318203684 rev. D (01/16)

EN GAS COOKTOP USE AND CARE GUIDE

Finding Information

Thank you for choosing Electrolux, the new

premium brand in home appliances. This Use &

Care Guide is part of our commitment to customer

satisfaction and product quality throughout the

service life of your new appliance.

We view your purchase as the beginning of a

relationship. To ensure our ability to continue

serving you, please use this page to record

important product information.

Keep a record for quick

reference

Please read & save this guide

Questions?

For toll-free telephone support in the U.S. and

Canada:

1-877-4ELECTROLUX (1-877-435-3287)

For online support and Internet production information

visit http://www.electroluxappliances.com

Purchase date

Electrolux model number

Electrolux serial number

Table of contents

Finding information .................................................... 2

Safety .......................................................................3-5

Getting Started .........................................................5-6

• GroundingInstructions ..........................................5

• LiqueedPetroleum(Propane)GasConversion ... 6

Surface Cooking ......................................................6-9

• FlameSize .............................................................6

• ProperBurnerAdjustments ...................................6

• LocationsoftheBurners ........................................7

• PlacementofBurnerCaps ....................................8

• SurfaceCookingUtensils ......................................9

• SettingSurfaceControls ......................................10

General Care and cleaning .................................11-12

Care and Cleaning Table ............................................ 11

• CareandCleaningofStainlessSteel .................. 12

• CleaningtheCooktop,Grates,Capsand

 BurnerHeads .................................................11-12

Solutions to common problems ..............................13

• SurfaceBurnerDoNotLight ...............................13

• BurnerFlameOnlyLightsHalf

 WayAroundBurner ............................................13

• BurnerFlameisOrange ......................................13

Notes..........................................................................14

Warranty information ...............................................15

NOTE

Registering your product with Electrolux enhances

our ability to serve you. You can register online at

www.electroluxappliances.com or by dropping

your Product Registration Card in the mail.

• Removealltapeandpackagingwrap

before using the appliance. Destroy the

carton and plastic bags after unpacking

the appliance.Neverallowchildrentoplay

withpackagingmaterial.Donotremovethe

model/serial plate attached to the cooktop.

• ProperInstallation-Besureyourappliance

is properly installed and grounded by a

qualiedtechnicianinaccordancewiththe

National Fuel Gas Code ANSI Z223.1—latest

edition in the United States, or in Canada

CAN/CGA B149.1, and CAN/CGA B149.2,

and the National Electrical Code ANSI/

NFPA No. 70—latest edition in United

States, or in Canada CSA Standard C22.1,

Canadian Electrical Code, Part 1, and local

code requirements. Installand/oradjustonly

per installation instructions provided in the

literature package for this cooktop.

What you need to know about safety instructions

Warning and Important Instructions appearing in this guide are not meant to cover all possible conditions

and situations that may occur. Common sense, caution and care must be exercised when installing,

maintaining or operating a microwave.

ALWAYS contact your dealer, distributor, service agent or manufacturer about problems or conditions

you do not understand.

Recognize Safety Symbols, Words, Labels

WARNING—Hazardsorunsafepracticeswhich

COULDresultinseverepersonalinjuryordeath.

Iftheinformationinthismanualisnotfollowedexactly,areorexplosionmayresultcausing

property damage, personal injury or death.

FOR YOUR SAFETY:

— Donotstoreorusegasolineorotherammablevaporsandliquidsinthevicinityofthisorany

other appliance.

— WHAT TO DO IF YOU SMELL GAS:

• Donottrytolightanyappliance.

• Donottouchanyelectricalswitch;donotuseanyphoneinyourbuilding.

• Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s

instructions.

• Ifyoucannotreachyourgassupplier,calltheredepartment.

— Installation and service must be performed by a qualied installer, servicer or the gas

supplier.

CAUTION—Hazardsorunsafepracticeswhich

COULDresultinminorpersonalinjury.

