EN Electric Double Hotplate
Translation of the original manual
SCP 2271WH
- 2 -
09/2020
Copyright © 2020, Fast ČR, a.s.
1
2
A
7
3
4
5
6
- 3 -
09/2020
Copyright © 2020, Fast ČR, a.s.
EN
Electric Double
Hotplate
User'smanual
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND STORE FOR
FUTURE USE.
■
This appliance may be used by children
8 years of age and older and by persons
with physical or mental impairments
or by inexperienced persons, if they
are properly supervised or have been
informed about how to use the product
in asafe manner and understand the
potential dangers. Cleaning and user
maintenance must not be performed
by children unless they are older than
8 years of age and under supervision.
Keep this appliance and the power
cord out of reach of children that are
younger than 8 years of age.
■
Children must not play with the
appliance.
■
This appliance is designed for
household use only. It is not intended
for use in locations such as:
–
staff kitchens in stores, offices and
other workplaces;
– agricultural farms;
–
hotel or motel rooms and other living
areas;
– bed and breakfast establishments.
■ Do not use the appliance outdoors or
in an industrial environment.
■ Never use the appliance for any other
purposes than those for which it is
intended.
■
Before connecting the appliance to
apower socket, check that the nominal
voltage on its rating label matches the
voltage in the power socket to which
you wish to connect it. Connect the
appliance only to aproperly grounded
socket. Do not use an extension cord.
Fully unwind the power cord before
use.
Attention:
This appliance is not intended to
be operated using an external
timer switch or remote control.
■
Only use the appliance on ahorizontal,
dry, clean, stable and heat resistant
surface. Do not use the appliance on
the drip area of the kitchen sink.
■
Do not place the appliance on the edge
of atable or on an electric or gas stove
or in their vicinity.
■ Do not use the appliance on asurface
that is sensitive to heat or that is
covered by atable cloth, paper or other
flammable material, in the vicinity of
curtains and other flammable materials
or materials sensitive to heat.
■
During operation there needs to be
sufficient area for air circulation above
the appliance and around it. Asafety
clearance of at least 50 cm must be
maintained, in the direction of the
main radiant heat, from the surface
of flammable materials located above
the hotplate, and at least 20 cm in all
other directions around the appliance.
- 4 -
09/2020
Copyright © 2020, Fast ČR, a.s.
■
While in operation, the appliance must
be located on akitchen countertop
with no cupboard above it.
■
Do not place any items on to the
appliance.
■
Do not cover the appliance or block
its vents. The lid of the appliance may
only be closed when the appliance is
disconnected from the power socket
and has cooled down completely.
This label located on the appliance
means:
ATTENTION: Hot surface
These surfaces may become hot during
use.
■
The temperature of accessible surfaces
on the appliance is high when the
appliance is in operation and, due to
residual heat, for acertain time after
operation. Do not touch the hot surface
of the appliance. There is adanger of
burns.
■
When the appliance is in operation,
the temperature of adjacent surfaces
may be higher.
■
Do not use the appliance without
apot or pan placed on the hotplate.
Regularly check the condition of the
food while the hotplate is running.
■
Only use pots and pans intended for
cooking.
■ Always make sure that the pot or pan
is correctly placed on the hotplate.
The handle of the cookware must
be in asafe position so as to prevent
brushing against it and overturning
the cookware.
■ Be very careful when cooking with oil
or shortening. Shortening or oil heated
to ahigh temperature may ignite.
■
When handling hot cookware, which
contains hot food or liquids, be
especially careful so as not to burn or
scald yourself.
■
When handling hot cookware, use
kitchen gloves.
■
The appliance must not be left without
supervision when in operation or when
connected to apower socket.
■
Always check that both the
temperature control knobs are set to
position MIN before connecting the
appliance to apower socket. Always
after finishing using the appliance, set
both the temperature control knobs
to position MIN and disconnect the
power cord from the power socket.
Keep in mind that the hotplates will
emit residual heat for acertain time
after they are used. Be especially
careful not to touch the hot surface of
the appliance.
