A P R O U D H E R I T A G E O F E X P E R I E N C E & Q U A L I T Y
WWW . V I N O T E M P . C O M
SINGLE-ZONE WINE COOLERS
EL-WCU103-02, EL-WCU110-02
EL-WCU104-02, EL-WCU111-02
EL-WCU106-02, EL-WCU108-02
EL-WCU107-02, EL-WCU109-02
EL-WCU105-02, EL-WCU112-02
IMPORTANT:
Complete your product registration today!
Visit product and warranty registration at:
https://www.vinotemp.com/extended-warranty/register-warranty
https://www.vinotemp.com/product-registration-form
For more information on warranty service and repair, please
refer to the appropriate section of your product literature.
For additional information about Vinotemp products,
visit www.vinotemp.com or call toll-free 1-800-777-8466
For more information on Prop 65, go to:
Please also fill out the Questionnaire below for a chance
to receive a FREE GIFT.
https://www.vinotemp.com/prop65
PRODUCT REGISTRATION
Purchase Confirmation
With the information you provide, we can confirm the date of purchase for your product.
The confirmation is of benefit to you, especially if your original proof of purchase is lost.
Product Registration
Completing this product registration is the only way to guarantee you will be notified
of substantive issues that arise concerning your product.
Become a Member of the Vinotemp
®
Family
Complete this product registration with your e-mail address and receive special
offers and updates on new products via e-mail.
2
WWW.VIN O T E MP. C O M
This unit can be used for storage and/or service. The unit has a glass door and soft interior
light that you can use to display your wine.
Storing wines at the proper temperature is important. To preserve them as long as
possible wine should be stored at approximately 55° Fahrenheit. However, the chart below
suggests the optimal drinking temperature for the different styles of wine.
°C °F Wine Style
18 64 Full Bodied Red Wines, Shiraz
17 62 Tawny Port
15 59 Medium Bodied Red Wines
14 57 Amontillado Sherry
13 55 Light Bodied Red Wines
12 54 Full Bodied White Wines
11 52 Medium Bodied White Wines
10 50 Rosé, Light Bodied White Wines
9 48 Vintage Sparkling
8 46 Fino Sherry
7 45 Non Vintage Sparkling
3
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
W
General Operating Instructions
Remove all external and internal packaging from your appliance. Be sure that all parts
have been included before discarding any packaging materials. You may want to keep the
box and packing materials for use at a later date.
Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged.
Let the unit rest UNPLUGGED for 24 hours once you have it placed in
your home.
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
-Save these instructions-
To register your product, visit:
http://www.vinotemp.com
Register your warranty within 10 days of receiving the unit.
Please be sure to retain your proof of purchase.
Protect Your Investment with an Extended Warranty!
Add a New Leaf extended warranty to your order, and have the security of knowing that if there should
be a problem, even years in the future, New Leaf will be there to assist! Usable for any Wine Cellar or
other electronic device manufactured by Vinotemp. Add this warranty to purchases made from
vinotemp.com or other qualified venders. Warranty must be registered within the fir
st 10 days from
original purchase.
Visit
www.Vinotemp.com to purchase.
4
WWW.VIN O T E MP. C O M
TABLE OF CONTENTS
IMPORTANT SAFETY INSTRUCTIONS
.......................................................................
6
ELECTRICAL CONNECTION
............................................................................................
7
PARTS AND SPECIFICATIONS
...............................................................................
8-11
INSTALLATION
.................................................................................................................14
OPERATING YOUR WINE COOLER..........................................................................15
CARE AND MAINTENANCE.........................................................................................17
TROUBLESHOOTING....................................................................................................18
TERMS OF SALE AND WARRANTY..........................................................................19
SERVICE & IMPORTANT NOTICE............................................................................28
BOTTLE CAPACITY
...................................................................................................12-13
5
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electrical shock or injury when using
your appliance, follow these basic precautions:
• Do not operate this or any other appliance with a damaged cord.
• Do not operate if housing is removed or damaged.
• Exercise caution and use reasonable supervision when appliance is used near children. Never allow
children to operate, play with or crawl inside the appliance. Keep packing materials away from children.
• Before performing any maintenance or cleaning, ensure that the unit is unplugged or that the power line
is disconnected.
• Do not clean appliance with flammable fluids. Do not store or use gasoline or other fl
ammable vapors
and liquids in the vicinity of this or any other appliance. The fumes can create a fire hazard or explosion.
• Exercise caution when moving and installing the unit. The cooler is heavy and may require two or more
people when moving the unit to prevent strain or injury.
• To ensure proper ventilation for your appliance, the front of the unit must be completely unobstructed.
Choose a well-ventilated area with temperatures above °F and below °F.
• Locate the unit away from direct sunlight and sources of heat (stove,
heater, radiator, etc).This unit is
intended for indoor use only and must be installed in an area protected from the elements.
• Place the appliance on a solid, level surface.
• Do not attempt to repair or replace any part of your appliance unless it is specifically recommended in
this manual. All other servicing should be referred to a qualified technician.
• Connect to properly polarized outlets only. It is recommended that a separate circuit, serving only your
appliance be provided. Use receptacles that cannot be turned off by a switch
or pull chain. Be sure that
the plug is fully inserted into the receptacle.
• To protect against electric shock, do not immerse appliance, plug or cord in water or other liquids. Avoid
locating the unit in moist areas.
• This appliance is designed to be built-in (fully-recessed) or freestanding.
• Do not use this appliance for other than its intended purpose. For indoor, household use only.
• Do not operate the unit with wet hands, while standing on a wet surface or while standing in water.
• Do not use solvent-based cleaning agents or abrasives on the interior of the cooler. These cleaners may
damage or discolor the interior.
• Keep fingers out of pinch point areas and be careful when closing doors if children are around.