Important Safety Instructions

Ask your dealer to recommend a qualied

technician and an authorized repair service.

Know how to shut off gas supply at the meter and

disconnect the electrical power to the cooktop

at the circuit breaker or fuse box in case of an

emergency.

•User servicing—Do not repair or replace

anypartoftheapplianceunlessspecically

recommended in the manuals. All other

servicing should be done only by a qualied

technician, This may reduce the risk of personal

injuryanddamagetothecooktop.

•Nevermodifyoraltertheconstructionofa

cooktop by removing panels, wire covers

or any other part of the product.

• Air curtain or other overhead hoods, which

operatebyblowingadownwardairowonto

arange,shallnotbeusedinconjunctionwith

gas ranges other than when the hood and

range have been designed, tested and listed

by an independent test laboratory for use in

combination with each other.

• Stepping,leaningorsittingonthiscooktop

can result in serious injuries and also cause

damage to the cooktop. Do not allow children

to climb or play around the cooktop.

• NEVER use this appliance as a space heater

to heat or warm the room. Doingsomayresult

in carbon monoxide poisoning and overheating

of the oven.

•Use Proper Flame Size—Adjust ame size so it does

not extend beyond the edge of the utensil. The use of

undersized utensils will expose a portion of the burner ame

to direct contact and may result in ignition of clothing. Proper

relationship of utensil to ame will also improve efciency.

•Do Not Use Stove Top Grills on Your Sealed Gas Burners—

If you use a stove top grill on a sealed gas burner, it will cause

incomplete combustion and can result in exposure to carbon

monoxide levels above allowable current standards. This can

be hazardous to your health.

•Use proper pan size. This cooktop can be equipped with

one or more surface units of different sizes. Select utensils

having at bottoms large enough to cover the surface unit.

The use of undersized utensils will expose a portion of the

surface heating unit to direct contact and may result in ignition

of clothing. Proper relationship of utensil to the surface unit

will also improve efciency

•StorageonAppliance—Flammablematerials

should not be stored on the cooktop or near

surface units. This includes paper, plastic and

cloth items, such as cookbooks, plasticware

andtowels,aswellasammableliquids.Do

not store explosives, such as aerosol cans, on

or near the cooktop. Flammable materials may

explodeandresultinreorpropertydamage.

•Do Not Leave Children Alone—Children

should not be left alone or unattended in the

area where appliance is in use. They should

never be allowed to sit or stand on any part of

the appliance.

Do not store items of interest to children in the

cabinets above the cooktop. Children climbing

on the cooktop to reach items could be seriously

injured.

•DO NOT TOUCH SURFACE BURNERS/

UNIT, GRATES OR AREAS NEAR THESE

BURNERS/UNIT. Surface burners/unit may be

hoteventhoughamesarenotvisible/unitis

dark in color. Areas near surface burners/unit

maybecomehotenoughtocauseburns.During

and after use, do not touch, or let clothing or

otherammablematerialstouchtheseareas

untiltheyhavehadsufcienttimetocool.Among

these areas are the cooktop and surfaces facing

the cooktop.

•Wear Proper Apparel—Loose-fitting or

hanging garments should never be worn

while using the appliance. Donotletclothing

or other flammable materials contact hot

surfaces.

•Do Not Use Water or Flour on Grease

Fires—Smothertherewithapanlid,oruse

baking soda, a dry chemical or foam-type

extinguisher.

•Whenheatingfatorgrease,watchitclosely.

Fatorgreasemaycatchreifallowedtobecome

too hot.

•Use Only Dry Potholders—Moist ordamp

potholders on hot surfaces may result in

burns from steam.Donotletpotholderstouch

hotheatingelements,theameorburners.Do

not use a towel or other bulky cloth instead of

a potholder.

•DoNotHeatUnopenedFoodContainers—

Buildupofpressuremaycausecontainer

to burst and result in injury.

