Important safeguard

• Use this appliance only as described in this

instructionmanual.

 Aswithanyelectricalappliance,theinstructions

aim to cover as many situations  as possible.

Cautionandcommonsenseshouldbeusedwhen

operatingandinstallingthisairconditioner.

• Thisappliancehas been manufacturedtocool

and dehumidify domestic environments and

mustnotbeusedforotherpurposes.

• It is dangerous to alter or modify the unit's

characteristicsinanyway.

• Theappliancemustbe installed in accordance

withtherelevantnationallegislation.

• Shouldrepairsbenecessary,contactthenearest

authorizedRepairServiceCenter.Unauthorized

servicingcanbedangerous.

• Theapplianceisnotintendedforusebypersons

(including children) with reduced physical,

sensory or mental capabilities, or lack of

experience and knowledge, unless they have

beengivensupervisionorinstructionconcerning

useoftheappliancebyapersonresponsiblefor

theirsafety.

 Children should be supervised to ensure that

theydonotplaywiththeappliance.

• If the power cable is damaged, it must be

replacedbythemanufactureroranauthorized

technicalservicecentreinordertoavoidallrisk.

• Alwaysensuretheapplianceispluggedintoa

grounded3-prongoutlet.Ifyouhaveanydoubts

checkwithaqualiedelectrician.

• Donotuseextensioncables.

• Before cleaning or maintenance operations,

alwaysunplugtheunitfromtheoutlet.

• Donotpullonorplacestrainonthepowercord

whenmovingtheappliance.

• Theapplianceshouldnotbeinstalledwherethe

atmospheremaycontaincombustiblegases,oil

orsulphur,ornearheatsources.

• Donotresthotorheavyobjectsontheappliance.

• Cleantheltersatleastonceaweek.

• Avoidusingheatersneartheunit.

• The unit should be transported in a vertical

position.Ifthisisnotpossiblesecuretheunitat

anangle,donotlieithorizontally.

• Before transporting the unit, drain the unit.

Aftertransportation,waitatleast6hoursbefore

switchingtheuniton.

• The packaging materials can be recycled.You

are therefore recommended to place them in

the special containers for dierentiated waste

collection.

• This appliance is tted with a special safety

device.Whenthecompressorswitcheso,this

devicepreventsitfromswitchingonagainforat

least3minutes.

• WARNING: Changes or modications not

expresslyapprovedbythepartyresponsiblefor

compliance could void the user's authority to

operatetheequipment.

Specic warnings for appliances with R410A

refrigerant gas

R410ArefrigerantgasconformstoECregulationson

theenvironment.

Avoid perforating the refrigerant circuit of the

appliance.

ENVIRONMENTAL INFORMATION:

This unit contains uorinated greenhouse gases

coveredbytheKyotoProtocol.

Maintenance and disposal must be carried out by

qualiedpersonnelonly(R410A,GWP=1975).

Save these instructions

Thisproductisforhouseholdonly

INTRODUCTION

ThankyouforchoosingaDe’Longhiproduct.Pleasetakeafew

momentstoreadtheinstructionstoavoidrisksordamagetothe

appliance.

DESCRIPTION

Description of the appliance (see page 3 - A)

A1 airoutletgrille

A2 controlpanel

A3 handles

A4 castorwheels

A5 BioSilverlter

A6 airintakegrille

A7 airexhausthosehousing

A8 airintakegrille

A9 powercable

A10drainagehosewith2caps

A11remotecontrolsignalreceiver

A12remotecontrolcompartment

Descrizione of the accessories (see page 3 - B)

B1 wallangewithcap

B2 airexhausthose

B3 hoseadaptor

B4 accessoryforwallmounting

B5 windowbracketwithpins

B6 additionalwindowbracket

B7 windowoutlet

B8 remotecontrol

B9 endofseasondustcover

B10endofseasonaccessoriesbag

Electrical connection

Beforepluggingtheapplianceintothetheelectricalreceptacle,

checkthat:

• Theoutlet’s powersupplycorrespondsto thevalue indi-

catedontheratinglabelonthebackoftheappliance;

• Theoutletandelectricalcircuitareadequatefortheappli-

ance;

• Theoutletisa3-holegroundedoutlet .Ifthisisnot

thecase,youmustchooseanotheroutlet.Failuretofollow

theseimportantsafetyinstructionsabsolvesthemanufac-

turerofallliability.

