Table of contents
1 Safety ............................................4
1.1 General information....................4
1.2 Intended use...............................4
1.3 Restriction on user group...........4
1.4 Safe transport.............................4
1.5 Safe installation ..........................5
1.6 Safe use .....................................6
1.7 Damaged appliance...................8
2 Preventing material damage .......9
3 Environmental protection and
saving energy...............................9
3.1 Disposing of packaging .............9
3.2 Saving energy.............................9
4 Installation and connection.........9
4.1 Scope of delivery........................9
4.2 Criteria for the installation
location .....................................10
4.3 Installing the appliance ............10
4.4 Preparing the appliance for
the first time..............................11
4.5 Connecting the appliance to
the electricity supply.................11
5 Familiarising yourself with
your appliance............................12
5.1 Appliance .................................12
5.2 Control panel............................13
6 Features......................................14
6.1 Shelf..........................................14
6.2 Variable shelf............................14
6.3 Extendable shelf .......................14
6.4 Fruit and vegetable con-
tainer with humidity control ......14
6.5 Flat frozen food container ........15
6.6 Butter and cheese compart-
ment..........................................15
6.7 Door rack..................................15
6.8 Accessories..............................15
7 Basic operation ..........................16
7.1 Switching on the appliance ......16
7.2 Operating tips...........................16
7.3 Switching off the appliance ......16
7.4 Setting the temperature............16
8 Additional functions ..................17
8.1 Super cooling ..........................17
8.2 Automatic Super freezing.........17
8.3 Manual Super freezing .............17
8.4 Holiday mode ...........................18
9 Alarm...........................................18
9.1 Door alarm ...............................18
9.2 Temperature alarm ...................18
10 Refrigerator compartment .......19
10.1 Tips for storing food in the
refrigerator compartment .......19
10.2 Chill zones in the refriger-
ator compartment...................19
10.3 "OK" sticker ............................19
11 Freezer compartment...............20
11.1 Freezing capacity ...................20
11.2 Fully utilising the freezer
compartment volume .............20
11.3 Tips for storing food in the
freezer compartment ..............20
11.4 Tips for freezing fresh food ....20
11.5 Shelf life of frozen food at
−18°C....................................21
11.6 Defrosting methods for
frozen food .............................21
12 Defrosting.................................21
12.1 Defrosting in the refriger-
ator compartment...................21
12.2 Defrosting in the freezer
compartment ..........................21
13 Cleaning and servicing............22
13.1 Preparing the appliance for
cleaning ..................................22
en
3
13.2 Cleaning the appliance ..........22
13.3 Cleaning the condensation
channel and drainage hole ....23
13.4 Removing the fittings..............23
13.5 Removing appliance com-
ponents...................................24
14 Troubleshooting.......................26
14.1 Power failure...........................29
14.2 Conducting an appliance
self-test ...................................29
15 Storage and disposal...............29
15.1 Taking the appliance out of
operation ................................29
15.2 Disposing of old appliance ....29
16 Customer Service.....................30
16.1 Product number (E-Nr.) and
production number (FD).........30
17 Technical data ..........................30
en Safety
4
1 Safety
Observe the following safety instructions.
1.1 General information
¡ Read this instruction manual carefully.
¡ Keep the instruction manual and the product information safe
for future reference or for the next owner.
¡ Do not connect the appliance if it has been damaged in transit.
1.2 Intended use
This appliance is only intended to be fully fitted in a kitchen.
Only use this appliance:
¡ for chilling and freezing food and for making ice cubes.
¡ In private households and in enclosed spaces in a domestic en-
vironment.
¡ Up to an altitude of 2000 m above sea level.
1.3 Restriction on user group
This appliance may be used by children aged 8 or over and by
people who have reduced physical, sensory or mental abilities or
inadequate experience and/or knowledge, provided that they are
supervised or have been instructed on how to use the appliance
safely and have understood the resulting dangers.
Children must not play with the appliance.
Cleaning and user maintenance must not be performed by chil-
dren unless they are being supervised.
Children above the age of three years old and younger than eight
years old may load and unload the the fridge-freezer.
1.4 Safe transport
WARNING‒Risk of injury!
The high weight of the appliance may result in injury when lifted.
▶
Do not lift the appliance on your own.
Safety en
5
1.5 Safe installation
WARNING‒Risk of electric shock!
Incorrect installation is dangerous.
▶
Connect and operate the appliance only in accordance with the
specifications on the rating plate.
▶
Connect the appliance to a power supply with alternating cur-
rent only via a properly installed socket with earthing.
▶
The protective conductor system of the domestic electrical in-
stallation must be properly installed.
▶
Never equip the appliance with an external switching device,
e.g. a timer or remote control.
▶
When the appliance is installed, the mains plug of the power
cord must be freely accessible. If free access is not possible, an
all-pole isolating switch must be installed in the permanent elec-
trical installation according to the installation regulations.
▶
When installing the appliance, check that the power cable is not
trapped or damaged.
If the insulation of the power cord is damaged, this is dangerous.
▶
Never let the power cord come into contact with heat sources.
WARNING‒Risk of explosion!
If the appliance's ventilation openings are sealed, a leak in the re-
frigeration circuit may result in a flammable mixture of gas and air.
▶
Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
WARNING‒Risk of fire!
It is dangerous to use an extended power cord and non-approved
adapters.
▶
Do not use extension cables or multiple socket strips.
▶
If the power cord is too short, contact Customer Service.
▶
Only use adapters approved by the manufacturer.
