GE - General Electric GE Profile' 30" Free-Standing Double User Manual

Safety Instructions  . . . . . . . . . . . . . .2–5
Operating Instructions
Clock, Timer and
Control Lockout . . . . . . . . . . . . . . .18, 19
Convection Oven . . . . . . . . . . . . . .21–25
Roasting Guide  . . . . . . . . . . . . . . . . .25
Timed Features . . . . . . . . . . . . . .23, 24
Cookware . . . . . . . . . . . . . . . . . . . . . . . . .7
Lower Oven Drawer  . . . . . . . . . . . . . .20
Oven  . . . . . . . . . . . . . . . . . . . . . . . .14, 15
Broiling Guide  . . . . . . . . . . . . . . . . .15
Oven Controls  . . . . . . . . . . . . . . . .12, 13
Probe  . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Proofing Feature  . . . . . . . . . . . . . . . . .26
Sabbath Feature  . . . . . . . . . . . . . . . . . .32
Self-Cleaning  . . . . . . . . . . . . . . . . .27, 28
Special Features  . . . . . . . . . . . . . . .29–31
Surface Units  . . . . . . . . . . . . . . . . . . 6–11
Knob-Controlled Models . . . . . .10, 11
Touch Pad-Controlled Models  . . .8, 9
Thermostat Adjustment—
Do It Yourself  . . . . . . . . . . . . . . . . . . . .19
Timed Baking and
Roasting Features . . . . . . . . . . . . . . . . .16
Warming Feature  . . . . . . . . . . . . . . . . .26
Care and Cleaning . . . . . . . . . . . 33–39
Troubleshooting Tips . . . . . . . . . 40–44
Accessories . . . . . . . . . . . . . . . . . . . . . . 50
Consumer Support
Consumer Support  . . . . . . . Back Cover
Product Registration  . . . . . . . . . . 45, 46
Warranty . . . . . . . . . . . . . . . . . . . . . . . . 51
ge.com
JB968
JB988
Owner’s Manual
49-80487-1  12-07 JR
Write the model and serial
numbers here:
Model
# ______________
Serial
# ______________
You can find them on a label
behind the storage drawer
on the range frame.
Ranges
Radiant Self-Cleaning Convection

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

WARNING!

For your safety, the information in this manual must be followed to minimize the risk of fire, electric

shock, or to prevent property damage, personal injury, or loss of life.

All ranges can tip and injury could result.

To prevent accidental tipping of the range, attach it to the wall and floor by installing the Anti-Tip

device supplied.

If the Anti-Tip device supplied with the range does not fit this application, use the universal Anti-Tip

device WB2X7909.

To check if the device is installed and engaged properly, remove the storage drawer and inspect

the rear leveling leg. Make sure it fits securely into the slot.

If you pull the range out from the wall for any reason, make sure the device is properly engaged when

you push the range back against the wall. If it is not, there is a possible risk of the range tipping over

and causing injury if you or a child stand, sit or lean on an open door.

Please refer to the Anti-Tip device information in this manual. Failure to take this precaution could

result in tipping of the range and injury.

WARNING ANTI-TIP DEVICE

IMPORTANT SAFETY NOTICE

The California Safe Drinking Water and Toxic Enforcement Act requires the Governor of California to

publish a list of substances known to the state to cause cancer, birth defects or other reproductive

harm, and requires businesses to warn customers of potential exposure to such substances.

The fiberglass insulation in self-clean ovens gives off a very small amount of carbon monoxide during

the cleaning cycle. Exposure can be minimized by venting with an open window or using a ventilation

fan or hood.

When using electrical appliances, basic safety precautions should be followed, including the following:

■ Use this appliance only for its intended

purpose as described in this Owner’s Manual.

■ Be sure your appliance is properly installed and

grounded by a qualified installer in accordance

with the provided installation instructions.

■ Have the installer show you the location of

the circuit breaker or fuse. Mark it for easy

reference.

■ Do not attempt to repair or replace any

part of your range unless it is specifically

recommended in this manual. All other

servicing should be referred to a qualified

technician.

■ Before performing any service, disconnect

the range power supply at the household

distribution panel by removing the fuse or

switching off the circuit breaker.

■ Do not leave children alone—children should

not be left alone or unattended in an area

where an appliance is in use. They should

never be allowed to sit or stand on any part

of the appliance.

■ Do not allow anyone to climb, stand or hang

on the door, storage drawer or cooktop. They

could damage the range and even tip it over,

causing severe personal injury.

SAFETY PRECAUTIONS

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

ge.com

■ Do not store flammable materials in an oven

or near the cooktop.

■

CAUTION:

Items of interest to children

should not be stored in cabinets above a range

or on the back of a range—children climbing

on the range to reach items could be seriously

injured.

■ Never wear loose-fitting or hanging garments

while using the appliance. Be careful when

reaching for items stored over the range.

Flammable material could be ignited if

brought in contact with hot surface units or

heating elements and may cause severe burns.

■ Use only dry pot holders—moist or damp

pot holders on hot surfaces may result in

burns from steam. Do not let pot holders

touch hot surface units or heating elements.

Do not use a towel or other bulky cloth in

place of pot holders.

■ Do not use water on grease fires. Never pick

up a flaming pan. Turn the controls off.

Smother a flaming pan on a surface unit

by covering the pan completely with

a well-fitting lid, cookie sheet or flat tray.

Use a multi-purpose dry chemical or

foam-type fire extinguisher.

■ Flaming grease outside a pan can be put

out by covering it with baking soda or, if

available, by using a multi-purpose dry

chemical or foam-type fire extinguisher.

■ Flame in the oven can be smothered

completely by closing the oven door and

turning the oven off or by using a multi-

purpose dry chemical or foam-type fire

extinguisher.

■ For your safety, never use your appliance

for warming or heating the room.

■ Do not let cooking grease or other flammable

materials accumulate in or near the range.

■ Do not touch the surface units, the heating

elements or the interior surface of the oven.

These surfaces may be hot enough to burn

even though they are dark in color. During and

after use, do not touch, or let clothing or other

flammable materials contact the surface units,

areas nearby the surface units or any interior

area of the oven; allow sufficient time for

cooling first.

■ Potentially hot surfaces include the cooktop,

areas facing the cooktop, oven vent opening,

surfaces near the opening, crevices around the

oven door.

■

REMEMBER:

The inside surface of the oven

may be hot when the door is opened.

■ Do not store or use combustible materials,

gasoline or other flammable vapors and liquids

in the vicinity of this or any other appliance.

■ Keep the hood and grease filters clean

to maintain good venting and to avoid

grease fires.

■ Teach children not to play with the controls

or any other part of the range.

■ Always keep dish towels, dish cloths, pot

holders and other linens a safe distance

from your range.

■ Always keep wooden and plastic utensils and

canned food a safe distance from your range.

■ Always keep combustible wall coverings,

curtains or drapes a safe distance from

your range.

WARNING!

SAFETY PRECAUTIONS

Cook meat and poultry thoroughly—meat to at least an INTERNAL temperature of 160°F and poultry to at least

an INTERNAL temperature of 180°F. Cooking to these temperatures usually protects against foodborne illness.

COOK MEAT AND POULTRY THOROUGHLY…

Do not operate the oven or cooktop controls if the glass is broken. Food splatter or cleaning solution

may penetrate a broken control panel or cooktop and create a risk of electrical shock. Contact a

qualified technician immediately should your glass control panel or cooktop become broken.

Safety Instructions Operating InstructionsSafety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

IMPORTANT SAFETY INFORMATION.

READ ALL INSTRUCTIONS BEFORE USING.

Use proper pan size—select cookware having flat bottoms large enough to cover the surface unit heating

element. The use of undersized cookware will expose a portion of the surface unit to direct contact and may

result in ignition of clothing. Proper relationship of cookware to surface unit will also improve efficiency.

■ Never leave the surface units unattended at

high heat settings. Boilovers cause smoking

and greasy spillovers that may catch on fire.

■ Only certain types of glass, glass ⁄ceramic,

earthenware or other glazed containers are

suitable for cooktop service; others may break

because of the sudden change in temperature.

■ To minimize the possibility of burns, ignition

of flammable materials and spillage, the handle

of a container should be turned toward the

center of the range without extending over

nearby surface units.

■ Always turn the surface units off before

removing cookware.

■ When preparing flaming foods under the

hood, turn the fan on.

■ Use care when touching the cooktop.

The glass surface of the cooktop will retain

heat after the controls have been turned off.

■ Keep an eye on foods being fried at high or

medium high heat settings.

■ Foods for frying should be as dry as possible.

Frost on frozen foods or moisture on fresh

foods can cause hot fat to bubble up and

over the sides of the pan.

■ Use little fat for effective shallow or deep

fat frying. Filling the pan too full of fat can

cause spillovers when food is added.

■ If a combination of oils or fats will be used

in frying, stir together before heating, or

as fats melt slowly.

■ Always heat fat slowly, and watch as it heats.

■ Use a deep fat thermometer whenever

possible to prevent overheating fat beyond

the smoking point.

■ Avoid scratching the glass cooktop. The

cooktop can be scratched with items such

as sharp instruments, rings or other jewelry,

and rivets on clothing.

■ Large scratches or impacts to glass doors or

cooktops can lead to broken or shattered glass.

■ Do not operate the radiant surface units if the

glass is broken. Spillovers or cleaning solution

may penetrate a broken cooktop and create a

risk of electrical shock. Contact a qualified

technician immediately should your glass

cooktop become broken.

■ Never use the glass cooktop surface as a

cutting board.

■ Do not place or store items that can melt or

catch fire on the glass cooktop, even when it

is not being used.

■ Be careful when placing spoons or other stirring

utensils on glass cooktop surface when it is in use.

They may become hot and could cause burns.

■ Clean the cooktop with caution. If a wet

sponge or cloth is used to wipe spills on a hot

surface unit, be careful to avoid steam burns.

Some cleaners can produce noxious fumes if

applied to a hot surface.

NOTE:

We recommend that you avoid wiping

any surface unit areas until they have cooled

and the indicator light has gone off. Sugar

spills are the exception to this. Please see the

Cleaning the glass cooktop

section.

■ When the cooktop is cool, use only the

CERAMA BRYTE

Ceramic Cooktop Cleaner

and the CERAMA BRYTE Ceramic Cooktop

Cleaning Pad to clean the cooktop.

■ To avoid possible damage to the cooking

surface, do not apply cleaning cream to

the glass surface when it is hot.

■ After cleaning, use a dry cloth or paper towel

to remove all cleaning cream residue.

■ Read and follow all instructions and warnings

on the cleaning cream labels.

■ Do not use plastic wrap to cover food. Plastic

may melt onto the surface and be very difficult

to remove.

RADIANT SURFACE UNITS

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

SAVE THESE INSTRUCTIONS

Safety Instructions Operating InstructionsSafety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

ge.com

■ Do not heat unopened food containers.

Pressure could build up and the container

could burst, causing an injury.

■ Keep the oven vent unobstructed.

■ Keep the oven free from grease buildup.

■ Place the oven rack in the desired position

while the oven is cool. If racks must be handled

when hot, do not let pot holder contact the

heating elements.

■ When using cooking or roasting bags in the

oven, follow the manufacturer’s directions.

■ Pulling out the rack to the stop-lock is a

convenience in lifting heavy foods. It is also

a precaution against burns from touching

hot surfaces of the door or oven walls.

■ Do not use the oven to dry newspapers.

If overheated, they can catch on fire.

■ Do not use the oven for a storage area. Items

stored in an oven can ignite.

■ Do not leave paper products, cooking utensils

or food in the oven when not in use.

■ Do not use aluminum foil to line oven bottoms.

Improper installation of aluminum foil may

result in a risk of electric shock or fire.

Stand away from the range when opening the oven door. Hot air or steam which escapes can cause

burns to hands, face and/or eyes.

WARNING!

OVEN

READ AND FOLLOW THIS SAFETY INFORMATION CAREFULLY.

Do not use oven cleaners. No commercial oven cleaner or oven liner protective coating of any kind

should be used in or around any part of the oven. Residue from oven cleaners will damage the inside

of the oven when the self-clean cycle is used.

■ Do not clean the door gasket. The door gasket

is essential for a good seal. Care should be

taken not to rub, damage or move the gasket.

■ Before self-cleaning the oven, remove shiny,

silver-colored oven racks (on some models)

and all other cookware.

■ Gray porcelain-coated oven racks (on some

models) may be cleaned in the oven during

the self-clean cycle.

■ Be sure to wipe up excess spillage before

starting the self-cleaning operation.

■ If the self-cleaning mode malfunctions, turn

the oven off and disconnect the power supply.

Have it serviced by a qualified technician.

■ Clean only parts listed in this Owner’s Manual.

SELF-CLEANING UPPER OVEN

■ The purpose of the WARM setting of the lower

oven drawer is to hold hot cooked foods at

serving temperature. Always start with hot food;

cold food cannot be heated or cooked in the

WARM setting of the lower oven drawer.

■ Do not use the drawer to dry newspapers.

If overheated, they can catch on fire.

■ Do not leave paper products, plastics, canned

food or combustible materials in the drawer.

■ Never leave jars or cans of fat drippings in or

near your drawer.

■ Do not warm food in the drawer for more than

two hours.

■ Never place, use or self-clean the lower oven

drawer pan in the upper oven.

■

Do not touch the heating element or the interior

surface of the drawer.

