42"/46" LED-LCD TV, 120Hz 1080p
NS-42E570A11/NS-46E570A11
User Guide
ii
www.insigniaproducts.com
Contents
CHILD SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Important safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Cautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Installing the stand or wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . .5
Installing the stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installing a wall-mount bracket . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
TV components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Back . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Side . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Using the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Installing remote control batteries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Aiming the remote control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the remote control holder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Programming a universal remote control to work with your TV . . . . 9
Making connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting the power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting an antenna or cable TV (no box) . . . . . . . . . . . . . . . . . . . . . 10
Connecting a cable or satellite box . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Connecting an HDMI device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connecting a component video device . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Connecting a computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting headphones . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting a digital sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Connecting an analog sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Turning on your TV for the first time . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Understanding the basics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Turning your TV on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Selecting the video input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
On-screen menu overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Navigating the menus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Selecting a channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Adjusting the volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Displaying additional information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Adjusting the picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Adjusting the TV picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Adjusting component video . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Adjusting the computer image . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Turning Game Mode on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Adjusting the sound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Adjusting sound settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
iii
Contents
www.insigniaproducts.com
Playing TV audio only . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Changing channel settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Automatically scanning for channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Hiding channels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting up a favorite channel list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Viewing a favorite channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Adding or changing a channel label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Checking the digital signal strength . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setting parental controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Setting or changing the password . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Locking control buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Blocking unrated TV . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting parental control levels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Downloading rating information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Using closed captioning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Turning closed captioning on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Selecting the closed captioning mode . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Customizing digital closed captioning styles . . . . . . . . . . . . . . . . . . . . . 28
Adjusting time settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Setting the time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Setting the sleep timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Adjusting menu settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Adjusting the menu transparency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Selecting the menu language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Turning Auto Input Sensing on or off . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Labeling an input source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Using INlink . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Restoring settings to the defaults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Using USB . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Switching to USB mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Browsing photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Setting up a favorite photos list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Viewing favorite photos . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Viewing all photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Viewing favorite photos in a slideshow . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Customizing slideshow settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Maintaining . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Cleaning the TV cabinet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Cleaning the TV screen . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Legal notices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Two-year limited warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
US and Canada Markets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Mexico Market . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
iv
Contents
www.insigniaproducts.com
1
www.insigniaproducts.com
As you enjoy your new product, keep these
safety tips in mind
The issue
The home theater entertainment experience is a growing trend, and larger TVs are popular
purchases. However, TVs are not always supported on the proper stands or installed
according to the manufacturer’s recommendations. We and the consumer electronics
industry are committed to making home entertainment enjoyable and safe.
TVs that are inappropriately placed on dressers, bookcases, shelves, desks, speakers, chests, or
carts may fall over and cause injury.
Tune into safety
• One size of TV stand does not fit all. Use only a TV stand
rated for the weight of your TV.
• Carefully read and understand all enclosed instructions
for proper use of this product.
• Don’t let children climb on or play with entertainment
system furniture and TVs.
• Don’t place TVs on furniture that can easily be used as
steps, such as a crate or chest of drawers.
• Remember that children can become excited while
watching a program, especially on a “larger-than-life” TV.
Make sure that you place or install the TV where it cannot
be pushed, pulled over, or knocked down.
• Make sure that you route all cords and cables so that they
cannot be pulled or grabbed by curious children.
Wall mounting
If you decide to wall mount your TV, always remember:
• One size of wall mount does not fit all. Use only a wall mount rated for the weight of
your TV and that has been recommended by this TV manufacturer, listed in this
manual, or otherwise listed by an independent laboratory as suitable for your TV.
• Follow all instructions supplied by the TV and wall mount manufacturers.
• If you have any doubts about your ability to safely wall mount your TV, get help from a
professional installer.
• Make sure that the wall where you are mounting the TV is
appropriate. Some wall mounts are not designed to be
mounted to walls backed with steel studs or cinder blocks. If
you are unsure, ask a professional installer.
• TVs can be heavy. At least two people are required for safe wall mount installation.
f
CHILD SAFETY
It makes a difference how and where you use
your flat panel display
2
NS-42E570A11/NS-46E570A11
www.insigniaproducts.com
Important safety
instructions
1 Read these instructions.
2 Keep these instructions.
3 Heed all warnings.
4 Follow all instructions.
5 Do not use this apparatus near water.
6 Clean only with a dry cloth.
7 Do not block any ventilation openings. Install in
accordance with the manufacturer's
instructions.
8 Do not install near any heat sources such as
radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce
heat.
9 Do not defeat the safety purpose of the
polarized or grounding-type plug. A polarized
plug has two blades with one wider than the
other. A grounding type plug has two blades
and a third grounding prong. The wide blade or
the third prong are provided for your safety. If
the provided plug does not fit into your outlet,
consult an electrician for replacement of the
obsolete outlet.
10 Protect the power cord from being walked on or
pinched particularly at plugs, convenience
receptacles, and the point where they exit from
the apparatus.
11 Only use attachments/accessories specified by
the manufacturer.
12 Use only with a cart, stand, tripod,
bracket, or table specified by the
manufacturer, or sold with the
apparatus. When a cart is used, use
caution when moving the
cart/apparatus combination to avoid injury from
tip-over.
13 Unplug this apparatus during lightning storms
or when unused for long periods of time.
14 Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has
been damaged in any way, such as
power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or
has been dropped.
15 The wall plug is the disconnecting device. The
plug must remain readily operable.
16 An apparatus with three-prong, grounding-type
plug is a Class I apparatus which needs to be
grounded to prevent possible electric shock.
Make sure that you connect the Class I
apparatus to a grounding-type, three-prong
outlet.
17 Remote control batteries should not be exposed
to excessive heat such as sunshine, fire, or the
like.
18 The apparatus should not be exposed to
dripping or splashing, and no objects filled with
liquids, such as vases, should be placed on the
apparatus.
Warnings
Electric shock hazard
To reduce the risk of fire or electric shock, do not
remove any cover or expose the device to rain or
moisture. No user-serviceable parts are inside. Refer
servicing to qualified service technicians.
Lightning
For added protection for your device receiver
during a lightning storm, or when it is left
unattended and unused for long periods of time,
unplug it from the power outlet and disconnect any
antenna or cable system. This helps prevent
property damage and personal injury from
lightning and power line surges.
Power lines
An outside antenna system should not be located in
the vicinity of overhead power lines or other
electric light or power circuits, or where it can fall
into such power lines or circuits. When installing an
outside antenna system, extreme care should be
taken to keep from touching such power lines or
circuits as contact with them might be fatal.
Handling the LCD panel
• Your TV’s screen is made of glass. Do not drop
your TV or hit, jolt, or press hard against the LCD
panel. If the screen breaks, be careful of broken
glass.
• If the LCD panel is broken, make absolutely sure
that you do not touch the liquid in the panel. This
may cause skin inflammation.
• If the liquid gets in your mouth, immediately
gargle, rinse, and consult with your doctor. Also, if
the liquid gets in your eyes or touches your skin,
consult with your doctor after rinsing for at least
15 minutes or longer in clean water.
Replacement parts
When replacement parts are required, make sure
that the service technician uses replacement parts
specified by the manufacturer that have the same
characteristics as the original part. Unauthorized
substitutions may result in fire, electric shock,
personal injury, or other hazards.
Safety check
After completing any service or repair to this device,
ask the service technician to perform routine safety
checks to determine that your TV is in correct
operating condition.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within your TV. This
label is located on the back of your TV.
This symbol indicates that there are
important operating and maintenance
instructions in the literature
accompanying your TV.
S3125A
3
www.insigniaproducts.com
Power source
Operate your TV only from the type of power source
indicated on the marking label. If you are not sure
of the type of power supplied to your home, consult
an electrician or your local power company.
Cautions
Damage requiring service
Unplug this TV from the power outlet and refer
servicing to qualified service personnel under the
following conditions:
• When the power supply cord or plug is damaged
or frayed.
• If liquid has been spilled or objects have fallen
into your TV.
• If your TV has been exposed to rain or water.
• If your TV does not operate normally by following
the operating instructions. Adjust only those
controls that are covered by the operating
instructions because incorrect adjustment of
other controls may result in damage and will
often require extensive work by a qualified
technician to restore your TV to its normal
operation.
• If your TV has been dropped or damaged in any
way.
• When your TV exhibits a distinct change in
performance.
Outdoor antenna grounding
If an outside antenna or cable system is connected
to your TV, make sure that the antenna or cable
system is grounded to provide some protection
against voltage surges and built-up static charges.
Article 810 of the National Electrical Code,
ANSI/NFPA No. 70, provides information with
respect to correct grounding of the mast and
supporting structure, grounding of the lead-in wire
to an antenna discharge unit, size of grounding
conductors, location of the antenna-discharge unit,
connection to grounding electrodes, and
requirements for the grounding electrode.
Note to CATV system installer
Article 820 of the National Electrical Code,
ANSI/NFPA No. 40 provides guidance for correct
grounding. Specifically, it states that the cable
ground must be connected to the grounding
system of the building as close to the point of cable
entry as practical.
Condensation
Moisture will form on the TV if the TV is brought
from cool surroundings into a warm room or if the
temperature of the room rises suddenly. When this
happens, the TV's performance may be impaired. To
prevent this, let the TV stand in its new
surroundings for about an hour before switching it
on, or make sure that the room temperature rises
gradually.
Condensation may also form during the summer if
the TV is exposed to the breeze from an air
conditioner. In such cases, change the location of
the TV.
Mobile telephone warning
To avoid interference with your TV picture and
sound, operating problems, or even damage, keep
your cordless and cellular telephones away from
the TV.
End of life directives
Your TV contains tin-lead solder and a fluorescent
lamp containing a small amount of mercury.
Disposal of these materials may be regulated for
environmental reasons. Your TV also contains
material that can be recycled and reused. For
disposal or recycling information, contact your local
authorities or the Electronic Industries Alliance at
www.eia.org to find a recycler in your area.
Non-active pixels
The LCD panel contains almost 3 million thin film
transistors, which provide exceptionally sharp video
quality. Occasionally, a few non-active pixels may
appear on the screen as a fixed blue, green, or red
point. These non-active pixels do not adversely
affect the performance of your TV, and are not
considered defects.
Antenna lead-in wire
Grounding clamp
Antenna discharge unit
Grounding conductors
Ground clamps
Power service grounding electrode system
Electric service equipment
2
1
3
4
5
6
7
1
2
3
4
5
6
7
4
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
Introduction
Congratulations on your purchase of a high-quality
Insignia product. Your NS-42E570A11, or
NS-46E570A11 represents the state of the art in
LED-LCD TV design and is designed for reliable and
trouble-free performance.
AUDYSSEY Dynamic Volume plus Dynamic EQ:
Have you ever caught yourself wishing that you
didn't constantly need to adjust the volume:
wishing that the commercials wouldn't blare and
that you could better hear whispering during a
movie scene? Audyssey Dynamic Volume is a
feature that lets you put the remote control down
and enjoy your show while Audyssey adjusts the
sound levels for you automatically. Audyssey
Dynamic EQ is a feature that automatically finds the
richest sound settings-including enhanced bass-for
each scene, even when the volume level is held
steady, making the sound coming from your TV
speakers sound more lifelike. (See page 19 for
instructions on how to adjust the audio settings to
take advantage of Audyssey.)
SRS TruSurround HD:
At Insignia, providing you with superior audio
quality is just as important as exceptional picture
quality. That's why we added SRS TruSurround HD,
which provides you with a theater-like
surround-sound experience, with the clearer dialog
and the enhanced bass sounds that movie viewers
and gamers crave.
