Operating Instructions
Dishwasher
To prevent accidents and machine damage, read these instructions be-
fore installation or use.
en-US M.-Nr. 10 546 720HG06
Contents
2
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 4
Guide to the dishwasher..................................................................................... 13
Appliance overview ............................................................................................... 13
Control panel......................................................................................................... 14
Caring for the environment ................................................................................ 15
Energy-saving dishwashing................................................................................... 16
Before using for the first time ............................................................................ 17
Opening the door .................................................................................................. 17
Closing the door.................................................................................................... 17
Child lock............................................................................................................... 17
Water softener ....................................................................................................... 18
Displaying and setting the water hardness level .............................................. 19
Before using the appliance for the first time, you require: .................................... 21
Dishwasher salt ..................................................................................................... 21
Filling the salt reservoir..................................................................................... 22
Salt refill indicator............................................................................................. 23
Rinse aid................................................................................................................ 24
Adding rinse aid ...............................................................................................24
Rinse aid indicator............................................................................................ 25
Setting the rinse aid dosage............................................................................. 25
Loading the dishwasher...................................................................................... 26
Tips........................................................................................................................ 26
Loading examples ................................................................................................. 28
FlexAssist .............................................................................................................. 29
Upper basket......................................................................................................... 29
Adjusting the upper basket ..............................................................................30
Lower basket......................................................................................................... 31
Cutlery ................................................................................................................... 33
Cutlery tray (depending on model) ................................................................... 33
Operation.............................................................................................................. 34
Detergent............................................................................................................... 34
Turning on.............................................................................................................. 37
Selecting a program .............................................................................................. 37
Starting a program ................................................................................................ 38
Time display .......................................................................................................... 38
Energy management ............................................................................................. 39
At the end of the program ..................................................................................... 39
Turning off the dishwasher .................................................................................... 40
Unloading the dishwasher..................................................................................... 40
Contents
3
Interrupting a program........................................................................................... 41
Changing a program.............................................................................................. 41
Options ................................................................................................................. 42
Short ................................................................................................................ 42
Turning off the refill indicators ............................................................................... 43
Delay Start............................................................................................................. 44
Optimize Standby.................................................................................................. 46
Factory default settings......................................................................................... 47
Program overview ............................................................................................... 48
Cleaning and care ............................................................................................... 50
Cleaning the wash cabinet .................................................................................... 50
Cleaning the door and the door seal..................................................................... 50
Cleaning the door front ......................................................................................... 51
Filter system .......................................................................................................... 52
Cleaning the spray arms........................................................................................ 54
Frequently Asked Questions .............................................................................. 55
Technical problems ............................................................................................... 55
Water intake fault................................................................................................... 57
Water drainage fault .............................................................................................. 57
General problems .................................................................................................. 58
Noises.................................................................................................................... 59
Poor cleaning results............................................................................................. 60
Frequently asked questions ............................................................................... 63
Cleaning the water intake...................................................................................... 63
Cleaning the drain pump and non-return valve..................................................... 64
Customer service ................................................................................................ 65
Repairs .................................................................................................................. 65
Warranty ................................................................................................................ 65
Optional accessories .......................................................................................... 66
Installation Instructions ......................................................................................... 69
Electrical connection .......................................................................................... 70
Water connection ................................................................................................ 71
The Miele WaterProof System ............................................................................... 71
Water intake .......................................................................................................... 71
Drainage ................................................................................................................ 72
Sound emission testing ...................................................................................... 73
IMPORTANT SAFETY INSTRUCTIONS
4
This dishwasher complies with current safety requirements. Inap-
propriate use can, however, lead to personal injury and damage to
property.
To avoid the risk of accidents and damage to the dishwasher,
please read the installation plan and the operating instructions
carefully before it is installed and used for the first time. Both con-
tain important information on its installation, safety, use and main-
tenance.
Keep the installation plan and the operating instructions in a safe
place and pass them on to any future owner.
Miele cannot be held liable for damage caused by non-compliance
with this information.
IMPORTANT SAFETY INSTRUCTIONS
5
Correct use
This dishwasher is intended for use in domestic households and
similar residential environments.
This dishwasher is not suitable for outdoor use.
It must only be used as specified in these operating instructions
for cleaning domestic dishes and cutlery. Any other usage is not
supported by the manufacturer and could be dangerous.
This appliance is not intended for use by persons (including chil-
dren) with reduced physical, sensory or mental capabilities, or lack
of experience and knowledge.
IMPORTANT SAFETY INSTRUCTIONS
8
To avoid the risk of damage to the dishwasher, make sure that the
connection data on the data plate (fuse rating, voltage, and fre-
quency) matches the electrical supply before connecting the dish-
washer to the mains. Consult a qualified electrician if in any doubt.
Do not connect the dishwasher to the electrical supply until it has
been fully installed and any adjustment has been made to the door
springs.