These surfaces may be

hot enough to burn.

REMEMBER:

The inside surface of the drawer

may be hot when the drawer is opened.

■ Use care when opening the drawer. Open the

drawer a crack and let hot air or steam escape

before removing or replacing food. Hot air or

steam which escapes can cause burns to hands,

face and/or eyes.

■ Do not use aluminum foil to line the lower

oven drawer. Foil is an excellent heat insulator

and will trap heat beneath it. This will upset

the performance of the drawer and it could

damage the interior finish.

LOWER OVEN DRAWER

(on some models)

Temperature Limiter

Every radiant surface unit has a

temperature limiter.

The temperature limiter protects the

glass cooktop from getting too hot.

The temperature limiter may cycle the

units off for a time if:

■

The pan boils dry.

■

The pan bottom is not flat.

■

The pan is off center.

■

There is no pan on the unit.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

About the radiant surface units.

NOTE: Throughout this manual, features and appearance may vary from your model.

Never cook directly on the glass.

Always use cookware.

About the radiant surface units

The radiant cooktop features heating

units beneath a smooth glass surface.

Cooktop temperatures increase with

the number of surface units that are

on. With 3 or 4 units turned on, surface

temperatures are high. Always use

caution when touching the cooktop.

An indicator light will come on when the

surface unit is turned on.

The appropriate

HOT SURFACE

indicator

light will glow when its corresponding

radiant element is turned on and will

remain on until the surface has cooled

below 150°F.

NOTE:

Hot surface indicator light will:

■

Come on when the surface unit is

turned on.

■

Stay on even after the unit is turned off.

■

Glow brightly until the unit has cooled

below 150°F.

NOTE: A slight odor is normal when a new

cooktop is used for the first time. It is caused by

the heating of new parts and insulating materials

and will disappear in a short time.

NOTE: On models with light-colored glass

cooktops, it is normal for the cooking zones to

change color when hot or cooling down. This is

temporary and will disappear as the glass cools

to room temperature.

It is safe to place hot cookware from the

oven or surface on the glass cooktop

when the surface is cool.

Even after the surface units are turned

off, the glass cooktop retains enough

heat to continue cooking. To avoid

overcooking, remove pans from the

surface units when the food is cooked.

Avoid placing anything on the surface

unit until it has cooled completely.

■

Water stains (mineral deposits) are removable

using the cleaning cream or full strength white

vinegar.

■

Use of window cleaner may leave an iridescent

film on the cooktop. The cleaning cream will

remove this discoloration.

■

Don’t store heavy items above the cooktop.

If they drop onto the cooktop, they can cause

damage.

■

Do not use the surface as a cutting board.

;;

;

;;;;;;;;

;;;;;;;;;

;;

;;;;

;

;;

;

;;

;;;

;;

;

;;

SURFACE

COOKING

;;

;

;;

;

;;

;

;;

;

;;;

;

;;

;

;;;;;

;;;;;;

;

;;

;

;;;;;

;;;

OFF CENTER

Always place the pan in the center of

the surface unit you are cooking on.

;;

;

;;

;

;;

;

;;

;

;;

;

;;

;

;;;;;;

;

;;;;

;

;;;

DRAGGING

Do not slide cookware across the

control or cooktop surface because it

can scratch the glass. The glass is

scratch-resistant, not scratchproof.

Safety Instructions Operating InstructionsSafety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Stainless Steel:

recommended

Aluminum:

heavy weight recommended

Good conductivity. Aluminum residues

sometimes appear as scratches on the

cooktop, but can be removed if cleaned

immediately. Because of its low melting

point, thin weight aluminum should not

be used.

Copper Bottom:

recommended

Copper may leave residues which can

appear as scratches. The residues can

be removed, as long as the cooktop is

cleaned immediately. However, do not let

these pots boil dry. Overheated metal can

bond to glass cooktops. An overheated

copper bottom pot will leave a residue

that will permanently stain the cooktop

if not removed immediately.

Porcelain Enamel Covered Cast Iron:

recommended

As long as the cookware is covered

completely with porcelain enamel, this

cookware is recommended. Caution is

recommended for cast iron cookware

that is not completely covered with

smooth porcelain enamel, as it may

scratch the glass ceramic cooktop.

Glass-ceramic:

usable, but not recommended

Poor performance. May scratch the

surface.

Stoneware:

usable, but not recommended

Poor performance. May scratch the

surface.

Check pans for flat bottoms by using

a straight edge.

Pans with rounded, curved, ridged or

warped bottoms are not

recommended.

Home Canning Tips

Be sure the canner is centered over the

surface unit.

Make sure the canner is flat on the

bottom.

To prevent burns from steam or heat,

use caution when canning.

Use recipes and procedures from

reputable sources. These are available

from manufacturers such as Ball

and

Kerr

and the Department of Agriculture

Extension Service.

Flat-bottomed canners are recommended.

Use of water bath canners with rippled

bottoms may extend the time required to

bring the water to a boil.

ge.com

The following information will help you choose cookware which will give good performance on glass cooktops.

Use only flat-bottomed woks.

Wok Cooking

We recommend that you use only a flat-bottomed

wok. They are available at your local retail store.

Do not use woks that have support rings.

Do not use round-bottom woks. You

could be seriously burned if the wok

tipped over.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

To turn on a single surface unit:

Touch the

ON/OFF

pad, then touch

the

(+)

(–)

pad.

Use the

(+)

(–)

pad to choose the

desired power setting.

To turn off a single surface unit, touch

the

ON/OFF

pad again.

Single Surface Unit—Cook Settings

Surface Unit Cook Settings

The controls for the radiant surface

units allow for 10 different heat settings:

LO, 2–9 and HI. The heating element

may not visibly glow at low heat settings.

NOTE: When changing from a high heat setting to

a lower heat setting, the surface unit may stop

glowing. This is normal. The unit is still on and hot.

NOTE: This cooktop has a rapid heat-up feature.

If the cooktop is cool when turned on, it will glow

red for a short period of time until the desired

power setting is reached.

Tri-Ring Burner

To use the multi-size burner:

Touch the

ON/OFF

pad for the front

right surface unit.

Use the

(+)

(–)

pad to set the desired

power setting.

Touch the

BURNER SIZE

pad as

needed to select the desired burner

size. When first selected, the 12″ size

is on. Touch again for the 9″ and

again for the 6″.

The light next to the

BURNER SIZE

pad

indicates which size surface unit is on.

To turn the surface unit off, touch the

ON/OFF

pad.

■ At high or medium-high settings, never

leave food unattended. Boilovers cause

smoking; greasy spillovers may catch

on fire.

■ It is safe to place hot cookware

from the oven or surface units on the

glass-ceramic surface when it is cool.

NOTE: Cooktop temperatures increase with the

number of surface units that are on. With 3 or

more units turned on, surface temperatures are

high, so be careful when touching the cooktop.

The hot surface indicator light(s) will remain lit

after the surface unit is off until the surface has

cooled below 150°F.

Using Heat Settings

Using the surface units—Touch pad-controlled models.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Precise Warm Feature

To turn on the precise warm feature:

Touch the

ON/OFF

pad, then

touch the

PRECISE WARM

pad.

The surface unit will turn on to

warmer setting W3 (medium setting).

Use the

(+)

(–)

pad to choose

additional settings between

W1 (lowest setting) and W5

(highest setting).

To change from the warmer settings

to regular cooking settings, press the

PRECISE WARM

pad again. The surface

unit will be on power setting LO. The

surface unit may then be set to the

desired regular cooking setting using the

(+)

(–)

pads. To turn off the surface unit,

whether using regular cooking settings or

warmer settings, touch the

ON/OFF

pad.

Food Type Control Setting

Breads/Pastries W1

Vegetables W2

Sauces W3

Soups (cream) W3

Stews W4

Hot Beverages W5

Soups (liquid) W5

The chart above shows initial suggested settings only.

The temperature, type and amount of food, type of pan

and the time held will affect the quality of the food.

CAUTION: Do not warm food on a

PRECISE WARM surface unit setting for more

than 2 hours.

Do not use plastic wrap to cover food. Plastic

may melt onto the surface and be very difficult

to remove.

Use only cookware recommended for

top-of-range cooking.

CAUTION: Always start with

hot food. Do not use to heat cold food.

Placing uncooked or cold food on a

precise warm setting could result in

foodborne illness.

For best results, all food on

PRECISE

WARM

should be covered with a lid or

aluminum foil.

Always use pot holders or oven mitts

when removing food from a precise warm

surface unit as cookware will be hot.

A hot surface indicator light will glow

when the glass surface is hot and will

remain on until the surface has cooled

below 150°F.

ge.com

All single burners may be used for

either regular cooking or precise

warming.

Consumer Support

Troubleshooting Tips

Care and Cleaning Operating Instructions Safety Instructions

How to Set

Push the knob in and turn in either

direction to the setting you want.

At both

OFF

and

the control

clicks

into position. You may hear

slight

clicking

sounds during cooking,

indicating the control is keeping the

power level you set.

HOT SURFACE

indicator light, on the

cooktop, will glow when any radiant

element is turned on. It will remain

on until the surface is cooled to

approximately 150°F.

Hot surface indicator light will:

■

come on when the unit is hot to the touch.

■

stay on even after the unit is turned off.

■

glow until the unit is cooled to approximately

150°F.

Be sure you turn the control knob to

OFF when you finish cooking.

Using the Bridge Burner (on some models)

To use the bridge burner, turn the

left front control knob to the

BRIDGE

BURNER

settings.

For full bridge surface unit operation,

also turn on the left rear surface unit.

To use only the front surface unit, turn

the control knob to the

FRONT BURNER

settings.

Using the surface units—Knob-controlled models.

Tri-Ring Surface Element (on some models)

The rear center surface element offers 3 cooking

areas to match the size of the cookware you

are using.

To use the largest cooking area, push in

and turn the

SELECTOR

knob to

″. Push

and turn the control knob to the desired

setting.

To use the medium cooking area, press

and turn the

SELECTOR

knob to

″. Push

down and turn the control knob to the

desired setting.

To use the smallest cooking area, turn

the

SELECTOR

knob to

″. Push and turn

the control knob to the desired setting.

This will activate only the smallest inside

heating area.

BURNER

SIZE

12"

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

ge.com

Using the Warming Zone (on some models)

The

WARMING ZONE

is located in the

back center of the glass surface. Always

start with hot food. Do not use to heat

cold food. Placing uncooked or cold food

on the

WARMING ZONE

could result in

foodborne illness.

To use the

WARMING ZONE

Touch the

WARMING ZONE ON/OFF

pad.

Touch the

1 (LO), 2 (MED)

3 (HI)

pad

to select the desired control setting.

Touch the

START

pad.

“WARMER

ON”

will be in the control display.

To turn off the

WARMING ZONE

Touch the

WARMING ZONE ON/OFF

pad.

NOTE: The CLEAR/OFF pad will not turn off the

WARMING ZONE.

For best results, all foods on the

WARMING ZONE

should be covered with

a lid or aluminum foil.

Always use pot holders or oven mitts

when removing food from the

WARMING ZONE

, as cookware will be hot.

HOT

surface indicator light will glow

when the glass surface is hot and will

remain on until the surface is cool

enough to touch. Lower settings may

not heat the glass surface enough to

cause the

HOT

surface indicator light

to come on.

NOTE: The WARMING ZONE will not glow red

like the cooking elements.

Food Type Control Setting

Sauces LO

Soups (cream) Medium

Stews Medium

Vegetables Medium

Hot Beverages HI

Soups (other than cream) HI

Breads/Pastries LO

The chart above shows initial suggested settings only.

The temperature, type and amount of food, type of pan

and the time held will affect the quality of the food.

CAUTION: Do not leave food on the

WARMING ZONE for more than 2 hours.

■

Do not use plastic wrap to cover food. Plastic

may melt onto the surface and be very difficult

to clean.

■

Use only cookware recommended for

top-of-range cooking.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

BAKE Pad

Touch to select the bake function.

BROIL HI/LO Pad

Touch to select the broil function.

CONVECTION BAKE Pad

Touch to select baking with the convection

function.

CONVECTION ROAST Pad

Touch to select roasting with the

convection function.

PROOF Pad

Touch to select a warm environment useful

for rising yeast-leavened products.

START Pad

Must be touched to start any cooking or

cleaning function.

Display

Shows the time of day, oven temperature,

whether the oven is in the bake, broil or

self-cleaning mode and the times set for

the timer or automatic oven operations.

If “F– and a number or letter” flash in the display and

the oven control signals, this indicates a function

error code. Touch the CLEAR/OFF pad. Allow the oven to

cool for one hour. Put the oven back into operation. If the

function error code repeats, disconnect the power to the

oven and call for service.

If your oven was set for a timed oven operation

and a power outage occurred, the clock and all

programmed functions must be reset.

The time of day will flash in the display when there

has been a power outage.

SELF CLEAN STD/LO Pad

Touch to select self-cleaning function. See

the

Using the self-cleaning oven

section.

OVEN LIGHT ON/OFF Pad

Touch to turn the oven light on or off.

DELAY START Pad

Use along with

COOKING TIME

SELF CLEAN STD/LO

pads to set the oven

to start and stop automatically at a time

you set.

COOKING TIME Pad

Touch this pad and then touch the number

pads to set the amount of time you want

your food to cook. The oven will shut off

when the cooking time has run out.

