www.lg.com
OWNER’S MANUAL
LED LCD MONITOR
LED LCD MONITOR MODELS
Please read this manual carefully before operating your set and
retain it for future reference.
ENGLISH
E1960S
E2060S
E2260S
E2360S
E1960T
E2060T
E2260T
E2360T
E2260V
E2360V
1
Important Precautions
This unit has been engineered and manufactured to ensure your personal safety,
however improper use may result in potential electrical shock or fire hazards. In
order to allow the proper operation of all safeguards incorporated in this display,
observe the following basic rules for its installation, use, and servicing.
On Safety
Use only the power cord supplied with the unit. In case you use another power
cord, make sure that it is certified by the applicable national standards if not being
provided by the supplier. If the power cable is faulty in any way, please contact the
manufacturer or the nearest authorized repair service provider for a replacement.
The appliance coupler is used as the disconnect device.
Please make sure the device is installed near the wall outlet to which it is
connected and that the outlet is easily accessible.
Operate the display only from a power source indicated in the specifications of this
manual or listed on the display. If you are not sure what type of power supply you
have in your home, consult with your dealer.
Overloaded AC outlets and extension cords are dangerous. So are frayed power
cords and broken plugs. They may result in a shock or fire hazard. Call your
service technician for replacement.
As long as this unit is connected to the AC wall outlet, it is not disconnected from
the AC power source even if the unit is turned off.
Do not Open the Display:
There are no user serviceable components inside.
There are Dangerous High Voltages inside, even when the power is OFF.
Contact your dealer if the display is not operating properly.
To Avoid Personal Injury :
Do not place the display on a sloping shelf unless properly secured.
Use only a stand recommended by the manufacturer.
Do not drop an object on or apply impact to the product. Do not throw any toys
or objects on the product screen.
It can cause injury to human, problem to product and damage the display.
To Prevent Fire or Hazards:
Always turn the display OFF if you leave the room for more than a short period
of time. Never leave the display ON when leaving the house.
Keep children from dropping or pushing objects into the display's cabinet
openings. Some internal parts carry hazardous voltages.
Do not add accessories that have not been designed for this display.
When the display is to be left unattended for an extended period of time, unplug
it from the wall outlet.
In the presence of thunder and lightning, never touch the power cord and signal
cable because it can be very dangerous. It can cause electric shock.
2
Important Precautions
On Installation
Do not allow anything to rest upon or roll over the power cord, and do not place the
display where the power cord is subject to damage.
Do not use this display near water such as near a bathtub, washbowl, kitchen sink,
laundry tub, in a wet basement, or near a swimming pool.
Displays are provided with ventilation openings in the cabinet to allow the release
of heat generated during operation. If these openings are blocked, built-up heat
can cause failures which may result in a fire hazard. Therefore, NEVER:
Block the bottom ventilation slots by placing the display on a bed, sofa, rug, etc.
Place the display in a built-in enclosure unless proper ventilation is provided.
Cover the openings with cloth or other material.
Place the display near or over a radiator or heat source.
Do not rub or strike the Active Matrix LCD with anything hard as this may scratch,
mar, or damage the Active Matrix LCD permanently.
Do not press the LCD screen with your finger for a long time as this may cause
some afterimages.
Some dot defects may appear as Red, Green or Blue spots on the screen.
However, this will have no impact or effect on the display performance.
If possible, use the recommended resolution to obtain the best image quality for
your LCD display. If used under any mode except the recommended resolution,
some scaled or processed images may appear on the screen. However, this is
characteristic of the fixed-resolution LCD panel.
Leaving a fixed image on the screen for a long time may cause damage to the
screen and cause image burn-in. Make sure to use a screen saver on the product.
Burn-in and related problems are not covered by the warranty on this product.
Do not shock or scratch the front and sides of the screen with metallic objects.
Otherwise, it may cause damage to the screen.
Make sure the panel faces forward and hold it with both hands to move. If you
drop the product, the damaged product can cause electric shock or fire. Contact
an authorized the service center for repair.
Avoid high temperatures and humidity.
Important Precautions
3
On Cleaning
Unplug the display before cleaning the face of the display screen.
Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display
screen because over-spraying may cause electrical shock.
When cleaning the product, unplug the power cord and scrub gently with a soft
cloth to prevent scratching. Do not clean with a wet cloth or spray water or other
liquids directly onto the product. An electric shock may occur. (Do not use
chemicals such as benzene, paint thinners or alcohol)
Spray water onto a soft cloth 2 to 4 times, and use it to clean the front frame;
wipe in one direction only. Too much moisture may cause staining.
On Repacking
Do not throw away the carton and packing materials. They make an ideal
container in which to transport the unit. When shipping the unit to another
location, repack it in its original material.
On Disposal (Only , Hg lamp used LCD Monitor)
The fluorescent lamp used in this product contains a small amount of mercury.
Do not dispose of this product with general household waste.
Disposal of this product must be carried out in accordance to the regulations of
your local authority.
4
Accessories
Owner's Manual/Cards
Power Cord
15-pin D-Sub Signal Cable
(To set it up, this signal cable may be
attached to this product before
shipping out.)
DVI-D Signal Cable
(This feature is not available in
all countries.)
NOTE
This accessories may look different from those shown here.
User must use shielded signal interface cables (D-sub 15 pin cable, DVI-D cable) with ferrite
cores to maintain standard compliance for the product.
AC-DC adapter
(Depending on the country)
!!! Thank for selecting LGE products !!!