If it becomes necessary, the power cable must be re-

placed by a qualied professional only.

Theinstructionsbelowwillenableyoutoprepareyouraircon-

ditionerforoperationasecientlyaspossible.Beforeuse,make

suretheairintakeandoutletgrillesareunobstructed.

USE

AIR CONDITIONING WITHOUT INSTALLATION

For optimal results set-up in a double-hung window:

1) Placethebracket inthe window sill,extendthe bracket

fullywithinthewindowframe,xthebracketbyusingthe

pinthenlowerthewindowontothebracket,(shouldthe

windowbracketbetoolargeforthewindow.Theplastic

canbecutwithasawbyaqualiedprofessional.)

2) ScrewthehoseadaptorB3tothehose’sendB2.

3) Fittheairexhausthoseinthehousingatthebackofthe

appliance.Insertitasshowningure1.

4) ConnectthewindowoutletB7totheotherendoftheex-

hausthose.

5) Insertthewindowoutletendoftheexhausthoseintothe

slotofthewindowbracket(g.2).

Other set-up methods:

• Thankstothelockingpins,it’spossibletousethewindow

bracketalsoforslidingwindows.Positiontheholeofthe

bracketsotoallowacorrectinstallationoftheexhausthose

(seegure3).

• Ifyouhaveacasementwindow(gure4)followsteps2&

3andplacethewindowoutletB7outsidethewindowto

exhaustthehotair.

Forhelpwithinstallation,operation,andforall

accessoriesandspare/replacementparts,pleasecontact

ourtollfreecustomerservicecallcenterat:

1-800-322-3848[USonly]

1-888-335-6644[Canadaonly]

01-800-711-8805(Mexicoonly]

orlogontoourwebsiteat www.delonghi.com

SEMIPERMANENT INSTALLATION

If required, your appliance can also be installedsemi-perma-

nently(Fig.5).

min. 12 inches

min. 30cm

min. 12 inches

min. 30cm

Proceedasfollows:

• Drillaholeø5,25inches(134mm)inanoutsidewallor

through a window pane. Respect the  dimensions and

heightoftheholegiveningure6and7.

134

Ø 5.25 inches

• FitthewallangeB1intothehole.

• FittheairexhausthoseB2 intherelevanthousinglocated

ontherearsideoftheappliance.(g.1).

• FittheendofthehoseB2 tothewallangeB1 asshownin

g.7.

• WhenthehoseB2isnotconnected,thedrilledholecanbe

closedwiththeangecapB1.

inthe

window

panel

inthewooden

kickboard

ofaFrench

window

inthewall:

youare

recommended

toinsulatethe

sectionofwall

usingsuitable

insulation.

MAX 39 inches

MIN 14 inches

NOTE: As special tools are required for installation, we

suggest you have the appliance installed by specialized

personnel.

NOTE: When installingthe air conditionersemi-permanently,

youshouldleaveadoorslightlyopenlittleas1/2“(1cm)to

guaranteecorrectventilationandroompressure.

NOTE:Keeptheairhosesasshortandfreeofcurvesaspossible

toavoidconstrictions.

DESCRIPTION OF THE CONTROL PANEL (C)

C1 ON/STAND-BYbutton

C2 MODE selectionbutton(conditioning,dehumidifying,fan)

C3 Timerbutton

C4  Increasetemperature/programmedoperationtimebutton

C5  Decreasetemperature/programmedoperationtimebutton

C6 Fanspeedselectionbutton(LOW/MED/HIGH/AUTO)

C7 WHISPERCOOLselectionbutton

C8 REALFEELselectionbutton

C9 REALFEELlight

C10 Air-conditioningsymbol

C11 Dehumidifyingsymbol

C12 Fansymbol

C13 Timersymbol

C14 Alarmsymbol

C15REALFEELsymbol

C16WHISPERCOOLsymbol

C17 Temperaturevalueset,programmeddelayedON/OFFtime

C18 Fanspeedindicator

C19 Timerindicator

C20 Temperatureselectedscaleindicator

Note: The panel buttons are backlit but only the buttons

relevanttotheactivefunctionwillbeon.

