
2- Another reason that your refrigerator is
equipped with a movable middle section is that it
increases the net volume of the fridge compart-
ment. Standard middle sections occupy some
non-usable volume in the refrigerator.
24 / 29 EN
Refrigerator / User Manual
Operating the product
5.16 Use of internal water dispenser
and water dispenser at the door
(in some models)
After connecting the refrigerator to a water source
or replacing the water filter, flush the water
system. Use a sturdy container to depress and
hold the water dispenser lever for 5 seconds,
then release it for 5 seconds. Repeat until water
begins to flow. Once water begins to flow, continue
depressing and releasing the dispenser paddle
(5 seconds on, 5 seconds off) until a total of 4
gal. (15L) has been dispensed. This will flush air
from the filter and water dispensing system, and
prepare the water filter for use. Additional flushing
may be required in some households. As air is
cleared from the system, water may spurt out of
the dispenser.
Allow 24 hours for the refrigerator to cool down
the water. Dispense enough water every week to
maintain a fresh supply.
C
After 5 minutes of continuous
dispensing, the dispenser will stop
dispensing water to avoid flooding.
To continue dispensing, press the
dispenser paddle again.
5.17 Dispensing water
Hold a container under the dispenser spout while
pressing the dispenser pad.
Release the dispenser pad to stop dispensing.
C
It is normal for the first few glasses of
water taken from the dispenser to be
warm.
C
If the water dispenser is not used for a long
period of time, dispose of first few glasses
of water to obtain fresh water.
During initial use, you will have to wait
approximately 24 hours for the water to cool down.
Take out the glass a little while after you pull the
trigger.
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
Water dispenser at the door (in some models)
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
Select
Quick FreezeQuick Cool
FN
OK
3 “
3 “
Built-in water dispenser (in some models)
25 / 29 EN
Refrigerator / User Manual
Operating the product
Built-in water dispenser (in some models)
5.18 Maintaining water dispenser
A
Before using your fridge for the first
time and after replacing your water
filter, water dispenser may drip drops
of water. To prevent water dripping or
leaking from dispenser, please bleed
the air from the system by dispensing
5-6 gallons (about 20 liter) of water
through the water dispenser before
the first use and every time after
you change the water filter. This will
remove any air trapped in the system
and stop the water dispenser from
leaking. Checking coupler position
and the straightness of water line at
the back of the unit will be required if
there’s an obstruction in water flow.
C
If your water dispenser is leaking just a few
drops of water after you have dispensed some
water, this is normal.
26 / 29 EN
Refrigerator / User Manual
Operating the product
5.19 Icematic
(in some models)
To get ice from the icematic, fill the water tank
in the fridge compartment with water up to the
maximum level.
Ice cubes in the ice drawer may stick to each other
and become a block due to hot and humid air in
approximately 15 days. This is normal. If you can-
not break the block apart, you can empty the ice
container and make ice again.
In some models, the water tank is filled by the
main source, do not need to fill it by hand.
C
It is recommended to change the water
in the water tank if it remains in the
water tank for more than 2-3 weeks.
C
Strange noises you hear from the refrig-
erator at 120-minute intervals are the
sounds of ice-making and pouring. This
is normal.
C
If you do not want to make ice, press the Ice
off icon to stop the icematic to save energy
and prolong the service life of your refrigerator.
C
It is normal that a few drops of water drop
from the dispenser after you have taken water.
5.20 Icematic and ice
storage container
(in some models)
Using the Icematic
Fill the Icematic with water and place it into its
seat. Your ice will be ready approximately in two
hours. Do not remove the Icematic from its seating
to take ice.
Turn the knobs on the ice reservoirs clockwise by
90 degrees.
Ice cubes in the reservoirs will fall down into the
ice storage container below.
You may take out the ice storage container and
serve the ice cubes.
If you wish, you may keep the ice cubes in the ice
storage container.
Ice storage container
Ice storage container is only intended for
accumulating the ice cubes. Do not put water in it.
Otherwise, it will break.