Portable multiple socket strips or portable power supply units may
overheat and cause a fire.
▶
Do not place portable multiple socket strips or power supply
units on the back of the appliance.
en Safety
6
1.6 Safe use
WARNING‒Risk of electric shock!
An ingress of moisture can cause an electric shock.
▶
Only use the appliance in enclosed spaces.
▶
Never expose the appliance to intense heat or humidity.
▶
Do not use steam- or high-pressure cleaners to clean the appli-
ance.
WARNING‒Risk of suffocation!
Children may put packaging material over their heads or wrap
themselves up in it and suffocate.
▶
Keep packaging material away from children.
▶
Do not let children play with packaging material.
Children may breathe in or swallow small parts, causing them to
suffocate.
▶
Keep small parts away from children.
▶
Do not let children play with small parts.
WARNING‒Risk of explosion!
If the cooling circuit is damaged, flammable refrigerant may es-
cape and explode.
▶
To accelerate the defrosting process, do not use any other
mechanical devices or means other than those recommended
by the manufacturer.
▶
If food is stuck to the freezer compartment, loosen it with a blunt
implement such as the handle of a wooden spoon.
Products which contain flammable propellants and explosive sub-
stances may explode, e.g. spray cans.
▶
Do not store products which contain flammable propellants (e.g.
spray cans) or explosive substances in the appliance.
WARNING‒Risk of fire!
Electrical devices within the appliance may cause a fire, e.g. heat-
ers or electric ice makers.
▶
Do not operate electrical devices within the appliance.
Safety en
7
WARNING‒Risk of injury!
Containers that contain carbonated drinks may burst.
▶
Do not store containers that contain carbonated drinks in the
freezer compartment.
Injury to the eyes caused by escaping flammable refrigerant and
hazardous gases.
▶
Do not damage the tubes of the refrigerant circuit or the insula-
tion.
WARNING‒Risk of cold burns!
Contact with frozen food and cold surfaces may cause burns by
refrigeration.
▶
Never put frozen food straight from the freezer compartment
into your mouth.
▶
Avoid prolonged contact of the skin with frozen food, ice and
surfaces in the freezer compartment.
CAUTION‒Risk of harm to health!
To prevent food from being contaminated, you must observe the
following instructions.
▶
If the door is open for an extended period of time, this may lead
to a considerable temperature increase in the compartments of
the appliance.
▶
Regularly clean the surfaces that may come into contact with
food and accessible drain systems.
▶
Store raw meat and fish in suitable containers in the refrigerator
so that they do not touch or drip on other food.
▶
If the fridge/freezer is empty for an extended period of time,
switch off the appliance, defrost it, clean it and leave the door
open to prevent the formation of mould.
Metal or metal-style parts in the appliance may contain aluminium.
If acidic food comes into contact with aluminium in the appliance,
aluminium foil ions may pass into the food.
▶
Do not consume soiled food.
en Safety
8
1.7 Damaged appliance
WARNING‒Risk of electric shock!
If the appliance or the power cord is damaged, this is dangerous.
▶
Never operate a damaged appliance.
▶
Never pull on the power cord to unplug the appliance. Always
unplug the appliance at the mains.
▶
If the appliance or the power cord is damaged, immediately un-
plug the power cord or switch off the fuse in the fuse box.
▶
Call customer services. →Page30
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out by trained
specialist staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be re-
placed by the manufacturer, the manufacturer's Customer Ser-
vice or a similarly qualified person in order to prevent any risk.
WARNING‒Risk of fire!
If the tubes are damaged, flammable refrigerant and harmful
gases may escape and ignite.
▶
Keep naked flames and ignition sources away from the appli-
ance.
▶
Ventilate the room.
▶
Switch off the appliance. →Page16
▶
Unplug the appliance from the mains or switch off the circuit
breaker in the fuse box.
▶
Call after-sales service. →Page30
Preventing material damage en
9
Preventing material damage
2 Preventing material
damage
Preventing material damage
ATTENTION!
Using the base, runners or appliance
doors as a seat surface or climbing
surface may damage the appliance.
▶
Do not stand or support yourself
on the base, runners or doors.
Contamination with oil or fat may
cause plastic parts and door seals to
become porous.
▶
Keep plastic parts and door seals
free of oil and grease.
Metal or metal-style parts in the appli-
ance may contain aluminium. Alu-
minium reacts when it comes into
contact with acidic foods.
▶
Do not store unpackaged food in
the appliance.
Environmental protection and saving energy
3 Environmental protec-
tion and saving energy
Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environ-
mentally compatible and can be re-
cycled.
▶
Sort the individual components by
type and dispose of them separ-
ately.
3.2 Saving energy
If you follow these instructions, your
appliance will use less power.
Selecting the installation location
¡ Keep the appliance out of direct
sunlight.
¡ Install the appliance as far away as
possible from heating elements,
cookers and other heat sources:
– Maintain a 30mm clearance to
electric or gas cookers.
– Maintain a 300mm clearance to
oil or solid-fuel cookers.
¡ Use a niche depth of 560mm.
¡ Never cover or block the exterior
ventilation grilles.
Saving energy during use
Note:The arrangement of the fittings
does not affect the energy consump-
tion of the appliance.
¡ Open the appliance only briefly
and then close it carefully.
¡ Never cover or block the interior
ventilation openings or the exterior
ventilation grilles.
¡ Transport purchased food in a
cool bag and place in the appli-
ance quickly.
¡ Allow warm food and drinks to
cool down before storing them.