Afterfewsecondsofthecontrolpanelinactivity,itsbrightness

willbeautomaticallyreducedandinthenextfewminutesitwill

befurtherreduced.

C1 C10

C2 C11 C12 C13 C14 C3 C4

C8C9 C6C19C15C7 C5C16

C17

C18

C20

CONTROL PANEL

OPERATING FROM THE CONTROL PANEL

TURNING THE APPLIANCE ON/OFF

Before plugging the appliance check the caps on back of

the unit are correctly inserted on drainage hose A10.

Plugtheapplianceintoelectricalreceptacle.Twolinesappearon

thedisplayindicatingthattheapplianceisinstand-byandthe

buttons and lighton.

Touch button(C1)toswitchtheapplianceon.

Whenturnedon,theairconditionerstartsoperatinginthesame

modeaswhenitwasturnedo.

Note

:Ifyoudon’tswitchontheappliance,afterafewminutes,the

and buttonsswitchoandthedisplayfadestoreduceen-

ergyconsuption.

Toturnotheappliance,touchthe button,thenunplug

theappliance.

Note

Neverswitchotheappliancebyunpluggingit:always

usethe button,waitafewminutesandthenunplug.Doing

so,theappliancewillrunacheckoftheoperatingconditions.

REAL FEEL FUNCTION

REALFEELis theinnovativeDe’Longhitechnologythatworks

simultaneouslyontemperaturereductionandhumiditycontrol,

securingbestcomfortlevel.

Withtraditionalsystems,duringworkingtime,optimalcomfort

conditionsmaybereachedbutnotsecuredovertime.WithREAL

FEEL,onceoptimalcomfortisreached,PACautomaticallymodu-

latescompressoractionandfanspeed,tokeepitovertime.

Toactivatethefunction,touch button.

Perfect!Perfect!

REALFEELlight(C9)changescolorwhenapproachingthebest

comfortlevel(seefollowingdiagram).

HIGH

°C/°F

LOW

LOW HIGH

Perfect!

• The well-being feeling is a subjective condition: for this

reason, dierent people may judge dierentlythesame

environmentalconditions.

• Inparticularlysevereenvironmentalconditions(largesize

oftheenvironment,hightemperatureorhumidityoutside,

poorinsulationoftheroom,toomanyofpeopleorstrong

heatloadintheroom,strongexposuretothesun...)this

devicemaynotbeabletoreachthebestcomfortlevel.

AIR CONDITIONING MODE

Idealforhotmuggyweatherwhenyouneedtocoolanddehu-

midifytheroom.Tosetthismode:

• TouchrepeatedlytheMODE buttonuntiltheconditioning

symbol is displayed: the display shows the desired

temperature.

• Press+(C4)or-(C5)buttonstoadjustthedesiredtem-

perature.

• Selectthefanspeedbypressingthe button(C6).

Youcanchoose:

ORANGE LIGHT: Room conditions far

fromoptimallevel.

GREEN LIGHT: Most people feel good

roomconditions,nearoptimallevel.

BLUE LIGHT: Bestcomfortlevel.

HUMIDITY

TEMPERATURE

HIGH

MEDIUM

LOW

HIGH

MEDIUM

LOW

Operating curve

Perfect!Perfect!

REALFEELlight(C9)changescolorwhenapproachingthebest

comfortlevel(seefollowingdiagram).

HIGH

°C/°F

LOW

LOW HIGH

Perfect!

• The well-being feeling is a subjective condition: for this

reason, dierent people may judge dierentlythesame

environmentalconditions.

• Inparticularlysevereenvironmentalconditions(largesize

oftheenvironment,hightemperatureorhumidityoutside,

poorinsulationoftheroom,toomanyofpeopleorstrong

heatloadintheroom,strongexposuretothesun...)this

devicemaynotbeabletoreachthebestcomfortlevel.