• This appliance is designed for storing and cooling wines. Do not store perishable food or medical
products within the unit.
• When disposing of refrigerated appliances, special handling is often required. It is the consumer’s
responsibility to comply with federal and local regulations when disposing of this product.
• Do not slide your wine cooler into place.
• WARNING: Risk of child entrapment and suffocation. Before you throw away this or an old unit, take off
the door. Leave the shelves in place, so that children may not easily climb inside.
Caution:flammable refrigerant used! When handing,moving and use of the refrigerator,make sure
to avoid either damaging the refrigerant tubing,or in creasing the risk of a leak.
•
6
WWW.VIN O T E MP. C O M
W
ELECTRICAL CONNECTION
Improper use of the grounded plug can result in the risk of electrical shock.
If the power cord is damaged, frayed or shows cracks or abrasions across
its length, have it replaced at an authorized service center.
For your protection, this unit is equipped with a 3-conductor cord set that has a molded 3-prong grounding-
type plug, and should be used in combination with a properly connected grounding-type outlet.
• Do not under any circumstances cut or remove the third ground prong from the power cord supplied.
For personal safety, this appliance must be properly grounded.
• The cord should be secured behind the unit and not left exposed or dangling to prevent accidental
injury.
• A standard electrical supply (115V AC only, 60Hz, 15A), properly grounded in
accordance with the
National Electrical Code and local codes and ordinances, is required.
• Never unplug the unit by pulling the power cord. To disconnect the appliance, always grip the plug
firmly and pull straight out from the wall outlet. When moving the unit, be careful not to damage the
power cord.
• The unit should always be plugged into its own individual electrical outlet with a voltage rating that
matches the rating label on the unit.
Extension Cord
CAUTION: It is strongly recommended that you do not use an adapter
or an extension cord with this unit.
7
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
8
W W W . V I N O T E M P . C O M
PARTS AND SPECIFICATIONS
①Cabinet
② rooD ssalG lluF
③Stainless Steel Handle
④Ventilator
⑤ sgeL gnileveL
⑥Control Panel
⑦
⑧
Shelves
Lock
Note：EL-WCU103-02 or EL-WCU105-02 is with right hinge, the handle is on the left.
①Cabinet
②Stainless Steel Glass Door
③Stainless Steel Handle
④Ventilator
⑤ sgeL gnileveL
⑥Control Panel
⑦
⑧
Shelves
Lock
Note：EL-WCU104-02 is with right hinge, the handle is on the left.
MODELEL-WCU103-02, EL-WCU110-02, EL-WCU105-02, EL-WCU112-02
MODELEL-WCU104-02, EL-WCU111-02
EL-WCU110-02 or EL-WCU112-02 is with left hinge, the handle is on the right.
EL-WCU111-02 is with left hinge, the handle is on the right.
Model
EL-WCU103-02, EL-WCU110-02
EL-WCU104-02, EL-WCU111-02
EL-WCU105-02, EL-WCU112-02
Voltage AC 115V
41-100°F/Humidity 45-90%
Frequency 60Hz
Ambrient Temp Range
Control Temp Range 39-65°F
Refrigerant R600a/1.23Oz
Power Consumption 0.6kWh/24h
Input Power 200W
Volume 5.3 cu.ft
Net Weight 115LBS
123LBS
Gross Weight
Dimensions (WxDxH)
23-1/2 x 25-1/2 x 34-3/8in
25-1/2 x 26 x 35-3/4in
Box Dimensions (WxDxH)
*Note: The storage capacity is based on a standard 750ml wine bottle.
Storing large and/or oddly shaped bottles (including champagne and sparkling wine bottles)
will decrease the bottle capacity of the wine cooler.
Note:
EL-WCU103-02
full glass door with black edge, right hinge, stainless steel handle in black.
EL-WCU110-02
full glass door with black edge, left hinge, stainless steel handle in black.
EL-WCU105-02
full glass door with white edge, right hinge, stainless steel handle in white.
EL-WCU112-02
full glass door with white edge, left hinge, stainless steel handle in white.
EL-WCU104-02
stainless steel glass door, right hinge, stainless steel handle.
EL-WCU111-02
stainless steel glass door, left hinge, stainless steel handle.
9
732 Sout h Race t rac k R oad , H end erson, N evada 89015
i n f o @ v i n o t e m p . c o m
①Cabinet
② rooD ssalG lluF
③Stainless Steel Handle
④Ventilator
⑤ sgeL gnileveL
⑥Control Panel
⑦
⑧
Shelves
Lock
Note：EL-WCU106-02 is with right hinge, the handle is on the left.
EL-WCU108-02 is with left hinge, the handle is on the right.
①Cabinet
②Stainless Steel Glass Door
③Stainless Steel Handle
④Ventilator
⑤ sgeL gnileveL
⑥Control Panel
⑦
⑧
Shelves
Lock
Note：EL-WCU107-02 is with right hinge, the handle is on the left.
EL-WCU109-02 is with left hinge, the handle is on the right.
10
WWW.VIN O T E MP. C O M
PARTS AND SPECIFICATIONS
MODEL
EL-WCU107-02, EL-WCU109-02
MODELEL-WCU106-02, EL-WCU108-02
Note:
EL-WCU106-02
full glass door with black edge,right hinge, stainless steel handle in black.
EL-WCU108-02
full glass door with black edge,left hinge, stainless steel handle in black.
EL-WCU107-02
stainless steel glass door ,right hinge, stainless steel handle.
EL-WCU109-02
stainless steel glass door ,left hinge, stainless steel handle.