CLEAR/OFF Pad

Touch to cancel

ALL

oven operations

except the clock and timer.

CLOCK Pad

Touch before setting the clock.

Number Pads

Use to set any function requiring numbers

such as the time of day on the clock, the

timer, the oven temperature, the internal

food temperature, the start time and

length of operation for timed baking

and self-cleaning.

KITCHEN TIMER ON/OFF Pad

Touch to select the timer feature.

PROBE Pad

Touch when using the probe to cook food.

WARM Pad

Touch to keep cooked foods warm. See the

How to Set the Oven for Warming

section.

RANGE LOCKOUT Pad

Touch this pad, then touch

START

lock/unlock the range touch pad controls.

Oven Control, Clock and Timer Features and Settings

Features and appearance

may vary.

On some models

Using the oven controls.

NOTE: Throughout this manual, features and appearance may vary from your model.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

BAKE Pad

Touch to select the bake function.

BROIL HI/LO Pad

Touch to select the broil function.

CONVECTION BAKE Pad

Touch to select baking with the convection

function.

CONVECTION ROAST Pad

Touch to select roasting with the

convection function.

PROOF Pad

Touch to select a warm environment useful

for rising yeast-leavened products.

START Pad

Must be touched to start any cooking or

cleaning function.

Display

Shows the time of day, oven temperature,

whether the oven is in the bake, broil or

self-cleaning mode and the times set for

the timer or automatic oven operations.

If “F– and a number or letter” flash in the display and

the oven control signals, this indicates a function

error code. Touch the CLEAR/OFF pad. Allow the oven to

cool for one hour. Put the oven back into operation. If the

function error code repeats, disconnect the power to the

oven and call for service.

If your oven was set for a timed oven operation

and a power outage occurred, the clock and all

programmed functions must be reset.

The time of day will flash in the display when there

has been a power outage.

SELF CLEAN STD/LO Pad

Touch to select self-cleaning function. See

the

Using the self-cleaning oven

section.

OVEN LIGHT ON/OFF Pad

Touch to turn the oven light on or off.

DELAY START Pad

Use along with

COOKING TIME

SELF CLEAN STD/LO

pads to set the oven

to start and stop automatically at a time

you set.

COOKING TIME Pad

Touch and then touch the number pads to

set the amount of time you want your food

to cook. The oven will shut off when the

cooking time has run out.

CLEAR/OFF Pad

Touch to cancel

ALL

oven operations

except the clock and timer.

CLOCK Pad

Touch before setting the clock.

Number Pads

Use to set any function requiring numbers

such as the time of day on the clock, the

timer, the oven temperature, the internal

food temperature, the start time and

length of operation for timed baking

and self-cleaning.

KITCHEN TIMER ON/OFF Pad

Touch to select the timer feature.

PROBE Pad

Touch when using the probe to cook food.

WARM Pad

Touch to keep cooked foods warm. See the

How to Set the Oven for Warming

section.

WARMING ZONE ON/OFF Pad

Touch to select the warming zone

function.

Oven Control, Clock and Timer Features and Settings

Features and appearance

may vary.

On some models

ge.com

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Preheating and Pan Placement

Preheat the oven if the recipe calls for it.

Preheating is necessary for good results

when baking cakes, cookies, pastry and

breads.

To preheat, set the oven at the correct

temperature. The control will beep when

the oven is preheated and the display will

show your set temperature. This will take

approximately 10–15 minutes.

Baking results will be better if baking

pans are centered in the oven as much

as possible. If baking with more than one

pan, place the pans so each has at least

1″ to 1

⁄2″ of air space around it.

If baking four cake layers at the same time,

place two layers on rack B and two layers on

rack D. Stagger pans on the rack so one is

not directly above the other.

Type of Food Rack Position

Frozen pies (on cookie sheet) D

Angel food cake A

Bundt or pound cakes B or C

Biscuits, muffins, brownies, C or D

cookies, cupcakes,

layer cakes, pies

Casseroles C or D

Turkey A

Before you begin…

The racks have stops, so that when placed

correctly on the supports, they will stop

before coming completely out, and will

not tilt.

When placing and removing cookware,

pull the rack out until it stops.

On some models, the bake heating

element is under the oven floor. Do not

place foods on the oven bottom for

cooking.

To remove a rack,

pull it toward you,

tilt the front end up and pull it out.

To replace,

place the end of the rack

(stop-locks) on the support, tilt up the

front and push the rack in.

CAUTION: When you are using a

rack in the lowest position (A), you will need to

use caution when pulling the rack out. We

recommend that you pull the rack out several

inches and then, using two pot holders, pull the

rack out by holding the sides of it. The rack is low

and you could be burned if you place your hand in

the middle of the rack and pull all the way out. Be

very careful not to burn your hand on the door

when using the rack in the lowest position (A).

The oven has 6 rack positions.

How to Set the Upper Oven for Baking or Roasting

Touch the

BAKE

pad.

Touch the number pads to set

the desired temperature.

Touch the

START

pad.

NOTE:

You will hear the convection fan while

the oven is preheating. The fan will stop

after the oven is preheated and the display

shows your set temperature. This is normal.

Check food for doneness at

minimum time on recipe. Cook

longer if necessary.

Touch the

CLEAR/OFF

pad when

cooking is complete.

Do not place foods directly on the

oven floor.

Using the upper oven.

To avoid possible burns, place the racks in the desired position before you turn the oven on.

Oven rack

Aluminum Foil

Do not use aluminum foil on the bottom

of the oven.

Never entirely cover a rack with

aluminum foil. This will disturb the heat

circulation and result in poor baking.

A smaller sheet of foil may be used to

catch a spillover by placing it on a lower

rack several inches below the food.

How to Set the Upper Oven for Broiling

Leave the door open to the broil stop position.

The door stays open by itself, yet the proper

temperature is maintained in the oven.

Place the meat or fish on a broiler

grid in a broiler pan designed

for broiling.

Follow suggested rack positions in

the

Broiling Guide.

Touch the

BROIL HI/LO

pad once for

HI Broil.

To change to

LO Broil,

touch the

BROIL HI/LO

pad again.

Use

LO Broil

to cook foods such as

poultry or thick cuts of meat thoroughly

without over-browning them.

Touch the

START

pad.

When broiling is finished, touch the

CLEAR/OFF

pad.

NOTE: Broil and self-clean settings will not work

if the temperature probe is plugged in.

The size, weight, thickness,

starting temperature

and your preference

of doneness will affect

broiling times. This guide

is based on meats at

refrigerator temperature.

† The U.S. Department of Agriculture

says “Rare beef is popular, but you

should know that cooking it to only

140°F means some food poisoning

organisms may survive.” (Source:

Safe Food Book. Your Kitchen

Guide. USDA Rev. June 1985.)

If your range is connected to 208 volts,

rare steaks may be broiled by preheating

the broiler and positioning the oven rack

one position higher.

ge.com

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Broiling Guide

Quantity and/ Rack First Side Second Side

Food or Thickness Position Time (min.) Time (min.) Comments

Ground Beef 1 lb. (4 patties) E 9 6 Space evenly. Up to 8

Well Done 1/2 to 3/4″ thick E 11 10 patties take about the

same time.

Beef Steaks

Rare† 1″ thick F 7 5 Steaks less than 1″

Medium 1 to 1

⁄2 lbs. E 9 6–7 thick cook through

Well Done E 11 8–9 before browning. Pan

frying is recommended.

Slash fat.

Rare† 1

⁄2″ thick D 14 11

Medium 2 to 2

⁄2 lbs. D 18 14–16

Well Done D 22 20

Chicken 1 whole cut up C 25 10 Broil skin-side-down

2 to 2

⁄2 lbs., first.

split lengthwise

2 Breasts C 25 10–15

Lobster Tails 2–4 C 18–20 Do not Cut through back of

10 to 12 oz. each turn shell. Spread open.

over. Brush with melted

butter before broiling

and after half of

broiling time.

Fish Fillets 1/4 to 1/2″ thick E 6 5 Handle and turn very

carefully. Brush with

lemon butter before

and during cooking,

if desired.

Ham Slices 1/2″ thick D 6 6 Increase time 5 to 10

(precooked) minutes per side for

⁄2″ thick or home-

cured ham.

Pork Chops 2 (1/2″ thick) E 10 10 Slash fat.

Well Done 2 (1″ thick) about 1 lb. D 15 15

Salmon Steaks 2 (1″ thick) D 10 7–8 Grease pan. Brush

4 (1″ thick) about 1 lb. D 12 10 steaks with melted

butter.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

How to Set an Immediate Start and Automatic Stop

The oven will turn on immediately and cook for

a selected length of time. At the end of the

cooking time the oven will turn off automatically.

Touch the

BAKE

pad.

Touch the number pads to set the

desired oven temperature.

Touch the

COOKING TIME

pad.

NOTE: If your recipe requires preheating, you may

need to add additional time to the length of the

cooking time.

Touch the number pads to set the

desired length of cooking time. The

minimum cooking time you can set

is 1 minute.

The oven temperature that you set

and the cooking time that you

entered will be in the display.

Touch the

START

pad.

NOTE: An attention tone will sound if you are using

timed baking and do not touch the START pad.

The oven will turn

, and the display will

show the cooking time countdown and the

changing temperature starting at 100°F.

(The temperature display will start to

change once the oven temperature reaches

100°F.) When the oven reaches the

temperature you set, 3 beeps will sound.

The oven will continue to cook for

the set amount of time, then turn off

automatically, unless the WARM feature

was set. See the

How to Set the Oven for

Warming

section.

Touch the

CLEAR/OFF

pad to clear

the display if necessary. Remove the

food from the oven. Remember,

even though the oven turns off

automatically, food left in the oven

will continue cooking after the oven

turns off.

How to Set a Delayed Start and Automatic Stop

The oven will turn on at the time of day you set,

cook for a specific length of time and then turn off

automatically.

Make sure the clock shows the correct

time of day.

Touch the

BAKE

pad.

Touch the number pads to set the

desired oven temperature.

Touch the

COOKING TIME

pad.

NOTE: If your recipe requires preheating, you may

need to add additional time to the length of the

cooking time.

Touch the number pads to set the

desired length of cooking time. The

minimum cooking time you can set

is 1 minute.

The oven temperature that you set

and the cooking time that you

entered will be in the display.

Touch the

DELAY START

pad.

Touch the number pads to set the

time of day you want the oven to

turn on and start cooking.

Touch the

START

pad.

NOTE: An attention tone will sound if you are using

timed baking and do not touch the START pad.

NOTE: If you would like to check the times

you have set, touch the DELAY START pad to

check the start time you have set or touch the

COOKING TIME pad to check the length

of cooking time you have set.

When the oven turns

at the time

of day you set, the display will show the

cooking time countdown and the

changing temperature starting at 100°F.

(The temperature display will start to

change once the oven temperature

reaches 100°F.) When the oven reaches

the temperature you set, beeps will sound.

The oven will continue to cook for

the set amount of time, then turn off

automatically, unless the WARM feature

was set. See the

How to Set the Oven for

Warming

section.

Touch the

CLEAR/OFF

pad to clear

the display if necessary. Remove the

food from the oven. Remember,

even though the oven turns off

automatically, food left in the oven

will continue cooking after the oven

turns off.

Using the timed baking and roasting features. (on some models)

NOTE: Foods that spoil easily—such as milk, eggs, fish, stuffings, poultry and pork—should not be allowed to sit for

more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure that

the oven light is off because heat from the bulb will speed harmful bacteria growth.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Insert the probe fully into the food.

Plug the probe into the outlet in the

oven. Make sure it’s pushed all the

way in. Close the oven door. Make

sure the probe cable is not touching

the broil element.

Touch the

PROBE

pad.

Touch the number pads to set the

desired internal food or meat

temperature. The maximum

internal temperature for the food

that you can set is 200ºF.

Touch the

BAKE

pad.

Touch the number pads to set the

desired oven temperature.

Touch the

START

pad.

The display will flash if the probe is inserted

into the outlet and you have not set a probe

temperature and touched the START pad.

After the internal temperature of the

food reaches 100°F, the changing internal

temperature will be shown in the display.

When the internal temperature of

the food reaches the number you

have set, the probe and the oven

turn off and the oven control signals.

To stop the signal, touch the

CLEAR/OFF

pad. Use hot pads to

remove the probe from the food.

Do not use tongs to pull on it—they

might damage it.

■

If the probe is removed from the oven while

probe cooking, the oven will not automatically

turn off.

To change the oven temperature during

the Bake/Roast cycle, touch the

BAKE

pad and then the number pads to set the

new temperature.

■

You can use the Kitchen Timer even though

you cannot use timed oven operations

while using the probe.

Use of probes other than the one

provided with this product may result in

damage to the probe or oven control.

Use the handles of the probe and plug

when inserting and removing them from

the food and outlet.

■

To avoid damaging your probe, do not use

tongs to pull on the cable when removing it.

■

To avoid breaking the probe, make sure food

is completely defrosted before inserting.

After preparing the meat and placing it

on a trivet or a broiler pan grid designed

for broiling, follow these directions for

proper probe placement.

Insert the probe completely into the

meat. It should not touch bone, fat

or gristle.

NOTE: Failure to fully insert the probe into the

meat may result in poor cooking performance

because the probe will sense the oven air vs.

the food temperature.

■

Never leave your probe inside the oven during

a self-cleaning or broil cycle.

■

Do not store the probe in the oven.