¡ Thaw frozen food in the refrigerator
compartment to utilise the low tem-
perature of the food.
¡ Always leave some space between
the food and to the back panel.
¡ Defrost the freezer compartment
regularly.
Installation and connection
4 Installation and con-
nection
Installation and connection
4.1 Scope of delivery
After unpacking all parts, check for
any transport damage and for com-
pleteness of delivery.
If you have any complaints, contact
your dealer or our after-sales service
→Page30.
en Installation and connection
10
The delivery consists of the following:
¡ Built-in appliance
¡ Equipment and accessories
1
¡ Installation material
¡ Installation instructions
¡ User manual
¡ Customer service directory
¡ Warranty enclosure
2
¡ Energy label
¡ Information on energy consump-
tion and noises
4.2 Criteria for the installation
location
WARNING
Risk of explosion!
If the appliance is in a space that is
too small, a leak in the refrigeration
circuit may result in a flammable mix-
ture of gas and air.
▶
Only install the appliance in a
space with a volume of at least
1m
3
per 8g refrigerant. The
volume of refrigerant is indicated
on the rating plate. →"Appliance",
Fig. 1 /
5
, Page13
The weight of the appliance ex works
may be up to 75kg depending on
the model.
The subfloor must be sufficiently
stable to bear the weight of the appli-
ance.
Permitted room temperature
The permitted room temperature de-
pends on the appliance's climate
class.
The climate class can be found on
the rating plate. →"Appliance", Fig.
1 /
5
, Page13
Climate
class
Permitted room tem-
perature
SN 10°C to 32°C
N 16°C to 32°C
ST 16°C to 38°C
T 16°C to 43°C
The appliance is fully functional within
the permitted room temperature.
If an appliance with climate class SN
is operated at colder room temperat-
ures, the appliance will not be dam-
aged up to a room temperature of
5°C.
Niche dimensions
Observe the niche dimensions if you
install your appliance in the niche. If
this is not the case, problems may
occur when installing the appliance.
Niche depth
Install the appliance in the recom-
mended niche depth of 560mm.
If the niche depth is smaller, the en-
ergy consumption increases slightly.
The niche depth must be a minimum
550mm.
Niche width
An inside niche width of at least
560mm is required for the appli-
ance.
Side-by-side installation
If you want to install two appliances
side by side, you must maintain a
distance of at least 150mm between
the appliances.
4.3 Installing the appliance
▶
Install the appliance in accordance
with the enclosed installation in-
structions.
1
Depending on the appliance specifications
2
Not in all countries
Installation and connection en
11
4.4 Preparing the appliance
for the first time
1. Remove the informative material.
2. Remove the protective foil and
transit bolts, e.g. remove the ad-
hesive strips and carton.
3. Clean the appliance for the first
time. →Page22
4.5 Connecting the appliance
to the electricity supply
1. Insert the mains plug of the appli-
ance's power cable in a socket
nearby.
The connection data of the appli-
ance can be found on the rating
plate. →"Appliance", Fig. 1 /
5
,
Page13
2. Check the mains plug is inserted
properly.
a The appliance is now ready for
use.
en Familiarising yourself with your appliance
12
Familiarising yourself with your appliance
5 Familiarising yourself with your appliance
Familiarising yourself with your appliance
5.1 Appliance
You can find an overview of the parts of your appliance here.
1
2
3
4
5
6
7
8
9
A
B
1
A
Refrigerator compartment
→Page19
B
Freezer compartment
→Page20
1
Control panel →Page13
2
Variable shelf →Page14
3
Extendable shelf →Page14
Familiarising yourself with your appliance en
13
4
Fruit and vegetable container
with humidity control
→Page14
5
Rating plate →Page30
6
Flat frozen food container
→Page15
7
Frozen food container
→Page24
8
Butter and cheese compart-
ment →Page15
9
Door storage compartment
for large bottles →Page15
Note:Deviations between your appli-
ance and the diagrams may differ
with regard to their features and size.
5.2 Control panel
You can use the control panel to configure all functions of your appliance and
to obtain information about the operating status.
1 2 3
4
5 6
7
8 9
2
1
(Refrigerator compart-
ment) switches Super cooling
on or off.
2
/ (Refrigerator compartment)
sets the temperature of the
refrigerator compartment.
3
Displays the set temperature
for the refrigerator compart-
ment in°C.
4
switches holiday mode
on or off.
5
switches the warning
signal off.
6
/ (Freezer compartment)
sets the temperature of the
freezer compartment.
7
Displays the set temperature
for the freezer compartment
in °C.
8
(Freezer compartment)
switches Super freezing on or
off.
9
switches the appliance on
or off.
en Features
14
Features
6 Features
Features
The features of your appliance de-
pend on the model.
6.1 Shelf
To vary the shelf as required, you
can remove the shelf and re-insert it
elsewhere.
→"Removing the shelf", Page23
6.2 Variable shelf
Use the variable shelf to store tall
items, e.g. cans or bottles, on the
shelf below.
You can remove the front section of
the variable shelf and slide it below
the rear part of the shelf.
6.3 Extendable shelf
In order to achieve an improved over-
view and to remove food more
quickly, pull out the extendable shelf.
6.4 Fruit and vegetable con-
tainer with humidity con-
trol
Store fresh fruit and vegetables loose
in the fruit and vegetable container.
Cover any chopped fruit and veget-
ables, or store in air-tight packaging.
You can adjust the humidity in the
fruit and vegetable container using
the humidity controller and a special
seal. This allows fresh fruit and veget-
ables to be stored for up to twice as
long as with conventional storage.