Please make sure the following items are included with your
monitor. If any items are missing, contact your dealer.
Connecting the Display
5
Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
Connecting the stand
1. Place the monitor face down on the cushion or soft cloth.
3. Attach the monitor to the Stand Base by turning the screw to the right.
4
.
Once assembled take the monitor up carefully and face the front side.
2. Assemble the Stand Base into the Stand Body in the correct direction as shown in the picture.
Stand Base
Stand Body
Screw : Turn the
screw by using the
screw handle.
6
Connecting the Display
IMPORTANT
This illustration depicts the general model of connection. Your monitor may differ from the items
shown in the picture.
Do not carry the product upside down holding only the stand base. The product may fall and get
damaged or injure your foot.
Turn the screw to the left to separate the stand body
from the stand base.
Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
Positioning your display
Adjust the position of the panel in various ways for maximum comfort.
Tilt Range : -5˚ to 15˚
IMPORTANT
It is recommended that in order to maintain an ergonomic and comfortable
viewing position, the forward tilt angle of the monitor should not exceed 5
degrees.
When adjusting the angle of the screen, do not put your finger(s) in between
the head of the monitor and the stand body. You can hurt your finger(s).
-5
15
7
NOTE
‘ Self Image Setting Function’? This function provides the user with optimal display
settings.When the user connects the monitor for the first time, this function automatically adjusts
the display to optimal settings for individual input signals.
‘AUTO’ Function? When you encounter problems such as blurry screen, blurred letters, screen
flicker or tilted screen while using the device or after changing screen resolution, press the
AUTO function button to improve resolution.
A
Connect D-sub(Analog signal) Cable
1. Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
2.
Connect signal input cable and power cord in order, then tighten the screw
of the signal cable.
Connecting with the PC
1
2
3. Press the power button on the front panel to turn the power on. When monitor power is
turned on, the 'Self Image Setting Function' is executed automatically.
NOTE
This is a simplified representation of the rear view.
This rear view represents a general model; your display may differ from the view as shown.
Connecting the Display E1960S/E2060S/E2260S/E2360S
A
Mac adapter : For Apple Macintosh use,
a separate plug adapter is needed to
change the 15 pin high density (3 row) D-
sub VGA connector on the supplied cable
to a 15 pin 2 row connector.
When using a D-Sub signal input cable
connector for Macintosh
Wall-outlet type
Varies according to model.
Power Button
Connect the signal
input cable and
tighten it up by
turning in the
direction of the
arrow as shown in
the figure.
8
Connecting the Display E1960T/E2060T/E2260T/E2360T
NOTE
‘ Self Image Setting Function’? This function provides the user with optimal display
settings.When the user connects the monitor for the first time, this function automatically adjusts
the display to optimal settings for individual input signals.
‘AUTO’ Function? When you encounter problems such as blurry screen, blurred letters, screen
flicker or tilted screen while using the device or after changing screen resolution, press the
AUTO function button to improve resolution.
A
B
Connect DVI-D(Digital signal) Cable
Connect D-sub(Analog signal) Cable
1. Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
2.
Connect signal input cable and power cord in order, then tighten the screw
of the signal cable.
Connecting with the PC
1
2
NOTE
This is a simplified representation of the rear view.
This rear view represents a general model; your display may differ from the view as shown.
3. Press the power button on the front panel to turn the power on. When monitor power is
turned on, the 'Self Image Setting Function' is executed automatically.
(Only Analog Mode)
Wall-outlet type
DVI-D (This feature is not available in all countries.)
Varies according to model.
Power Button
Connect the signal
input cable and
tighten it up by
turning in the
direction of the
arrow as shown in
the figure.
Mac adapter : For Apple Macintosh use,
a separate plug adapter is needed to
change the 15 pin high density (3 row) D-
sub VGA connector on the supplied cable
to a 15 pin 2 row connector.
When using a D-Sub signal input cable
connector for Macintosh
Connecting the Display E2260V/E2360V
9
A
B
Connect DVI-D(Digital signal) Cable
Connect D-sub(Analog signal) Cable
Connect HDMI Cable
1. Before setting up the monitor, ensure that the power to the monitor, the computer
system, and other attached devices is turned off.
2.
Connect signal input cable and power cord in order, then tighten the screw
of the signal cable.
Connecting with the PC
1
2
NOTE
This is a simplified representation of the rear view.
This rear view represents a general model; your display may differ from the view as shown.
C
Wall-outlet type
Headphone/Earphone Input
AV equipment
(Set-Top Box, DVD,
Video,
Video Game Console)
* HDMI is optimized on the AV equipment.
* Not supported PC
DVI-D (This feature is not
available in all countries.)
Varies according to model.
Connect the signal
input cable and
tighten it up by
turning in the
direction of the
arrow as shown in
the figure.
Mac adapter : For Apple Macintosh use,
a separate plug adapter is needed to
change the 15 pin high density (3 row) D-
sub VGA connector on the supplied cable
to a 15 pin 2 row connector.
When using a D-Sub signal input cable
connector for Macintosh
10
Connecting the Display E2260V/E2360V
NOTE
‘ Self Image Setting Function’? This function provides the user with optimal display
settings.When the user connects the monitor for the first time, this function automatically adjusts
the display to optimal settings for individual input signals.
‘AUTO’ Function? When you encounter problems such as blurry screen, blurred letters, screen
flicker or tilted screen while using the device or after changing screen resolution, press the
AUTO function button to improve resolution.