Insignia Motion 120Hz:
With a 120 Hz screen refresh rate twice the rate of a
60 Hz screen, a screen with 1,080 lines of resolution
(up from 720 lines in the last generation of HDTVs),
and special motion-detection technology, you will
be experiencing a picture with clearer detail and
brightness, smoother transitions, and reduced
motion blurring, particularly when watching
fast-motion sports and action scenes. (See page 16
for instructions on how to adjust the TV picture.)
SupraHD by Zoran:
An advanced-design microprocessor enables the
exceptional picture and sound quality that you
expect from today's home theater.
Game mode:
Video games generally require adjustments to the
television picture settings to get the maximum
experience. By simply pressing a button on your
remote control, your television settings will
automatically adjust for video games. It couldn't be
easier. (See page 18 for instruction on how to turn
Game Mode on and off.)
INlink:
Enjoy the benefit of having HDMI CEC-compatible
products plug and play! No setup is needed! CEC
technology lets different components discover and
communicate with each other.
Your remote control has buttons for controlling
playback of HDMI CEC-compatible devices, such as
a Blu-ray Disc or DVD player. You do not need to
program your remote control or enter any codes.
If the HDMI device is HDMI CEC-compatible, you
need to turn on the feature in the device’s menu
options and your TV’s INlink menu. See the
documentation that came with the device to
determine if the device is HDMI CEC-compatible
and how to turn on the feature. (See page 32 for
instructions on how to use INlink.)
5
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Installing the stand or
wall-mount bracket
Installing the stand
To install the stand:
1 Carefully place your TV screen face-down on a
cushioned, clean surface to protect the screen
from damages and scratches.
2 Secure the stand to the screen with the four
provided screws.
Installing a wall-mount bracket
To attach your TV to a wall-mount bracket:
1 Carefully place your TV screen face-down on a
cushioned, clean surface to protect the screen
from damages and scratches.
2 Remove the five screws that secure the stand
module on your TV.
3 Remove the stand module.
4 Attach the wall-mount bracket with thread ISO
M6 type screws only (not included). Make sure
that the insertion length of the M6 screws is
between 0.39 ~ 0.47 inches (10 ~ 12 mm). A
shorter length might make the TV
wall-mounting insecure. A longer length might
create a space between the wall-mount bracket
and TV.
NS-42E570A11 (42-inch)
Warning
This apparatus is intended to be supported by a UL
Listed wall mount bracket.
7.84 in. (200 mm)
7.84 in. (200 mm)
Wall mount brackets
6
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
NS-46E570A11 (46-inch)
TV components
Accessories
Remote control and batteries (2 AAA)
Stand with screws
Component cable
Audio cable
Remote control holder
Cleaning cloth
Quick Setup Guide
Front
Back
# Item Description
INPUT
Press to open the Source List, then press or to
select a video input source.
In menu mode, press to confirm selections.
MENU
Press to open the on-screen menu. For more
information, see “Navigating the menus” on page 15.
CH
Press to go to the previous channel in the channel list.
For more information, see “Selecting a channel” on
page 15.
CH
Press to go to the next channel in the channel list. For
more information, see “Selecting a channel” on
page 15.
VOL Press to decrease the volume.
VOL Press to increase the volume.
(power)
Press to turn your TV on or off (Standby mode). When
your TV is off, power still flows into it. To disconnect
power, unplug the power cord.
15.75 in. (400 mm)
15.75 in. (400 mm)
Wall mount brackets
7
6
5
3
2
4
1
1
2
3
4
5
6
7
# Item Description
COMPONENT Y/PB/PR
Connect the video for a component video device to
these jacks. For more information, see “Connecting a
component video device” on page 11.
COMPONENT L/R audio
Connect the audio for a component video device to
these jacks. For more information, see “Connecting a
component video device” on page 11.
PC/DVI AUDIO IN
Connect the audio for a computer or a DVI device to
this jack. For more information, see “Connecting a
computer” on page 12 or “Connecting an HDMI
device” on page 11.
PC IN
Connect the video (VGA) for a computer to this jack.
For more information, see “Connecting a computer” on
page 12.
ANT/CABLE IN
Connect an antenna or cable TV to this jack. For more
information, see “Connecting an antenna or cable TV
(no box)” on page 10.
1
2
3
4
5
7
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Side Remote control
# Item Description
AUDIO OUT
Connect an external sound system to these jacks. For
more information, see “Connecting an analog sound
system” on page 13.
(headphone)
Connect headphones to this jack. For more
information, see “Connecting headphones” on
page 12.
USB
Connect a USB device, such as USB flash drive, to this
jack.
HDMI1/HDMI2/
HDMI3/HDMI4
Connect an HDMI devices to these jacks. An HDMI
cable carries both video and sound. You do not need to
make an audio connection for an HDMI device.
For more information, see “Connecting an HDMI
device” on page 11.
When connecting a DVI device using an HDMI-DVI
adapter, connect the device to the HDMI1 jack.
SPDIF
Connect an audio amplifier to this jack. For more
information, see “Connecting a digital sound system”
on page 12.
1
2
3
4
5
# Item Description
(power)
Press to turn your TV on or off (Standby mode). When
your TV is off, power still flows into it. To disconnect
power, unplug the power cord.
INPUT
Press to open the Source List, then press or to
cycle through the available input sources. For more
information, see “Selecting the video input source” on
page 14.
AUDIO
Press to select SRS, Bass, Treble, Balance, or Reset
Audio Settings. For more information, see
“Adjusting sound settings” on page 19.
DYN VOL
Press to select the level of Audyssey Dynamic Volume.
You can select Heavy, Medium, Light, or Off. For
information see “Adjusting sound settings” on
page 19.
Numbers
Press to enter channel numbers and the parental
control password.
—
Press to enter a digital sub-channel number. For more
information, see “Selecting a channel” on page 15.
MUTE
Press to mute the sound. Press again to restore the
sound.
VOL+/VOL–
Press to increase or decrease the volume.
FAV
Press to open the Favorite Channel list. For more
information, see “Setting up a favorite channel list” on
page 21.
1
2
3
4
5
6
7
8
9
8
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Using the remote control
Installing remote control batteries
To install the remote control batteries:
1 Remove the battery cover.
2 Insert two AAA batteries into the battery
compartment. Make sure that you match the +
and – symbols on the batteries with the + and –
symbols in the battery compartment.
3 Replace the battery cover.
MENU Press to open the on-screen menu.
Press to move left, right, up, or down in on-screen
menus.
INFO
Press to display TV status information, such as the
channel number, channel name (if available), or signal
source. For more information, see “Displaying
additional information” on page 16.
ZOOM
Press to select the aspect ratio. For more information,
see “Adjusting the TV picture” on page 16.
(fast reverse)
Press to fast reverse on HDMI CEC-compatible devices.
(play)
Press to start playback on HDMI CEC-compatible
devices.
(skip back)
Press to skip back to the previous title or track on
HDMI CEC-compatible devices.
(skip forward)
Press to skip forward to the next title or track on HDMI
CEC-compatible devices.
PICT
Press to select the video modes. You can select Vivid,
Standard, Energy Savings, Theater, Sports, or
Custom. For more information, see “Adjusting the TV
picture” on page 16.
RECALL
In TV mode, press to return to the previous channel.
In USB mode, press to switch back to a higher level
folder.
CH /CH
Press to change TV channels. For more information,
see “Selecting a channel” on page 15.
GUIDE
Press to display the program guide. For more
information, see “Displaying additional information”
on page 16.
EXIT
Press to close the on-screen menu.
SLEEP
Press to set the sleep timer. You can select Off, 5, 10,
15, 30, 60, 90, 120, 180, or 240 minutes. For more
information, see “Setting the sleep timer” on page 30.
OK/ENTER Press to confirm selections or changes.
CC
Press to turn closed captioning on or off. You can select
CC Off, CC On, or CC On when Mute. For more
information, see “Selecting the closed captioning
mode” on page 27.
Video input selection
TV—Press to select TV as the video source.
COMP—Press to select the device connected to the
COMPONENT video jacks.
HDMI—Press one or more times to select the device
connected to the HDMI 1, HDMI 2, HDMI 3, or
HDMI 4 jack.
For more information, see “Selecting the video input
source” on page 14.
GAME
Press to display the Game mode status. Press this
button again to turn Game mode On or Off. For more
information, see “Turning Game Mode on or off” on
page 18.
(pause)
Press to pause playback on HDMI CEC-compatible
devices.
(fast forward)
Press to fast forward on HDMI CEC-compatible devices.
(stop)
Press to stop playback on HDMI CEC-compatible
devices.
# Item Description
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
Cautions
• Batteries should not be exposed to excessive
heat, such as sunshine, heat registers, or fire.
• Battery chemicals can cause a rash. If the
batteries leak, clean the battery compartment
with a cloth. If chemicals touch your skin, wash
immediately.
• Make sure that batteries are disposed of
correctly. Do not burn or incinerate.
Notes
• Do not mix batteries of different types.
• Do not mix old and new batteries.
• Remove batteries when the charge is depleted.
• If the remote control is not going to be used for
an extended period of time, remove the
batteries.
9
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Aiming the remote control
To aim the remote control:
• Point the remote control towards the remote
sensor on the front of your TV.
Using the remote control holder
Your TV comes with a remote control holder you
can put the remote control in when you are not
using it. You can put the holder on a table or mount
it on a wall.
Programming a universal remote control to
work with your TV
You can operate your Insignia TV with a new or
existing universal remote control.
To program a universal remote control to work
with your TV:
1 See the table below for common codes. If you
have problems programming your remote or
need a different remote control code, visit
www.insigniaproducts.com for the latest
remote control code information.
Codes for other remote controls are available
online at: www.insigniaproducts.com
2 Follow your universal remote control’s
instructions to enter the TV code you found in
Step 1.
3 If all else fails, you must use a different universal
remote control that can operate both your
set-top box and your TV. Four such remotes are
listed on the chart, but many other compatible
models are available in the market.
For more help, go to insigniaproducts.com or
call technical support for your universal remote
control or set-top box manufacturer, or call the
Insignia Customer Care Center. For US and
Canada markets, call 1-877-467-4289. For
Mexico markets, call 01 800-926-3000.
Notes
• Do not expose the remote control to shock or
liquids.
• Do not use the remote control in an area with
high humidity.
• Do not place the remote control in direct
sunlight.
• Do not place objects, such as furniture, between
the remote control and the remote sensor.
• The remote control may not work if direct
sunlight or bright light shines on the remote
sensor. Either move your TV or change the angle
at which you use the remote control.
Tips
• Different types of walls may require different
types of screws. If you want to wall mount the
remote control holder, make sure that you use
the correct screws for the type of wall. (Screws
are not provided.)
• The remote control holder is shipped with
separate adhesive tape for wall mounting. This
tape may not work with all types of walls. Make
sure that you use the correct tape for the type of
wall.
Tape
Screws (not
included)
Insignia TV codes for universal remote controls
(for all Insignia TVs manufactured after Jan. 1, 2007)
Universal remote control makes and models
Philips PHDVD5,
PH5DSS,
PMDVR8, PDVR8
RCA
RCU807
One for All
URC-6690
Sony
RM-VL600
115 135 0464 8043
Set-top box makes and models
Comcast
M1057
Dish Network
VIP508, VIP622
Motorola
DRC800
TIVO
Series 3, HD
DirectTV
RC23
0463 720 0463 0091 10463
Tips
• The brand name is often visible on the front of
the universal remote control, and the model
number is often visible on the back.
• If your universal remote control isn’t listed on
the chart, refer to your universal remote
control’s instructions and try codes for the
brands Orion, Emerson, Memorex, Sansui,
Sylvania, or Zenith. You may need to try several
codes before finding a match.