AIR CONDITIONING MODE

Idealforhotmuggyweatherwhenyouneedtocoolanddehu-

midifytheroom.Tosetthismode:

• TouchrepeatedlytheMODE buttonuntiltheconditioning

symbol is displayed: the display shows the desired

temperature.

• Press+(C4)or-(C5)buttonstoadjustthedesiredtem-

perature.

• Selectthefanspeedbypressingthe button(C6).

Youcanchoose:

Minimum speed:forsilentoperation.

Medium speed:reducesnoiselevelswhile main-

tainingacomfortabletemperature.

Maximum speed:toachievethetargettempera-

tureasrapidlyaspossible.

the appliance automatically selects the

mostsuitablefanspeedinrelationtothetemperaturesetonthe

digitaldisplayandcurrentroomtemperature.

The most suitable indoor temperature for the room during the

summer varies from 75°F to 81°F (24 to 27°C). You are recom-

mended, however, not to set a temperature much below the out-

door temperature.

WHISPER COOL (available in conditioning mode only)

By activating this function, the operating noise is further re-

duced.Toactivateit,touchthe (C7)button.

Thedisplayshowstherelativesymbol(C16).

DEHUMIDIFYING MODE

Ideal to reduce room humidity (spring and autumn, damp

rooms,rainyperiods,etc).In dehumidifyingmode,theappli-

ance MUSTbeset-upinthesame wayasforairconditioning,

withtheairexhausthose(B2)attachedtoenablethemoisture

tobedischargedoutside.Tosetthismode:

• TouchrepeatedlytheMODE buttonuntilthedehumidify-

ingsymbolisdisplayed.

FAN MODE

Whenusingthe appliancein thismode,theair exhausthose

(B2)doesnotneedtobeconnected.

Tosetthismode:

• TouchrepeatedlytheMODE buttonuntilthefansymbolis

displayed.

• Selectthefanspeedbypressingthe button(C6).

Youcanchoose:

Minimum speed:forsilentoperation.

Medium speed:reducesnoiselevelsbutstillmain-

tainsagoodfanpower.

Maximum speed:formaximumfanpower.

CHANGING TEMPERATURE SCALE

x20”

Thetemperaturecanbedisplayedin°For°C.Tochangethetem-

peraturescale,turnotheunitbytouchingthe button,then

keeptouchedtheMODEbuttonforapproximately20seconds.

Theapplianceemitsabeeptoconrm.

SETTING THE TIMER

Thetimercanbeusedtodelayappliancestartuporshutdown.

Thisavoidswasting electricity bynot operatingthe appliance

whenitisnotneeded.

How to program delayed start up

• Plugtheapplianceintoanelectricalreceptacleandturnthe

unittostandby.

• Touchthetimerbutton(C3):thetimersymbol(C13)and

 thenumberofhourscomeon.

• Usethe+(C4)or- (C5)buttonstosetthenumberofhours

delaybeforetheappliancecomeson.

• Theapplianceworksusingthemodepreviouslyset.

 Theappliancecanbe settocomeonwithinthenext 24

hours.

• Afewsecondafterset,thesettingismemorised,thetimer

symbolislitandthedisplayshowsthattheapplianceisin

standby.

Todeletethesetting,touchtwotimesthetimerbutton(C3).The

timersymbol(C13)switcheso.

How to program delayed shutdown

• Withtheairconditioningon,ineverymode,itispossibleto

setthedelayedshutdown.

• TouchtheTimer(C3)button:thetimersymbol(C13)and

thehoursswitchon.

• Usethe+(C4)or- (C5)buttonstosetthenumberofhours

delaybeforetheapplianceturnso.

Afewsecondafterset,thesettingismemorised,thetimersym-

bolislitandthedisplayshowsthecurrentmode.

Attheendofthesettimetheapplianceautomaticallyturnsin

standbymode.Todeletethesetting,touchtwotimesthetimer

button(C3).Thetimersymbol(C13)switcheso.

