Cube
EN
www.tefal.com
UR20XX
1820006540
2
EN
Important Safety
recommendations
Safety instructions and guidelines
• R
ead the instruction manual carefully before using your
appliance for the first time. This product is designed
for domestic and indoor use only. Any commercial use,
inappropriate use or failure to comply with the instructions,
the manufacturer accepts no responsibility and the guarantee
will not apply.
• The appliance must not be left unattended while it is
connected to the supply mains.
• Do not unplug your appliance by pulling on the power cord.
Always unplug your appliance:
– before filling the water tank or rinsing the boiler
– before cleaning the appliance,
– after each use.
• Never fill the appliance directly from the tap.
• The appliance does not work without the scale collector
(depending on the model).
• The appliance must be used and rested on a flat, stable and
heat-resistant surface.
• When you place the iron on its stand or on a separated base,
ensure that the surface on which the stand or the separated
base is placed is stable.
• Do not place the separated base on the ironing board cover
or on a soft surface.
• This appliance is not intended for use by individuals (including
children) with reduced physical, sensory or mental capabilities,
3
or lack of experience and knowledge, unless they have been
given supervision by a person responsible for their safety.
• Children must be supervised to ensure that they do not play
with the appliance.
• This appliance may be used by children aged 8 years and older
and by individuals lacking experience or knowledge or with
reduced physical, sensory or mental capabilities, provided that
they have been thoroughly instructed regarding the use of the
appliance, are supervised, and understand the risks involved.
Children must not play with the appliance. Cleaning and user
maintenance shall not be made by children without supervision.
• Keep the appliance and its power cord out of reach of children
under 8 years of age when it is in use or cooling down.
• The surfaces of your appliance can reach very high
temperatures when functioning, which may cause
burns. Do not touch the hot surfaces of the appliance
(accessible metal parts and plastic parts adjacent to the
metallic parts).
• It is very important not to use descaling products (vinegar,
industrial descalers, etc.) to rinse the boiler, as they may
damage it.(depending on model)
• Before emptying the boiler/rinsing the collector, always wait
until the appliance has cooled down and has been unplugged
for over 2 hours before loosening the drainage/collector cap.
• Caution: If the cap or drainage cap is damaged, have it
replaced by an approved service centre.
• The filling or decalcifying or rinsing or inspection apertures
that are under pressure, must not be opened during use.
• Do not use other decalcifying products than the one cited in
the Instruction for use
• Care should be taken when using the appliance due to
emission of steam
• Unplug the appliance during cleaning & filling
4
• The appliance must not be used if it has been dropped, if
it appears to be damaged, if it is leaking or is not working
correctly.
• Do not attempt to dismantle your appliance: take it to an
approved service center to avoid any danger.
• If the power cord or steam cord of your appliance is damaged,
it must be replaced by an approved service centre in order to
avoid any danger.
• Before storing the appliance, once it is unplugged, please wait
until it has cooled down completely (around 1 hour).
• All accessories, consumables and removable parts must be bought only from an approved service centre.
• For your safety, this appliance conforms to all applicable regulations (Low Voltage, Electromagnetic Compatibility and
Environment Directives, etc.).
• Your appliance is an electrical appliance: it must be used under normal conditions of use.
• It is equipped with 2 safety systems(depending on model):
– a valve to prevent the build-up of pressure, which allows excess steam to escape in the event of the appliance
malfunctioning,
– a thermal fuse to prevent overheating.
• Always plug your appliance:
– into a mains circuit with voltage between 220 V and 240 V (Alternating current only),
– into a socket outlet with an earth connection.
Faulty connection can cause irreparable damage to the appliance and will invalidate your guarantee.
• If you are using an extension cord, ensure that it is correctly rated (16A) with an earth connection and is fully extended.
• Fully unwind the power cord before plugging it into an earthed plug socket.
• Never touch the power cord or steam cord with the soleplate of the appliance. Do not leave the power cord or steam
cords close to or in contact with sources of heat or sharp edges.
• The water in the appliance may still be hot and cause burns even after 2 hours of cooling down. Handle the appliance
with care when the cap/collector is removed, particularly when you are emptying it.
• Your appliance emits steam that may cause burns.
– Handle the iron with care, particularly when using the vertical steam function.
– Never steam clothing when it is worn by a person, always steam it on a hanger.
– Never iron in a seated position with your legs below the ironing board.
– Never direct the steam towards people or animals.
• The first time the appliance is used, there may be some reject of particles, fumes and smell but this is not harmful.
• Never immerse your appliance in water or any other liquid. Never place it under tap water.
• Careful during the assembly of the product & the board to pinch risks(depending on model)
• Never place the flat iron on the ironing board, always use the iron rest. Similarly, never place the separated base on
the ironing board(depending on model)
Important notice for appliances ≥ 2200W only :
Under unfavorable mains conditions, phenomena like transient voltage drops or lighting fluctuations can happen.
Therefore, it is recommended that the iron is connected to a power supply system with a maximum impedance of 0,29
Ω. If necessary, the user can ask the public power supply company for the system impedance at the interface point.
What water should I use?
• This appliance has been designed to be used with untreated tap water. If your water is very hard, (hardness above 30°F,
or 17°dH or 21°e) use a mixture of 50% tap water and 50% distilled water. In some seaside regions, salt content might
be high. In that case, use only water bottle, with low mineral level.
• They are different type of softened water, and most of them can be used in your appliance. However, some of them,
especially the one with chemical components, like salt, might occur white or brown runs. If you face this type of issue,
we recommend you to use non-treated tap water or bottled water.