Tips
• If your universal remote control has a code
search feature, run a code search to identify a
code that matches your TV. See your universal
remote control’s instructions for details.
• If your universal remote control has a “Learn”
feature, you can manually program it using the
Insignia TV remote to “teach” the commands
one at a time. See your universal remote
control’s instructions for details.
10
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Making connections
Connecting the power
To connect the power:
• Plug the power cord into a power outlet.
Connecting an antenna or cable TV (no box)
To connect an antenna or cable TV (no box):
1 Turn off your TV and all connected equipment.
2 Connect a coaxial cable to the ANT/CABLE IN
jack on the back of your TV and to the antenna
or cable TV wall jack.
Connecting a cable or satellite box
Many cable or satellite TV boxes have more than
one connection type. To get the best video, you
should use the best connection type available.
To connect a cable or satellite box:
1 Connect the incoming cable from the cable TV
or satellite TV wall jack to the cable-in jack on
the cable box.
2 Depending on the jacks available on the cable
or satellite TV box, connect a cable from the
outgoing jacks on the cable or satellite TV box
to the corresponding jacks on the back or side
of your TV. The connection can be to an HDMI
jack or the COMPONENT Y/P
B/PR jacks.
3 If you use the COMPONENT Y/P
B/PR jacks,
connect an audio cable (provided) to the
COMPONENT L/R audio jacks.
Notes
• Use a coaxial cable to eliminate interference and
noise from radio waves.
• Do not bundle the coaxial cable with the power
cord or other cables.
• If the antenna is not installed correctly, contact
qualified service personnel to correct the
problem.
ANT/CABLE IN
Connection type Video quality
HDMI Best
Component Better than coaxial
Coaxial Good
Note
If the cable or satellite TV box does not have an HDMI
or component video connection, connect the cable
or satellite TV box to the ANT/CABLE IN jack on the
back of your TV. For more information, see
“Connecting an antenna or cable TV (no box)” on
page 10.
HDMI
Component
Side of TV
11
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Connecting an HDMI device
To connect an HDMI device:
1 Make sure that your TV’s power cord is
unplugged and the HDMI device is turned off.
2 Connect an HDMI cable (not provided) to the
HDMI 1, HDMI 2, HDMI 3, or HDMI 4 jack on
the side of your TV and to the HDMI OUT jack
on the HDMI device.
3 Turn on your TV, then turn on the HDMI device.
4 Press INPUT to open the Source List.
5 Press or to highlight HDMI 1, HDMI 2,
HDMI 3, or HDMI 4, then press OK/ENTER.
Connecting a component video device
You can connect a component video device, such as
a camcorder, game console, or VCR, using the
component video jacks on the back of your TV.
To connect a component video device:
1 Make sure that your TV’s power cord is
unplugged and the component video device is
turned off.
2 Connect a component video cable to the
COMPONENT Y/P
B/PR jacks on the back of your
TV and to the COMPONENT OUT video jacks on
the component video device.
3 Connect an audio cable to the
COMPONENT L/R audio jacks on the back of
your TV and to the COMPONENT AUDIO OUT
jacks on the component video device.
4 Turn on your TV, then turn on the component
video device.
5 Press INPUT to open the Source List.
6 Press or to highlight COMPONENT, then
press OK/ENTER.
Note
If your device has an HDMI connection, we
recommend that you use the HDMI connection to
get the best quality possible.
Notes
To connect a DVI device, you need an HDMI-DVI
adapter (not included) and a 3.5 mm audio cable (not
included). Connect the adapter to the DVI device and
the HDMI 1 jack on the side of your TV. Connect the
audio cable to the DVI device and to the
PC/DVI AUDIO IN jack on the back of your TV.
Side of TV
HDMI device
Note
If your camcorder, game console, or VCR has an HDMI
jack, we recommend using the HDMI jack to connect
to your TV. HDMI povides the best video.
Note
To turn Game Mode on or off, press GAME.
Back of TV
Component video device
12
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Connecting a computer
To connect a computer:
1 Make sure that your TV’s power cord is
unplugged and the computer is turned off.
2 Connect a VGA cable (not included) to the PC IN
jack on the back of your TV and to the VGA jack
on the computer.
3 Connect an audio cable to the
PC/DVI AUDIO IN jack on the back of your TV
and to the AUDIO OUT jack on the computer.
4 Turn on your TV, then turn on the computer.
5 Press INPUT to open the Source List.
6 Press or to highlight VGA, then press
OK/ENTER.
Connecting headphones
The TV speakers are muted when headphones are
attached.
To connect headphones:
• Connect headphones to the on the side of
your TV.
Connecting a digital sound system
To connect a digital sound system:
• Connect a digital audio cable to the SPDIF jack on
the side of your TV and to the digital audio jack on
the amplifier.
Note
When the computer enters Standby mode, your TV
turns off. If your TV does not turn on when you
“wake” your computer, press (power) on your TV
or remote control.
For HDMI-DVI input from PC, the TV will enter
Standby mode after one minute if no signal is
detected.
Back of TV
Warning
Loud noise can damage your hearing. When using
headphones, use the lowest volume setting on your
headphones that still lets you hear the sound.
Side of TV
Side of TV
Digital sound system
13
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Connecting an analog sound system
To connect an analog sound system:
• Connect a standard audio cable to the AUDIO
OUT L and R jacks on the back of your TV and to
the AUDIO IN jacks on the sound system.
Turning on your TV for the
first time
The first time you turn on your TV, the Setup Wizard
opens. The Setup Wizard guides you through
setting up basic settings including the menu
language, time mode, picture mode, and TV signal
source.
To set up your TV:
1 Make sure that you have:
• Installed the remote control batteries. (See
page 8 for details).
• Connected an antenna, cable TV, or satellite
TV. (See page 10 for details.)
• Connected the power cord. (See page 10 for
details.)
2 Press (power) to turn on your TV. The Choose
your menu language screen opens.
3 Press or to highlight English, Francais, or
Español, then press OK/ENTER. The Time screen
opens.
4 Press or to select Auto or Manual, then
press OK/ENTER.
5 Press or to highlight Time Zone, then press
or to select your time zone. You can select
Eastern, Central, Mountain, Pacific, Alaska,
Hawaii, Atlantic, or Newfoundland.
6 Press or to highlight Daylight Savings,
then press or to select On (if your viewing
area observes Daylight Savings Time) or Off (if
your viewing area does not observe Daylight
Savings Time).
7 If you selected Manual for Mode, set the date
by pressing or to highlight Year, Month, or
Day, then press or to adjust the setting.
8 If you selected Manual for Mode, set the time
by pressing or to highlight Time, then
pressing or to select the hour, minute, or
AM/PM field. Press or to adjust the setting.
Note:
If you connect the audio output from a DVD player,
VCR, set top box, cable box, satellite box, game
console, or other video device directly to an amplifier
without passing the audio through your TV set, you
need to fine-tune the lip/audio sync on the amplifier
to synchronize the video.
Back of TV
Analog sound system
Notes
• If you set the time mode to Auto, the date and
time are set based on a time signal received
from a DTV channel, and the only options you
can adjust are Time Zone and Daylight Savings.
• You can change the menu language or scan for
channels at a later date. For more information,
see “Adjusting the menu transparency” on
page 30, “Selecting the menu language” on
page 31, or “Automatically scanning for
channels” on page 20.
MENU
EXIT
OK
ENTER
Choose your menu Language
English
Français
Español
MOVE SELECT PREVIOUS EXIT
Set menu language to English, Français, or Español
MENU
EXIT
OK
ENTER
If Automatic, options are automatically set by TV source
Time
otuAedoM
Newfoundland
On
2010
Jan
1
12 : 01 AM
Time Zone
Daylight Savings
Year
Month
Day
Time
MOVE SELECT PREVIOUS EXIT
14
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
9 Press OK/ENTER. The Choose your Picture Mode
screen opens.
10 Press or to highlight Home Mode (default)
or Retail Mode, then press OK/ENTER.
If you selected Retail Mode, a message appears
“Are you sure you want Retail mode? Since in
this mode Energy saving is not realized.” Select
Ye s to continue, or select No to change your
selection.
The Choose your TV source screen opens.
11 Press or to highlight Antenna, Cable, or
Cable/Satellite Box (if your cable TV uses a box,
select Cable/Satellite Box), then press
OK/ENTER. If you chose Antenna or Cable, your
TV automatically starts scanning for channels
available in your viewing area. If you chose
Cable/Satellite box, your TV does not need to
scan for channels.
During auto channel search, your TV searches
for digital channels first. If you chose Antenna,
when the digital channel search is complete, a
message appears asking if you want to search
for analog channels. If you do not need to
search for analog channels, press MENU or EXIT
stop searching for channels.
When the scan is complete, the Setup Wizard
closes automatically.
Understanding the basics
Turning your TV on or off
To turn your TV on or off:
1 Make sure that the power cord is connected to a
power outlet.
2 Press (power) to turn on your TV. The power
indicator LED turns blue.
3 Press (power) again to turn off your TV. Your
TV enters Standby mode and the power
indicator LED turns red.
Selecting the video input source
To select the video input source:
1 Turn on your TV, then press INPUT. The Source
List opens.
2 Press or to highlight a video input source,
then press OK/ENTER.
You can also press a direct input button to select
the video input source.
• Press TV to select TV.
• Press COMP to select Component.
• Press HDMI once to select HDMI 1.
• Press HDMI twice to select HDMI 2.
• Press HDMI three times to select HDMI 3.
• Press HDMI four times to select HDMI 4.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
MENU
EXIT
OK
ENTER
Choose your Picture Mode
Home Mode
Retail Mode
MOVE SELECT PREVIOUS EXIT
Reduces total power consumption
MENU
EXIT
OK
ENTER
Channel scan may take 20+ minutes
Choose your TV source
Antenna
Digital Channels
Analog Channels
0
0
Cable
Cable/Satellite box
MOVE SELECT PREVIOUS EXIT
Scanning for digital channels
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
Warning
When your TV is in Standby mode, it is still receiving
power. To completely disconnect power, unplug the
power cord.
Note
If your TV does not receive an input signal for several
minutes, it automatically goes into Standby mode.
Note
If Auto Input Sensing is set to On, only the jacks that
have connected devices are active. The other inputs
are grayed and cannot be selected.
Source List
TV
Component
VGA
HDMI 1
HDMI 2
HDMI 3
HDMI 4
USB
15
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
On-screen menu overview
Picture menu
Audio menu
Channels menu
Settings menu
USB menu
Navigating the menus
Selecting a channel
• Press CH or CH to go to the next or previous
channel on the memorized channel list.
• Press the number buttons to enter the channel
number you want, then wait for the channel to
change or press OK/ENTER to immediately
change the channel.
• To select a digital sub-channel, press the number
buttons to select the main digital channel, press
—, then press the number button for the
sub-channel. Wait for the channel to change, or
press OK/ENTER to immediately change the
channel. For example, to tune to channel 5.1,
press 5, —, then 1.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU
EXIT
OK
ENTER
Audio
Audyssey Dynamic Volume
SRS TruSurround HD
Treble
Bass
Balance
PICTURE AUDIO CHANNELS SETTINGS
Digital Audio/SPDIF
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect sound quality
Medium
Off
32
32
0
PCM
USB
MENU EXIT
OK
ENTER
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Labels
Channel Strength
PICTURE AUDIO CHANNELS SETTINGS
ffOylnO oiduA
MOVE SELECT PREVIOUS EXIT
Adjust channel options
USB
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
Press MENU to open the on-screen menu
Press the right or left arrow to move the
cursor on the screen or to adjust a selected
item.
Press the up or down arrow to select menu
options.
Press OK/ENTER to confirm a selection or
enter a sub-menu.
