IMPORTANT : Please read this operation manual before starting operating the equipment.
IMPORTANT : Veuillez lire ce mode d’emploi avant de commencer à utilliser l’appareil.
IMPORTANTE: Lea este manual de operación antes de comenzar a operar el equipo.
OPER ATION MANUAL
MODE D'EMPLOI
MANUAL DE OPERACIÓN
LIQUID CRYSTAL TELEVISION
TÉLÉVISEUR ACL
TELEVISOR CON PANTALLA
DE CRISTAL LÍQUIDO
LC-32LE440U
ENGLISHFRANÇAISESPAÑOL ENGLISHFRANÇAISESPAÑOL
ENGLISHFRANÇAISESPAÑOL
OPERATION MANUAL
IMPORTANT:
To aid reporting in case of loss or theft, please
record the TV's model and serial numbers in the
space provided. The numbers are located at the
rear of the TV.
Model No.:
Serial No.:
LIQUID CRYSTAL TELEVISION
ENGLISH
IMPORTANT INFORMATION
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS PRODUCT TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL.
The lightning flash with arrow-head
symbol,within an equilateral triangle,is
intended to alert the user to the presence
of uninsulated“dangerous voltage“within
the product’s enclosure that may be of
sufficient magnitude to constitute a risk of
electric shock to persons.
The exclamation point within a triangle
presence of important operating and
maintenance(servicing)instruction in the
literature accompanying the product .
ENGLISH
1
LC-32LE440U
IMPORTANT INFORMATION
2
TRADEMARKS
INFORMATION:
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
— Consult the dealer or an experienced radio/TV technician for help.
Note to CATV system installer: This reminder is provided to call the CATV system installer’s
attention to Article 820 of the National Electrical Code that provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be connected to the grounding
system of the building, as close to the point of cable entry as practical.
• HDMI,the HDMI logo,and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC in the United States and other countries.
• Manufactured under license from Dolby Laboratories.Dolby and the double-D
symbol are trademarks of Dolby Laboratories.
WARNING: FCC Regulations state that any unauthorized changes or modifications to this
equipment not expressly approved by the manufacturer could void the user’s authority to operate
this equipment.
CAUTION:
This product satisfies FCC regulations when shielded cables and connectors are used to connect
the unit to other equipment. To prevent electromagnetic interference with electric appliances such
as radios and televisions, use shielded cables and connectors for connections.
CAUTION: TO PREVENT ELECTRIC SHOCK,MATCH WIDE BLADE OF PLUG TO WIDE SLOT,
FULLY INSERT.
DECLARATION OF CONFORMITY:
SHARP LIQUID CRYSTAL TELEVISION, MODEL LC-32LE440U This device complies with Part 15
of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation.RESPONSIBLE PARTY:
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
TEL: 1-800-BE-SHARP
For Business Customers: URL http://www.sharpusa.com
3
IMPORTANT SAFETY INSTRUCTIONS
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Protect the power cord from being walked on or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
10) Only use attachments/accessories specified by the manufacturer.
11) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or
sold with the apparatus. When a cart is used, use caution when moving the cart/apparatus
combination to avoid injury from tip-over.
12) Unplug this apparatus during lightning storms or when unused for long periods of time.
13) Refer all servicing to qualified service personnel. Servicing is required when
the apparatus has been damaged in any way, such as power-supply cord
or plug is damaged, liquid has been spilled or objects have fallen into the
apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
14) WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain
or moisture.
15) Where the MAINS plug or an appliance coupler is used as the disconnect device, the
disconnect device shall remain readily operable.
16) The apparatus shall not be exposed to dripping or splashing and that no objects filled with
liquids, suchas vases, shall be placed on the apparatus.
Additional Safety Information
17) Power Sources—This product should be operated only from the type of power source
indicated on the marking label. If you are not sure of the type of power supply to your
home, consult your product dealer or local power company. For products intended to
operate from battery power, or other sources, refer to the operating instructions.
18) Overloading—Do not overload wall outlets, extension cords, or integral convenience
receptacles as this can result in a risk of fire or electric shock.
19) Object and Liquid Entry—Never push objects of any kind into this product through
openings as they may touch dangerous voltage points or short-out parts that could result
in a fire or electric shock. Never spill liquid of any kind on the product.
20) Damage Requiring Service—Unplug this product from the wall outlet and refer servicing to
qualified service personnel under the following conditions:
a) When the AC cord or plug is damaged,
b) If liquid has been spilled, or objects have fallen into the product,
c) If the product has been exposed to rain or water,
d) If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as an improper
adjustment of other controls may result in damage and will often require extensive work
by a qualified technician to restore the product to its normal operation,
e) If the product has been dropped or damaged in any way, and
f) When the product exhibits a distinct change in performance - this indicates a need for
service.
Thank you for your purchase of the Sharp Liquid Crystal Television. To ensure safety and
many years of trouble-free operation of your product, please read the Important Safety
Instructions carefully before using this product.
DEAR SHARP CUSTOMER
4
IMPORTANT SAFETY INSTRUCTIONS
21) Replacement Parts—When replacement parts are required, be sure the service technician
has used replacement parts specified by the manufacturer or have the same
characteristics as the original part. Unauthorized substitutions may result in fire, electric
shock, or other hazards.
22) Safety Check—Upon completion of any service or repairs to this product, ask the service
technician to perform safety checks to determine that the product is in proper operating
condition.
23) Wall or ceiling mounting—Use a wall mount bracket that has been listed by an
independent laboratory (such as UL, CSA, ETL).
EXAMPLE OF ANTENNA GROUNDING AS PER
NATIONAL ELECTRICAL CODE, ANSI/NFPA 70
ANTENNA
LEAD IN WIRE
GROUND
CLAMP
NEC — NATIONAL ELECTRICAL CODE
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250)
ELECTRIC
SERVICE
EQUIPMENT
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
CAUTION
• These servicing instructions are for use by qualified service personnel only. To reduce the risk of electric
shock do not perform any servicing other than that contained in the operating instructions unless you are
qualified to do so.
• Outdoor Antenna Grounding — If an outside
antenna is connected to the television
equipment, be sure the antenna system is
grounded so as to provide some protection
against voltage surges and built-up static
charges.
Article 810 of the National Electrical Code,
ANSI/NFPA 70, provides information with
regard to proper grounding of the mast
and supporting structure, grounding of the
lead-in wire to an antenna discharge unit,
size of grounding conductors, location
of antenna-discharge unit, connection to
grounding electrodes, and requirements for
the grounding electrode.
• Warning statement indicating that Class I apparatus shall be connected to a mains socket outlet
with a protective earthing connection.
• Statement indicating that when the mains plug or appliance coupler shall remain readily operable.
• Where the MAINS plug or an appliance coupler is used as the disconnect device, the disconnect
device shall remain readily operable.
• Where an all-pole MAINS SWITCH is used as the disconnect device, the location on the
apparatus and the function of the switch shall be described, and the switch shall remain readily
operable.
• Water and Moisture — Do not use this product near water - for example, near a bath tub, wash
bowl, kitchen sink, or laundry tub; in a wet basement; or near a swimming pool; and the like.
• Stand — Do not place the product on an unstable cart, stand, tripod or table. Placing the product
on an unstable base can cause the product to fall, resulting in serious personal injuries as well as
damage to the product. Use only a cart, stand, tripod, bracket or table recommended by the
manufacturer or sold with the product. When mounting the product on a wall, be sure to follow
the manufacturer’s instructions. Use only the mounting hardware recommended by the
manufacturer.
• Selecting the location — Select a place with no direct sunlight and good ventilation.
• Ventilation — The vents and other openings in the cabinet are designed for ventilation. Do not
cover or block these vents and openings since insufficient ventilation can cause overheating and/
or shorten the life of the product. Do not place the product on a bed, sofa, rug or other similar
surface, since they can block ventilation openings. This product is not designed for built-in
installation; do not place the product in an enclosed place such as a bookcase or rack, unless
proper ventilation is provided or the manufacturer’s instructions are followed.
• The Liquid Crystal panel used in this product is made of glass. Therefore, it can break when the
product is dropped or applied with impact. Be careful not to be injured by broken glass pieces
in case the panel breaks.
IMPORTANT SAFETY INSTRUCTIONS
5
• Heat — The product should be situated away from heat sources such as radiators, heat registers,
stoves, or other products (including amplifiers) that produce heat.
• The Liquid Crystal panel is a very high technology product with 2,073,600 pixels (LC-32LE540U),
giving you fine picture details. Occasionally, a few non-active pixels may appear on the screen as
a fixed point of blue, green or red. Please note that this does not affect the performance of your
product.
• Lightning — For added protection for this television equipment during a lightning storm, or when
it is left unattended and unused for long periods of time, unplug it from the wall outlet and
disconnect the antenna. This will prevent damage to the equipment due to lightning and
power-line surges.
• Power Lines — An outside antenna system should not be located in the vicinity of overhead
power lines or other electric light or power circuits, or where it can fall into such power lines or
circuits. When installing an outside antenna system, extreme care should be taken to keep
from touching such power lines or circuits as contact with them might be fatal.
• To prevent fire, never place any type of candle or flames on the top or near the TV set.
• To prevent fire or shock hazard, do not place the AC cord under the TV set or other heavy items.
• Do not display a still picture for a long time, as this could cause an afterimage to remain.
• To prevent fire or shock hazard, do not expose this product to dripping or
splashing.
No objects filled with liquids, such as vases, should be placed on the product.
• Do not insert foreign objects into the product. Inserting objects in the air
vents or other openings may result in fire or electric shock. Exercise special
caution when using the product around children.
Precautions when transporting the TV
• When transporting the TV, never carry it by holding or otherwise putting pressure onto the display.
Be sure to always carry the TV by two people holding it with two hands — one hand on each side
of the TV.
Caring for the Cabinet
• Use a soft cloth (cotton, flannel, etc.) and gently wipe the surface of the cabinet.
• Using a chemical cloth (wet/dry sheet type cloth, etc.) may deform the components of the main
unit cabinet or cause cracking.
• Wiping with a hard cloth or using strong force may scratch the surface of the cabinet.
• If the cabinet is very dirty, wipe with a soft cloth (cotton, flannel, etc.) soaked in neutral detergent
diluted with water and thoroughly wrung out, and then wipe with a soft dry cloth.
• The cabinet is primarily made of plastic. Avoid using benzene, thinner, and other solvents, as
these may deform the cabinet and cause the paint to peel off.
• Do not apply insecticides or other volatile liquids.
Also, do not allow the cabinet to remain in contact with rubber or vinyl products for a long period
of time. Plasticizers inside the plastic may cause the cabinet to deform and cause the paint to
peel off.
Caring for the Liquid Crystal panel
• Turn off the main power and unplug the AC cord from the wall outlet before handling.
• Gently wipe the surface of the display panel with a soft cloth (cotton, flannel, etc.).
To protect the display panel, do not use a dirty cloth, liquid cleaners,
or a chemical cloth (wet/ dry sheet type cloth, etc.). This may damage
the surface of the display panel.
• Wiping with a hard cloth or using strong force may scratch the surface
of the display panel.
• Use a soft damp cloth to gently wipe the display panel when it is really
dirty. (It may scratch the surface of the display panel when wiped strongly.)
• If the display panel is dusty, use an anti-static brush, which is commercially available, to clean it.
• To avoid scratching the frame or screen, please use a soft, lint free cloth for cleaning. Approved
cleaning cloths are available directly from Sharp in single (00Z-LCD-CLOTH) or triple (00Z-LCD-
CLOTH-3) packs.
Call 1-800-BE-SHARP for ordering, or VISIT http://www.sharpusa.com/SharpDirect.
IMPORTANT SAFETY INSTRUCTIONS
CHILD SAFETY
It Makes A Difference How and Where You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product, please keep these safety tips
in mind:
THE ISSUE
The home theater entertainment experience is a growing trend and larger •
flat panel displays are popular purchases. However, flat panel displays are
not always supported on the proper stands or installed according to the
manufacturer’s recommendations.
Flat panel displays that are inappropriately situated on dressers, bookcases, •
shelves, desks, speakers, chests or carts may fall over and cause injury.
THIS MANUFACTURER CARES!
The consumer electronics industry is committed to making home •
entertainment enjoyable and safe.
TUNE INTO SAFETY
One size does NOT fit all. Follow the manufacturer’s recommendations for •
the safe installation and use of your flat panel display.
Carefully read and understand all enclosed instructions for proper use of this •
product.
Don’t allow children to climb on or play with furniture and television sets.•
Don’t place flat panel displays on furniture that can easily be used as steps, •
such as a chest of drawers.
Remember that children can become excited while watching a program, •
especially on a “larger than life” flat panel display. Care should be taken
to place or install the display where it cannot be pushed, pulled over, or
knocked down.