OPERATING FROM THE REMOTE CONTROL

USING THE REMOTE CONTROL

• Pointtheremotecontrolat thereceiver(A11)onthe air

conditioner.Theremotecontrolmustbenomorethan16

ft(5meters)awayfromtheappliance(withoutobstacles

betweentheremotecontrolandthereceiver).

• Theremotecontrolmustbehandledwithextremecare.Do

notdropitorexposeittodirectsunlightorsourcesofheat.



NOTE: Theremotecontrolcanbesafelystoredintheappropiate

compartmentA12(seegure).

DESCRIPTION OF THE REMOTE CONTROL D

D1) ON/STAND-BYbutton

D2) Increase/decreasetemperature/programmedoperation

D3) “MODE”selectionbutton

D4) Fanspeedselectionbutton

D5) REAL FEEL selectionbutton

D6) WHISPER COOL selectionbutton

D7) Switchbutton°C/°F

D8) TIMER button



INSERTING OR REPLACING THE BATTERIES

• Removethecoverontherearoftheremotecontrol;

• ReplacetheoldbatterieswithtwonewR03“AAA”1.5Vbat-

teries,insertingthemcorrectly(seetheinstructionsinside

thebatterycompartment);

• Replacethecover.

If the remote control unit is replaced or discarded, the batteries

must be removed and disposed of in accordance with current

legislation as they are harmful to the environment. Do not mix

old and new batteries.

Do not mix alkaline, standard (carbon-zinc) or rechargeable

(nickel-cadmium) batteries. Do not dispose of batteries in re.

Batteries may explode or leak. If the remote control is not be

used for a certain length of time, remove the batteries.

TURNING THE APPLIANCE ON

• Plugintotheelectricalreceptacle..

• Pressthe button(D1)(whenturnedon,theaircon-

ditionerstartsoperatinginthesamemodeaswhenitwas

turnedo).

• Toswitchtheapplianceo,pressbutton(D1) ,then

removetheplug.

NOTE: Never switchthe applianceo byremovingthe plug.

Alwaysswitchitobypushingonthe buttonand

waitingfewminutesbeforeremovingtheplug.Onlyinthis

waytheappliancewillperformthestandardcheckings.

FUNCTIONS SELECTION

Thecontrolsontheremotecontrolarethesameasthoseonthe

controlpaneloftheappliance(C).Youshouldthereforereferto

the instructions in the chapter“OPERATINGFROMTHE CON-

TROLPANEL”toselectthedesiredfunctions.PressbuttonD7,

toswitchthetemperaturedisplayfrom°Cto°Fandviceversa.

Note:

• Thisequipmenthasbeentestedandfoundtocomplywith

thelimitsforaClassBdigitaldevice,pursuanttopart15of

theFCCRules.Theselimitsaredesignedtoprovidereason-

ableprotectionagainstharmfulinterferenceinaresiden-

tialinstallation.

• Thisequipmentgenerates,usesandcanradiateradiofre-

quencyenergyand,ifnotinstalledandusedinaccordance

withtheinstructions, maycause harmfulinterferenceto

radio communications. However, there is no guarantee

thatinterferencewillnotoccurinaparticularinstallation.

Ifthisequipmentdoescauseharmfulinterferencetoradio

ortelevisionreception,whichcanbedeterminedbyturn-

ingtheequipmentoandon,theuserisencouragedtotry

tocorrecttheinterferencebyoneormoreofthefollowing

measures:

-Reorientorrelocatethereceivingantenna.

- Increase the separation between the equipment and

receiver.

- Connecttheequipmentintoanoutletonacircuitdier-

entfromthattowhichthereceiverisconnected.

- Consultthedealeroranexperiencedradio/TVtechnician

MAX 16 ft

MAX 5 meters

D6D5

forhelp.

 Changes or modications not expressly approved bythe

partyresponsibleforcompliancecouldvoidtheuser’sau-

thoritytooperatetheequipment.

• ThisdevicecomplieswithPart15oftheFCCRules.Opera-

tionissubjecttothefollowingtwoconditions:(1)thisde-

vicemaynotcauseharmfulinterference,and(2)thisdevice

mustacceptanyinterferencereceived,includinginterfer-

encethatmaycauseundesiredoperation.