Press MENU to return to the previous menu.
Press EXIT to close the menu
16
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
• Press RECALL to go to the last viewed channel.
• Press FAV to open the favorite channel list, press
or to highlight a channel, then press
OK/ENTER.
Adjusting the volume
To adjust the volume:
• Press VOL + or VOL – to increase or decrease the
volume.
• Press MUTE to turn off the sound. Press MUTE
again to turn the sound back on.
Displaying additional information
• Press INFO. Your TV displays status information,
such as the channel number, channel name (if
available), signal source, program description, and
DTV signal strength.
• Press GUIDE to show the digital program guide,
which may show current channel name, program
name, time, rating, and summaries, depending on
the information provided by the broadcaster.
Adjusting the picture
Adjusting the TV picture
1 Press MENU. The on-screen menu opens with
the Picture menu displayed.
2 Press to highlight an option, then press
OK/ENTER to access the submenu. You can
select:
• Mode—Selects the picture mode. You can
select Vivid, Standard, Energy Savings,
Theater, Sports, or Custom.
• Brightness—Adjusts the brightness of dark
areas of the picture.
• Contrast—Adjusts the white level of the
picture.
• Color—Adjusts the color intensity of the
picture.
• Tint—Adjusts the picture tint.
• Sharpness—Adjusts the sharpness.
• Advanced Video—Opens the Advanced Video
menu where you can adjust additional video
options.
• Aspect Ratio—Selects the aspect ratio.
You can select Normal, Zoom, Wide,
Cinema, or Auto. Auto is only available in
TV mode and when Auto Zoom on the
Channels menu is set to On. When a
computer is connected to the VGA jack or
HDMI jack, only Wide and Normal are
available.
Note
If the favorite channel list has more than one page,
press or to scroll through the pages.
DTV
WABCnow
No Program Title
09:10PM2009 March 1
NONE Default
No Program Description
Sound On
-3
7
Henry’s World {V-ME}
1/11 11:00AM - 11:30AM Next28-3 KCET-Vm
TV-Rating
Super Hero Henry/The Treasure Hunt
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU EXIT
OK
ENTER
Advanced Video
Aspect Ratio
Overscan
Color Temperature
Noise Reduction
Insignia Motion 120Hz
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Auto
On
Cool
Middle
20
Low
Backlight
Adjust how the picture fills the screen
USB
17
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
• Overscan—Adjusts the picture’s
reproduction rate. You can select On or
Off. Overscan is set to off when viewing a
computer’s image to show the full image
on your TV.
• Color Temperature—Selects the color
temperature to change the overall color of
the picture. You can select Cool, Normal,
or Warm.
• Noise Reduction—Controls video noise.
You can select Off, Low, Middle, or High.
• Insignia Motion 120 Hz—Eliminates
motion blur to provide clear detail and
smooth motion. You can select:
• Off—Disables Insignia Motion 120 Hz.
• Low—Sets Insignia Motion 120 Hz effect
to minimum (default).
• Medium—Provides smooth and clear
picture motion for normal use.
• High—Eliminates motion blur with clear
detail and smooth motion.
• 24p film mode—Provides smooth and
clear motion from film-based video.
• Backlight—Controls the overall brilliance
of the screen. You can adjust the backlight
through a range of 0 ~ 30.
• Advanced Contrast—When you see the
pop-up menu, set Adaptive Contrast to
On to adjust picture detail and brightness
automatically or to set Dynamic Contrast
Ratio to On to automatically adjust the
contrast between the light and dark areas
of the picture.
• Reset Picture Settings—Resets all picture
settings to the factory defaults. When you
select this option, a confirmation box opens.
Press or to select Yes or No, then press
OK/ENTER to confirm.
3 Press or to adjust the option, or press or
to select a setting.
4 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting component video
To adjust component video:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Component Settings, then
press OK/ENTER or . The Component Settings
screen opens.
4 Press or to highlight an option, then press
or to adjust the option. You can select:
• Phase—Minimizes horizontal distortion.
(0 ~ 100)
• Reset Component Settings—Resets
component settings to the factory defaults.
5 Press MENU to go to the previous menu or press
EXIT to close the menu.
Note
The Overscan option is only available in digital TV,
Component, and HDMI modes.
Note
• If you notice a ghosting type effect (or other
artifact) in some content, artifact, select LOW.
• For certain gaming applications, select Game
mode or turn off the Insignia Motion 120Hz in
the Advanced Video menu.
• If the Game mode is turned On, Insignia
Motion 120Hz will be set to Off automatically.
Note
This setting is available only when the video input
source is set to Component and your TV is receiving
a component signal.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
Phase
Reset Component Settings
50
OK
ENTER
MENU EXIT
Settings
Component Settings
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Minimizes horizontal distortion
USB
18
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Adjusting the computer image
To adjust the computer image:
1 Make sure that your TV is in VGA mode. For
more information, see “Selecting the video
input source” on page 14.
2 Press MENU. The on-screen menu opens.
3 Press or to highlight SETTINGS. The
Settings menu opens.
4 Press or to scroll down the list of options
and highlight Computer Settings.
5 Press OK/ENTER or . The Computer Settings
menu opens.
6 Press or to highlight an option, then press
or to adjust the option. You can select:
• Auto Adjust—Automatically adjusts the
image settings such as position and phase.
• H. Position—Moves the image right or left.
(0 ~ 100)
• V. Position—Moves the image up or down.
(0 ~ 100)
• Clock—Minimizes vertical stripes in the
screen image. (0 ~ 100)
• Phase—Minimizes horizontal distortion.
(0 ~ 100)
• Reset Computer Settings—Resets the
computer settings to the factory default.
7 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Turning Game Mode on or off
To get the maximum gaming experience, your TV
features a Game Mode setting to optimize the
picture for playing games.
To turn Game Mode on or off:
1 Press MENU. The on-screen menu opens.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
Settings
Auto Input Sensing
INlink
Game Mode
Computer Settings
Input Labels
PICTURE AUDIO CHANNELS SETTINGS
Component Settings
MOVE SELECT PREVIOUS EXIT
Set options for when a computer is cnnected to the TV
USB
On
On
Auto Adjust
H. Position
V. Position
Clock
Phase
50
50
50
50
Reset Computer Settings
OK
ENTER
MENU
EXIT
Settings
Computer Settings
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Adjust to the PC signal timing automatically when ON
USB
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
19
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press or to scroll down the list of options
and highlight Game Mode.
4 Press OK/ENTER or to access the submenu,
then press or to select On or Off.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting the sound
Adjusting sound settings
To adjust sound settings:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight AUDIO. The Audio
menu opens.
3 Press to highlight an option, then press
OK/ENTER to access the submenu. You can
select:
• Audyssey Dynamic Volume—Adjusts the
volume to keep the volume level consistent.
You can select Off, Light, Medium, or Heavy.
This option is automatically set to Off when
SRS TruSurround HD is switched from Off to
On.
• SRS TruSurround HD—Provides the ultimate
home theater sound solution. You can select
On or Off. The option is automatically set to
Off when Audyssey Dynamic Volume is
switched from Off to On.
• Treble—Adjust high frequency sound.
• Bass—Adjust low frequency sound.
• Balance—Adjusts the sound between the left
and right speakers.
• Digital Audio/SPDIF—Sends digital audio to
an external audio system. You can select RAW
or PCM.
• Audio Language—Selects the audio
language based on the languages supported
by a digital TV channel.
• MTS/SAP—Selects the sound mode (for
analog channels only). You can select:
• Mono—Produces a clearer sound if stereo
sound is difficult to hear.
• Stereo—Produces dynamic stereo sound
for sporting events and concerts.
• SAP—Selects a second language, weather,
or added commentary, if available.
4 Reset Audio Settings— Reset all audio settings
to factory defaults. When you select this option,
a confirmation box opens. Press or to select
Ye s or No, then press
OK/ENTER to confirm.
5 Press or to modify a scale or to move from
left to right to make a choice in a submenu.
Press or to move up or down when
selecting from a list of choices in a submenu.
6 Press MENU to go to the previous menu or EXIT
to close the menu.
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
Settings
Auto Input Sensing
INlink
Game Mode
Computer Settings
Input Labels
PICTURE AUDIO CHANNELS SETTINGS
Component Settings
MOVE SELECT PREVIOUS EXIT
Game Mode
USB
On
On
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU
EXIT
OK
ENTER
Audio
Audyssey Dynamic Volume
SRS TruSurround HD
Treble
Bass
Balance
PICTURE AUDIO CHANNELS SETTINGS
Digital Audio/SPDIF
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect sound quality
Medium
Off
32
32
0
PCM
USB
20
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Playing TV audio only
You can turn off the picture on your TV and listen to
the program audio only.
To play TV audio only:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight CHANNELS. The
Channels menu opens.
3 Press to highlight Audio Only, then press
OK/ENTER or to access the submenu.
4 Press or to select On.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Changing channel settings
Automatically scanning for channels
When you scan for channels, your TV searches for
channels with signals and stores the channel
information in the channel list. When you press
CH or CH , your TV goes to the next or previous
channel in the channel list.
If the TV signal source changes, for example you
change from an outdoor antenna to cable TV (no
box), you need to scan for channels.
To automatically scan for channels:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight CHANNELS. The
Channels menu opens.
3 Press to highlight Auto Channel Search, then
press OK/ENTER or to access the submenu.
The Auto Channel Search screen opens.
Notes
• It takes about three seconds after the menu
closes and the picture disappears before the
audio plays.
• Audio Only works only when the input source is
TV and your TV is receiving a broadcast signal.
• To exit audio only mode, press any button.
When you exit audio only mode, the Audio
Only option is automatically reset to Off.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU EXIT
OK
ENTER
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Labels
Channel Strength
PICTURE AUDIO CHANNELS SETTINGS
ffOylnO oiduA
MOVE SELECT PREVIOUS EXIT
Adjust channel options
USB
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU EXIT
OK
ENTER
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Labels
Channel Strength
PICTURE AUDIO CHANNELS SETTINGS
ffOylnO oiduA
MOVE SELECT PREVIOUS EXIT
Adjust channel options
USB
MENU EXIT
OK
ENTER
Auto Channel Search
Channels
Choose your TV source
Antenna
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Select Antenna if using an antenna for standard or HD TV
Cable
Analog Channels
Digital Channels
0
0
Cable/Satellite Box
USB
21
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
4 Press to highlight Antenna, Cable, or
Cable/Satellite Box, then press OK/ENTER to
start the scan.
• If you are using an antenna for a standard or
HD TV signal, select Antenna.
• If your cable is connected directly to the TV
(using no tuner box), select Cable.
• If your cable is connected to your TV through a
tuner box, select Cable/Satellite Box.
If you selected Antenna or Cable, your TV
searches automatically for available channels in
your area and stores the channel information in
the channel list. This may take several minutes.
While searching, the TV displays a progress
report.
Or,
If you selected Cable/Satellite Box, the channel
search is not necessary. Press EXIT to close the
menu.
Hiding channels
You can hide channels in the channel list. When you
press CH or CH , your TV will skip the hidden
channels. You can still tune to a hidden channel by
pressing the number buttons for the channel.
To hide channels:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight CHANNELS. The
Channels menu opens.
3 Press to highlight Add/Skip Channels, then
press OK/ENTER or . The Add/Skip Channels
screen opens.
4 Press or to highlight the channel you
want to hide, then press OK/ENTER. The check
mark disappears.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Setting up a favorite channel list
To set up a favorite channel list:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight CHANNELS. The
Channels menu opens.
