GB
Quick Guide
CONTROL PANEL
1. ON/OFF button
2. START/PAUSE button with indicator light
3. WASH CYCLE PROGRESS indicator lights
4. DOOR LOCKED indicator light
5. FUNCTION buttons with indicator lights
6. CHILDLOCK button with indicator light
7. DELAY TIMER button
8. SPIN button
9. TEMPERATURE button
10. WASH CYCLE knob
WASH CYCLE TABLE
THANK YOU FOR BUYING A INDESIT PRODUCT
In order to receive a more complete assistance,
please register your product on
www.indesit.com/register
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
1
10
2 3
6
9
4
8
7
5
Maximum load 8 kg
Power input in o mode 0.5 W / in left-on mode 8 W
Detergents and
Additives
Recommended
detergent
Residual
dampness %
(**)
Energy
consumption
kWh
Total water l
Laundry
temperature °C
Wash cycle
Temperature
Maxim
spin
(r.p.m.)
Maximum
load (kg)
Duration
(h : m)
Prewash Wash
Fabric
softener
Powder
Liquid
Setting Range 1 2 3
1 Mixed
40°C
– 40°C
1000 8 0:59 –
–
– – – –
2 Cotton
60°C
– 60°C
1000 8 0:59 –
– – – –
3 Cotton
40°C
– 40°C
1000 8 0:45 –
–
– – – –
4 Cotton
30°C
– 30°C
800 4,5 0:30 –
–
71 0,18 36,7 27
5 Synthetics
30°C
– 30°C
1000 4,5 0:59 –
–
– – – –
6 Silk & Delicates
30°C
– 30°C
0 2 0:59
–
– – – –
7 Wool
40°C
– 40°C
800 2 0:59 –
–
– – – –
8 Express
20°C
– 20°C
800 1,5 0:15 –
–
– – – –
9 Cotton (2)
40°C
– 60°C
1400 8 3:40 –
53 1,03 92 45
10 Synthetics (3)
40°C
– 60°C
1400 4,5 2:55 –
53 0,54 55 43
11 Whites
60°C
– 90°C
1400 8 2:35
+90°
54,6 1,79 89 55
12 Sport
30°C
– 30°C
600 4 0:60 –
–
– – – –
13 20°C
20°C
– 20°C
1400 8 1:50 –
–
54,5 0,14 77,7 22
14 Eco 40-60 (1)
40 °C 40°C
1351 8 3:30 –
53 0,90 57 33
1351 4 2:45 –
53 0,68 47 35
1351 2,0 2:10 –
53 0,50 37 33
15 Rinse + Spin
– – 1400 8 0:55 – –
– – – – – –
16 Spin + Drain *
– – 1400 8 0:10 – – – – – – – – –
9
Eco Cotton (4)
60 °C 60 °C 1400 8 3:45 –
53 1,04 53 –
40 °C 40 °C 1400 8 3:40 –
53 1,03 92 –
Required dosage Optional dosage
4)
Eco Cotton -
Test wash cycles in compliance with regulations 1061/2010. Set 9 wash cycle
at a temperature of 40°C or 60°C to access this cycles.
* By selecting the 16 cycle and excluding the spin cycle, the washing machine will drain only.
** After programme end and spinning with maximum selectable spin speed, in default
programme setting.
Note: for the Eco 40-60 program in the WASH CYCLE TABLE the value of the maximum eective
spin is shown.
The cycle duration indicated on the display or instruction manual is an estimate based on
standard conditions. The actual duration may vary in relation to several factors, such as the
temperature and pressure of the incoming water, ambient temperature, amount of detergent,
load quantity and type, load balancing and any additional options selected. The values given
for programmes other than the Eco 40-60 programme are indicative only.
1) Eco 40-60
-
Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.
The most ecient programme in terms of energy and water consumption for washing
normally soiled cotton laundry.
For all testing institutes:
2) Long cotton cycle: set cycle 9 at a temperature of 40°C.
3) Long synthetics cycle: set cycle 10 at a temperature of 40°C.
PRODUCT DESCRIPTION
1.
3.
2.
5.
4.
7.
6.
8.
1. Top
2. Detergent dispenser drawer
3. Control panel
4. Handle
5. Porthole door
6. Drain pump (behind the plinth)
7. Plinth (removable)
8. Adjustable feet (2)
DETERGENT DISPENSER DRAWER
Compartment 1: Pre-wash detergent
(powder)
Compartment 2: Washing detergent (powder
or liquid)
If liquid detergent is used, the removable plastic
partition A (supplied) should be used for proper
dosage. If powder detergent is used, insert the
partition into slot B.
Compartment 3: Additives (fabric softener,
etc.)
The fabric softener must never exceed the “max”
level indicated on the central pin.
! Use powder detergent for white cotton garments, for pre-washing, and
for washing at temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
! To remove the drawer, press lever C and pull the drawer outwards.
C
