1 2 3 4 5
6
Programme ended when ...
... Start/Reload goes out and or (if was
selected, no final drain/spin) is indicated on the display
panel, the buzzer sounds. Set the volume of the buzzer.
apage 6
Changing the programme ...
If you have selected the wrong programme by mistake:
Reselect the programme.
Select Start/Reload $.
Pausing the programme ...
Touch the Start/Reload $ button.
Follow the instructions in the display field: when lights
up and appears in the display, the door can be
opened. If required, add /remove a laundry item; if
and are displayed alternately, the door cannot be
opened due to a high water level in the drum or a high
temperature.
Touch Start/Reload $button to continue the
programme.
... or terminate the programme
Programmes with high temperature:
Cool down laundry: Select Rinse/Freshen up 2.
Select Start/Reload $.
Programmes at lower temperature:
Select Drain >or Spin .
Select Start/Reload $.
((Childproof lock)
Programme cannot be changed by accidental operation.
To activate the childproof lock:
After the programme starts, press and hold the ( button for 5 seconds;
Release when the ( symbol lights up.
When the programme ends, the Start/Reload $ indicator remains on to remind you to
deactivate the childproof lock.
*
( symbol flashes if the programme has been changed while childproof lock is activated.
To deactivate the childproof lock:
Touch and hold the
( button until the ( symbol turns off;
Release the button.
If the childproof lock is deactivated while the programme selector is in a different position
from when the childproof lock was activated*, the current programme will be halted.
ʑ
Additional functions
See also Programme overview apage 7
Ĉ SpeedPerfect
For washing in a shorter time with a washing result
comparable to that of the standard programme.
ć EcoPerfect
For saving energy with a washing performance
comparable to that of the standard programme.
2Extra Rinse
Additional rinse cycle. Prolonged programme duration.
For areas with very soft water or for further improving the
washing result.
7 Prewash
Activate prewash. For heavily soiled, hard-wearing
textiles, e.g. made of cotton or linen.
The additional function indicator light is on when this option is selected; if this option cannot
be selected for the programme, this is indicated by a short flashing of the light and an
acoustic signal.
ʑ
$Start/Reload
To start or pause the programme.
ʑ
Signals
Set to ÂPress and
hold
1 step
clockwise
Button signals Information signals
Set volume* Set volume*1 step
clockwise
Set to Â
1. Start signal mode
2. Set volume for ...
Release
#
*If required, set repeatedly
1 step
clockwise
direct
Sorting and loading the laundry
Observe the care information provided by the manufacturer.
Sort the laundry according to the information on the care labels.
Sort the laundry according to type, colour, degree of soiling and
temperature.
Remove any foreign objects as there is a risk of rusting.
Do not exceed the maximum load. apage 7
Observe the instructions in the Important information section. apage 9
Load both large and small items of laundry.
Close the washing machine door. Take care not to trap any items of clothing
between the loading door and rubber seal.
Add detergent and care product
Add the appropriate amount according to:
Amount of laundry, soiling, water hardness (ask your water supply
company) and manufacturers instructions.
Models without insert for liquid detergent: pour liquid detergent into an
appropriate dispenser and place in the drum.
During operation: close the detergent drawer.
Correct installation according to
separate installation instructions.
Check the machine
Never switch on a damaged machine.
Inform your after-sales service.
Insert the mains plug
With dry hands only.
Only hold the plug by the plug
body.
Turn on the tap
To achieve the labeling comsumption
values, two cycles of CottonsL90 °C
programme without laundry are required
to be run at initial setup.
Note: This operation only needs to be
completed once.
Compartment II: Detergent for the main wash, water softener,
bleacher, stain remover
Your washing machine
Congratulations You have opted for a modern, high-quality
domestic appliance manufactured by BOSCH. The washing machine
is distinguished by its economical use of water and energy.
Every appliance that leaves our factory has been inspected thoroughly
to ensure that it functions properly and is in perfect condition.
For further information about products, accessories, spare parts and
services, visit our website: www.bosch-home.com or contact our after-
sales service centres.
Environmentally friendly waste disposal
All packaging must be disposed of in accordance with environmental
guidelines. This appliance is certified in accordance with European
Directive 2002/96/EEC on Waste Electrical and Electronic Equipment
(WEEE).
This directive provides the framework for the EU-wide collection and
reuse of used appliances.