Care should be taken to route all cords and cables connected to the flat•
panel display so that they cannot be pulled or grabbed by curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL MOUNT YOUR FLAT PANEL DISPLAY,
ALWAYS:
Follow all instructions supplied by the display and wall mount manufacturers.•
If you have any doubts about your ability to safely install your flat panel display, contact your retailer •
about professional installation.
Make sure that the wall where you are mounting the display is appropriate. Some wall mounts are not •
designed to be mounted to walls with steel studs or old cinder block construction. If you are unsure,
contact a professional installer.
A minimum of two people are required for installation. Flat panel displays can be heavy.•
Note: CEA is the preeminent trade association promoting growth in
the $161 billion U.S. consumer electronics industry. More than 2,200
companies enjoy the benefits of CEA membership, including legislative
advocacy, market research, technical training and education, industry
promotion and the fostering of business and strategic relationships.
6
QUICK REFERENCE
Supplied Accessories
• Always use the AC cord supplied with the TV.
• The illustrations above are for explanation purposes and may vary slightly from the actual
accessories.
Make sure the following accessories are provided with the product.
CAUTION
• Do not push too hard or put excessive pressure to the stand neck to avoid the damages
when you turn the TV for the most comfortable viewing angle.
• To detach the stand, perform the steps in reverse order.
Remote control unit
( X 1)
Page 11
“AAA” size battery
( X 2)
Page 13
Stand ( X 1)
with Screws
Page 8
Operation manual
( X 1)
x4
Attaching/Detaching the Stand
• Before attaching (or detaching) the stand, unplug the AC cord.
• Before performing work spread cushioning over the base area to lay the TV on. This will prevent it
from being damaged.
CAUTION
• Attach the stand in the correct direction.
• Be sure to follow the instructions. Incorrect installation of the stand may result in the TV
falling over.
1. Put the TV face down on a safe surface that is covered by a soft and smooth cloth.
2. Adjust the TV stand to the bottom of the TV.
3. Fasten the screws by using a cross-head screwdriver (Not supplied).
2
3
7
Quick Installation Tips
4.
Insert the batteries into the remote control
unit. (See page 11.)
QUICK REFERENCE
8
1. Attach your antenna to the back of the
television. (See page 10.)
2. Connect the AC plug for the television into the
AC outlet.
• Place the TV close to the AC outlet, and keep
the power plug within reach.
• TO PREVENT RISK OF ELECTRIC SHOCK,
DO NOT TOUCH UN-INSULATED PARTS
OF ANY CABLES WITH THE AC CORD
CONNECTED.
3.
When turning on the TV for the first time,
press
POWER on the television.
POWER indicator
POWER
• Speakers cannot be detached from the TV.
• The TV angle cannot be adjusted.
30º 30º
30º
30º
17´ (5 m)
Remote control sensor
INPUT
2
Using the Remote Control Unit
QUICK REFERENCE
9
Use the remote control unit by pointing it towards the remote control sensor on the TV. Objects
between the remote control unit and the remote control sensor may prevent proper operation.
IMPORTANT:
If the POWER indicator light on the television still does not turn off, press POWER on the remote control to turn the
power on.
IMPORTANT:
IF THE UNIT DOES NOT POWER ON - UNPLUG THE TELEVISION FROM THE OUTLET AND REPEAT THE
INSTALLATION STEPS.
IF YOU STILL ENCOUNTER NO POWER, PLEASE CONTACT US AT 1-800-BE-SHARP.
■ Cautions regarding the remote control
unit
• Do not expose the remote control unit to
shock. In addition, do not expose the remote
control unit to liquids, and do not place in an
area with high humidity.
• Do not install or place the remote control unit
under direct sunlight. The heat may cause
deformation of the remote control unit.
• The remote control unit may not work
properly if the remote control sensor on the
TV is under direct sunlight or strong lighting.
In such cases, change the angle of the
lighting or the TV, or operate the remote
control unit closer to the remote control
sensor.
Antennas
1. A 75-ohm system is generally a round cable
with F-type connector that can easily be
attached to a terminal without tools
(Commercially available).
2. A 300-ohm system is a flat “twin-lead” cable
that can be attached to a 75-ohm terminal
through a 300/75-ohm adapter (Commercially
available).
Preparation
Connecting Antenna
Connect the antenna cable to the TV using one of the methods in the illustration as •
shown ( , , or ).
F-type connector
300-ohm twin-lead cable (flat)
F-type connector
75-ohm coaxial cable
(round)
75-ohm coaxial cable
300-ohm twin-lead cable
75-ohm coaxial cable (round)
75-ohm coaxial cable
IN OUT
300-ohm
twin-lead cable
VHF
ANTENNA
UHF
ANTENNA
Combiner
(commercially available)
300/75-ohm adapter
(commercially available)
300-ohm twin-lead cable (flat)
75-ohm coaxial cable (round)
Cable TV lead-In
Cable without a CATV converter1
Coaxial cable
(commercially available)
Coaxial cable
(commercially available)
Home Antenna
terminal (75-ohm)
Home Antenna
terminal (75-ohm)
or
or
VHF/UHF antenna2
Combination VHF/UHF antenna3
Separate VHF/UHF antenna4
To TV antenna terminal
1 2 3 4
10
To enjoy a clearer picture, use an outdoor antenna. The following is a brief explanation of the types
of connections that are used for a coaxial cable. If your outdoor antenna uses a 75-ohm coaxial
cable with an F-type connector, plug it into the antenna terminal at the rear of the TV set.
When connecting the RF cable to the TV set, do
not tighten F-type connector with tools. If tools
are used, it may cause damage to your TV set.
(The breaking of internal circuit, etc.)
Installing Batteries in the Remote Control Unit
CAUTION
Improper use of batteries can result in chemical leakage or explosion. Be sure to follow the
instructions below.
• Do not mix batteries of different types. Different types of batteries have different characteristics.
• Do not mix old and new batteries. Mixing old and new batteries can shorten the life of new
batteries or cause chemical leakage in old batteries.
• Remove batteries as soon as they are worn out. Chemicals that leak from batteries come in
contact with skin can cause a rash. If you find any chemical leakage, wipe thoroughly with a cloth.
• The batteries supplied with this product may have a shorter life expectancy due to storage
conditions.
• If you will not be using the remote control unit for an extended period of time, remove batteries
from it.
• The batteries (batteries installed) shall not be exposed to excessive heat such as sunshine, fire or
the like.
1 Open the battery cover.
Place the batteries with their terminals •
corresponding to the (
) and ( )
indications in the battery compartment.
2 Insert two “AAA” size batteries (supplied
with the product).
3 Close the battery cover.
If the remote control fails to operate TV functions, replace the batteries in the remote control unit.
Preparation
11
Contents
Dimensional Drawings
The dimensional drawings for the LCD TV set are shown on the inside back cover.•
IMPORTANT INFORMATION ...................................................................................... 1
TRADEMARKS............................................................................................................. 2
IMPORTANT SAFETY INSTRUCTIONS...................................................................... 3
QUICK REFERENCE.................................................................................................... 7
Supplied Accessories .............................................................................................. 7
Attaching/Detaching the Stand ................................................................................ 7
Quick Installation Tips .............................................................................................. 8
Using the Remote Control Unit ................................................................................ 9
Antennas ............................................................................................................... 10
Connecting Antenna Cable .................................................................................... 10
Installing Batteries in the Remote Control Unit ........................................................ 11
Contents..................................................................................................................... 12
Part Names ................................................................................................................ 13
TV (Front) ............................................................................................................... 13
TV (Side/Rear) ........................................................................................................ 13
Remote Control Unit .............................................................................................. 14
Introduction to Connections ................................................................................... 15
Experiencing HD Images ......................................................................................
.
15
Types of Connection ............................................................................................ 15
.
Displaying an External Equipment Image Display .................................................. 15
Connecting to External Equipment ......................................................................... 16
Connecting a Blu-ray Disc/DVD Player or HD
Cable/Satellite Set-top Box
................................................................................... 16
Connecting a Game Console,VCR,Camcorder
or Cable/Satellite Set-top Box
12
............................................................................... 17
Connecting an Audio Amplifier ............................................................................... 18
Connecting an AV Amplifier ................................................................................... 18
Connecting a PC ................................................................................................... 19
Watching TV............................................................................................................... 20
Turning On/Off the Power ...................................................................................... 20
EZ Setup ............................................................................................................ 20
Direct Button Operation ............................................................................................ 22
On-Screen Display Menu.......................................................................................... 26
Menu Items ............................................................................................................ 26
On-Screen Display Menu Operation ....................................................................... 27
Menu Operation Button ......................................................................................... 28
Connecting a USB Memory Device/USB Hard Drive .............................................. 37
Select the Files to Play Back ................................................................................. 37
Playing Back Files on a USB Memory Device ........................................................ 37
Picture Settings ..................................................................................................... 28
Audio Settings ...................................................................................................... 30
Power Control ..................................................................................................... 30
System Options ................................................................................................... 31
Initial Setup .......................................................................................................... 33
Information ......................................................................................................... 36
Enjoying Photo/Music/Video Playback .................................................................. 37
Appendix .................................................................................................................... 40
Troubleshooting ..................................................................................................... 40
Specifications ........................................................................................................ 41
PC Compatibility Chart .......................................................................................... 42
RS232 Port Specifications ..................................................................................... 43
Calling for Service ..................................................................................................... 45
Legal notices ......................................................................................................... 44
Part Names
TV (Front)
TV (Side/Rear)
*1: See pages 16, 17, 18 and 19 for external equipment connection.
*2: See page 15,20,22and 28 for button operations.
• The illustrations in this operation manual are for explanation purposes and may vary slightly from
the actual operations.
13
POWER indicator
Light sensor
Remote control sensor
*2
POWER
button
MENU
button
INPUT
button
Channel
buttons
(CH
/
)
Volume
buttons
(VOL
k
/
l
)
*1
PC IN
AUDIO
PC/HDMI
INPUT 4
Y/VIDEOPBPR
R-AUDIO-L
ANT./CABLE
INPUT 2
INPUT 3
*1
DIGITAL AUDIO
OUTPUT
INPUT 1
terminal (HDMI)
HEAD PHONE
RS-232C IOIOI
terminal
USB
RS-232C
USB
(DC5V 500mA)
IOIOI
HEAD
INPUT 1
PHONE
DIGITAL
AUDIO OUTPUT
Remote Control Unit
Part Names
14
1
INPUT
3
4
5
6
7
8
9
0
ENT
1
2
DI S P LAY FRE E ZE
FLASHBACK
MUT E
SURRO UND
TV US B
PC
MENU
FAV O RIT E CH
SLEEP CC VIEW MODEAV MODE
AUDIO
VOL CH
+
NRUTERTIXE
LCDTV
GJ221
A B C D
ENTER
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
POWER
• When using the remote control unit, point it at
the TV.
1. INPUT: Select a TV input source.
(See page 22.)
2. 0–9: Set the channel.
3. ENT: Jumps to a channel after selecting with
the 0-9 buttons.
4. FLASHBACK: Press to switch to the
previously tuned channel or external input
mode. Press again to switch back to the
currently tuned channel or external input
mode.
5. AUDIO: Display the MTS/SAP setting menu.
(See page 23.)
6. MUTE: Mute the sound. (See page 22.)
7. CH / : Select the channel. (See page 22.)
8. MENU: Display the menu screen.
9. PC: Direct switch PC source.
10. / / / , ENTER: Select a desired item on
the screen. (See page 28.)
11. RETURN: Return to the previous menu
screen.
12. FAVORITE CH:
Selects preset favorite channels in four different
categories. While watching, you can toggle the
selected channels by pressing A, B, C and D.
The every key of the favorite can select the
many channels.
13. AV MODE: Select an adjusted picture
settings. Standard, Movie,Game, PC,
Dynamic, Dynamic(Fixed),User. (See page 23.)
14. VIEW MODE: Select the Picture Mode.
(See page 25.)
15. : Only for USB.
16. POWER: Switch the power on or enters
standby mode. (See page 20.)
17. • (DOT): (See page 22.)
18. DISPLAY: Display the current channel (or
input source) information on the screen.
19. FREEZE: Set the still image. Press again to
return to normal screen.
20. VOL +/- : Set the volume. (See page 22.)
21. SURROUND: Display the surround setting
menu. (See page 23.)
22. TV: Direct switch TV source.
23. USB: Direct switch USB source.
24. EXIT: Turn off the menu screen.
25. SLEEP: Allows you to set a time when the TV
automatically switches to standby. This display
will disappear after a few seconds, and the
sleep timer automatically starts counting down.
(See page 22.)
26. CC: Display captions during closed-caption
source.(See page 24.)