The air humidity in the fruit and
vegetable container can be set
according to the type and amount of
food to be stored by moving the
humidity control:
¡ Low humidity required when
primarily storing fruit or if the appli-
ance is very full.
¡ High humidity required when
primarily storing vegetables as well
as when the appliance is filled with
mixed items or is not very full.
Condensation may form in the fruit
and vegetable container depending
on the food and quantity stored.
Remove the condensation with a dry
cloth and adjust the air humidity in
the vegetable container using the hu-
midity controller.
To ensure that the quality and aroma
are retained, store fruit and veget-
ables that are sensitive to cold out-
side of the appliance at temperatures
of approx. 8°C to 12°C, e.g. pine-
apple, bananas, citrus fruits, cucum-
bers, courgettes, peppers, tomatoes
and potatoes.
Features en
15
6.5 Flat frozen food container
Store flat frozen items, the ice stor-
age container and the ice scoop in
the flat frozen food container.
6.6 Butter and cheese com-
partment
Store butter and hard cheese in the
butter and cheese compartment.
To open the butter and cheese com-
partment, press down lightly on the
centre of the flap.
Note:The compartment opens down-
wards. The flap slides under the com-
partment.
6.7 Door rack
To adjust the door racks as required,
you can remove the door rack and
re-insert elsewhere.
→"Removing door rack", Page24
6.8 Accessories
Use original accessories. These have
been made especially for your appli-
ance.
The accessories for your appliance
depend on the model.
Egg tray
Store eggs safely on the egg tray.
Bottle holder
The bottle holder prevents bottles
from falling over when the appliance
door is opened and closed.
Freezer tray
You can freeze smaller quantities of
food quickly in the freezer drawer,
e.g. berries, pieces of fruit, herbs and
vegetables.
Distribute the frozen food evenly in
the frozen food tray and allow to
freeze for approx. 10 to 12hours.
Then place in a freezer bag or a
freezer box.
Ice pack
Use the ice pack for temporarily
keeping food cool, e.g. in a cool bag.
Tip:If a power failure or malfunction
occurs, the ice pack can be used to
slow down the thawing process for
the stored frozen food.
en Basic operation
16
Ice cube tray
Use the ice cube tray to make ice
cubes.
Making ice cubes
Use only drinking water tomake ice
cubes.
1. Fill the ice cube tray with drinking
water up to ¾ and place in the
freezer compartment.
If the ice cube tray is stuck to the
freezer compartment, loosen it with
a blunt implement only (e.g. spoon
handle).
2. To loosen the ice cubes, twist the
ice cube tray slightly or hold it
briefly under flowing water.
Basic operation
7 Basic operation
Basic operation
7.1 Switching on the appli-
ance
1. Press .
a The appliance begins to cool.
a A warning signal sounds, the tem-
perature display (freezer compart-
ment) flashes and lights up
because the freezer compartment
is still too warm.
2. Switch off the warning signal using
.
a goes out as soon as the set
temperature has been reached.
3. Set the required temperature.
→Page16
7.2 Operating tips
¡ Once you have switched on the
appliance, the set temperature is
only reached after several hours.
Do not put any food in the appli-
ance until the set temperature has
been reached.
¡ The housing around the freezer
compartment is temporarily heated
slightly. This prevents condensa-
tion in the area of the door seal.
¡ When you close the door, a va-
cuum may be created. The door is
then difficult to open again. Wait a
moment until the vacuum is offset.
7.3 Switching off the appli-
ance
▶
Press .
7.4 Setting the temperature
Setting the refrigerator
compartment temperature
▶
Press / (Refrigerator compart-
ment) repeatedly until the temper-
ature display (refrigerator compart-
ment) shows the required temper-
ature.
The recommended temperature in
the refrigerator compartment is
4°C.
→""OK" sticker", Page19
Setting the freezer compartment
temperature
▶
Press / (Freezer compartment) re-
peatedly until the temperature dis-
play (freezer compartment) shows
the required temperature.
The recommended temperature in
the freezer compartment is
−18°C.
Additional functions en
17
Additional functions
8 Additional functions
Additional functions
8.1 Super cooling
With Super cooling, the refrigerator
compartment cools as cold as pos-
sible.
Switch on Super cooling before pla-
cing large quantities of food.
Note:When Super cooling is
switched on, increased noise may
occur.
Switching on Super cooling
▶
Press (Refrigerator compart-
ment).
a (Refrigerator compartment)
lights up.
Note:After approx. 15hours, the ap-
pliance switches to normal operation.
Switching off Super cooling
▶
Press (Refrigerator compart-
ment).
a The previously set temperature is
displayed.
8.2 Automatic Super freezing
With automatic Super freezing, the
freezer compartment cools down to a
much lower temperature than for nor-
mal mode. This freezes food right
through more quickly.
The automatic Super freezing
switches on if you place fresh food in
the frozen food tray that is attached
to the rear of the large frozen food
container or in the flat frozen food
containers, starting from the right-
hand side.
If the automatic Super freezing is
switched on, (Freezer compart-
ment) lights up and increased noises
may occur.
After operation, the appliance
switches from automatic Super freez-
ing to normal operation.
Cancelling automatic Super
freezing
▶
Press (Freezer compartment).
a The previously set temperature is
displayed.
8.3 Manual Super freezing
With Super freezing, the freezer com-
partment cools as cold as possible.
Switch on Super freezing four to
sixhours before placing food weigh-
ing 2kg or more into the freezer
compartment.
