Frigidaire FGSC2335TFB side-by-side refrigerator

User Manual - Transcript

• Page 1 - English - : TABLE OF CONTENTS wwwfrigidairecom USA 18009449044 wwwfrigidaireca Canada 18002658352 All about the Use amp Care of your Refrigerator A07201402 October 2018 Important Safety Instructions 2 Features At A Glance 4 Installation 5 Door Removal Instructions 7 Handle Installation 9 Connecting the Water Supply 10 Controls 12 Storage Features 19 Automatic Ice amp Water Dispenser 21 Changing the Filter 24 Normal Operating Sounds amp Sights 26 Care amp Cleaning 27 Before You Call 29 Major Appliance Warranty 33
• Page 2 - English - : Doors Handles are secure and tight Door seals completely to cabinet on all sides Freezer door is level across the top Leveling Refrigerator is level sidetoside and tilted ¼ 6mm fronttoback Toe grille is properly attached to refrigerator Cabinet is setting solid on all corners Electrical Power House power turned on Refrigerator plugged in Ice Maker House water supply connected to refrigerator No water leaks present at all connections recheck in 24 hours Ice maker is turned ON Ice amp water dispenser operates correctly Frontltermustbeushwithlter housing select models Final Checks Shipping material removed Fresh food and freezer temperatures set Crisper humidity controls set Registration card sent in Installation Checklist Denitions This is the safety alert symbol It is used to alert you to potential personal injury hazards Obey all safety messages that follow this symbol to avoid possible injury or death For your Safety DO NOT store or use gasoline or other ammableliquidsinthevicinityofthisor any other appliance Read product labels for warningsregardingammabilityandother hazards DO NOT operate the refrigerator in the presence of explosive fumes Avoid contact with any moving parts of automatic ice maker Remove all staples from the carton Staples can cause severe cuts and also destroy nishesiftheycomeincontactwithother appliances or furniture Child Safety Destroy or recycle the carton plastic bags and any exterior wrapping material immediately after the refrigerator is unpacked Children should NEVER use these items to play Cartons covered with rugs bedspreads plastic sheets or stretch wrap may become airtight chambersandcanquicklycausesuffocation Proper Disposal of your Refrigerator or Freezer Risk of child entrapment Child entrapment and suffocation are not problems of the past Junked or abandoned refrigerators or freezers are still dangerous even if they will sit for just a few days If you are getting rid of your old refrigerator or IMPORTANT SAFETY INSTRUCTIONS DANGER DANGER indicates an imminently hazardous situation which if not avoided will result in death or serious injury WARNING WARNING indicates a potentially hazardous situation which if not avoided could result in death or serious injury CAUTION CAUTION indicates a potentially hazardous situation which if not avoided may result in minor or moderate injury IMPORTANT IMPORTANT indicates installation operation or maintenance information which is important but not hazardrelated WARNING Please read all instructions before using this refrigerator
• Page 3 - English - : Grounding type wall receptacle Do not under any circumstances cut remove or bypass the grounding prong Power cord with 3prong gounded plug Electrical information The refrigerator must be plugged into its own dedicated 115 Volt 60 Hz 15 Amp AC only electrical outlet The power cordoftheapplianceisequippedwitha threeprong grounding plug for your protec tion against electrical shock hazards It must be plugged directly into a properly grounded three prong receptacle The receptacle must be installed in accordance with local codes andordinancesConsultaqualiedelectri cian Avoid connecting refrigerator to a WARNING These guidelines must be followed to ensure that safety mechanisms in this refrigerator will operate properly IMPORTANT Pressing and holding the OnOff button for three seconds located on the temperature control panel Electronic controls or turning the Freezer and Fresh Food controls to 0 Mechanical controls will disable your refrigerators cooling system but does not disconnect the power to the lighting system and other electrical components To turn off power to your refrigerator you must unplug the power cord from the electrical outlet CAUTION To avoid personal injury or property damage handle tempered glass shelves carefully Shelves may break suddenly if nicked scratched or exposed to sudden temperature change Ground Fault Interrupter GFI circuit Do not use an extension cord or adapter plug If the power cord is damaged it should be replaced by an authorized service technician to prevent any risk Never unplug the refrigerator by pulling on thepowercordAlwaysgriptheplugrmly and pull straight out from the receptacle to prevent damaging the power cord Unplug the refrigerator before cleaning and before replacing a light bulb to avoid electrical shock Performance may be affected if the voltage varies by 10 or more Operating the refrig eratorwithinsufcientpowercandamage the compressor Such damage is not covered under your warranty Do not plug the unit into an electrical outlet con trolled by a wall switch or pull cord to prevent the refrigerator from being turned off accidentally freezer please follow the instructions below to help prevent accidents Proper Disposal of RefrigeratorsFreezers We strongly encourage responsible appliance recyclingdisposal methods Check with your utility company or visit wwwenergystargovrecycle for more information on recycling your old refrigerator Before you throw away your old refrigeratorfreezer Remove doors Leave shelves in place so children may not easily climb inside Have refrigerant removed by a qualiedservice technician IMPORTANT SAFETY INSTRUCTIONS IMPORTANT CFCHCFC Disposal Your old refrigerator may have a cooling system thatusedCFCsorHCFCschlorouorocarbons orhydrochlorouorocarbonsCFCsandHCFCs are believed to harm stratospheric ozone if released to the atmosphere Other refrigerants may also cause harm to the environment if released to the atmosphere If you are throwing away your old refrigerator make sure the refrigerant is removed for properdisposalbyaqualiedtechnicianIf you intentionally release refrigerant you may besubjecttonesandimprisonmentunder provisions of environmental legislation
• Page 4 - English - : FEATURES AT A GLANCE Features may vary according to model Fixed Door Bin Door Bin Fixed Door Bin Door Bin Dairy Door Water Filter Air Filter Crisper Pan and Cover Deli Drawer Large Basket Door Bin Door Bin Door Bin Door Bin Wire Shelf Wire Shelf Ice Maker Glass Shelf Glass Shelf Slide Out Basket Wire Shelf IMPORTANT Features not included with your refrigerator can be purchased at wwwfrigidairecom or by calling 18009449044