3. Press the power button on the front panel to turn the power on. When monitor power is
turned on, the 'Self Image Setting Function' is executed automatically.
(Only Analog Mode)
Power Button
11
Control Panel Functions E1960S/E2060S/E2260S/E2360S
Front Panel Controls
MODE Button
Use this button to enter F-ENGINE, ORIGINAL RATIO,
PHOTO EFFECT menus.
For more information, refer to page 26 to 31.
MENU Button
OSD LOCKED/UNLOCKED
This function allows you to lock the current control
settings, so that they cannot be inadvertently changed.
Press and hold the MENU button for several seconds.
The message "OSD LOCKED" should appear.
You can unlock the OSD controls at any time by pushing
the MENU button for several seconds. The message
"OSD UNLOCKED" should appear.
Use this button to enter or exit from the On Screen Display.
12
Control Panel Functions
AUTO Button
AUTO IMAGE ADJUSTMENT
When adjusting your display settings, always press
the AUTO button before entering the On Screen
Display(OSD). (Only Analog Mode)
This will automatically adjust your display image to
the ideal settings for the current screen resolution
size (display mode).
The best display mode is
E1960S : 1360 x 768
E2060S : 1600 x 900
E2260S/E2360S : 1920 x 1080
Use this button to turn the display on or off.
The power indicator stays light blue if the display is
running properly (On Mode). If the display is in Sleep
Mode (Energy Saving), the power indicator is red.
Power Button &
Power Indicator
Exit the OSD(On Screen Display).
EXIT Button
13
Control Panel Functions E1960T/E2060T/E2260T/E2360T/E2260V/E2360V
Front Panel Controls
MODE Button
Use this button to enter F-ENGINE, ORIGINAL RATIO,
PHOTO EFFECT menus.
For more information, refer to page 26 to 31.
MENU Button
OSD LOCKED/UNLOCKED
This function allows you to lock the current control
settings, so that they cannot be inadvertently changed.
Press and hold the MENU button for several seconds.
The message "OSD LOCKED" should appear.
You can unlock the OSD controls at any time by pushing
the MENU button for several seconds. The message
"OSD UNLOCKED" should appear.
Use this button to enter or exit from the On Screen Display.
14
Control Panel Functions
AUTO Button
AUTO IMAGE ADJUSTMENT
When adjusting your display settings, always press
the AUTO button before entering the On Screen
Display(OSD). (Only Analog Mode)
This will automatically adjust your display image to
the ideal settings for the current screen resolution
size (display mode).
The best display mode is
E1960T : 1360 x 768
E2060T : 1600 x 900
E2260T/E2360T : 1920 x 1080
E2260V/E2360V : 1920 x 1080
INPUT Button
Use this button to turn the display on or off.
The power indicator stays light blue if the display is
running properly (On Mode). If the display is in Sleep
Mode (Energy Saving), the power indicator is red.
Power Button &
Power Indicator
When two input signals at least are connected, you can
select the input signal (D-SUB/DVI/HDMI) you want. When
only one signal is connected, it is automatically detected.
The default setting is D-Sub.
(SOURCE Hot key)
Exit the OSD(On Screen Display).
EXIT Button
15
On Screen Display (OSD) Control Adjustment E1960S/E2060S/E2260S/E2360S
Screen Adjustment
Making adjustments to the image size, position and operating
parameters of the display is quick and easy with the On Screen
Display Control system.
A short example is given below to familiarize you with the use of the
controls. The following section is an outline of the available
adjustments and selections you can make using the OSD.
To make adjustments in the On Screen Display, follow these steps:
Press the discretionary button, then the main menu of the OSD appears.
To access a control, use the corresponding buttons.
Use the / buttons to adjust the image to the desired level.
Use the button to select other sub-menu items.
Press the EXIT Button to exit from the OSD.
1
2
3
4
16
On Screen Display (OSD) Control Adjustment E1960T/E2060T/E2260T/E2360T
Screen Adjustment
Making adjustments to the image size, position and operating
parameters of the display is quick and easy with the On Screen
Display Control system.
A short example is given below to familiarize you with the use of the
controls. The following section is an outline of the available
adjustments and selections you can make using the OSD.
To make adjustments in the On Screen Display, follow these steps:
Press the discretionary button, then the main menu of the OSD appears.
To access a control, use the corresponding buttons.
Use the / buttons to adjust the image to the desired level.
Use the button to select other sub-menu items.
Press the EXIT Button to exit from the OSD.
1
2
3
4
17
On Screen Display (OSD) Control Adjustment E2260V/E2360V
Screen Adjustment
Making adjustments to the image size, position and operating
parameters of the display is quick and easy with the On Screen
Display Control system.
A short example is given below to familiarize you with the use of the
controls. The following section is an outline of the available
adjustments and selections you can make using the OSD.
To make adjustments in the On Screen Display, follow these steps:
Press the discretionary button, then the main menu of the OSD appears.
To access a control, use the corresponding buttons.
Use the / buttons to adjust the image to the desired level.
Use the button to select other sub-menu items.
Press the EXIT Button to exit from the OSD.
1
2
3
4
18
On Screen Display(OSD) Selection and Adjustment
The following table indicates all the On Screen Display control, adjustment,
and setting menus.
F-ENGINE
ORIGINAL
RATIO
EFFECT
MODE
To select or customize desired
image settings
NOTE
The order of icons may differ depending on the model (18 to 31).
