DSC-HX99/DSC-HX95/DSC-WX800/DSC-WX700
Digital Still Camera
Startup Guide
4-746-011-11(1)
Preparations
Checking the supplied items
The number in parentheses indicates the number of pieces.
• Camera (1)
• Power cord (mains lead) (1) (supplied
in some countries/regions)
• Rechargeable battery pack NP-BX1 (1)
• Micro USB cable (1)
• AC Adaptor (1)
The type of the AC Adaptor may differ
depending on the country/region.
• Wrist strap (1)
• Startup Guide (this manual) (1)
• Reference Guide (1)
Inserting the battery pack (supplied)/memory card
(sold separately) into the camera
Open the battery/memory card cover, and insert the battery pack and a memory
card into the camera. Then, close the cover.
microSD
memory
card
Memory
Stick Micro
media
Battery pack
Lock lever
Battery pack
Make sure that the battery pack is facing in the correct direction, and insert it while
pressing the battery lock lever.
Memory card
microSD memory card/microSDHC memory card/microSDXC memory card: Insert
the card straight with the terminal side facing the monitor side of the camera.
Memory Stick Micro: Insert the card with the terminal side facing the lens side of
the camera.
This camera is compatible with microSD memory cards or Memory Stick Micro
media. For details on the compatible memory cards, refer to the “Help Guide.”
When you use a memory card with this camera for the first time, it is recommended
that you format the card using the camera in order to stabilize the performance of
the memory card.
Charging the battery pack
1 Turn the power off.
If the camera is turned on, the battery pack will not be charged.
2 Connect the camera with the battery pack
inserted to the AC Adaptor (supplied)
using the micro USB cable (supplied), and
connect the AC Adaptor to the wall outlet
(wall socket).
The charge lamp will light up when charging
starts. When the charge lamp turns off,
charging is completed.
Charge lamp
Setting the language and the clock
ON/OFF (Power) button
Control wheel
Select items : ////
/
Confirm : Center button
1 Press the ON/OFF (Power) button to turn on the camera.
2 Select the desired language and then press the center of the control
wheel.
3 Make sure that [Enter] is selected on the screen and then press the
center.
4 Select the desired geographic location and then press the center.
5 Set [Daylight Savings], [Date/Time], and [Date Format], and then select
[Enter] and press the center.
If you want to reconfigure the date/time or the area setting at a later point,
select MENU
(Setup) [Date/Time Setup] or [Area Setting].
Shooting
Shooting still images
1 Select the desired shooting
mode by turning the mode
dial.
(Flash pop-up)
switch
Shutter
button
Mode dial
2 Press the shutter button
halfway down to focus.
3 Press the shutter button all
the way down.
Using the flash
Slide the (Flash pop-up) switch to pop up the flash.
Restore the flash to its original position after using it. Make sure that the flash
portion is not sticking up.
Shooting movies
1 Press the MOVIE (Movie) button to
start recording.
Movie recording can be started from
any shooting mode in the default
setting.
MOVIE (Movie) button
2 Press the MOVIE button again to
stop recording.
Using the viewfinder (only for models with a viewfinder)
Slide down the viewfinder pop-up switch to
raise the viewfinder. Then, grasp both sides
of the eyepiece frame and pull it toward the
monitor side until it clicks. Use the diopter
adjustment lever to adjust the visibility of the
image in the viewfinder.
To store the viewfinder, grab both side of the
eyepiece frame, and push it back into the
viewfinder until it clicks. Then, push down the
top of the viewfinder.
Eyepiece
frame
Viewfinder pop-up switch
Diopter adjustment lever
Viewing
1 Press the (Playback) button to
switch to the playback mode.
(Playback) button
C/
(Delete) button
Control wheel
2 Select an image with the control
wheel.
You can move to the previous image/
next image by pressing the left/right
side of the control wheel.
To start playing back a movie, press
the center button on the control
wheel.
Deleting a displayed image
Press the (Delete) button while the image is displayed, and then select [Delete]
using the control wheel.
Once you have deleted an image, you cannot restore it. Confirm the image before
deleting it.
This guide describes the necessary preparations to start using
the product, basic operations, etc.
For details, refer to the “Help Guide” (web manual).
http://rd1.sony.net/help/dsc/1815/h_zz/
“Help Guide” (Web manual)
©2018 Sony Corporation Printed in China
Specifications
Camera
DSC-HX99
Rated input: 3.6V
, 1.8W
Operating temperature:
0 to 40°C (32 to 104°F)
Storage temperature:
–20 to 55°C (–4 to 131°F)
Dimensions (W/H/D) (Approx.):
102.0 × 58.1 × 35.5mm
(41/8 × 23/8 × 17/16in.)
Mass (CIPA compliant) (Approx.):
242g (8.6oz) (including battery pack,
microSD memory card)
DSC-HX95
Rated input: 3.6V
, 1.8W
Operating temperature:
0 to 40°C (32 to 104°F)
Storage temperature:
–20 to 55°C (–4 to 131°F)
Dimensions (W/H/D) (Approx.):
102.0 × 58.1 × 35.5mm
(41/8 × 23/8 × 17/16in.)
Mass (CIPA compliant) (Approx.):
243g (8.6oz) (including battery pack,
microSD memory card)
DSC-WX800
Rated input: 3.6V
, 1.5W
Operating temperature:
0 to 40°C (32 to 104°F)
Storage temperature:
–20 to 55°C (–4 to 131°F)
Dimensions (W/H/D) (Approx.):
101.6 × 58.1 × 35.5mm
(41/8 × 23/8 × 17/16in.)
Mass (CIPA compliant) (Approx.):
233g (8.3oz) (including battery pack,
microSD memory card)
DSC-WX700
Rated input: 3.6V
, 1.5W
Operating temperature:
0 to 40°C (32 to 104°F)
Storage temperature:
–20 to 55°C (–4 to 131°F)
Dimensions (W/H/D) (Approx.):
101.6 × 58.1 × 35.5mm
(41/8 × 23/8 × 17/16in.)
Mass (CIPA compliant) (Approx.):
233g (8.3oz) (including battery pack,
microSD memory card)
AC Adaptor
AC-UUD12/AC-UUE12
Rated input:
100 - 240V
, 50/60Hz, 0.2A
Rated output: 5V
, 1.5A
AC-UB10C
Rated input:
100 - 240V
, 50/60Hz, 70mA
Rated output: 5V
, 0.5A
Rechargeable battery pack
NP-BX1
Rated voltage: 3.6V
Design and specifications are subject to
change without notice.