In order to utilise the freezer capacity,
use Super freezing.
→"Prerequisites for freezing capa-
city", Page20
Note:When Super freezing is
switched on, increased noise may
occur.
Switching on manual Super
freezing
▶
Press (Freezer compartment).
a (Freezer compartment) lights
up.
Note:After approx. 60hours, the ap-
pliance switches to normal operation.
Switching off manual Super
freezing
▶
Press (Freezer compartment).
a The previously set temperature is
displayed.
en Alarm
18
8.4 Holiday mode
If you are going to be away for a long
time, you can switch on energy-sav-
ing holiday mode on the appliance.
CAUTION
Risk of harm to health!
The refrigerator compartment heats
up while the holiday mode is
switched on. The increased temperat-
ure may cause bacteria to increase
and spoil the food.
▶
When the holiday mode is
switched on, do not store any food
in the refrigerator compartment.
The appliance automatically sets the
temperatures.
Refrigerator com-
partment
14°C
Freezer compart-
ment
Temperature re-
mains un-
changed
Switching on holiday mode
▶
Press .
a lights up.
a No temperature is shown in the
temperature display (refrigerator
compartment).
Switching off holiday mode
▶
Press .
a The previously set temperature is
displayed.
Alarm
9 Alarm
Alarm
9.1 Door alarm
If the appliance door is open for a
while, the door alarm switches on.
A warning tone sounds.
Switching off the door alarm
▶
Close the appliance door or press
.
a The warning tone is switched off.
9.2 Temperature alarm
If the freezer compartment becomes
too warm, the temperature alarm is
switched on.
A warning tone sounds and
lights up.
CAUTION
Risk of harm to health!
During the thawing process, bacteria
may multiply and spoil the frozen
food.
▶
Do not refreeze food after it has
been defrosted or started to de-
frost.
▶
Refreeze food only after cooking.
▶
These items should no longer be
stored for the maximum storage
period.
The temperature alarm can be
switched on in the following cases:
¡ The appliance is switched on.
Do not store any food until the ap-
pliance has reached the set tem-
perature.
¡ Large quantities of fresh food are
being placed inside.
Switch on Super freezing before
placing large quantities of food in
the appliance.
¡ The freezer compartment door is
open for too long.
Check whether the frozen food has
defrosted or thawed.
Switching off the temperature
alarm
▶
Press .
a The warning tone is switched off.
Refrigerator compartment en
19
a The temperature display (freezer
compartment) briefly indicates the
warmest temperature reached in
the freezer compartment. The tem-
perature display (freezer compart-
ment) then indicates the set tem-
perature again.
a From this time on, the warmest
temperature is measured again
and saved.
a lights up until the set temper-
ature is reached again.
Refrigerator compartment
10 Refrigerator compart-
ment
Refrigerator compartment
You can keep meat, sausage, fish,
dairy products, eggs, prepared meals
and pastries in the refrigerator com-
partment.
The temperature can be set from
2°C to 8°C.
The refrigerator compartment can
also be used to store highly perish-
able foods in the short to medium
term. The lower the selected temper-
ature, the longer the food remains
fresh.
10.1 Tips for storing food in
the refrigerator compart-
ment
¡ Only store food when fresh and
undamaged.
¡ Store food covered or in air-tight
packaging.
¡ Allow hot food and drinks to cool
down first before placing in the ap-
pliance.
¡ Observe the best-before date or
use-by date specified by the manu-
facturer.
10.2 Chill zones in the refri-
gerator compartment
The air circulation in the refrigerator
compartment creates different chill
zones.
Coldest zone
The coldest zone is between the ar-
row stamped on the side and the
shelf underneath.
Tip:Store highly perishable food
such as fish, sausages and meat in
the coldest zone.
Warmest zone
The warmest zone is at the very top
of the door.
Tip:Store food that does not spoil
easily in the warmest zone, e.g. hard
cheese and butter. Cheese can then
continue to release its aroma and the
butter will still be easy to spread.
10.3 "OK" sticker
The "OK" sticker lets you check
whether the refrigerator compartment
reaches the safe temperature ranges
of +4°C or colder recommended for
food.
The "OK" sticker is not included with
all models.
If the sticker does not indicate "OK",
gradually reduce the temperature.
→"Setting the refrigerator compart-
ment temperature", Page16
Once the appliance is switched on, it
may take up to 12hours until the set
temperature is reached.
Correct setting
en Freezer compartment
20
Freezer compartment
11 Freezer compartment
Freezer compartment
You can store frozen food, freeze
food and make ice cubes in the
freezer compartment.
The temperature can be set from
−16°C to −24°C.
Long-term storage of food should be
at –18°C or lower.
The freezer compartment can be
used to store perishable food long-
term. The low temperatures slow
down or stop the spoilage.
11.1 Freezing capacity
The freezing capacity indicates the
quantity of food that can be frozen
right through to the centre within a
specific period of time.
Information on freezing capacity can
be found on the rating plate. →"Appli-
ance", Fig. 1 /
5
, Page13
Prerequisites for freezing capacity
1. Approx. 24 hours before placing
fresh food in the appliance, switch
on Super freezing.
→"Switching on manual Super
freezing", Page17
2. If the appliance has a flat frozen
food container, fill this with food
first. For appliances without a flat
frozen food container, fill the low-
est frozen food container with food
first.
3. Freeze fresh food as close as pos-
sible to the side panels.
11.2 Fully utilising the freezer
compartment volume
Learn how to store the maximum
amount of frozen food in the freezer
compartment.