• Page 5 - English - : INSTALLATION This Use amp Care Guide provides general operating instructions for your model Use the refrigerator only as instructed in this Use amp Care Guide Before starting the refrigerator follow these important rst steps Location Choose a place that is near a grounded electrical outlet Do Not use an extension cord or an adapter plug If possible place the refrigerator out of direct sunlight and away from the range dishwasher or other heat sources Therefrigeratormustbeinstalledonaoor that is level and strong enough to support a fully loaded refrigerator Consider water supply availability for models equippedwithanautomaticicemakerIf you do not hook up water to the refrigerator remember to turn the ice maker off Installation Installation clearances Allow the following clearances for ease of installation proper air circulation and plumbing and electrical connections SidesampTop ⅜inch Back 1 inch Toe Grille Installation and Removal To install toe grille 1 Open both doors Slide left and right sides of toe grille over lower hinges of refrigerator 2 Whilepushingtoegrillermlyagainstcabinet fasten bottom clips of toe grille to cabinet 3 Fasten top clips to cabinet 4 Close the doors Fasten right and left side clips into groove of bottom hinge To remove toe grille 1 With both doors closed unfasten right and left side clips of toe grille from bottom hinge groove 2 OpenbothdoorsPressrmlyontopof toe grille until top of toe grille pops off 3 Pull toe grille outward toward your body and off of lower hinges Installing Toe Grille Removing Toe Grille CAUTION Do Not install the refrigerator where the temperature will drop below 55F 13C or rise above 110F 43C The compressor will not be able to maintain proper temperatures inside the refrigerator Do Not block the toe grille on the lower frontofyourrefrigeratorSufcientair circulation is essential for the proper operation of your refrigerator NOTE If your refrigerator is placed with the door hinge side against a wall you may have to allow additional space so the door can be opened wider
• Page 6 - English - : INSTALLATION Raise Door Opening Your refrigerator should be positioned to allow easy access to a counter or table when removing food For best use of drawers and freezer baskets the refrigerator should be in a position where both the refrigerator and freezer doors can be fully opened Guidelines for nal positioning of your refrigerator All four corners of the cabinet must rest rmlyontheoor The cabinet should be level at the front and rear The sides should tilt ¼ inch 6 mm from front to back to ensure that doors close and seal properly Doors should align with each other and be level All of these conditions can be met by raising or lowering the adjustable front rollers To level the cabinet using the front rollers 1 Open both doors and remove the toe grille see Toe Grille Installation and Removal in the Installation section 2 Closethedoorsanduseaatblade screwdriveror⅜inchsocketwrenchto raise or lower the front rollers 3 Ensure both doors are bindfree with their seals touching the cabinet on all 4 sides Set Screw some models Hinge Hinge Flange Open Door 716quot Wrench and 332quot Hex Key some models Door Stop Flange 6 Replacethetoegrillebyttingitinto place see Toe Grille Installation and Removal in the Installation section Raise Door Raise Door Door Door To level the doors using the adjustable lower hinge some models 1 Before leveling either door remove set screw that locks door height into position The door cannot be adjusted without set screw removed 2 If the refrigerator door is lower than the freezer door raise the refrigerator door by turning the adjustment screw clockwise using a inch wrench See illustration 3 If the freezer door is lower than the refrigerator door raise the freezer door by turning the adjustment screw clockwise using a inch wrench See illustration 4 After leveling verify door stop contacts lower hinge and top of door does not contact upper hinge through full movement of door from fully closed to fully open 5 Reinstall set screw locking the door height NOTE The refrigerator doors are designed to shut by themselves within a 20 degree opening
• Page 7 - English - : DOOR REMOVAL INSTRUCTIONS To prepare for removing the doors 1 Make sure the electrical power cord is unplugged from the wall outlet 2 Open both doors and remove the toe grille as explained in the Installation Instructions that came with your appliance 3 Remove any food from the door shelves 4 Close the doors To remove the refrigerator top hinge cover 1 Remove the three screws from each cover over the top door hinges 2 Lift hinge cover straight up and off To remove the refrigerator door 1 Trace lightly around the doors top hinge with a pencil This makes reinstallation easier Rear Cover Screw Front Cover Screws Top Hinge Cover Hinge Screws Top Hinge Phillips Head Tools Necessary Socket Wrench Set Adjustable Wrench 38quot Fixed Wrench Top Hinge Screw Bottom Hinge Screw Top Hinge Cover Front Screw Top Hinge Cover Rear Screw or or 2 Remove the 2 screws from the top hinge Lift the door off of the bottom hinge and set it aside
• Page 8 - English - : To remove the freezer top hinge cover 1 Remove the 2 screws from each cover over the top door hinges 2 Lift hinge cover straight up and off Front Cover Screws Rear Cover Screw Top Hinge Cover Hinge Screws MultiWire Cable Top Hinge To remove the freezer door 1 Detach the multiwire cable connector located above the top hinge Grasp both sides of the connector rmlyand pull apart 2 Trace lightly around the hinge with a pencil This makes reinstallation easier 3 Detach the water tube from the connector located below the freezer door The Door Hinge Assembly Screws Water Line Tubing NonAdjusting Hinge some models Closer Pin Hinge Door Water Line Tubing Screws Hinge Assembly Adjustable Hinge some models connector releases when you press its outer sleeve inward 4 Remove the screws from the top hinge and pull the multiwire cable through it Lift the door off of the bottom hinge 5 Remove the 2 bottom hinge screws and hinge if necessary DOOR REMOVAL INSTRUCTIONS Adjustable Hinge some models Door Hinge Assembly Closer Pin Hinge Screws 3 Remove the 2 bottom hinge screws and hinge if necessary CAUTION Be sure doors are set aside in a secure position where they cannot fall and cause personal injury To reinstall the refrigerator door reverse the above steps To Disconnect 1 Press outer ring against face of fitting 2 Pull to remove tube Insert tube and push until mark touches face of fitting To Connect 6 Lay the door on its side to avoid damage to the water tube extending from the bottom hinge To reinstall the freezer door reverse the above steps
• Page 9 - English - : HANDLE INSTALLATION Ensure Handle Set Screws are Facing Each Other with Doors Closed 1 Remove handles from protective packaging 2 Position freezer handle end caps over upper and lower preinstalled shoulder bolts A that are fastened into door ensuring the holes for the set screws are facing towards the refrigerator door 3 Whileholdinghandlermlyagainst door fasten furthermost upper and furthermost lower Allen set screws B with supplied Allen wrench 4 Firmly tighten the inside Allen set screws 5 Repeat steps 2 through 4 to install refrigerator handle Ensure the holes for the set screws are facing towards the freezer door Freezer Upper End Cap Refrigerator Upper End Cap Frigidaire Gallery Refrigerator Lower End Cap Freezer Lower End Cap Freezer Upper End Cap Refrigerator Lower End Cap Refrigerator Upper End Cap Freezer Lower End Cap Frigidaire Professional A B A B B A B A CAUTION Wear gloves and safety goggles and use extreme CAUTION when installing these handles The rounded end of the handles may be sharp some models IMPORTANT To ensure proper installation of handles please review these instructions and illustrations thoroughly prior to installing the handles NOTE All set screws should be tightened and subushAllensetscrewshouldbe seated just below the surface of the end cap of handle end cap The end caps should be drawn tight to freezer and refrigerator doors with no gaps