INPUT
3
4
5
6
7
8
9
0
E N T
1
2
DIS PL AY FRE EZ E
FLASHBACK
MUT E
SU RROUN D
TV USB
PC
ME NU
AUDIO
VOL CH
+
POWER
RETURNEXIT
ENTER
Introduction to Connections
Experiencing HD Images
An HDTV without an HD source is just an ordinary TV.
To enjoy HD images on the TV, you should get HD programming from the following:
• Over-the-air broadcasting via HD quality antenna
• HD cable/satellite subscription
• HD compatible external equipment
Types of Connection
• For information on updating to HD programming, ask your cable/satellite service provider.
15
Displaying an External Equipment Image Display
To view external source images, select the input source by pressing INPUT on the remote control
unit or on the TV.
Image quality differs depending on the terminal used. To enjoy clearer images, check the output
terminals of your external equipment and use its appropriate terminals for higher quality images.
For connecting the TV to external equipment, use commercially available cables.
• The illustrations of the terminals are for explanation purposes and may vary slightly from the actual products.
INPUT1
INPUT2
INPUT3
INPUT4
PC IN
Input Source
HDMI1
HDMI2
HDMI3
COMP/AV
USB
TV
1. Press INPUT.
• The CH list screen displays.
2. Press / to select the input source.
• You can also select the input source by
pressing INPUT. Each time INPUT is
pressed, the input source toggles.
INPUT4TV
INPUT1 INPUT2 INPUT3
• An image from the selected source
automatically displays.
Page 16
Terminal
on the TV
Cable
Terminal on external
equipment
Quality
HDMI-certified cable
DVI-HDMI conversion cable
HD
Quality
Standard
Quality
AUDIO
DVI OUT
Component video cable
Audio cable
Page 16
Page 17
Page 17
INPUT 1, 2, 3
AUDIO
PC/HDMI
INPUT 1, 2, 3
INPUT 4
Y/VIDEOPBPR
R-AUDIO-L
INPUT 4
Y/VIDEOPBPR
R-AUDIO-L
AV cable
INPUT
Ø 3.5 mm stereo minijack cable
You can connect many types of external equipment to your TV. To view external source images,
select the input source from INPUT on the remote control unit or on the TV. (See pages 15 and 22.)
For connecting the TV to external equipment, use commercially available cables.
CAUTION
• To protect equipment, always turn off the TV before connecting any external equipment.
• Please read the relevant operation manual (Blu-ray disc player, etc.) carefully before making connections.
Connecting a Blu-ray Disc/DVD Player or HD Cable/Satellite Set-top Box
When using HDMI cable (INPUT 1, 2, or 3):
The HDMI (High Definition Multimedia Interface) terminal is an audio-video interface that enables a
connection for audio and video signals using a single cable. The HDMI terminal supports
high-resolution video input.
• Blu-ray disc player • DVD player
• HD cable/satellite set-top box
• To enjoy 1080p display capability, connect your external equipment using an HDMI-certified cable or a
component cable and set the equipment to 1080p output.
• Supported Audio format: Linear PCM, sampling rate 32/44.1/48kHz.
When using DVI-HDMI conversion cable (INPUT 1, 2, or 3):
• Blu-ray disc player • DVD player
• HD cable/satellite set-top box
• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in
addition to connecting a DVI-HDMI conversion cable to the INPUT 1,2,3 (HDMI) terminal, connect a
Ø 3.5 mm stereo minijack cable to the AUDIO PC/HDMI terminal.
Connecting to External Equipment
HDMI OUT
HDMI-certified cable
AUDIO DVI OUT
Ø 3.5 mm stereo minijack cable
DVI-HDMI conversion cable
INPUT 2
INPUT 3
INPUT 2
INPUT 3
AUDIO
PC/HDMI
16
When using Component cable (INPUT 4):
• Blu-ray disc player • DVD player
• HD cable/satellite set-top box
• To enjoy 1080p display capability, connect your external equipment using an HDMI-certifi ed cable or a
component cable and set the equipment to 1080p output.
• See page 19 for connecting a Blu-ray disc player, DVD player or an HD cable/satellite set-top box to the HDMI
terminal.
Connecting a Game Console, VCR, Camcorder or Cable/Satellite Set-top Box
When using Composite cable (INPUT 4):
• Game console • VCR
• Camcorder • Cable/Satellite set-top box
Connecting to External Equipment
COMPONENT OUT
Audio cable
Component video cable
AUDIO-L (White)
AUDIO-R (Red)
INPUT 4
Y/VIDEOPBPR
R-AUDIO-L
Y (Green)
P
B
(Blue)
P
R
(Red)
AV cable
VIDEO (Yellow)
AUDIO-L (White)
AUDIO-R (Red)
AV cable
VIDEO (Yellow)
AUDIO-L (White)
AUDIO-R (Red)
INPUT 4
Y/VIDEOPBPR
R-AUDIO-L
INPUT 4
Y/VIDEOPBPR
R-AUDIO-L
17
INPUT 2
INPUT 3
DIGITAL
AUDIO OUTPUT
Connecting an Audio Amplifier
When using coaxial cable:
It is possible to output audio through the DIGITAL AUDIO terminal. PCM audio outputs from the
terminal.
Connecting an AV Amplifier
• If the image is not in sync with the audio, check the settings of the connected surround system.
• Letting the TV output the audio to an AV amplifier:
HDMI OUT
HDMI
IN
HDMI
OUT
HDMI-certified cable
HD Cable/Satellite set-top box
• Digital Audio output is not available when using an HDMI input.
Connecting to External Equipment
DIGITAL AUDIO INPUT
OPTICAL
Optical fiber cable
Connecting a PC
Refer to page 46 for a list of PC signals compatible with the TV.
When using HDMI cable (INPUT 1, 2 or 3):
• The HDMI terminals only support digital signal.
When using DVI-HDMI conversion cable (INPUT 1,2,3):
• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in
addition to connecting a DVI-HDMI conversion cable to the INPUT 1,2,3 (HDMI) terminal, connect
a
Ø 3.5 mm stereo minijack cable
to the AUDIO PC/HDMI terminal.
When using analog RGB cable (PC IN):
• When using an analog RGB cable, input the audio signal to the AUDIO PC/HDMI terminal of PC IN.
22
Connecting to External Equipment
AUDIORGB
Analog RGB cable
(D-sub 15-pin cable or VGA cable)
DVI OUT
AUDIO
DVI-HDMI conversion cable
HDMI OUT
HDMI-certified cable
Ø 3.5 mm stereo minijack cable
INPUT 2
INPUT 3
AUDIO
PC/HDMI
INPUT 2
INPUT 3
Ø 3.5 mm stereo minijack cable
AUDIO
PC/HDMI
PC IN
18
Connecting a PC
Refer to page 42 for a list of PC signals compatible with the TV.
When using HDMI cable (INPUT 1, 2 or 3):
• The HDMI terminals only support digital signal.
When using DVI-HDMI conversion cable (INPUT 1,2,3):
• When using a DVI-HDMI conversion cable, you should make an analog audio connection. In this case, in
addition to connecting a DVI-HDMI conversion cable to the INPUT 1,2,3 (HDMI) terminal, connect
a
Ø 3.5 mm stereo minijack cable
to the AUDIO PC/HDMI terminal.
When using analog RGB cable (PC IN):
• When using an analog RGB cable, input the audio signal to the AUDIO PC/HDMI terminal of PC IN.
Connecting to External Equipment
AUDIORGB
Analog RGB cable
(D-sub 15-pin cable or VGA cable)
DVI OUT
AUDIO
DVI-HDMI conversion cable
HDMI OUT
HDMI-certified cable
Ø 3.5 mm stereo minijack cable
INPUT 2
INPUT 3
AUDIO
PC/HDMI
INPUT 2
INPUT 3
Ø 3.5 mm stereo minijack cable
AUDIO
PC/HDMI
PC IN
19
Turning On/Off the Power
EZ Setup
Watching TV
Press POWER on the TV, or POWER on the remote control
unit to turn the power on.
• POWER indicator: Power on, Green; Power off, red.
Press POWER on the TV, or POWER on the remote control
unit again to turn the power off.
• The TV enters standby and the image on the screen
disappears.
• If you are not going to use this TV for a long period of time, be sure to
remove the AC cord from the AC outlet.
• Small amount of electric power is still consumed even when the TV is
turned off.
• If there is no signal input for 15 minutes, the power will turn to standby
mode automatically.
INPUT
3
1
2
POWER
When you turn on the TV for the first time, the
EZ Setup will guide you through the setup
process. Perform the following steps before
you press POWER on the remote control unit.
1. Insert the batteries into the remote control
unit. (See page 11.)
2. Connect the antenna cable to the TV. (See
page 10.)
3. Plug in the AC cord to the AC outlet. (See
page 8.)
1. EZ Setup
• The EZ Setup screen display at the first
use. Press ENTER to start the EZ setup.
2. Language setting
TV USB
PC
MENU
NRUTERTIXE
ENTER
Thank You for Your Purchase of our SHARP Liquid Crystal Television.
Please press [ENTER] to start the Wizard.
TV
EZ Setup Welcome
Enter
Enter
TV Location
Select "Home" or "Store" for the location where
you plan to install the TV. This product qualifi es
for ENERGY STAR in Home mode default
setting.
3. Location setting
• Press / to select “Home” or “Store”
and press to the next step.
• Select the OSD menu language from
English, Spanish, or French.
• Press / to select the desired
language listed on the screen, and then
press the button to the next step.
Language
TV
EZ Setup
Set the on-screen display language
English
Français
Español
Select Enter Back Exit
Enter Return EXIT
Language
TV EZ Setup
Select where the TV will be placed.
The picture will be optimized for
that location.
Home
Store
Select Enter Back Exit
Enter Return EXIT
TV Location
POWER
20
Watching TV
Home: “Power Saving” is set to "On", and AV MODE
is set to "STANDARD".
Store: “Power Saving” is set to "Off" and AV MODE is
set to "DYNAMIC (Fixed)".
• ENERGY STAR qualification is based on AV MODE
"STANDARD".
4. Air/Cable (Antenna setting)
• Make sure what kind of connection is
made with your TV when selecting “Air”
or “Cable”.
• Press / to select “Air” or “Cable” and
press to the next step.
TV EZ Setup Air/Cable
Selecting Air/Cable channels
Air
Cable
Select Enter Back Exit
Enter Return EXIT
CH Search (Channel search)
Channel auto search makes the TV look for all
channels viewable in the set area.
5. When "Air" or "Cable" is selected
in Antenna setting:
Press / to select "Start", and then
press ENTER.
TV EZ Setup CH Search
Searching receivable channels
Start
Cancel
Select Back ExitEnter
Enter Return EXIT
6. Start channel searching
• Wait until the channel scan to complete.
• If you press EXIT, the process will
return to the previous step.
• If you skip this step, the channel search
can be performed in the Initial Setup Menu.
(See page 34.)
TV EZ Setup CH Search
Searching receivable channels.
Now tunning Channels automatlcally..
Analog: 0
Digital: 0
22%
Cancel
EXIT
7. Completed
After setting complete, the screen will
show "EZ setup Completed",press
ENTER to finish the EZ Setup.The
TV will then switch to the first channel
found.
TV EZ Setup Completed
EZ Setup Completed
Back
Return
Exit
Enter
• Auto programming may take 20+ minutes to
complete. Please wait until you see the Auto
programming complete message.
21
Direct Button Operation
An image from the selected source •
automatically displays.
Each time • INPUT is pressed, the
input source toggles.
If you press ▲ / ▼ to select the •
input source, press ENTER to
confirm your selection.
connection.
MUTE
Mutes the current sound output.
Press MUTE.
Mute can be canceled by using the •
method below.
- Mute will be canceled if you press
VOL + / - or MUTE.
SLEEP
Allows you to set a time when the TV
automatically switches to standby.
Press SLEEP.
The remaining time displays when •
the sleep timer has been set.
Each time you press • SLEEP, the
remaining time switches as shown
below.
Off 30 60 90 120
When set, the time automatically •
starts counting down.
If you want to adjust the sleep •
timer, you can press SLEEP twice
then change the time setting.
Select "Off" by pressing SLEEP to •
cancel the sleep timer.
The TV will enter standby mode (power •
indicator lights red) when the remaining
time reaches zero.
Changing Channels
You can change channels by pressing
CH / or 0-9, or • (DOT).
Examples:
To select a 1 or 2-digit channel number
(e. g., Channel 5):
Press 5 ENT.
To select a 3-digit channel number
(e. g., Channel 115):
Press 1 1 5 ENT.
To select a 4-digit channel number
(e. g., Channel 22.1):
Press 2 2 • (DOT) 1
ENT.
When selecting a 1-digit channel •
number, it is not necessary to press 0
before the number.
Changing Volume
You can change the volume by pressing
VOL / on the TV or on the remote
control unit.