To adjust the image size
To adjust the screen color mode
NORMAL
MOVIE
INTERNET
WIDE
ORIGINAL
NORMAL
GAUSSIAN BLUR
SEPIA
MONOCHROME
DSUB
DVI-D
LANGUAGE
POWER INDICATOR
WHITE BALANCE
FACTORY RESET
To customize the screen status
for a user's operating
environment
OTHERS
HORIZONTAL
VERTICAL
CLOCK
PHASE
OVERSCAN
DISPLAY
To adjust the position of the
screen
COLOR TEMP
GAMMA
COLOR
To customize the color of the
screen
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
To adjust the brightness,
contrast and sharpness of the
screen
To improve the clarity and
stability of the screen
VOLUME
To adjust the headphone/
earphone volume
HDMI
HDMI
HDMI
DVI-D
HDMI
DVI-D
HDMI
DVI-D
HDMI
DVI-D
HDMI
RED
GREEN
BLUE
(PRESET) (USER)
sRGB
6500K
7500K
8500K
9300K
Main menu Sub-menu
Supported input
Description
VOLUME
D-SUB
D-SUB
D-SUB
D-SUB
D-SUB
D-SUB
D-SUB
: D-SUB(Analog signal) input
: DVI-D(Digital signal) input
: HDMI signal
D-SUB
DVI-D
HDMI
DSUB
DVI-D
HDMI
DSUB
DVI-D
HDMI
STANDARD
MOVIE
GAME
SPORTS
HDMI
19
On Screen Display(OSD) Selection and Adjustment
You were introduced to the procedure of selecting and adjusting an item using the
OSD system. Listed below are the icons, icon names, and icon descriptions of the
all items shown on the Menu.
Sub-
menus
NOTE
OSD (On Screen Display) menu languages on the monitor may differ from the manual.
Menu Name
Icons
Button
Tip
Move to the upper menu
Adjust (Decrease/Increase)
Select another sub-menu
Exit
Press the MENU Button, then the main menu of the OSD appears.
E1960T/E2060T/E2260T/E2360T
E1960S/E2060S/E2260S/E2360S
20
On Screen Display(OSD) Selection and Adjustment
You were introduced to the procedure of selecting and adjusting an item using the
OSD system. Listed below are the icons, icon names, and icon descriptions of the
all items shown on the Menu.
Sub-
menus
NOTE
OSD (On Screen Display) menu languages on the monitor may differ from the manual.
Menu Name
Icons
Button
Tip
Move to the upper menu
Adjust (Decrease/Increase)
Select another sub-menu
Exit
Press the MENU Button, then the main menu of the OSD appears.
E2260V/E2360V
21
On Screen Display(OSD) Selection and Adjustment
Main menu Sub menu Description
BRIGHTNESS
CONTRAST
SHARPNESS
BLACK LEVEL
To adjust the brightness of the screen.
To adjust the contrast of the screen.
To adjust the clearness of the screen.
You can set the offset level. If you select
'HIGH', the screen will be bright and if you
select ‘LOW’, the screen will be dark.
(only for HDMI input)
* Offset?
As the criteria for video signal, it is the
darkest screen the monitor can show.
E1960S/E2060S/E2260S/E2360S
E1960T/E2060T/E2260T/E2360T
E2260V/E2360V
: Move to the upper menu
: Decrease
: Increase
: Select another sub-menu
EXIT : Exit
D-SUB/DVI-D input
HDMI input
22
On Screen Display(OSD) Selection and Adjustment
PRESET
Select the screen color.
• sRGB: Set the screen color to fit the
sRGB standard color
specification.
• 6500K to 7500K: Slightly reddish white.
• 8500K to 9300K: Slightly bluish white.
RED
Set your own red color levels.
GREEN
Set your own green color levels.
BLUE
Set your own blue color levels.
GAMMA
Set your own gamma value. : 0 / 1 / 2
On the monitor, high gamma values
display whitish images and low
gamma values display blackish
images.
COLOR TEMP
USER
E1960S/E2060S/E2260S/E2360S
E1960T/E2060T/E2260T/E2360T
E2260V/E2360V
: Move to the upper menu
: Decrease
: Increase
: Select another sub-menu
EXIT : Exit
Main menu Sub menu Description
PRESET Mode
USER Mode
Select either PRESET or USER to
adjust the screen color.
PRESET Mode
USER Mode
23
On Screen Display(OSD) Selection and Adjustment
Main menu Sub menu Description
E1960S/E2060S/E2260S/E2360S
E1960T/E2060T/E2260T/E2360T
E2260V/E2360V
: Move to the upper menu
: Decrease
: Increase
: Select another sub-menu
EXIT : Exit
CLOCK
PHASE
OVERSCAN
To minimize any vertical bars or
stripes visible on the screen
background.
The horizontal screen size will also
change.
To adjust the focus of the display.
This item allows you to remove any
horizontal noise and clear or sharpen
the image of characters.
Removes noise that may occur at the
edges of an image when HDMI is
connected to an external device. When
ON is selected, the image size is
reduced to prevent noise. When OFF is
selected, the original image size is
maintained regardless of noise.
(Only for HDMI input)
HORIZONTAL
VERTICAL
To move image left and right.
To move image up and down.
D-SUB input
HDMI input
D-SUB input
24
On Screen Display(OSD) Selection and Adjustment
VOLUME To adjust the volume of headphone/
Earphone.