The dishwasher may only be operated if the door opening mecha-
nism is working correctly. Otherwise there could be a risk of danger
while the automatic door opening mechanism (depending on model)
is active.
To check that the door opening mechanism is working correctly:
– The door springs must be adjusted equally on both sides. They
are correctly adjusted when the door remains stationary when left
half open (approx. 45° opening angle). It is also important that the
door cannot fall open.
– The door locking pins automatically retract when the door opens
at the end of the drying phase.
Do not connect the appliance to the electrical supply by a multi-
socket adapter or an extension lead. These do not guarantee the re-
quired safety of the appliance (e.g. danger of overheating).
This appliance must not be installed and operated in a non-sta-
tionary location (e.g., on a ship).
Do not install the dishwasher in a room where there is a risk of
frost. Frozen hoses may burst or split. The reliability of the electronic
module may be impaired at temperatures below freezing point.
To avoid any damage to the appliance, the dishwasher must only
be operated when it is connected to a fully vented plumbing system.
The plastic housing of the water connection contains an electrical
valve. The housing must not be dipped in water.
IMPORTANT SAFETY INSTRUCTIONS
9
There are live wires in the water intake hose. Do not shorten the
water intake hose, even if it is too long.
The built-in WaterProof System offers reliable protection against
water damage if the following conditions are met:
– Proper installation
– Proper maintenance of the dishwasher or replacement of the
parts in case of noticeable damage
– Closing of the water valve during longer absences (for example,
vacation)
The WaterProof System will work even if the appliance is switched
off. However, the appliance must remain connected to the electricity
supply.
The water pressure (flow pressure at the connection point) must
be between 7.25 - 145 psi.
A damaged appliance could be dangerous. If the dishwasher gets
damaged, turn off the electrical supply and contact Miele.
The manufacturer's warranty will be invalidated if the appliance is
not repaired by a Miele-authorized service technician.
Defective components should be replaced by Miele original parts
only. Only with these parts can the manufacturer guarantee the
safety of the appliance.
During installation, maintenance and repair work, the appliance
must be disconnected from the electrical supply (turn it off and with-
draw the plug from the socket).
If the connection cable is damaged, it must be replaced with a
special cable of the same type (available from Miele) by a Miele-au-
thorized service technician only.
Guide to the dishwasher
13
Appliance overview
a
Upper spray arm (not visible)
b
Cutlery tray (depending on model)
c
Upper basket
d
Middle spray arm
e
Air intake for drying (depending on
model)
f
Lower spray arm
g
Filter system
h
Data plate
i
Rinse aid reservoir
j
Dual compartment detergent dis-
penser
k
Reservoir for dishwasher salt
Guide to the dishwasher
14
Control panel
a
Program selection
b
Time display
c
Check/Refill indicators
d
Start button with indicator light
e
Short button with indicator light
f
Delay Start button with indicator
light
g
Program selection button
h
(On/Off) button
Caring for the environment
15
Disposal of the packing mate-
rial
The cardboard box and packing materi-
als protect the appliance during ship-
ping. They have been designed to be
biodegradable and recyclable.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children. Dan-
ger of suffocation!
Disposal of your old appliance
Electrical and electronic appliances
contain valuable materials. They also
contain certain substances, compounds
and components which were essential
for the proper functioning and safe use
of the equipment. Handling these mate-
rials improperly by disposing of them in
your household waste can be harmful to
your health and the environment. There-
fore, please do not dispose of your old
appliance with regular household waste
and follow local regulations on proper
disposal.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please en-
sure that your old appliance is kept
away from children until removal. Ob-
serve safety requirements for appli-
ances that may tip over or pose an en-
trapment hazard.
Caring for the environment
16
Energy-saving dishwashing
This dishwasher is economical in the
consumption of water and energy.
For best results follow these tips:
– For most economical dishwashing,
make full use of the baskets without
overloading the dishwasher.
– Choose a program that best suits the
degree of soiling and the type of
dishes being washed.
– Select the Normal program (depend-
ing on model) for energy-saving dish-
washing. This program is the most ef-
ficient in terms of its combined en-
ergy and water consumption at clean-
ing normally soiled dishes.
– Follow the detergent manufacturer's
recommendations on detergent
dosage.
– When using powder or liquid deter-
gent, you can use
1
/
3
less detergent if
baskets are only half full.
– The dishwasher can be connected to
a hot water supply for further
economies. If the water is heated by
for example, solar panels, this would
be energy efficient.
However, if your water is heated by
electricity we recommend cold water
connection.
Before using for the first time
17
Opening the door
To open the door, reach under the
door grip and pull.
If the door is opened during operation,
all functions are automatically inter-
rupted.
Water in the dishwasher may be
hot. Danger of scalding!
Only open the door during operation
if absolutely necessary and exercise
extreme caution when doing so.