CAUTION: To prevent possible burns,

do not unplug the probe from the oven outlet until

the oven has cooled.

For roasts with no bone, insert the probe

into the meatiest part of the roast. For

bone-in ham or lamb, insert the probe

into the center of the lowest large muscle.

Insert the probe into the center of dishes

such as meat loaf or casseroles.

Insert the probe into the meatiest part of

the inner thigh from below and parallel

to the leg of a whole turkey.

NOTE: Self-clean and Broil settings will not work

if the temperature probe is plugged in.

The temperature probe has a

skewer-like probe at one end and

a plug at the other end that goes

into the outlet in the oven.

How to Set the Upper Oven For Baking/Roasting When Using the Probe

(on some models)

Plug

Cable

Handles

Probe

Using the probe. (on some models) ge.com

For many foods, especially roasts and poultry, internal food temperature is the best test for doneness. The

temperature probe takes the guesswork out of roasting by cooking foods to the exact doneness you want.

Read and remove label

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

To Set the Clock

The clock must be set to the correct time

of day for the automatic oven timing

functions to work properly. The time of

day cannot be changed during a timed

baking or self-cleaning cycle.

Touch the

CLOCK

pad.

Touch the number pads.

Touch the

START

pad.

Make sure the clock is set to the

correct time of day.

To Set the Kitchen Timer

Touch the

KITCHEN TIMER

ON/OFF

pad.

Touch the number pads until the

amount of time you want shows

in the display. For example, to set

2 hours and 45 minutes, touch

2, 4

and

in that order. If you make a

mistake touch the

KITCHEN TIMER

ON/OFF

pad and begin again.

Touch the

START

pad.

After touching the START pad, SET disappears;

this tells you the time is counting down, although

the display does not change until one minute has

passed. Seconds will not be shown in the display

until the last minute is counting down.

When the Kitchen Timer reaches

:00

the control will beep 3 times followed

by one beep every 6 seconds until

the

KITCHEN TIMER ON/OFF

pad

is touched.

The 6-second tone can be canceled by following

the steps in the Special features of your oven

control section under Tones at the End of a

Timed Cycle.

The Kitchen Timer is a minute timer only.

The Kitchen Timer does not control

oven operations. The maximum

setting on the Kitchen Timer is 9 hours

and 59 minutes.

To Reset the Kitchen Timer

If the display is still showing the time

remaining, you may change it by

touching the

KITCHEN TIMER ON/OFF

pad,

then touch the number pads until the

time you want appears in the display.

If the remaining time is not in the display

(clock, delay start or cooking time are in

the display), recall the remaining time by

touching the

KITCHEN TIMER ON/OFF

pad

and then touching the number pads to

enter the new time you want.

To Cancel the Kitchen Timer

Touch the

KITCHEN TIMER ON/OFF

pad twice.

Your control will allow you to lock out the touch

pads so they cannot be activated when pressed.

To lock/unlock the touch pad controls:

Touch the

RANGE LOCKOUT

pad,

then touch the

START

pad.

The surface unit displays (on models

so equipped) will show

and the

oven display will show

Loc On

for

several seconds, then they will go

blank until a cooking pad is touched.

To unlock the control, touch the

RANGE LOCKOUT

pad, then touch

the

START

pad.

If the range control is locked and a

cooking pad is touched, the appropriate

surface display (on models so equipped)

or the oven display will show that the

control is locked.

■

The RANGE LOCKOUT mode affects all

touch pads. No touch pads will work when

this feature is activated.

Range Lockout (on some models)

Using the clock, kitchen timer and control lockout.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

To Adjust the Thermostat

Touch the

BROIL HI/LO

and

BAKE

pads at the same time until the

display shows

SF.

Touch the

BAKE

pad. A two digit

number shows in the display.

Touch

BAKE

again to alternate

between increasing and decreasing

the oven temperature.

The oven temperature can be

adjusted up to (+) 35ºF hotter or (-)

35ºF cooler. Touch the number pads

the same way you read them. For

example, to change the oven

temperature 15ºF, touch

and

When you have made the

adjustment, touch the

START

pad to

go back to the time of day display.

Use your oven as you would normally.

Adjust the upper oven thermostat—Do it yourself!

You may find that your new oven cooks differently than the one it replaced. Use your new oven for a few weeks to

become more familiar with it. If you still think your new oven is too hot or too cold, you can adjust the thermostat

yourself.

Do not use thermometers, such as those found in grocery stores, to check the temperature setting of your oven.

These thermometers may vary 20–40 degrees.

NOTE: This adjustment will only affect baking and roasting temperatures; it will not affect broiling, convection or

self-cleaning temperatures. The adjustment will be retained in memory after a power failure.

The type of margarine will affect baking performance!

Most recipes for baking have been developed using high fat products such as butter or margarine (80% fat). If you

decrease the fat, the recipe may not give the same results as with a higher fat product.

Recipe failure can result if cakes, pies, pastries, cookies or candies are made with low fat spreads. The lower the

fat content of a spread product, the more noticeable these differences become.

Federal standards require products labeled “margarine” to contain at least 80% fat by weight. Low fat spreads, on the

other hand, contain less fat and more water. The high moisture content of these spreads affects the texture and flavor

of baked goods. For best results with your old favorite recipes, use margarine, butter or stick spreads containing at least

70% vegetable oil.

Your control will allow you to lock out the touch

pads so they cannot be activated when pressed.

To lock/unlock the touch pad controls:

Touch and hold the

and

pads

at the same time until the control

beeps.

The oven display will show

Loc On

for several seconds, then it will go

blank until a cooking pad is touched.

To unlock the control, touch and

hold the

and

pads at the same

time until the control beeps.

If the range control is locked and a

cooking pad is touched, the oven display

will show that the control is locked.

■

On models with CONTROL LOCKOUT only,

the oven will be locked out. The knob-controlled

surface units will still be active.

Control Lockout (on some models)

ge.com

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Using the lower oven drawer. (on some models)

To Use the Lower Oven Drawer

Push in and turn the lower oven

drawer knob to any desired setting.

Allow the lower oven drawer to

preheat.

■ The ON signal light is located above the

knob and glows when the knob is in the

ON position. It remains ON until the

knob is moved to the OFF position.

■ The “Heating” signal light is located

below the knob and glows when the

heating elements are active. Preheat is

complete after the “Heating” signal has

turned off for the first time after the

knob is turned on.

NOTES:

■

Always use the included drawer rack when

using the lower oven drawer.

■

The lower oven drawer cannot be used during

a self-clean cycle of the upper oven.

■

Do not put food, foil or cookware directly on

the bottom of the lower oven drawer. Always

use the included drawer rack.

■

If foods require a cover, use only foil or lids

able to withstand baking temperatures. Do not

use plastic.

■

Maximum height of foods that can be baked

in the lower oven drawer is 3

⁄

″

■

Do not put liquid or water in the lower oven

drawer.

■

Never place plastics, paper, canned foods or

combustible material in the lower oven drawer.

The lower oven drawer may be used to bake foods using the same times and temperatures as a standard oven. Foods

ideal for baking in the lower oven drawer include pizza, frozen foods, casseroles, biscuits, rolls and many desserts.

Push in and turn the lower oven

drawer knob to any desired setting.

When Using the Lower Oven Drawer Warm Setting

The WARM SETTING of the lower oven drawer

can be used to keep hot cooked foods at serving

temperatures. Always start with hot food. Do not

use the WARM SETTING to heat cold food other

than crisping crackers, chips or dry cereal.

NOTE: The beginning temperature of the

food, the amount of food, the type of food, the

container and the amount of time the food is in

the drawer will affect the quality and ending

temperature of the food.

Push in and turn the control knob

to the warm setting.

The lower oven drawer uses less energy than the upper oven.

Allow the following approximate times for preheating:

Desired Lower Preheat

Oven Temperature Time

WARM 10 minutes

350°F 15 minutes

425°F 25 minutes

Because heated air is circulated evenly

throughout the oven, foods can be

baked with excellent results using

multiple racks.

Multi-rack baking may increase cook

times slightly for some foods but the

overall result is time saved. Cookies,

muffins, biscuits and other quickbreads

give very good results with multi-rack

baking.

To cook food on more than one rack in

convection bake, use

CONVECTION BAKE

MULTI

When baking on 3 racks, place one

rack in the second (B) position, one rack

in the fourth (D) position and one rack

in the sixth (F) position.

For two-rack baking, place one rack

in the second (B) rack position. Place

the other rack in the fourth (D) rack

position.

Multi-Rack Convection Baking

Multi-rack position.

When convection baking with only 1 rack, use

CONVECTION BAKE 1 RACK and follow the

rack positions recommended in the Using the

oven section.

■

Ideal for baked foods cooked on 1 rack.

1-Rack Convection Baking

The convection oven comes with two

convection baking modes started by

touching the

CONVECTION BAKE MULTI/

1 RACK

pad once

twice, depending

on your cooking need:

MULTI—

for convection cooking on more

than one rack. Touch the

CONVECTION

BAKE MULTI/1 RACK

pad

once

. See the

Multi-Rack Convection Baking

section below.

1 RACK—

for convection cooking on one

rack only. Touch the

CONVECTION BAKE

MULTI/1 RACK

pad

twice

. See the

1-Rack

Convection Baking

section below.

Introduction

Convection Fan Operation

In a convection oven, a fan circulates hot air over,

under and around the food.

This circulating hot air is evenly distributed

throughout the oven cavity. As a result, foods are

evenly cooked and browned—often in less time

with convection heat.

NOTE:

To maximize cooking evenness,

the fan is designed to rotate in both

directions, with a pause in between.

This is normal.

The convection fan shuts off when the

oven door is opened.

DO NOT

leave the

door open for long periods of time while

using convection cooking or you may

shorten the life of the convection heating

element.

Using the convection oven. (on some models) ge.com

Adapting Recipes…

You can use your favorite recipes in the

convection oven.

When convection baking, the Auto

Recipe

™

Conversion feature automatically

reduces the set regular baking temperature

by the recommended 25°F. See Auto

Recipe

™

Conversion in the Special

Features section.

■

Use pan size recommended.

■

Some package instructions for frozen

casseroles or main dishes have been

developed using commercial convection ovens.

For best results in this oven, preheat the oven

and use the temperature on the package.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Touch the

CONVECTION BAKE MULTI/

1 RACK

pad once for multi-rack

convection baking. This mode is used

for cooking food items on more than

one rack (i.e., 2, 3 or more racks) at

the same time in convection bake.

See the

Multi-Rack Convection Baking

section for more information.

Touch the

CONVECTION BAKE MULTI/

1 RACK

pad twice for one rack

convection baking. This mode is used

for cooking food items on only one

rack in convection bake.

Touch the

CONVECTION ROAST

pad

for convection roasting.

Touch the number pads to set the

oven temperature.

Touch the

START

pad.

NOTE: If the Auto Recipe

™

Conversion Feature

is on, it will automatically reduce the set regular

baking temperature by 25°F to the appropriate

convection temperature in convection bake mode.

See Auto Recipe

™

Conversion in the Special

Features section.

To change the oven temperature, touch

the

CONVECTION BAKE MULTI/1 RACK

CONVECTION ROAST

pad and then the

number pads to set the new temperature.

When the oven starts to heat, the

changing temperature, starting at 100°F,

will be displayed. When oven reaches the

temperature you set, 3 beeps will sound.

Touch

CLEAR/OFF

pad when finished.

■

You will hear a fan while cooking with

convection. The fan will stop when the door

is opened, but the heat will not turn off.

■

You may hear the oven clicking during

baking. This is normal.

■

In convection bake modes, for maximum cooking

evenness, the fan is designed to rotate in

both directions, with a pause in between.

This is normal.

Cookware for Convection Cooking

Before using your convection oven, check

to see if your cookware leaves room for air

circulation in the oven. If you are baking

with several pans, leave space between

them. Also, be sure the pans do not touch

each other or the walls of the oven.

Paper and Plastic

Heat-resistant paper and plastic

containers that are recommended for

use in regular baking can also be used

for convection baking, but should not

be used at temperatures higher than

the temperature recommended by the

cookware manufacturer. Plastic cookware

that is heat-resistant to temperatures of

400°F can also be used.

Metal and Glass

Any type of cookware will work in your

convection oven. However, metal pans

heat the fastest and are recommended

for convection baking.

■

Darkened or matte-finished pans will bake

faster than shiny pans.

■

Glass or ceramic pans cook more slowly.

For recipes like oven-baked chicken,

use a pan with low sides. Hot air

cannot circulate well around food

in a pan with high sides.

How to Set the Upper Oven for Convection Baking or Roasting

When baking cookies, you will get

the best results if you use a flat

cookie sheet instead of a pan with

low sides.

Using the convection oven. (on some models)

Convection Roast

■

Good for large tender cuts of meat, uncovered.

The convection fan circulates the heated

air evenly over and around the food.

Meat and poultry are browned on all

sides as if they were cooked on a

rotisserie. The heated air seals in juices

quickly for a moist and tender product

while, at the same time, creating a rich

golden brown exterior.

When you are convection roasting, it is

important that you use a broiler pan and

grid designed for broiling for best

convection roasting results. The pan is

used to catch grease spills and the grid

is used to prevent grease spatters.

How to Set an Immediate Start and Automatic Stop

The upper oven will turn on immediately and cook

for a selected length of time. At the end of the

cooking time, the oven will turn off automatically.

