PART NO. DESCRIPTION
PAC
1211
PAC
1811
PAC
2412
PAC
3612
PAC
3632
PAC
3634
PAC
6012
PAC
6032
PAC
6034
ELECTRICAL COMPONENTS
025-001
Transformer, 24V, 40VA
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
025-002
Contactor, 20AMP, 2-Pole, 24V coil
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
025-003
Contactor, 30AMP, 2-Pole, 24V coil
✓
025-005
Contactor, 30AMP, 3-Pole, 24V coil
✓ ✓ ✓ ✓
025-009
Contactor, 40 AMP, 2-Pole, 24V coil
✓
025-011
Transformer, High Voltage, 2 KVA
✓ ✓
025-045
3-Phase Monitor (208-230V)
✓ ✓
025-046
3-Phase Monitor (460V)
✓ ✓
027-001
Red Indicator Light
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
028-026
LCDI Cord (5-15P), #30380550
✓
028-027
LCDI Cord (5-20P), #30390005
✓
028-024
LCDI Cord (6-20P), #30389503
✓
028-028
LCDI Cord (6-30P), #30384012
✓
028-014
Svc Cord, 8/3 (10ft) w/(6-50P) Plug
✓
028-016
Cord Plug (L15-30P)
✓ ✓
028-018
Cord Cable SOW 10/4 (10 ft)
✓ ✓ ✓ ✓
028-029
Cord Plug (L16-20P)
✓ ✓
029-002
Condensate Tank Micro Switch Assy
✓ ✓ ✓ ✓ ✓ ✓
029-003
Rocker Switch
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
CONTROLS
066-021
Cooling Thermostat BA8724 (S/N: U1-34483 and higher)
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
SA066-005REPL
Replacement Thermostat for Robertshaw (300-205)
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
066-014
Hi-Pres. Cut-Out, Man. Reset, 600 PSI
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
PAC (R410A)
Portable Spot Cooler (Air Cooled)
When ordering, please specify the MODEL and SERIAL NUMBER of the unit, to ensure accuracy.
Need help identifying a part? Call our KEEP COOL TEAM (847) 583-0311
SERVICE PARTS LIST
Effective: 02-11-2021
Information is subject to change without notice
oceanaire-inc.com (847) 583-0311 Page 1 of 4
PART NO. DESCRIPTION
PAC
1211
PAC
1811
PAC
2412
PAC
3612
PAC
3632
PAC
3634
PAC
6012
PAC
6032
PAC
6034
PAC (R410A)
Portable Spot Cooler (Air Cooled)
When ordering, please specify the MODEL and SERIAL NUMBER of the unit, to ensure accuracy.
Need help identifying a part? Call our KEEP COOL TEAM (847) 583-0311
SERVICE PARTS LIST
Effective: 02-11-2021
AIR FILTERS
030-033
Evaporator Filter 11-1/2 X 17-7/8 (bhb)
✓
030-041
Condenser Filter 15-7/8 X 15-7/8 (AL)
✓
030-039
Evaporator Filter 16-3/4 X 20-1/2 (bhb)
✓ ✓
030-011
Condenser Filter 19-15/16 X 23-7/8 (AL)
✓ ✓
030-045
Evaporator Filter 23-3/4 X 20 9 (bhb)
✓ ✓ ✓
030-044
Condensed Filter 23-3/4 X 28 (AL)
✓ ✓ ✓
030-042
Evaporator Filter 23-3/4 X 24-3/4 (bhb)
✓ ✓ ✓
030-014
Condenser Filter 23-3/4 x 29-3/4 (AL)
✓ ✓ ✓
GRILLES
038-045
Evap Discharge Grille 5-1/8 X 11-11/16
✓
038-049
Evap Return Grille 11-3/4 x 17-7/8
✓
038-046
Evap Discharge Grille 8-1/2 X 13-3/4
✓ ✓
076-682
Evap Discharge Grille Frame (18, 24)
✓ ✓
038-051
Evap Return Grille 20-7/8 X 17-3/16
✓ ✓
038-036
Evap Discharge Grille 10-3/4 X 19
✓ ✓ ✓ ✓ ✓ ✓
038-040
Evap Return Grille 19-3/4 X 23
✓ ✓ ✓
038-050
Evap Return Grille 23-7/8 X 24-7/8
✓ ✓ ✓
CASTERS
011-005
4” Gray w/Brake (Tente casters after Y142457)
✓ ✓ ✓ ✓ ✓ ✓
011-006
4” Gray, Swivel
✓ ✓ ✓ ✓ ✓ ✓
011-012
5”, Gray w/Brake
✓ ✓ ✓
011-011
5” Gray, Swivel
✓ ✓ ✓
COILS
031-015
Evap Coil (1015)
✓
031-039
Cond Coil (1039)
✓
031-048
Evap Coil (3048)
✓ ✓
031-046
Cond Coil (3046)
✓ ✓
031-043
Evap Coil (3043)
✓ ✓ ✓
031-044
Cond Coil (3044)
✓ ✓ ✓
031-040
Evap Coil (3040)
✓ ✓ ✓
031-041
Cond Coil (3041)
✓ ✓ ✓
Information is subject to change without notice
oceanaire-inc.com (847) 583-0311 Page 2 of 4
PART NO. DESCRIPTION
PAC
1211
PAC
1811
PAC
2412
PAC
3612
PAC
3632
PAC
3634
PAC
6012
PAC
6032
PAC
6034
PAC (R410A)
Portable Spot Cooler (Air Cooled)
When ordering, please specify the MODEL and SERIAL NUMBER of the unit, to ensure accuracy.