Model
EL-WCU106-02, EL-WCU108-02
EL-WCU107-02, EL-WCU109-02
Voltage AC 115V
41-100°F/Humidity 45-90%
Frequency 60Hz
Ambrient Temp Range
Control Temp Range 39-65°F
Refrigerant R600a/1.69Oz
Power Consumption 1.39kWh/24h
Input Power 200W
Volume 16.2 cu.ft
Net Weight 266LBS
281LBSGross Weight
Dimensions (WxDxH) 24 x 28-3/4 x 73-3/4in
26 x 29-1/2 x 75inBox Dimensions (WxDxH)
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
11
*Note: The storage capacity is based on a standard 750ml wine bottle.
Storing large and/or oddly shaped bottles (including champagne and sparkling wine bottles)
will decrease the bottle capacity of the wine cooler.
EL-WCU103-02, EL-WCU110-02, EL-WCU105-02, EL-WCU112-02, EL-WCU104-02, EL-WCU111-02
2
WWW. V I N O T E M P . C O M
PMETONIV
RELOOCENIWENOZ-ELGNIS
YTICAPAC ELTTOB
.selttobsselroerometadommoccaotrelooceniwruoyfosevlehsehttsujdayamuoY
.sevlehsehttuolluptonodesaelp,hgih3-2selttobgnikcatsfI
You may adjust the shelves of your wine cooler to accommodate more or less bottles.
If stackin eht g
bottle ,rehto hcae fo pot no s
please do not pull out the shelves.
EL-WCU106-02, EL-WCU108-02, EL-WCU107-02, EL-WCU109-02: Approximate 141 bottles
VINOTEMP
SINGLE-ZONE WINE COOLER
BOTTLE CAPACITY
732 Sout h Race t rac k R oad , H end erson, N evada 89015
i n f o @ v i n o t e m p . c o m
13
INSTALLING THE STAINLESS STEEL HANDLE
This wine cellar includes a stainless steel handle that is not required to operate this unit. To install the handle
please follow the below instructions:
On the door interior, slightly pull back the
door gasket on the side you wish to install the
handle to reveal the two (2) designated holes
for handle installation.
NOTE: Door gasket must not be removed, detached or
altered as it may directly affect cooling performance.
Using a screwdriver (not included), install the handle tightly
as shown in the diagram above with the included screws,
lock washers and flat washers (2 each).
INSTALLING THE CHARCOAL FILTER
To install the charcoal filter, please follow the below instructions:
Place the carbon filter on top the wooden shelf.
The back of the filter has a 3M glue tape which you can
affix to the shelf or the inside of the unit.
•
•
14
WWW.VIN O T E MP. C O M
INSTALLATION
Remove all packing material before using your wine cooler.
IMPORTANT: Before connecting the unit to a power source, let it stand upright for approximately 24
hours. This will reduce the possibility of a malfunction in the cooling system from handling during
transportation.
Clean the interior surface with lukewarm water and a soft cloth.
This unit is designed for freestanding or built in installation but indoor use only. Position the unit in a dry
and well-ventilated place. Avoid placing the wine cooler near any source of heat or moisture, or in direct
sunlight. Do NOT install the unit in a location with an ambient temperature that will fall below
For built-in installation, leave a
ensure proper air circulation to cool the compressor and condenser. Also, be sure to not obstruct the
front exhaust vent with any objects as this may affect the unit from performing properly.
clearance at the top of the wine cooler are suggested to ensure proper air circulation to cool the
compressor and condenser. Do not place underneath a table, counter top, or anything of the sort as this
will not allow for proper air circulation.
Do not slide the unit into place.
Place the wine cooler on a level surface strong enough to support it when it is fully loaded. T o level the
wine cooler, adjust the front leveling legs at the bottom of the wine cooler.
Plug the wine cooler into an exclusive, properly installed-grounded wall outlet.
When you use the wine cooler for the first time or restart the wine cooler after having
been shut off for a long time, there could be a few degrees variance between the
temperature you select and the one indicated on the LED readout . This is normal and
it is due to the length of the activation time. Once the wine cooler is running for a few
hours everything will be back to normal.
If the unit is unplugged, power lost, or turned off, you must wait 3 to 5 minutes
before restarting the unit. If you attempt to restart before this time delay, the wine
cooler will not start.
The controls of your wine cooler
Up
Used to raise (warm)the set temperature by 1
°C
or 1
°F
.
Temperature Display
°C
/
°F
Display
Down
Used to lower (cool) the set temperature by 1
°C
or 1
°F
.
Set temperature
press this bottom,
to set temperature.
view the SET and
temperature in at any time
the “SET” on SET temperature will temporarily “flash” in the LC D
display for 5 seconds
The DISPLAY temperature
°F /°C Selector
Select the temperature display setting in Fahrenheit or Celsius degree.
Operating Your Wine Cooler
The Wine cooler should
be
placed in
a
position
where the ambient temperature is
between
-38°C /41-100°F . Humidity level is between 45~90%. If the position is above
or below this range, the performance of the unit may be affected. For example, placing
your unit in extreme cold or hot conditions may cause interior temperature to fluctuate.
NOTE:
DISPLAY
shows you the current temperature of your wine cooler.
or
.
You can
2
3
5
6
4
7
Backlight Used to turn on/off the backlight.
1
1
2
3
4
5
6
Within 5 seconds, you can press
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
15
W
16
WWW.VIN O T E MP. C O M
Shelves
To avoid damaging the door gasket, please make sure that the door is fully open when
pull the shelves out approximatel
pulling shelves out of the rail compartment.
For easy access to the bottles stored,
you must
The shelves are designed to slide.
Light switch positions are located inside the unit (shown above) for you to turn the backlight on/off.
Orange backlight
Blue backlight
If you turn on the Blue/Orange backlight at the same time, do not leave them both on for a long
time since it can cause a high level of energy consumption.
90%.