•Know which knob controls each surface

burner.AlwaysturntheknobtotheLITEposition

when igniting the burners. Visually check that the

burnerhaslit.Thenadjusttheamesoitdoes

not extend beyond the edge of the utensil.

•Clean the appliance regularly to keep all

parts free of grease that could catch re.

Exhaustfanventilationhoodsandgreaselters

shouldbekeptclean.Donotallowgreaseto

accumulateonhoodorlter.Greasydeposits

inthefancouldcatchre.Whenamingfood

under the hood, turn fan on. Refer to hood

manufacturer’s instructions for cleaning.

Important Safety Instructions

This appliance is equipped with a 3-prong grounding plug for your protection against shock hazard and should be plugged

directly into a properly grounded receptacle. DO NOT cut or remove the grounding prong from this plug.

Avoid re hazard or electrical shock. DO NOT use an adapter plug, an extension cord, or remove grounding prong from

electrical power cord. Failure to follow this warning can cause serious injury, re or death.

•UtensilHandlesShouldBeTurnedInward

and Not Extend Over Adjacent Surface

Burners/Unit —To reduce the risk of burns,

ignition of ammable materials, and spillage

due to unintentional contact with the utensil,

the handle of the utensil should be positioned

so that it is turned inward, and does not extend

overadjacentsurfaceburners.

•NeverLeaveSurfaceBurners/UnitUnattended

at High Heat Settings—Boilovers cause

smoking and greasy spillovers that may ignite,

or a pan that has boiled dry may melt.

•ProtectiveLiners—Donotusealuminumfoil

to line any part of the cooktop, use aluminum

foil only to cover food during cooking. Improper

installation of these liners may result in risk of

electricshock,orre.

•GlazedCookingUtensils—Onlycertaintypes

of glass, glass/ceramic, ceramic, earthenware,

or other glazed utensils are suitable for

cooktop service without breaking due to the

sudden change in temperature. Check the

manufacturer’s recommendations for cooktop

use.

•Do Not Use Decorative Surface Burner

Covers. If a burner/unit is accidentally turned

on, the decorative cover will become hot and

possibly melt. You will not be able to see that the

burnerison.Burnswilloccurifthehotcovers

aretouched.Damagemayalsobedonetothe

cooktop or burners because the covers may

cause overheating. Air will blocked from the

burner/unit and cause combustion problems.

NOTE

Save these important safety instructions for future

reference.

Important safety notice

The California Safe Drinking Water and Toxic

EnforcementActrequirestheGovernorofCalifornia

to publish a list of substances known to the state to

cause cancer, birth defects or other reproductive

harm, and requires businesses to warn customers

of potential exposure to such substances.

Important Safety Instructions

Getting Started

Do not, under any

circumstances, cut,

remove, or bypass

the grounding

prong.

Power supply

cord with 3-prong

grounding plug

Grounding

type wall

receptacle

Grounding Instructions

For personal safety, the cooktop must be properly

grounded. For maximum safety, the power cord

must be plugged into an electrical outlet that is

correctlypolarizedandproperlygrounded.

DO NOT operate the cooktop using a 2-prong

adapter or an extension cord. If a 2-prong wall

receptacle is the only available outlet, it is the

personal responsibility of the consumer to have

it replaced with a properly grounded 3-prong wall

receptacleinstalledbyaqualiedelectrician.

See the INSTALLATION INSTRUCTIONS

packaged with this cooktop for complete installation

and grounding instructions.

For most cooking, start on the highest control

setting and then turn to a lower one to complete

the process. Use the chart below as a guide for

determiningproperamesizeforvarioustypes

ofcooking.Thesizeandtypeofutensilusedand

theamountoffoodbeingcookedwillinuencethe

setting needed for cooking.