1. Remove all fittings from the freezer
compartment. →Page23
2. Store food directly on the shelves
and on the floor of the freezer
compartment.
11.3 Tips for storing food in
the freezer compartment
¡ Store food in air-tight packaging.
¡ Do not bring food which is to be
frozen into contact with frozen
food.
¡ Place the food over the whole area
of the compartments or the frozen
food containers.
¡ To quickly and gently freeze larger
quantities of fresh food, place this
in the top frozen food container.
¡ To ensure that the air can circulate
freely in the appliance, push the
frozen food containers in as far as
they will go.
11.4 Tips for freezing fresh
food
¡ Freeze fresh and undamaged food
only.
¡ Freeze food in portions.
¡ Cooked food is more suitable than
food that can be eaten raw.
¡ Vegetables: Wash, chop up and
blanch before freezing.
¡ Fruit: Wash, pit and perhaps peel,
possibly add sugar or ascorbic
acid solution.
¡ Food that is suitable for freezing in-
cludes baked items, fish and sea-
food, meat, game, poultry, eggs
without shells, cheese, butter and
quark, ready meals and leftovers.
¡ Food that is unsuitable for freezing
includes lettuce, radishes, eggs in
shells, grapes, raw apples and
pears, yoghurt, sour cream, crème
fraîche and mayonnaise.
Defrosting en
21
Packing frozen food
If you select suitable packaging ma-
terial and the correct type of pack-
aging, you can determine the product
quality and prevent freezer burn.
1. Place the food in the packaging.
2. Squeeze out the air.
3. Pack food airtight to prevent it
from losing flavour and drying out.
4. Label the packaging with the con-
tents and the date of freezing.
11.5 Shelf life of frozen food
at −18°C
Food Storage time
Fish, sausages, pre-
pared meals and
baked goods
up to
6months
Poultry, meat up to
8months
Vegetables, fruit up to
12months
The imprinted freezer calendar indic-
ates the maximum storage duration
in months at a constant temperature
of –18°C.
11.6 Defrosting methods for
frozen food
CAUTION
Risk of harm to health!
During the thawing process, bacteria
may multiply and spoil the frozen
food.
▶
Do not refreeze food after it has
been defrosted or started to de-
frost.
▶
Refreeze food only after cooking.
▶
These items should no longer be
stored for the maximum storage
period.
¡ Defrost animal-based food, such
as fish, meat, cheese, quark, in the
refrigerator compartment.
¡ Defrost bread at room temperat-
ure.
¡ Prepare food for immediate con-
sumption in the microwave, in the
oven or on the hob.
Defrosting
12 Defrosting
Defrosting
12.1 Defrosting in the refri-
gerator compartment
When the appliance is operating,
condensation droplets or frost form
on the rear panel of the refrigerator
compartment due to functional reas-
ons. The back panel in the refriger-
ator compartment defrosts automatic-
ally.
Condensation runs through the con-
densation channel into the drainage
hole to the evaporation pan and does
not have to be wiped away.
To ensure that the condensation can
drain and odours do not form, ob-
serve the following information:
→"Cleaning the condensation chan-
nel and drainage hole", Page23.
12.2 Defrosting in the freezer
compartment
The freezer compartment does not
defrost automatically. A layer of hoar-
frost in the freezer compartment im-
pairs refrigeration of the frozen food
and increases power consumption.
Defrosting the freezer
compartment
Regularly defrost the freezer com-
partment.
en Cleaning and servicing
22
1. Switch on Super freezing approx.
fourhours before defrosting.
→"Switching on manual Super
freezing", Page17
This means that the food reaches
very low temperatures and it can
be stored for longer at room tem-
perature.
2. Remove the frozen food container
with the frozen food and temporar-
ily place it in a cool location. Place
ice packs (if available) on the
frozen food.
3. Switch off the appliance.
→Page16
4. Disconnect the appliance from the
power supply.
Unplug the appliance from the
mains or switch off the circuit
breaker in the fuse box.
5. To accelerate the defrosting pro-
cess, place a pan of hot water on
a trivet in the freezer compartment.
6. Wipe up the condensation water
with a soft cloth or sponge.
7. Rub the freezer compartment dry
with a soft, dry cloth.
8. Electrically connect the appliance.
9. Switch on the appliance.
→Page16
10.Reinsert the frozen food containers
with the frozen food.
Cleaning and servicing
13 Cleaning and servi-
cing
Cleaning and servicing
To keep your appliance working effi-
ciently for a long time, it is important
to clean and maintain it carefully.
Customer Service must clean inac-
cessible points. Cleaning by cus-
tomer service can give rise to costs.
13.1 Preparing the appliance
for cleaning
1. Switch off the appliance.
→Page16
2. Disconnect the appliance from the
power supply.
Unplug the appliance from the
mains or switch off the circuit
breaker in the fuse box.
3. Take out all of the food and store it
in a cool place.
Place ice packs (if available) onto
the food.
4. If there is a layer of hoarfrost, allow
this to defrost.
5. Remove all fittings and accessor-
ies from the appliance.
→Page23
6. Remove the shelf above the fruit
and vegetable container.
→Page24
13.2 Cleaning the appliance
WARNING
Risk of electric shock!
An ingress of moisture can cause an
electric shock.
▶
Do not use steam- or high-pres-
sure cleaners to clean the appli-
ance.
Liquid in the lighting or in the con-
trols can be dangerous.
▶
The rinsing water must not drip
into the lighting or controls.