(Only for HDMI input)
E2260V/E2360V
: Move to the upper menu
: Decrease
: Increase
: Mute
EXIT : Exit
Main menu Sub menu Description
HDMI input
25
On Screen Display(OSD) Selection and Adjustment
Press the , buttons to reset
immediately.
Main menu Sub menu Description
To choose the language in which the
control names are displayed.
LANGUAGE
WHITE
BALANCE
If the output of the video card is
different the required specifications,
the color level may deteriorate due
to video signal distortion. Using this
function, the signal level is adjusted
to fit into the standard output level of
the video card in order to provide the
optimal image.
Activate this function when white
and black colors are present in the
screen.
Restore all factory default settings except
"LANGUAGE."
FACTORY
RESET
POWER
INDICATOR
Use this function to set the power
indicator on the front side of the monitor
to ON or OFF.
If you set OFF, it will go off.
If you set ON at any time, the power
indicator will automatically be turned on.
NOTE
If this does not improve the screen image, restore the factory default settings. If necessary, execute the
WHITE BALANCE function again. This function will be enabled only when the input signal is an analog
signal.
E1960S/E2060S/E2260S/E2360S
E1960T/E2060T/E2260T/E2360T
E2260V/E2360V
: Move to the upper menu
: Decrease
: Increase
: Select another sub-menu
EXIT : Exit
DVI-D input
D-SUB input
D-SUB input
HDMI/DVI-D input
26
On Screen Display(OSD) Selection and Adjustment
You were introduced to the procedure of selecting and adjusting an item using the
OSD system. Listed below are the icons, icon names, and icon descriptions of the
all items shown on the Menu.
Sub-
menus
NOTE
OSD (On Screen Display) menu languages on the monitor may differ from the manual.
Menu Name
Icons
Button
Tip
Move to the upper menu
Move
Select another sub-menu
Exit
Press the MODE Button, then the main menu of the OSD appears.
E1960T/E2060T/E2260T/E2360T
E2260V/E2360V
E1960S/E2060S/E2260S/E2360S
27
On Screen Display(OSD) Selection and Adjustment
Main menu Sub menu Description
NORMAL
Select this when you want to use the product
in the most general using environment.
MOVIE
Select this when you are watching a video or
movie.
INTERNET
Select this when you are working on the
document (Word etc.)
E1960S/E2060S/E2260S/E2360S
E1960T/E2060T/E2260T/E2360T
: Move to the upper menu
,
: Move
EXIT : Exit
28
On Screen Display(OSD) Selection and Adjustment
E2260V/E2360V
: Move to the upper menu
,
: Move
EXIT : Exit
Main menu Sub menu Description
D-SUB/DVI-D input
HDMI input
Select this when you want to use the
product in the most general using
environment.
Select this when you are watching a
video or movie.
Select this when you want to use the
original standard video.
* In the General (Standard) mode, the
is turned off.
NORMAL
STANDARD
D-SUB/DVI-D input
HDMI input
MOVIE
29
On Screen Display(OSD) Selection and Adjustment
: Move to the upper menu
,
: Move
EXIT : Exit
Main menu Sub menu Description
D-SUB/DVI-D input
HDMI input
Select this when you are working on
the document (Word etc.)
Select this when you are playing a
game.
Select this when you watching general
sports.
INTERNET
GAME
SPORTS
HDMI input
30
On Screen Display(OSD) Selection and Adjustment
Main menu Sub menu Description
Change the input image signal ratio to
original.
WIDE
ORIGINAL
Switch to full screen mode according to
input image signal.
* This function works only if input
resolution is lower than monitor ratio
(16:9).
: Move to the upper menu
,
: Move
EXIT : Exit
31
On Screen Display(OSD) Selection and Adjustment
Main menu Sub menu Description
NORMAL
The PhotoEffect function is disabled.
GAUSSIAN
BLUR
This menu changes the screen to be more
colorful and smoother.
SEPIA
This menu changes the screen to be
Sepia tone (brown color).
MONOCH
-ROME
This menu changed the screen to be
Gray tone(black-and-white Picture) .
: Move to the upper menu
,
: Move
EXIT : Exit
32
Troubleshooting
No image appears
Check the following before calling for service.
No image appears
Do you see a "OSD LOCKED" message on the screen?
● Is the power cord of the
display connected?
● Is the power indicator
light on?
● Is the power indicator
blinking?
● Do you see an "OUT OF
RANGE" message on
the screen?
● Do you see a "CHECK
SIGNAL CABLE"
message on the
screen?
•
Check and see if the power cord is connected
properly to the power outlet.
•
Press the Power button.
•
If the display is in power saving mode, try moving
the mouse or pressing any key on the keyboard to
bring up the screen.
• Try to turn on the PC
.
•
This message appears when the signal from the
PC (video card) is out of horizontal or vertical
frequency range of the display. See the
'Specifications' section of this manual and
configure your display again.
•
This message appears when the signal cable
between your PC and your display is not
connected. Check the signal cable and try again.
• You can secure the current control settings,
so that they cannot be inadvertently changed.
You can unlock the OSD controls at any time
by pushing the MENU button for several
seconds: the message
“OSD UNLOCKED” will appear.
●
Do you see “OSD
LOCKED” when you
push MENU button?
33
Troubleshooting
Display image is incorrect
● Display Position is
incorrect.
● On the screen
background, vertical
bars or stripes are
visible.
● Any horizontal noise
appearing in any
image or characters
are not clearly
portrayed.
•
Press the AUTO button to automatically adjust
your display image to the ideal setting.