Need help identifying a part? Call our KEEP COOL TEAM (847) 583-0311
SERVICE PARTS LIST
Effective: 02-11-2021
BLOWER WHEEL & HOUSING
013-025
Blower Wheel 6-5/16” D x 6-7/8” W
E & C E
013-111
Blower Wheel 6-5/16” D x 6-7/8” W Fergas
E
013-112
Blower Wheel 8" D X 8" W
C C E E E
013-121
Blower Wheel 10" D X 10" W
E E E
013-126
Blower Wheel 10" D X 10" W
C C C
013-027
Blower Assy 10-10T (Wheel & Housing)
E E E
013-037
Blower Assy 10-10T (Wheel & Housing)
C C C
013-118
Blower Assy 10-10R (Wheel & Housing)
C C C
FAN MOTORS
SA050-025
Fan Motor Assembly 7190-3398 (with capacitor)
C
050-026
Fan Motor 7190-3425 (with capacitor)
E E
SA050-021
Fan Motor Assembly DF3G036N (with capacitor)
C
050-031
Fan Motor DF2H014N
E
050-035
Fan Motor 7185-0125
C E E E
SA050-034
Fan Motor Assembly 7126-4472 (with capacitor)
C C C E&C E&C E&C
CAPACITORS (for Motors)
017-008
Capacitor for Motor 7.5MFD 370V
E&C E E E
017-018
Capacitor for Motor 10MFD 370V
E&C E
017-022
Capacitor for Motor 6MFD 370V
C
017-017
Capacitor for Motor 20MFD 370V
C C C E&C E&C E&C
COMPRESSORS
020-044
Compressor, 115V, GK102CAB (overload included)
✓
020-045
Compressor, 115V, GKS134CA (overload included)
✓
020-062
Compressor, 230V, GJS208KAA
✓
020-079
Compressor, 230V, ZP31K5E-PFV-130 (order 021-016 Molded Plug as needed)
✓
020-080
Compressor, 230V, 3Ø, ZP31K5E-TF5-130 (order 021-016 Molded Plug as needed)
✓
020-081
Compressor, 460V, 3Ø, ZP31K5E-TFD-130 (order 021-017 Molded Plug as needed )
✓
020-082
Compressor, 230V, ZP54K5E-PFV-130 (order 021-016 Molded Plug as needed)
✓
020-083
Compressor, 230V, 3Ø, ZP54K5E-TF5-130 (order 021-016 Molded Plug as needed)
✓
020-084
Compressor, 460V, 3Ø, ZP54K5E-TFD-130 (order 021-017 Molded Plug as needed)
✓
021-010
Mounting Kit (as needed)
✓ ✓ ✓ ✓ ✓ ✓
Information is subject to change without notice
oceanaire-inc.com (847) 583-0311 Page 3 of 4
PART NO. DESCRIPTION
PAC
1211
PAC
1811
PAC
2412
PAC
3612
PAC
3632
PAC
3634
PAC
6012
PAC
6032
PAC
6034
PAC (R410A)
Portable Spot Cooler (Air Cooled)
When ordering, please specify the MODEL and SERIAL NUMBER of the unit, to ensure accuracy.
Need help identifying a part? Call our KEEP COOL TEAM (847) 583-0311
SERVICE PARTS LIST
Effective: 02-11-2021
CAPACITORS (for Compressors)
017-029
Capacitor, 55 MFD 370V
✓
017-005
Capacitor, 50 MFD 370V
✓
017-030
Capacitor, 45 MFD 440V
✓
017-002
Capacitor, 45 MFD 370V
✓
017-016
Capacitor, 80 MFD 370V
✓
017-012
Hard Start Kit SPP-5 (*option)
* * *
017-021
Hard Start Kit SPP-7S (*option)
✓
*
MISCELLANEOUS
023-013
5 gallon Condensate Tank, Rectangular
✓ ✓ ✓ ✓ ✓ ✓
023-008
Drip Tray, 2-Tier
✓
023-006
Drip Tray, 2-Tier
✓ ✓
042-014
Door Latch
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
042-015
Black Pull Handle
✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓ ✓
042-017
Soft Grip Handle (colors may vary)
✓ ✓ ✓ ✓ ✓ ✓
057-008R
Replacement Condensate Pump, 115V
✓ ✓
057-012R
Replacement Condensate Pump, 230V
✓ ✓ ✓ ✓ ✓ ✓ ✓
Information is subject to change without notice
oceanaire-inc.com (847) 583-0311 Page 4 of 4
