FF7WBIIFADA
32.25" x 23.63" x 23.5" (H x W x D)
ADA compliant built-in undercounter all-refrigerator for
general purpose or commercial use, auto defrost
w/integrated door frame for overlay panels
Highlights:
Commercially approved for use in foodservice
establishments
Flexible design allows built-in or freestanding use in 24"
spaces
32" height allows installation under lower ADA compliant
counters
Product Features:
Commercially approved ETL-S listed to NSF-7 Standards for use in commercial establishments
ADA compliant 32 inch height fits under standard ADA counters
Slim undercounter dimensions Less than 24 inches wide with a full 5.5 c.f. capacity
Built-in capable Make the best use of space by installing your appliance under the counter and flush with
other cabinets
Integrated door frame Customize the front by mounting an overlay panel over the door; seamless look can blend
into other cabinetry with no exposed frame. Handle not included (panel size: 23 5/16" W x 28
1/4" H and at least 3/4" thick; maximum weight: 10 lbs.)
Automatic defrost Reduced user maintenance with automatic defrost
Adjustable shelves Rearrange the refrigerator space to accommodate all shapes and sizes or remove shelves for
a simple clean-up
One piece interior liner Easy clean-up with a seamless liner that won't hold a mess in hidden crevices
Deep shelf space Interior accommodates large trays up to 19 1/2" x 15 1/2"
SUMMIT APPLIANCE DIVISION, FELIX STORCH, INC. | ISO 9001:2015 Certified
770 Garrison Avenue Bronx, NY 10474 USA TEL 718-893-3900 FAX 844-478-8799 inf[email protected] www.summitappliance.com
FF7WBIIFADA Specifications:
Overview
Height of Cabinet 32.0" (81 cm)
Height to Hinge Cap 32.25" (82 cm)
Width 23.63" (60 cm)
Depth 23.5" (60 cm)
Depth with door at 90° 45.63" (116 cm)
Capacity 5.5 cu.ft. (156 L)
Defrost Type Automatic
Door Panel-Ready
Cabinet White
US Electrical Safety ETL
Canadian Electrical
Safety
ETL-C
Sanitation ETL-S
Amps 1.4
Voltage/Frequency 115 V AC/60 Hz
Weight 100.0 lbs. (45 kg)
Shipping Weight 105.0 lbs. (48 kg)
Estimated Time to Ship 2 to 4 days
Parts & Labor Warranty 1 Year
Compressor Warranty 5 Years
Refrigerator Features
Door Swing RHD
Reversible Factory Reversible
Shelf Type Wire
Shelf Qty 3
Adjustable Shelves Yes
Thermostat Type Dial
Fan Type Exterior
Refrigerant Type R600a
Refrigerant Amount 0.64oz.
High Side PSI 180.0
Low Side PSI 80.0
Level Legs Qty 4
Interior Light Yes
Dimensions
Interior Height 26.25" (67 cm)
Interior Width 21.0" (53 cm)
Interior Depth 17.75" (45 cm)
Compressor Step Height 5.5" (14 cm)
Compressor Step Width 21.0" (53 cm)
Compressor Step Depth 5.5" (14 cm)