• ThisClassBdigitalapparatuscomplieswithCanadianCAN

ICES-3(B)/NMB-3(B).

IF ... IS DISPLAYED,

“LowTemperature”

(frostprevention)

..WHAT SHOULD I DO?

Theapplianceisttedwithafrostprotec-

tiondevicetoavoidexcessiveformationof

ice.The appliancestarts up againauto-

matically when the defrosting process is

completed.

IF ... IS DISPLAYED,

ProbeFailure

(Probedamaged)

..WHAT SHOULD I DO?

Ifthisisdisplayed,contactyourlocalau-

thorizedservicecenter.

IF ... IS DISPLAYED,

“HighLevel”

(Internaltrayfull)

..WHAT SHOULD I DO?

Empty theinternal safety tankfollowing

the instructions in the section “End of

season operations”. If HL alarm reoccurs

frequentely,contactyourlocalauthorized

servicecenter.

SELFDIAGNOSIS

Theappliancehasaselfdiagnosissystemtoidentifyanumberofmalfunctions.

Errormessagesaredisplayedontheappliancedisplay.

TIPS FOR CORRECT USE

Toensureoptimalresultsfromyourairconditioner,followthese

recommendations:

• closethewindowsanddoorsintheroomtobeaircondi-

tioned When installingtheair conditioner semi-perma-

nently,youshouldleaveadoorslightlyopen(aslittleas

1/2”(1cm)toguaranteeproperventilation.

Closedoorsandwindows

• Neverusetheapplianceinverydamprooms(laundriesfor

example).

• Protecttheroomfromdirectexposuretothesunbypar-

tiallyclosingcurtainsand/orblindstomaketheappliance

muchmoreeconomicaltorun.

Closeblindsorcurtains

• Neverusetheapplianceoutdoors.

•

Makesuretherearenoheatsourcesintheroom.

• makesuretheairconditionerisstandingonalevelsurface.

donotcovertheappliance

• Neverrestobjectsofanykindontheairconditioner.

• Neverobstructtheairintakeoroutletgrilles.

CLEANING

Before cleaning or maintenance, turn the appliance o by

touchingthe button,thenunplugfromtheelectricalre-

ceptacle.

CLEANING THE CABINET

Youshouldcleantheappliancewithaslightlydampcloththen

drywithadrycloth.Forsafetyreasons,neverwashtheaircon-

ditionerwithwater.

Precautions

Never use petrol, alcohol or solvents to clean the appliance.

Neversprayinsecticideliquidsorsimilar.

CLEANING THE BIO SILVER AIR FILTER

Ifthelterisdirty,aircirculationiscompromisedandthee-

ciencyoftheappliancedecreases.

Itisthereforegoodpracticetocleanthelteratregularinter-

vals.Thefrequencydependsonthedurationandconditionsof

operation.

Iftheunitisusedconstantlyorsystematically,youarerecom-

mendedtocleanthelteronceaweek.

Thelterishousedintheintakegrille.

Tocleanthelter,extractasshowning.8

Useavacuumcleanertoremovethedustcollectedonthelter.

Ifitisverydirty,immerseinwarmwaterand rinseanumber

oftimes.Thewatershouldneverbehotterthan104°F(40°C).

After washing the lter, allow it to dry completely before

repositioningit.

TheBioSilverlterhelpscapturedustandpollenandhelpsre-

ducethegrowthofbacteriaandmoldonthelter.

START OF SEASON CHECKS

Makesurethepowercable andplugareundamaged andthe

groundconnectionisecient.

Followtheinstallationinstructionsprecisely.

END OF SEASON OPERATIONS

Todrainallwaterfromthecircuit,removetheexternalcapby

unscrewingit inthe anticlockwisedirection then,removethe

internalcapfromthedrainageonthebackoftheapplianceand

allowthewatertodrainoutintoabasin(g.9).