Make sure the clock shows the correct

time of day.

Touch the

CONVECTION BAKE

MULTI/1 RACK

pad once for multi-

rack convection baking. This mode

is used for cooking food items on

more than one rack (i.e., 2, 3 or

more racks) at the same time in

convection bake. See

Multi-Rack

Baking

section for more information.

Touch the

CONVECTION BAKE MULTI/

1 RACK

pad twice for one rack

convection baking. This mode is used

for cooking food items on only one

rack in convection bake.

Touch the

CONVECTION ROAST

pad

for convection roasting.

ouch

the number pads to set the

oven temperature.

ouch

the

COOKING TIME

pad.

NOTE: If your recipe requires preheating, you may

need to add additional time to the length of the

cooking time.

Touch the number pads to set the

desired length of cooking time. The

minimum cooking time you can set

is 1 minute. The oven temperature

that you set and the cooking time that

you entered will be in the display.

Touch the

START

pad.

The oven will turn

, and the display will

show the cooking time countdown and the

changing temperature starting at 100°F.

(The temperature display will start to

change once the oven temprature reaches

100°F.) When the oven reaches the

temperature you set, 3 beeps will sound.

NOTE: If the Auto Recipe

™

Conversion Feature

is on, it will automatically reduce the set regular

baking temperature by 25°F to the appropriate

convection temperature in convection bake mode.

See Auto Recipe

™

Conversion in the Special

Features section.

The oven will continue to cook for the set

amount of time, then turn off automatically,

unless the WARM

feature was set. See the

How to Set the Oven for Warming

section.

After the oven turns off, the end-of-cycle

tone will sound.

Touch the

CLEAR/OFF

pad to clear

the display if necessary. Remove

the food from the oven. Remember,

even though the oven turns off

automatically, food left in the oven

will continue cooking after the oven

turns off.

Using the timed features for convection cooking. ge.com

You will hear a fan while cooking with these features. The fan will stop when the door is opened, but the heat

will not turn off.

NOTE: Foods that spoil easily—such as milk, eggs, fish, stuffings, poultry and pork—should not be allowed to sit

for more than 1 hour before or after cooking. Room temperature promotes the growth of harmful bacteria. Be sure

that the oven light is off because heat from the bulb will speed harmful bacteria growth.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

How to Set a Delayed Start and Automatic Stop

The upper oven will turn on at the time of day you

set, cook for a specific length of time and then turn

off automatically.

Make sure the clock shows the correct

time of day.

Touch the

CONVECTION BAKE

MULTI/1 RACK

pad once for multi-

rack convection baking. This mode

is used for cooking food items on

more than one rack (i.e., 2, 3 or

more racks) at the same time in

convection bake. See

Multi-Rack

Baking

section for more information.

Touch the

CONVECTION BAKE MULTI/

1 RACK

pad twice for one rack

convection baking. This mode is used

for cooking food items on only one

rack in convection bake.

Touch the

CONVECTION ROAST

pad

for convection roasting.

Touch the number pads to set the

oven temperature.

Touch the

COOKING TIME

pad.

NOTE: If your recipe requires preheating, you may

need to add additional time to the length of the

cooking time.

Touch the number pads to set the

desired length of cooking time. The

minimum cooking time you can set

is 1 minute.

The oven temperature that you set

and the cooking time that you entered

will be in the display.

Touch the

DELAY START

pad.

Touch the number pads to set the

time of day you want the oven to turn

on and start cooking.

Touch the

START

pad.

NOTE: An attention tone will sound if you are

using timed baking or roasting and do not touch

the START pad.

NOTE: If you would like to check the times you have

set, touch the DELAY START pad to check the start

time you have set, or touch the COOKING TIME

pad to check the length of cooking time you have set.

When the oven turns

at the time of day

you set, the display will show the cooking

time countdown and the changing

temperature starting at 100°F. (The

temperature display will start to change

once the oven temperature reaches 100°F.)

When the oven reaches the temperature

you set, 3 beeps will sound.

NOTE: If the Auto Recipe

™

Conversion Feature

is on, it will automatically reduce the set regular

baking temperature by 25°F to the appropriate

convection temperature in convection bake mode.

See Auto Recipe

™

Conversion in the Special

Features section.

The oven will continue to cook for the

programmed amount of time, then shut

off automatically, unless the WARM

feature

was set. See the

How to Set the Oven for

Warming

section.

After the oven turns off, the end-of-cycle

tone will sound.

Touch the

CLEAR/OFF

pad to clear

the display if necessary. Remove

the food from the oven. Remember,

even though the oven shuts off

automatically, food left in the oven

will continue cooking after the oven

turns off.

Using the timed features for convection cooking.

How to Set the Upper Oven for Convection Roasting when Using the Probe

Place the oven rack in the position

that centers the food between the

top and bottom of the oven. Insert

the probe into the meat. Make sure

it is pushed all the way in.

Plug the probe into the outlet in the

oven. Make sure it is pushed all the

way in. Close the oven door.

Touch the

PROBE

pad.

Touch the number pads to set the

desired internal meat temperature.

NOTE:

The maximum internal temperature

for the food that you can set is 200°F.

Touch the

CONVECTION ROAST

pad.

Touch the number pads to set the

desired oven temperature.

The display will flash

PROBE

and the oven

control will signal if the probe is inserted

into the outlet, and you have not set a probe

temperature and pressed the

START

pad.

Touch the

START

pad.

When the oven starts to heat, the word

will be in the display.

After the internal temperature of the meat

reaches 100°F, the changing internal

temperature will be shown in the display.

When the internal temperature of

the meat reaches the number you

have set, the probe and the oven

turn off and the oven control signals.

To stop the signal, touch the

CLEAR/OFF

pad. Use hot pads to

remove the probe from the food.

Do not use tongs to pull on it—

they might damage it.

NOTE: If the probe is removed from the

oven while probe cooking, the oven will not

automatically turn off.

CAUTION: To prevent possible burns,

do not unplug the probe from the oven outlet until

the oven has cooled.

NOTE:

■

You will hear a fan while cooking with this

feature. The fan will stop when the door is

opened, but the heat will not turn off.

■

You can use the Kitchen Timer even though you

cannot use timed oven operations.

■

Never leave your probe inside the oven during

a self-cleaning cycle.

■

Do not store the probe in the oven.

■

Probe not for use in Broil or Self-Clean functions.

For best results when roasting large

turkeys and roasts, we recommend

using the probe included in the

convection oven.

To change the oven temperature

during the Convection Roast cycle,

touch the CONVECTION ROAST pad

and then touch the number pads to

set the new desired temperature.

Convection Roasting Guide

Meats Minutes/Lb. Oven Temp. Internal Temp.

Beef Rib, Boneless Rib, Rare 20–24 325°F 140°F†

Top Sirloin Medium 24–28 325°F 160°F

(3 to 5 lbs.) Well 28–32 325°F 170°F

Beef Tenderloin Rare 10–14 325°F 140°F†

Medium 14–18 325°F 160°F

Pork Bone-In, Boneless (3 to 5 lbs.) 23–27 325°F 170°F

Chops (1/2 to 1″ thick) 2 chops 30–35 total 325°F 170°F

4 chops 35–40 total 325°F 170°F

6 chops 40–45 total 325°F 170°F

Ham Canned, Butt, Shank (3 to 5 lbs. fully cooked) 14–18 325°F 140°F

Lamb Bone-In, Boneless (3 to 5 lbs.) Medium 17–20 325°F 160°F

Well 20–24 325°F 170°F

Seafood Fish, Whole (3 to 5 lbs.) 30–40 total 400°F

Lobster Tails (6 to 8 oz. each) 20–25 total 350°F

Poultry Whole Chicken (2

⁄2 to 3

⁄2 lbs.) 24–26 350°F 180°–185°F

Cornish Hens, Unstuffed (1 to 1

⁄2 lbs.) 50–55 total 350°F 180°–185°F

Stuffed (1 to 1

⁄2 lbs.) 55–60 total 350°F 180°–185°F

Duckling (4 to 5 lbs.) 24–26 325°F 180°–185°F

Turkey, Whole*

Unstuffed (10 to 16 lbs.) 8–11 325°F 180°–185°F

Unstuffed (18 to 24 lbs.) 7–10 325°F 180°–185°F

Turkey Breast (4 to 6 lbs.) 16–19 325°F 170°F

* Stuffed birds generally require 30–45 minutes additional roasting time. Shield legs and breast with foil to prevent

overbrowning and drying of skin.

† The U.S. Department of Agriculture says “Rare beef is popular, but you should know that cooking it to only 140°F means

some food poisoning organisms may survive.” (Source: Safe Food Book. Your Kitchen Guide. USDA Rev. June 1985.)

Using the convection oven. ge.com

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

How to Set the Upper Oven For Warming (on some models)

The

WARM

feature keeps cooked

foods hot.

This feature is not designed to reheat

cold food.

To use the

WARM

feature, touch the

WARM

pad and then the

START

pad.

To use the

WARM

feature after Timed

Baking or Roasting, follow these steps:

Touch the mode of cooking that

you want to use (

BAKE, CONVECTION

BAKE MULTI, CONVECTION BAKE

1 RACK

CONVECTION ROAST

Touch the number pads to set the

oven temperature.

Touch the

COOKING TIME

pad.

Touch the number pads to set the

desired length of cooking time.

Touch the

WARM

pad.

Touch the

START

pad.

To Crisp Stale Items

■ Place food in low-sided dishes or pans.

■ For best results, place the food items in

a single layer. Do not stack.

■ Leave them uncovered.

■ Check crispness after 20–30 minutes.

Add time as needed.

IMPORTANT NOTES:

■

Food should be kept hot in its cooking container

or transferred to a heat-safe serving dish.

■

For moist foods, cover them with an oven-safe

lid or aluminum foil.

■

Fried or crisp foods do not need to be covered,

but can become too dry if warmed for too long.

■

Repeated opening of the door allows the hot

air to escape and the food to cool.

■

Allow extra time for the temperature inside the

oven to stabilize after adding items.

■

With large loads it may be necessary to cover

some of the cooked food items.

■

Remove serving spoons, etc., before placing

containers in the oven.

■

Do not use plastic containers, lids or

plastic wrap.

CAUTION: Plastic containers, lids or

plastic wrap will melt if placed in the oven.

Melted plastic may not be removable and is not

covered under your warranty.

How to Set the Upper Oven For Proofing (on some models)

Place the covered dough in a dish in

the oven on shelf B or C.

NOTE: For best results, cover the dough with a

cloth or with greased plastic wrap (the plastic

may need to be anchored underneath the

container so the oven fan will not blow it off).

Touch the

PROOF

pad and then the

START

pad.

The display will read

PrF

(proof).

The oven interior light turns on and

remains on during proofing.

The proofing feature automatically

provides the optimum temperature for

the proofing process, and therefore does

not have a temperature adjustment.

Set the

KITCHEN TIMER ON/OFF

for

the minimum proof time.

When proofing is finished, touch

the

CLEAR/OFF

pad.

■

To avoid lowering the oven temperature and

lengthening proofing time, do not open the

oven door unnecessarily.

■

Check bread products early to avoid

over-proofing.

NOTE:

■

Do not use the proofing mode for warming

food or keeping food hot. The proofing oven

temperature is not hot enough to hold foods

at safe temperatures. Use the WARM feature

to keep food warm.

■

Proofing will not operate when oven is above

125°F. “HOT” will show in the display.

Using the proofing and warming features.

The proofing feature maintains a warm environment useful for rising yeast-leavened products.

How to Set the Upper Oven for Cleaning

The oven door must be closed and all controls

set correctly for the cycle to work properly.

Touch the

SELF CLEAN STD/LO

pad

once for a 4-hour clean time or

twice for a 3-hour clean time.

A 3-hour self-clean time is

recommended for use when

cleaning small, contained spills.

A self-clean time of 4 hours or

longer is recommended for

a dirtier oven.

If a time other than 4 hours or

3 hours is needed, use the number

pads and enter the desired

clean time.

You can change the clean time to any

time between 2

⁄2 hours and 5 hours,

depending on how dirty your oven is.

Touch the

START

pad.

The door locks automatically. The display

will show the clean time remaining. It will

not be possible to open the oven door

until the temperature drops below the

lock temperature and the

LOCKED

light

goes off.

When the

LOCKED

light goes off, you will

be able to open the door.

■ The word

LOCKED

will flash and the

word

door

will display if you set the

clean cycle and forget to close the

oven door.

■ To stop a clean cycle, touch the

CLEAR/OFF

pad. When the

LOCKED

light

goes off indicating the oven has cooled

below the locking temperature, you

will be able to open the door.

Wipe up heavy soil on the oven

bottom.

Before a Clean Cycle

We recommend venting your kitchen

with an open window or using a

ventilation fan or hood during the

first self-clean cycle.

Remove broiler pan, broiler grid, probe,

all cookware and any aluminum foil

from the oven.

NOTE:

■ If your oven is equipped with shiny,

silver-colored oven racks, remove them

before you begin the self-clean cycle.

■ If your oven is equipped with gray

porcelain-coated oven racks, they

may be left in the oven during the

self-clean cycle.

The shiny, silver-colored oven racks

(on some models) can be self-cleaned,

but they will darken, lose their luster and

become hard to slide.

Soil on the front frame of the range and

outside the gasket on the door will need

to be cleaned by hand. Clean these areas

with hot water, soap-filled steel-wool pads

or cleansers such as Soft Scrub

. Rinse

well with clean water and dry.