Closing the door
Push the baskets in.
Then lift the door upwards and push
until it clicks into position.
Danger of crushing injuries!
Do not put your hand inside the door
as it is closing.
Child lock
The child lock can be used to prevent
children opening the dishwasher. The
door can then only be opened by using
a lot of force.
To lock the door, push the slide un-
derneath the recessed handle to the
right.
To unlock the door, push the slide to
the left.
Before using for the first time
18
Water softener
In order to achieve good cleaning re-
sults, the dishwasher needs to operate
with soft water. Hard water results in a
build-up of calcium deposits on dish-
ware and in the dishwasher.
Water supplies with a hardness level
higher than 4 gr/gal (4 °d) needs to be
softened. This takes place automatically
in the integrated water softener. The
water softener in the dishwasher is suit-
able for a water hardness level of up to
73 gr/gal (70 °d).
– The water softener requires dish-
washer salt.
Depending on the water hardness
level (< 22 gr/gal, or 21 °d), dish-
washer salt is not required if combi-
nation tablets are being used (see
"Operation - Detergent").
– The dishwasher must be pro-
grammed for the water hardness in
your area.
– Your local water supplier can tell you
the water hardness level in your area.
– Where the water hardness fluctuates
e.g. between 10 - 16 gr/gal (10 - 15
°d), always program the dishwasher
to the higher value (16 gr/gal or 15 °d
in this example).
It is useful to know your water hardness
so that you can provide the service
technician with this information in the
event of any service calls.
Enter the water hardness below:
____________ gr/gal (°d)
The dishwasher is programmed at the
factory for a water hardness level of 1
gr/gal (1 °d).
If this setting corresponds to the hard-
ness of your water, you do not need to
do anything more.
However, if you have a different water
hardness, you must adjust the water
softener to match your water hardness.
Before using for the first time
19
Displaying and setting the water
hardness level
Turn the dishwasher off with the
button, if it is turned on.
Press the Start button and, simulta-
neously, switch the dishwasher on
using the button.
Keep the Start button pressed for at
least four seconds until the Start indi-
cator light comes on.
If this does not happen, start the proce-
dure from the beginning again.
Press the button twice.
The indicator light will flash twice at
short intervals.
The value which has been set for the
water hardness appears as a figure in
the time display (see table) according to
.
will start flashing in the time display.
This is the factory default setting of 1°.
Use the Start button to select the
value which equates to your water
hardness level.
Each press of the button moves you
up a level. When the highest water
hardness level is reached, the setting
starts from the beginning again.
The setting is now stored in memory.
Turn the dishwasher off with the
button.
Before using for the first time
20
°d gr/gal °f Time
display
1 1 2 1
2 2 4 2
3 3 5 3
4 4 7 4
5 5 9 5
6 6 11 6
7 7 13 7
8 8 14 8
9 9 16 9
10 10 18 10
11 11 20 11
12 13 22 12
13 14 23 13
14 15 25 14
15 16 27 15
16 17 29 16
17 18 31 17
18 19 32 18
19 20 34 19
20 21 36 20
°d gr/gal °f Time
display
21 22 38 21
22 23 40 22
23 24 41 23
24 25 43 24
25 26 45 25
26 27 47 26
27 28 49 27
28 29 50 28
29 30 52 29
30 31 54 30
31 32 56 31
32 33 58 32
33 34 59 33
34 35 61 34
35 36 63 35
36 38 65 36
37-45 39--47 66-80 45
46-60 48-63 82-107 60
61-70 64-73 109-125 70
Before using for the first time
23
Salt refill indicator
Fill the salt reservoir with dishwasher
salt when the Salt indicator light
comes on. If it comes on during a
program, wait until the end of the pro-
gram.
Risk of corrosion!
Immediately after filling the salt
reservoir, run the QuickIntenseWash
program with the Short programming
option selected and without any
dishware in the dishwasher to re-
move any traces of salt from the
wash cabinet.
After the salt reservoir has been filled,
the refill indicator may still be lit up if
the salt concentration has not yet
reached the correct level. It will go out
when the correct concentration is
reached.
The salt refill indicator will be turned off
if you have programmed the dishwasher
for a water hardness below 5 gr/gal
(5°d).
If you only ever use combination prod-
ucts in your dishwasher, you can
switch both refill indicators for salt and
rinse aid off if you wish (see "Options,
Refill indicators").
If you switch to using detergent that
does not contain salt or rinse aid, it
is important to remember to add
dishwasher salt and rinse aid and to
switch the indicators back on.
Before using for the first time
24
Rinse aid
Rinse aid is needed to prevent spotting
on dishes and glassware. The rinse aid
is filled in the reservoir and the set
amount will be automatically dosed.
Filling the rinse aid reservoir with
detergent will damage the reservoir.
Only pour rinse aid formulated for
residential dishwashers into the
reservoir.