For deep fat frying, useathermometerandadjust

the surface control knob accordingly. If the fat is too

cool, the food will absorb the fat and be greasy. If

the fat is too hot, the food will brown so quickly that

thecenterwillbeundercooked.Donotattemptto

deep fat fry too much food at once as the food will

neither brown nor cook properly.

The colorof the ame isthekey to properburner

adjustment.Agoodameis clear,blueandhardly

visible in a well-lighted room. Each cone of ame

shouldbesteadyandsharplydened.Adjustorclean

burnerifameisyellow-orange.Tocleanburner,see

instructions under General Care & Cleaning.

RIGH

WRON

Getting Started

LiqueedPetroleum

(Propane) Gas Conversion

ThisappliancecanbeusedwithNaturalGasand

PropaneGas.Itisshippedfromthefactoryforuse

with natural gas.

AkitforconvertingtoLPgasissuppliedwithyour

cooktop.Thekitismarked“FORLP/PROPANE

GASCONVERSION”.Followtheinstallation

instructions which are inside the envelope.

Theconversionmustbeperformedbyaqualied

service technician in accordance with the kit

instructions and all local codes and requirements.

Failure to follow instructions could result in serious

injuryorpropertydamage.Thequaliedagency

performing this work assumes responsibility for the

conversion.

Severe shock, or damage to the cooktop may occur if the

cooktop is not installed by a qualied installer or electrician.

Any additions, changes or conversions required in order for this

appliance to satisfactorily meet the application needs must be

made by a qualied service technician in accordance with the

manufacturer’s instructions and all codes and requirements of

the authority having jurisdiction. Failure to follow the instructions

could result in serious injury or property damage. The qualied

agency performing this work assumes responsibility for the

conversion.

Surface Cooking

Flame Size

ProperBurnerAdjustments

*These settings are based on using medium-

weight aluminum pans with lids. Settings may

vary when using other types of pans.

Neverextendtheamebeyondtheouteredgeof

theutensil.Ahigheramesimplywastesheatand

energy, and increases your risk of being burned by

theame.

*Flame Size Type of Cooking

High Flame

Start most foods; bring water

to a boil; pan broiling

Medium Flame

Maintain a slow boil; thicken

sauces, gravies; steam

LowFlame

Keep foods cooking; poach;

stew

The30”cooktop(modelA)isequippedwith

differentsizedburners.

The surface burners are located on the cooktop as

follows:

- a 5000BTU(naturalgas)burnerlocatedatthe

right rear position;

- a 9500BTU(naturalgas)burnerlocatedatthe

left front position;

- a 14000BTU(naturalgas)burnerlocatedatthe

right front position;

- a 20000BTU(naturalgas)burnerlocatedatthe

left rear position;

Surface Cooking

LocationoftheBurners

OFF

OFF OFF

OFF

30" cooktop - Model A

30"cooktop-ModelB

36" cooktop

The 36”cooktopisequippedwithdifferentsized

burners.

The surface burners are located on the cooktop as

follows:

- a 5000BTU(naturalgas)burnerlocatedatthe

right rear position;

- two 9500BTU(naturalgas)burnerslocatedat

the left front and left rear positions;

- a 14000BTU(naturalgas)burnerlocatedatthe

right front position;

- and a 20000BTU(naturalgas)burnerlocated

at the center rear position.

The30”cooktop(modelB)isequippedwith

differentsizedburners.

The surface burners are located on the cooktop as

follows(SeeFigure):

- a 5000BTU(naturalgas)burnerlocatedatthe

right rear position;

- a 20000BTU(naturalgas)burnerlocatedat

the center rear position;

- a 9500BTU(naturalgas)burnerslocatedatthe

left front position;

- a 7500BTU(naturalgas)burnerslocatedatthe

left rear position;

- and a 12000BTU(naturalgas)burnerlocated

at the right front position.

OFF

OFF OFF

OFFOFF

Surface Cooking

Place a burner cap on each burner head, matching

thecapsizetotheheadsize.Thecapforeach

burner has an inner locating ring which centers

thecapcorrectlyontheburnerhead.Besurethat

all the burner caps and burner heads are correctly

placedBEFOREusingyourappliance.