Do not clean the gasket. The fiberglass

material of the oven door gasket cannot

withstand abrasion. It is essential for the

gasket to remain intact. If you notice it

becoming worn or frayed, replace it.

Wipe up any heavy spillovers on the

oven bottom.

Make sure the oven light bulb cover is

in place and the oven light is off.

IMPORTANT:

The health of some birds

is extremely sensitive to the fumes given

off during the self-cleaning cycle of any

range. Move birds to another well-

ventilated room.

Using the self-cleaning upper oven. ge.com

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

After a Clean Cycle

You may notice some white ash in the

oven. Wipe it up with a damp cloth after

the oven cools.

If white spots remain, remove them with a soap-

filled steel wool pad and rinse thoroughly with

a vinegar and water mixture.

These deposits are usually a salt residue

that cannot be removed by the clean

cycle.

If the oven is not clean after one clean

cycle, repeat the cycle.

■ You cannot set the oven for cooking or

another self-clean cycle until the oven

is cool enough for the door to unlock.

■ While the oven is self-cleaning, you can

touch the

CLOCK

pad to display the

time of day. To return to the clean

countdown, touch the

SELF CLEAN

STD/LO

pad.

■ If the racks become hard to slide, apply

a small amount of cooking oil to a

paper towel and wipe the edges of the

oven racks with the paper towel.

How to Delay the Start of Cleaning

Touch the

SELF CLEAN STD/LO

pad

once for a 4-hour clean time or

twice for a 3-hour clean time.

A 3-hour self-clean time is

recommended for use when

cleaning small, contained spills.

A self-clean time of 4 hours or

longer is recommended for

a dirtier oven.

If a time other than 4 hours or

3 hours is needed, use the number

pads and enter the desired

clean time.

You can change the clean time to any

time between 2

⁄2 hours and 5 hours,

depending on how dirty your oven is.

Touch the

DELAY START

pad.

Using the number pads, enter the

time of day you want the clean cycle

to start.

Touch the

START

pad.

The door locks automatically. The display

will show the start time. It will not be

possible to open the oven door until

the temperature drops below the lock

temperature and the

LOCKED

light

goes off.

When the

LOCKED

light goes off, you

will be able to open the door.

Using the self-cleaning upper oven.

The oven door must be closed and all controls set correctly for the cycle to work properly.

12-Hour Shutdown

With this feature, should you forget and leave the

oven on, the control will automatically turn off the

oven after 12 hours during baking functions or

after 3 hours during a broil function.

If you wish to turn

OFF

this feature, follow

the steps below.

Touch the

BROIL HI/LO

and

BAKE

pads at the same time until the

display shows

SF.

Touch the

DELAY START

pad until

no shdn

(no shut-off) appears in the

display.

Touch the

START

pad to activate the

no shut-off and leave the control

set in this special features mode.

Fahrenheit or Celsius Temperature Selection

Your oven control is set to use the Fahrenheit

temperature selections, but you may change this

to use the Celsius selections.

Touch the

BROIL HI/LO

and

BAKE

pads at the same time until the

display shows

SF.

Touch the

COOKING TIME

and

BROIL

HI/LO

pads at the same time. The

display will show

(Fahrenheit).

Touch the

COOKING TIME

and

BROIL

HI/LO

pads again at the same time.

The display will show

(Celsius).

Touch the

START

pad.

Tones at the End of a Timed Cycle

At the end of a timed cycle, 3 short beeps will

sound followed by one beep every 6 seconds

until the CLEAR/OFF pad is touched. This

continual 6-second beep may be canceled.

To cancel the 6-second beep:

Touch the

BROIL HI/LO

and

BAKE

pads at the same time until the

display shows

SF.

Touch the

KITCHEN TIMER ON/OFF

pad. The display shows

CON BEEP

(continuous beep). Touch the

KITCHEN TIMER ON/OFF

pad again.

The display shows

BEEP.

(This cancels

the one beep every 6 seconds.)

Touch the

START

pad.

Special features of your oven control. ge.com

Your new touch pad control has additional features that you may choose to use. The following are the features

and how you may activate them.

The special feature modes can only be activated while the display is showing the time of day. They remain

in the control’s memory until the steps are repeated.

When the display shows your choice, touch the START pad. The special features will remain in memory after

a power failure, except for the Sabbath feature, which will have to be reset.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

12-Hour, 24-Hour or Clock Blackout

Your control is set to use a 12-hour clock.

If you would prefer to have a 24-hour

military time clock or black out the clock

display, follow the steps below.

Touch the

BROIL HI/LO

and

BAKE

pads at the same time until the

display shows

SF.

Touch the

CLOCK

pad once. The

display will show

12 hr.

If this is

the choice you want, touch the

START

pad.

Touch the

CLOCK

pad again to change

to the 24 hour military time clock. The

display will show

24 hr.

If this is the choice

you want, touch the

START

pad.

Touch the

CLOCK

pad again to black out

the clock display. The display will show

OFF.

If this is the choice you want, touch

the

START

pad.

NOTE: If the clock is in the black-out mode you

will not be able to use the Delay Start function.

Special features of your oven control.

ge.com

Auto Recipe

™

Conversion

When using convection bake, the Auto Recipe

™

Conversion feature will automatically convert

entered regular baking temperatures to

convection baking temperatures.

This feature is activated so that the display will

show the actual converted (reduced) temperature.

For example, if you enter a regular recipe

temperature of 350°F and press the START pad,

the display will show CON and the converted

temperature of 325°F.

To deactivate the feature:

Press the

BAKE

and

BROIL HI/LO

pads

at the same time until the display

shows

Press the

CONVECTION BAKE

MULTI/1 RACK

pad. The display will

show

CON ON

. Press the

CONVECTION BAKE MULTI/1 RACK

pad again. The display will show

CON OFF

Press the

START

pad.

To reactivate the feature, repeat steps

1–3 above but press the

START

pad when

CON ON

is in the display.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

The Sabbath feature can be used for baking/roasting only. It cannot be used for convection, broiling, self-cleaning or

Delay Start cooking.

NOTE: The oven light comes on automatically (on some models) when the door is opened and goes off when the door is closed. The bulb may be

removed. See the Oven Light Replacement section. On models with a light switch on the control panel, the oven light may be turned on and left on.

How to Set for Regular Baking/Roasting

Make sure the clock shows the correct time of day and

the oven is off.

Touch and hold

both

the

BROIL HI/LO

and

BAKE

pads,

at the same time

, until the

display shows

SF.

NOTE:

If bake or broil appears in the

display, the

BROIL HI/LO

and

BAKE

pads

were not touched at the same time.

Touch the

CLEAR/OFF

pad and begin

again.

Tap the

DELAY START

pad until

SAb bAtH

appears in the display.

Touch the

START

pad and ⊃ will appear

in the display.

Touch the

BAKE

pad. No signal will

be given.

Using the number pads, enter the

desired temperature between 170°F and

550°F. No signal or temperature will be

given.

Touch the

START

pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃ will appear in the display

indicating that the oven is baking/

roasting. If ⊃ doesn’t appear in the

display, start again at Step 4.

To adjust the oven temperature, touch the

BAKE

pad, enter the new temperature using

the number pads and touch the

START

pad.

NOTE:

The

CLEAR/OFF

and

COOKING TIME

pads

are active during the Sabbath feature.

⊃

How to Set for Timed Baking/Roasting—Immediate Start and Automatic Stop

Make sure the clock shows the correct time of day and

the oven is off.

Touch and hold

both

the

BROIL HI/LO

and

BAKE

pads,

at the same time

, until the

display shows

SF.

NOTE:

If bake or broil appears in the

display, the

BROIL HI/LO

and

BAKE

pads

were not touched at the same time.

Touch the

CLEAR/OFF

pad and begin

again.

Tap the

DELAY START

pad until

SAb bAtH

appears in the display.

Touch the

START

pad and ⊃ will appear

in the display.

Touch the

COOKING TIME

pad.

Touch the number pads to set the

desired length of cooking time between

1 minute and 9 hours and 99 minutes.

The cooking time that you entered will

be displayed.

Touch the

START

pad.

Touch the

BAKE

pad. No signal will be

given.

Using the number pads, enter the

desired temperature. No signal or

temperature will be given.

Touch the

START

pad.

After a random delay period of

approximately 30 seconds to 1 minute,

⊃ will appear in the display indicating

that the oven is

baking/roasting.

If ⊃

doesn’t appear in the display, start again

at Step 7.

To adjust the oven temperature, touch the

BAKE

pad, enter the new temperature using

the number pads and touch the

START

pad.

When cooking is finished, the display will

change from ⊃ to ⊃ and

0:00

will appear,

indicating that the oven has turned

OFF

but is

still set in Sabbath. Remove the cooked food.

⊃

How to Exit the Sabbath Feature

Touch the

CLEAR/OFF

pad.

If the oven is cooking, wait for a random

delay period of approximately 30

seconds to 1 minute, until only ⊃

is in the display.

Touch and hold

both

the

BROIL HI/LO

and

BAKE

pads,

at the same time

, until

the display shows

SF.

Tap the

DELAY START

pad until

12 shdn

no shdn

appears in the display.

Choose

12 shdn

, indicating that the oven

will automatically turn off after 12 hours

no shdn

, indicating that the oven will

not automatically turn off after 12 hours.

Press

START

when the option that you

want is in the display (

12 shdn

no shdn

NOTE:

If a power outage occurred while

the oven was in Sabbath, the oven will

automatically turn off and stay off even

when the power returns. The oven

control must be reset.

When the display shows

⊃

the

oven is set in Sabbath. When the

display shows

⊃

the oven is

baking/roasting.

⊃

When the display shows

⊃

the

oven is set in Sabbath. When the

display shows

⊃

the oven is

baking/roasting.

⊃

Using the Sabbath feature.

(Designed for use on the Jewish Sabbath and Holidays) (on some models)

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

If your range is removed for cleaning, servicing or any reason, be sure the anti-tip

device is re-engaged properly when the range is replaced. Failure to take this

precaution could result in tipping of the range and cause injury.

Care and cleaning of the range. ge.com

Be sure all controls are off and all surfaces are cool before cleaning any part of the range.

How to Remove Protective Shipping Film and Packaging Tape

Carefully grasp a corner of the protective

shipping film with your fingers and slowly

peel it from the appliance surface. Do not

use any sharp items to remove the film.

Remove all of the film before using the

appliance for the first time.

To assure no damage is done to the

finish of the product, the safest way to

remove the adhesive from packaging tape

on new appliances is an application of a

household liquid dishwashing detergent.

Apply with a soft cloth and allow to soak.

NOTE: The adhesive must be removed from all

parts. It cannot be removed if it is baked on.

Control Knobs

The control knobs may be removed for easier

cleaning.

Make sure the knobs are in the

OFF

positions and pull them straight off the

stems for cleaning.

The knobs can be cleaned in a

dishwasher or they may also be washed

with soap and water. Make sure the inside

of the knobs are dry before replacing.

Replace the knobs in the

OFF

position to

ensure proper placement.

Oven Vent

The oven vent is located above the right rear

surface unit.

This area could become hot during

oven use.

It is normal for steam to come out of

the vent.

The vent is important for proper air circulation.

Never block this vent.

Control Panel

If desired, the touch pads may be deactivated

before cleaning.

See the

Range Lockout

Control Lockout

information in the

Using the clock, timer

and control lockout

section in this manual.

Clean up splatters with a damp cloth.

You may also use a glass cleaner.

Remove heavier soil with warm soapy

water. Do not use abrasives of any kind.

Reactivate the touch pads after cleaning.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

The gasket is designed with a gap at the

bottom to allow for proper air circulation.

Do not rub or clean the door gasket—

it has an extremely low resistance to

abrasion.

If you notice the gasket becoming worn,

frayed or damaged in any way or if it

has become displaced on the door,

you should have it replaced.

Lift-Off Oven Door

The door is very heavy. Be careful when

removing and lifting the door.

Do not lift the door by the handle.

To remove the door:

Fully open the door.

Pull the hinge locks down toward

the door frame, to the unlocked

position. A tool, such as a small

flat-blade screwdriver, may be

required.

Firmly grasp both sides of the door

at the top.

Close door to the door removal

position, which is halfway between

the broil stop position and fully

closed.

Lift door up and out until the hinge

arm is clear of the slot.

To replace the door:

Firmly grasp both sides of the door

at the top.

With the

door at the

same angle as

the removal

position, seat the

indentation of

the hinge arm

into the bottom

edge of the hinge slot. The notch in

the hinge arm must be fully seated

into the bottom of the slot.

Fully open the door. If the door will

not fully open, the indentation is not

seated correctly in the bottom edge

of the slot.

Push the hinge locks up against the

front frame of the oven cavity to the

locked position.

Close the oven door.

Indentation

Bottom

edge

of slot

Hinge arm

Cleaning the Oven Door

To clean the inside of the door:

■ Because the area inside the gasket is

cleaned during the self-clean cycle,

you do not need to clean this by hand.

■ The area outside the gasket and

the door liner can be cleaned with

a soap-filled steel wool or plastic pad,

hot water and detergent. Rinse well

with a vinegar and water solution.

To clean the outside of the door:

■ Use soap and water to thoroughly

clean the top, sides and front of the

oven door. Rinse well. You may also

use a glass cleaner to clean the glass

on the outside of the door. Do not let

water drip into the vent openings.