If the results are unsatisfactory, adjust the image
position using the H position and V position icon
in the on screen display.
•
Press the AUTO button to automatically adjust
your display image to the ideal setting.
If the results are unsatisfactory, decrease the
vertical bars or stripes using the CLOCK icon in
the on screen display.
•
Press the AUTO button to automatically adjust
your display image to the ideal setting.
If the results are unsatisfactory, decrease the
horizontal bars using the PHASE icon in the on
screen display.
•
Check Control Panel --> Display --> Settings
and adjust the display to the recommended
resolution or adjust the display image to the ideal
setting. Set the color setting higher than 24 bits
(true color).
IMPORTANT
Check Control Panel --> Display --> Settings and see if the frequency or the resolution
were changed. If yes, readjust the video card to the recommend resolution.
If the recommended resolution (optimal resolution) is not selected, letters may be blurred
and the screen may be dimmed, truncated or biased. Make sure to select the recommend
resolution.
The setting method can differ by computer and O/S (Operation System),
and resolution mentioned above may not be supported by the video card
performance. In this case, please ask to the computer or the video card
manufacturer.
34
Troubleshooting
The Audio function is not working
Display image is incorrect
● The screen color is
mono or abnormal.
● The screen blinks.
•
Check if the signal cable is properly connected
and use a screwdriver to fasten if necessary.
•
Make sure the video card is properly inserted in
the slot.
•
Set the color setting higher than 24 bits (true color)
at Control Panel - Settings.
•
Check if the screen is set to interlace mode and if
yes, change it to the recommend resolution.
●
Picture OK & No sound.
• Check whether volume is "0".
• Check sound muted.
• HDMI cable installed properly.
• Head phone cable installed properly.
• Check sound format. Not supply to compressed
sound format.
Do you see an "Unrecognized monitor, Plug&Play (VESA
DDC) monitor found" message?
●
Have you installed the
display driver?
•
Be sure to install the display driver from the display
driver CD (or diskette) that comes with your
display. Or, you can also download the driver from
our web site: http://www.lg.com.
•
Make sure to check if the video card supports
Plug&Play function.
35
Specifications E1960S
47.0 cm (18.5 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
47.0
cm
0.300 mm x 0.300 mm (Pixel pitch)
Display
Horizontal Freq. 30 kHz to 83 kHz (Automatic)
Vertical Freq. 56 Hz to 75 Hz (Automatic)
Input Form Separate Sync.
Sync Input
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Video Input
Max VESA 1360 x 768 @60 Hz
Recommend VESA 1360 x 768 @60 Hz
Resolution
Plug&Play
On Mode
:
17 W(Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 44.20 cm (17.40 inch)
Height 35.53 cm (13.99 inch)
Depth 16.20 cm (6.38 inch)
Weight(excl. packing) 1.8 kg (3.97 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 2.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2AB
Without Stand
Width 44.20 cm (17.40 inch)
Height 35.10 cm (13.82 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type ADS-24NP-12-1 12024G, manufactured by HONOR Electronic
AC-DC Adapter
36
Specifications E1960T
47.0 cm (18.5 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
47.0
cm
0.300 mm x 0.300 mm (Pixel pitch)
Display
Horizontal Freq. 30 kHz to 83 kHz (Automatic)
Vertical Freq. 56 Hz to 75 Hz (Automatic)
Input Form Separate Sync.
Digital
Sync Input
Signal Input 15 pin D-Sub Connector
DVI-D Connector (Digital)
Input Form RGB Analog (0.7 Vp-p/ 75 ohm), Digital
Video Input
Max VESA 1360 x 768 @60 Hz
Recommend VESA 1360 x 768 @60 Hz
Resolution
Plug&Play
On Mode
:
17 W(Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 44.20 cm (17.40 inch)
Height 35.53 cm (13.99 inch)
Depth 16.20 cm (6.38 inch)
Weight(excl. packing) 1.8 kg (3.97 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 2.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2B(Digital),DDC2AB(Analog)
Without Stand
Width 44.20 cm (17.40 inch)
Height 35.10 cm (13.82 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type ADS-24NP-12-1 12024G, manufactured by HONOR Electronic
AC-DC Adapter
37
Specifications E2060S
50.8 cm (20.0 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
50.8
cm
0.2766 mm x 0.2766 mm (Pixel pitch)
Display
Horizontal Freq. 30 kHz to 83 kHz (Automatic)
Vertical Freq. 56 Hz to 75 Hz (Automatic)
Input Form Separate Sync.
Sync Input
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Video Input
Max VESA 1600 x 900 @ 60 Hz
Recommend VESA 1600 x 900 @ 60 Hz
Resolution
Plug&Play
On Mode
:
21 W(Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 47.40 cm (18.66 inch)
Height 37.30 cm (14.69 inch)
Depth 16.20 cm (6.38 inch)
Weight(excl. packing) 2.0 kg (4.41 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 2.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2AB
Without Stand
Width 47.40 cm (18.66 inch)
Height 36.88 cm (14.52 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type ADS-24NP-12-1 12024G, manufactured by HONOR Electronic
AC-DC Adapter
38
Specifications E2060T
50.8 cm (20.0 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
50.8
cm
0.2766 mm x 0.2766 mm (Pixel pitch)
Display
Horizontal Freq. 30 kHz to 83 kHz (Automatic)
Vertical Freq. 56 Hz to 75 Hz (Automatic)
Input Form Separate Sync.