You can select the
The
7
Power
To turn off the appliance, touch the mark and hold for at least 5 seconds.
Press again to turn on the appliance. The LED
readout will show the original
temperature set previously when you restart the appliance or reconnect after power cuts.
Setting the Temperature Control
temperature display setting from Fahrenheit to Celsius degrees by
touching the
°C/°F
Selector mark. Fahrenheit or Celsius degree indicator will appear
temperaturein blue color in the temperature display window. You can set the
by touching the UP and DOWN marks.
The temperature will
The temperature will
increase by
bydecrease 1
°C
or 1
°F
if you touch the DOWN mark once.
Temperature range :
4
-
18
°C
/
39
-
65
°F
The set temperature will appear in blue color in the LED display window.
desired
1
°C
or 1
°F
if you touch the UP mark once.
DOOR LOCK
The wine cooler comes with a lock and key combination. The keys are located inside the plastic bag
containing the Owner’s Manual. To unlock the door, insert the key into the lock and turn it counter-clockwise.
To lock the door, insert the key and turn it clockwise, ensuring that the metal pin is fully engaged.
DEFROSTING
The wine cooler defrosts automatically. The evaporator behind the rear wall of the unit automatically defrosts
and the condensate collects in the drainage channel behind the rear wall of the unit, and flows through the
drainage hole into the drip tr
ay by the compressor, where it evaporates.
CARE AND MAINTENANCE
CLEANING YOUR WINE COOLER
IMPORTANT: Always unplug the unit before cleaning or performing maintenance. Never use harsh
cleansers or scouring pads to clean any part of the unit.
• Turn off the power, unplug the appliance, and remove all items including shelves.
• Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2
tablespoons of baking soda to a quart of water.
• Wash the shelves with a mild detergent solution.
• Wring excess wate
r out of the sponge or cloth before cleaning control panels or any electrical parts.
• Wash the outside cabinet with warm water and mild liquid detergent. Rinse well and wipe dry with a
clean
soft cloth.
POWER FAILURE
Most power failures are corrected within a few hours and should not affect the temperature of your appliance.
If the power is off for an extended period of time, proper steps should be taken to protect your contents.
INACTIVITY
If the unit will not be used for a period of less than three weeks, leave the cooler operating. If the period of
inactivity is several months, remove all items and turn the unit off. Clean an
d dry the interior thoroughly.
Leave the door open slightly to prevent any possible moisture build-up.
MOVING YOUR WINE COOLER
Before moving your wine cooler, first be sure to remove all items from the cooler.
• Securely tape down any loose items, such as shelves, inside the unit.
• Turn the adjustable leg up to the base to avoid damage.
• Tape the door shut.
• Ensure that the unit stays securely in the upright position during transportation. Protect the outside of
the appliance with a blanket or similar item.
ENERGY SAVING TIPS
• The unit should be located in the coolest area of the room away from heat sources or direct sunlight.
• Ensure that the unit has proper allowances on all sides for proper ventilation. Never cover any air
vents.
• Only open the cooler door for as long as necessary. Frequent opening of the door will affect internal
temperature.
W
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
17
PROBLEM
S WITH YOUR WINE COOLER
Most c
ommon problems can be solved easily, saving you the cost of a possible service call. Try the following
suggestions to see if you can solve the problem before contacting Vinotemp at
Info@Vinotemp.com.
TROUB
LESHOOTING
PROBLEM POSSIBLE CAUSE
Wine
Cooler does not operate
• Ensur
e unit is plugged into an electrical outlet.
• Check if unit is turned off.
• Check for a tripped circuit breaker or blown fuse.
Wine
Cooler is not cold
enough
• Check
the temperature control setting.
• External environment or ambient temperature may require a higher
setting.
• Check if door does not close completely or is open too often.
• Check if door gasket does not seal properly.
Wine
Cooler turns on and off
frequently
• The r
oom temperature may be hotter than normal.
• Check if door does not close completely or is open too often.
• Check if door gasket does not seal properly.
• The temperature control is not set correctly.
Wine
Cooler light does not
work
• Ensur
e unit is properly plugged in.
• Check for a tripped circuit breaker or blown fuse.
• Check if the light switch is OFF.
Wine
Cooler makes too much
noise or vibrates
• Check
to ensure the unit is level.
• The rattling noise may come from the flow of refrigerant. This is
normal.
• As each cycle ends, you may hear gurgling sounds caused by the
flow of refrigerant in the unit. This is normal.
• Contraction and expansion of the inside walls may cause popping
and crackling noises.
Wine
Cooler door will not
close properly
• Check
to ensure the unit is level.
• The door was reversed and was not properly installed.
• The gasket is dirty.
• The shelves are out of position.
1
W W W . V I N O T E M P . C O M
18
Shipping/Delivery fees are the responsibility of the Purchaser. Seller is not responsible for the
carrier’s missed/Non delivery for any reason. Delivery is curbside. Optional upgrades in delivery
service is an additional fee. If upgraded delivery service cannot be performed properly, Purchaser
agrees to accept delivery curbside and the difference in upgraded cost will not be refunded. If item
with free shipping/freight is canceled in transit, a charge of 25% of the price of the unit/s plus freight
costs both ways will be charged. All damages must be noted at time of delivery on BOL and Seller
to be notified within 48 hours of delivery of such damage. Purchaser acknowledges if cancelation
is authorized by Seller, a 35% restocking fee and freight both ways will be charged. No cancelation
or refund on made-to- order products. If an order has been placed and production has not started,
cancellation fee of 15% of total amount will be charged. Cancelled orders paid by Credit Card will
have an additional fee of 3% deducted from the total refund. Once your order has shipped, the
shipping address cannot be changed. Refurbished units are sold as is. Purchaser assumes risks to
the quality and performance of goods and assumes the costs of all necessary service or repair not
covered herein.
