DRAPER TOOLS LTD, HURSLEY ROAD, CHANDLER'S FORD, EASTLEIGH, HANTS. SO53 1YF. U.K.
www.drapertools.com e-mail: [email protected]
SRDH0716
Steel Mesh Garden Cart
Stock No.85634 Part No.GMC/450
06/2016ASSEMBLY INSTRUCTIONS
WHAT’S IN THE BOX?
PARTS LIST
Check that all parts are included with your Steel Mesh Garden Cart prior to assembly.
Drawings are not to scale.
QTY: 1PC.
$Bed.
QTY: 2PCS.
%Side Panels. &Front Panel.
QTY: 1PC.
'Back Panel.
QTY: 1PC.
QTY: 1PC.
)Front Axle
Sub - Assembly.
*Yoke.
QTY: 1PC. QTY: 2PCS.
+Front Struts.
QTY: 1PC.
, Front Axle
Connection Bar.
.Rear Struts.
QTY: 2PCS.QTY: 1PC.
- Rear Axle
Sub - Assembly.
QTY:
4PCS.
(13” Wheels.
/Handle.
QTY: 1PC.
CAUTION: Please read these assembly instructions fully BEFORE attempting to assemble
this cart. Failure to comply with these instructions may result in injury. Do not load the
garden cart with more than 450kg. Always distribute payload evenly over the surface of
the bed. Do not operate or use on objects that can cause damage to the pneumatic tyres.
Do not inflate tyres to more than 30psi (2.1bar). Save these instructions for further
reference.
Warning:
This cart is not a toy. Do not allow children to play with this cart at any time.
Do not exceed maximum load capacity 450kg on level ground.
1