Make sure each burner cap is properly aligned and

level.

Turn the burner on to determine if it will light. If the

burnerdoesnotlight,contactaServiceCenter.Do

not service the sealed burner yourself.

ATTENTION:Donotslidetheburnercapsonthe

cooktop, doing so can damage the surface.

Placement of burner caps

BurnerRing

Alignment Tab

BurnerCap

BurnerRing

BurnerBase

Simmer Head

BurnerBase

Alignment Tab Slot

BurnerCap

BurnerHead

CorrectBurnerCap

Placement

IncorrectBurnerCap

Placement

BurnerCapLip

IMPORTANT

For Proper Ignition: Burner Ring

AlignmentTabMustAlignwithBurner

BaseAlignmentTabSlot

Surface cooking utensils

Note: Always use a utensil for its intended purpose. Follow manufacturer’s instructions. Some utensils

were not made to be used in the oven or on the cooktop.

*GOOD

• Flatbottom and

straight sides.

• Tightttinglids.

• Weightofhandle

does not tilt pan. Pan

is well balanced.

• Pansizesmatchthe

amount of food to be

preparedandthesize

of burner.

• Madeofmaterialthat

conducts heat well.

• Easytoclean.

POOR

• Curvedandwarpedpan

bottoms.

• Panoverhangsunitbymore

than2.5cm(1”).

• Heavyhandletiltspan.

• Flameextendsbeyondunit.

Pansshouldhaveatbottoms.Check

foratnessbyrotatingaruleracross

the bottom. There should be no gaps

between the pan and ruler.

* Specialty pans such as lobster pots,

griddles and pressure cookers may be

used but must conform to the above

recommended cookware requirements.

Surface Cooking

Setting surface controls

Your cooktop may be equipped with any

combination of the following burners:

SimmerBurner:bestusedforsimmeringdelicate

sauces, etc.

StandardBurner:usedformostallsurfacecooking

needs.

LargeBurner:bestusedwhenbringinglarge

quantities of liquid to temperature and when

preparing larger quantities of food.

Regardlessofsize,alwaysselectautensil

that is suitable for the amount and type of food

beingprepared.Selectaburnerandamesize

appropriatetothepan.Neverallowamesto

extend beyond the outer edge of the pan.

The valves provide enhanced control of the burner

ame.Eachburner

lights automatically

from an electric ignitor

when its control knob

is pushed.

Do not place plastic items such as salt and

pepper shakers, spoon holders or plastic

wrappings on top of the cooktop when it is in

use. These items could melt or ignite. Potholders,

towelsor woodspoons couldcatchreifplaced

tooclosetoaame.

To operate the surface burner:

1. Place cooking utensil on burner.

2. Push in and turn the Surface Control knob to the

symbol .

Note: All electronic ignitors will click at the same time

when the knob is pushed in. However, only the burner

you are turning on will ignite.

3. Visually check that the burner has lit.

4. Turnthecontrolknobtothedesiredamesize.

The control knobs do not have to be set at a

particularmark.Usetheguidesandadjustthe

ameasneeded.

In the event of an electrical power outage, the

surface burners can be lit manually. To light a

surface burner, hold a lit match to the burner head,

then slowly turn the Surface Control knob to light

position. Use caution when lighting surface burners

manually.

Care and Cleaning

Cleaning Recommendations

Surface Type Cleaning Recommendation

• Painted and Plastic

Control Knobs

For general cleaning, use hot, soapy water and a cloth. For more difcult

soils and built-up grease,applyaliquiddetergentdirectlyontothesoil.Leave

on soil for 30 to 60 minutes. Rinse with a damp cloth and dry. DO NOT

use abrasive cleaners on any of these materials; they can scratch.