Intended use
Contents Page
ʋIntended use ...................................................................................... 1
ʋProgrammes ...................................................................................... 1
ʋPreparation ..................................................................................... 2/3
ʋSetting and adjusting programmes ............................................... 3
ʋWashing ........................................................................................... 3/4
ʋRemoving the laundry ...................................................................... 4
ʋDisplay information, Options, Functions ................................... 5/6
ʋProgramme overview........................................................................ 7
ʋSafety instructions .............................................................................. 8
ʋConsumption values .......................................................................... 8
ʋImportant information ....................................................................... 9
ʋInsert for liquid detergent.................................................................. 9
ʋCare ...................................................................................................10
ʋInformation on the display panel...................................................10
ʋMaintenance .....................................................................................11
ʋWhat to do if .................................................................................... 12
ʋEmergency release ..........................................................................13
ʋCustomer service ............................................................................13
Protection of the environment/Conservation tips
Always fill the washing machine with a maximum amount of
laundry for the relevant programme.
Do not use prewash when washing laundry that is soiled normally.
Instead of the CottonsL90°C programme, select
Cottons L60°C with additional function ćEco Perfect.
Comparable cleaning result with significantly lower energy
consumption.
Dose detergent according to the manufacturers instructions
and water hardness.
If the laundry is to be subsequently dried in a tumble dryer, select
a spin speed as specified by the dryer manufacturer.
Preparation
Before washing for the first time,
run a wash once without any laundry in the machine apage 9
Setting and adjusting programmes
Display panel/
Option buttons/
Additional functions
Programme selector Start/
Reload
1
2
3
Washing
Compartment ~: Fabric softener, impregnating agent, starch
Compartment I: Detergent for prewash
ʋFor domestic use only.
ʋFor washing machine-washable fabrics in a detergent
solution.
ʋTo be operated with cold mains water and
commercially available low foam detergents and care
products which are suitable for use in washing
machines.
Do not leave children unattended near the
washing machine.
The washing machine is not to be used by
children or persons not familiar with the
operating instructions.
Keep pets away from the washing machine.
Dilute viscous fabric softener and fabric conditioner with water.
This prevents blockages.
ʑ
Display symbols
ʑ
Display information
Before starting a programme, the max. load
for the selected programme is displayed
when the door is open. The remaining time
or finish-in time is displayed when the door
is closed.
*Display shown may vary depending on the
model and selected programme.
ʑ
Option buttons
You can change the spin speed and temperature beforehand and while the selected programme is running. The effects
depend on the progress of the programme.
°C (Temp.)
You can change the indicated washing temperature. The maximum washing temperature that can be selected
depends on the programme that has been selected.
(Finish in)
When you select a programme, the respective programme duration is displayed. You can delay the start of the
programme before it begins. The finish-in time indicates when the programme will be finished. It can be set in hourly
increments up to a maximum of 24 hours. Press and hold the (Finish-in) button until the required number of hours
is shown (h=hour). Select Start/Reload$.
(Spin speed)
You can change the indicated spin speed. The maximum spin speed which can be selected depends on the selected
programme. If is selected, the load is held in the rinsing water.
1Wash: On if wash process is running.
Rinse: On if rinse process is running.
Spin: On if spin process is active
if the symbol cflashes
apage 10
+Water tap: Flashing if tap not open or no water supply.
Door: On if door can be opened.
Overdosage: On if too much detergent used.
Automatic load detection: Automatically detects the
load size after the water inlet phase and sets the accurate remaining
time. Symbols indicate small, medium and full loads measured*
according to the recommended max. load for the selected
programme.
* Automatic display of the detected load only for washing
programmes with a max. load recommendation > 3.0 kg except for
Rinse, Spin and Drain. Different types of textiles with different water
absorption rates may influence the load display.
kg, e.g. kg*: max. recommended load for selected programme
apage 7, Programme overview
time, e.g
.
*: remaining time
*: finish-in time defined by user apage 5
: pause
: door can be opened in Pause status
: end of programme
: end of programme with the setting
: set volume of signals apage 6
: Information on the display apage 10
Removing laundry
Open the washing machine door and remove the
laundry.
If (Rinse stop = no final drain/spin) is active: Select
the spin speed or set programme selector to Drain
>or
Spin
.
Select Start/Reload $.
Remove any foreign objects as there is a risk of rusting.
Turn off the tap
Switch off
Set the programme selector to ÂOff.
Programmes
Detailed programme overview. apage 7
The temperature and spin speed can be selected
individually, irrespective of the selected programme and
programme progress.