Inordertoproperlystoragetheapplianceattheendofthesea-

son,wesuggestyoucoveritwiththesuppliedendof season

dustcover B9andyouputtheaccessoriesintherelevant

endofseasonaccessoriesbagB10.

Whentheapplianceisempty,replacethecaps.

Cleanthelteranddrythoroughlybeforeputtingback.

TECHNICAL SPECIFICATIONS

Powersupplyvoltage seeratinglabel

Max.absorbedpower

duringairconditioning “

Refrigerant “

Coolingcapacity “

LIMIT CONDITIONS

Roomtemperaturefor

airconditioning 64÷104°F18÷40°C

Transport, lling, cleaning, recovery and disposal of

refrigerant should be performed by a technical service

centre appointed by the manufacturer only.

The appliance should be disposed of by a specialist centre

appointed by the manufacturer only.

TO AVOID DAMAGE TO THE UNIT:

NEVERTRANSPORTORTURNTHEAPPLIANCEUPSIDEDOWNOR

ONITSSIDE.IFTHISOCCURS,WAIT6 HOURSBEFORETURNING

THEAPPLIANCEON,24HOURSISRECOMMENDED.Aftertheunit

hasbeenonitsside,oilneedstoreturntothecompressortoen-

sureproperfunction.Withoutallowingtheunitthistime(6-24

hours)theunitmayfunctionforonlyashorttime,andthenthe

compressorwillbreakdownfromlackofoil.

ELECTRICAL CONNECTION

Thisapplianceisequippedwitha3pronggroundedplug.The

plugmustbeconnectedintoanoutletthatisproperlyinstalled

andgroundedintheaccordancewithalllocalcodesandordi-

nances.Donot modify the plug providedwith the appliance.

Ifit willnottthe outlet,havea properoutlet installed bya

qualiedelectricianorrelocatetheunittoaproperoutlet.Ifthe

householdelectricalsupplydoesnotmeettheabovespecica-

tions,orifyouarenotsureyourhomehasaneectiveelectrical

ground,haveaqualiedelectricianoryourlocalelectricalutility

companycheckitandcorrectanyproblems.

SAFETY PLUG

Theapplianceisttedwithasafetyplugtoprotectthepower

cable.

Ifpoweriscuto,unplug fromtheoutletandmakesurethe

powercableisundamaged.

Ifthecableisdamaged,calltheservicecenterimmediately.

Ifpowercutsofrequentlyandthepowercableisundamaged,

contactaqualiedelectrician.

OPERATION OF THE SAFETY PLUG

Ifthesafetydeviceincorporatedintheplugtripsand cutso

thepowersupply,checkthatthepowercableandplugarenot

damaged.

Ifthepowercableisundamaged,torestoreoperationpressthe

"RESET"button.

Toverifycorrectoperationoftheplug,pressthe"TEST"button

periodicallyandmakesuretheappliancedisconnects.Ifthisis

notthecase,contacttheservicecenter.

Torestoreoperation,pressthe"RESET"button.

TROUBLESHOOTING

PROBLEM CAUSE SOLUTION

Theairconditionerdoesnotcomeon itisnotpluggedintothetheelectrical

receptacle

plugintotheelectricalreceptacle

thereisnocurrent wait

theinternalsafetydevicehastripped calltheServiceCenter

Theairconditionerworksforashort

timeonly

therearebendsorkinksintheair

exhausthose

positiontheairhosecorrectly,keepingit

asshortandfreeofcurvesaspossibleto

avoidbottlenecks

somethingispreventingtheairfrom

beingdischarged

checkandremoveanyobstacles

obstructingairdischarge

Theairconditionerworks,butdoesnot

cooltheroom

windows,doorsand/orcurtainsopened closedoors,windowsandcurtains,

bearinginmindthe“TIPSFORCORRECT

USE”givenpreviously

thereareheatsourcesintheroom(oven,

hairdryer,etc.)

eliminatetheheatsources

theairexhausthoseisdetachedfrom

theappliance

ttheairexhausthoseinthehousingat

thebackoftheappliance(g.1).

dustlterclogged cleanorreplacethelterasdescribed

previously

thetechnicalspecicationofthe

applianceisnotadequatefortheroom

inwhichitislocated.

