JBL Consumer Products, Inc.
80 Crossways Park West
Woodbury, NY 11797
8500 Balboa Blvd.
Northridge, CA 91329
800 336 4JBL (4525)
A Harman International Company
Part No. JGS10OWN
G SERIES LOUDSPEAKERS
Specifications G SUB10
Amplifier Power (RMS)* 80 Watts
Low Frequency Woofer 10"
Voice Coil Diameter 2"
Cone Material Poly-fiber Laminate
Inputs Line Level & Speaker Level
Outputs Full-Range Speaker
Crossover Frequency 50–200 Hz (Continuously Variable)
Frequency Response (–6dB) 30 Hz to (62–250 Hz)**
External Dimensions (HxWxD) 17-1/4" x 13-1/4" x 14-1/4"
External Dimensions (mm) 438 x 337 x 362mm
Weight (each) 35 lbs (15.9kg)
Shipping Weight 40 lbs (18.1kg)
*ALC circuit defeated.
**Determined by crossover setting.
JBL continually strives to improve its products. New materials, production methods and design
refinements are introduced into existing models without notice as a routine expression of our design
philosophy. For this reason, JBL loudspeakers may differ in some respect from their published
specifications and descriptions, but will always equal or exceed the original specifications unless
otherwise stated.
SERVICE
Should your subwoofer ever need
service, return it to the JBL dealer
from whom it was purchased. If for
some reason this is impractical, in the
USA, call 800-336-4JBL for the
nearest warranty station.
Do not
return products to the JBL factory
without prior authorization.