(Box here for check mark) Accept Terms & Conditions
Vinotemp International Corp. (“Seller”) and the person or entity that acquires these goods from
Seller (“Purchaser”) hereby fully agrees to the following terms and conditions of the sale:
Shipping/Delivery fees are the responsibility of the Purchaser whether freight prepaid or freight
collect. Seller assumes responsibility for the goods sold to the Purchaser until the goods have
reached Purchaser’s delivery address (FOB Destination) and the delivery receipt is signed clear.
Seller is not responsible for the carrier’s late delivery, missed delivery, unpaved roads, remote
locations, stairs, elevators, narrow door openings and other such issues in attempting to fit or deliver
the goods into the Purchaser’s location. Delivery to remote locations may require additional fees.
Remote location may be defined at the discretion of the carrier as more or less than 50 miles from
the nearest major city. Purchaser assumes all responsibility for additional costs related to freight
such as access, measurement, installation, hookup, wiring, moving and storage of the goods, flight
of stairs, carrier’s inability to safely and/or adequately deliver, inability to use the building elevator to
lift the goods, narrow openings, along with any additional costs to deliver or redeliver the product
properly. Make sure to review access to the property and size of the product ordered. The
transportation of all goods is subject to the terms and conditions which the carrier imposes on
Purchaser. Installation is the responsibility of the Purchaser. If white glove delivery was ordered and
cannot be performed properly, or access is hindered in any way, Purchaser agrees to accept
delivery curbside (delivery service cannot be refunded). If Purchaser will-calls or pays for their own
freight responsibility transfers to the Purchaser when the Purchaser or Purchasers freight company
picks up the unit from Seller. Freight quoted are either curbside, threshold or white glove. Standard
white glove delivery is main floor, easy access and NO STAIRS, Doors, aligned feet attached (if
necessary) and removal of packaging, additional fees for additional requests. Each service has a
different rate and will require additional fees. If freight is not charged (Free Shipping or Freight
Included) and the order is cancelled after shipping, a freight charge of 25% of the cost of the unit,
Terms & Conditions
Cancellation or Fees Terms:
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
19
each direction will be charged. Item swap outs are arranged as curbside delivery and pickup unless
noted otherwise. There is no white glove service for returns. Approved returns must have original
and/or proper packaging. Swap-outs (Delivery and Pick up are at the same time) Original unit must
be packed and ready for carrier pick up at time of delivery of new unit. Packaging of old unit must
be adequate for shipping, not oversized or on a pallet if unit was not originally delivered on a pallet.
Carrier will not drop off new unit if the original unit is not ready. If the carrier has to make a second
attempt, customer will be subject to additional charges for the attempted delivery and for any
packaging issues. Deliveries include ONE attempt by the shipping company to deliver the product
to the consumer. If for any reason the customer is unavailable to accept the order and the product
is undeliverable under any circumstances, the customer will be responsible for any extra shipping
and handling charges. We are a manufacturer not a shipping company, deliveries are done by a 3rd
party service. Email us at [email protected] for a quote or any additional information. Freight
discussed is Continental USA (excluding Alaska, Puerto Rico, Hawaii), cost is additional please
email [email protected] for a quote.
If you use a service repair company without approval or parts not supplied by Vinotemp and your
unit under warranty fails to work, we will repair your item provided you ship your unit prepaid to and
from our facility in Henderson. Vinotemp is not responsible for install or removal costs or
unauthorized repairs. If the repair or unauthorized part damaged the unit, we will provide customer
a cost to repair that damage.
California Proposition 65 Warning: The products sold on this ecommerce website and to the public
may contain chemicals and other substances known to the State of California to cause cancer and
birth defects and other reproductive harm.
Totes made of vinyl, imitation leather, and/or leather material contain lead and/or other substances
that are known to the State of California to cause cancer, birth defects and other reproductive harm.
Microfiber “Plastic microfiber” means a small synthetic particle that is fibrous in shape, less than 5
millimeters in length, and is released into water through the regular washing of textiles made from
synthetic material.
Composite wood: May contain formaldehyde.
Galvanized metal and some of its constituents contain lead and/or other substances that are known
to the State of California to cause cancer, birth defects and other reproductive harm.
Products made of vinyl contain lead, Diethyl Hexyl Phthalate (DEHP), and/or other substances that
are known to the State of California to cause cancer, birth defects and other reproductive harm.
Acrylic may contain Acrylic Acid and/or other substances that are known to the State of California to
cause cancer, birth defects, and other reproductive harm.
Appliances may contain tin or lead in either the paint or the controllers, and/or other substances that
are known to the State of California to cause cancer, birth defects, and other reproductive harm.
Our barware items may contain plastic, acrylic, enamel, crystal, metal and/or other substances that
are known to the State of California to cause cancer, birth defects, and other reproductive harm.
Appliances may contain Tin, Lead or Nickel.
W W W . V I N O T E M P . C O M
20
Damage: All damages must be noted at time of delivery. If a bill is signed that there is no damage,
buyer accepts delivery as free and clear. Any claim for damages of the goods, when FOB
Destination, that incurred during shipment by the carrier are insured and handled directly with the
carrier by the Seller if noted on the receipt and notified within 48 hours of delivery. OPEN AND
INSPECT YOUR DELIVERY. When FOB Destination, if the item is damaged by the freight company,
and Purchaser cancels rather than accepts a replacement, the order can be cancelled by paying for
freight costs both ways and a 35% restocking fee for stocked items. No cancellation or refunds on
custom/made or made to order products. When shipped 3rd Party (FOB Warehouse), Purchaser
assumes all responsibility for delivery, payment of freight and freight claims for damages during
shipment. Manufacture defects will be handled directly with Seller, subject to the limited warranty
below.