When using "Tab" detergents rinse
aid is not needed.
Adding rinse aid
Press the button on the lid of the
rinse aid reservoir in the direction of
the arrow until the flap springs open.
Add rinse aid only until it is visible in
the opening.
The rinse aid reservoir holds approx.
3.7 oz. (110 ml).
Close the flap firmly so that it clicks
into place. Otherwise water can enter
the rinse aid reservoir during a pro-
gram.
Wipe up any spilled rinse aid. This
prevents over-foaming occurring dur-
ing the next program.
Before using for the first time
25
Rinse aid indicator
When the Rinse Aid indicator lights up,
the rinse aid reservoir contains suffi-
cient rinse aid for 2-3 programs only.
Add rinse aid.
If you only ever use combination prod-
ucts in your dishwasher, you can
switch both refill indicators for salt and
rinse aid off if you wish (see "Options -
Refill indicators").
Setting the rinse aid dosage
You can adjust the rinse aid dosage for
best results.
The rinse aid dosage is set in stages
from 0 to 6. It is set to 3 at the factory.
This is the recommended setting.
If spots appear on dishware and glass-
ware:
Increase the rinse aid dosage.
If clouding or smearing appears on
dishware and glassware:
Decrease the rinse aid dosage.
Turn the dishwasher off with the
button, if it is turned on.
Press the Start button and, simulta-
neously, switch the dishwasher on
using the button.
Keep the Start button pressed for at
least four seconds until the Start indi-
cator light comes on.
If this does not happen, start the proce-
dure from the beginning again.
Press the button 3 times.
The indicator light will flash 3 times
at short intervals.
The set value will appear in the display
after .
The flashing sequence will appear in
the display.
This indicates a factory default setting
of 3.
Use the Start button to select the set-
ting required.
Each press on the button moves you
up a level. After reaching the highest
value, the counter starts from the be-
ginning again.
The setting is now saved.
Turn the dishwasher off with the
button.
Loading the dishwasher
30
Adjusting the upper basket
In order to gain more space for taller
items the upper basket can be adjusted
on three levels with 3/4" (2 cm) between
each level.
The upper basket can also be set at an
angle with one side high and the other
side low. Make sure, however, that the
basket can slide smoothly in and out of
the cabinet.
Pull the upper basket out.
To raise the upper basket:
Lift the basket until it clicks into
place.
To lower the upper basket:
Pull upwards on the levers at either
side of the upper basket.
Adjust the basket to the desired
height and then push the levers se-
curely back down into position.
Depending on the setting of the upper
basket, the following plate dimensions
can be accommodated.
Dishwashers with cutlery tray
Upper
basket
adjustment
Plate in inches (cm)
Upper
basket
Lower
basket
Upper 7 7/8" (15) 12
3/16" (31)
Middle 6
11/16" (17)
11
7/16" (29)
Lower 7 1/2" (19) 10 5/8" (27)
Depending on the setting of the upper
basket, a variety of plate dimensions
can be accommodated.
Operation
35
Detergent dosage
Follow the dosage recommended by
the manufacturer on the packaging.
Unless directed otherwise, use one
detergent tab or add 1 1/4 - 2 table-
spoons (20 - 30 ml) detergent to
compartment II, depending on the
level of soiling. With very heavy soil-
ing you can also add a small amount
of detergent to compartment l.
Tabs may not dissolve completely
when the "QuickPowerWash" pro-
gram (if available) is used.
Use only the recommended amount
of detergent. Continued use of too
much detergent may cause machine
damage.
Dishwasher detergents can
cause burning in the nose, mouth,
and throat if swallowed, or inhibit
breathing.
Avoid inhaling or swallowing dish-
washer detergent. Keep children
away from detergent. Keep detergent
out of the reach of children. Keep
children away
from the dishwasher when the door
is open. There could still be deter-
gent residues in the dishwasher. Only
add detergent just before starting the
program and lock the door with the
child lock (depending on model).
Operation
36
Adding detergent
Press the opening catch on the deter-
gent dispenser. The flap will spring
open.
The flap is always open at the end of a
program.
Add the required amount of detergent
and close the flap.
Make sure that the detergent packag-
ing is properly closed after use to
avoid it getting damp and becoming
lumpy.
Dispensing aid
Compartment I holds a maximum of 2
teaspoons (10 ml),
Compartment II holds a maximum of
3.5 tablespoons (50 ml) of detergent.
The marks in compartment II indicate
the levels of approximately 1 ¼ and 2
tablespoons (20 and 30 ml) respec-
tively. The marks indicate the approxi-
mate fill level in ml when the door is
open in a horizontal position.
Operation
37
Turning on
Make sure the spray arms are not ob-
structed.
Close the door.
Turn on the water supply if it is turned
off.
Turn the dishwasher on with the
button.