Note
You can press EXIT to stop the auto channel search,
but you will need to run the auto channel search
again to create a channel list.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU EXIT
OK
ENTER
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Labels
Channel Strength
PICTURE AUDIO CHANNELS SETTINGS
ffOylnO oiduA
MOVE SELECT PREVIOUS EXIT
Adjust channel options
USB
Notes
• A channel with a check mark is not hidden. A
channel with no check mark is hidden.
• If the list has more than one page, press or
to scroll through the pages.
Ch 5-0 Ch 9-0
MENU EXIT
OK
ENTER
Add/Skip Channels
Channels
PICTURE AUDIO CHANNELS
SETTINGS
MOVE SELECT PREVIOUS EXIT
Manually add and skip channels in your program list
Ch 9-1 WWOR DT
Ch 10-0
Ch 60-2
Ch 60-4
Ch 9-2 WNYW DT
Ch 60-1
Ch 60-3
Ch 60-7
USB
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU EXIT
OK
ENTER
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Labels
Channel Strength
PICTURE AUDIO CHANNELS SETTINGS
ffOylnO oiduA
MOVE SELECT PREVIOUS EXIT
Adjust channel options
USB
22
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
3 Press to highlight Favorites, then press
OK/ENTER or . The Favorites screen opens.
4 Press or to highlight the channel you
want to add to the favorites list, then press
OK/ENTER. A check mark appears next to the
channel.
5 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Viewing a favorite channel
To view a favorite channel:
1 Press FAV on your remote control. The favorite
channel list opens.
2 Press or to highlight a channel, then press
OK/ENTER to tune to the channel.
3 Press EXIT to close the favorite channel list.
Adding or changing a channel label
1 Press MENU. The on-screen menu opens.
2 Press or to highlight CHANNELS. The
Channels menu opens.
3 Press to highlight Channel Labels, then press
OK/ENTER or . The Channel Labels screen
opens.
4 Press or to select the channel you want to
label, then press to move to the channel label
field.
5 Press or to select a letter, then press to
move to the next letter. Repeat this step to enter
additional letters. You can enter as many as 11
letters.
6 Press OK/ENTER to confirm the label.
7 Press or to check Ye s or No, then press
OK/ENTER.
8 Press MENU to go to the previous menu, or
press EXIT to close the menu.
Notes
• To remove a channel from the favorites list,
highlight the channel, then press ENTER. The
check mark disappears and the channel is
removed from the list.
• If the list has more than one page, press or
to scroll through the pages.
Notes
If the list has more than one page, press or to
scroll through the pages.
MENU
EXIT
OK
ENTER
FavoritesChannels
PICTURE AUDIO CHANNELS SETTINGS
USB
MOVE SELECT PREVIOUS EXIT
Add channels to create a favorites list
Ch 5-0
Ch 9-1 WWOR DT
Ch 10-0
Ch 60-2
Ch 60-4
Ch 9-0
Ch 9-2 WNYW DT
Ch 60-1
Ch 60-3
Ch 60-7
MENU
EXIT
OK
ENTER
MOVE SELECT PREVIOUS EXIT
Select your favorite channel
Favorites
Ch 5-0
Ch 10-0
Ch 60-3
Ch 60-8
Ch 60-11
Ch 60-12
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU EXIT
OK
ENTER
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Labels
Channel Strength
PICTURE AUDIO CHANNELS SETTINGS
ffOylnO oiduA
MOVE SELECT PREVIOUS EXIT
Adjust channel options
USB
MENU
EXIT
OK
ENTER
Channels
Channels Labels
Ch 5-0
Create labels for channels, up to 11 characters
ABC
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
USB
23
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Checking the digital signal strength
To check the digital signal strength:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight CHANNELS. The
Channels menu opens.
3 Press to highlight Channel Strength, then
press OK/ENTER or . The DTV signal meter
screen opens.
4 Press MENU to go to the previous menu, or
press EXIT to close the menu.
Setting parental controls
Setting or changing the password
Your TV has a V-chip that lets you control the type
of programs your children can watch. Parental
controls include two ratings: MPAA (based on age)
and TV Parental Guidelines (based on content and
age). A TV program may have an MPAA or TV
Parental Guidelines rating, so you should set
controls for both ratings.
Before you can select ratings, you need to set up a
parental controls password.
To set up a password:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Parental Controls, then
press OK/ENTER or . The Enter Password
screen opens.
Note
When you are tuned to a digital TV channel, you can
press INFO to see the DTV signal strength.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
MENU EXIT
OK
ENTER
Channels
Auto Channel Search
Add/Skip Channels
Favorites
Channel Labels
Channel Strength
PICTURE AUDIO CHANNELS SETTINGS
ffOylnO oiduA
MOVE SELECT PREVIOUS EXIT
Adjust channel options
USB
MENU EXIT
OK
ENTER
Channel Strength
Now
0010
0%
CH 7-3
MOVE SELECT PREVIOUS EXIT
Display signal strength of selected digital channel
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
Enter Password
24
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
4 Press the number buttons to enter the
password. If you have not set a password, enter
0000. The Parental Controls menu opens.
5 Press or to highlight Change Password,
then press OK/ENTER or . The Enter New
Password screen opens.
6 Press the number buttons to enter the new
password, then enter the new password again.
Locking control buttons
You can lock the control buttons on the TV. When
the buttons are locked, you can only operate the TV
using the remote control.
To lock control buttons:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Parental Controls, then
press OK/ENTER or . The Enter Password
screen opens.
4 Press the number buttons to enter the
password. If you have not set a password, enter
0000. The Parental Controls menu opens.
5 Press or to highlight Button Lock, then
press OK/ENTER or to access the submenu.
6 Press or to select On or Off.
7 Press MENU to go to the previous menu, or
press EXIT to close the menu.
Note
Write down your password and save it for future use.
If you forget your password, enter 9999 as the
password. This password always remains valid for
resetting your password.
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Off
Off
Button Lock
USA Parental Locks
Canadian Parental Locks
Block Unrated TV
PICTURE AUDIO CHANNELS SETTINGS
Change Password
MOVE SELECT PREVIOUS EXIT
Lock or unlock the buttons on the TV
USB
Enter New Password
Confirm New Password
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
Enter Password
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Off
Off
Button Lock
USA Parental Locks
Canadian Parental Locks
Block Unrated TV
PICTURE AUDIO CHANNELS SETTINGS
Change Password
MOVE SELECT PREVIOUS EXIT
Lock or unlock the buttons on the TV
USB
25
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Blocking unrated TV
To block unrated TV:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Parental Controls, then
press OK/ENTER or . The Enter Password
screen opens.
4 Press the number buttons to enter the
password. If you have not set a password, enter
0000. The Parental Controls menu opens.
5 Press or to highlight Block Unrated TV,
then press OK/ENTER or to access the
submenu.
6 Press or to select On (blocks unrated TV) or
Off (does not block unrated TV).
7 Press MENU to go to the previous menu, or
press EXIT to close the menu.
Setting parental control levels
You can set parental controls for the U.S. and
Canada.
Some of the age-based TV Parental Guidelines
ratings also have content-based ratings.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
Enter Password
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Off
Off
Button Lock
USA Parental Locks
Canadian Parental Locks
Block Unrated TV
PICTURE AUDIO CHANNELS SETTINGS
Change Password
MOVE SELECT PREVIOUS EXIT
Block TV programs that do not have a rating
USB
U.S. TV ratings
NONE Not rated
TV-Y All children
TV-Y7 Children over seven years of age
TV-G General audiences
TV-PG Parental guidance suggested
TV-14 Parents strongly cautioned
TV-MA Mature audiences only
U.S. TV content ratings
FV Fantasy violence
L Adult language
SSexual situations
V Violence
D Sexually suggestive dialog
U.S. movie (MPAA) ratings
None Movie not rated
G General audiences
PG Parental guidance suggested
PG-13 Suitable for children 13 and older
R Parental guidance suggested for
children under 17
NC-17 Not suitable for children under 17
X Adults only
N/A Not rated
Canadian English ratings
EExempt programming
C Children
C8+ Children over 8 years old
G General audiences
PG Parental guidance
14+ Over 14 years old
18+ Adult programming
Canadian French ratings
EExempt programming
G General audiences
8ans+ Over 8 years old
13ans+ Over 13 years old
16ans+ Over 16 years old
18ans+ Adult programming
26
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
To set parental control levels:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Parental Controls, then
press OK/ENTER or . The Enter Password
screen opens.
4 Press the number buttons to enter the
password. If you have not set a password, enter
0000. The Parental Controls menu opens.
5 Press to highlight USA Parental Locks or
Canadian Parental Locks, then press
OK/ENTER or . The USA Parental Locks or
Canadian Parental Locks screen opens.
6 Press or to highlight a rating, then
press OK/ENTER to block or unblock the rating.
When you block a rating, that rating and all
higher ratings are blocked.
7 Press MENU to go to the previous menu, or
press EXIT to close the menu.
Downloading rating information
You can download rating information to use when
setting parental controls.
To download rating information:
1 Press MENU. The on-screen menu opens.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
Enter Password
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Off
Off
Button Lock
USA Parental Locks
Canadian Parental Locks
Block Unrated TV
PICTURE AUDIO CHANNELS SETTINGS
Change Password
MOVE SELECT PREVIOUS EXIT
Lock or unlock the buttons on the TV
USB
Note
• When you first set parental controls, they take
effect immediately.
• If you have set parental controls then tune to a
blocked channel or program, you are prompted
to enter the password. After you enter the
password, parental controls are tuned off. To
turn parental controls back on, turn off your TV
then turn it back on. Parental controls will be
turned back on.
OK
ENTER
MENU EXIT
Settings
TV RatingsMPAA Rating
FV L S V D
Parental Controls USA Parental Locks
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
None
PG
G
PG-13
R
NC-17
X
Restrict movie and TV programs by US Ratings
None
TV-Y7
TV-Y
TV-G
TV-PG
TV-14
TV-MA
USB
OK
ENTER
MENU
EXIT
Settings
English Rating French Rating
Parental Controls Canadian Parental Locks
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
E
C8+
C
G
PG
14+
18+
Restrict movie and TV programs by Canadian Ratings
E
8 ans+
G
13 ans+
16 ans+
18 ans+
USB
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
27
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Parental Controls, then
press OK/ENTER or . The Enter Password
screen opens.
4 Press the number buttons to enter the
password. If you have not set a password, enter
0000. The Parental Controls menu opens.
5 Press or to scroll down the list of options
and highlight RRT5.
6 Press OK/ENTER or . The RRT5 screen opens.
7 Press to highlight an option, then press
OK/ENTER or to open the submenu.
8 Press or to select a rating.
9 Press MENU to go to the previous menu, or
press EXIT to close the menu.
Using closed captioning
Turning closed captioning on or off
To turn closed captioning on or off:
• Press CC to select CC Off, CC On, or CC On When
Mute.
Selecting the closed captioning mode
To select the closed captioning mode:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
Enter Password
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Off
Off
Button Lock
USA Parental Locks
Canadian Parental Locks
Block Unrated TV
PICTURE AUDIO CHANNELS SETTINGS
Change Password
MOVE SELECT PREVIOUS EXIT
Lock or unlock the buttons on the TV
USB
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Off
USA Parental Locks
Canadian Parental Locks
Block Unrated TV
PICTURE AUDIO CHANNELS SETTINGS
Change Password
MOVE SELECT PREVIOUS EXIT
Display an advanced V-Chip ratings table for digital channels
RRT5
USB
Note
• If the program is broadcast with RRT5 rating
information, the information is downloaded
automatically and can be used for parental
controls.
• If the program is not broadcast with RRT5 rating
information, no information is downloaded.
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
28
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
3 Press to highlight Closed Caption, then press
OK/ENTER or . The Closed Caption menu
opens.
4 Press or to highlight Analog Caption or
Digital Caption, then press OK/ENTER or to
open the submenu.
