43000 SERIES
RANGE HOOD
READ AND SAVE THESE INSTRUCTIONS
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY
TO PERSONS, OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer. If
you have questions, contact the manufacturer at the address or
telephone number listed in the warranty.
2. Before servicing or cleaning unit, switch power off at service panel
and lock service panel to prevent power from being switched on
accidentally. When the service disconnecting means cannot be
locked, securely fasten a prominent warning device, such as a
tag, to the service panel.
3. Installation work and electrical wiring must be done by a quali-
-
dards.
prevent backdrafting. Follow the heating equipment manufacturer’s
guideline and safety standards such as those published by the
Society for Heating, Refrigeration and Air Conditioning Engineers
5. When cutting or drilling into wall or ceiling, do not damage electri-
cal wiring and other hidden utilities.
6. Ducted fans must always be vented to the outdoors.
7. Do not use this unit with any solid-state speed control device.
9. Use with approved cord-connection kit only.
10.This unit must be grounded.
TO REDUCE THE RISK OF A RANGE TOP GREASE FIRE:
1. Never leave surface units unattended at high settings. Boilovers
cause smoking and greasy spillovers that may ignite. Heat oils
slowly on low or medium settings.
2. Always turn hood ON when cooking at high heat or when cooking
3. Clean ventilating fans frequently. Grease should not be allowed
4. Use proper pan size. Always use cookware appropriate for the
size of the surface element.
TO REDUCE THE RISK OF INJURY TO PERSONS IN THE EVENT
OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOW-
ING:*
metal tray, then turn off the burner. BE CAREFUL TO PREVENT
AND CALL THE FIRE DEPARTMENT.
2. NEVER PICK UP A FLAMING PAN - You may be burned.
3. DO NOT USE WATER, including wet dishcloths or towels - a
know how to operate it.
*Based on “Kitchen Firesafety Tips” published by NFPA.
CAUTION
2. To avoid motor bearing damage and noisy and/or unbalanced
impellers, keep drywall spray, construction dust, etc. off power
unit.
3. For best capture of cooking impurities, your range hood should
be mounted 18-25” above the cooking surface.
and requirements.
IMPORTANT: OBSERVE ALL GOVERNING CODES AND ORDI-
NANCES
grease which rise from the cooking surface. Before you being the
installation be sure that all parts and accessories are removed from
carton. For best results and ease in the installation of this range
hood, read the instructions sheet to become familiar with the step-
by-step installation.
TOOls ANd mATeRIAls
ReqUIRed
❑ Drill, electric or ratchet drive
❑ 1/8" drill bit for drilling pilot holes
❑ 1-1/4" wood bit for drilling electrical wiring access hole
❑ One common head screwdriver for securing hood mounting
screws to the cabinet and hood sheet metal parts
❑ Pliers for opening knockouts
❑ Pencil, rule and level for marking cabinet locations
❑ Saber saw or keyhole saw for cutting the wall or cabinet open-
ings
❑ -
❑ Electrical wiring and supplies of type to comply with local codes
The following materials are required only for installation on recessed
❑
❑
INsTAlleR:
LEAVE THIS MANUAL WITH THE
HOMEOWNER.
HOmeOWNeR:
USE AND CARE INSTRUCTIONS ON PAGE 4.
!
INTENDED FOR DOMESTIC COOKING ONLY
!
To register this
product visit
www.broan.com