To increase the volume, press •
VOL .
To decrease the volume, press •
VOL .
INPUT
To view external source images, select the
input
source using INPUT on the remote
control unit or INPUT on the TV.
Press
INPUT.
1.
A list of selectable sources •
appears.
Press
INPUT
again to select the input 2.
source.
INPUT
3
4
5
6
7
8
9
0
ENT
1
2
DI SP LA Y FRE E ZE
FLASHBACK
MU TE
SU RR O UN D
TV US B
PC
ME NU
AUDIO
VOL CH
+
POWER
FAV OR IT E CH
SL E EP CC VIEW MODEAV MODE
NRUTERTIXE
LCDTV
GJ221
A B C D
ENTER
• See page 16-19 for external equipment
22
Direct Button Operation
FLASHBACK
Press FLASHBACK to switch to the previously
tuned channel or input.
• Press FLASHBACK again to switch back to the
currently tuned channel or input.
SURROUND
The surround function produces Surround effect
from the speakers. Each time you press
SURROUND, the mode changes between On
and Off.
• ON: Makes it possible to enjoy nature,realistic
surround sound.
• Off: Outputs the normal sound.
• You can have the same settings by choosing
“Surround” on the menu items. (See page 23.)
FREEZE
AV MODE
Allows you to capture and freeze a moving
image that you are watching.
Press FREEZE.
• A moving image is captured.
• Press FREEZE again to cancel the function.
AV MODE gives you several viewing options to
choose from to best match the surrounding
environment of the TV,which can vary due to
factors like room brightness, type of program
watched or the type of image input from external
equipment.
Press AV MODE. Current AV MODE displays.
• Press AV MODE again before the mode
displayed on the screen disappears.
AUDIO
■ MTS/SAP stereo mode
The TV has a feature that allows reception of
sound other than the main audio for the program.
This feature is called Multi-channel Television
Sound (MTS). The TV with MTS can receive mono
sound, stereo sound and Secondary Audio
Programs(SAP). The SAP feature allows a TV
station to broadcast other information, which could
be audio in another language or something
completely different like weather information.
You can enjoy Hi-Fi stereo sound or SAP
broadcasts when available.
• Stereo broadcasts: View programs like live sporting
events, shows and concerts in dynamic stereo sound.
• SAP broadcasts: Receive TV broadcasts in either
MAIN or SAP sound.
MAIN sound: The normal program soundtrack (either in
mono or stereo).
SAP sound: Listen to a second language,supplementary
commentary or other information. (SAP is mono sound.)
If stereo sound is difficult to hear.
• Obtain a clearer sound by manually switching to fixed
mono-sound mode.
You can change MTS as shown below to match
the television broadcast signal.
Press AUDIO to toggle between audio modes.
Examples: when receiving MTS and SAP
MAIN + SAP mode: MAIN SAP
MONO mode: MONO
■ Digital broadcasting audio mode
The types of audio transmitted in a digital
broadcast include SURROUND as well as
MONO and STEREO. In addition, it is possible
for multiple audio tracks to accompany a single
video track.
Press MTS/SAP to toggle between audio
modes.
Example: when receiving Digital
broadcasting
STEREO (Audio1) STEREO (Audio2)
SURROUND (Audio3)
23
• MTS only operates while in TV mode.
Direct Button Operation
Closed Captions (CC)
Your TV is equipped with an internal Closed
Caption decoder. It allows you to view
conversations, narration and sound effects
as subtitles on your TV.
Closed Captions are available on some TV
programs and on some VHS home video tapes
at the discretion of the program provider.
Digital Closed Caption service is a new caption
service available only on digital TV programs
(also at the discretion of the service provider).
It is a more flexible system than the original
Closed Caption system, because it allows for a
variety of caption sizes and font styles. When the
Digital Closed Caption service is in use, it will be
indicated by the appearance of a 3-letter
abbreviation that also indicates the language of
the Digital Closed Captions: ENG (English), SPA
(Spanish), FRA (French) or other language codes.
Not all programs and VHS videotapesoffer closed
captions.
In the Closed Caption system, there can be more
than one caption service provided. Each is
identified by its own number. The “CC1” to “CC4”
services display subtitles of TV programs
superimposed over the program's picture.
In the Closed Caption system, the “TEXT1” to “TEXT4”
services display text that is unrelated to the
program being viewed (e.g., weather or news).
These services are also superimposed over the
program currently being viewed.
1. Press CC.
• This will display the current Closed Caption information.
Press CC to turn the Closed Caption on or off.
• Caption Display will not work when viewing a 480i, 480p,
720p, 1080i or 1080p input via the COMPONENT: Y-PbPr
or HDMI inputs.
• Closed Captions availability and content depends on the
broadcaster. Closed Caption are available when the Closed
Caption icon is displayed on screen.
• Closed Captions and Digital Captions availability and
content depends on the broadcaster. Closed Caption are
available when the Closed Caption icon is displayed on
screen.
Example:
Analog:
CC1 CC2 CC3 CC4 TT1
-- TT4 TT3 TT2
Digital:
CC1 CC2 CC3 CC4 TT1 TT2 TT3 TT4
-- CS6 CS5 CS4 CS3 CS2 CS1
24
1 Press VIEW MODE.
2 Press VIEW MODE or / while the View Mode menu is displayed to select a desired item on
the menu.
For 4:3 programs
Example: Screen size images
For HD programs
For PC input mode
Example: Screen size images
• The View Mode menu displays.
• The menu lists the View Mode options selectable for the type of video signal currently being
received.
• When using Dot by Dot or Full Screen, it is possible to see noise or bars around different outer
portions of the screen, Please change view mode to correct this.
• Connect the PC before making adjustments.
• Selectable screen size may vary with input signal type.
StretchZoomS.Stretch (Smart stretch)
Suitable for viewing
conventional 4:3 programs in
their normal format.
Suitable for stretching 4:3
programs to fi ll the screen.
Suitable for viewing wide-
screen 2.35:1 anamorphic
DVDs in full screen.
This mode is useful for 1.78:1
DVDs. When viewing 1.85:1
DVDs, stretch mode will still show
very thin black bands at the top
and bottom of the screen.
Normal
Input signal Normal Cinema
4:3
Keeps the original
aspect ratio in a full
screen display.
For viewing
widescreen
programs. The top
and bottom of the
image is cropped.
An image fully fi lls the
screen.
Detects the resolution
of the signal and
displays an image with
the same number of
pixels on the screen.
Input signal
16:9 An image fully fi lls the
screen.
Detects the resolution
of the signal and
displays an image with
the same number of
pixels on the screen.
Full Screen Dot by Dot
Dot by Dot
Normal
VIEW MODE
You can select the screen size.
Direct Button Operation
• You can sequentially select a View Mode that has its own aspect ratio.
Stretch: Suitable for viewing wide-screen 1.78:1 aspect ratio program, stretch mode will still show
very thin black bands at the top and bottom of the screen.
Dot by Dot (1080i/p only): Detects the resolution of the signal and displays an image with the
same number of pixels on the screen.
Full Screen(720p only): You can select “Full Screen” only when receiving a 720p signal.
S.Stretch (Smart stretch): Suitable for stretching 4:3 programs to fi ll the screen.
Zoom: Suitable for viewing wide-screen 2.35:1 aspect-ratio programs in full screen.
AUDIO
25
On-Screen Display Menu
Menu Items
System Options
View Option ............................. Pages 30-33
View Mode ............................ Page 31
Freeze ................................... Page 31
Change Audio ....................... Page 31
Change CC ........................... Page 32
Input Terminal Setting
Audio Setup .......................... Page 32
PC input ................................ Page 32
Audio Select .......................... Page 32
HDMI Setup .......................... Page 33
Speaker
Caption Setup..................................Page 33
Caption Style ........................ Page 33
Font Size ............................... Page 33
Font Color .......................... Page 33
Font Opacity ......................... Page 33
Background Color ................. Page 33
Background Opacity ............. Page 33
Window Color ....................... Page 33
Window Opacity .................... Page 33
Initial Setup
EZ Setup ......................................... Page 33
Broadcasting Setup
CH Setup .............................. Page 34
Favorite CH ........................... Page 34
Language ........................................ Page 34
Individual Setup
Secret No. ............................ Page 34
Parental CTRL ..................... Pages 34
Reset .............................................. Page 34
Information
Identifi cation .................................... Page 36
Picture Settings
Backlight ......................................... Page 28
Contrast .......................................... Page 28
Brightness ....................................... Page 28
Color ............................................... Page 28
Tint.................................................. Page 28
Sharpness....................................... Page 28
AV MODE (Changing Pic.Quality) ..... Page 29
OPC................................................ Page 29
Advanced ........................................ Page 29
Color Temp. ......................... Page 29
Active Contrast ..................... Page 29
DI Film Mode ......................... Page 29
Digital Noise Reduction ......... Page 29
Audio Settings
Surround ......................................... Page 30
Treble .............................................. Page 30
Balance ........................................... Page 30
Bass ................................................ Page 30
• Some menu items may not be displayed depending on the selected input source.
26
......................... Page 34
............................ Pages 34
Power Control
Power Saving .................................. Page 30
No Signal Off ................................... Page 30
................................ Page 33
...............Pages 31-33
On-Screen Display Menu
On-Screen Display Menu Operation
1. Press MENU to display the MENU screen.
2.
Press / to select the desired menu.
Press / to select a specific
adjustment item, and then press ENTER.
• Additional related adjustment items may be
displayed. Press / to select the desired
item.
Adjust the item while referring to the
guide display.
• Operations vary depending on the function
or item. Refer to the guide display
corresponding to the menu setting screen
for button operations.
3. Press MENU to exit.
Example
Menu
Information
Initial
Setup
System
Options
Settings
AV MODE
[STANDARD]
STANDARD
OPC
[On]
Contrast
Backlight
[ 51]
[ 82]
Brightness
[ 50]
Color
[ 50]
Tint
[ 0]
Sharpness
[ 10]
Advanced
Reset
Picture Settings
1
2
3
• Menu options differ in the selected input modes, but
the operating procedures are the same.
• The screens in the operation manual are for
explanation purposes (some are enlarged, others
cropped) and may vary slightly from the actual
screens.
• The order of explanations for each menu item in
the following pages is not necessarily in accordance
with the alignment of the items on the screen.
Guide display
• This indicates the buttons that can be operated
on the displayed screen. The guide display varies
depending on the menu setting screen.
•
The operations for some selected items may be
displayed in the operational guide bar at the
bottom of the screen.
Item displayed in gray
Example
1
2
3
4
5
Menu
Information
Initial
Setup
System
Options
Settings
AV MODE
[STANDARD]
STANDARD
[ON]
OPC
Contrast
Brightness
[ 50]
Color
[ 50]
Tint
[ 0]
Advanced
Reset
Picture Settings
[ 82]
[ 51]
• This indicates that the item cannot be selected.
There are various reasons why the items cannot
be selected, but the main reasons are as follows:
—Nothing is connected to the selected input
terminal.
—
The function is not compatible with the current
input signal.
Item in brackets
• This indicates the current setting for the item.
Item displayed in white
• This indicates that the item can be selected.
Item displayed in blue
• This indicates the item currently selected.
•
Press ENTER to go to the adjustment screen for
this item.
27
Sharpness
[ 10]
Select Menu Select
RETURN
Exit
ENTER
Enter
Adjust Select
RETURN
Back
ENTER
Enter
Adjust Select
RETURN
Back
ENTER
Enter
Backlight
On-Screen Display Menu
Menu Operation Button
TV US B
PC
MENU
NRUTERTIXE
ENTER
MENU :
Press to open or close the menu
screen.
Press to select a desired item on
the screen or adjust a selected
item.
ENTER: Press to go to the next step or
complete the setting.
RETURN: Press to return to the previous
step.
Using the control panel of the main unit
You can also operate the menu with the control
panel of the main unit.
Button operations on the control panel
correspond to the ones on the remote control
as shown below.
/▼/▲
◄/►:
Using the remote control
Use the following buttons on the remote control
to operate the menu.
MENU on the remote
control or EXIT on the
remote control while OSD
menu is on.
MENU:
INPUT:
ENTER on the remote
control.
CH
/
:
Cursor / on the remote
control.
VOL :
Cursor / on the remote
control.
/
Example
Menu
Settings
AV MODE
[STANDARD]
STANDARD
OPC
[On]
Picture Settings
1. Press MENU to display the MENU screen,
and then press ◄/► to select "Picture
Settings" and press ENTER or ▼ to enter it.
2. Press ▲/▼ to select a specific adjustment
item and press ENTER or ► to enter the
setting.
3. Press ◄/► to adjust the setting.
4. Press MENU to exit.
• Backlight control is disabled when OPC is “On”.