• Page 10 - English - : CONNECTING THE WATER SUPPLY Before Installing The Water Supply Line You Will Need BasicToolsadjustablewrenchatblade screwdriver and Phillips TM screwdriver Access to a household cold water line with water pressure between 30 and 100 psi A water supply line made of ¼ inch 64 mm OD copper or stainless steel tubing To determine the length of tubing needed measure the distance from the ice maker inlet valve at the back of the refrigerator to your cold water pipe Then add approximately 7 feet 21 meters so the refrigerator can be moved out for cleaning as shown A shutoff valve to connect the water supply line to your household water system Do not use a selfpiercing type shutoff valve Donotreusecompressionttingoruse thread seal tape To Connect Water Supply Line To Ice Maker Inlet Valve 1 Disconnect refrigerator from electric power source 2 Place end of water supply line into sink or bucketTurnONwatersupplyandush supply line until water is clear Turn OFF water supply at shutoff valve 3 Remove plastic cap from water valve inlet and discard cap 4 If you use copper tubing Slide brass compression nut then ferrule sleeve onto water supply line Push water supply line into water valve inlet as far as it will go ¼ inch64 mm Slide ferrule sleeveintovalveinletandngertighten compression nut onto valve Tighten another half turn with a wrench DO NOT over tighten See Figure 1 If you use braided exible stainless steel or polyline tubing The nut is already assembled on the tubing Slide nutontovalveinletandngertighten nut onto valve Tighten another half turn with a wrench DO NOT over tighten See Figure 2 A compression nut and ferrule sleeve for connecting a copper water supply line to the ice maker inlet valve WARNING To avoid electric shock which can cause death or severe personal injury disconnect the refrigerator from electrical power before con necting a water supply line to the refrigerator CAUTION To Avoid Property Damage Copper or Stainless Steel braided tubing is recommended for the water supply line Water supply tubing made of ¼ inch plastic is not recommended to be used Plastic tubing greatly increases the poten tial for water leaks and the manufacturer will not be responsible for any damage if plastic tubing is used for the supply line DO NOT install water supply tubing in areas where temperatures fall below freezing Chemicals from a malfunctioning softener can damage the ice maker If the ice maker is connected to soft water ensure that the softener is maintained and work ing properly NOTE Check with your local building authority for recommendations on water lines and associated materials prior to installing your new refrigerator Depending on your local state building codes Frigidaire recom mends for homes with existing valves its Smart Choice water line kit 5304490728 with a 6 ft Stainless Steel Water Line or 5304493869 with a 6 ft Polyline Water Line and for homes without an existing valve Frigidaire recommends its Smart Choice water line kit 5304490717 with a 20 ft copper water line with selftapping saddle valve Please refer to wwwfrigidaire comstore for more information IMPORTANT Ensure that your water supply line connec tions comply with all local plumbing codes
• Page 11 - English - : Figure 1 Plastic Water Tubing to Ice Maker Fill Tube Steel Clamp Brass Compression Nut Ferrule Sleeve Copper water line Water Valve Bracket Valve Inlet Water Valve Copper water line from household water supply Include enough tubing in loop to allow moving refrigerator out for cleaning CONNECTING THE WATER SUPPLY 5 With steel clamp and screw secure water supply line copper tubing only to rear panel of refrigerator as shown 6 Coil excess water supply line copper tubing only about 2½ turns behind refrigerator as shown and arrange coils so they do not vibrate or wear against any other surface 7 Turn ON water supply at shutoff valve and tighten any connections that leak 8 Reconnect refrigerator to electrical power source Figure 2 Steel Clamp Braided Flexible Stainless Steel Water Line Water Valve Bracket Valve Inlet Water Valve 6 ft 18 Meters Braided flexible stainless steel water line from household water supply Plastic Water Tubing to Ice Maker Fill Tube Include enough tubing in loop to allow moving refrigerator out for cleaning IMPORTANT After connecting the water supply refer to How to Prime the Water Supply System for important information about priming an empty water supply system To ensure that your water dispenser works properly the water supply system must becompletelylledwithwaterwhen yourrefrigeratorisrstconnectedtothe household water supply line
• Page 12 - English - : CONTROLS FRIGIDAIRE GALLERY User Interface varies by model NOTE The recommended settings for a product installed in a kitchen is 37ºF for the fresh food copartment and 0ºF for the freezer Operating the Controls Press Options key Use Arrow keys ᴠ to scroll the menu selections Use the or keys to change the option from onoffchange temperature or mode ºFºC Use the Options key to exit and save changes Quick Freeze On Off Activates a faster rate for freezing food Deactivates after 12 hours Ice Maker On Off Press and hold for three seconds to toggle the ice maker in the freezer compartment on and off Display On Off Toggles the temperature displays On and Off Refrigeration Temp Allows the temperature set points to be adjusted Control tempera tures range from 33F 1C to 47F 8C Freezer Temp Allows the temperature setpoints to be adjusted Control temperatures range from 6F 21C to 6F 15C Mode F C Toggles display from Fahrenheit to Celsius
• Page 13 - English - : CONTROLSFRIGIDAIRE GALLERY User Interface varies by model Operating the Controls Press Options key Use Arrow keys ᴠ to scroll the menu selections Press and hold Set key for 3 seconds Use the Options key to exit and save changes power off Press and hold Set for 3 seconds to turn off the cooling system It also turns off the ice maker and all dispenser functions The display will read power off Press and hold Set to turn power on water lter DisplaysthecurrentstatusofthewaterlterGood Order or ReplaceToresetthelterstatustoGood press and hold the Set key for 3 seconds air lter DisplaysthecurrentstatusoftheairlterGood Order or ReplaceToresetthelterstatustoGood press and hold the Set key for 3 seconds default settings While in the default option press and hold the Set key for 3 seconds to reset all refrigerator settings to their factory default settings
• Page 14 - English - : CONTROLS FRIGIDAIRE GALLERY User Interface varies by model Operating the Controls To activate features press the corresponding icon key on the display water Press the Water key to select water Indicator light will be illuminated above the active feature cube Press the Cube key to select cubed ice Indicator light will be illumi nated above the active feature crush Press the Crush key to select crushed ice Indicator light will be illuminated above the active feature control locked Press and hold for 3 seconds to lock the display While in the locked state you will not be able to change any settings on the display nor dispense ice and water The Control Lockedindicatorwillashand illuminate and an audible warning tone will sound Press and hold a second time to unlock the display light Toggles dispenser light On and Off
