PRODUCT SPECIFICATION SHEETS Residential Undercounter Refrigeration
24” CSERIES
Wine Reserve
PERLICK CORPORATION 8300 W. Good Hope Rd., Milwaukee, WI 53223 • (800) 558-5592 • perlick.com
Form No. Z2685_HC24WB_Gen 4
Rev 02.22.2021
KEY PRODUCT FEATURES AND BENEFITS
• 800 BTU/hr capacity delivers commercial grade cooling performance
• Variable speed compressor minimizes sound; up to 30% quieter than competitors
• Commercial-grade all stainless steel interior provides superior durability and easy cleaning; black vinyl exterior for
built in applications
• Wine shelves fully extend on vibration dampened, stainless steel ball-bearing glides; stainless steel wine shelves
will not absorb odors over time
Quick Features:
• Industry’s best full 6 year warranty for owner ease of mind
• Available with stainless steel or panel ready door to match your design style
• Audible door alarm warns user if door is held open
• Selectable blue or white LED lighting
• R600a Natural Refrigerant offers maximum energy efficiency with zero ozone depletion potential
• Storage for up to 45 bottles of wine
MODELS DESCRIPTION
HC24WB-4-1R/L Indoor C-Series Wine Reserve Solid Stainless Steel Door
HC24WB-4-2R/L Indoor C-Series Wine Reserve Solid Panel Ready Door
HC24WB-4-3R/L Indoor C-Series Wine Reserve Stainless Steel Glass Door
HC24WB-4-4R/L Indoor C-Series Wine Reserve Panel Ready Glass Door
Glass Door Model Solid Door Model
I
N
D
U
S
T
R
Y
’
S
B
E
S
T
I
N
D
U
S
T
R
Y
’
S
B
E
S
T
W
A
R
R
A
N
T
Y
W
A
R
R
A
N
T
Y
6 YEAR
6 YEAR
FULL 6 YEARS, 6 YEARS ON SEALED SYSTEM
FULL 6 YEARS, 6 YEARS ON SEALED SYSTEM
PERLICK CORPORATION 8300 W. Good Hope Rd., Milwaukee, WI 53223 • (800) 558-5592 • perlick.com
PRODUCT SPECIFICATION SHEETS Residential Undercounter Refrigeration
24” CSERIES
Wine Reserve
ACCESSORIES
MODEL NOS. DESCRIPTION
L Factory Installed Lock
66736 Caster Kit for HP24/HC24/HA24 models
6711524 Wood Faces for Wine Shelf (7/pk)
MODEL NUMBERS HC24WB
MODEL DESCRIPTION 24 “ Indoor Wine Reserve
ATTRIBUTES
Perlick Anti-Condensation System NO
OVERALL DIMENSIONS
Width - in. (mm) 23-7/8” (606 mm.)
Depth - in. (mm) 24” (610 mm.)
Height - in. (mm) 34-1/4” (870 mm.)
OPENING DIMENSIONS
Width - in. (mm) 24” (610 mm.)
Depth - in. (mm) 24-7/8” (632 mm.)
Height - in. (mm) 34-1/2” (876 mm.)
INTERNAL VOLUME Net. Cu. Ft. 5.2 cu. ft.
SHIPPING WEIGHT Lbs. (kg.) 195 lbs (88.45 kg.)
ELECTRICAL SPECIFICATIONS
Electrical Supply 115 VAC/60 Hz/1 Ph
Running Load Amps 2.2 amps
Electrical Connection Cord connected
Cord Plug Type
NEMA 3 Prong 5-15P
Cord Length 6’
Defrost Initiation Automatic
Defrost Type O cycle
Thermostat Digital
Lighting Type LED
REFRIGERATION SPECIFICATIONS
Refrigerant R600a (50g)
Expansion Device Capillary Tube
Temperature Settings F°C°
45° (7.2°) - 42° (18.3°)
Factory Set Point 36° (2.2°)
Heat Rejection (at 75°F) 450 BTU/hr
Pull Down Capacity 800 BTU/hr
Front Vented Yes
PLUMBING None Required
Installation Notes: To achieve 24” install depth, place electrical connection adjacent to the installation cavity.
Perlick accessories are available for purchase through an
authorized Perlick dealer. For a full list of accessories and to
nd a dealer near you, visit perlick.com.
Form No. Z2685_HC24WB_Gen 4
Rev 02.22.2021
PERLICK CORPORATION 8300 W. Good Hope Rd., Milwaukee, WI 53223 • (800) 558-5592 • perlick.com
PRODUCT SPECIFICATION SHEETS Residential Undercounter Refrigeration
24” CSERIES
Wine Reserve
CUSTOMER MODEL NUMBER REGULATORY MODEL NUMBER Hinge Side Lock
HC24WB41L
HC24WB4F00SLS0W
Left No
HC24WB41R
HC24WB4F00SRS0W
Right No
HC24WB42L
HC24WB4F00PL00W
Left No
HC24WB42R
HC24WB4F00PR00W
Right No
HC24WB43L
HC24WB4F00TLS0W
Left No
HC24WB43R
HC24WB4F00TRS0W
Right No
HC24WB44L
HC24WB4F00RL00W
Left No
HC24WB44R
HC24WB4F00RR00W
Right No
HC24WB41LL
HC24WB4F00SLSLW
Left Yes
HC24WB41RL
HC24WB4F00SRSLW
Right Yes
HC24WB42LL
HC24WB4F00PL0LW
Left Yes
HC24WB42RL
HC24WB4F00PR0LW
Right Yes
HC24WB43LL
HC24WB4F00TLSLW
Left Yes
HC24WB43RL
HC24WB4F00TRSLW
Right Yes
HC24WB44LL
HC24WB4F00RL0LW
Left Yes
HC24WB44RL
HC24WB4F00RR0LW
Right Yes
Form No. Z2685_HC24WB_Gen 4
Rev 02.22.2021
PERLICK CORPORATION 8300 W. Good Hope Rd., Milwaukee, WI 53223 • (800) 558-5592 • perlick.com
PRODUCT SPECIFICATION SHEETS Residential Undercounter Refrigeration
24” CSERIES
Wine Reserve