Selected item button button
Backlight The screen
brightens
The screen
dims
Contrast For less
contrast
For more
contrast
Brightness For less
brightness
For more
brightness
Color For less color
intensity
For more color
intensity
Tint Skin tones
become reddish
Skin tones
become greenish
Sharpness For less
sharpness
For more
sharpness
Picture Settings
Adjusts the picture to your preference with the
following picture settings.
Contrast
[ 50]
Brightness
[ 50]
Color
[ 50]
Tint
[ 0]
Sharpness
[ 10]
Advanced
Reset
[ 80]
TV US B
PC
MENU
FAV O RIT E CH
SLEEP CC VIEW MODEAV MODE
NRUTERTIXE
LCDTV
GJ221
A B C D
ENTER
28
Backlight
On-Screen Display Menu
AV MODE (Changing Pic.Quality)
OPC
Advanced
Color Temp. (Color Temperature)
The audio and video settings can be changed
to suit the program or input content being
watched.
Select from the following AV modes.
USER/STANDARD/MOVIE/GAME/PC/
DYNAMIC/DYNAMIC (Fixed)
VGAActive Contrast
VGADl Film Mode
VGADigital Noise Reduction
• The selectable items vary depending on the input
source.
• You can select AV MODE by pressing AV MODE
on the remote control unit. See page 23 for details
of AV MODE settings.
Automatically adjusts the brightness of the
screen.
Off: The brightness is fixed at the value set in
"Backlight".
On: Automatically adjusts.
• When set to "On", the Optical Picture Control (OPC)
senses the surrounding light and automatically
adjusts the backlight brightness. Make sure nothing
obstructs the OPC sensor, which could affect its
ability to sense surrounding light.
This TV provides various advanced functions
for optimizing the picture quality.
• For resetting all adjustment items to the factory
preset values, press / to select "Reset", and
then press ENTER.
• For resetting all adjustment items to the factory
preset values, press / to select "Reset", and
then press ENTER.
For a better white balance, use color
temperature correction.
Warm:
White with reddish tone
Standard:
Cool:
White with bluish tone
User:
White balance can be adjusted manually through
the R/G/B Gain between a maximum of 255 and a
minimum of 0 for each color temperature.
Automatically adjusts the image contrast
according to the scene.
On: Automatically adjusts the image
contrast.
Off: No adjustment.
Automatically detects a film-based source
(originally encoded at 24 frames/second),
analyzes it then recreates each still film frame
for high-definition picture quality.
Auto: Detects, analyzes, converts film
source.
Off: Normal viewing mode.
• “DI Film Mode" does not function depending on
input signal type.
• “Auto" does not function when channel display
shows an input signal resolution of 480p, 720p, or
1080p.
• “DI Film Mode" is not available during PC format
input.
Produces a clearer video image.
Auto: Automatically adjusts the level of
noise reduction.
High/Middle/Low: Select a desired level
for viewing a clearer video image.
Off: No adjustment.
• "Digital Noise Reduction" is not available when PC
format is being input.
29
On-Screen Display Menu
Audio Settings
You can adjust the sound quality to your
preference with the following settings.
Example
1. Press MENU to display the MENU screen,
and then press / to select "Audio
Settings".
2. Press / to select a specific adjustment
item.
• Select "Treble", "Bass" or "Balance" and
then press ENTER to set each item.
3. Press / (or / ) to select the desired
setting, and then press ENTER.
4. Press MENU to exit.
• For resetting Audio adjustment items to the factory
preset values, press / to select "Reset", press
ENTER, press / to select "Yes", and then press
ENTER.
Menu
Audio
Settings
Bass
[ 50]
Treble
[ 50]
Balance
[ 0]
Surround
[Off]
Reset
Audio Settings
TV US B
PC
MENU
RETURNEXIT
ENTER
The surround function produces Surround
effect from the speakers.
On: Makes it possible to enjoy natural,
realistic surround sound.
Off: Outputs the normal sound.
Selected item button button
Treble For weaker
treble
Bass For weaker
bass
For stronger
treble
For stronger
bass
Balance Decrease audio
from the right
speaker
Decrease audio
from the left
speaker
Surround
Power control setting allows you to save energy.
Power
Control
Menu
No Signal Off
Power Saving
[On]
[Enable]
Power Control
Example
1. Press MENU to display the MENU screen,
and then press / to select "Power
Control".
2. Press / to select a specific adjustment
item, and then press / to select the desired
setting.
3. Press MENU to exit.
This function allows you to set the Power
Saving level in order to decrease the power
consumption and increase the backlight
lifespan.
On: Optimizes power reduction based upon
video content.
Off: This function does not work.
• "Power Saving" does not function when you set AV
MODE to DYNAMIC (Fixed)".
• You cannot select a different Power Saving item for
each AV MODE.
When "Power Saving" is set, the "OPC" settings for
all AV Modes will automatically change.
—"DYNAMIC (Fixed)" will remain set to "Off".
Power Control
Power Saving
This function allows the TV to automatically shut the
power down when there is no signal received.
Enable: The power will automatically shut down if
there is no signal for 15 minutes.
Disable: This function does not work.
No Signal Off
TV US B
PC
MENU
RETURNEXIT
ENTER
• For some discs, setup may be required on your
DVD/BD player. In this case, please refer to the
operation manual of your DVD/BD player.
30
[STANDARD]
On-Screen Display Menu
View Option
View Mode
Freeze
Change Audio
These functions are useful for adjusting the
audio and video settings. The View Option
functions can be operated with the remote
control unit.
This function changes the screen size.
Select "View Option" on the menu to display
the View Mode menu screen.
The View Mode menu varies depending on the
input source.
• You can select View Mode by pressing VIEW
MODE on the remote control unit.
— See page 25 for adjusting the video being input from
a TV, other audiovisual equipment, USB-Video.
Allows you to capture and freeze a moving
image that you are watching.
• You can select Freeze by pressing FREEZE on the
remote control unit. See page 23 for details of
Freeze function.
Menu
View Option
System Options
Caption Setup
Input Terminal Setting
System
Options
1. Press MENU to display the MENU screen,
and then press / to select "System
Options".
2. Press / to select a specific adjustment
item and then press ENTER.
3. Press / (or / ) to select the desired
setting, and then press ENTER.
4. Press MENU to exit.
System Options
Example
The TV has a feature that allows reception of
sound other than the main audio for the
program. This feature is called Multi-channel
Television Sound (MTS). The TV with MTS can
receive mono sound, stereo sound
and
Secondary Audio Programs (SAP). The SAP
feature allows a TV station to broadcast other
information, which could be audio in another
language or something completely different like
weather information.
Allows you to change the audio when multiple
audio is available for the program you are
watching
.
You can enjoy Hi-Fi stereo sound or SAP
broadcasts where available.
• Stereo broadcasts: View programs like live
sporting events, shows and concerts in dynamic
stereo sound.
• SAP broadcasts: Receive TV broadcasts in either
MAIN or SAP sound.
MAIN sound: The normal program soundtrack
(either in mono or stereo).
SAP sound: Listen to a second language,
supplementary commentary or other information.
(SAP is mono sound.)
If stereo sound is difficult to hear.
• Obtain a clearer sound by manually switching to
fixed mono-sound mode.
You can change MTS as shown below to match the
television broadcast signal.
Press ENTER to toggle between audio modes.
Examples: when receiving MTS and SAP
STEREO mode: STEREO MONO
STEREO + SAP mode: ST(SAP) SAP(ST) MONO
MAIN + SAP mode: MAIN SAP
MONO mode: MONO
Digital broadcasting audio mode
The types of audio transmitted in a digital broadcast include
SURROUND as well as MONO and STEREO.In addition,it is
possible for multiple audio tracks to accompany a single
video track.
Press ENTER to toggle between audio modes.
Example: when receiving Digital broadcasting
STEREO (Audio 1) STEREO (Audio 2)
SURROUND (Audio 3)
• MTS only operates while in TV mode.
TV US B
PC
ME NU
FAV ORITE CH
S L E E P CC VIEW MODE AV MODE
NRUTERTIXE
LCDTV
GJ221
A B C D
ENTER
31
On-Screen Display Menu
PC Input
Audio Select
Auto Sync. (for Analog PC Input Mode Only)
Allows you to change the Closed Caption
display.Select “Change CC” on the menu to
display the Closed Caption information.
You can output digital audio to an AV amplifi er
or similar device whose DIGITAL AUDIO INPUT
terminal is connected to the DIGITAL AUDIO
OUTPUT terminal on the TV. Please select an
audio output format compatible with the audio
format of the program you are watching and
the equipment connected.
PCM: The optical output terminal outputs
audio signal in PCM form. If your digital
audio system does not support Dolby
Digital, select "PCM".
Dolby Digital: The optical output terminal
outputs audio signal in Dolby Digital form. It
reproduces sound from surround program
of digital.
Off: Disables digital audio output.
Change CC
Audio Setup
Input Terminal Setting
The Auto Sync. is only available when then
input source is PC and your TV is receiving a
computer signal. Select “Auto Sync.” For
adjusting the settings automatically.
• Be sure to connect the PC to the TV and switch it
on before starting "Auto Sync.".
V-Pos.: Centers the image by moving it up
or down.
Clock: Adjust when the image flickers with
vertical stripes.
Phase: Adjust when characters have low
contrast or when the image flickers.
This function sets the terminal to output the
computer audio.
The adjustment items vary depending on the
input source. Select the input source
corresponding to the terminal connected to the
PC and then adjust the desired item.
• The default cursor position may not be in the center,
because the screen position variable ranges may be
asymmetrical.
• The screen position variable ranges depend on the
View Mode or the signal type. The ranges can be
seen on the position-setting screen.
• You can change Closed Caption by pressing CC on
the remote control unit.See page 24 for details of
Closed Caption function.
32
PC IN
Video: Select this when the TV and PC are
connected using an analog RGB cable and
the audio is not input.
Video+Audio: Select this when the TV and
PC are connected using an analog RGB
cable and the audio is input via a Ø 3.5 mm
stereo minijack.
HDMI IN
Auto: Audio Selected automatic,the default
setting is "Auto".
HDMI(Digital): Select this when the TV and
PC are connected using an HDMI-certified
cable and audio is input via the same cable.
HDMI+Analog: Select this when the TV and
PC are connected using a DVI-HDMI
conversion cable and the audio is input via a
Ø 3.5 mm stereo minijack.
• When "Audio Select" is set to "HDMI(Digital)", sound
will not be produced if you use only an
HDMI-certified cable to connect HDMI-compatible
equipment. To produce sound, you should make an
analog audio connection.
• If you want to connect HDMI-compatible equipment
using only an HDMI-certifi ed cable, set "Audio
Select" to "HDMI(Digital)".
Fine Sync.
Ordinarily you can easily adjust the picture as
necessary to change image position using
"Auto Sync.". In some cases, however, manual
adjustment is needed to optimize the image.
H-Pos.: Centers the image by moving it to
the left or right.
On-Screen Display Menu
HDMI Setup
Speaker
Choose to turn on or off the TV internal speaker.
The audio output signals will not be turned off
enen though the TV speaker is off.The default
setting is On.
HDMI Setup only shows and is avavilable when
HDMI device is connected.Select from Auto,
Graphic , or Video.
• HDMI mode is only workable for HDMI Video&
Progressive timing as followed:1920 x 1080p,
1280 x720p,720 x480p,720 x576p.
Initial Setup
Example
You can run EZ Setup again, even after setting
up the preset channels.
Language: Select from among 3 languages
(English, French and Spanish).
TV Location: Select "Home" or "Store" for the
location where you plan to install the TV. This
product qualifi es for ENERGY STAR in Home
mode default setting.
Home: “Power Saving” is set to "ON", and AV MODE is
set to "STANDARD".
Store: “Power Saving” is set to "Off" and AV MODE is set
to "DYNAMIC (Fixed)".
Air/Cable: Make sure what kind of connection is
made with your TV when selecting "Air" or "Cable".
CH Search: Channel auto search makes the TV
look for all channels viewable in the set area.
• If "Cable" is selected for Antenna setting, scrambled
channels are removed after the Channel search has
been completed.
Completed: The settings confirmation screen is
displayed. Confirm the information displayed on
the screen.
1. Press MENU to display the MENU screen,
and then press / to select "Initial Setup".
2. Press / to select a specific adjustment
item, and then press ENTER.
• When you select "Individual Setup",you
can enter the 4-digit secret number here.
See page 34 for setting a secret number.
3. Press / (or / ) to select the desired
setting, and then press ENTER.
4. Press MENU to exit.
•
See EZ Setup on pages 20 to 21 for setting each
item.
• If no channel is found, confirm the type of
connectionmade with your TV and try "EZ Setup"
again.