• Page 15 - English - : CONTROLS Alarms Sabbath Mode The Sabbath Mode is a feature that disables portions of the refrigerator and its controls in accordance with observance of the weekly Sabbath and religious holidays within the Orthodox Jewish community Sabbath Mode is turned ON and OFF by pressing and holding both the and for vesecondsThedisplayshowsSbwhilein Sabbath mode In the Sabbath Mode the High Temp alarm is active for health reasons For example if the door is left ajar the High Temp alarm is activated The refrigerator will function normally once the door is closed without any violation of the SabbathHolidays The High Temp alarm is permitted when cabinet temperature is outside the safe zone for 20 minutes The alarm silences itself after 10 minutes while the High Temp icon stays lit until the Sabbath mode is exited For further assistance guidelines for proper usage and a complete list of models with the Sabbath feature please visit the web at httpwwwstarkorg Power Failure In the event of a power failure the power fail alert will be illuminated Press alarm reset to acknowledge the alarm Other modes may be turned off until the alarm is acknowledged When the power fail alert is acknowledged the refrigerator will resume normal operation The high temp alarm may also be illuminated until a safe operating range temperature has been reached Freezer Temp If the freezer temperature reaches 26F or greater the alarm will sound and the temperaturewillashYoucan disable the alarm by pressing the set key but the High Temp indicator will illuminate until the temperature goes below 26F Fresh Food Temp If the fresh food temperature reaches 55F or greater the alarm will sound and the temperaturewillashYoucan disable the alarm by pressing the set key but the High Temp indicator will illuminate until the temperature goes below 55F Door Ajar If the freezer or fresh food doors have been left open for veminutesormoreanalarm will sound and the door ajar indicator will illuminate on the display Press the set key to reset any system alarms Flapper When Cube or Crush is selectediftheapperorice chute door is being held open by a jammed ice cube an alarm will sound for two minutes The alarm will reset after two minutes or when the ice cube is removed and the set key is pressed to reset FRIGIDAIRE GALLERY NOTE While in Sabbath Mode neither the lights dispenser nor the control panel will work until Sabbath Mode is deactivated Refrigerator stays in Sabbath Mode after power failure recovery It must be deacti vated with the buttons on the control panel NOTE Although you have entered the Sabbath Mode the ice maker will complete the cycle it had already initiated The ice cube compartment will remain cold and new ice cubes can be made with standard trays
• Page 16 - English - : User Interface InDoor Controls options may vary POWER ONOFF Press and hold for three seconds to turn off the cooling system It also turns off the ice maker and all dispenser functions The display will read OFF DEFAULT SETTINGS Press and hold for three seconds to reset all refrigerator settings to their factory default settings ICE MAKER ONOFF Press and hold for 3 seconds to toggle the ice maker in the freezer compartment ON or OFF POWERPLUS FREEZE Activates a faster rate for freezing food and increases ice production in the freezer Deactivates after 12 hours AIR FILTER Displays the current status of the air lterGOOD ORDER or REPLACE ToresetthelterstatustoGOOD press and hold for three seconds WATER FILTER Displays the current status of the water lterGOOD ORDER or REPLACE To resetthelterstatustoGOOD press and hold for three seconds MUTE ALARM Tones emitted by each key press can be turned off based on user preference The sounds are muted when the red indicator is lit Warning signals will stay active REFRIGERATOR TEMP Allows the temperature set points to be adjusted Press the or indicator to adjust the temperature to the desired setting Control temperatures range from 33F 1C to 43F 6C FREEZER TEMP Allows the temperature set points to be adjusted Press the or indicator to adjust the temperature to the desired setting Control temperatures range from 6F 21C to 4F 16C CONTROLS FRIGIDAIRE PROFESSIONAL
• Page 17 - English - : CONTROLS FRIGIDAIRE PROFESSIONAL Alarms Power Failure In the event of a power failure the POWER FAIL alert will be illuminated Press MUTE ALARM to acknowledge the alarm Other modes may be turned off until the alarm is acknowledged While a POWER FAIL alert is displayed on the control panel the unit will continue normal operation The POWER FAIL alert on the control panel will be removed once the user acknowledges the power fail condition by pressing MUTE ALARM or DEFAULT SETTINGS Freezer Temp If the freezer temperature reaches 26F or greater the alarm will sound and the temperaturewillashandthedispenser control will display HIGH TEMP DETECTED You can disable the alarm by pressing MUTE ALARM but the HIGH TEMP DETECTED indicator will illuminate until the temperature goes below 26F Fresh Food Temp If the fresh food temperature reaches 55F or greater the alarm will sound and the temperaturewillashandthedispenser control will display HIGH TEMP DETECTED You can disable the alarm by pressing MUTE ALARM but the HIGH TEMP DETECTED indicator will illuminate until the temperature goes below 55F Door Ajar If the freezer or fresh food doors have been leftopenforveminutesormoreanalarm will sound and the door ajar indicator will illuminate on the display Press MUTE ALARM to reset any system alarms Flapper When CUBES or CRUSHED is selected iftheapperoricechutedoorisbeing held open by a jammed ice cube an alarm will sound for two minutes and the current selection will blink on the dispenser control The alarm will reset after two minutes or when the ice cube is removed Dispenser Controls options may vary WATER Press the WATER key to select water CUBES Press the CUBES key to select cubed ice CRUSHED Press the CRUSHED key to select crushed ice light Toggles dispenser light on and off
• Page 18 - English - : CONTROLS FRIGIDAIRE PROFESSIONAL Sabbath Mode The Sabbath Mode is a feature that disables portions of the refrigerator and its controls in accordance with observance of the weekly Sabbath and religious holidays within the Orthodox Jewish community Sabbath Mode is turned ON and OFF by simultaneously pressing and holding both the freezer and the refrigerator for vesecondsThedisplayshowsSbwhilein Sabbath mode In the Sabbath Mode the HIGH TEMP alarm is active for health reasons For example if the door is left ajar the HIGH TEMP alarm is activated The refrigerator will function normally once the door is closed without any violation of the SabbathHolidays The HIGH TEMP alarm is permitted when cabinet temperature is outside the safe zone for 20 minutes The alarm silences itself after 10 minutes while the HIGH TEMP icon stays lit until the Sabbath mode is exited For further assistance guidelines for proper usage and a complete list of models with the Sabbath feature please visit the web at httpwwwstarkorg NOTE While in Sabbath Mode neither the lights dispenser nor the control panel will work until Sabbath Mode is deactivated Refrigerator stays in Sabbath Mode after power failure recovery It must be deacti vated with the buttons on the control panel NOTE Although you have entered the Sabbath Mode the ice maker will complete the cycle it had already initiated The ice cube com partment will remain cold and new ice cubes can be made with standard trays
• Page 19 - English - : STORAGE FEATURES Cantilever Glass Shelf Cantilever Shelf Adjustment Refrigerator shelves are easily adjusted to suit individual needs Before adjusting the shelves remove all food Cantilever shelves are supported at the back of the refrigerator To adjust cantilever shelves 1 Lift front edge up 2 Pull shelf out Replace the shelf by inserting the hooks at rear of the shelf into the wall bracket Lower the shelf into the desired slots and lock into position Glass shelves some models catch and hold accidental spills In some models the glass shelves slide out for easy access to food and for fast cleaning The shelves slide out indepen dently of their mounting brackets Just pull the front of the shelf forward Shelves can be extended as far as the stopper will allow but are not removable from their mounting brackets Door storage Door bins and shelves are provided for convenient storage of jars bottles and cans Frequentlyuseditemscanbequicklyselected Some models have door bins that can accommodate gallonsized plastic drink containers and economysized jars and containers Some bins are adjustable for maximum storage capacity Crisper Humidity Control Higher Humidity Lower Humidity Cool Drawer some models SomemodelsareequippedwithaCoolDrawer for storage of luncheon meats spreads cheeses and other deli items This drawer does