Fees: All sales are final. Unless authorized in writing by the Seller, Purchaser may not return the
goods under any circumstance. If Seller agrees in writing to take back stocked goods, there will be
a restocking/service fee that is 35% of the purchase price of the goods and freight both ways
(product must be new, unused, and in original packaging). If Purchaser returns goods claiming that
the goods are defective and goods are found to be in working condition by the Seller, Purchaser is
liable for the cost of freight both ways plus and a service fee that is 35% of the purchase price of the
goods. Built to Order and Custom products are nonreturnable, nonrefundable. Purchaser must
notify Seller of nonconforming goods within 48 hours of receipt, after which time all goods are
deemed accepted by the Purchaser. If an order has been placed and production has not started,
cancellation of your order will be a 15% charge. If Purchaser tenders payment with a check that has
insufficient funds (NSF), a collection fee plus NSF fee of $50 will be added to the invoice, which
Purchaser agrees to pay promptly. If Purchaser puts a stop payment on a check or credit card for
any reason, Purchaser agrees to pay for all costs associated with the Seller’s collection or litigation
of such a claim, including, without limitation, general and special damages, court costs and
attorneys’ fees. Finance charges begin the date of invoice. Title to the goods reverts back to the
Seller in the case of nonpayment of goods or services. All fees and costs to retrieve the product,
cost of freight, legal costs, collection fees and court fees, credit card fees and interest rate of 18%
(annual rate) will be the responsibility of the Purchaser. In a credit card dispute, Purchaser assumes
and must immediately pay any “credit card arbitration” fees and chargeback fees which the credit
card companies charge at the time of the chargeback. Cancelled orders using a Credit Card will
have an additional fee of 3% deducted from the refund.
Any disputes not resolved within 30 days from the invoice date will be reported to credit reporting
agencies.
LIMITED WARRANTY: Seller warrants that the goods will be free of defects in materials and
workmanship as follows:
Furniture style (wood) wine cabinets made in the U.S.: all cooling unit parts only for a period of 1
(year) year; cabinetry and labor (uninstalled) for a period of 12 (twelve) Months (Model numbers
“Vino” and “Custom”.
Metal cabinet units (appliances) (compressor) (made in China and Denmark)(Model numbers start
with EL, VT, IL, or EP: parts and labor for cooling system and cabinetry for a period of 12 (twelve)
months.
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
21
Thermoelectric Units: 90 (ninety) days (including Wine and Beverage Coolers, Beer Dispensers,
Humidor, Portofino Wood Cellars, and Refrigerators). (Models start with EL, VT, IL or EP).
WineMate and Cellar Tec (WM, Wine Mate or CT)(Wine Cooling Units) Split and Ducted Systems
and other installed cooling units are parts only for 1 year, no labor. Self Contained WineMate
Cooling Systems are 1 year parts, 1 year labor. Removal and reinstallation of cooling units is not
included.
Wine Accessories, Racking Systems, Parts and Other miscellaneous items is a 30 day warranty.
Il Romanzo units: Warranty 90 (ninety) days. Replacement part 12 (twelve) months from the date of
sale.
Brama: 1 year warranty from date of purchase.
Non-New Units (Scratch & Dent/Refurbished/Floor Models), warranty for compressor units is 90
days from your dated invoice and 30 days for thermoelectric units (parts for function only, not
cosmetic defects). These units are refurbished and sold as is; Purchaser assumes risks to the
quality and performance of goods and assumes the costs of all necessary service or repair not
covered herein. Extended warranties via New Leaf may not be purchased on Non-New Units.
Delivery is curbside. Upgrades in delivery will require an additional fee.
Element Grills (via Element Products LLC), grills have a thirty day limited parts warranty on grill
accessories.
If a model is not listed here will have 90 day warranty on parts only if it’s a new item.
Parts and Repairs: Warranty on in-house repairs: 90 days parts and labor for compressor; 30 days
parts and labor for Thermoelectric; Customer is required to put down a labor deposit of $75 for
Thermoelectric units; $150 for compressor based Wine Coolers and $195 for WineMate units which
will be kept if a unit is found to be in good working condition. Customer is responsible for freight
costs to us.
Warranty on parts purchased: 30 days; if part fails within 30 days of purchase, customer is to ship
us back the part; upon inspection, if defective, VT will send replacement part at no charge.
If a purchaser claims a product is “defective” with regards to refrigeration, Purchaser must obtain a
letter from a qualified refrigeration technician at the Purchaser’s cost to verify that the unit was
installed properly, with proper ventilation and the unit is truly malfunctioning due to a manufacturing
defect.
Removal or reinstallation of a unit is not included in warranted costs. Purchaser’s exclusive remedy
is limited at Seller’s option to repair or replace defective part[s] with either new or reconditioned
part[s]. Purchaser is responsible for shipping the unit prepaid to a designated facility and Seller will
pay return shipping charges in the continental United States for items repaired under warranty
within 12 (twelve) months from date of sale. The returned unit must be packaged correctly, with
enough protection to ensure the unit is not further damaged. Oversized or lack of packaging is not
permitted and will be refused. Replacement or exchanged units will be returned to Purchaser
through curbside delivery only. Any redelivery fees are the Purchasers responsibility. Since the
natural variation in texture, density, grain, color, tone, and shade of wood is unavoidable; Seller
W W W . V I N O T E M P . C O M
22
does not guarantee the texture, color, tone, or shade of the wood: nor does seller guarantee the
colorfastness of wood or against peeling, chipping, cracking, or scratching. Note: Unfinished wood
is subject to warping; all wood surfaces must be sealed before placing cellar into service. Make sure
doors are aligned by reviewing the owner’s manual. Improper repair or placement of the unit will
void the warranty. Any third party repair facility must be preapproved in writing by Seller, before
providing replacement parts under warranty. Change Orders: Custom units already in production
that require a change will be subject to a change order fee.