Cottons L
Hardwearing textiles
Easy-Care ISynthetic fibres, easy-care textiles
Mix
1
Textiles made of cotton and synthetic fibres
Delicate/Silk ߣSilk and delicate washable textiles
:Wool O
Hand and machine-washable wool or wool-rich
textiles
Spin Additional spin cycle
Drum Clean .For drum hygiene or fluff removal
Drain >Draining of the water inside the drum
Rinse/Freshen up 2Extra rinse with spin
Jeans/Dark Wash KDark textiles
Sportswear $Sportswear made of microfibre
Shirts
Programme for Shirts/Blouses
Kidswear E
Textiles for children
Allergy Plus ā
Programme for allergic people and advanced
hygiene
Super 15/30 /
Extra short programme
Detergent drawer with
compartments I, II, ~
Control panel
Door handle
Drum
Display information, Options, Functions Options, Functions
All buttons are sensitive and a
gentle tap is adequate.
If you press and hold the Option
buttons, the setting options
automatically scroll through.
Select Start/Reload $
Washing
Serviceflap
If the
( symbol lights up or
flashes in the display panel, the
childproof lock is active.
adeactivate, page 6
For additional functions and
option buttons, see the Individual
settings section.
apage 5/6
Programme selector for
switching the machine on
and off and for selecting the
programme. Can be rotated
in either direction.
Read these instructions before switching on the washing
machine.
Also follow the separate installation instructions.
Observe the safety instructions on page 8.
Insert for liquid detergent (depending on model), apage 9
7
Programme overview (see also the information on page 5, 6)
Programmes °C max. (kg)
Type of laundry
Additional functions; information
CottonsLD - 90
7.5 /5.0 *
Standard washing program for hard-wearing textiles made of cotton or linen.
Ĉ SpeedPerfect *, ć EcoPerfect, 2 Extra Rinse,
7 Prewash
Allergy Plus āD - 60
Programme specially designed for allergic people and advanced hygiene, suit-
able for hard-wearing textiles made of cotton or linen.
Kidswear E
D - 40
7.5 /5.0 *
Programme suitable for washing kids wear made of cotton or synthetic tex-
tiles.
Ĉ SpeedPerfect, ć EcoPerfect, 2 Extra Rinse,
7 Prewash;
Wash the clothing inside out.
Jeans/Dark Wash
3.5
Dark coloured textiles made of cotton or synthetics.
Easy-Care I
D - 60
Textiles made of synthetic materials or blended fabrics.
Ĉ SpeedPerfect, ć EcoPerfect, 2 Extra Rinse,
7 Prewash
Mix
1
Mixed load consisting of textiles made of cotton and synthetic fibres.
Shirts D - 60
2.0
Suitable for Shirts/Blouses made of cotton, linen, synthetic fibres or blended
fabrics.
Ĉ SpeedPerfect, ć EcoPerfect, 2 Extra Rinse,
7 Prewash
Delicate/Silk
D - 40
For delicate, washable textiles, e.g.made of silk, satin, synthetic fibres or
blended fabrics.
Sportswear $Suitable for sportswear made of microfibre e.g Acrylic, Nylon, Spandex, etc.
:Wool O
Hand and machine-washable wool or wool-rich textiles.
Especially gentle washing programme to prevent shrinkage,
longer programme pauses (textiles rest in detergent solution)
e.g. cashmere, mohair or angora. Also suited for hand washable silk.
Super 15/30 /
D - 40 2.0/ 3.5 *
Extra short programme approx. 15-30 minutes, suitable for lightly soiled and
small amounts of laundry.
Ĉ SpeedPerfect
*, 2 Extra Rinse
Drum Clean .
D , 40 , 90
0
Special programme for drum hygiene or fluff removal
90° = antibacterial programme, use no detergent
40° = antibacterial programme, special drum cleaning detergent can be used
D = no antibacterial programme, to remove hair or fluff from the tub.
Spin
7.5
Extra spin with selectable spin speed.
Ĉ SpeedPerfect
Rinse/Freshen up 2Extra rinse with spin. 2 Extra Rinse
Drain >
Draining of the water inside the drum, e.g. after rinse stop.
The programmes are time-controlled for lightly soiled textiles. If textiles are heavily soiled, reduce the load and select additional function, e.g. 7Prewash.
Programmes without prewash - pour detergent into compartment II; Programmes with prewash - divide detergent between compartments I and II.
* Reduced load for ĈSpeedPerfect option.
For further information and a selection of our products,
go to our website: http://www.bosch-home.com
or contact our after-sales service centres
Robert Bosch Hausgeräte GmbH
Carl -Wery-Str.34
D-81739 Munich/Germany
WAS28461AU 9000857016
9302
Loading ...
Loading ...
Loading ...