Duringoperation,thereisanunpleasant

smellintheroom

lterclogged cleanthelterasdescribedpreviously

Theairconditionerdoesnotoperatefor

aboutthreeminutesafterrestartingit

preventstheappliancefrombeing

restarteduntilthreeminuteshave

elapsedsinceitwaslastturnedo

wait.Thisdelayispartofnormal

operation.

Thesymbol andoneofthe

followingmessages:HL/PF

theappliancehasaselfdiagnosissystem

toidentifyanumberofmalfunctions.

seetheSELF-DIAGNOSISchapter

De’LonghiisthedistributorofKenwoodhomeappliances.

This warranty applies to all home appliances with De’Longhi or Kenwood brand names

LIMITED WARRANTY

WewarranteachDe’LonghiAIRCONDITIONERtobefreefromdefectsinmaterialandworkmanship.Fromthepurchasedate,our

obligationunderthiswarrantyistoprovidetwo(2)yearfreepartsandlaborontheentireAIRCONDITIONER,withanadditionalfour

(4)yearsfreeonanypartofthesealedsystemconsistingofthecompressor,evaporator,condenserandfactoryconnectedrefrigerant

tubing.Laborandallotherpartsduringtheadditionalfour(4)yearwarrantyaretobepaidbytheowner.AllAIRCONDITIONERSin

needofrepairaretobeshippedtoanauthorizedDe’Longhiservicecenterattheowner’sexpense,andDe’Longhiwillthenincurthe

returnshippingcosts.Aftertherstsix(6)yearsofownership,allexpenses(allparts,laborandshipping)aretobepaidbytheowner

oftheunit.ThiswarrantyshallapplyonlyiftheAIRCONDITIONERisusedinaccordancewiththefactorydirectionsthataccompanyit,

andonanAlternatingCurrent(AC)circuit.Thiswarrantyisinlieuofallotherwarrantiesandrepresentations,expressedorimplied,

andallotherobligationsorliabilitiesonourpart.Wedonotauthorizeanyotherpersonorcompanytoassumeforusanyliabilityin

connectionwiththesaleoruseofourAIRCONDITIONER.ThiswarrantyshallnotapplytoanyAIRCONDITIONERthathasbeenrepaired

oralteredoutsideourfactorynorshallitapplytoanyAIRCONDITIONERthathasbeensubjectedtomisuse,negligenceoraccidents.

Ifrepairsbecomenecessary,seecontactinformationbelow:

U.S. Residents:

Pleasecontactourtollfreehotlineat 1-800-322-3848

orlogontoourwebsiteatwww.delonghi.com

CANADA Residents:

Pleasecontactourtollfreehotlineat1-888-335-6644

orlogontoourwebsiteatwww.delonghi.com

MEXICO Residents:

Pleasecontactourtollfreehotlineat01-800-711-8805

orlogontoourwebsiteatwww.delonghi.com

Theabovewarrantyisinlieuofallotherexpresswarrantiesandrepresentations.Allimplied

warrantiesarelimitedtotheapplicablewarrantyperiodsetforthabove.Thislimitationdoesnotapplyifyouenterintoanextended

warrantywith De’Longhi.Somestates/countriesdo not allow limitations on how long an implied warranty lasts, so the above

exclusionsmaynotapplytoyou.De’Longhidoesnotauthorizeanyotherpersonorcompanytoassumeforitanyliabilityin

connectionwiththesaleoruseofitsappliance.

How does country law apply?

Thiswarrantygivesyouspeciclegalrights,andyoumayalsohaveotherrights,whichvaryfromstatetostate/countrytocountry.

Delonghi PACAN120EW 3-in-1 Portable Air Conditioner, Dehumidifier & Fan

Product's Documents

User Manual

Specifications

Delonghi PACAN120EW Questions and Answers

Related Products

Delonghi ‎PACAN135EWS 3-in-1 Portable Air Conditioner, Dehumidifier & Fan

Delonghi PACEX390LVYN Pinguino 3-in-1 Portable Air Conditioner, Dehumidifier & Fan
