User Manual GE® GTW845CPNDG 5.0 cu. ft. Capacity Smart Washer

• Owner's manual - (English, French, Spanish)

OWNER’S MANUAL & INSTALLATION INSTRUCTIONS WASHERS for GE® GTW845CPNDG

Contents

• SAFETY INSTRUCTIONS
• USING THE WASHER
• Getting Started
• Loading
• Appliance Communication
• CARE AND CLEANING
• INSTALLATION
• INSTRUCTIONS
• TROUBLESHOOTING TIPS
• LIMITED WARRANTY
• CONSUMER SUPPORT .

Care and Cleaning

Exterior of the Washer: Immediately wipe off any spills with a damp cloth.

Interior of the Washer: To clean the interior of the washer, select the Bulky Items feature on the control panel. This Bulky Items cycle should be performed, at a minimum, once per month. This cycle will use more water, in addition to bleach, to control the rate at which soils and detergents may accumulate in your washer.

1. Remove any garments or objects from the washer and ensure the washer basket is empty.
2. Open the washer lid and pour one cup or 250 ml of liquid bleach or other washing machine cleaner into the basket.
3. Close the lid and select the Bulky Items cycle. Push the Start button.
4. When the Bulky Items cycle is working, the display will show the estimated cycle time remaining. Do not interrupt the cycle

Dispenser Drawer

• After some period of use, a small amount of detergent or softener residue may be present in the dispenser drawer. The drawer can easily be removed for cleaning. To remove the drawer, pull it out until the drawer stops and then lift up on the front of the drawer. The drawer can then be removed from the dispenser box. Wash the drawer in warm, soapy water using a mild detergent. Rinse drawer with warm water. If siphon caps are removed for cleaning, be sure to push siphon caps fully back into place after cleaning. The dispenser drawer and siphon caps are not dishwasher safe.
• The dispenser box is not removable, but it can be wiped clean using a damp cloth if necessary. Do not attempt to remove the dispenser box for cleaning.

Proper Installation

This washer must be properly installed and located in accordance with the Installation Instructions before it is used.

• Ensure that the hot water hose is connected to the “H” valve and the cold water hose is connected to the “C” valve.
• Install or store where it will not be exposed to temperatures below freezing or exposed to the weather, which could cause permanent damage and invalidate the warranty.
• Properly ground washer to conform with all governing codes and ordinances. Follow details in the Installation Instructions.
• Ensure washer is properly leveled and washer legs are adjusted such that unit is stable.
• Optional drain hose extension recommended for discharging heights from 60” - 96”.
• GE Appliances strongly recommends the use of factory specified parts. A list of factory hoses available for purchase are listed. These hoses are manufactured and tested to meet GE Appliances specifications.
• GE Appliances strongly recommends the use of new water supply hoses. Hoses degrade over time and need to be replaced every 5 years to reduce the risk of hose failures and water damage.