Menu
EZ Setup
Language
Broadcasting Setup
Individual Setup
Reset
Initial Setup
Initial
Setup
[English]
TV US B
PC
MENU
RETURNEXIT
ENTER
EZ Setup
33
Caption Setup
This function allows you to adjust the closed
caption screen appearance to suit your
preference. You can adjust 8 items:
• Caption Style: Set to As Default or Custom
mode. If Custom mode is selected, user can modify
the detail styles described below. The setting result
will be shown immediately on the bottom of the
submenu OSD.
Note: This feature is only available in Digital TV
(ATSC) mode.
• Caption Size: Selects this option to choose a
caption display size according to your own
preference. Select “Small”, “Standard”, or “Large”.
• Foreground Color: Choose the caption display
text color.
• Foreground Opacity: Select the text opacity.
• Background Color: Choose one of the background
color.
• Background Opacity: Choose one of the
background opacity options.
• Window Color: Choose one of the display windows
color.
• Window Opacity: Select one of the display windows
opacity options.
Auto: The HDMI input timing is set to Video mode or
Graphic mode automatically
Graphic: HDMI input timing set to Graphic mode(PC).
The image is full scan
Video: HDMI input timing set to Video mode .The
image is over scan.
On-Screen Display Menu
Reset
Individual Setup
Secret No.
Parental CTRL (Parental Control Setting)
Status
If Initial Installation does not memorize all the
channels in your region, follow the instructions
below to manually memorize the channels.
Air/Cable: Make sure what kind of
connection is made with your TV when
selecting "Air" or "Cable".
CH Search: Channel auto search makes
the TV look for all channels viewable in the
set area.
CH Memory: You can select the channels
to skip in each ANALOG (Air), ANALOG
(Cable), DIGITAL (Air) and DIGITAL (Cable).
• While watching,you can toggle the selected
channels by pressing the A,B,C, and D button on
the remote control.
You can also select a language from the EZ
Setup menu. Select from among 3 languages:
English, French and Spanish.
This function allows you to program 4 favorite
channels, in 4 different categories. By setting
the favorite channels in advance, you can select
your favorite channels easily.
To register your favorite channel:
1.
Press MENU on the remote control and select
“Initial Setup”/“Broadcasting Setup”/
“Favorite CH”.
2. Press / to select the category that you want to
store your favorite channel.
3. Press / to select your desired channel and
press ENTER button to confirm.
To delete your favorite channel
1.
Press MENU on the remote control and select
“Initial Setup”/“Broadcasting Setup”/
“Favorite CH”.
2. Press / to select “All data clear” and press
ENTER to start clearing all favorite channel data.
Broadcasting Setup
Language
CH Setup
Favorite CH (Favorite Channel Setting)
If complex adjustments are made and the
settings cannot be restored to normal, you can
reset the settings to the factory preset values.
Before entering the Individual Setup,user has to
key in the Secret No. first.Enter a 4-digit Secret
No. with the number buttons on the remote
control.The default Secret No. is 0000.
• The Channel Setup settings will not be changed.
• The Language settings will not be changed.
• The Secret number settings will not be changed.
• The TV Location settings will not be changed.
Allows you to use a secret number to protect
certain settings from being accidentally
changed.
New Secret No. :
Enter a 4-digit Secret No. with the number
buttons on the remote control to change you
secret No..
Confirm Secret No.:
Enter you new 4-digit Secret No. again to
confirm.
• As a precautionary measure, make a note of your
secret number and keep it in a familiar place.
Used to enable or disable the parental control
function. This function will not be selectable
from the menu if you do not fi rst confi gure your
secret number.
YES: Enables Parental CTRL.
NO: Disables Parental CTRL.
34
•
See EZ Setup on pages 20 to 21 for setting each
item.
• If no channel is found, confi rm the type of
connection made with your TV and try channel
search again.
• If you press the Enter key after CH search finish,
CH search is re-start.
On-Screen Display Menu
V-Chip
V-CHIP is an electronic filtering device built into
your TV. This tool gives parents a great degree
of control over broadcasts accessed by their
children. It allows parents to select programs
judged suitable for child viewing while blocking
ones judged not suitable. It does so
automatically once you activate the V-CHIP
feature in your TV. "V-Chip" and "Status" will
not be selectable from the menu if you do not
first confi gure your secret number.
• The U.S. has two rating systems for viewing content:
TV Parental Guidelines and movie ratings.
• The TV Parental Guidelines work in conjunction with
the V-CHIP to help parents screen out inappropriate
television shows from their children.
• Movie ratings are used for original movies rated by
the Motion Picture Association of America (MPAA)
as watched on cable TV and not edited for
television. The V-CHIP can also be set to block
MPAA-rated movies.
• The setting automatically enters "Block" for any
ratings below your selection.
• If Status is not set to "On", the confi guration settings
will not work.
MPAA (Voluntary movie rating system)
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
PG-13
R
NC-17
X
NONE
PG
G
• Voluntary movie rating system only uses an
age-based rating.
Press / to adjust the item to your desired
position." " indicates the item is blocked.
Press MENU to exit.
G: General audiences. All ages admitted.
PG: Parental guidance suggested. Some material may
not be suitable for children.
PG-13: Parents strongly cautioned. Some material
may be inappropriate for children under 13.
R: Restricted. Under 17 requires accompanying parent
or adult guardian (age varies in some jurisdictions).
NC-17: No one 17 and under admitted.
X: X is an older rating that is unifi ed with NC-17 but
may be encoded in the data of older movies.
TV Parental Guidelines
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
TV-G
TV-PG
TV-14
TV-MA
NONE
TV-Y7
TV-Y
L
S
V
FV
D
Example
MPAA
TV Guidelines
Can. English Ratings
Can. French Ratings
TV-G
TV-PG
TV-14
TV-MA
NONE
TV-Y7
TV-Y
L
S
V
FV
D
When setting an individual content-based rating
item:
1. Press or ENTER to access blocked
content items from the currently selected
age-based rating item.
2. Press / to select an individual item, and
then press ENTER to unblock it (" " is
removed). Repeat the same steps for the
other items.
3. Press or RETURN to register after all
individual content rating items are set.
Content
FV: Fantasy violence.
V: Violence.
S: Sexual situation.
L: Adult language.
D: Sexually suggestive dialog.
Rating
Content
FV V S L
D
Suggested
age
TV-Y
TV-Y7
TV-G
TV-PG
TV-14
TV-MA
Press / to adjust the item to your desired
position." " indicates the item is blocked.
Press MENU to exit.
Suggested age
TV-Y: All children.
TV-Y7: Directed to older children.
TV-G: General audience.
TV-PG: Parental Guidance suggested.
TV-14: Parents strongly cautioned.
TV-MA: Mature audience only.
35
On-Screen Display Menu
: The content rating can be set, but this
rating is not normally broadcast by TV stations.
: Content rating can be set.
Canadian Rating Systems (Canadian English
ratings and Canadian French ratings)
• The TV rating systems in Canada are based on the
Canadian Radio-Television and Telecommunications
Commission (CRTC) policy on violence in television
programming.
• While violence is the most important content
element to be rated, the structure developed takes
into consideration other program content like
language, nudity, sexuality and mature themes.
• When setting the V-CHIP on the Canadian system
you can choose either the Canadian English ratings
or the Canadian French ratings.
Canadian English Ratings
Example
MPAA
TV Guidelines
Can. French Ratings
E
C
C8+
G
PG
14+
18+
NONE
Can. English Ratings
Press / to adjust the item to your desired
position. " " indicates the item is blocked.
Press MENU to exit.
E: Exempt: Includes news, sports, documentaries and
other information programming; talk shows, music
videos, and variety programming.
C: Children: Intended for younger children under the
age of 8 years. Pays careful attention to themes that
could threaten their sense of security and well-being.
C8+: Children over 8 years old: Contains no portrayal
of violence as the preferred, acceptable, or only way
to resolve confl ict; nor encourage children to imitate
dangerous acts which they may see on the screen.
G: General: Considered acceptable for all age groups.
Appropriate viewing for the entire family, contains
very little violence, physical, verbal or emotional.
PG: Parental Guidance: Intended for a general
audience, but may not be suitable for younger
children (under the age of 8) because it could
contain controversial themes or issues.
14+: Over 14 years: Could contain themes where
violence is one of the dominant elements of the
storyline, but it must be integral to the development of
plot or character. Language usage could be profane
and nudity present within the context of the theme.
18+: Adults: Intended for viewers 18 years and older and
might contain depictions of violence, which while
related to the development of plot, character or
themes, are intended for adult viewing. Could contain
graphic language and portrayals of sex and nudity.
Reactivating the temporarily released
V-CHIP BLOCK
You can reactivate the temporarily released
V-CHIP BLOCK as shown below.
• Select "Status" setting from the Parental CTRL menu to
reactivate BLOCK. (See page 34.)
• Select "V-Chip" setting ("MPAA", "TV Guidelines", "Can.
English Ratings" or "Can. French Ratings") from the
Parental CTRL to reactivate BLOCK. (See pages 35 to 36.)
• Switch off the TV power.
• Performing any of the three above will activate the
V-CHIP BLOCK.
1. Press MENU to display the MENU screen, and
then press / to select "Information".
2. Press / to select a specifi c adjustment item,
and then press ENTER.
3. Press / (or / ) to select the desired
setting, and then press ENTER.
4. Press MENU to exit.
Press / to adjust the item to your desired
position. " " indicates the item is blocked. Press
MENU to exit.
E: Exempt programming.
G: General: All ages and children, contains minimal
direct violence, but may be integrated into the plot
in a humorous or unrealistic manner.
8ans+: General but inadvisable for young children:
May be viewed by a wide public audience, but could
contain scenes disturbing to children under 8 who
cannot distinguish between imaginary and real
situations. Recommended for viewing with parent.
13ans+: Over 13 years: Could contain scenes of
frequent violent scenes and therefore recommended
for viewing with parent.
16ans+: Over 16 years: Could contain frequent violent
scenes and intense violence.
18ans+: Over 18 years: Only for adult viewing. Could
contain frequent violent scenes and extreme
violence.
How to temporarily release the V-CHIP
BLOCK
When the V-CHIP BLOCK is working and
censors a broadcast, "V-CHIP HAS BEEN
ACTIVATED." displays.
1. Press ENTER while the V-CHIP is working, and
then the secret number setting menu displays.
2. Input the 4-digit secret number by using 0–9.
At this time V-CHIP BLOCK temporarily releases.
Information
Example
Menu
Identification
Information
Information
The current version of the TV software is displayed.
TV US B
PC
MENU
RETURNEXIT
ENTER
Canadian French Ratings
Example
MPAA
TV Guidelines
Can. French Ratings
Can. English Ratings
8ans+
13ans+
16ans+
18ans+
NONE
G
E
Identification
36
37
Enjoying Photo/Music/Video Playback
You can connect the TV to a USB memory
device, USB hard drive to enjoy viewing
pictures, listening to music, and watching
videos.
Connecting a USB Memory Device/
USB Hard Drive
• Depending on the USB memory device/USB hard
drive, the TV may not be able to recognize the
recorded data.
• It may take time to read the recorded data if the
USB memory device/USB hard drive contains
many fi les or folders.
• Use only alphanumeric characters for naming files.
• File names over 80 characters (may vary depending
on character set) may not be displayed.
Insert the USB memory device with recorded
photos, music or videos into the USB terminal
on the TV.
• When connecting a USB hard drive, be sure to use
a hard drive with an AC adapter.
• Do not remove a USB memory device or memory
card from the TV while transferring files, using the
slide show function, or switching screens, or
before you exit "USB" from the INPUT list.
• Do not insert and remove a USB memory device/
USB hard drive to and from the TV repeatedly.
• When using a card reader, be sure to insert
Memory first before using the card reader.
• USB input cannot be selected when displaying the
browser. Close the browser first.
CAUTION
• Do not use a USB extension cable when
connecting a USB memory device to the USB
terminal on the TV.
• Using a USB extension cable with the USB
memory device may prevent the TV from
performing correctly.
2. Press / to select "Photo", "Music" or
"Video", and then press ENTER.
Music
Video
Example
3. Press / to select the desired folder,
and then press ENTER.
• You cannot switch the input mode if a USB memory
device is not connected.
• 16 is the maximum number of USB drives that can
be displayed.
• "VIEW MODE" is fixed during the Photo or Music
mode. During "Video mode", is depending on the type
of video signal currently being received.(see page 25)
• The key guide display disappears automatically after
a set time. To display the key guide display again,
press DISPLAY.
INPUT1
INPUT2
INPUT3
INPUT4
TV
PC IN
Input Source
HDMI1
HDMI2
HDMI3
COMP/AV
USB
Playing Back Files on a USB
Memory Device
1. Press INPUT to select USB from the input
list or press USB direct button to enter it.