5 Press or to select a setting. You can
select:
• CC1 through CC4—Closed captioning
appears in a small banner across the bottom
of the screen. The closed captioning displayed
depends on the content provided by the
broadcaster.
• Text 1 through Text4—Closed captioning that
covers half or all of the screen. Tex t1 through
Text4 display content provided by the
broadcaster.
6 Press MENU to go to the previous menu, or
press EXIT to close the menu.
Customizing digital closed captioning styles
To customize digital closed captioning styles:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Closed Caption, then press
OK/ENTER or . The Closed Caption screen
opens.
4 Press or to highlight Digital CC Settings,
then press OK/ENTER or . The Digital CC
Settings screen opens.
5 Press to highlight Style, then press or to
select Custom. If Style is set to Automatic, you
cannot adjust individual style options.
6 Press to highlight an option, then press or
to adjust the option. You can select:
• Style—Selects the digital closed captioning
style. This option must be set to Custom to
change individual style options.
• Size—Selects the font size.
• Font—Selects the font type.
• Text Color—Selects the text color.
• Text Opacity—Selects the text opacity.
• Background Color—Selects the background
color.
• Background Opacity—Selects the
background opacity.
• Edge Effect—Selects the edge style.
• Edge Color—Selects the edge color.
7 Press MENU to go to the previous menu, or
press EXIT to close the menu.
OK
ENTER
MENU
EXIT
Settings
Closed Caption
CS1Digital Caption
CC1
Digital CC Settings
Adjust Closed Captioning settings
Analog Caption
CC OffCaption Control
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
USB
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU EXIT
Settings
Closed Caption
CS1Digital Caption
CC1
Digital CC Settings
Customize the look of digital Closed Captioning
Analog Caption
CC OffCaption Control
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
USB
MENU EXIT
OK
ENTER
Digital CC Settings
Style
Size
Font
Text Color
Text Opacity
Background Color
Background Opacity
Edge Effect
Edge Color
Automatic
Automatic
Automatic
Automatic
Automatic
Automatic
Automatic
Automatic
Automatic
DECIDED BY AUTO
MOVE SELECT PREVIOUS EXIT
Set the look of digital CC. Automatic uses broadcaster’s style.
29
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Adjusting time settings
Setting the time
To set the time:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Time, then press OK/ENTER
or . The Time menu opens.
4 Press or to highlight Date/Time, then press
OK/ENTER. The Date/Time screen opens.
5 Press or to highlight Mode, then press
ENTER. A menu opens.
6 Press or to highlight Manual (to set the
options manually) or Auto (the options are
automatically set by the TV signal source).
7 Press OK/ENTER to close the menu.
8 Press or to highlight Time Zone, then press
ENTER. The Time Zone menu opens.
9 Press or to select your time zone. You can
select Eastern, Central, Mountain, Pacific,
Alaska, Hawaii, Atlantic, or Newfoundland.
10 Press ENTER to close the menu.
11 If your viewing area observes daylight savings
time, press or to highlight Daylight
Savings, then press OK/ENTER.
12 Press or to select On, then press OK/ENTER
to close the menu.
13 If you selected Custom for Mode:
• Press or to highlight Year,
Month, or
Date, then press or to adjust the setting.
• Press or to highlight Time, press or to
select the hour, minute, or AM/PM field, then
press or to adjust the setting.
14 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
Settings
Time
OffSleep Timer
Date/Time
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
USB
Adjust the date and time to get the correct program times
OK
ENTER
MENU
EXIT
Settings Time Date/Time
Auto
Pacific
On
2009
Jan
Time Zone
Mode
Daylight Savings
Year
Month
If Automatic, options are automatically set by TV source
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
1Day
USB
30
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Setting the sleep timer
To set the sleep time:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Time, then press OK/ENTER
or . The Time menu opens.
4 Press or to highlight Sleep Timer, then
press OK/ENTER or to access the sleep timer
list.
5 Press or to select the amount of time before
your TV turns off automatically. To turn off the
sleep timer, select Off.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Adjusting menu settings
Adjusting the menu transparency
To select the menu language:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Menu Settings, then press
OK/ENTER or . The Menu Settings menu opens.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
Settings
Time
OffSleep Timer
Date/Time
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
USB
Adjust the date and time to get the correct program times
OK
ENTER
MENU EXIT
Settings Time
OffSleep Timer
Date/Time
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
USB
Off
5 minutes
10 minutes
15 minutes
30 minutes
60 minutes
90 minutes
120 minutes
180 minutes
240 minutes
Note
You can also press SLEEP one or more times to set
the sleep timer. You can select Off, 5, 10, 15, 30, 60,
90, 120, 180, or 240 minutes.
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
Settings Menu Settings
English
0
Language
Adjust how transparent the TV menu appears
0ycnerapsnarT
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
USB
31
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
4 Press or to select Transparency, then press
OK/ENTER or to access the submenu.
5 Press or to adjust the transparency.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Selecting the menu language
To select the menu language:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Menu Settings, then press
OK/ENTER or . The Menu Settings menu opens.
4 Press to highlight Language, then press
OK/ENTER or to open the submenu.
5 Press or to select a language. You can select
English, Francais, or Español.
6 Press MENU to return to the previous menu, or
press EXIT to close the menu.
Turning Auto Input Sensing on or off
When the Auto Input Sensing feature is turned on,
your TV automatically detects which video jacks
have devices connected to them. Your TV uses this
information to determine what options are
highlighted on the Source List when you press
INPUT. If no device is connected to a video jack, the
option if greyed on the Source List and cannot be
selected.
To turn Auto Input Sensing on or off:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Auto Input Sensing, then
press OK/ENTER or to access the submenu.
4 Press or to select On (video input sources
for connected devices are highlighted in the
Source List) or Off (no video input sources are
highlighted in the Source List).
5 Press MENU to go to the previous menu or press
EXIT to close the menu.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
Settings Menu Settings
English
0
Language
Set menu language to English, Français, or Español
Transparency 0
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
USB
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
On
Off
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
INlink
MOVE SELECT PREVIOUS EXIT
Allows selection of active sources connected to input jacks with INPUT key
USB
On
32
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Labeling an input source
To label an input source:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Input Labels, then press
OK/ENTER or . The Input Labels screen opens.
4 Press or to select the input you want to
change the label for (for example, Component).
5 Press to move the cursor to the label selection
field.
6 Press or to select the label you want (—,
VCR, DVD, Set Top Box, Satellite, Cable Box,
DVD/PVR, Blu-ray, Game 1, Game 2,
Camcorder, Receiver, PC, or Custom), then
press OK/ENTER to confirm the change.
7 Press or to check Ye s or No, then press
OK/ENTER to confirm.
8 To change another input label, press to move
the cursor to the input selection field, then
repeat Step 4 through Step 7.
9 Press MENU to go to previous menu or press
EXIT to close the on-screen menu.
Using INlink
INlink lets you control HDMI CEC-compatible
devices using the remote control that came with
your TV. For more information, see “INlink:” on
page 4.
To use INlink, you must set the INlink Control
option on the INlink menu to On.
To turn INlink on or off:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press or to scroll down the list of options
and highlight INlink.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU EXIT
Settings Input Labels
Component
Create labels for the devices connected to your TV
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
DVD
USB
Notes
• The INlink function only works when the TV
remote control is set to TV.
• Turn on the HDMI/CEC feature for the
HDMI/CEC-compatible device that you are
connecting to your TV before you access the
INlink function.
• Some HDMI CEC-compatible devices might not
support this INlink feature.
• The TV remote control may not work correctly
under certain conditions. If this occurs, re-select
the INlink Device Lists option and select the
registered HDMI CEC-compatible device.
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
OK
ENTER
MENU
EXIT
Settings
Time
Auto Input Sensing
Input Labels
INlink
Menu Settings
PICTURE AUDIO CHANNELS SETTINGS
Game Mode
MOVE SELECT PREVIOUS EXIT
Allow the TV to automatically control CEC devices connected to the TV via HDMI
USB
On
On
33
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
4 Press OK/ENTER or . The INlink menu opens.
5 Press or to select an option, then press
OK/ENTER or to access the submenu. You can
select:
• INlink Control—Lets your TV automatically
control CEC devices connected to the TV
through HDMI. Press or OK/ENTER to select
On or Off.
• Device Auto Power Off—Turns off connected
HDMI CEC-compatible devices when you turn
off your TV. Press or OK/ENTER to select On
or Off.
• TV Auto Power On—Turns on your TV when a
connected HDMI CEC-compatible device is
turned on. Press or OK/ENTER to select On
or Off.
• INlink Device Lists—Displays the device list
to register or remove the connected HDMI
CEC-compatible devices from the list.
• Connect—Wakes up the connected
HDMI/CEC device.
• Root Menu—Accesses the menu of
connected HDMI CEC-compatible device
with your TV remote control.
Press OK/ENTER or . Your TV scans for
connected HDMI CEC-compatible devices and
displays the devices in a list.
6 Press MENU to go to previous menu or press
EXIT to close the on-screen menu.
Restoring settings to the defaults
To restore settings to the defaults:
1 Press MENU. The on-screen menu opens.
2 Press or to highlight SETTINGS. The
Settings menu opens.
3 Press to highlight Reset to Default, select
Ye s , then press OK/ENTER to confirm. All
settings except the channel list and parental
control password will be reset to the default
settings.
4 Press MENU to go to the previous menu or press
EXIT to close the menu.
OK
ENTER
MENU
EXIT
Settings
INlink
INlink Control
TV Auto Power On
INlink Device Lists
Device Auto Power Off
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Allow the TV to automatically control CEC devices connected to the TV via HDMI
USB
On
On
On
MENU EXIT
OK
ENTER
Mode
Brightness
Contrast
Color
Tint
PICTURE AUDIO CHANNELS SETTINGS USB
MOVE SELECT PREVIOUS EXIT
Adjust settings to affect picture quality
Energy Savings
50
48
70
0
0ssenprahS
Note
You may need to scroll down to see the Reset to
Default option.
OK
ENTER
MENU
EXIT
Settings
Parental Controls
Time
Menu Settings
Auto Input Sensing
Closed Caption
PICTURE AUDIO CHANNELS SETTINGS
Input Labels
MOVE SELECT PREVIOUS EXIT
Set various TV options
USB
On
34
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Using USB
You can view JPEG photos stored on a USB flash
drive, by connecting the flash drive to the USB port
on your TV.
Switching to USB mode
To switch to USB mode:
1 Connected the USB flash drive to the USB port
on the back of your TV. A message asks if you
want to view photos on the flash drive.
2 Press or to select Ye s , then press
OK/ENTER. The on-screen menu opens with the
USB menu displayed.
Browsing photos
To browse photos:
1 Make sure that you have switched to USB mode.
For more information, see “Switching to USB
mode” on page 34.
2 Press MENU. The on-screen menu opens with
the USB menu displayed.
3 Press to highlight Browse Photos, then press
OK/ENTER. The browse screen opens.
4 Press or to select a folder that contains
photos, then press OK/ENTER to open the
folder.
5 Press or to select a photo, then press
OK/ENTER to view the photo.
6 Press or to view the next photo. Press or
to view the previous photo.
7 To enlarge the image, press ZOOM one or more
times. In zoom mode:
• Press or to navigate around the
screen.
• To go to next photo, press ZOOM one or more
times until “Zoom Fill” mode pops up, then
press or to select another photo.
Note
Unless otherwise noted, all tasks in this section are
based on using the remote control.
Notes
• Never remove the USB device or turn off your TV
while viewing JPEG pictures.
• We recommend that you back up the data on
your USB device.
• The JPEG picture viewer only supports JPEG
format images (with “.jpg” file extensions) and
not all JPEG files are compatible with the TV.