• Porcelain Enamel

• BurnerGrates,BurnerCaps

Clean burner grates in the dishwasher and dry upon removal.

Gentlescouringwithasoapyscouringpadwillremovemostspots.Rinse

with a 1:1 solution of clean water and ammonia. If necessary,coverdifcult

spots with an ammonia-soaked paper towel for 30 to 40 minutes. Rinse

withcleanwaterandadampcloth,thenscrubwithasoap-lledscouring

pad. Rinse and wipe dry with a clean cloth. Remove all cleaners or the

porcelain may become damaged during future heating. DO NOT use

spray oven cleaners on the cooktop.

• SurfaceBurners The holes in the burners of your cooktop must be kept clean at all times

forproperignitionandacomplete,evename. Clean the burner holes

routinely with a small gauge wire or needle and especially after bad

spillovers which could clog these holes.

To remove, clean and replace sealed burner units; follow the instructions

inGeneralCare&CleaningsectionunderCleaningBurners,Grates

and Trivets. For stubborn stains, scrub with soap and water or a mild

abrasivecleanseranddampcloth.Drytheburnersthoroughlyinawarm

oven for 30 minutes. Then replace them, making sure they are seated

and level. DO NOT put burner units in the dishwasher.

• Stainless Steel Clean stainless steel with hot, soapy water and a dishcloth. Rinse with

clean water and a cloth. Do not use cleaners with high concentrations

of chlorides or chlorines.Donotuseharshscrubbingcleaners.Only

use kitchen cleaners that are especially made for cleaning stainless steel.

Always be sure to rinse the cleaners from the surface as bluish stains

may occur during heating that cannot be removed.

Care and cleaning of stainless steel

Care and cleaning table

Do not remove any parts from the cooktop until they

have completely cooled and are safe to handle.

IMPORTANT

Do not use spray oven cleaners on the cooktop.

Special care and cleaning are required for maintaining the appearance of stainless parts. Please refer to

the table provided at the beginning of the General Care & CleaningsectioninthisUse&CareManual.

The cooktop is designed to make cleaning easier.

Becausethegasburneraresealed,cleanupsare

easy when spillovers are cleaned up immediately.

Cleaning cooktop, grates, caps and burner heads

Cleaning the cooktop

If a spill occurs on or in the recessed or countered

areas, blot up spill with an absorbent cloth. Rinse

withaclean,dampclothandwipedry.Donotuse

harsh abrasive cleaners on the cooktop. They can

scratch the porcelain. Completely rinse any mild

cleaners used from the surface or the porcelain

cooktop may become damaged during future

heating.

Care and Cleaning

Your appliance is shipped with the burner heads

andburnercapsinthecorrectlocations.Before

using your gas appliance be sure to:

●Followinstallationinstructionsbeforeoperating.

●Removeallpackingtapefromcooktoparea.

Cleaning cooktop, grates, caps and burner heads

Cleaning the grates

The burner grates are dishwasher safe and may be

cleaned in the dishwasher. Remove any excessive

soils before placing in the dishwasher.

IMPORTANT

●Forpropergasowandignitionoftheburners

— DO NOT allow spills, food, cleaning

agents or any other material to enter the gas

oriceopening.

●Thecooktopisnotremovable.Donotattempt

to remove or lift the cooktop.

IMPORTANT

When placing the burner caps on the cooktop, be

sure the burner caps are seated firmly on top of

burnerheads.Improperflamesizeanduneven

heating may result when any surface burners are

turnedONandtheburnercapsarenotseated

correctly.

●To avoid possible burns use care when

cleaning the cooktop. DO NOT attempt to clean

the cooktop whenever the cooktop or burner

heads are still hot.

●To avoid possible burns DO NOT attempt any

of the following cleaning instructions provided

beforeturningOFFallofthesurfaceburners

and allow them to cool.

●To avoid possible burns DO NOT attempt to

operate the surface burners without the burner

caps.