27 / 29 EN
Refrigerator / User Manual
6 Maintenance and Cleaning
Cleaning the product regularly will prolong its
service life.
B
WARNING: Disconnect the power
before cleaning the refrigerator.
• Do not use sharp and abrasive tools,
soap, house cleaning materials,
detergents, gas, gasoline, varnish and
similar substances for cleaning.
• Melt a teaspoonful of carbonate in
the water. Moisten a piece of cloth
in the water and wring out. Wipe the
device with this cloth and dry off
thoroughly.
• Take care to keep water away from
the lamp’s cover and other electrical
parts.
• Clean the door using a wet cloth.
Remove all items inside to detach
the door and chassis shelves. Lift the
door shelves up to detach. Clean and
dry the shelves, then attach back in
place by sliding from above.
• Do not use chloric water or cleaning
products on the exterior surface and
chrome-coated parts of the product.
Chlorine will cause rust on such
metallic surfaces.
• Do not use sharp, abrasive tools,
soap, household cleaning agents,
detergents, kerosene, fuel oil,
varnish etc. to prevent removal and
deformation of the prints on the
plastic part. Use lukewarm water and
a soft cloth for cleaning and then
wipe it dry.
6.1. Preventing Bad Odour
The product is manufactured free of any
odorous materials. However, keeping the food in
inappropriate sections and improper cleaning of
internal surfaces may lead to malodour.
To avoid this, clean the inside with carbonated
water every 15 days.
• Keep the foods in sealed holders.
Microorganisms may spread out
of unsealed food items and cause
malodour.
• Do not keep expired and spoilt foods
in the refrigerator.
6.2. Protecting Plastic Surfaces
Oil spilled on plastic surfaces may damage the
surface and must be cleaned immediately with
warm water.
28 / 29 EN
Refrigerator / User Manual
7. Troubleshooting
Check this list before contacting an authorised
service agent. Doing so will save you time and
money. This list includes frequent complaints that
are not related to faulty workmanship or materials.
Certain features mentioned herein may not apply to
your product.
The refrigerator is not working.
• The power plug is not fully settled. >>> Plug it in
to settle completely into the socket.
• The fuse connected to the socket powering the
product or the main fuse is blown. >>> Check the
fuses.
Condensation on the side wall of the cooler
compartment (MULTI ZONE, COOL, CONTROL
and FLEXI ZONE).
• The door is opened too frequently >>> Take care
not to open the product’s door too frequently.
• The environment is too humid. >>> Do not install
the product in humid environments.
• Foods containing liquids are kept in unsealed
containers. >>> Keep the foods containing liquids
in sealed containers.
• The product’s door is left open. >>> Do not keep
the product’s door open for long periods.
• The thermostat is set to too low temperature. >>>
Set the thermostat to appropriate temperature.
Compressor is not working.
• In case of sudden power failure or pulling the
power plug off and putting back on, the gas
pressure in the product’s cooling system is
not balanced, which triggers the compressor
thermic safeguard. The product will restart after
approximately 6 minutes. If the product does not
restart after this period, contact an authorised
service agent.
• Defrosting is active. >>> This is normal for a fully-
automatic defrosting product. The defrosting is
carried out periodically.
• The product is not plugged in. >>> Make sure the
power cord is plugged in.
• The temperature setting is incorrect. >>> Select
the appropriate temperature setting.
• The power is out. >>> The product will continue
to operate normally once the power is restored.
The refrigerator’s operating noise is increasing
while in use.
• The product’s operating performance may
vary depending on the ambient temperature
variations. This is normal and not a malfunction.
The refrigerator runs too often or for too
long.
• The new product may be larger than the
previous one. Larger products will run for longer
periods.
• The room temperature may be high. >>> The
product will normally run for long periods in
higher room temperature.
• The product may have been recently plugged
in or a new food item is placed inside. >>>
The product will take longer to reach the set
temperature when recently plugged in or a new
food item is placed inside. This is normal.
• Large quantities of hot food may have been
recently placed into the product. >>> Do not
place hot food into the product.