not have a separate temperature control Crisper Drawer Crispers Crispers allow you theexibilitytostore any manner of items including fruits vegetables nuts etc Crispers do not feature humidity controls Fresh Drawers with Humidity Control some models The fresh drawers located under the bottom refrigerator shelf are designed for storing fruits vegetables and other fresh produce The fresh drawers feature humidity control which allows you to adjust the humidity within the drawer This can extend the life of fresh vegetables that keep best in high humidity Wash items in clear water and remove excess water before placing them in the crispers Items with strong odors or high moisture content should be wrapped before storing The dairy compartment which is warmer than the general food storage section is intended for short term storage of cheese spreads or butter CAUTION To avoid personal injury or property dam age handle tempered glass shelves care fully Shelves may break suddenly if nicked scratched or exposed to sudden tempera ture change Allow the glass shelves to sta bilize to room temperature before cleaning Do not wash in dishwasher NOTE Leafy vegetables keep best when stored with the humidity control set on Higher Humidity or in a drawer without a Humidity Control This keeps incoming air to a minimum and maintains maximum moisture content
• Page 20 - English - : Chill Drawer some models SomemodelsareequippedwithaChillDrawerChillDrawertemperaturescanbeadjustedby sliding the Chill Drawer Temperature Control in either direction Use this pan for short term storage of bulk meat items If meats are to be kept longer than one or two days they should be frozenTheChillDrawerisxedandcannotbemovedupordownIffruitsorvegetablesareto be stored in the Chill Drawer set the Chill Drawer Temperature Control to a warmer setting to prevent freezing Colder Warmer Chill Drawer with Temperature Control STORAGE FEATURES
• Page 21 - English - : AUTOMATIC ICE amp WATER DISPENSER Priming the water supply system Ice maker operation amp care After the refrigerator is installed properly and has cooled for several hours the ice maker can produce ice within 24 hours The ice maker will lltheicebinfromtherearYoumustdispense some ice to force the ice forward in the bin Thiswillallowthebintollcompletely Ice Maker and Storage Bin Capacity This ice maker should produce 25 to 3 pounds of ice per 24 hours depending on usage conditions Ice is produced at a rate of 10 cubes every 75 to 90 minutes How much ice can be stored in the ice bin When completely full the bin in standard depth units will hold about 11 pounds of ice total weight of ice and bin will be about 15 pounds The bin in counter depth units will hold about 85 pounds of ice total weight of ice and bin will be about 12 pounds Turning the ice maker on and off Ice production is controlled by the ice makers OnOff feature on the control panel Pressing and holding the OnOff button toggles the ice maker OnOff 1 Beginllingthesystembypressingand holding a drinking glass against the water dispenser paddle 2 Keep the glass in this position until water comes out of the dis penser It may take about 1½ minutes 3 Continue dispensing water for aboutfourminutestoushthesystemand plumbing connections of any impurities stopping to empty the glass as necessary Dispenser varies by model CAUTION For proper dispenser operation recom mended water supply pressure should fall between 30 psi and 100 psi Excessive pres sure may cause the system to malfunction NOTE The water dispenser has a builtin device that shutsoffthewaterowafterthreeminutes of continuous use To reset this shutoff device simply release the dispenser paddle NOTE Dispensed water is not chilled For colder water add ice to cup or container before dispensing water NOTE The ice maker also has a builtin plastic signal arm that automatically stops ice production when the ice bin is full This signal arm should not be used to manually stop the ice maker IMPORTANT Turning off the ice maker simply disables ice making You will still be able to dispense existing ice and you will still be able to dispense water
• Page 22 - English - : Ice makerdispenser tips If your refrigerator is not connected to a water supply or the water supply is turned off turn off the ice maker as described in the previous section The following sounds are normal when the ice maker is operating Motor running Ice dropping into ice bin Water valve opening or closing Running water When dispensing ice you will hear a snapping or clicking sound when the ice chute opens and closes Ifyouneedalargequantityoficeatone time it is best to get cubes directly from the ice bin Ice cubes stored too long may develop an oddavorEmptytheicebinasexplained below When dispensing cubed ice it is normal to haveasmallquantityoflittlepiecesalong with the whole cubes To avoid splashing dispense ice into your containerbeforeaddingliquids Itisnormalforicetolltothetopofthe ice bin Using the ice maker after installation Beforemakingiceforthersttimebesure to prime the water supply system Air in new plumbing lines can result in two or three empty ice maker cycles Furthermore if the system isnotushedthersticecubesmaybe discoloredorhaveanoddavor AUTOMATIC ICE amp WATER DISPENSER IMPORTANT Your ice maker is turned on at the factory so it can work as soon as you install your refrigerator If you cannot connect a water supply set the ice makers OnOff feature toOffotherwisetheicemakersllvalve may make a loud chattering noise when it attempts to operate without water IMPORTANT Small ice cubes or ice chips jamming in the icemakermaybeasignthatyourwaterlter needs changing If you have a side mounted ice maker you may also experience hol low cubes partially frozen cubes with water inside When these cubes are harvested they break open and spill water over the other ice cubes in the ice container forming a solid massoficeAsthewaterlternearstheend of its useful life and becomes clogged with particles less water is delivered to the ice maker during each cycle The ice maker cant lleverycubeintheicemakermoldleading to small cubes or chips that can get caught between the ice ejector blades and the strip per Remember if your ice maker is jamming with small ice cubes or its been six months or longer since you last changed your water lterreplacethewaterlterwithanewone Poorqualityhouseholdwatermayrequirethe ltertobechangedmorefrequently CAUTION If the water supply to your refrigerator is softened be sure the softener is properly maintained Chemicals from a water softener can damage the ice maker
• Page 23 - English - : AUTOMATIC ICE amp WATER DISPENSER Cleaning the storage bin Clean the ice maker and ice bin at regular intervals especially prior to vacation or moving 1 Turn off the ice maker 2 Remove the ice bin by lifting up slightly on the front of the bin and pulling it straight out of the ice maker housing Removing Ice Bin 3 Empty and carefully clean the ice bin with mild detergent Do not use harsh or abrasive cleaners Rinse with clear water 4 Allow the ice bin to dry completely before replacing in the freezer 5 Remove ice chips and clean the ice bin shelf and the freezer door chute 6 Replace the ice bin Turn the ice maker on to resume ice production Remove and empty the ice bin if An extended power failure one hour or longer causes ice cubes in the ice bin to melt and refreeze together after power is restored jamming the dispenser mechanism Youdonotusetheicedispenserfrequently Ice cubes will freeze together in the bin jamming the dispenser mechanism Remove the ice bin and shake to loosen the cubes or clean as explained above CAUTION Besuretormlysupporttheundersideoftheice bin when removing it from the refrigerator A stan dard depth bin that is full of ice will weigh about 15 pounds total and a counter depth bin that is full of ice will weigh about 12 pounds total CAUTION NEVER use an ice pick or similar sharp instrument to break up the ice This could damage the ice bin and dispenser mechanism To loosen stuck ice use warm water Before replacing the ice bin make sure it is completely dry IMPORTANT When removing or replacing the ice bin ensure that the ice bin is fully seated before closing the freezer door If the ice bin is not positioned correctly the refrigerator will not dispense ice The freezer door also may not close properly causing warm air to leak into the freezer compartment
