Cord/Cordless Lithium-Ion Trimmer
Model No. PT-1L
Operating Manual
Manual De Operación
Manual D’Utilisation
Includes But Not Limited To:
Sterling Mag
WAHL Beret
TECHNICAL SUPPORT AND QUESTIONS
Phone: 1-800-776-9245
Email: techsupport@wahlclipper.com
Website: www.wahlpro.com
Wahl Clipper Corporation offers a limited warranty on this product.
Please visit our website for full warranty terms.
© WAHL CLIPPER CORPORATION
Sterling, IL USA
FORM #92566-1301 Printed in USA
For Products Marked
with an FCC Approval:
1. This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause
undesired operation.
2. Changes or modifications not expressly approved by the party
responsible for compliance could void the user’s authority to
operate this device.
3. NOTE: This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However,
there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
− Reorient or relocate the receiving antenna.
− Increase the separation between the equipment and receiver.
− Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
− Consult the dealer or an experienced radio/TV technician for help.
Para Productos Marcados
con Aprobación de la FCC:
1. Este dispositivo cumple con la parte 15 de las Reglas de la FCC.
Su operación está sujeta a las dos condiciones siguientes: (1)
Este dispositivo no puede causar interferencia nociva, y (2) este
dispositivo debe aceptar cualquier interferencia recibida, incluyendo
la interferencia que pueda causar una operación indeseada.
2. Los cambios y modificaciones que no sean aprobados
explícitamente por la parte responsable del cumplimiento podrían
anular la autorización del usuario para usar este dispositivo.
3. NOTA: Este equipo ha sido probado y se ha determinado que cumple
con los límites de un dispositivo digital de Clase B, en los términos
de la parte 15 de las Reglas de la FCC. Estos límites están diseñados
para brindar una protección razonable contra la interferencia nociva
en una instalación residencial. Este equipo genera, utiliza y puede
emitir energía de radiofrecuencia y, de no instalarse y usarse de
acuerdo con las instrucciones, puede causar interferencia nociva a
las radiocomunicaciones. Sin embargo, no hay garantía de que no
ocurrirá interferencia en una instalación en particular. Si este equipo
causa interferencia nociva a la recepción de radio o televisión, lo
que puede determinarse al encender y apagar el equipo, se invita al
usuario a tratar de corregir la interferencia tomando una o más de
las siguientes medidas:
− Reorientar o reubicar la antena de recepción.
− Aumentar la separación entre el equipo y el receptor.
− Conectar el equipo a un tomacorriente que esté en un circuito
diferente a aquel en el que está conectado el receptor.
− Consultar a su distribuidor o a un técnico experimentado de
radio y televisión.
FIND US ON SOCIAL MEDIA
For servicing, please ship your product prepaid to:
Wahl Service Center
3001 North Locust Street
Sterling, IL 61081
IMPORTANT
SAFEGUARDS
When using your electrical appliance, basic precautions should always
be followed, including the following:
READ ALL INSTRUCTIONS AND SAFEGUARDS
BEFORE USING THIS APPLIANCE.
DANGER
To reduce the risk of death or injury by electric shock:
1. Do not reach for an appliance that has fallen into water. Unplug
immediately from the outlet. Note: Some electrical parts inside the
appliance are electrically live, even with the switch “OFF.”
2. Do not use while bathing or in a shower.
3. Do not place or store appliance where it can fall or be pulled into a
tub or sink. Do not place in or drop into water or other liquid.
4. Always unplug this appliance before cleaning.
5. Except when charging, always unplug this appliance from the
electrical outlet immediately after using.
WARNING
To reduce the risk of burns, electrical shock or injury to persons:
1. This appliance can be used by children aged from 14 years and
above and persons with reduced physical, sensory or mental
capabilities or lack of experience and knowledge if they have
been given supervision or instruction, by a person responsible for
their safety, concerning the use of the appliance in a safe way and
understand the hazards involved. Children should be supervised to
ensure that they do not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
2. Use this appliance only for its intended use as described in this manual.
Do not use attachments not recommended by the manufacturer.
3. Never operate this appliance if it has a damaged cord or plug, if it
is not working properly, if it has been dropped or damaged, or if it
has been dropped into water. Return the appliance to Wahl Clipper
Corporation for examination and repair.
4. Keep the cord away from heated surfaces.
5. Never operate the appliance with the air openings blocked or while
on a soft combustible surface, such as a bed or couch, where air
openings may be blocked. Keep the air openings (if any) free from
lint, hair or the like.
6. Do not use outdoors or operate where aerosol (spray) products are
being used or where oxygen is being administered.
7. Never drop or insert any object into any opening.
8. Do not use this appliance with a damaged or broken comb nor with
teeth missing from the blades, as injury may occur. Before use,
make certain blades are aligned properly. (See Clipper or Trimmer
Care Instructions. May not be applicable for all appliances.)
9. During use, do not place or leave the appliance where it is expected
to be subject to damage by an animal, or exposed to weather.
10. To disconnect, turn all controls to “OFF,” then remove plug or
charger from outlet.
11. Turn all controls to “OFF” before placing on or removing blades or
attachments.
12. An appliance with a permanently attached cord should never be left
unattended when plugged in.
13. Keep this appliance dry.
For an appliance that has a rechargeable battery:
14. Do not crush, disassemble, heat above 100°C (212°F), or incinerate
the appliance, due to risk of fire, explosion, or burns.