ATTENTION!
Unsuitable cleaning products may
damage the surfaces of the appli-
ance.
▶
Do not use hard scouring pads or
cleaning sponges.
▶
Do not use harsh or abrasive de-
tergents.
▶
Do not use cleaning products with
a high alcohol content.
Cleaning and servicing en
23
If liquid gets into the drainage hole,
the evaporation pan may overflow.
▶
The rinsing water must not get into
the drainage hole.
If you clean fittings and accessories
in the dishwasher, this may cause
them to become deformed or discol-
our.
▶
Never clean fittings and accessory
in the dishwasher.
1. Prepare the appliance for cleaning.
→Page22
2. Clean the appliance, the fittings,
the accessories and the door seals
with a dish cloth, lukewarm water
and a little pH-neutral washing-up
liquid.
3. Dry thoroughly with a soft, dry
cloth.
4. Insert the fittings and install the ap-
pliance components.
5. Electrically connect the appliance.
6. Switch on the appliance.
→Page16
7. Putting the food into the appliance.
13.3 Cleaning the condensa-
tion channel and drain-
age hole
Regularly clean the condensation
channel and drainage hole to ensure
that the condensation can drain.
▶
Carefully clean the condensation
channel and the drainage hole,
e.g. using a moistened cotton bud.
13.4 Removing the fittings
If you want to clean the fittings thor-
oughly, remove these from your ap-
pliance.
Removing the shelf
▶
Pull out and remove the shelf.
en Cleaning and servicing
24
Removing the extendable shelf
1. Firmly pull out the extendable shelf
until the locking catch is released.
2. Lower the shelf and swing it out to
the side.
Removing door rack
▶
Lift the door rack and remove it.
Removing the fruit and vegetable
container
1. Pull out the fruit and vegetable
container as far as it will go.
2. Lift the fruit and vegetable con-
tainer at the front and remove it
.
Removing the frozen food
container
1. Take out the frozen food container
as far as it will go.
2. Lift the frozen food container at the
front and remove it .
13.5 Removing appliance
components
If you want to clean your appliance
thoroughly, you can remove certain
components from your appliance.
Removing the shelf above the fruit
and vegetable container
1. Pull out the fruit and vegetable
container.
Cleaning and servicing en
25
2. Remove the shelf and rotate it
.
3. Press the fastenings for the lower
cover outwards.
4. Lift the cover at the front and
pull it out at the rear .
en Troubleshooting
26
Troubleshooting
14 Troubleshooting
Troubleshooting
You can rectify minor faults on your appliance yourself. Read the troubleshoot-
ing information before contacting after-sales service. This will avoid unneces-
sary costs.
WARNING
Risk of electric shock!
Incorrect repairs are dangerous.
▶
Repairs to the appliance should only be carried out by trained specialist
staff.
▶
Only use genuine spare parts when repairing the appliance.
▶
If the power cord of this appliance is damaged, it must be replaced by the
manufacturer, the manufacturer's Customer Service or a similarly qualified
person in order to prevent any risk.
Fault Cause and troubleshooting
The appliance is not
cooling, the displays
and lighting are lit.
Showroom mode is switched on.
▶
Carry out the appliance self-test. →Page29
a Once the appliance self-test has ended, the appli-
ance switches to normal operation.
The LED lighting does
not work.
Different causes are possible.
▶
Call customer service.
The customer service number can be found in the
enclosed customer service directory.
or appears in the
temperature display.
The electronics have detected a fault.
1.
Switch off the appliance. →Page16
2. Disconnect the appliance from the mains.
Unplug the appliance from the mains or switch off
the circuit breaker in the fuse box.
3. Reconnect the appliance after five minutes.
4. If the message still appears on the display, call cus-
tomer service.
The customer service number can be found in the
enclosed customer service directory.
Troubleshooting en
27
Fault Cause and troubleshooting
The temperature dis-
play (freezer compart-
ment) flashes.
The temperature in the freezer compartment was too
warm.
1. Press .
a The temperature display (freezer compartment)
briefly indicates the warmest temperature reached
in the freezer compartment. The temperature dis-
play (freezer compartment) then indicates the set
temperature again.
2. Press .
a The temperature display (freezer compartment) no
longer flashes.
A warning tone
sounds, the temperat-
ure display (freezer
compartment) flashes
and lights up.
Different causes are possible.
▶
Press .
a The alarm is switched off.
The appliance door is open.
▶
Close the appliance door.
The exterior ventilation grilles are blocked.
▶
Remove any obstructions from in front of the exter-
ior ventilation grilles.
Larger quantities of fresh food have been put in.
▶
Do not exceed the max. freezing capacity.
→"Freezing capacity", Page20
The temperature dif-
fers greatly from the
setting.
Different causes are possible.
1.
Switch off the appliance. →Page16
2. Switch the appliance back on after fiveminutes.
→Page16
‒ If the temperature is too warm, check the temper-
ature again after a couple of hours.
‒ If the temperature is too cold, check the temper-
ature again on the following day.
The base of the refri-
gerator compartment
is wet.
The condensation channel or drainage hole are
blocked.
▶
Clean the condensation channel and the drainage
hole. →Page23
The appliance hums,
bubbles, buzzes,
gargles or clicks.
Not a fault. A motor is running, e.g. refrigerating unit,
fan. Refrigerant flows through the pipes. The motor,
switches or solenoid valves are switching on or off.
No action required.
The appliance makes
noises.
Fittings wobble or stick.