Select the Files to Play Back
Photo Mode
Viewing Thumbnails
USB MediaPhoto 01/01\Photo
Example
Select Enter
Enter
c d
c d
Exit
Exit
Buttons for thumbnails operations
Buttons Description
Select a desired item.
EXIT
Return to the previous process.
Menu
Sub Menu
ENTER
When selecting a folder icon: Enter this directory.
▲/▼/
▲
▲
/
When selecting a photo thumbnail: Slide show.
Enjoying Photo/Music/Video Playback
Press MENU to display the sub-menu. You can
browse the files by the following options.
• Sort
• Media Type
• Thumbnail size
• When there are invalid photo files, the X mark will be display
for the file.
• You can see the file name, shooting date, file size and pixel
size of the selected photo in the top-left corner of the screen
(shooting date is only available in the EXIF file format).
The photo selected on the thumbnail selection
screen by pressing ENTER.
Press MENU to display the sub-menu. You can
select the following options to display the
photos.
• Pause
• Repeat
• Shuffle
• Duration
• Effect
• Show Info
Slide Show
Buttons for slide show operation
• The key guide display disappears automatically after a set time.
To display the key guide display again, press DISPLAY.
Example
Example
Photo 1x
None IMG_9690.jpg
Short 1/29
Menu
Menu
Repeat
A
Duration
B
Effect
C
Shuffle
D
The photo in slide show by pressing
Buttons for viewing Individual Photos
operation
Photo 1x single
None G%25C3%2592TIC-DESCAN5ANT.jpg
Short 5/29
Menu
Menu
Repeat
A
Rotate
B
Zoom
C
Shuffle
D
Viewing Individual Photos
Buttons Description
EXIT
Return to the thumbnail selection screen
B(green) Rotate the photo by 90 degrees to the left
C(blue) Zoom photo
A(red)
Repeat one / Repeat all
D(yellow)
Go to the next/previous photo
Play the photo in random order
/
• The key guide display disappears automatically after a
set time. To display the key guide display again, press
DISPLAY.
• Rotating photos only applies to the temporarily selected
item and this setting is not saved.
Buttons Description
Select a desired item.
EXIT
Return to the previous process.
Menu
Sub Menu
ENTER
▲/▼/
▲
▲
/
Music Mode
USB Media01/01\Music Music
Example
Buttons for music mode
2011-05-27 001001 1.mp3 2.mp3 3.mp3 4.mp3003
5.mp3 6.mp3 7.mp3
Select Enter
Enter
c d
c d
Exit
Exit
Music 00:00:03 00:04:49
2.mp3
3/8
Menu
Menu
Enter
Enter
Repeat
A
Shuffle
B
When selecting a folder icon: Enter this directory.
When selecting a music file: Play music.
Example
Slider show
DISPLAY Display the information
Menu Sub Menu
Press MENU to display the sub-menu. You
can select the following options to display the
photos.
• Play
• Repeat
• Shuffle
• Rotate
• Zoom
• Show Info
Press MENU to display the sub-menu. You
can browse the flies by the following options.
• Sort
• Media Type
• Thumbnail size
38
Buttons Description
EXIT
Return to the thumbnail selection screen
B(green) Select slider show interval
C(blue) Select slide show effect
A(red)
Repeat one / Repeat all
D(yellow)
Go to the next/previous photo
Play the photo in random order
/
Viewing individual photo
DISPLAY Display the information
Menu Sub Menu
Enjoying Photo/Music/Video Playback
39
Press MENU to display the sub-menu. You can
select the following options to play the musics.
• Pause
• Repeat
• Shuffle on
• Show Info
• Hide Spectrum
• Lyric Options
Video Mode
Press MENU to display the sub-menu. You
can browse the files by the following options.
• Sort
• Media Type
• Thumbnail size
USB Device Compatibility
Example
USB MediaVideo 01/01\
Select Enter
Enter
c d
c d
Exit
Exit
menu2 Microsoft GIF... images_169 Araxis Merge v... Music Photo _Epic_puti..
Buttons for Video mode
Vedio 1x 1/1
Menu
Menu
Repeat
A
Repeat AB
D
OK. You know, most of the collection here was put together during the Ching dynasty.
So, what did you think?
I was impressed with the landscape paintings, and all the jade carvings.
That jadecabbage just can't be beat!
Some of the bronze pieces go back to the 17th century B.C., but the collection itself was
set up by the first emperor of the Sung dynasty over a thousand years ago.
That's the same style roof as on the Chiang Kai-shek Memorial and the
Concert Hall, right? It seems like I've seen it before.
OK. You know, most of the collection here was put together during the Ching dynasty.
So, what did you think?
I was impressed with the landscape paintings, and all the jade carvings.
That jadecabbage just can't be beat!
Some of the bronze pieces go back to the 17th century B.C., but the collection itself was
set up by the first emperor of the Sung dynasty over a thousand years ago.
That's the same style roof as on the Chiang Kai-shek Memorial and the
Concert Hall, right? It seems like I've seen it before.
1/1
00:00:08 00:19:23
_ _Epic-Putin paws women voters_-1
Buttons Description
Select a desired item.
EXIT
Return to the previous process.
Menu
Sub Menu
ENTER
When selecting a folder icon: Enter this directory.
▲/▼/
▲
▲
/
When selecting a video file: Play video.
Example
USB devic USB Memory, USB card reader (Mass
Storage class), USB hard drive
File syste FAT/FAT32/NTFS (USB hard drive only)
Photo fi le
format
JPEG(.jpg .jpeg) Progressive JPEG
(.jpeg .jpg) BMP(.bmp) PNG(.png)
Music fi le
format
MP3 (.mp3)
Bitrate: 32k, 40k, 48k, 56k, 64k, 80k,
96k, 112k, 128k, 160k, 192k, 224k,
256k, 320kbps
Sampling frequency: 32k, 44.1k, 48kHz
Video fi le format
File
extension
Container Video Audio
.avi AVI
XviD
H.264
MPEG4
Motion Jpeg
MP3
AC3
LPCM
ADPCM
MP3
AC3
LPCM
ADPCM
MP3
AC3
LPCM
ADPCM
.mkv MKV
.asf
.wmv
ASF
.mp4
.mov
.3gp
MP4
(SMP4)
MP3
AAC/
HEAAC
AC3
LDCM
AAC/HEAAC
MPEG
.mpg
.mpeg
PS
MPEG2
MPEG1
MPEG2 MPEG1
XviD
H.264
XviD
H.264
MPEG4
MPEG2
XviD
H.264
MPEG4
• Operation using USB hubs is not guaranteed.
• Some video fi le formats may not be played depending
on the fi le.
• Some images may not be displayed in the appropriate
aspect ratio depending on the fi le format.
Press MENU to display the sub-menu. You
can follow the options to play the videos.
• Pause
• Repeat
• Program
• Show Info
• AV Mode
• Title
• Edition
• Chapter
• View Mode
Backward
B
Forward
C
Buttons for playing music
Buttons Description
EXIT
Return to the thumbnail selection screen
B(green) Play the music in random order.
Go to the next/previous photo.
Forward/Backward.
A(red)
Repeat one./ Repeat all.
/
/
Play/Pause.
DISPLAY Display the information.
Menu Sub Menu
/
D(yellow)
Buttons Description
EXIT
Return to the thumbnail selection screen.
Repeat AB.Select the part you want to play
tepeatedly.
A(red)
Repeat one./Repeat all.
B(green)
Backward.
C(blue)
Forward.
Buttons for Video mode
Forward/Backward.
Go to the next/previous video.
Play/Pause/Stop.
DISPLAY Display the information.
Menu Sub Menu.
/
/
/ /
▲
Troubleshooting
Appendix
noituloS elbissoPmelborP
No power
Check if you pressed POWER on the remote control unit.
press POWER on the TV.
Is the AC cord disconnected? (See page 8.)
Unit cannot be
operated.
External influences such as lightning, static electricity, may
cause improper operation. In this case, operate the unit after
first turning off the power of the TV or unplugging the AC cord
and re-plugging it after 1 or 2 minutes.
Remote control unit
does not operate.
Are batteries inserted with polarity ( , ) aligned?
(See page 11.)
Are batteries worn out? (Replace with new batteries.)
Are you using it under strong or fluorescent lighting?
Is a fluorescent light illuminated near the remote control
sensor?
Picture is cut off/with
sidebar screen.
Are screen mode adjustments such as picture size made
Strange color,
light color, or color
misalignment
Is the room too bright? The picture may look dark in a room
that is too bright.
Power is suddenly
turned off.
The unit’s internal temperature has increased. Remove any
objects blocking vent.
No picture
No sound
Have you pressed MUTE on the remote control unit?
The TV sometimes
makes a cracking
sound.
This is not a malfunction. This happens when the cabinet
slightly expands and contracts according to change in
temperature. This does not affect the TV’s performance.
Has the power been turned on? (See page 20.)
correctly? (See page 25.)
Adjust the picture tone. (See page 28.)
Is the sleep timer set? (See page 22.)
Is connection to other components correct? (See page 15.)
Is the volume too low? (See page 22.)
(See page 22.)
Is the correct input selected? (See page 22.)
(See page 20.) If the indicator on the TV is still red,
40
CLEARING THE MASTER PASSWORD
If you forgot the password number, reset the secret number by following the procedures
below:
Press1. MENU
5. Select “Secret No.”
As a precautionary measure, make a note of your secret number above, cut it from this •
manual, and keep it in a safe place.
Select2. “Initial Setup”,press “ENTER”
Select
3. “Individual Setup”,press “ENTER”
4. Press number 7071
6. Enter new password
Specifications
Appendix
41
• As part of policy of continuous improvement, SHARP reserves the right to make design and
specification changes for product improvement without prior notice. The performance specification
figures indicated are nominal values of production units. There may be some deviations from these
values in individual units.
Model:LC-32LE440UItem
LCD
panel
32” Class (31.5” Diagonal)Size
Resolution 1,049,088 pixels (1366 x 768)
TV
Function
TV-standard (CCIR) American TV Standard ATSC/NTSC System
Receiving
Channel
VHF/UHF VHF 2-13ch, UHF 14-69ch
CATV 1-135ch (non-scrambled channel only)
Digital Terrestrial
Broadcast (8VSB)
2-69ch
Digital cable
(64/256 QAM)
*1
1-135ch (non-scrambled channel only)
Audio multiplex BTSC System
5 W x 2Audio out
Terminals
Side
USB 1 Photo/Music/Video mode, Software update
Headphone
INPUT 4
RS-232C 9-pin D-sub male connector
Rear
Component / Composite in
PC IN
AUDIO PC/HDMI
Audio in (Ø 3.5 mm jack)
ANT/CABLE
75 Ω Unbalance, F Type x 1 for Analog (VHF/UHF/CATV)
DIGITAL AUDIO OUTPUT
Optical Digital audio output x 1 (PCM/Dolby Digital)
English/French/SpanishOSD language
AC 120V~60HzPower Requirement
75W (0.7W Standby with AC 120V)Power Consumption
Weight
TV + stand 19.4 lbs./8.8 kg
TV only 17.9 lbs./8.1 kg
Dimension
(W x H x D)
*2
TV + stand 30
13
/
32
x 21
5
/
64
x 7
49
/
64
inch
TV only 30
13
/
32
x 19 x 1
47
/
64
37
/
64
inch
Operating temperature +32°F to +104°F (0°C to +40°C)
INPUT 1 HDMI in with HDCP, Audio in (Ø 3.5 mm stereo jack)
INPUT 2 HDMI in with HDCP, Audio in (Ø 3.5 mm stereo jack)
INPUT 3 HDMI in with HDCP, Audio in (Ø 3.5 mm stereo jack)
Headphone out
ANALOG RGB (PC) in (15-pin mini D-sub female connector),
Audio in (Ø 3.5 mm stereo jack)
*1
Emergency alert messages via Cable are unreceivable.
*2
The dimensional drawings are shown on the inside back cover.
Cautions regarding use in high and low temperature environments
When the unit is used in a low temperature space (e.g. room, office), the picture
may leave trails or appear slightly delayed. This is not a malfunction, and the unit will
recover when the temperature returns to normal.
Do not leave the unit in a hot or cold location. Also, do not leave the unit in a location
exposed to direct sunlight or near a heater, as this may cause the cabinet to deform
and the Liquid Crystal panel to malfunction.
Storage temperature: -4°F to +140°F (-20°C to +60°C)
PC Compatibility Chart
It is necessary to set the PC correctly to display XGA and WXGA signal.