15. For the purpose of recharging the battery, only use the detachable
power supply unit (charger) provided with this appliance.
16. This charger is intended to be correctly orientated in a vertical or
floor mount position.
17. Always attach plug to appliance first, then to outlet.
18. Use charge stand with Wahl products and power supplies only.
SAVE THESE
INSTRUCTIONS
THIS APPLIANCE IS FOR COMMERCIAL USE ONLY
TRIMMER USE
USING CORD/CORDLESS TRIMMERS
If battery power is low, the power cord can attach directly to the unit
for continued use as a corded unit.
CORDED OPERATION
• Attach power cord plug into
trimmer first, then to outlet.
If your battery is completely run
down, allow the unit to charge
for 1 minute (switched OFF)
before using as a corded unit.
(Figure 1)
• If the cord is left attached to the
trimmer when not in use, the
cord will automatically charge
the trimmer when left in the
OFF position.
RECHARGING OPTIONS
• For units without a recharge
stand, attach power cord
plug into trimmer first, then
to outlet. Be sure trimmer is
switched OFF when charging.
(Figure 1)
• For units with a recharge
stand, place trimmer in
recharge stand so nameplate
faces forward. (Figure 2) Attach
power cord plug into recharge
stand first, then to outlet.
(Figure 3) (Not all units have a
recharge stand.)
CHARGING THE BATTERY
Before the equipment is used for the first time, it should be charged
3-5 hours. For recharging information, refer to Trimmer Use
Recharging Options.
Recommendation: The batteries should only be recharged when
the performance of the equipment has deteriorated noticeably.
BATTERY OPERATION
Switch ON the unit using the ON/OFF switch and, after use, switch it
OFF again. When the battery is fully charged, the unit can be used for
up to 120 minutes continuous run time.
2 hours to reach a full charge with a discharged battery.
LED INDICATOR
During charging, the charge indicator is illuminated. The charge
indicator will begin to blink when almost fully charged and may shut
off when fully charged.
STANDARD BLADE REMOVAL AND
INSTALLATION
To remove the blades, hold the
unit firmly in your hand and push
the blades away from the front
of the trimmer. The blades and
mounting plate behind them will
all come off in one piece. Use the
cleaning brush provided to clean
away any hair that has become
clogged between the blades. Oil
the blades after cleaning. Before replacing blades, make sure the
two spring wires are firmly seated in the notches provided and that
the top blade moves freely. If springs are not firmly seated, your unit
may malfunction and make a very loud noise. To replace blades, place
the tab at the bottom of the blade unit into the space provided on
the unit. Once it is seated, snap blade into place. You will hear a click
when the blades are fully in place.
LITHIUM-ION BATTERY REPLACEMENT,
TRIMMER DISPOSAL AND RECYCLING
• This unit uses a Lithium-Ion battery. For battery replacement
send the entire, intact unit to:
Wahl Service Center
3001 North Locust Street
Sterling, IL 61081
• Do not attempt to remove the battery. Lithium-Ion batteries can
explode, catch fire, and/or cause burns if disassembled, damaged,
or exposed to water or high temperatures.
• If you choose not to send the appliance in for battery
replacement, the entire intact unit must be disposed. Do not
attempt to remove the battery for disposal. Lithium-Ion batteries
may be subject to local disposal regulations. Many locations
prohibit disposal in standard waste receptacles. Check your local
laws and regulations.
• For recycling contact a government recycling agency, waste
disposal service, retailer, or visit online recycling sources, such as
www.batteryrecycling.com or www.rbrc.org.
TROUBLESHOOTING
If your cord/cordless trimmer does not seem to be operating or
charging properly, please check the following:
• Check the outlet’s current by plugging another appliance (one
you know is in proper working condition) into the outlet.
• Make sure the unit is not connected to a power source that turns
itself off when lights are turned off.
• Make sure the unit and power cord contacts are clean and free of
hair or other contaminants.
• Verify that the blade assembly moves freely and is mounted properly.
If you still encounter problems with your unit, send your unit and
recharging transformer to Wahl Clipper Corporation with a note
explaining the problem.
Wahl Clipper Corporation offers a limited warranty on this product.
Please visit our website for full warranty terms.
TRIMMER CARE
BLADE CARE AND OILING
In order to ensure that you get the most life and performance out
of the trimmer, we recommend oiling daily. To oil it properly, the
trimmer should be held so the blades are in a downward position as
shown. Place one drop of Wahl oil in the center of the movable top
blade and one drop of oil on each end of the top blade. Turn trimmer
switch ON and run to distribute the oil. When oil is evenly distributed,
turn trimmer OFF and wipe off excess oil with a soft cloth. Periodically
oil heel of blade (shown in image) to reduce blade friction.
(USE WAHL OIL ONLY)
WIPE OFF EXCESS OIL so it does not run into the motor compartment.
Oil in the motor compartment will eventually lead to poor motor performance.
Blades should be oiled after using disinfectant or sanitizing solution.
UNIT CARE
Use a clean cloth (dry or dampened with water).
DO NOT USE bleach, benzene or thinner to clean the unit.
CORD CARE
The cord should never be used to pull the trimmer. Freedom of
movement needs to be maintained. Care should be used to keep the
cord untwisted, and undamaged. When stored, the cord should be
coiled and placed neatly in a dry place.
For servicing, please ship your product prepaid to:
Wahl Service Center
3001 North Locust Street
Sterling, IL 61081
Loading ...
Loading ...
Loading ...