▶
Check the removable fittings and, if required, re-
place these.
en Troubleshooting
28
Fault Cause and troubleshooting
The appliance makes
noises.
Bottles or containers are touching.
▶
Move the bottles or containers away from each
other.
Super freezing is switched on.
No action required.
Storage and disposal en
29
14.1 Power failure
During a power failure, the temperat-
ure in the appliance rises; this re-
duces the storage time and the qual-
ity of the frozen food.
On the website for your appliance,
the technical data provides you with
the storage times for frozen food in
the event of a fault.
Notes
¡ Open the appliance as little as
possible during a power failure
and do not place any other food in
the appliance.
¡ Check the quality of the food
immediately after a power failure.
– Dispose of any frozen food that
has defrosted and is hotter than
5°C.
– Cook or fry slightly thawed
frozen food, and then either con-
sume it or freeze it again.
14.2 Conducting an appliance
self-test
1. Switch off the appliance.
→Page16
2. Switch the appliance back on after
approx. fiveminutes. →Page16
3. Within the first 10seconds after
switching on, press and hold
(Freezer compartment) for 3 to
5seconds until an audible signal
sounds.
a The appliance self-test starts.
a While the appliance self-test is run-
ning, a long audible signal sounds.
a If, at the end of the appliance self-
test, two audible signals sound
and the temperature display indic-
ates the set temperature, your ap-
pliance is OK. The appliance
switches to normal operation.
a If, at the end of the appliance self-
test, five audible signals sound
and (Freezer compartment)
flashes for 10seconds, inform the
after-sales service.
Storage and disposal
15 Storage and disposal
Storage and disposal
You can find out here how to prepare
your appliance for storage. You will
also find out how to dispose of old
appliances.
15.1 Taking the appliance out
of operation
1. Switch off the appliance.
→Page16
2. Disconnect the appliance from the
power supply.
Unplug the appliance from the
mains or switch off the circuit
breaker in the fuse box.
3. Remove all of the food.
4.
Defrost the appliance. →Page21
5.
Clean the appliance. →Page22
6. To guarantee the ventilation inside
the appliance, leave the appliance
open.
15.2 Disposing of old appli-
ance
Valuable raw materials can be re-
used by recycling.
WARNING
Risk of harm to health!
Children can lock themselves in the
appliance, thereby putting their lives
at risk.
▶
Leave shelves and containers in-
side the appliance to prevent chil-
dren from climbing in.
▶
Keep children away from the re-
dundant appliance.
en Customer Service
30
WARNING
Risk of fire!
If the tubes are damaged, flammable
refrigerant and harmful gases may
escape and ignite.
▶
Do not damage the tubes of the re-
frigerant circuit or the insulation.
1. Unplug the appliance from the
mains.
2. Cut through the power cord.
3. Dispose of the appliance in an en-
vironmentally friendly manner.
Information about current disposal
methods are available from your
specialist dealer or local authority.
This appliance is la-
belled in accordance
with European Directive
2012/19/EU concerning
used electrical and elec-
tronic appliances (waste
electrical and electronic
equipment - WEEE).
The guideline determ-
ines the framework for
the return and recycling
of used appliances as
applicable throughout
the EU.
Customer Service
16 Customer Service
Customer Service
If you have any queries, are unable to
rectify faults on the appliance your-
self or if your appliance needs to be
repaired, contact Customer Service.
Function-relevant genuine spare parts
according to the corresponding Eco-
design Order can be obtained from
Customer Service for a period of at
least 10 years from the date on
which your appliance was placed on
the market within the European Eco-
nomic Area.
Note:Under the terms of the manu-
facturer's warranty applicable to the
location, the use of Customer Service
is free of charge. The minimum dura-
tion of the warranty (manufacturer's
warranty for private consumers) in
the European Economic Area is 2
years according to the terms of war-
ranty applicable to the location. The
terms of warranty do not affect other
rights or claims held by yourself un-
der local legislation.
Detailed information on the warranty
period and terms of warranty in your
country is available from our after-
sales service, your retailer or on our
website.
If you contact Customer Service, you
will require the product number (E-
Nr.) and the production number (FD)
of your appliance.
The contact details for Customer Ser-
vice can be found in the enclosed
Customer Service directory or on our
website.
16.1 Product number (E-Nr.)
and production number
(FD)
You can find the product number (E-
Nr.) and the production number (FD)
on the appliance's rating plate.
→"Appliance", Fig. 1 /
5
, Page13
Make a note of your appliance's de-
tails and the Customer Service tele-
phone number to find them again
quickly.
Technical data
17 Technical data
Technical data
Refrigerant, cubic capacity and fur-
ther technical specifications can be
found on the rating plate.
→"Appliance", Fig. 1 /
5
, Page13
Technical data en
31
You can find more information about
your model online at https://
eprel.ec.europa.eu/
1
. This web ad-
dress is linked to the official EU
EPREL product database. Please
then follow the instructions on
searching for models. The model
identifier is made up of the charac-
ters before the slash in the product
number (E-Nr.) on the rating plate. Al-
ternatively, you can also find the
model identifier in the first line of the
EU energy label.
1
Only applies to countries in the European Economic Area
Constructa-Neff Vertriebs-GmbH
Carl-Wery-Straße 34
81739 München
GERMANY
Valid within Great Britain:
Imported to Great Britain by
BSH Home Appliances Ltd.
Grand Union House
Old Wolverton Road
Wolverton, Milton Keynes
MK12 5PT
United Kingdom
*9001590897*
9001590897
en
010810