The Start indicator light flashes and the
indicator light comes on next to the pro-
gram selected.
Selecting a program
Choose your program according to the
type of load and the degree of soiling.
The different programs and their uses
are described in the Program Over-
view chapter.
Use the program selection button
to select the program required.
The indicator light for the program se-
lected will light up.
The program duration will appear in
hours and minutes in the display.
You can now select program options
(see "Options").
If any program options are selected, the
appropriate indicator lights will also
light up.
Operation
39
Energy management
To save energy, the dishwasher will
switch off automatically 10minutes af-
ter the last time a button has been
pressed or 10minutes after the end of
the program (see "Options, Optimize
Standby").
Press the button to switch the
dishwasher back on.
The dishwasher will not turn off while
a program is running, during the delay
start period, or if there is a fault.
At the end of the program
The program has finished when .
appears in the display.
The drying fan may continue to run for
a few minutes at the end of the pro-
gram.
The dishwasher can now be opened
and unloaded (see "Unloading the
dishwasher").
To prevent the risk of steam
damage to the counter edging above
the dishwasher, it is advisable to
leave the door closed until you are
ready to unload the dishware. Alter-
natively you can open the door fully
until the dishware is cool enough to
unload. Do not leave the door only
partially open.
Operation
40
Turning off the dishwasher
At the end of a program:
The dishwasher can be switched off
at any time using the button.
Switching the dishwasher off during a
program stops the program.
Turning the dishwasher off during the
run-up to a delay start time (FlexiTimer)
will also stop the process.
If the dishwasher is not going to be
used for a longer period of time, e.g.,
while on vacation, the water supply
should be turned off.
Unloading the dishwasher
Dishes tend to break and chip more
easily when they are hot. Allow the
dishes to cool until they are comfortable
enough to handle before unloading
them.
The dishes will cool much faster if you
open the door when the program has
ended.
First unload the lower basket, then the
upper basket, and finally the cutlery tray
(depending on model).
This will prevent water drops from the
upper basket and cutlery tray from fall-
ing onto the dishes in the lower basket.
Options
42
Short
The "Short" option reduces the du-
ration of programs in which this option
is available (see "Program overview").
In order to achieve optimum cleaning
results, consumption rates are in-
creased with this option.
When used in combination with the
"QuickintenseWash" program, the Short
option results in a wash program
without drying or automatic opening of
the door (if available).
Turn the dishwasher on with the
button.
The Start indicator light flashes.
Select a program.
Press the button.
The indicator light will light up.
The program can now be started.
The option selected will remain active
for that particular program until the set-
ting is changed.
Options
43
Turning off the refill indicators
If you consistently use a Tab detergent,
you can deactivate the refill indicators if
you wish.
Turn the dishwasher off with the
button, if it is turned on.
Press the Start button and, simulta-
neously, switch the dishwasher on
using the button.
Keep the Start button pressed for at
least four seconds until the Start indi-
cator light comes on.
If this does not happen, start the proce-
dure from the beginning again.
Press the button 9 times.
The indicator light will flash 9 times
at short intervals.
The flashing sequence in the time dis-
play will show whether the refill indica-
tors are switched on or off.
– : Refill indicators activated
– : Refill indicators deactivated
Press the Start button to change the
setting.
The setting is now stored in memory.
Turn the dishwasher off with the
button.
If you switch to using detergent that
does not contain salt or rinse aid, it
is important to remember to add
dishwasher salt and rinse aid and to
switch the indicators back on.
Options
46
Optimize Standby
"Optimize Standby" is activated by de-
fault.
To save energy, the dishwasher will
switch off automatically a few minutes
after the last time a button has been
pressed or after the end of a program.
The dishwasher will not turn off while
a program is running, during the delay
start period, or if there is a fault.
Optimize Standby can be switched off if
you prefer. If you do this the duration
before the dishwasher switches off au-
tomatically increases to 6 hours. Doing
this will increase energy consumption.
Turn the dishwasher off with the
button, if it is turned on.
Press the Start button and, simulta-
neously, switch the dishwasher on
using the button.
Keep the Start button pressed for at
least four seconds until the Start indi-
cator light comes on.
If this does not happen, start the proce-
dure from the beginning again.
Press the button 8 times.
The indicator light will flash 8 times
at short intervals.
The flashing sequence in the display
shows whether or not Optimize Standby
is activated.
– : "Optimize Standby" activated
– : "Optimize Standby" deactivated
Press the Start button to change the
setting.
The setting is now stored in memory.
Turn the dishwasher off with the
button.
Options
47
Factory default settings
If you have altered any settings from the
factory default, you can reset them
back to the factory default settings as
follows:
Turn the dishwasher off with the
button, if it is turned on.
Press the Start button and, simulta-
neously, switch the dishwasher on
using the button.
Keep the Start button pressed for at
least four seconds until the Start indi-
cator light comes on.