■ If any stain on the door vent trim is

persistent, use a soft abrasive cleaner

and a sponge-scrubber for best results.

■ Spillage of marinades, fruit juices,

tomato sauces and basting materials

containing acids may cause

discoloration and should be wiped

up immediately. When surface is

cool, clean and rinse.

■ Do not use oven cleaners, cleaning

powders or harsh abrasives on the

outside of the door.

Care and cleaning of the range.

Removal position

Hinge

lock

Hinge

lock

Slot

Push hinge locks up to lock.

Pull hinge locks down to unlock.

Hinge

arm

ge.com

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Removable Lower Oven Drawer Pan

NOTE: Allow lower oven drawer to cool before

removing pan.

NOTE: Wipe spills promptly after each use.

■ Never place, use or self-clean the lower

oven drawer pan in the upper oven.

■ Lower oven drawer has a removable

pan for easy cleaning. Clean with hot

soapy water and a sponge or dish towel.

Dry with a clean cloth. Replace the pan

in the lower oven drawer.

NOTE: For models with an electric warming

drawer or lower oven drawer, before performing

any adjustments, cleaning or service, disconnect

the range electrical power supply at the

household distribution panel by removing the

fuse or switching off the circuit breaker. Make

sure the drawer heating element is cool.

Care and cleaning of the range.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Oven Heating Elements

Do not clean the broil element. Any soil

will burn off when the element is heated.

Clean the oven floor with warm, soapy

water.

On some models, the bake element is not

exposed and is under the oven floor. If spillovers,

residue or ash accumulate on the oven floor,

wipe up before self-cleaning.

Storage Drawer Removal (on some models)

To remove the drawer:

Pull the drawer out until it stops.

Lift the front of the drawer until the

stops clear the guides.

Remove the drawer.

To replace the drawer:

Place the drawer rails on the guides.

Push the drawer back until it stops.

Lift the front of the drawer and push

back until the stops clear the guides.

Lower the front of the drawer and

push back until it closes.

Stop guide

Rail

Oven Light Replacement

CAUTION: Before replacing your oven light bulb,

disconnect the electrical power to the range at the

main fuse or circuit breaker panel.

Be sure to let the light cover and bulb

cool completely.

To remove the cover:

Hold a hand under the cover so it

doesn’t fall when released. With

fingers of the same hand, firmly

push back the wire cover holder.

Lift off the cover.

Do not remove any screws to remove

the cover.

Replace bulb with a 40-watt

appliance bulb.

To replace the cover:

Place it into groove of the light

receptacle. Pull wire forward to the

center of the cover until it snaps

into place.

Connect electrical power to the

range.

Wire cover holder.

Wipe up heavy soil on the oven

bottom.

Stainless Steel Surfaces (on some models)

Painted Surfaces

Painted surfaces include the door,

top of the control panel and the drawer

front. Clean these with soap and water

or a vinegar and water solution.

Do not use commercial oven cleaners,

cleaning powders, steel wool or harsh

abrasives on any painted surface.

Oven Racks

All oven racks may be cleaned by hand

with an abrasive cleaner or steel wool.

After cleaning, rinse the racks with clean

water and dry with a clean cloth. Gray

porcelain-coated oven racks may remain

in the oven during the self-cleaning

cycle without being damaged. The shiny,

silver-colored oven racks may remain in

the oven during the self-cleaning cycle,

but they will lose their luster and become

hard to slide.

It will be necessary to grease all oven

rack side edges with a light coating of

vegetable oil after cleaning them by hand

or in the oven. This will help maintain

the ease of sliding the racks in and out

of the oven.

ge.com

Do not use a steel wool pad; it will scratch

the surface.

To clean the stainless steel surface,

use warm sudsy water or a stainless steel

cleaner or polish. Always wipe the surface

in the direction of the grain. Follow the

cleaner instructions for cleaning the

stainless steel surface.

To inquire about purchasing stainless

steel appliance cleaner or polish, or to

find the location of a dealer nearest you,

please call our toll-free number:

National Parts Center 1.800.626.2002

ge.com

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Oven rack

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Allow the cooktop to cool.

Use a single-edge razor blade scraper

at approximately a 45° angle against

the glass surface and scrape the soil.

It will be necessary to apply pressure

to the razor scraper in order to

remove the residue.

After scraping with the razor scraper,

spread a few drops of CERAMA

BRYTE

Ceramic Cooktop Cleaner

on the entire burned residue area.

Use the CERAMA BRYTE

Cleaning

Pad to remove any remaining

residue.

For additional protection, after all

residue has been removed, polish

the entire surface with CERAMA

BRYTE

Ceramic Cooktop Cleaner

and a paper towel.

Burned-On Residue

WARNING: DAMAGE to your glass surface may

occur if you use scrub pads other than those

recommended.

Allow the cooktop to cool.

Spread a few drops of CERAMA

BRYTE

Ceramic Cooktop Cleaner

on the entire burned residue area.

Using the included CERAMA

BRYTE

Cleaning Pad for Ceramic

Cooktops, rub the residue area,

applying pressure as needed.

If any residue remains, repeat the

steps listed above as needed.

For additional protection, after all

residue has been removed, polish

the entire surface with CERAMA

BRYTE

Ceramic Cooktop Cleaner

and a paper towel.

The CERAMA BRYTE

Ceramic

Cooktop Scraper and all

recommended supplies are

available through our Parts Center.

See instructions under “To Order

Parts” section on next page.

NOTE: Do not use a dull or nicked

blade.

Heavy, Burned-On Residue

Use a CERAMA BRYTE

Cleaning

Pad for Ceramic Cooktops.

Normal Daily Use Cleaning

ONLY use CERAMA BRYTE

Ceramic

Cooktop Cleaner on the glass cooktop.

Other creams may not be as effective.

To maintain and protect the surface of

your glass cooktop, follow these steps:

Before using the cooktop for the

first time, clean it with CERAMA

BRYTE

Ceramic Cooktop Cleaner.

This helps protect the top and

makes cleanup easier.

Daily use of CERAMA BRYTE

Ceramic Cooktop Cleaner will help

keep the cooktop looking new.

Shake the cleaning cream well.

Apply a few drops of CERAMA

BRYTE

Ceramic Cooktop Cleaner

directly to the cooktop.

Use a paper towel or CERAMA

BRYTE

Cleaning Pad for Ceramic

Cooktops to clean the entire

cooktop surface.

Use a dry cloth or paper towel

to remove all cleaning residue.

No need to rinse.

NOTE: It is very important that you DO NOT heat

the cooktop until it has been cleaned thoroughly.

Clean your cooktop after

each spill. Use CERAMA

BRYTE

Ceramic Cooktop

Cleaner.

Cleaning the glass cooktop.

To order CERAMA BRYTE

Ceramic

Cooktop Cleaner and the cooktop

scraper, please call our toll-free number:

National Parts Center 800.626.2002

ge.com

CERAMA BRYTE

Ceramic

Cooktop Cleaner . . . . . . . . . . . .# WX10X300

CERAMA BRYTE

Ceramic

Cooktop Scraper . . . . . . . . . . .# WX10X0302

Kit . . . . . . . . . . . . . . . . . . . . . . . . . .# WB64X5027

(Kit includes cream and cooktop scraper)

CERAMA BRYTE

Cleaning Pads for

Ceramic Cooktops . . . . . . . . . .# WX10X350

Sugary spillovers (such as

jellies, fudge, candy, syrups)

or melted plastics can cause

pitting of the surface of your

cooktop (not covered by the

warranty) unless the spill is

removed while still hot.

Special care should be taken

when removing hot

substances.

Be sure to use a new, sharp

razor scraper.

Do not use a dull or nicked

blade.

To Order Parts

To clean the rubber-like seal at the outer

edge of the glass, wipe it with cooktop

cream when needed.

Rubber-like Seal

Metal Marks and Scratches

Be careful not to slide pots and pans

across your cooktop. It will leave

metal markings on the cooktop

surface.

These marks are removable using

the CERAMA BRYTE

Ceramic

Cooktop Cleaner with the CERAMA

BRYTE

Cleaning Pad for Ceramic

Cooktops.

If pots with a thin overlay of

aluminum or copper are allowed

to boil dry, the overlay may leave

black discoloration on the cooktop.

This should be removed

immediately before heating again

or the discoloration may be

permanent.

WARNING: Carefully check the

bottom of pans for roughness that would scratch

the cooktop.

ge.com

Damage from Sugary Spills and Melted Plastic

Turn off all surface units. Remove

hot pans.

Wearing an oven mitt:

a. Use a single-edge razor blade

scraper (CERAMA BRYTE

Ceramic Cooktop Scraper) to

move the spill to a cool area on

the cooktop.

b. Remove the spill with paper

towels.

Any remaining spillover should be

left until the surface of the cooktop

has cooled.

Don’t use the surface units again

until all of the residue has been

completely removed.

NOTE: If pitting or indentation in the glass

surface has already occurred, the cooktop glass

will have to be replaced. In this case, service will

be necessary.

Glass surface—potential for permanent damage.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Troubleshooting Tips

Save time and money! Review the charts on the following

pages first and you may not need to call for service.

Problem Possible Causes What To Do

Surface units will not

Improper cookware • Use pans which are flat and match the diameter of

maintain a rolling boil

being used. the surface unit selected.

or cooking is not

In some areas, the power • Cover pan with a lid until desired heat is obtained.

fast enough

(voltage) may be low.

Surface units do

A fuse in your home may be • Replace the fuse or reset the circuit breaker.

not work properly

blown or the circuit breaker

tripped.

Cooktop controls • Check to see the correct control is set for the surface

improperly set. unit you are using.

Surface unit stops

This is normal. The unit

glowing when turned

is still on and hot.

to a lower setting

Scratches (may appear

Incorrect cleaning • Scratches are not removable. Tiny scratches will become

as cracks) on cooktop

methods being used. less visible in time as a result of cleaning.

glass surface

Cookware with rough bottoms • To avoid scratches, use the recommended cleaning

being used or coarse particles procedures. Make sure bottoms of cookware are clean

(salt or sand) were between before use, and use cookware with smooth bottoms.

the cookware and the surface

of the cooktop.

Cookware has been slid

across the cooktop surface.

Areas of discoloration

Food spillovers not cleaned • See the

Cleaning the glass cooktop

section.

on the cooktop

before next use.

Hot surface on a model • This is normal. The surface may appear discolored

with a light-colored cooktop. when it is hot. This is temporary and will disappear

as the glass cools.

Plastic melted to

Hot cooktop came into • See the

Glass surface—potential for permanent damage

the surface

contact with plastic placed section in the

Cleaning the glass cooktop

section.

on the hot cooktop.

Pitting (or indentation)

Hot sugar mixture spilled • Call a qualified technician for replacement.

of the cooktop

on the cooktop.

Frequent cycling

Improper cookware • Use only flat cookware to minimize cycling.

off and on of

being used.

surface units

Oven light does

Light bulb is loose. • Tighten or replace the bulb.

not work

Oven will not work

Plug on range is not completely • Make sure electrical plug is plugged into a live, properly

inserted in the electrical outlet. grounded outlet.

A fuse in your home may be • Replace the fuse or reset the circuit breaker.

blown or the circuit

breaker tripped.

Oven controls improperly set. • See the

Using the oven

section.

Oven too hot. • Allow the oven to cool to below locking temperature.

Before you call for service…

Problem Possible Causes What To Do

Food does not bake

Oven controls improperly set. • See the

Using the oven

section.

or roast properly

Rack position is incorrect • See the

Using the oven

section.

or the rack is not level.

Incorrect cookware or • See the

Using the oven

section.

cookware of improper

size being used.

Oven thermostat needs • See the

Adjust the oven thermostat—Do it yourself!

adjustment. section.

Food does not

Oven controls improperly set. • Make sure you touch the

BROIL HI/LO

pad.

broil properly

Improper rack position • See the

Broiling Guide.

being used.

Cookware not suited • For best results, use a pan designed for broiling.

for broiling.

The probe is plugged into the • Unplug and remove the probe from the oven.

outlet in the oven.

(on some models)

In some areas the power • Preheat the broil element for 10 minutes.

(voltage) may be low.

• Broil for the longest period of time recommended in

the

Broiling Guide.

Oven temperature

Oven thermostat • See the

Adjust the oven thermostat—Do it yourself!

too hot or too cold

needs adjustment. section.

Storage drawer

Rear drawer support is • Reposition the drawer. See the

Storage Drawer

is crooked

on top of the guide rail.

Removal

instructions in the

Care and cleaning of your

range

section.

• Check to make sure drawer is properly seated

if removed.

Storage drawer

Power cord may be • Reposition the drawer and power cord. See the

won’t close

obstructing drawer

Storage Drawer Removal

instructions in the

Care and

in the lower back

cleaning of your range

section.

of the range.

Rear drawer support is • Reposition the drawer. See the

Storage Drawer

on top of the guide rail.

Removal

instructions in the

Care and cleaning of your

range

section.

ge.com

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Troubleshooting Tips

Problem Possible Causes What To Do

Clock and timer do

Plug on range is not completely • Make sure electrical plug is plugged into a live, properly

not work

inserted in the electrical outlet. grounded outlet.

A fuse in your home • Replace the fuse or reset the circuit breaker.

may be blown or the

circuit breaker tripped.

Oven controls improperly set. • See the

Using the clock and timer

section.