Storage Fees: When having an item serviced by a Vinotemp service technician at the Vinotemp
facility, Purchaser agrees to pick up their repaired item or make arrangements for return shipping
within a 30 day period once they have been notified by Vinotemp through phone call, email, or letter
that their unit is ready for pick up. If the item remains in the Vinotemp warehouse after 30 days but
no longer than 60 days, the Purchaser will incur additional storage fees of 2%. After 60 days in
storage, the item will become property of Vinotemp. For custom units with deposits: If product is not
picked up or shipped within 60 days of completion, Purchaser deposit is forfeited and product
becomes the property of Vinotemp. Warranty period is from the date of sale (not from shipping,
delivery, nor installation). All completed cabinetry, racking, or other custom work must be picked up
or shipped within a period of 14 days after Vinotemp has notified the Purchaser by phone call, email,
or letter. Any completed cabinetry, racking, or other custom work stored longer than 14 days will
incur an additional monthly storage fee. After 60 days, the product will become property of
Vinotemp.
This Limited Warranty does not cover damage due to such things as accident, misuse, abuse,
mishandling, neglect, acts of God, fires, earthquakes, floods, high winds, government, war, riot or
labor trouble, strikes, lockouts, delay of carrier, unauthorized repair, or any other cause beyond the
control of the Seller, whether similar or dissimilar to the foregoing. Seller is not responsible for any
damages caused to Purchaser's property resulting from the goods. This limited warranty applies
only inside the Continental US (Alaska, Puerto Rico, Hawaii and other territories/countries are not
warranted). Purchaser understands and acknowledges that the goods sold here are wine cellars,
cigar humidors, and/or other similar units which house wine or cigars or other items. Purchaser
assumes all risk of using these units, including risk of spoilage, humidity variations, temperature
variations, leaks, fire, water damage, mold, mildew, dryness and similar and any other perils that
might occur. Seller is not responsible for incidental or consequential damages, and there are no
warranties, expressed or implied, which extend beyond the Limited Warranty described above.
Warranty and liability are nontransferable. The implied warranties of merchantability and of fitness
for a particular purpose are hereby expressly disclaimed. Some states do not allow the exclusion of
incidental or consequential damages, or a waiver of the implied warranties of fitness and/or
merchantability, so the above limitations may not apply to you. This warranty gives you specific legal
rights and you may also have other rights which vary from state to state. Seller disclaims any
indemnification for claims of infringement of any intellectual property of protectable nature. In the
event of any dispute between Seller and Purchaser arising out of or relating to these terms and
conditions or to the goods sold generally, Purchaser must first file a written claim with Seller within
ten days of the occurrence giving rise to the claim and wait an additional thirty days for a response
before initiating any legal action. The sale and all terms are subject to Nevada law. Any legal
proceeding arising out of or relating to these terms and conditions or to the goods sold Purchaser
shall bring, solely and exclusively in Clark County. In no event may Purchaser initiate any legal
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
23
proceeding more than six months after the occurrence of the event giving rise to the dispute. Seller
may make nonpayment claims until debt is paid in full. Any dispute or claim relating in any way to
these to the Terms and Conditions, the Website, or any products or services sold or distributed by
or through this Website, store, or catalog will be resolved by binding arbitration, rather than in court,
except that you may assert claims in small claims court if your claims qualify. The Federal Arbitration
Act and federal arbitration law apply to the Terms and Conditions. We each agree that any dispute
resolution proceedings will be conducted only on an individual basis and not in a class, consolidated
or representative action. If for any reason a claim proceeds in court rather than in arbitration we
each waive any right to a jury trial. Both parties agree to bring suit in court to enjoin infringement or
other misuse of intellectual property rights.
The above terms and conditions are the only ones governing this transaction and Seller makes no
oral representations of any kind. These Terms and Conditions can only be modified in writing,
signed by both Purchaser and Seller.
SPECIFIC WARRANTY BELOW for SCRATCH & DENT/OPEN BOX/ REFURBISHED/FLOOR
MODELS/ CLOSEOUTS, OVERSTOCK: TERMS AND CONDITIONS OF SALE
Vinotemp (and its brands Element, Wine Mate, Cellar Tec, Apex Wine Racks, Epicureanist Il
Romanzo, Brama(“Seller”) and the person of the entity that acquires these goods from Seller
(“Purchaser”) hereby fully aggress to the following terms and conditions of the sale:
1. Freight: Vinotemp is not a freight, moving or installation company, if Freight is arranged for the
Buyer, the Seller assumes no responsibility for the goods sold to the Purchaser once the goods
have left the Seller’s premises, including, but not limited to, late delivery by the moving carrier, or for
events caused by any difficulty carrier incurs in attempting to fit the goods into the Purchaser’s place
of business or residence due to the size of the goods or otherwise, such as the disassembly and
reassembly of the goods. Purchaser assumes all responsibility for delivery, payment of freight, extra
fees, access, measurement, installation, hook-up, moving and storage of the goods. The
transportation of all goods is subject to the terms and conditions which the moving carrier imposes
on Purchaser including, but not limited to, additional charges imposed per flight of stairs, and/or
additional charges resulting from the carrier’s inability to safely and/or adequately use the building
elevator to lift the goods to an upper floor. Any claim for damages incurred during shipment by the
carrier of the goods are insured and handled directly with the carrier and must be noted at time of
delivery.
2. All sales are final, and unless authorized in writing by the Seller, Purchaser is not entitled to return
goods, under any circumstances. If Purchaser refuses to accept goods, the Purchaser is liable for
the return and cost of freight both directions and a restocking/service fee that is 35% of the purchase
price of the goods. Purchaser must notify Seller of non-conforming goods within four days of
delivery, after which time all goods are deemed accepted.
