WATER ALERT SYSTEM OWNERS MANUAL
FOR SKUS: 691-3703, 691-3704, 691-3705
*ALL SKUS ARE SOLD SEPARATELY*
GENERAL USE AND APPLICATIONS
Insurance companies cite water damage from faulty plumbing, flooded
basements & frozen pipes as the third most common cause of
homeowner claims. While you can’t predict water leaks or mechanical
failure, you can improve your response time with a Barracuda Water
Alert System to help you protect your property and minimize repair
costs.
With the alert system, you use your smartphone to monitor for water
leaks, sump basin water levels and high or low temperature/humidity
levels to prevent damage. Water damage can be caused by frozen or
broken pipes, rusty water heaters, leaky roofs, basements and
foundations from snow, rain or floods, faulty plumbing installation, sump
pump basin overflow, leaky dishwasher hoses and washing machine
overflow.
Monitor and protect property: By purchasing and connecting a
control tower/gateway to your existing network router, and downloading
the app from www.barracudapumps.com/alerts. The control tower/
gateway will communicate with the separately purchased sensors/
probes to monitor your home and will send you text and e-mail alerts.
MONITORING APPLICATIONS
Home, second home, office or rental property
Kitchens, baths, laundry & pool rooms
Utility sinks, sumps & water heaters
Basements, garages, attics, greenhouses & farms
Sump pump basins
Near aquariums & terrariums
ADDITIONAL EQUIPMENT (NOT INCLUDED)
Two AAA 1.5V Alkaline batteries
Browser with high speed Internet
Network router
HOW IT WORKS
The wireless water alert sensor(s)/probe(s) monitors wet/dry
conditions, water level and temperature/humidity; it sends the
data to the control tower/gateway up to 200 ft. (60.96m). See
important setup and operation section for range information.
Connect the control tower/gateway to your network router with
the included LAN cable. The control tower/gateway uses your
high speed Internet connection to send the data to your app.
Information can be viewed via the app and text and email
alerts will be sent. (1 year included)
Add up to 5 wireless remote & sensors/probes (sold
separately) per control tower/gateway to monitor in other
areas.
SETUP AND ACTIVATION OF THE
WATER ALERT SYSTEM
Download La Crosse Mobile App
1. www.barracudapumps.com/alerts
2. iOS App Store, search La Crosse Alerts Mobile
3. Android Play Store, search La Crosse Alerts Mobile
Follow directions on the mobile device screen to register; for
assistance, see support menu within the app.
CUSTOMER SUPPORT / RESOURCES
Barracuda Customer Support: 1-800-495-9278
Web support: www.barracudapumps.com/alerts
FACTORY RESET - UNREGISTERED PRODUCT
(For unregistered product, try the following before contacting support)
Reset control tower / gateway
1. remove a/c cord
2. Press and hold gray button
3. reinsert a/c cord
4. release button aft.er red light blinks 4 times
Remote & Sensor/Probe – press and hold gray button until segments fill with
18.88; try registration when counting begins
NOTE: For registered product, do not reset, see support menu within the app
for additional information.
DIAGNOSE CONTROL TOWER/GATEWAY LIGHTS
1 blink – LAN cable missing; cable or port bad
2 blinks – no internet protocol (IP) address from router
3 blinks – no DNS resolve; aka can’t find server
4 blinks – ready to register
Both Blink – existing registration not deleted
No Lights – check a/c power or factory reset
Solid Red – registered gateway
WATER
ALERT
CONTROL
TOWER/
GATEWAY
691-3703*
*Requires
purchase of
691-3704
and/or
691-3705
WIRELESS
REMOTE
WATER
ALERT
REED
SENSOR
691-3705*
*Requires
purchase
of 691-3703
WIRELESS REMOTE
WATER ALERT
FLOOR
SENSOR/
PROBE
691-3704*
*Requires
purchase of
691-3703
*WHAT YOU NEED TO PUCHASE*
YOU NEED 1 & 2 - ALL ITEMS SOLD SEPARATELY
WATER ALERT CONTROL TOWER/GATEWAY SKU: 691-3703
- Requires purchase of 691-3704 and/or 691-3705
Receives information from the water alert sensors/probes.
The control tower/gateway can receive information from up
to 5 wireless water alert sensors/probes.
Package Contents: Control tower/gateway, 4 ft. cat 5
Ethernet cable, power adapter, mounting bracket, hardware
pack and installation instructions.
WIRELESS REMOTE WATER ALERT FLOOR SENSOR/
PROBE SKU: 691-3704 - Requires purchase of 691-3703
Senses temperature, humidity & wet/dry conditions.
Sends this information to the control tower/gateway.
Package Contents: Wireless remote, floor sensor with
6ft. cable, mounting bracket, hardware pack and
installation instructions.
WIRELESS REMOTE WATER ALERT REED SENSOR
SKU: 691-3705 - Requires purchase of 691-3703
For use in sump pump basins. Senses temperature,
humidity & water level within the sump basin. Sends
this information to the control tower/gateway.
Package Contents: Wireless remote, reed sensor with 8
ft. cable, mounting bracket, stainless steel hose clamp
and installation instructions.
CONTROL TOWER/GATEWAY INSTALLATION
Control tower/gateway hardware cabling (if not registered*)
Connect LAN cable between router & gateway.
Insert a/c power cord in control tower/gateway.
Watch for 4 red blinks (if not, see diagnose gateway)
*a registered gateway shows a solid red light (verify existing status before add sensor)
You will need to purchase a 691-3704 Wireless remote floor sensor/probe and/or
691-3705 Wireless remote reed sensor to complete the water alert system.
1
2
AND/OR