Digital
Sync Input
Signal Input 15 pin D-Sub Connector
DVI-D Connector (Digital)
Input Form RGB Analog (0.7 Vp-p/ 75 ohm), Digital
Video Input
Max VESA 1600 x 900 @ 60 Hz
Recommend VESA 1600 x 900 @ 60 Hz
Resolution
Plug&Play
On Mode
:
21 W(Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 47.40 cm (18.66 inch)
Height 37.30 cm (14.69 inch)
Depth 16.20 cm (6.38 inch)
Weight(excl. packing) 2.0 kg (4.41 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 2.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2B(Digital),DDC2AB(Analog)
Without Stand
Width 47.40 cm (18.66 inch)
Height 36.88 cm (14.52 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type ADS-24NP-12-1 12024G, manufactured by HONOR Electronic
AC-DC Adapter
39
Specifications E2260S
54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
54.6
cm
0.248 mm x 0.248 mm (Pixel pitch)
Display
Horizontal Freq. 30 kHz to 83 kHz (Automatic)
Vertical Freq. 56 Hz to 75 Hz (Automatic)
Input Form Separate Sync.
Sync Input
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Video Input
Max VESA 1920 x 1080 @60 Hz
Recommend VESA 1920 x 1080 @60 Hz
Resolution
Plug&Play
On Mode
:
26 W(Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 50.88 cm (20.03 inch)
Height 39.24 cm (15.45 inch)
Depth 17.20 cm (6.77 inch)
Weight(excl. packing) 2.3 kg (5.07 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 3.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2AB
Without Stand
Width 50.88 cm (20.03 inch)
Height 38.74 cm (15.25 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type FSP036-DGAA1, manufactured by FSP Electronic
or type LCAP07F, manufactured by Lienchange Electronics
AC-DC Adapter
40
Specifications E2260T
54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
54.6
cm
0.248 mm x 0.248 mm (Pixel pitch)
Display
Horizontal Freq. 30 kHz to 83 kHz (Automatic)
Vertical Freq. 56 Hz to 75 Hz (Automatic)
Input Form Separate Sync.
Digital
Sync Input
Signal Input 15 pin D-Sub Connector
DVI-D Connector (Digital)
Input Form RGB Analog (0.7 Vp-p/ 75 ohm), Digital
Video Input
Max VESA 1920 x 1080 @60 Hz
Recommend VESA 1920 x 1080 @60 Hz
Resolution
Plug&Play
On Mode
:
26 W(Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 50.88 cm (20.03 inch)
Height 39.24 cm (15.45 inch)
Depth 17.20 cm (6.77 inch)
Weight(excl. packing) 2.3 kg (5.07 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 3.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2B(Digital),DDC2AB(Analog)
Without Stand
Width 50.88 cm (20.03 inch)
Height 38.74 cm (15.25 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type FSP036-DGAA1, manufactured by FSP Electronic
or type LCAP07F, manufactured by Lienchange Electronics
AC-DC Adapter
41
Specifications E2260V
54.6 cm (21.5 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
54.6
cm
0.248 mm x 0.248 mm (Pixel pitch)
Display
Sync Input
Video Input
Max VESA 1920 x 1080 @60 Hz
Recommend VESA 1920 x 1080 @60 Hz
Resolution
Plug&Play
On Mode
:
26 W (Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 50.88 cm (20.03 inch)
Height 39.24 cm (15.45 inch)
Depth 17.20 cm (6.77 inch)
Weight(excl. packing) 2.3 kg (5.07 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 3.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2B (Analog, Digital, HDMI)
Without Stand
Width 50.88 cm (20.03 inch)
Height 38.74 cm (15.25 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type FSP036-DGAA1, manufactured by FSP Electronic
or type LCAP07F, manufactured by Lienchange Electronics
AC-DC Adapter
Horizontal Freq. Analog,Digital: 30 kHz to 83 kHz (Automatic)
HDMI : 30 kHz to 83 kHz (Automatic)
Vertical Freq. Analog,Digital : 56 Hz to 75 Hz (Automatic)
HDMI : 56 Hz to 61 Hz (Automatic)
Input Form Separate Sync., Digital
Signal Input 15 pin D-Sub Connector
DVI-D connector (Digital)
19 pin HDMI Connector
Input Form Analog (0.7 Vp-p/ 75 ohm), Digital, HDMI
42
Specifications E2360S
58.4 cm (23.0 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
58.4
cm
0.265 mm x 0.265 mm (Pixel pitch)
Display
Horizontal Freq. 30 kHz to 83 kHz (Automatic)
Vertical Freq. 56 Hz to 75 Hz (Automatic)
Input Form Separate Sync.
Sync Input
Signal Input 15 pin D-Sub Connector
Input Form RGB Analog (0.7 Vp-p/ 75 ohm)
Video Input
Max VESA 1920 x 1080 @60 Hz
Recommend VESA 1920 x 1080 @60 Hz
Resolution
Plug&Play
On Mode
:
30 W (Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 54.23 cm (21.35 inch)
Height 41.20 cm (16.22 inch)
Depth 17.20 cm (6.77 inch)
Weight(excl. packing) 2.6 kg (5.73 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 3.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2AB
Without Stand
Width 54.23 cm (21.35 inch)
Height 40.83 cm (16.07 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type FSP036-DGAA1, manufactured by FSP Electronic
or type LCAP07F, manufactured by Lienchange Electronics
AC-DC Adapter
43
Specifications E2360T
58.4 cm (23.0 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
58.4
cm
0.265 mm x 0.265 mm (Pixel pitch)
Display
Horizontal Freq. 30 kHz to 83 kHz (Automatic)
Vertical Freq. 56 Hz to 75 Hz (Automatic)
Input Form Separate Sync.