Oven will not self-clean

The oven temperature is • Allow the range to cool and reset the controls.

too high to set a self-clean

operation.

Oven controls improperly set. • See the

Using the self-cleaning oven

section.

The probe is plugged into • Remove the probe from the oven.

the outlet in the oven.

(on some models)

“Crackling” or

This is the sound of the • This is normal.

“popping” sound

metal heating and cooling

during both the cooking and

cleaning functions.

Excessive smoking

Excessive soil. • Touch the

CLEAR/OFF

pad. Open the windows to

during a clean cycle

rid the room of smoke. Wait until the

LOCKED

light

goes off. Wipe up the excess soil and reset the clean

cycle.

Oven door will not

Oven too hot. • Allow the oven to cool below locking temperature.

open after a clean cycle

Oven not clean after a

Oven controls not properly set. • See the

Using the self-cleaning oven

section.

clean cycle

Oven was heavily soiled. • Clean up heavy spillovers before starting the clean

cycle. Heavily soiled ovens may need to self-clean

again or for a longer period of time.

“LOCKED” flashes

The self-clean cycle has been • Close the oven door.

in the display

selected but the door is not

closed.

“LOCKED” light is

The oven door is locked • Touch the

CLEAR/OFF

pad. Allow the oven to cool.

on when you want

because the temperature

to cook

inside the oven has not

dropped below the

locking temperature.

“F—and a number

You have a function error code. • Disconnect all power to the range for at least 30

or letter” flash

seconds and then reconnect power. If the function

in the display

error code repeats, call for service.

Before you call for service…

Problem Possible Causes What To Do

Loc On appears in the

The controls have • See the

Range lockout

Control lockout

section

oven display or LC

been locked. to unlock.

in the surface display

Control signals after

You forgot to enter a • Touch the

BAKE

pad and desired temperature or

entering cooking time

bake temperature or the

SELF CLEAN STD/LO

pad and desired clean time.

or start time

cleaning time.

Display goes blank

A fuse in your home may be • Replace the fuse or reset the circuit breaker.

blown or the circuit

breaker tripped.

The clock is in the • See the

Special features of your oven control

section.

black-out mode.

Display flashes

Power failure. • Reset the clock.

Unable to get the

Oven control pads were • The

BROIL HI/LO

and

BAKE

pads must be touched at

display to show “SF”

not touched properly. the same time and held

for 3 seconds

“Probe” appears in

This is reminding you to • Enter a probe temperature.

the display

enter a probe temperature

(on some models)

after plugging in the probe.

Power outage,

Power outage or surge. • Reset the clock. If the oven was in use, you must reset

clock flashes

it by touching the

CLEAR/OFF

pad, setting the clock

and resetting any cooking function.

Steam from the vent

When using the convection • This is normal.

feature, it is normal to see

steam coming out of the oven

vent. As the number of racks

or amount of food being

cooked increases, the amount

of visible steam will increase.

“Burning” or “oily”

This is normal in a new oven • To speed the process, set a self-clean cycle for a

odor emitting from

and will disappear in time. minimum of 3 hours. See the

Using the self-cleaning

the vent

oven section.

Strong odor

An odor from the insulation • This is temporary.

around the inside of the oven

is normal for the first few times

the oven is used.

Fan noise

A convection fan may • This is normal. To maximize cooking evenness,

automatically turn on the fan is designed to operate in both directions,

and off. with a pause in between.

• The convection fan will operate during preheat

of the bake cycle. The fan will turn off after the oven

is heated to the set temperature. This is normal.

ge.com

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Before you call for service…

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Problem Possible Causes What To Do

Oven racks are

The shiny, silver-colored • Apply a small amount of vegetable oil to a paper

difficult to slide

racks were cleaned in a towel and wipe the edges of the oven racks with

self-clean cycle. the paper towel. Do not spray with Pam

or other

lubricant sprays.

Drawer does not slide

The drawer is out • Fully extend the drawer and push it all the way in.

smoothly or drags

of alignment. See the

Care and cleaning of the range

section.

Drawer is over-loaded or • Reduce weight. Redistribute drawer contents.

load is unbalanced.

Lower oven drawer or

A fuse in your home may be • Replace the fuse or reset the circuit breaker.

warming drawer will

blown or the circuit breaker

not work

tripped.

Controls improperly set. • See the

Electric warming drawer

Lower oven

drawer

section.

Excessive condensation

Liquid in drawer. • Remove liquid.

in the drawer

Uncovered foods. • Cover food with lid or aluminum foil.

Temperature setting too high. • Reduce temperature setting.

Food dries out in the

Moisture escaping. • Cover food with lid or aluminum foil.

lower oven drawer or

Drawer not fully closed. • Push drawer in until latch engages.

warming drawer

Troubleshooting Tips

General Electric Company

Warranty Registration Department

P.O. Box 32150

Louisville, KY 40232-2150

GE Service Protection Plus

™

GE, a name recognized worldwide for quality and dependability, offers you

Service Protection Plus

™

—comprehensive protection on all your appliances—

No Matter What Brand!

Benefits Include:

• Backed by GE

• All brands covered

• Unlimited service calls

• All parts and labor costs included

• No out-of-pocket expenses

• No hidden deductibles

• One 800 number to call

You will be completely satisfied with our service protection or you may request your money back

on the remaining value of your contract. No questions asked. It’s that simple.

Protect your refrigerator, dishwasher, washer and dryer, range, TV, VCR and much more—any brand!

Plus there’s no extra charge for emergency service and low monthly financing is available. Even icemaker

coverage and food spoilage protection is offered. You can rest easy, knowing that all your valuable

household products are protected against expensive repairs.

Place your confidence in GE and call us in the U.S. toll-free at 800.626.2224

for more information.

*All brands covered, up to 20 years old, in the continental U.S.

We’ll Cover Any Appliance.

Anywhere. Anytime.*

Please place in envelope and mail to:

✁

Cut here

Consumer Product Ownership Registration

Important

Mail

Today!

GE Consumer & Industrial

Appliances

General Electric Company

Louisville, KY 40225

ge.com

First

Name

Mr. ■■ Ms. ■■ Mrs. ■■ Miss ■■

Street

Address

City

State

Date Placed

In Use

Month

Day

Year

Zip

Code

Apt. #

Last

Name

Phone

Number

Consumer Product Ownership Registration

Dear Customer:

Thank you for purchasing our product and thank you for placing your confidence in us.

We are proud to have you as a customer!

Follow these three steps to protect your new appliance investment:

Important: If you did not get a registration card with your

product, detach and return the form below to

ensure that your product is registered, or register

online at ge.com.

Model Number Serial Number

✁

Cut here

Complete and mail

your Consumer

Product Ownership

Registration today.

Have the peace of

mind of knowing we

can contact you in

the unlikely event of

safety modification.

After mailing the

registration below,

store this document

in a safe place. It

contains information

you will need should

you require service.

Our service number is

800.GE.CARES

(800.432.2737).

Read your Owner’s

Manual carefully.

It will help you

operate your new

appliance properly.

Model Number Serial Number

E-mail Address*

* Please provide your e-mail address to receive, via e-mail, discounts, special offers and other important

communications from GE Appliances (GEA).

■■ Check here if you do not want to receive communications from GEA’s carefully selected partners.

FAILURE TO COMPLETE AND RETURN THIS CARD DOES NOT DIMINISH YOUR

WARRANTY RIGHTS.

For more information about GEA’s privacy and data usage policy, go to ge.com and click on

“Privacy Policy” or call 800.626.2224.

Notes.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Notes.

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Notes.

Safety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

Consumer Support Troubleshooting Tips Care and Cleaning Operating Instructions Safety Instructions

Accessories.

Looking For Something More?

You can find these accessories and many more at ge.com, or call 800.626.2002

(during normal business hours). Have your model number ready.

Tired of discolored racks? Wishing you had extra-heavy-duty oven racks?

NOW AVAILABLE

for your range:

GE’

s innovative, self-cleanable porcelain-coated oven racks!

• Heavy Duty

• Durable

• Able to be cleaned in a self-cleaning oven

Visit

ge.com

for more information.

Surface Elements & Drip Pans Oven Racks Broiler Pan

Oven Elements Light Bulbs Knobs

Cleaner Cleaning Pads Scraper

This warranty is extended to the original purchaser and any succeeding owner for products purchased for

home use within the USA. If the product is located in an area where service by a GE Authorized Servicer is not

available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE

Service location for service. In Alaska, the warranty excludes the cost of shipping or service calls to your home.

Some states do not allow the exclusion or limitation of incidental or consequential damages. This warranty

gives you specific legal rights, and you may also have other rights which vary from state to state. To know

what your legal rights are, consult your local or state consumer affairs office or your state’s Attorney General.

Warrantor: General Electric Company. Louisville, KY 40225

Safety Instructions Operating InstructionsSafety Instructions Operating Instructions Care and Cleaning Troubleshooting Tips Consumer Support

GE Electric Range Warranty.

All warranty service provided by our Factory Service Centers,

or an authorized Customer Care

technician. To schedule

service, on-line, 24 hours a day, visit us at ge.com, or call

800.GE.CARES (800.432.2737). Please have serial number and model

number available when calling for service.

■ Service trips to your home to teach you how to use

the product.

■ Improper installation, delivery or maintenance.

■ Failure of the product if it is abused, misused,

or used for other than the intended purpose or

used commercially.

■ Damage to the glass cooktop caused by use of cleaners

other than the recommended cleaning creams and

pads.

■ Damage to the glass cooktop caused by hardened

spills of sugary materials or melted plastic that

are not cleaned according to the directions in

the Owner’s Manual.

■ Replacement of house fuses or resetting of circuit

breakers.

■ Damage to the product caused by accident, fire, floods

or acts of God.

■ Incidental or consequential damage caused by possible

defects with this appliance.

■ Damage caused after delivery.

■ Product not accessible to provide required service.

What GE Will Not Cover:

Staple your receipt here.

Proof of the original purchase

date is needed to obtain service

under the warranty.

For The Period Of: GE Will Provide:

One Year Any part

of the range which fails due to a defect in materials or workmanship. During this

From the date of the limited one-year warranty,

GE will also provide,

free of charge,

all labor and in-home service

original purchase

to replace the defective part.

Five Years A replacement glass cooktop

if it should crack due to thermal shock, discolor, crack at the

From the date of the

rubber seal between the glass cooktop and the porcelain edge, or if the pattern wears off.

original purchase

A replacement radiant surface unit

if it should burn out.

During this

limited additional four-year warranty,

you will be responsible for any labor or

in-home service.

EXCLUSION OF IMPLIED WARRANTIES—Your sole and exclusive remedy is product repair as provided in this Limited

Warranty. Any implied warranties, including the implied warranties of merchantability or fitness for a particular purpose,

are limited to one year or the shortest period allowed by law.

Printed in the United States

GE Appliances Website ge.com

Have a question or need assistance with your appliance? Try the GE Appliances Website any day of the year!

For greater convenience and faster service, you can now download Owner’s Manuals, order parts or even

schedule service on-line.

Schedule Service ge.com

Expert GE repair service is only one step away from your door. Get on-line and schedule your service at

your convenience 24 hours any day of the year! Or call 800.GE.CARES (800.432.2737) during normal

business hours.

Real Life Design Studio ge.com

GE supports the Universal Design concept—products, services and environments that can be used by

people of all ages, sizes and capabilities. We recognize the need to design for a wide range of physical and

mental abilities and impairments. For details of GE’s Universal Design applications, including kitchen

design ideas for people with disabilities, check out our Website today. For the hearing impaired, please call

800.TDD.GEAC (800.833.4322).

Extended Warranties ge.com

Purchase a GE extended warranty and learn about special discounts that are available while your warranty

is still in effect. You can purchase it on-line anytime, or call 800.626.2224 during normal business hours.

GE Consumer Home Services will still be there after your warranty expires.

Parts and Accessories ge.com

Individuals qualified to service their own appliances can have parts or accessories sent directly to their

homes (VISA, MasterCard and Discover cards are accepted). Order on-line today, 24 hours every day or

by phone at 800.626.2002 during normal business hours.

Instructions contained in this manual cover procedures to be performed by any user. Other servicing generally

should be referred to qualified service personnel. Caution must be exercised, since improper servicing may cause

unsafe operation.

ge.com

If you are not satisfied with the service you receive from GE, contact us on our Website with all the details

including your phone number, or write to: General Manager, Customer Relations

GE Appliances, Appliance Park

Louisville, KY 40225

enhanced communication and prompt service under the terms of your warranty, should the need arise.

You may also mail in the preprinted registration card included in the packing material.

Consumer Support

GE - General Electric GE Profile' 30" Free-Standing Double Oven Range JB968SK2SS

Product's Documents

User Manual

Specifications

GE - General Electric JB968SK2SS Questions and Answers

Related Products

GE - General Electric GE Profile' 30" Free-Standing Double Oven Range JGB928BEK5BB

GE - General Electric GE Profile' 30" Free-Standing Double Oven Range JB968BK5BB

GE - General Electric GE Profile' 30" Free-Standing Double Oven Range JB968KK3CC

GE - General Electric GE Profile' 30" Free-Standing Double Oven Range JGB918WEK6WW

GE - General Electric GE Profile' 30" Free-Standing Double Oven Range JB968SL2SS

GE - General Electric GE Profile' 30" Free-Standing Double Oven Range JGB928KEK5CC