• The maximum supported JPEG format image
should be under 15360 × 8640 pixels (132 MB
pixels).
Note
• If your USB flash drive is already inserted at the
USB port, you will be asked if you want to view
photos stored on the USB flash drive.
•If you select No, your TV switches to the last
video input source it was in when your TV was
turned off.
•If the USB menu disappears, press MENU again
before you press any other button.
Show Photos with USB Flash Drive?
Yes
No
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU FAV EXIT
OK
ENTER
Number of Folders : 4
Number of Files : 0
MOVE SELECT PREVIOUS FAVORITE EXIT
File name File name File name File name
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU FAV
EXIT
OK
ENTER
File name
Number of Folders : 0
Number of Files : 17
MOVE SELECT PREVIOUS FAVORITE EXIT
35
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
8 If you are in a subfolder, press RECALL to return
to the root folder.
Setting up a favorite photos list
To set up a favorite photos list:
1 Make sure that you have switched to USB mode.
For more information, see “Switching to USB
mode” on page 34.
2 Press MENU. The on-screen menu opens with
the USB menu displayed.
3 Press to highlight Browse Photos, then press
OK/ENTER. The browse screen opens.
4 Press or to select a folder that contains
photos, then press OK/ENTER to open the
folder.
5 Press or to select a photo, then press
FAV on your remote control to check the
selected photo and add it to the favorite list. You
can remove a selected photo from the favorite
list by selecting it and pressing FAV again.
Viewing favorite photos
To view favorite photos:
1 Make sure that you have switched to USB mode.
For more information, see “Switching to USB
mode” on page 34.
2 Press MENU. The on-screen menu opens with
the USB menu displayed.
3 Press to highlight Browse Photos, then press
OK/ENTER. The browse screen opens.
4 Press or to select a folder that contains
photos, then press OK/ENTER to open the
folder.
Note
Favorite photos are labeled in the upper-right corner
with a heart-shaped icon.
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU FAV EXIT
OK
ENTER
Number of Folders : 4
Number of Files : 0
MOVE SELECT PREVIOUS FAVORITE EXIT
File name File name File name File name
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU FAV
EXIT
OK
ENTER
File name
Number of Folders : 0
Number of Files : 17
MOVE SELECT PREVIOUS FAVORITE EXIT
Note
You have to set up the favorite photo list before you
can view favorite photos.
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU FAV EXIT
OK
ENTER
Number of Folders : 4
Number of Files : 0
MOVE SELECT PREVIOUS FAVORITE EXIT
File name File name File name File name
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU FAV
EXIT
OK
ENTER
File name
Number of Folders : 0
Number of Files : 17
MOVE SELECT PREVIOUS FAVORITE EXIT
36
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
5 Press MENU to open the USB menu, then
press to highlight Favorite Photos.
6 Press OK/ENTER. The favorite photos screen
opens.
7 Press or to select the favorite photo
you want to view first, then press OK/ENTER.
8 Press or to view the next photo. Press or
to view the previous photo.
Viewing all photos in a slideshow
To view all photos in a slideshow:
1 Make sure that you have switched to USB mode.
For more information, see “Switching to USB
mode” on page 34.
2 Press MENU. The on-screen menu opens with
the USB menu displayed.
3 Press to highlight Browse Photos, then press
OK/ENTER. The browse screen opens.
4 Press or to select a folder that contains
photos, then press OK/ENTER to open the
folder.
5 Press MENU to open the USB menu.
6 Press to highlight View Slideshow.
7 Press OK/ENTER or to start the slideshow,
8 To stop the slideshow, press MENU or EXIT.
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
View only the photos you selected as your favorites
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU EXIT
OK
ENTER
Number of Files : 2
MOVE SELECT PREVIOUS EXIT
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU FAV EXIT
OK
ENTER
Number of Folders : 4
Number of Files : 0
MOVE SELECT PREVIOUS FAVORITE EXIT
File name File name File name File name
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
View your photos in a slideshow
USB
Photos
37
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Viewing favorite photos in a slideshow
To view favorite photos in a slideshow:
1 Make sure that you have switched to USB mode.
For more information, see “Switching to USB
mode” on page 34.
2 Press MENU. The on-screen menu opens with
the USB menu displayed.
3 Press to highlight Browse Photos, then press
OK/ENTER. The browse screen opens.
4 Press or to select a folder that contains
photos, then press OK/ENTER to open the
folder.
5 Press MENU to open the USB menu.
6 Press to highlight Favorite Photos, then press
OK/ENTER to open the Favorite Photos screen.
7 Press MENU to open the USB menu.
8 Press to highlight View Slideshow, then press
OK/ENTER or to start the slideshow.
9 To stop the slideshow, press MENU or EXIT.
Customizing slideshow settings
To customize slideshow settings:
1 Make sure that you have switched to USB mode.
For more information, see “Switching to USB
mode” on page 34.
2 Press MENU. The on-screen menu opens with
the USB menu displayed.
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU FAV EXIT
OK
ENTER
Number of Folders : 4
Number of Files : 0
MOVE SELECT PREVIOUS FAVORITE EXIT
File name File name File name File name
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
MENU EXIT
OK
ENTER
Number of Files : 2
MOVE SELECT PREVIOUS EXIT
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Find photos that are on the USB device
USB
Photos
38
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
3 Press to highlight Settings.
4 Press OK/ENTER or . The Settings menu opens.
5 Press to highlight a setting, then press or
to adjust the setting. You can select:
• Repeat—Repeats the slideshow when it
reaches the end. You can select On or Off.
• Shuffle—Displays the slideshow photos in
random order. You can select On or Off.
• Speed—Sets the amount of time a photo is
displayed before the slideshow moves to the
next photo. You can select 2 Sec, 4 Sec, 6 Sec,
or 8 Sec.
• Transition—Selects a transition effect when
moving to the next file in the slideshow. You
can select None, Fade to Black, Vertical
Wipe, Horizontal Wipe, or Random.
6 Press EXIT to close the menu.
Maintaining
• Do not use your TV in areas that are too hot or too
cold, because the cabinet may warp or the screen
may malfunction. Your TV works best in
temperatures that are comfortable to you.
• Storage temperatures are 32° to 122°F (0° to 50°C).
• Working temperatures are 41° to 104°F
(5° to 40°C).
• Do not place your TV in direct sunlight or near a
heat source.
Cleaning the TV cabinet
Clean the cabinet with a soft, lint-free cloth. If the
cabinet is especially dirty, moisten a soft, lint-free
cloth in a weak detergent solution, squeeze the
excess moisture from the cloth, then wipe the
screen or cabinet with the cloth. Use a clean cloth to
dry the screen or cabinet.
Cleaning the TV screen
Clean the screen with a soft, lint-free cloth.
Troubleshooting
OK
ENTER
MENU
EXIT
USB
Browse Photos
View Slideshow
Settings
Favorite Photos
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Change slideshow settings
USB
Photos
OK
ENTER
MENU
EXIT
USB
Repeat On
Off
None
4Sec
Speed
Transition
Shuffle
PICTURE AUDIO CHANNELS SETTINGS
MOVE SELECT PREVIOUS EXIT
Repeat the slideshow when it reaches the end
USB
Photos Settings
Warning
Do not try to repair your TV yourself. Refer all service
to a qualified service technician.
Problem Solution
Power
No power
• Make sure that the power cord is correctly
connected to your TV and a power outlet.
See”Connecting the power” on page 10.
• Unplug the power cord, wait 60 seconds,
then plug the cord back in and turn on
your TV.
Remote control
Remote control does not work
• Make sure that there are no obstructions
between the remote control and the
remote control sensor on the front of your
TV.
• Clean the remote sensor on the front of
your TV.
• Bright or fluorescent lighting may
interfere with the remote control signal.
Turn off the light or move your TV.
• Replace the batteries. Make sure that the
+ and – symbols on the batteries align
with the + and – symbols in the battery
compartment. See “Installing remote
control batteries” on page 8.
Remote control code cannot be
detected by a universal remote
• Purchase a separate learning remote
control.
• Go to www.insigniaproducts.com for a list
of remote control codes.
39
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
No picture
• Make sure that the Audio Only option is
set to Off. See “Playing TV audio only” on
page 20.
• Make sure that the video cables are
connected securely to the back of your TV.
See “Making connections” on page 10.
• Adjust the contrast and brightness. See
“Adjusting the TV picture” on page 16.
• Make sure that the correct video mode is
selected. See “Selecting the video input
source” on page 14.
• Make sure that the incoming signal is
compatible.
• Make sure the antenna is connected
correctly. See “Connecting an antenna or
cable TV (no box)” on page 10.
• Check the closed caption settings. Some
TEXT modes can block the screen. See
“Selecting the closed captioning mode”
on page 27.
Good sound but poor color
• Adjust the contrast, color, and brightness
settings. See “Adjusting the TV picture”
on page 16.
Poor picture
• Make sure that the room is not too bright.
Light reflecting off the screen can make
the picture difficult to see.
• If an S-VHS camera or a camcorder is
connected while another connected
device is turned on, the picture may be
poor. Turn off one or more devices.
Horizontal dotted line
• Your TV may be too close to another
electrical device, such as a hair dryer or
neon light. Turn off the device or move
your TV.
“Ghost” or double image
• Obstructions, such as a high-rise building
or hills, may be preventing your antenna
from receiving a clear signal. Using a
highly directional antenna may improve
the picture quality.
Snowy picture or noise
• Make sure that the AV and antenna cables
are connected securely.
VGA picture is not stable or
synchronized
• Make sure that you have selected the
correct VGA mode on your computer.
After images appear
• Do not display a still image, such as a logo,
game, or computer image, for an
extended period of time. This can cause a
permanent after-image to be burned into
the screen. This type of damage is not
covered by your warranty.
Picture has a few bright or dark
spots
• A few bright or dark dots on an LCD screen
is normal. It does not affect the operation
of this TV.
Audio
Good picture but no sound
• Increase the volume.
• Make sure that the sound is not muted.
• Make sure that the correct audio mode is
selected. See “Adjusting sound settings”
on page 19.
No output from one of the
speakers
• Adjust the balance in the Audio menu. See
“Adjusting sound settings” on page 19.
Other
Problem Solution
Buttons on the front of the TV
do not work
• Make sure that the Button Lock option is
set to Off. See “Locking control buttons”
on page 24.
• Unplug the power cord, wait a few
seconds, then plug the cord back in and
turn on your TV.
INlink does not work
• Make sure that the device you want to
control is HDMI CEC-compatible.
• Make sure that the HDMI device’s power
cord is connected correctly.
• Make sure that the INlink Control option is
set to On in the INlink menu. See “Using
INlink” on page 32.
• Scan for INlink devices again. See “Using
INlink” on page 32.
• Connect an INlink device using an
HDMI 1.3 cable.
• If it the HDMI cable is disconnected then
reconnected or if the power is turned off
scan for INlink devices again. See “Using
INlink” on page 32.
Problem Solution
40
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Specifications
Design and specifications are subject to change
without notice.
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of
this product is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this device
must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply within the
limits for a class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to
radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try
to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
FCC warning
Changes or modifications not expressly approved by the party
responsible for compliance with the FCC Rules could void the
user’s authority to operate this equipment.
Cables
Connections to this device must be made with shielded cables
with metallic RF/EMI connector hoods to maintain compliance
with FCC Rules and Regulations.
Canada ICES-003 statement
This Class B digital apparatus complies with Canadian ICES-003.
Standard Television Receiving Apparatus — Appareil de
réception télévision ordinaire, Canada BETS-7 / NTMR-7
Dolby License Notice and Trademark Acknowledgement
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
HDMI
HDMI, the HDMI logo, and
High-Definition Multimedia Interface are
trademarks or registered trademarks of
HDMI Licensing LLC.