5
• You should not use water from domestic appliances, with additives (starch, perfume, etc.) , rain water, boiled, filtered,
bottled water. Do not use pure distilled nor pure demineralized water. Such water might affect steam attributes and at
high temperature generate steam chamber sediment, liable to stain your linen and cause early appliance aging.
SAVE THESE INSTRUCTIONS
Help protect the environment!
Your appliance contains a number of recoverable or recyclable materials.
Take these to a collection centre, or to an approved service centre for processing.
Troubleshooting problems with your appliance
PROBLEMS CAUSES SOLUTIONS
Water is dripping
from the holes in the
soleplate
The water has condensed in
the tubes because you are
using the steamer for the first
time or have not used it for
a while.
Press the steam button away from your iron-
ing board until the iron emits steam.
The soleplate is not hot
enough to pro-duce steam.
Set the appliance to the steam zone* (see
user manual).
Traces of water appear
on the laundry
Your ironing board cover is
saturated with water as it is
not suitable for the power of
your appliance.
Ensure you use a suitable ironing board (a
mesh ironing board which prevents con-
densation).
White streaks are drip-
ping from the holes in
the soleplate
Your boiler is emitting
limescale as it is not rinsed
regularly.
Rinse the boiler as instructed in the user
manual.
Brown streaks are drip-
ping from the holes in
the soleplate and stain-
ing the laundry
You are using chemical des-
caling agents or additives in
the water.
Never add any product to the boiler (see the
section “What water should I use?”)
The soleplate is dirty or
brown and may mark
the laundry
The appliance is being used
on too high a temperature.
Clean the soleplate as instructed in the user
manual. Use a lower temperature.
The soleplate is
scratched or damaged
You have placed your iron flat
down on the metal iron rest.
Always place your iron on its heel or on the
iron rest.
The red “WATER” indica-
tor light is flashing*
You have not filled the water
tank.
Fill in the water tank and press the “OK”
button located on the control panel until the
indicator light goes off.
You have not pressed the “OK”
button.
Press the “OK” button located on the control
panel until the indicator light goes off.
The “anti-scale” indicator
light is flashing*
You have not pressed the “OK”
button.
Press the “OK” button located on the control
panel until the indicator light goes off.
The appliance will not
turn on or the iron
indicator light and the
“ON-OFF” indicator light
will not turn on.*
The “auto-off” system is acti-
vated after non-use and has
turned off your appliance.
Press the “ON-OFF” restart button located on
the control panel.
The red “WATER” indica-
tor light is flashing and
the “ON-OFF” button is
not working.*
The appliance has been
stored in a cold area (around
<10C°)
Unplug the appliance. Leave the appli-ance
for 3 hours until it reaches ambient tem-
perature.
A loud noise from the
appliance.
Not enough water in the tank. Fill the tank.
*Depending on the model
1. Product presentation
1
2
4
5
3
6
7
8
12
11
10
9
EN
Product presentation
1. Iron rest
2. Iron
3. Steam hose
4. Control panel
5. Steam unit
6. Removable water tank
7. Iron soleplate
8. Steam trigger
9. Anti calc light indicator
10. On/O button
11. Electric cable
12. Anti Calc cork
8
Please read the “Safety and use instructions” booklet before rst use.
On rst use, fumes and odour may come from the appliance. They do not aect the use of
the appliance and disappear quickly. Small particles may also come from the iron. These
are part of the production process and do not aect yourself or your garments. They
disappear quickly.
The appliance must be used and placed on a at, stable, heat-resistant surface. When you
place the appliance on its stand, ensure that the surface on which the stand is placed is
stable. Never use the appliance if it is reversed.
If you use an ironing board, never put your iron on it, always use the iron rest.
Never put the steam unit on the board.
EN
2. Before rst use
Unplug the appliance.
Remove the water tank. Fill it, and then replace it.
EN
When the water light ashes, please refer to the above instructions,
and then, click on the OK button to reboot the light.
EN
3. Product use
9
Put the iron on the iron rest. Plug the appliance and switch it on.
Wait until the light stops ashing.
EN
ON
Press the trigger in order to get steam.
EN
Never iron or steam directly on a garment being worn by someone.
EN
NO
Steam boost
Press the steam trigger three times to activate the steam boost.
EN
x 3
10
Mode selection
To switch between modes, press the STEAM button. The light will be
ashing in MAX mode, steady in ECO mode and o in NORMAL mode.
EN
Auto-o
After 8 minutes of inactivity, the steam unit will change to stand by
mode.
EN
8min
After 38 minutes of inactivity, the steam unit will switch o
automatically.
EN
38min
11
Position the iron and its iron rest on the steam unit.
EN
4. Iron rest use
If you use an ironing board, never put your iron on it, always use the iron rest.
Never put the steam unit on the board.
EN
Move around with your appliance. Plug in, switch it on, and wait until
it heats up. Always use when steam unit is on the ground, stable.
EN
ON
Be careful of heat and steam when using the appliance.
EN
12
Switch o the appliance. Wait 1 hour to allow it to cool down
completely.
EN
Clean the soleplate with a damp soft cloth or sponge.
EN
Never use abrasive products or surfaces to clean the soleplate.
EN
5. Product cleaning
OFF
NO
13
Switch o the appliance. Wait 1 hour to allow it to cool down
completely.
EN
Empty the water tank.
EN
6. Product tidying
OFF
14
*
ON
2H
OFF
When the appliance needs to be descaled, the anti calc light ashes.
EN
7. Anticalc
* Not included