Warning:
In the event that the surface
of the hotplate is cracked,
immediately turn the appliance
off and disconnect it from
the power socket to prevent
possible injury by electrical
shock. Never use the appliance
with acracked hotplate or if it
is damaged in any other way.
Hand the appliance over to an
authorised service centre for
repair.
- 5 -
09/2020
Copyright © 2020, Fast ČR, a.s.
■
Always set both the temperature
control knobs to position MIN and
disconnect the power cord from
the power socket when leaving the
appliance without supervision, when
not using it and before cleaning,
maintenance, moving or storing it.
Never move the appliance during
operation.
■
Allow the appliance to fully cool down
before moving, cleaning, maintenance
or storing it. Never move the appliance
when there is apot or pan on it or
unless it has cooled down completely.
■
Regularly clean the appliance after each
use according to the instructions in the
chapter Cleaning and maintenance.
Do not perform any maintenance on
the appliance except for cleaning as
described in this user’smanual.
■
To prevent the risk of injury by electrical
shock, do not submerge the appliance,
power cord or power plug into water
or another liquid.
■
Do not place heavy items on the power
cord. Make sure the power cord does
not hang over the edge of atable, that
it is not touching ahot surface or sharp
objects.
■
Disconnect the appliance from the
power socket by gently pulling the
plug of the power cord, and not the
power cord itself. Otherwise, this could
damage the power cord or the socket.
■ If the power cord is damaged, it must
be replaced by the manufacturer, its
service technician or by a similarly
qualified person, as this will prevent
adangerous situation from arising.
■
Do not use the appliance when it is
not functioning correctly or after it has
fallen on the floor, been submerged in
water or is damaged in any other way.
Hand it over to an authorised service
centre for inspection or repair.
■
In order to prevent a hazardous
situation arising, do not repair the
appliance yourself or modify it in
any way. Have all repairs performed
at an authorised service centre. By
tampering with the appliance, you risk
voiding your legal rights arising from
unsatisfactory performance or quality
warranty.
■ Prior to using this appliance, please read the user’smanual thoroughly, even in cases,
when one has already familiarised themselves with previous use of similar types of
appliances. Only use the appliance in the manner described in this user’smanual. Keep
this user’smanual in asafe place where it can be easily retrieved for future reference.
■
We recommend saving the original cardboard box, packaging material, purchase receipt
and responsibility statement of the vendor or warranty card for at least the duration of
the legal liability for unsatisfactory performance or quality. In the event of transportation,
we recommend that you pack the appliance in the original box from the manufacturer.
DESCRIPTION OF THE APPLIANCE
A1 Large hotplate, diameter 18 cm
A2 Indicator light
signals operation of large hotplate.
A3 Temperature control knob
serves to control the large hotplate.
A4 Small hotplate, diameter 15 cm
A5 Indicator light
signals operation of small hotplate.
A6 Temperature control knob
serves to control the small hotplate.
A7 Lid
BEFORE FIRST USE
■
Remove all packaging materials, including promotional tags and labels from the
appliance.
■
Wipe the surface of the appliance with aclean, lightly dampened cloth. Then wipe it dry.
OPERATING THE APPLIANCE
■
Place the appliance on akitchen countertop or on atable within reach of apower socket.
At the same time, make sure that all safety instructions are followed.
■ Open the lid A7.
■
Make sure that the temperature control knob A3 and A6 is set to position MIN and
that there are no foreign objects are located on the hotplate A1 and A4 and that its
surface is clean.
■
Fully unwind the power cord and connect it to apower socket. Since the appliance
heats up during operation, the power cord must be located in such away that it is not
touching the surface of the appliance.
■
Place apot or pan on the appropriate hotplate. To achieve optimal power consumption
and cooking time, use cookware with aflat base, the diameter of which corresponds to
the size of the hotplate. Place foodstuffs into the pot or pan.
■ Set the required temperature level using the appropriate temperature control knob.