If this does not happen, start the proce-
dure from the beginning again.
Press the button 19 times.
The indicator light will flash once at a
long interval and then 9 times at short
intervals.
The flashing sequence in the display in-
dicates whether a setting has been
changed from its factory default.
– : All settings are set to factory de-
fault settings
– : At least one setting has been
changed
To reset the dishwasher to the factory
default settings, press the Start but-
ton.
The setting is now stored in memory.
Turn the dishwasher off with the
button.
Program overview
48
Program When to use Program sequence
Pre-
wash
Main
wash
Interim
rinse
Final
rinse
Drying
°F/°C °F/°C
Normal
1)
Program for regular use to completely
wash a full load of normally soiled
dishes with the ability to adjust en-
ergy and water consumption based
on the soil load of the dishes.
As
needed
120-
140/
49-
60
X 145-
154/
63-
68
X
Pots &
Pans
For heavily soiled dishes and normally
soiled pots,pans and utensils with
dried on residue; use 20% more de-
tergent than recommended.
2X 167/
75
X 136/
58
X
China
&Crystal
For temperature sensitive glassware
and lightly soiled dishes, use 50% de-
tergent recommended. GlassCare
program for temperature-sensitive
glasses and dishes with light soiling.
Use 50% of the detergent amount.
X 113/
45
X 154/
68
X
Quick
Intense-
Wash
"Quick program" for standard dishes
soiling that has not dried on.
149/
65
X 140/
60
X
SaniWash To sanitize dishware, e.g. baby bot-
tles, cutting boards and preparation
dishes.
156/
69
2X 158/
70
X
Rinse&
Hold
To rinse dishes when a complete pro-
gram is not needed.
X
1)
This program is the most efficient in terms of its combined energy and water consumption
for cleaning normally soiled crockery.
This program is used for energy labeling purposes.
Cleaning and care
50
Check and clean your dishwasher
regularly. This will help avoid prob-
lems and faults.
All surfaces are susceptible to
scratching.
Contact with unsuitable cleaning
agents can alter or discolor all sur-
faces.
Cleaning the wash cabinet
Generally, the wash cabinet is self
cleaning if the correct amount of deter-
gent is used.
If, however, there are limescale or
grease deposits in the wash cabinet,
these can be removed with a special
cleaning agent (available from Miele).
Follow the instructions on the packag-
ing.
If you mainly use low temperature pro-
grams (< 120°F/50 °C), there is a risk of
bacteria and unpleasant odors building
up in the wash cabinet. To prevent this
happening the dishwasher will automat-
ically increase the temperature in the fi-
nal rinse of the selected program after
several programs using low tempera-
tures have been run.
Clean the filters in the wash cabinet
regularly.
Cleaning the door and the door
seal
Bacteria could build up on the door seal
and the sides of the dishwasher door as
these surfaces are outside the wash
cabinet and are not accessed and
cleaned by the spray arm jets.
Wipe the door seals regularly with a
damp cloth to remove food deposits.
Wipe off any food or drink residues
which may have dripped onto the
sides of the dishwasher door before
closing it.
Cleaning and care
52
Filter system
The filter system in the base of the
wash cabinet prevents food from being
redeposited on dishes. It also protects
the circulation pump from damage
caused by foreign objects.
This dishwasher must not be
used without all the filters in place!
Collection of coarse soil may cause the
filters to clog. The level of soiling and
time it takes before the filters need
cleaning will vary depending on use.
Check the condition of the filters reg-
ularly and clean them if necessary.
Filter system
Turn the dishwasher off.
Turn the handle counter-clockwise to
release the filter system .
Lift the filter system out of the dish-
washer . Remove any coarse parti-
cles and rinse the filter well under
running water.
Use a nylon brush if necessary.
Ensure that coarse soil does not
get into the circulation system and
cause a blockage.
Cleaning and care
54
Cleaning the spray arms
Particles of food can get stuck in the
spray arm jets and bearings. The spray
arms should therefore be inspected and
cleaned regularly (approx. every 4 - 6
months).
Turn the dishwasher off.
Remove the spray arms as follows:
Take out the cutlery tray (if your dish-
washer is fitted with one).
Push the top spray arm upwards to
engage the inner ratchet. Then un-
screw the spray arm.
Push the middle spray arm upwards
to engage the ratchet. Then un-
screw the spray arm .
Remove the lower basket.
Pull the lower spray arm firmly up-
wards to remove it.
Use a pointed object to push the food
particles that are stuck in the spray
arm jets into the spray arm.
Rinse the spray arms thoroughly un-
der running water.
Replace the spray arms and check
that they rotate freely.
Frequently Asked Questions
55
With the help of the following guide, minor faults in the performance of the appli-
ance, some of which may result from incorrect operation, can be put right without
contacting Miele Service. This will save time and money.