W W W . V I N O T E M P . C O M
24
3. If Purchaser tenders payment with a check that has insufficient funds (NSF), or stops payment on
a check or credit card for any reason, Purchaser agrees to pay for all costs associated with the
Seller’s connection or litigation of such a claim, including without limitation extra damages, court
costs, collection fees and attorney’s fees. Finance charges begin the date of invoice. Collection fees
plus NSF fee of $50 will be added to your invoice, which you agree to promptly pay. Title to the
goods does not pass until payment is received in full by Seller and Seller retains a security interest
in the goods until they are paid for in full. If the credit card dispute goes to arbitration, Buyer agrees
to pay for credit card arbitration fees.
4. LIMITED WARRANTY on Non-New Units (Scratch & Dent/Refurbished and Floor Models):
warranty for compressor units is 90 days from your dated invoice and 30 days for thermoelectric
units (parts for function only, not cosmetic defects). These units are refurbished and sold as is;
Purchaser assumes risks to the quality and performance of goods and assumes the costs of all
necessary service or repair not covered herein. Wine Accessories, Racking Systems and other
items not mentioned are not warranted. There is no warranty on parts purchased separately.
Removal and re-installation of unit is not included in warranted labor. Purchaser’s exclusive remedy
is limited, at Seller’s option; to repair or replace defective part[s] with either new or factory
reconditioned part[s]. Purchaser is responsible for shipping the unit pre-paid to designated facility
and Seller will pay return shipping charges in the continental United States for items repaired under
warranty. Since the natural variation in texture, density, grain, color, tone and shade of wood is
unavoidable; Seller does not guarantee the texture, color, tone or shade of the wood: nor does seller
guarantee the colorfastness of wood or against peeling, chipping, cracking or scratching. Note:
Unfinished wood is subject to warping; all wood surfaces must be sealed before placing cellar into
service. Improper placement of the unit will void the warranty. By Vinotemp in writing, any 3rd party
repair facility must be pre-approved before providing parts free of charge.
5. Freight: If As-Is unit is shipped including freight and delivery is denied, customer is responsible
for freight to and from buyer. Other costs Buyer is responsible for is storage, repackaging, and
attempted delivery fees.
6. Vinotemp does not cover damage due to such things as accident, misuse, abuse, mishandling,
neglect, acts of God, fires, earthquakes, floods, high winds, government, war, riot or labor trouble,
strikes, lockouts, delay of carrier, unauthorized repair, or any other cause beyond the control of the
Seller, whether similar or dissimilar to the foregoing. Seller is not responsible for any damages
caused to Purchaser's property resulting from the good. This limited warranty applies only inside the
Continental US. (Alaska, Puerto Rico and Hawaii are not warranted.)
7. Purchaser understands and acknowledges that the goods sold here are wine coolers, appliances,
cigar humidors, and/or other similar units which may house wine or cigars or other consumables.
Purchaser assumes all risk of using these units, including risk of spoilage, humidity variations,
temperature variations, leaks, fire, water damage, mold, mildew, dryness and similar perils that
might occur.
732 South Racetrack Road, Henderson, Nevada 89015
i n f o @ v i not e m p . c o m
25
8. UNLESS OTHERWISE PROVIDED BY APPLICABLE LAW, SELLER IS NOT RESPONSIBLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES, AND THERE ARE NO WARRANTIES,
EXPRESS OR IMPLIED, WHICH EXTEND BEYOND THE DESCRIPTION ON THE FACE
HEREOF; WARRANTY AND LIABILITY ARE NON-TRANSFERABLE. THE IMPLIED
WARRANTIES OF MERCHANTABILITY AND OF FITNESS FOR A PARTICULAR PURPOSE ARE
HEREBY EXPRESSLY DISCLAIMED. SELLER DISCLAIMS ANY INDEMNIFICATION FOR
CLAIMS OF INFRINGEMENT OF ANY INTELLECTUAL PROPERTY OF PROTECTABLE
NATURE.
9. In the event of any dispute between Seller and Purchaser arising out of or relating to these terms
and conditions or to the goods sold generally, Purchaser must first file a written claim with Seller
within thirty days of the occurrence giving arise to the claim and wait an additional thirty days for a
response before initiating any legal action. Any legal proceeding arising out of or relating to these
terms and conditions or to the goods sold generally shall be brought solely in Clark County. The
prevailing party in any such proceeding is entitled to its attorney’s fees and costs. In no event may
Purchaser initiate any legal proceeding more than six months after the occurrence of the event
giving rise to the dispute.
10. Delivery is curbside. Upgrades in delivery will require an additional fee.
The above terms and conditions are the only ones governing this transaction and Seller makes no
oral representations of any kind. These Terms and Conditions can only be modified in writing,
signed by both Purchaser and Seller. 09/30/2020
W W W . V I N O T E M P . C O M
26
SERVICE & IMPORTANT NOTICE
Upon receipt and inspection of unit, the supply cord must be replaced if it is damaged.
Contact our customer service at 1-800-777-8466 or info@vinotemp.com.
The manufacturer has a policy of continuous improvement on its products and
reserves the right to change materials and specifications without notice.
WARNING:
Please do not place the unit within reach of children.
For adult use only.
Contact info@vinotemp.com with any questions or visit
www.vinotemp.com
732 S. Racetrack Road
Henderson, NV 89015
www.vinotemp.com
Vinotemp is a registered trademark of Vinotemp International. All products, features, and services are subject to
change without notice. We cannot guarantee the accuracy of the contents of this document. We disclaim liability for
errors, omissions, or future changes.
© 2020 Vinotemp International. All rights reserved.