• Page 24 - English - : Air Filter some models Theairlterislocatedatthetopofthefresh foodcompartmentnexttothewaterlter Replacing the Air Filter Ingeneralyoushouldchangetheairlter everysixmonthsthelterstatuslighton the control panel prompts you to replace thelteraftersixmonthstoensureoptimal lteringofrefrigeratorodorsYoumaywant to adjust this time period depending on the types and amounts of food you typically store in your refrigerator To replace your PureSource Ultra TM airlter 1 Pulltheairlterhousingstraightout 2 Removetheoldlteranddiscardit 3 Unpackthenewlterandplaceitinside the housing 4 Slide the housing back into position Air Filter Locating the Filters Yourrefrigeratorisequippedwithwaterltering systemThewaterltersystemltersalldis pensed drinking water as well as the water used toproduceiceThelterislocatedinthetop right rear corner of the fresh food compartment Water Filter Thewaterlterislocatedatthetoprightside of the fresh food compartment Ordering Replacement Filters Toorderyourreplacementlterspleasevisit our online store at wwwfrigidairecomstore by calling tollfree at 18005997569 or by visiting the dealer where you purchased your refrigerator Frigidaire recommends that you orderextralterswhenyourstinstallyour refrigeratorandthatyoureplaceyourltersat least once every six months Hereistheproductnumbertorequestwhen ordering PureSource Ultra II TM Water Filter Part EPTWFU01 Replacing the Water Filter In general you should change the water ltereverysixmonthstoensurethehighest possiblewaterqualityWater Filter Status on the user interface prompts you to replace thelterafterastandardamountofwater 125 gallons473 liters for PureSource Ultra II TM hasowedthroughthesystem If your refrigerator has not been used for a period of time during moving for example change the lterbeforereinstallingtherefrigerator Filter Cartridge NOTE Whenorderingyourreplacementlter pleasereorderthesameltertypethatis currently in your refrigerator CHANGING THE FILTER
• Page 25 - English - : CHANGING THE FILTER Do not use with water that is microbiologically unsafeorofunknownqualitywithoutadequate disinfection before or after the system Systems certiedforcystreductionmaybeusedon disinfectedwatersthatmaycontainlterablecysts Test amp certication results Rated Capacity 125 gallons473 liters for PureSource Ultra II TM iceandwaterlter Ratedserviceow65gallonsperminute Operating Temp Min 33F Max 100F Maximum Rated Pressure 100 pounds per squareinch Recommended Minimum Operating Pressure30poundspersquareinch The PureSource Ultra II TM iceandwaterltersystemis testedandcertiedtoNSFANSI Standards 42 53 and 401 for the reductionofclaimsspeciedon the performance data sheet More about your Advanced Water Filter To replace your PureSource Ultra II TM water lter It is not necessary to turn the water supply off tochangethelterBereadytowipeupany small amounts of water released during the lterreplacement 1 Turn Off the ice maker power switch 2 Removetheoldlterbyrotatingitcounter clockwise to the left 90 degrees to release it 3 Slidetheoldltercartridgestraightoutof the housing and discard it 4 UnpackagethenewltercartridgeSlideit intothelterhousingasfarasitwillgowith the grip end horizontal 5 Pushlightlyinwardonthelterwhilerotating itclockwisetotherightThelterwillthen pull itself inward as it is rotated Rotate the lter90degreesuntilitstopsandthegrip end is vertical You may be able to feel a very lightclickasthelterlocksintoplace 6 Press a drinking glass against the water dispenser while checking for any leaks at thelterhousingAnyspurtsandsputters that occur as the system purges air out of the dispenser system are normal 7 Continue dispensing water for 34 minutes oruntil15gallonsofwaterhasowed through the system You will likely need to emptyandrellyourglassseveraltimes 8 Turn On the ice maker 9 Press and hold the Water Filter reset button on the control panel for three seconds When the display changes from Red to Green the status has been reset
• Page 26 - English - : Understanding the Sounds you may Hear Yournewhighefciencyrefrigeratormay introduce unfamiliar sounds These sounds normally indicate your refrigerator is operating correctlySomesurfacesonoorswallsand kitchen cabinets may make these sounds more noticeable Following is a list of major components in your refrigerator and the sounds they can cause A Evaporator Refrigerant through the evaporator may create a boiling or gurgling sound B Evaporator fan You may hear air being forced through the refrigerator by the evaporator fan C Defrost heater During defrost cycles water dripping onto the defrost heater may cause a hissing or sizzling sound After defrosting a popping sound may occur D Automatic ice maker When ice has been produced you will hear ice cubes falling into the ice bin E Electronic control amp automatic defrost control These parts can produce a snapping or clicking sound when turning the cooling system on and off F Condenser fan You may hear air being forced through the condenser G CompressorModernhighefciency compressors run much faster than in the past The compressor may have a high pitched hum or pulsating sound H Water valve Makes a buzzing sound each timeitopenstolltheicemaker I Drain pan not removable You may hear water dripping into the drain pan during the defrost cycle J Condenser May create minimal sounds from forced air K Motorized damper May produce a light humming during operation L Ice chute When dispensing ice you will hear a snapping or clicking sound when the solenoid opens and closes the ice chute NORMAL OPERATING SOUNDS AND SIGHTS NOTE Energyefcientfoaminyourrefrigeratoris not a sound insulator NOTE During automatic defrost cycle a red glow in the back wall vents of your freezer compartment is normal
• Page 27 - English - : IMPORTANT If you store or move your refrigerator in freezing temperatures be sure to completely drain the water supply system Failure to do so could result in water leaks when the refrigerator is put back into service Contact a service representative to perform this operation Protecting your investment Keeping your refrigerator clean maintains appearance and prevents odor buildup Wipe up any spills immediately and clean the freezer and fresh food compartments at least twice a year When cleaning take the following precautions Never use CHLORIDE or cleaners with bleach to clean stainless steel Do not wash any removable parts in a dishwasher Always unplug the electrical power cord from the wall outlet before cleaning Remove adhesive labels by hand Do not use razor blades or other sharp instruments which can scratch the appliance surface Do not remove the serial plate Donotuseabrasivecleanerssuchaswindowspraysscouringcleansersbrushesammable uidscleaningwaxesconcentrateddetergentsbleachesorcleanserscontainingpetroleum products on plastic parts interior doors gaskets or cabinet liners Do not use paper towels metallic scouring pads or other abrasive cleaning materials or strong alkaline solutions CARE amp CLEANING Vacation and moving tips Occasion Tips Short Vacations Leave refrigerator operating during vacations of three weeks or less Use all perishable items from refrigerator compartment Turn automatic ice maker off and empty ice bucket even if you will only be gone a few days Long Vacations Remove all food and ice if you will be gone one month or more Turn the cooling system off see Controls section for location of OnOff button and disconnect power cord Turn water supply valve to closed position Clean interior thoroughly Leave both doors open to prevent odors and mold buildup Block doors open if necessary Moving Remove all food and ice If using a handcart load from the side Adjust rollers all the way up to protect them during sliding or moving Pad cabinet to avoid scratching surface NOTE If you set your temperature controls to turn off cooling power to lights and other electrical components will continue until you unplug the power cord from the wall outlet CAUTION Pull the refrigerator straight out to move it Shifting it from side to side may damage ooringBecarefulnottomovetherefrigeratorbeyondtheplumbingconnections Damp objects stick to cold metal surfaces Do not touch refrigerated surfaces with wet or damp hands
