Perlick is commied to connuous improvement. Therefore, we reserve the right to change specicaons without warning.
FORM NO. Z2503
REV. A-11/07/2017
cr24F | 24” FREEZER column
PRODUCT SPECIFICATIONS
Appliance Dimensions
Exterior Width 23-3/4”
Exterior Depth 24”*
Exterior Height 83-11/16”
Required Cutout
Dimensions
Cutout Width 24”
Cutout Depth 25”
Cutout Height 84”
Depth with Door Open
50”
Product Weight
448 lbs
Capacity
12.6 cu. .
Electrical
Requirements
Electrical Supply 115V, 60 Hz., 1
Phase, 2.3 amps
Electrical Service 15 amp dedicated
circuit
Power Cord/
Receptacle
NEMA 5-15
plug, 5’ /3 prong
grounding-type
TEMPERATURE RANGES
Main Compartment
Factory Set to 0° (Range -10°-10°F)
QUICK FEATURES
▪ Ready to accept custom or stainless steel panel
▪ Touch-screen control streamlines the user experience.
Customize to your temperature preference in 1° increments.
Access sengs for lighng, Sabbath mode and more with a
single touch.
▪ Brightly illuminated by white roll-on theatre lighng
▪ Sleek stainless steel interiors
▪ Open pull out bins provide quick access to frozen goods
*Less panel. With typical 3/4” overlay panel installed, depth
becomes 24-3/4”
84"
4"
24"
83 11/16"
14 1/8"
66 1/2"
4"
OVERLAY TEMPLATE
DIMENSIONAL LIMIT
21.5/8"
1 4/5"
13 3/8"
22 3/16"
24 1/16"
23 3/4"
28"
90°
50 1/8"
1/2"
3"
3"
10 3/4"
5 1/4"
ELECTRICAL
OUTLET
LOCATION
CABINET
OPENING
84"
4"
24"
83 11/16"
14 1/8"
66 1/2"
4"
OVERLAY TEMPLATE
DIMENSIONAL LIMIT
21.5/8"
1 4/5"
13 3/8"
22 3/16"
24 1/16"
23 3/4"
28"
90°
50 1/8"
1/2"
3"
3"
10 3/4"
5 1/4"
ELECTRICAL
OUTLET
LOCATION
CABINET
OPENING
84"
4"
24"
83 11/16"
14 1/8"
66 1/2"
4"
OVERLAY TEMPLATE
DIMENSIONAL LIMIT
21.5/8"
1 4/5"
13 3/8"
22 3/16"
24 1/16"
23 3/4"
28"
90°
50 1/8"
1/2"
3"
3"
10 3/4"
5 1/4"
ELECTRICAL
OUTLET
LOCATION
CABINET
OPENING
