iNSTALLATiON AND SERVICE MUST BE PERFORMED BY A QUAMF[ED iNSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE iNSTRUCTiONS FOR FUTURE REFERENCE.
if the information in this manual is not followed exactly, a fire or explosion may result ]
causing property damage, persona[ iniury or death.
FOR YOUR SAFETY:
-- Do not store or use gasoline or other flammable vapors and liquids in
the vicinity of this or any other appliance.
-- WHAT TO DO mFYOU SMELL GAS:
® Do not try to light any appliance.
* Do not touch any e[ectrka[ switch; do not use any phone in your building.
* mmmediateIy caI[ your gas supplier from a neighbor's phone.
Follow the gas supp[ier's instructions.
if you cannot reach your gas supplier, ca[[ the fire department.
-- installation and service must be performed by a qualified installer, service agency or
the gas supplier.
Gas Cooktop
Dimensions
Gas Cooktop (6.4 cm) Q
Cutout Dimensions , tt
Figure 1
MODEL A WIDTH B.DEPTH C HEIGHT D.BOXWIDTH E.BOXDEPTH
30"GasCooktop 30 (76.2) 21sA(55.2) 4Y4(10.8) 27(68.6) I9 (48.3)
36"GasCooktop 36 (91.4) 21s4(55.2) 4Y4(10.8) 33_/4(84.5) 19(48.3)
MODEL MINIMUM MAXIMUM MINIMUM MAXIMUM COOKTOP
30"GasCooktop 27_/4(69.2) 28h (72.4) 8 (20.3)
36"GasCooktop 33_A(84,5) 34_A(87) 8 (20.3)
All dimensions are stated in inches and (cm),
Dimension H includes a 5" (!27 cm) space underneath the cooktop for connection to gas supply line
NOTE: Wiring diagrams for this cooktop are enclosed in this booklet
Printed in United States
318201460 (0607) Rev E
English o pages I-9
Espar_o[ - paginas 10-18
Wiring Diagram 19-20