• Page 28 - English - : CARE amp CLEANING Care and Cleaning Tips Part Cleaning Agents Tips and Precautions Interior amp Door Liners Soap and water Baking soda and water Usetwotablespoonsofbakingsodainonequartof warm water Be sure to wring excess water out of sponge or cloth before cleaning around controls light bulb or any electrical part Door Gaskets Soap and water Wipe gaskets with a clean soft cloth Drawers amp Bins Soap and water Use a soft cloth to clean drawer runners and tracks Do not wash any removable items bins drawers etc in dishwasher Glass Shelves Soap and water Glass cleaner Mildliquidsprays Allow glass to warm to room temperature before immersing in warm water Toe Grille Soap and water Mildliquidsprays Vacuum Remove toe grille see Installation Instructions Vacuum both sides and wipe with sudsy cloth or sponge Rinse and dry Exterior amp Handles Soap and water Non abrasive glass cleaner Do not use commercial household cleaners containing ammonia bleach or alcohol to clean handles Use a soft cloth to clean smooth handles Do not use a dry cloth to clean smooth doors Exterior amp Handles Stainless Steel Models Only Soap and water Stainless steel cleaners Never use CHLORIDE or cleaners with bleach to clean stainless steel Clean stainless steel front and handles with non abrasive soapy water and a dishcloth Rinse with clean water and a soft cloth Use a nonabrasive stainless steel cleaner These cleaners can be purchased at most home improvement or major department stores Always follow manufacturers instruction Do not use household cleaners containing ammonia or bleach NOTE Always clean wipe and dry with grain to prevent scratching Wash the rest of the cabinet with warm water and mildliquiddetergentRinsewellandwipedrywitha clean soft cloth
• Page 29 - English - : BEFORE YOU CALL Visit our web site at wwwfrigidairecom 18009449044 United States 18002658352 Canada CONCERN CAUSE SOLUTION AUTOMATIC ICE MAKER Ice maker is not making any ice Ice maker is turned off Refrigerator is not connected to water line or water valve is not open The water supply line is kinked Thewaterlterisnot seated properly Thewaterltermay be clogged with foreign material Turn on ice maker Press and hold the ON OFF button for three seconds until the indicator light is on Connect the unit to the household water supply and ensure the water valve is open Ensure that the supply line does not kink when the refrigerator is pushed into place against the wall Removeandreinstallthewaterlter Remove by rotating it counterclockwise to the left 90 degrees to release it Reinstall byslidingitintothelterhousingasfaras it will go with the grip end horizontal Push lightlyinwardonthelterwhilerotatingit clockwisetotherightThelterwillthen pull itself inward as it is rotated Rotate the lter90degreesuntilitstopsandthegrip end is vertical You may be able to feel a verylightclickasthelterlocksintoplace If water dispenses slowly or not at all or ifthelterissixmonthsoldorolderit should be replaced Ice maker is not making enough ice Ice maker is producing less ice than you expect Thewaterltermay be clogged with foreign material The water supply line is kinked Saddle valve on cold water pipe is clogged or restrict ed by foreign material Heavytrafcopening or closing of the doors excessively Freezer control is set too warm The ice maker produces approximately 25 to 3 pounds every 24 hours depending on usage conditions If water dispenses slower than normal orifthelterissixmonthsoldorolderit should be replaced Ensure that the supply line does not kink when the refrigerator is pushed into place against the wall Turn off household water line valve Remove valve Ensure that valve is not a selfpiercing saddle valve Clean valve Replace valve if necessary Press Quick Freeze to temporarily increase ice production rate Does not apply to Frigidaire Professional Set freezer control to colder setting to improve performance of the ice maker Allow 24 hours for temperature to stabilize
• Page 30 - English - : BEFORE YOU CALL CONCERN CAUSE SOLUTION AUTOMATIC ICE MAKER Continued Ice cubes are freezing together Ice cubes are not being usedfrequentlyenough or interruption of power for prolonged time Ice cubes are small or hol low shells of ice with water inside The hollow cubes break open in the bin and leak their water onto exist ing ice which causes it to freeze together Remove ice container and discard ice The ice maker will produce fresh supply Ice should be used at least twice weekly to keep the cubes separated This generally occurs when the ice maker does not get enough water This is usually theresultofacloggedwaterlteror restricted water supply Replace the water lterandiftheconditionstilloccurscheck for a Saddle Valve water valve not turned on all the way or kinked water supply line DISPENSER Ice amp Water Dispenser will not dispense ice Dispenser lock out is engaged Does not apply to Frigidaire Professional There is no ice in the bin to be dispensed The refrigerator doors are not completely closed Dispenser paddle has been pressed too long and the dispenser motor has overheated Press and hold control lock for 3 seconds See the Ice maker is not making any ice section above Be sure the refrigerator doors are completely closed The motor overload protector will reset in about three minutes and then ice can be dispensed Ice dispenser is jammed Ice has melted and frozen around auger duetoinfrequentuse temperatureuctuations andor power outages Ice cubes are jammed between ice maker and back of ice container Remove ice container thaw and empty the contents Clean container wipe dry and replace in proper position When new ice is made dispenser should operate Remove ice cubes that are jamming the dispenser Dispenser will not dispense water Dispenser lock out is engaged Does not apply to Frigidaire Professional Waterlternot seated properly Waterlterisclogged Household water line valve is not open Press and hold control lock for 3 seconds Removeandreinstallthewaterlter Be sure to press inward as you rotate it clockwise to lock it in place ReplaceltercartridgeBesuretopress inward as you rotate it clockwise to lock it in place Open household water line valve See CONCERN column AUTOMATIC ICE MAKER Water has an odd taste and or odor Water has not been dispensed for an extended period of time Unit not properly con nected to cold water line Draw and discard 1012 glasses of water to freshen the supply Connect unit to cold water line that supplies water to the kitchen faucet
