User Manual Kenmore 93013 Range

• Owner's manual - (English, Spanish)

User Guide Kenmore 93013  Range

 Table of Contents

• Appliance Warranty
• Important Safety Instructions
• Product Record/Serial Plate Location
• Before Setting Oven Controls
• Removing, replacing and arranging oven racks
• Before Setting Surface Controls
• Using proper cookware
• Cookware material types
• Home canning
• Setting Surface Controls
• Surface element settings
• Oven Control Features
• Setting Oven Controls
• Setting Clock
• Changing oven temperature display (F° or C°)
• Setting Timer
• Setting Bake
• Broil
• Adjusting Oven Temperature
• Care & Cleaning
• Cleaning recommendation table
• General cleaning
• Surface elements and drip bowls
• Removing and replacing lift-off oven door

To operate the surface element:

1. Place correctly sized cookware on surface element.

2. Push in and turn the surface control knob in either direction to the desired setting (See Fig. 2).

3. When cooking is complete, turn the surface element OFF before removing the cookware. Important notes:

• The surface control knobs do not have to be set exactly on a particular spot. Use the graphics provided as a guide and adjust the control knob as needed. Refer to Fig. 1 for suggested power level settings.

• Start most cooking operations on a higher setting and then turn to a lower setting to finish cooking.

• The ELEMENT ON indicator light(s) will glow when one or more surface elements are turned ON. A quick glance at this indicator light when finished surface cooking is an easy check to be sure all surface controls are turned OFF

To set the clock:

1. Press key pad once (do not hold key pad down).

2. Within 5 seconds, press and hold the or key pad until the correct time of day appears in the display and release key pad.

3. The clock should display the correct time of day

Changing temperature display mode (°F or °C)

The electronic oven control is set to display °F (Fahrenheit) when shipped from the factory. The display may be changed to show either Fahrenheit or Celsius oven temperatures.

To change temperature display mode from °F to °C (Celsius) or from °C to °F (Fahrenheit):

1. Press and hold Broil key pad (for 6-8 seconds) until F or C appears in the display. At this time the display will show the current temperature display mode whether set for F or C.

2. Press either or key pad to toggle between F (Fahrenheit) or C (Celsius) mode choices. C

3. To accept the change, wait until the oven control provides the acceptance beep (See Notes below).

4. The display will return to the time of day with the temperature display mode changed the next time the oven is set for Bake or Broil.