The following guide may help you to find the reason for a fault, and to correct it.
You should, however, note the following:
Unauthorized or incorrect repairs could cause personal injury or damage to
the appliance.
Repair work to electrical appliances must only be carried out by a suitably qual-
ified and competent person in strict accordance with current local and national
safety regulations. The manufacturer cannot be held liable for unauthorized
work.
Technical problems
Problem Possible cause and solution
After the dishwasher is
turned on with the
button, the Start indica-
tor light does not flash.
The dishwasher is not plugged in.
Insert the plug.
The circuit breaker has tripped.
Reset the fuse (see data plate for the correct fuse
rating).
The dishwasher stops
during a program.
The circuit breaker has tripped.
Reset the fuse (see data plate for the correct fuse
rating).
If the circuit breaker trips again, contact Miele Ser-
vice.
Frequently Asked Questions
57
Water intake fault
Problem Possible cause and solution
The Intake/Drain indica-
tor flashes on and off.
The water supply is turned off.
Turn on the water supply fully.
The dishwasher stops
during a program.
The Intake/Drain indica-
tor flashes.
Fault code or ap-
pears in the display.
Before fixing the fault:
Turn the dishwasher off with the button.
There is a problem with the water intake.
Turn on the water supply fully and start the pro-
gram again.
Clean the water intake filter (see "Frequently asked
questions").
The flow pressure at the connection point is lower
than 7.25 psi.
Contact a plumber.
Water drainage fault
Problem Possible cause and solution
The dishwasher stops
during a program.
The Intake/Drain indica-
tor flashes.
Fault code shows in
the display.
Before fixing the fault:
Turn the dishwasher off with the button.
There is a problem with the water intake.
There might be water in the wash cabinet.
Clean the filter system (see "Cleaning and care -
Filter system").
Clean the drain pump (see "Frequently asked
questions").
Clean the non-return valve (see "Frequently asked
questions").
Remove any kink or loop in the drain hose.
Frequently Asked Questions
59
Noises
Problem Possible cause and solution
There is a knocking
noise in the wash cabi-
net.
A spray arm is hitting the dishes.
Interrupt the program, and rearrange the items
which are obstructing the spray arm.
There is a rattling noise
in the wash cabinet.
Dishes is moving around in the wash cabinet.
Interrupt the program and rearrange loose pieces.
A foreign object (e.g., a cherry pit) has become
lodged in the drain pump.
Remove the foreign object from the drain pump
(see "Maintenance - Cleaning the drain pump and
non-return valve").
There is a knocking
noise from the water
pipe
This may be caused by the installation or the diameter
of the water pipe.
This has no influence on dishwasher function. If in
doubt, contact a suitably qualified plumber.
Frequently Asked Questions
61
Problem Possible cause and solution
Dishes is not dry or cut-
lery and glasses are
spotty.
The rinse aid dosage is set too low or the rinse aid
reservoir is empty.
Replenish the reservoir, increase the dosage, or
change the brand of rinse aid (see "Before using
for the first time - Rinse aid").
Dishes was taken out of the cabinet too soon.
Leave it in for longer (see "Operation").
Combination tabs have been used which have im-
paired drying performance.
Change your detergent, or replenish the rinse aid
(see "Before using for the first time - Rinse aid").
Glasses have a brown-
ish-blue discoloration;
the deposit cannot be
wiped off.
Detergent deposits.
Switch to another detergent.
Glasses are dull and
discolored; the deposit
cannot be wiped off.
The glassware is not dishwasher-safe. The surfaces
are affected.
There is no remedy.
Purchase glassware which is dishwasher-safe.
Tea or lipstick stains
have not been com-
pletely removed.
The wash temperature of the selected program was
too low.
Select a program with a higher wash temperature.
The bleaching effect of the detergent is too low.
Switch to another detergent.
Plastic parts are discol-
ored.
Natural dyes, e.g., from carrots, tomatoes, or ketchup
may be the cause. The amount of detergent used or
its bleaching effect was not sufficient to deal with nat-
ural dyes.
Use more detergent (see "Operation - Detergent").
Discoloration is irreversible.
Frequently asked questions
63
Cleaning the water intake
A filter is incorporated in the screw con-
nection of the water intake valve. The
filter must be cleaned when dirty, other-
wise insufficient water flows into the
wash cabinet.
The plastic housing of the water
connection contains an electrical
component.
The housing must not be dipped in
water.
Recommendation
If the water supply contains a large
amount of insoluble substances, we
recommend fitting a large-area filter in
the connection between the faucet and
the water intake hose threaded union.
This filter is available from a Miele
dealer or Miele Service.
To clean the filter:
Disconnect the dishwasher from the
electrical supply.
Switch off at the mains socket and
withdraw the plug.
Turn off the water supply.
Unscrew the water intake valve.
Take the seal ring out of the screw
connection.