Digital
Sync Input
Signal Input 15 pin D-Sub Connector
DVI-D Connector (Digital)
Input Form RGB Analog (0.7 Vp-p/ 75 ohm), Digital
Video Input
Max VESA 1920 x 1080 @60 Hz
Recommend VESA 1920 x 1080 @60 Hz
Resolution
Plug&Play
On Mode
:
30 W (Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 54.23 cm (21.35 inch)
Height 41.20 cm (16.22 inch)
Depth 17.20 cm (6.77 inch)
Weight(excl. packing) 2.6 kg (5.73 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 3.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2B(Digital),DDC2AB(Analog)
Without Stand
Width 54.23 cm (21.35 inch)
Height 40.83 cm (16.07 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type FSP036-DGAA1, manufactured by FSP Electronic
or type LCAP07F, manufactured by Lienchange Electronics
AC-DC Adapter
44
Specifications E2360V
58.4 cm (23.0 inch) Flat Panel Active matrix-TFT LCD
Anti-Glare coating
Visible diagonal size :
58.4
cm
0.265 mm x 0.265 mm (Pixel pitch)
Display
Horizontal Freq. Analog,Digital: 30 kHz to 83 kHz (Automatic)
HDMI : 30 kHz to 83 kHz (Automatic)
Vertical Freq. Analog,Digital : 56 Hz to 75 Hz (Automatic)
HDMI : 56 Hz to 61 Hz (Automatic)
Input Form Separate Sync., Digital
Sync Input
Signal Input 15 pin D-Sub Connector
DVI - D connector (Digital)
19 pin HDMI Connector
Input Form Analog (0.7 Vp-p/ 75 ohm), Digital, HDMI
Video Input
Max VESA 1920 x 1080 @60 Hz
Recommend VESA 1920 x 1080 @60 Hz
Resolution
Plug&Play
On Mode
:
30 W (Typ.)
Sleep Mode ≤ 1.0 W
Off Mode ≤ 0.5 W
Power
Consumption
Operating Conditions
Temperature 10 ˚C to 35 ˚C
Humidity 10 % to 80 % non-Condensing
Storage Conditions
Temperature -20 ˚C to 60 ˚C
Humidity 5 % to 90 % non-Condensing
Environment
al Conditions
With Stand
Width 54.23 cm (21.35 inch)
Height 41.20 cm (16.22 inch)
Depth 17.20 cm (6.77 inch)
Weight(excl. packing) 2.6 kg (5.73 lb)
Dimensions
& Weight
Tilt : -5˚ to 15˚
Range
12 V 3.0 A
Power Input
Attached ( ), Detached ( O )
Stand Base
Wall-outlet type
Power cord
DDC 2B (Analog, Digital, HDMI)
Without Stand
Width 54.23 cm (21.35 inch)
Height 40.83 cm (16.07 inch)
Depth 3.10 cm (1.22 inch)
NOTE
Information in this document is subject to change without notice.
Type FSP036-DGAA1, manufactured by FSP Electronic
or type LCAP07F, manufactured by Lienchange Electronics
AC-DC Adapter
45
Specifications
Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz)
*Recommend Mode
Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz)
*Recommend Mode
E1960S/E1960T
E2060S/E2060T
1
2
3
4
5
6
7
8
*9
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
832 x 624
1024 x 768
1024 x 768
1360 x 768
31.468
31.469
37.500
37.879
46.875
49.725
48.363
60.123
47.712
70
60
75
60
75
75
60
75
60
1
2
3
4
5
6
7
8
*9
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1152 x 864
1600 x 900
31.468
31.469
37.500
37.879
46.875
48.363
60.123
67.500
60.000
70
60
75
60
75
60
75
75
60
Preset Modes (Resolution) - D-sub(Analog) / DVI-D(Digital) INPUT
Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz)
*Recommend Mode
E2260S/E2360S/E2260T/E2360T/E2260V/E2360V
1
2
3
4
5
6
7
8
9
10
11
*12
720 x 400
640 x 480
640 x 480
800 x 600
800 x 600
1024 x 768
1024 x 768
1152 x 864
1280 x 1024
1280 x 1024
1680 x 1050
1920 x 1080
31.468
31.469
37.500
37.879
46.875
48.363
60.123
67.500
63.981
79.976
65.290
67.500
70
60
75
60
75
60
75
75
60
75
60
60
46
Specifications
Indicator
On Mode
Sleep Mode
Off Mode
Light Blue
Red
Off
LED Color
MODE
E2260V/E2360V
Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz)
1
2
3
4
5
6
7
8
480p
576p
720p
720p
1080i
1080i
1080p
1080p
31.50
31.25
37.50
45.00
28.12
33.75
56.25
67.50
60
50
50
60
50
60
50
60
HDMI Video Input
As an ENERGY STAR Partner LGE U. S. A.,Inc.
has determined that this product meets the
ENERGY STAR guidelines for energy efficiency.
ENERGY STAR is a set of power-saving
guidelines issued by the U.S. Environmental
Protection Agency(EPA).
Make sure to read the Important Precautions
before using the product.
Keep t he Own er ’s M anual (CD) in a n
accessible place for furture reference.
The model and serial number of the SET is
located on the back and one side of the SET.
Record it below should you ever need service.
MODEL
SERIAL