For quickly bringing the contents to aboil, use the highest level MAX, for frying we
recommend setting level 5, for maintaining aboil, set the medium levels 3 to 4 and for
keeping food warm, use the low levels 1 to 2. The temperature level can be changed
at any time during operation as required. During operation the thermostat switches
the hotplate on and off to maintain the set temperature. The indicator light A2 and A5
signals the thermostat switching on and off.
■ Regularly check the condition of the food while the hotplate is running. Do not leave
the appliance without supervision when it is in operation.
Note:
When first turned on, asmall amount of smoke may be emitted. This is an
entirely normal event, which will disappear after afew minutes.
- 6 -
09/2020
Copyright © 2020, Fast ČR, a.s.
■ When the meal is finished, set the appropriate temperature control knob to position
MIN and disconnect the power cord from the power socket.
■
Always after finishing using the appliance, make sure that both the temperature control
knobs A3 and A6 are set to position MIN and that the power cord is disconnected
from the power socket.
■
Allow the appliance to fully cool down and then clean it according to the instructions in
chapter Cleaning and maintenance. Keep in mind that the appliance will emit residual
heat for acertain time after it is used. Do not touch the hot surface. There is adanger of
burns. Never move the appliance unless it has cooled down completely.
CLEANING AND MAINTENANCE
■
Clean the appliance after every use. Makes sure that dried on food or other residues do
not accumulate on it. Before cleaning it, always set the temperature control knob A3
and A6 to position MIN, disconnect the power cord from the power socket and allow
the appliance to cool down completely.
■ To clean the hotplate A1 and A4, use asoft, lightly dampened textile. Then wipe the
hotplate A1 and A4 dry.
■
To clean the surface around the hotplates A1 and A4 use asoft, lightly dampened textile.
In the event of greater soiling, use asmall amount of neutral kitchen detergent. Remove
any remaining detergent using aclean, lightly dampened cloth. Then thoroughly wipe
the cleaned surface until dry.
■ Do not use steel wool, solvents, cleaning products with an abrasive effect, etc. to clean
the appliance. Otherwise the surface coat of the appliance may be damaged.
■ To prevent the risk of injury by electrical shock, do not submerge the appliance, power
cord or power plug into water or another liquid.
■ Discolouration of the surface of the appliance may occur after acertain period of use.
However, this does not have any effect on the functionality of the appliance.
STORAGE
■
Place the cooled and thoroughly cleaned appliance in aclean, dry place out of
children’sreach.
TECHNICAL SPECIFICATIONS
Rated voltage range .......................................................................................................................... 230 V
Rated frequency..................................................................................................................................50 Hz
Rated power input ........................................................................................................................ 2,500 W
Weight ...................................................................................................................................................5.4 kg
Changes to text and technical parameters are reserved.
INSTRUCTIONS AND INFORMATION REGARDING THE DISPOSAL
OF USED PACKAGING MATERIALS
Dispose of used packaging material at asite designated for waste in your municipality.
DISPOSAL OF USED ELECTRICAL AND ELECTRONIC EQUIPMENT
This symbol on products or original documents means that used electric
or electronic products must not be added to ordinary municipal waste.
For proper disposal, renewal and recycling hand over these appliances
to determined collection points. Alternatively, in some European Union
states or other European countries you may return your appliances to
the local retailer when buying an equivalent new appliance.
Correct disposal of this product helps save valuable natural resources
and prevents potential negative effects on the environment and human
health, which could result from improper waste disposal. Ask your local authorities or
collection facility for more details.
In accordance with national regulations penalties may be imposed for the incorrect
disposal of this type of waste.
For business entities in European Union states
If you want to dispose of electric or electronic appliances, ask your retailer or supplier for
the necessary information.
Disposal in other countries outside the European Union
This symbol is valid in the European Union. If you wish to dispose of this product, request
the necessary information about the correct disposal method from the local council or
from your retailer.
This product meets all the basic requirements of EU directives related to it.