Caps

Should you ever need to remove the burner caps

for cleaning lift the burner cap off the burner

head. Clean heavy soils with an absorbent cloth.

Rinse with a clean, damp cloth and immediately

thoroughly dry including the bottom and inside

ofthecap.Donotuseharshabrasivecleaners.

Theycanscratchtheporcelainonthecap.Donot

clean burner caps in dishwasher. When placing the

burner caps, see Important note below.

Burnerheads

Lifttheburnercapfromtheburnerhead.The

surface burner heads are secured to the cooktop

and must be cleaned in place.

Forpropergasowitmaybenecessarytoclean

theburnerheadsandslots.Toclean,rstusea

cleanDAMPclothtosoakupanyspills.Remove

any food from between the burner slots using a

small nonabrasive brush like a toothbrush and

afterwards wipe using a damp cloth. For stubborn

soils located in the slots, use a small-gauge wire or

needle to clean.

Should you experience ignition problems it may be

that an ignition port hole is partially blocked with

soil(seegurebelow).Withtheburnerheadin

place, use a small wire gauge needle or the end of

a paper clip to clear the ignition port or ports.

Slots

Ignition port

Oriceport

Solutions to common problems

Before you call for service,reviewthefollowinglist.Itmaysaveyoutime&expense.Thelistincludes

common occurrences that are not the result of defective workmanship or materials in this appliance.

Questions or for service call: 1-877-4ELECTROLUX (1-877-435-3287)

Beforeyoucall

Problem Solution

Surface burners

do not light.

• Surfacecontrolknobhasnotbeencompletelyturnedto

position. Turn the

Surface Control knob to and push in and until burner ignites and then turn

controlknobtodesiredamesize.

• Besuregassupplyvalveisopen.

• Burnerportsareclogged.Cleanburner.SeeCleaningtheburnergrates,burner

caps,burnerheadsingeneralcare&Cleaningsection.Withtheburneroff,

clean ports with a small-gauge wire or needle.

• Powercordisdisconnectedfromoutlet(Electricignitionmodelsonly).Besure

cord is securely plugged into the outlet.

• Electricalpoweroutage(electricignitionmodelsonly).Burnerscanbelit

manually.SeeSettingSurfaceControlsinthisUseandCareGuide.

Burnerameonly

lights half way

around burner

• Burnerportsareclogged.Withtheburneroff,cleanportsbyusingasmall-

gauge wire and needle.

• Moistureispresentaftercleaning.Lightlyfantheameandallowburnertooperate

untilameisfull.DrytheburnersthoroughlyfollowinginstructionsintheGeneral

Cleaning section.

Burnerameis

orange

• Dustparticlesinmainline.Allowtheburnertooperateafewminutesuntilame

turns blue.

• Incoastalareas,aslightlyorangeameisunavoidableduetosaltair.

Notes

Warranty

Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will

repair or replace any parts of this appliance that prove to be defective in materials or workmanship when such appliance is

installed, used, and maintained in accordance with the provided instructions. In addition, the glass cooktop or radiant surface

elementofyourappliance(excludingbuilt-inandfree-standingrangeappliances)iscoveredbyatwothroughveyear

limitedwarranty.Duringthe2ndthrough5thyearsfromyouroriginaldateofpurchase,Electroluxwillprovideareplacement

glass cooktop or radiant surface element for your appliance which has proven to be defective in materials or workmanship

when such appliance is installed, used, and maintained in accordance with the provided instructions.

Exclusions

This warranty does not cover the following:

1. Products with original serial numbers that have been removed, altered or cannot be readily determined.

2. Product that has been transferred from its original owner to another party or removed outside the USA or Canada.

3. Rust on the interior or exterior of the unit.

4. Productspurchased“as-is”arenotcoveredbythiswarranty.

5. Products used in a commercial setting.

6. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances not in

ordinary household use or used other than in accordance with the provided instructions.

7. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.

8. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc.,

which are not a part of the appliance when it is shipped from the factory.

9. Servicecallstorepairorreplaceappliancelightbulbs,airlters,waterlters,otherconsumables,orknobs,

handles, or other cosmetic parts.

10. Labororin-homeservicecostsduringtheadditionallimitedwarrantyperiodsbeyondtherstyearfromyour

original date of purchase.

11. Pickup and delivery costs; your appliance is designed to be repaired in the home.

12. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry trip charges,

or mileage expense for service calls to remote areas, including the state of Alaska.

13. Damagestothenishofapplianceorhomeincurredduringtransportationorinstallation,includingbutnotlimited

tooors,cabinets,walls,etc.

14. Damagescausedby:servicesperformedbyunauthorizedservicecompanies;useofpartsotherthangenuine

Electroluxpartsorpartsobtainedfrompersonsotherthanauthorizedservicecompanies;orexternalcausessuch

asabuse,misuse,inadequatepowersupply,accidents,res,oractsofGod.

DISCLAIMEROFIMPLIEDWARRANTIES;LIMITATIONOFREMEDIES

CUSTOMER’SSOLEANDEXCLUSIVEREMEDYUNDERTHISLIMITEDWARRANTYSHALLBEREPAIRORREPLACEMENT

ASPROVIDEDHEREIN.CLAIMSBASEDONIMPLIEDWARRANTIES,INCLUDINGWARRANTIESOFMERCHANTABILITY

ORFITNESSFORAPARTICULARPURPOSE,ARELIMITEDTOONEYEARORTHESHORTESTPERIODALLOWEDBY

LAW,BUTNOTLESSTHANONEYEAR.ELECTROLUXSHALLNOTBELIABLEFORCONSEQUENTIALORINCIDENTAL

DAMAGESSUCHASPROPERTYDAMAGEANDINCIDENTALEXPENSESRESULTINGFROMANYBREACHOFTHIS

WRITTENLIMITEDWARRANTYORANYIMPLIEDWARRANTY.SOMESTATESANDPROVINCESDONOTALLOWTHE

EXCLUSIONORLIMITATIONOFINCIDENTALORCONSEQUENTIALDAMAGES,ORLIMITATIONSONTHEDURATIONOF

IMPLIEDWARRANTIES,SOTHESELIMITATIONSOREXCLUSIONSMAYNOTAPPLYTOYOU.THISWRITTENWARRANTY

GIVESYOUSPECIFICLEGALRIGHTS.YOUMAYALSOHAVEOTHERRIGHTSTHATVARYFROMSTATETOSTATE.

IfYouNeedService

Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty period should service be

required. If service is performed, it is in your best interest to obtain and keep all receipts. Service under this warranty must be

obtained by contacting Electrolux at the addresses or phone numbers below.

This warranty only applies in the USA, Puerto Rico and Canada. In the USA and Puerto Rico, your appliance is warranted by

ElectroluxMajorAppliancesNorthAmerica,adivisionofElectroluxHomeProducts,Inc.InCanada,yourapplianceiswarranted

byElectroluxCanadaCorp.Electroluxauthorizesnopersontochangeoraddtoanyobligationsunderthiswarranty.Obligations

forserviceandpartsunderthiswarrantymustbeperformedbyElectroluxoranauthorizedservicecompany.Productfeatures

orspecicationsasdescribedorillustratedaresubjecttochangewithoutnotice.

Canada

1-800-265-8352

Electrolux Canada Corp.

5855 Terry Fox Way

Mississauga,Ontario,CanadaL5V3E4

USA

1.800.944.9044

Electrolux Home Products, Inc.,

10200DavidTaylorDrive

Charlotte,NC28262

electrolux.com/shop

Electrolux EW36GC55PB0 cooktop

Product's Documents

User Manual

Specifications

Electrolux EW36GC55PB0 Questions and Answers