• Page 31 - English - : BEFORE YOU CALL CONCERN CAUSE SOLUTION DISPENSER Ice amp Water Continued Water pressure is extremely low Cutoff and cuton pressures are too low well systems only Reverse osmosis system is in regenerative phase Have someone turn up the cutoff and cut on pressure on the water pump system well systems only It is normal for a reverse osmosis system to be below 20 psi during the regenerative phase Water not cold enough The water dispensing system is not designed to chill water Add ice to cup or container before dispensing water OPENINGCLOSING OF DOORSDRAWERS Doors will not close Door was closed too hard causing other door to open slightly Refrigerator is not level Itrocksontheoorwhen moved slightly Refrigerator is touching a wall or cabinet Close both doors gently Ensureoorislevelandsolidandcan adequatelysupporttherefrigerator Contact a carpenter to correct a sagging or slopingoor Ensureoorislevelandsolidandcan adequatelysupporttherefrigerator Contact a carpenter to correct a sagging or slopingoor Drawers are difcult to move Food is touching shelf on top of drawer Track that drawers slide on is dirty Remove top layer of items in drawer Ensure drawer is properly installed on track Clean drawer rollers and track See Care amp Cleaning RUNNING OF REFRIGERATOR Compressor does not run Freezer control is set to OF or 0 Refrigerator is in defrost cycle Plug at electrical outlet is disconnected House fuse blown or tripped circuit breaker Power outage Set freezer control This is normal for a fully automatic defrost refrigerator The defrost cycle occurs periodically lasting about 30 minutes Ensure plug is tightly pushed into outlet Checkreplace fuse with a 15 amp time delay fuse Reset circuit breaker Check house lights Call local electric company
• Page 32 - English - : BEFORE YOU CALL CONCERN CAUSE SOLUTION RUNNING OF REFRIGERATOR Continued Refrigerator runs too much or too long Single Speed Compressor Some Models Room or outside weather is hot Doors are opened too frequentlyortoolong Fresh Foodfreezer door may be slightly open Freezer control is set too cold Fresh Foodfreezer gasket is dirty worn cracked or poorlytted Condenser is dirty Its normal for the refrigerator to work longer under these conditions Warm air entering the refrigerator causes it to run more Open doors less often Ensure refrigerator is level Keep food and con tains from blocking door See PROBLEM column OPENINGCLOSING OF DOORSDRAWERS Set Fresh Food control to warmer setting until refrigerator temperature is satisfactory Allow 24 hours for temperature to stabilize Clean or change gasket Leaks in door seal will cause refrigerator to run longer in order to maintain desired temperatures Clean condenser See CARE amp CLEANING Compressor goes off and on frequently Thermostat keeps the refrigerator at a constant temperature This is normal Refrigerator goes on and off to keep temperature constant Single Speed Compressor Some Models Refrigerator seems to run too much or too long Variable Speed Compressor Some Models Your variable speed compressor is designed to run 100 of the time except during the defrost cycle At times it will run faster such as after a defrost cycle It is normal for the compressor to run continuously except during defrost mode DIGITAL TEMPERATURE DISPLAY Digital temper ature displays are ashing Electronic control system has detected a performance problem Call your Frigidaire service representative who can interpret any messages or number codesashingonthedigitaldisplays WATERMOISTUREFROST INSIDE REFRIGERATOR Moisture collects on inside of re frigerator walls Weather is hot and humid Door is slightly open The rate of frost buildup and internal sweating increases See PROBLEM column OPENINGCLOS ING OF DOORSDRAWERS Water collects on bottom side of drawer cover Vegetables contain and give off moisture It is not unusual to have moisture on the bottom side of the cover Move humidity control some models to lower setting Water collects in bottom of drawer Washed vegetables and fruit drain while in the drawer Dry items before putting them in the drawer Water collecting in bottom of drawer is normal WATERMOISTUREFROST OUTSIDE REFRIGERATOR Moisture collects on outside of refrigerator or between doors Weather is humid Door is slightly open causing cold air from inside refrigerator to meet warm air from outside This is normal in humid weather When hu midity is lower the moisture should disappear See PROBLEM column OPENINGCLOS ING OF DOORSDRAWERS
• Page 33 - English - : MAJOR APPLIANCE WARRANTY Your appliance is covered by a one year limited warranty For one year from your original date of purchase Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed used and maintained in accordance with the provided instructions Exclusions If You Need Service This warranty does not cover the following 1 Products with original serial numbers that have been removed altered or cannot be readily determined 2 Product that has been transferred from its original owner to another party or removed outside the USA or Canada 3 Rust on the interior or exterior of the unit 4 Products purchased asis are not covered by this warranty 5 Food loss due to any refrigerator or freezer failures 6 Products used in a commercial setting 7 Service calls which do not involve malfunction or defects in materials or workmanship or for appliances not in ordinary household use or used other than in accordance with the provided instructions 8 Service calls to correct the installation of your appliance or to instruct you how to use your appliance 9 Expenses for making the appliance accessible for servicing such as removal of trim cupboards shelves etc which are not a part of the appliance when it is shipped from the factory 10 Servicecallstorepairorreplaceappliancelightbulbsairlterswaterltersother consumables or knobs handles or other cosmetic parts 11 Surcharges including but not limited to any after hour weekend or holiday service calls tolls ferry trip charges or mileage expense for service calls to remote areas including the state of Alaska 12 Damagestothenishofapplianceorhomeincurredduringinstallationincludingbutnot limitedtooorscabinetswallsetc 13 Damages caused by services performed by unauthorized service companies use of parts other than genuine Electrolux parts or parts obtained from persons other than authorized service companiesorexternalcausessuchasabusemisuseinadequatepowersupplyaccidents resoractsofGod DISCLAIMER OF IMPLIED WARRANTIES LIMITATION OF REMEDIES CUSTOMERS SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT REPAIR OR REPLACEMENT AS PROVIDED HEREIN CLAIMS BASED ON IMPLIED WARRANTIES INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ARE LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW BUT NOT LESS THAN ONE YEAR ELECTROLUX SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY SOME STATES AND PROVINCES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES SO THESE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE This warranty only applies in the USA and Canada In the USA your appliance is warranted by Electrolux Major Appliances North America a division of Electrolux Home Products Inc In Canada your appliance is warranted by Electrolux Canada Corp Electrolux authorizes no person to change or add to any obligations under this warranty Obligations for service and parts under this warranty mustbeperformedbyElectroluxoranauthorizedservicecompanyProductfeaturesorspecications as described or illustrated are subject to change without notice Keep your receipt delivery slip or some other appropriate payment record to establish the warranty periodshouldserviceberequiredIfserviceisperformeditisinyourbestinteresttoobtainand keep all receipts Service under this warranty must be obtained by contacting Electrolux at the addresses or phone numbers below USA 18009449044 Frigidaire 10200 David Taylor Drive Charlotte NC 28262 Canada 18002658352 Electrolux Canada Corp 5855 Terry Fox Way Mississauga Ontario Canada L5V 3E4