Withdraw the filter using pointed pli-
ers and rinse clean under running wa-
ter.
Replace the filter and washer, making
sure they are sitting correctly.
Reconnect the water intake valve to
the faucet, making sure it goes on
correctly and is not cross-threaded.
Turn on the water supply.
If water leaks out, the screw connection
may not be connected securely or it
may have been screwed on at an angle.
Unscrew and reconnect the water in-
take valve correctly.
Customer service
65
Repairs
For problems that you cannot resolve
on your own, please contact:
– your Miele dealer or
– Miele Service
The telephone number for Miele is
listed at the back of these instruc-
tions.
In the event of a fault which you cannot
correct yourself please contact the
Miele Service Department at the phone
number on the back of this booklet.
Warranty
For more information, please refer to the
included warranty.
MieleCare (USA only)
MieleCare, our Extended Service Con-
tract program, gives you the assurance
of knowing that your appliance invest-
ment is covered by 5 years of worry free
ownership.
MieleCare is the only Extended Service
Contract in the industry that guarantees
repairs by a Miele Authorized Service
Provider using genuine Miele parts.
Only genuine Miele parts installed by
factory trained professionals can guar-
antee the safety, reliability, and
longevity of your Miele appliance.
Please note that unless expressly ap-
proved in writing by Miele’s Service de-
partment, Extended Service Contracts
offered by other providers for Miele
products will not be recognized by
Miele. Our goal is to prevent unautho-
rized (and untrained) service personnel
from working on your Miele products,
possibly doing further damage to them,
you and/or your home.
To learn more about MieleCare Ex-
tended Service Contracts, please con-
tact your appliance dealer or visit us
online at:
http://www.mieleusa.com
68
69
Installation Instructions
Please refer to the Installation Diagram supplied with these instructions.
To comply with IEC sound testing protocols, please contact Miele for additional
instructions.
Information is subject to change. Please refer to our website to obtain the most
current product specification, technical & warranty information.
Water connection
72
Drainage
– The machine comes equipped with a
built-in non-return valve on the dis-
charge side to prevent waste water
from flowing back into the dish-
washer.
– Take the drain line of the dishwasher
and attach the drain line as high as
possible under the counter rim of the
kitchen sink before connecting the
end to the drain. The loop will serve
to prevent a backed up drain or large
volume of water in the sink from si-
phoning back into the dishwasher.
– The dishwasher is supplied with ap-
prox. 5' 11" (1.5m) of flexible drain
hose with an internal diameter of
7/8" (22mm).
– The drain hose can be extended us-
ing extensions and adapters. The
drainage length must not be longer
than 13' 1 1/2" (4m) and the delivery
head must not exceed 3' 3 3/8" (1m).
– If the hose is to be directly fitted to
the drainage outlet on site, use the
hose clip supplied (see installation di-
agram).
– The hose can be directed to the left
or the right of the appliance.
– The on-site connector for the drain
hose can be adapted to different
widths of hose. If the connector pro-
trudes too far into the drain hose, it
will need to be shortened. Otherwise
the drain hose may become blocked.
– The drain hose must not be short-
ened.
Make sure that there are no kinks
in the hose, and that it is not
squashed or stretched.
After servicing the appliance, ensure
that the drain does not leak.
Venting the drain
If the on-site drain connection is situ-
ated lower than the guide path for the
bottom basket rollers in the open door,
the drain must be vented. Otherwise a
siphoning effect during a program can
cause the appliance to empty itself of
water.
To vent: open the dishwasher door
fully.
Pull the lower spray arm firmly up-
wards to remove it.
Cut off the top of the vent valve in the
wash cabinet.
Sound emission testing
73
Prerequisites for sound emission tests
Load the dishwasher with 16 standard place settings and use the Normal pro-
gram.
Setup for sound emission tests
The dishwasher must be set up according to the following specifications.
Install the dishwasher into an analyzing unit.
Secure the front panel.
Sound emission testing
75
Remove the protective film from the provided insulating strip (depending on
model) .
Push the insulating strip into the front top edge of the toe-kick .
9 Independence Way
Princeton, NJ 08540
Phone:
Fax:
www.mieleusa.com
U.S.A.
Miele, Inc.
National Headquarters
Please have the model and serial number
of your appliance available before
contacting Technical Service.
Canada
Importer
Miele Limited
Headquarters and Miele Centre
800-843-7231
609-419-4298
Technical Service & Support
Nationwide
Phone:
Fax:
161 Four Valley Drive
Vaughan, ON L4K 4V8
www.miele.ca
800-999-1360
888-586-8056
Customer Care Centre
Phone:
800-565-6435
905-532-2272
International Headquarters
Miele & Cie. KG
Carl-Miele-Straße 29
33332 Gütersloh
Germany
M.-Nr. 10 546 720 / 01en-US
G 4720