• The doors were opened frequently or kept open
for long periods. >>> The warm air moving
inside will cause the product to run longer. Do
not open the doors too frequently.
• The freezer or cooler door may be ajar. >>>
Check that the doors are fully closed.
• The product may be set to temperature too low.
>>> Set the temperature to a higher degree
and wait for the product to reach the adjusted
temperature.
• The cooler or freezer door washer may be
dirty, worn out, broken or not properly settled.
>>> Clean or replace the washer. Damaged
/ torn door washer will cause the product to
run for longer periods to preserve the current
temperature.
The freezer temperature is very low, but the
cooler temperature is adequate.
• The freezer compartment temperature is set
to a very low degree. >>> Set the freezer
compartment temperature to a higher degree
and check again.
The cooler temperature is very low, but the
freezer temperature is adequate.
• The cooler compartment temperature is set
to a very low degree. >>> Set the freezer
compartment temperature to a higher degree
and check again.
29 / 29 EN
Refrigerator / User Manual
Troubleshooting
The food items kept in cooler compartment
drawers are frozen.
• The cooler compartment temperature is set to a
very low degree. >>> Set the freezer compartment
temperature to a higher degree and check again.
The temperature in the cooler or the freezer is
too high.
• The cooler compartment temperature is set to
a very high degree. >>> Temperature setting
of the cooler compartment has an effect on the
temperature in the freezer compartment. Wait
until the temperature of relevant parts reach the
sufficient level by changing the temperature of
cooler or freezer compartments.
• The doors were opened frequently or kept open
for long periods. >>> Do not open the doors too
frequently.
• The door may be ajar. >>> Fully close the door.
• The product may have been recently plugged in
or a new food item is placed inside. >>> This is
normal. The product will take longer to reach the
set temperature when recently plugged in or a new
food item is placed inside.
• Large quantities of hot food may have been
recently placed into the product. >>> Do not place
hot food into the product.
Shaking or noise.
• The ground is not level or durable. >>> If the
product is shaking when moved slowly, adjust the
stands to balance the product. Also make sure the
ground is sufficiently durable to bear the product.
• Any items placed on the product may cause noise.
>>> Remove any items placed on the product.
The product is making noise of liquid flowing,
spraying etc.
• The product’s operating principles involve liquid
and gas flows. >>> This is normal and not a
malfunction.
There is sound of wind blowing coming from
the product.
• The product uses a fan for the cooling process.
This is normal and not a malfunction.
There is condensation on the product’s internal
walls.
• Hot or humid weather will increase icing and
condensation. This is normal and not a malfunction.
• The doors were opened frequently or kept open
for long periods. >>> Do not open the doors too
frequently; if open, close the door.
• The door may be ajar. >>> Fully close the door.
There is condensation on the product’s exterior
or between the doors.
• The ambient weather may be humid, this is quite
normal in humid weather. >>> The condensation
will dissipate when the humidity is reduced.
The interior smells bad.
• The product is not cleaned regularly. >>> Clean
the interior regularly using sponge, warm water and
carbonated water.
• Certain holders and packaging materials may
cause odour. >>> Use holders and packaging
materials without free of odour.
• The foods were placed in unsealed holders. >>>
Keep the foods in sealed holders. Micro-organisms
may spread out of unsealed food items and cause
malodour. Remove any expired or spoilt foods from
the product.
The door is not closing.
• Food packages may be blocking the door. >>>
Relocate any items blocking the doors.
• The product is not standing in full upright position
on the ground. >>> Adjust the stands to balance
the product.
• The ground is not level or durable. >>> Make sure
the ground is level and sufficiently durable to bear
the product.
The vegetable bin is jammed.
• The food items may be in contact with the upper
section of the drawer. >>> Reorganize the food
items in the drawer.
If The Surface Of The Product Is Hot.
• High temperatures may be observed between the
two doors, on the side panels and at the rear grill
while the product is operating. This is normal and
does not require service maintenance!Be careful
when touching these areas.
A WARNING:
If the problem persists after following the instructions
in this section, contact your vendor or an Authorised
Service. Do not try to repair the product.