PC Resolution
Horizontal
Frequency
Vertical
Frequency
VESA Standard
PC
VGA
720 x 400 31.46 kHz 70.08 Hz —
640 x 480
31.47 kHz 59.94 Hz O
37.50 kHz 75.00 Hz O
SVGA 800 x 600
37.88 kHz 60.32 Hz O
48.08 kHz 72.19 Hz O
46.88 kHz 75.00 Hz O
XGA 1024 x 768
48.36 kHz 60.00 Hz O
56.48 kHz 70.07 Hz O
60.02 kHz 75.03 Hz O
WXGA 1366 x 768 47.71 kHz 59.79 Hz O
Appendix
42
Appendix
RS232 Port Specifications
PC control of the TV
• Attach an RS-232C cable cross-type (commercially
available) to the supplied Din/D-Sub RS-232C for the
connections.
This operation system should be used by a person who is
accustomed to using computers.
Communication conditions
Set the RS-232C communication settings on the PC to
match the TV's communication conditions.
The TV's communication settings are as follows:
•
Communication procedure
Send the control commands from the PC via the RS-
232C connector.
The TV operates according to the received command
and sends a response message to the PC.
Do not send multiple commands at the same time.
Wait until the PC receives the OK response before
sending the next command.
Parameter
Input the parameter values, aligning left, and fi ll with
blank(s) for the remainder. (Be sure that 4 values are
input for the parameter.)
When the input parameter is not within an adjustable
range, “ERR” returns. (Refer to “Response code format”.)
Any numerical value can replace the “x” on the table.
3 0
0 0 0 9
0
? ? ? ?
?
When “?” is input for some
commands, the
present setting
value responds.
Command format
Eight ASCII codes
+
CR
Command 4-digits
Parameter 4-digits
Return code
C1 C2 C3 C4 P1 P2 P3 P4
Command 4-digits: Command. The text of four characters.
Parameter 4-digits: Parameter 0–9, x, blank, ?
Baud rate: 9,600 bps
Data length: 8 bits
Parity bit: None
Stop bit: 1 bit
Flow control: None
Response code format
Normal response
Return code (0DH)
Return code (0DH)
Problem response (communication
error or incorrect command)
O K
E R R
Command table
Commands not indicated here are not guaranteed to operate.
CONTROL ITEM COMMAND PARAMETER
CONTROL CONTENTS
POWER ON COMMAND SETTING
POWER SETTING
The Power On command rejected.
It input-switches by the toggle. (It is the same as an input change key)
It input-switches to TV. (A channel remains as it is. (Last memory))
It input-switches to INPUT1~INPUT6.
Although it can choose now, it is toggle operation in inside.
The screen position variable ranges depend on the View Mode or the
signal type. The ranges can be seen on the position-setting screen.
(Toggle)
Input terminal number (1–6)
An input change is included if it is not TV display.
In Air, 2–69ch is effective.
In Cable, 1–135ch is effective.
Toggle operation of a closed caption.
0: (Toggle), 1: On, 2: Off
0: Off, 1: OFF TIMER – 30 MIN., 2: OFF TIMER – 60 MIN.,
3: OFF TIMER – 90 MIN., 4: OFF TIMER – 120 MIN.
The channel number of TV
The channel number of TV +1
The channel number of TV
–1
(Toggle)
(1–135)
R S P W
I T G D
I T V D
I A V D
INPUT SELECTION A
AV MODE SELECTION
VOLUME
POSITION
VIEW MODE
SURROUND
SLEEP TIMER
CHANNEL
CC
DIRECT
(ANALOG)
(DIGITAL)
CH UP
CH DOWN
CHANNEL
H-POSITION
V-POSITION
CLOCK
PHASE
A V M D
V O L M
H P O S
V P O S
C L C K
P H S E
A C S U
O F T M
D C C H
C H U P
C H D W
C L C P
W I D E
0
x
0
*
*
*
*
*
*
*
*
*
*
x
x
x
*
*
*
*
*
*
*
*
*
*
*
*
DIGITAL Air (Two-Part numbers, 2-digit plus 2-digit)(0100-9999)
(1-999)
(0-999)
(0-9999)
(0-6383)
DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit)
DIGITAL Cable (Two-Part numbers, 3-digit plus 3-digit)
Front half of DIGITAL CABLE CHANNEL NO. (Designate major channel)
Rear half of DIGITAL CABLE CHANNEL NO. (Designate minor channel)
DIRECT
CHANNEL
D A 2 P * * * *
D C 2 U * * * _
D C 2 L * * * _
DIGITAL Cable (One-Part numbers, 5-digit, less than 10,000)
D C 1 0 * * * *
DIGITAL Cable (One-Part numbers, 5-digit, more than 10,000)
D C 1 1 * * * *
(Toggle)
AUDIO SELECTION
A C H A x _ _ _
0: (Toggle), 1: On, 2: Off
MUTE
M U T E * _ _
_ Off
The Power On command accepted.1 _ _ _ On
The Power On Command must be waited until system is completely Power Off (LED power
indicator turns to be Red)
1 _ _ _ Power On
It shifts to standby.P O W R 0 _ _ _ Power Off
TV
INPUT1-6
If an underbar (_) appears in the parameter column, enter a space.
•
If an asterisk (*) appears, enter a value in the range indicated in brackets under CONTROL
•
CONTENTS.
Any numerical value can replace the “x” on the table.
•
<
<
If it is not TV display, it will input-switch to TV. (same function as CH )
0: Although it can choose now, it is toggle operation in avilable items
5: Available in [AV] 720p and [PC] except 1280 x720 ,1920 x1080 timing
6: Available in [AV] 1080i and 1080p timing and [PC] except 1600 x1200,1280 x1024(LC-32LE440U)
and 1400 x 1050(LC-32LE440U)
2,3,4: Only available when [AV] signals is being input
1: Available in [AV] SD timing and [PC] except some timing (*1)
7: Only available in [PC] except some timing (*2)
(*1) 1360 x 768,1366 x 768,1280 x1024,1400 x1050,1600 x1200,1920 x1080
(*2) 1360 x 768,1366 x 768,1280 x720,1920 x1080
Only PC mode. (0–40,menu display range+/-20)
Only PC mode. (0–180,menu display range+/-90)
Only PC mode. (0–40,menu display range+/20)
Only PC mode. (0–100,menu disolay range+/-50)
Volume (0–100)
0:(Toggle) 1:Normal 2:S.Stretch 3:Stretch 4:Zoom
5:Full Screen 6:Dot by Dot 7:Cinema)
0:(TOGGLE) ,1:STANDARD,2:MOVIE,3:GAME,4:PC,
5:DYNAMIC,6:DYNAMIC(FIXED),7:USER
TOGGLE
43
If it is not TV display, it will input-switch to TV. (same function as CH )
44
Legal notices
■
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of this product is subject
to the following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply within the limits for a class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the •
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.•
■
FCC warning
Changes or modifications not expressly approved by the party responsible for compliance
with the FCC Rules could void the user’s authority to operate this equipment.
■
Cables
Connections to this device must be made with shielded cables with metallic RF/EMI
connector hoods to maintain compliance with FCC Rules and Regulations.
■
Canadian notice
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
“Standard Television Receiving Apparatus-Appareil de reception télévision ordinaire,
Canada BETS-7 / NTMR-7”.
Appendix
45
Calling for Service
CONSUMER LIMITED WARRANTY
SHARP ELECTRONICS CORPORATION warrants to the first consumer purchaser that this Sharp brand Liquid Crystal Display product (the
“Product”), when shipped in its original container, will be free from defective workmanship and materials, and agrees that it will, at its option, either
repair the defect or replace the defective Product or part thereof with a new or remanufactured equivalent at no charge to the purchaser for parts or
labor for the period(s) set forth below.
This warranty does not apply to any appearance items of the Product or if the serial number or model number affixed to the Product has been
removed, defaced, changed, altered or tampered with. This warranty does not cover installation or signal reception problems. This limited warranty
will not apply if the Product has been or is being used in a commercial setting or application; this warranty is meant solely for the non-commercial,
household use of the Product by consumers in their home or residence. If you intend to or already use this Product for commercial purposes or in a
commercial setting, there are warranties available to cover your use of this Product, the terms of which may vary. Please contact 1-800-BE-SHARP
for further information.
In order to enforce your rights under this limited warranty, you should follow the steps set forth below. You must be able to provide proof of
purchase to the servicer, which proof must include the date of purchase.
To the extent permitted by applicable state law, the warranties set forth are in lieu of, and exclusive of, all other warranties, express or implied.
Specifically ALL OTHER WARRANTIES OTHER THAN THOSE SET FORTH ABOVE ARE EXCLUDED, ALL EXPRESS AND IMPLIED WARRANTIES
INCLUDING THE WARRANTIES OF MERCHANTABILITY, FITNESS FOR USE, AND FITNESS FOR A PARTICULAR PURPOSE ARE SPECIFICALLY
EXCLUDED. IF, UNDER APPLICABLE STATE LAW, IMPLIED WARRANTIES MAY NOT VALIDLY BE DISCLAIMED OR EXCLUDED, THE DURATION
OF SUCH IMPLIED WARRANTIES IS LIMITED TO THE PERIOD(S) FROM THE DATE OF PURCHASE SET FORTH BELOW. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS WHICH VARY FROM STATE TO STATE.
The warranties given herein shall be the sole and exclusive warranties granted by Sharp and shall be the sole and exclusive remedy available to the
purchaser and only for the time periods set forth herein. No other representations or promises made by anyone are permitted. Correction of
defects, in the manner and for the period of time described herein, shall constitute complete fulfillment of all liabilities and responsibilities of Sharp
to the purchaser with respect to the Product, and shall constitute full satisfaction of all claims, whether based on contract, negligence, strict liability
or otherwise. Sharp does not warrant nor shall Sharp be liable, or in any way responsible, for Products which have been subject to abuse
(including, but not limited to, improper voltage), accident, misuse, negligence, lack of reasonable care, alteration, modification, tampering, misuse,
improper operation or maintenance or any damages or defects in the Product which were caused by repairs or attempted repairs performed by
anyone other than a Sharp authorized servicer. Nor shall Sharp be liable or in any way responsible for any incidental or consequential economic or
property damage. Some states do not allow limits on warranties or on remedies for breach in certain transactions; in such states, the limits herein
may not apply.
THIS LIMITED WARRANTY IS VALID ONLY IN THE FIFTY (50) UNITED STATES, THE DISTRICT OF COLUMBIA. AND PUERTO RICO
TO OBTAIN PRODUCT INFORMATION OR PURCHASE ACCESSORIES, CALL 1-800-BE-SHARP OR VISIT www.SharpUSA.com
Model Specific Section
What to do to Obtain Service:
Additional Exclusions from
Warranty Period for this Product:
Your Product Model Number & Description:
Warranty Coverage (if any):
LC-32LE440U LED Color Television (Be sure to have this information
and Proof of Purchase available when you need service for your Product.)
One (1) year parts and labor from date of purchase.
Image Retention resulting from a fixed image being displayed for long periods of
time is not covered by this Limited Warranty (see Operation Manual on how to
prevent this).
Service is provided by a Sharp Authorized Service Center in the United States. To
find the location of the nearest Sharp Authorized Service Center, call Sharp toll
free at 1-800-BE-SHARP. Sharp will provide instructions on service options
available for your Product.
If it is deemed the Product is to be shipped for servicing, be sure it is insured and
packaged securely. Please use two persons to carry the Product, transport it in
original packaging or packaging that provides comparable protection of the
Product, and ensure that the Product is covered to avoid scratches and damage.
Sharp shall not be responsible for lost, stolen or misdirected mail or for damage to
the product incurred during shipping.
For Products that are deemed in home service, a servicer will come to your
location. If necessary, the servicer may remove the unit for repair at the service
facility and return it once completed. In home service is not available in all areas
and Sharp may, at our option, elect to provide transportation of the Product to and
from an Authorized Service Center in those areas.
For location of the nearest Sharp Authorized Service, or to obtain product literature, accessories,
supplies, or customer assistance, please call 1-800-BE-SHARP.
Calling for Service
LIMITED WARRANTY
Unit: inch (mm)
Unité: pouce (mm)
Unidad: pulgada (mm)
Dimensional Drawings
*1
Active area/Área activa/Zone active
*2
Thinnest part/Parte más delgada/Partie la plus mince
30
13
/
32
(772)
27
21
/
32
(702.40)
*1
15
41
/
64
(397.00)
*1
19
37
/
64
(497)
21
5
/
64
(535)
11
55
/
64
(301)
3
25
/
64
(86) 1
47
/
64
(44)
*2
7
49
/
64
(197)
7
7
/
8
(200)
3
15
/
16
(100)
1
31
/
32
(50)
9
1
/
16
(230)
5
9
32
(134)
SHARP ELECTRONICS CORPORATION
Sharp Plaza, Mahwah, New Jersey 07495-1163
SHARP CORPORATION
Printed in China
Imprimé au Chine
Impreso en China
084-0001-7274(YT)