Audyssey
Energy Star
To meet Energy Star requirements, keep TV settings at
the factory default settings.
SRS TruSurround HD
is a trademark of SRS Labs, Inc. TruSurround
HD technology is incorporated under license
from SRS Labs, Inc.
Analog standard NTSC
Digital standard ATSC, 8-VSB, Clear-QAM
Photo standard JPEG format
Screen size NS-42E570A11: 42"
NS-46E570A11: 46"
Channel coverage VHF: 2-13
UHF: 14-69
CATV: Mid band - A-8 ~ A-1, A ~ I
Super band: J ~ W
Hyper band: AA ~ ZZ, AAA, BBB
Ultra band: 65 ~ 94, 100 ~ 135
Power source AC 120 V ~ 60 Hz
Power consumption 42": 135W with TV on
46": 160W with TV on
<1W in standby mode
Audio power 5W+5W (L/R)
10 W(subwoofer) internal speaker
Component video input (1) Y: 1 V (p-p), 75 ohm, including sync
PR/CR: ±0.35 V (p-p), 75 ohm
PB/CB: ±0.35 V (p-p), 75 ohm
Audio: 500 mV (rms)
Suggested resolutions: 1080i, 720p, 480p, 480i
HDMI input (4) 4 HDMI input jacks
HDCP compliant
E-EDID compliant
Suggested scan rates: 1080p, 1080i, 720p, 480p, 480i
VGA input (1) E-EDID compliant
Suggested scan rates: 640 × 480/60 Hz, 800 × 600/60 Hz,
1024 × 768/60 Hz, 1280 × 1024/60 Hz,
1680 × 1050/60Hz, 1920 × 1080/60 Hz
Audio input: Headphone mini-jack for stereo
Accessories Remote control and batteries (2 AAA)
Component cable with L/R audio cable
Quick Setup Guide
RC Holder
Cleaning Cloth
Dimensions NS-42E570A11:
With stand: 39.6 × 26.5 × 9.1 in.
(1005.5 × 672.2 × 231.4 mm)
Without stand: 39.6 × 24.7 × 1.8 in.
(1005.5 × 627.2 × 46.1 mm)
NS-46E570A11:
With stand: 43.3 × 28.9 × 9.9 in.
(1098.9 × 733.6 × 251.4 mm)
Without stand: 43.3 × 27.1 × 1.8 in.
(1098.9 × 688.6 × 46.1 mm)
Weight NS-42E570A11:
With stand: 38.1lbs. (17.3 kg)
Without stand: 31.9lbs. (14.5 kg)
NS-46E570A11:
With stand: 42.9lbs. (19.5 kg)
Without stand: 35.9lbs. (16.3 kg)
Audyssey Dynamic Volume™
41
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
Two-year limited warranty
US and Canada Markets
Definitions:
Insignia Products (“Insignia”) warrants to you, the original
purchaser of this new Insignia-branded television (“Product”),
that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of two
(2) years from the date of your purchase of the Product
(“Warranty Period”). For this warranty to apply, your Product
must be purchased in the United States or Canada from a Best
Buy or Future Shop authorized dealer of Insignia brand products
only that are packaged with this warranty statement.
How long does the coverage last?
The Warranty Period lasts for 2 years (730 days) from the date
you purchased the Product. Your purchase date is printed on the
receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the
material or workmanship of the Product is determined to be
defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product
with new or rebuilt parts; or (2) replace the Product at no charge
with new or rebuilt comparable products or parts. Products and
parts replaced under this warranty become the property of
Insignia and are not returned to you. If service of Products or
parts are required after the Warranty Period expires, you must
pay all labor and parts charges. This warranty lasts as long as you
own your Insignia Product during the Warranty Period. Warranty
coverage terminates if you sell or otherwise transfer the Product.
How to obtain warranty service?
If you purchased the Product at a Best Buy or Future Shop retail
store location and your television Product has a screen size of
less than 37 inches, please take your original receipt and the
Product to any Best Buy or Future Shop store. Make sure that you
place the Product in its original packaging or packaging that
provides the same amount of protection as the original
packaging. If you purchased the Product from a Best Buy or
Future Shop online web site, mail your original receipt and the
Product to the address listed on the web site. Make sure that you
put the Product in its original packaging or packaging that
provides the same amount of protection as the original
packaging.
To obtain in-home warranty service for a television with a screen
37 inches or larger, in the United States call 1-888-BESTBUY,
Canada call 1-866-BESTBUY for Future Shop call 1-800-663-2275.
Call agents will diagnose and correct the issue over the phone or
will have an Insignia-approved repair technician dispatched to
your home.
Where is the warranty valid?
This warranty is valid only to the original purchaser of the
product in the United States and Canada at Best Buy or Future
Shop branded retail stores or websites.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
• Installation
•Set up adjustments
•Cosmetic damage
• Damage due to acts of God, such as power surges
•Accident(s)
•Misuse
•Abuse
• Negligence
• Commercial purposes/use, including but not limited to use
in a place of business or in communal areas of a multiple
dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modification of any part of the Product, including the
antenna
• Plasma display panel damaged by static (non-moving)
images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia
to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA,
AAA, C etc.)
• Products where the factory applied serial number has been
altered or removed
• Loss or Theft of this product or any part of the product
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT
NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT,
LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES
NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE
PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE
PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY
AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY
FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
For customer service please call 1-877-467-4289
www.insigniaproducts.com
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, Minnesota, U.S.A.
55423-3645
© 2010 BBY Solutions, Inc.
All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc.
Registered in some countries. All other products and brand
names are trademarks of their respective owners.
Mexico Market
{RETAILER SEAL}
PLACE STICKER OF PRODUCT MAKE & MODEL HERE
DATE OF
PURCHASE:____________________________
Definitions:
Insignia Products (“Insignia”) warrants to you, the original
purchaser of this new Insignia-branded television (“Product”),
that the Product shall be free of defects in the original
manufacturer of the material or workmanship for a period of two
(2) years from the date of your purchase of the Product
(“Warranty Period”). For this warranty to apply, your Product
must be purchased in Mexico from a Best Buy authorized dealer
of Insignia brand products only that are packaged with this
warranty statement.
How long does the coverage last?
The Warranty Period lasts for 2 years (730 days) from the date
you purchased the Product. Your purchase date is printed on the
receipt you received with the Product.
What does this warranty cover?
During the Warranty Period, if the original manufacture of the
material or workmanship of the Product is determined to be
defective by an authorized Insignia repair center or store
personnel, Insignia will (at its sole option): (1) repair the Product
with new or rebuilt parts; or (2) replace the Product at no charge
with new or rebuilt comparable products or parts. Products and
parts replaced under this warranty become the property of
Insignia and are not returned to you. and parts charges. This
warranty lasts as long as you own your Insignia Product during
the Warranty Period. Warranty coverage terminates if you sell or
otherwise transfer the Product.
42
NS-42E570A11/NS-46E570A11 Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
How to obtain warranty service?
If you purchased the Product at a Best Buy retail store location
and your television Product has a screen size of less than 37
inches, please take your original receipt and the Product to any
Best store. Make sure that you place the Product in its original
packaging or packaging that provides the same amount of
protection as the original packaging. If you purchased the
Product from a Best Buy a online web site, mail your original
receipt and the Product to the address listed on the web site.
Make sure that you put the Product in its original packaging or
packaging that provides the same amount of protection as the
original packaging.
To obtain in-home warranty service for a television with a screen
37 inches or larger, in Mexico call 01 800-433-5778. Call agents
will diagnose and correct the issue over the phone or will have
an Insignia-approved repair technician dispatched to your home.
Where is the warranty valid?
This warranty is valid only to the original purchaser of the
product in Mexico at a Best Buy branded retail store or website.
What does the warranty not cover?
This warranty does not cover:
• Customer instruction/education
• Installation
•Set up adjustments
•Cosmetic damage
• Damage due to acts of God, such as power surges
•Accident(s)
•Misuse
•Abuse
• Negligence
• Commercial purposes/use, including but not limited to use
in a place of business or in communal areas of a multiple
dwelling condominium or apartment complex, or
otherwise used in a place of other than a private home.
• Modification of any part of the Product, including the
antenna
• Plasma display panel damaged by static (non-moving)
images applied for lengthy periods (burn-in).
• Damage due to incorrect operation or maintenance
• Connection to an incorrect voltage or power supply
• Attempted repair by any person not authorized by Insignia
to service the Product
• Products sold “as is” or “with all faults”
• Consumables, including but not limited to batteries (i.e. AA,
AAA, C etc.)
• Products where the factory applied serial number has been
altered or removed
• Loss or Theft of this product or any part of the product
REPAIR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS
YOUR EXCLUSIVE REMEDY FOR BREACH OF WARRANTY. INSIGNIA
SHALL NOT BE LIABLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES FOR THE BREACH OF ANY EXPRESS
OR IMPLIED WARRANTY ON THIS PRODUCT, INCLUDING, BUT
NOT LIMITED TO, LOST DATA, LOSS OF USE OF YOUR PRODUCT,
LOST BUSINESS OR LOST PROFITS. INSIGNIA PRODUCTS MAKES
NO OTHER EXPRESS WARRANTIES WITH RESPECT TO THE
PRODUCT, ALL EXPRESS AND IMPLIED WARRANTIES FOR THE
PRODUCT, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF AND CONDITIONS OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED IN
DURATION TO THE WARRANTY PERIOD SET FORTH ABOVE AND
NO WARRANTIES, WHETHER EXPRESS OR IMPLIED, WILL APPLY
AFTER THE WARRANTY PERIOD. SOME STATES, PROVINCES AND
JURISDICTIONS DO NOT ALLOW LIMITATIONS ON HOW LONG AN
IMPLIED WARRANTY LASTS, SO THE ABOVE LIMITATION MAY NOT
APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS, WHICH VARY
FROM STATE TO STATE OR PROVINCE TO PROVINCE.
Contact Insignia:
For customer service please call 1-800-926-3000
www.insigniaproducts.com
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, Minnesota, U.S.A.
55423-3645
© 2010 BBY Solutions, Inc.
All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc.
Registered in some countries. All other products and brand
names are trademarks of their respective owners.
Mexico Retailer Address:
Best Buy Mundo E
Boulevard Manuel Avila Camacho 1007
Periferico Norte Santa Monica
Col. San Lucas Tepetlacalco
43
Insignia 42"/46" LED-LCD TV, 120Hz 1080p
www.insigniaproducts.com
TM
If the power cord has been damaged, it should be replaced by the manufacturer, your service
provider or qualified personnel to avoid risks.
Si el cordón de alimentación es dañado, este debe ser remplazado por el fabricante o su agente de servicio o por personal calificado para evitar el riesgo.
www.insigniaproducts.com
US & Canada: 1 (877) 467-4289
Mexico: 01 (800) 926 - 3000
Distributed by Best Buy Purchasing, LLC
7601 Penn Avenue South, Richfield, MN USA 55423-3645
© 2010 BBY Solutions, Inc.
All rights reserved. INSIGNIA is a trademark of BBY Solutions, Inc. Registered in some countries.
All other products and brand names are trademarks of their respective owners.
Best Buy Imports, S. de R.L. de C.V. Av. Santa Fe 485, Segundo Piso, Colonia Cruz Manca, Programa Parcial de Desarrollo Santa Fe, Delegación Cuajimalpa, Distrito
Federal, México 05349 RFC#BBI0802114Q2
Se incluye el manual. Favor de leer este manual antes de usar el producto.
Para el Soporte técnico de Insignia en México, favor llame al: http://www.insigniaproducts.com
ENGLISH
10-0527
