EN
1
APPLIANCE
DAILY REFERENCE
GUIDE
Before using the appliance carefully read Safety Instructions.
PRODUCT DESCRIPTION
THANK YOU FOR BUYING A HOTPOINT PRODUCT.
In order to receive a more complete assistance,
please register your appliance on:
www.hotpoint.eu/register
You can download the Safety Instructions and the User
Manual, by visiting our website docs.hotpoint.eu
and following the Instructions on the back of this
booklet.
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Cutlery basket
7. Lower spray arm
8. Filter Assembly
9. Salt reservoir
10. Detergent and Rinse Aid dispensers
11. Rating plate
12. Control panel
0000 000 00000
Service:
1
2
3
4
5
6
7
9
8
1011
12
3
1
2
8
13
14
5
4
6
7 11 12
9
10
3 ’’
1. On-O/Reset button with indicator light
2. Program selection button with indicator light
3. Half Load button with indicator light / Key lock
4. Eco program indicator light
5. Key lock indicator light
6. Display
7. Program number and remaining time indicator
CONTROL PANEL
8. Tablet (Tab) indicator light
9. Closed water tap indicator light
10. Rinse Aid rell indicator light
11. Salt rell indicator light
12. Tablet (Tab) button with indicator light
13. Delay button with indicator light
14. Start/Pause button with indicator light / Drain out
