Instruction for use
3
14
3a
3d*
1
Burst of steam button
2
Spray button
3
Variable steam control
a
Dry ironing
b
Steam ironing
c
Self Clean
d
Autosteam
*
4
Water Filling inlet
5
Spray nozzle
6
Maximum water level indicator
7
Soleplate
8
Water tank
9
Temperature control dial
10
Thermostat control light
11
Handle
12
Cord
13
Cord support
14
Auto-Off LED
DESCRIPTION
10
12
13
11
9
86 7
3
3c
3b*
4
5
1
2
* depending on model
4
IMPORTANT SAFETY
INSTRUCTIONS
When using an iron, basic precautions should always be followed,
including the following:
Read all instructions before using
1. Only use an iron for its intended use.
2. To avoid the risk of electric shock, do not immerse the iron in
water or other liquids.
3. Always turn the iron OFF before plugging or unplugging the iron
from the electrical outlet. Never pull on the cord to disconnect the
iron from the electrical outlet; instead, grasp the plug and pull on
the plug to disconnect the iron.
4. Do not let the cord touch hot surfaces. Let the iron cool comple-
tely before putting the iron away. Coil the cord loosely around the
iron when storing.
5. Always disconnect the iron from the electrical outlet before
filling the iron with water, emptying the water from the iron, and
when the iron is not in use.
6. Do not operate the iron with a damaged cord or in the event the
iron has been dropped or damaged. To avoid the risk of electric
shock, do not disassemble the iron. Take it to a qualified service-
man for examination and repair. Incorrect assembly might result
in a risk of electric shock when the iron is used after reassembly.
7. Close supervision is required for any appliance used by or near
children. Do not leave the iron unattended while the iron is connec-
ted or on an ironing board.
8. Burns can occur from touching hot metal parts, hot water, or
steam. Use caution when you turn a STEAM IRON upside down –
there might be hot water in the reservoir.
9. To avoid a circuit overload, do not operate an iron on the same
circuit with another high wattage appliance.
10. If an extension cord is absolutely necessary, a cord with an
ampere rating equal to or greater than the maximum rating of the
iron shall be used. A cord rated for less amperage can result in a
risk of fire or electric shock due to overheating. Care shall be taken
to arrange the cord so that it cannot be pulled or be tripped over.
11. This appliance is not intended for use by children and other
persons whose physical, sensory, or mental capabilities or lack of
experience and knowledge prevents them from using the appliance
5
Environment
Environment protection first !
i Your appliance contains valuable materials which can be recovered or
recycled.
Leave it at a local civic waste collection point.
BEFORE USE
1 • Unpacking
- Remove soleplate cover before using iron. Remove all
packaging from the iron.
- Please read all of the instructions for use and the
Important Safeguards carefully.
- It is normal for a small amount of smoke and a light
odor to be produced the first time it is used. This will
quickly disappear.
- Particles may emit from iron during first use.
They are not harmful and should disappear after iron has
been allowed to steam.
safely without supervision or instruction by a responsible person
to ensure that they can use the appliance safely.
12. Children should be supervised by the responsible person to
ensure that they do not play with the appliance.
13. The iron must be used and rested on a stable surface;
14. When placing the iron on its stand, ensure that the surface on
which the stand is placed is stable;
15. The iron is not to be used if it has been dropped, if there are
visible signs of damage or if it is leaking.
SPECIAL INSTRUCTIONS
16. The iron must not be left unattend while it is connected to
supply mains.
17. Always disconect the iron from the electrical outlet, before you
leave the room.
SAVE THESE INSTRUCTIONS
6
2 • Helpful Hints
- When ironing start with fabrics that require a low temperature setting (
•
)
and finish with those which need the highest temperature (
•••
).
- Mixed fiber fabrics should be ironed on the temperature for the most
delicate fabric. For example a shirt that is 60% cotton and 40% polyester
should be ironed at the (
•
) setting for synthetics.
- If spray starch is used, spray it onto the reverse side of the garment.
Allow starch to penetrate before ironing by setting garment aside for 30
seconds.
- For best results, use a mesh type ironing board to allow excess steam to
escape.
- For delicate fabrics, we recommend carrying out a test on an
unobtrusive area of the garment such as an inner seam.
- Adhere to manufacturer recommendations on garment label.
WATER RECOMMENDATIONS
1 • Tap water
Rowenta irons are designed to be used with REGULAR TAP WATER
(up to 12 grains of hardness). If your water is harder than this, Rowenta
recommends mixing half tap water with half bottled spring water which
reduces the hardness; or just use bottled spring water. Never use 100 %
distilled water as this can cause the iron to spit and leak.
2 • Softened water
There are many types of household water softeners and the water from
many of them is perfectly acceptable for use in an iron. However, some
types of softeners, particularly those that use chemicals such as salt, can
cause the appliance to leak or spit during use. If you experience this type
of problem, we recommend that you try using bottled spring water or
untreated tap water. Never use 100 % distilled water.
Once you have changed water it will take several uses to correct the problem.
Rowenta recommends trying the steam function for the first time on an old
towel or cloth that can be discarded to avoid damaging your clothes.
3 • Iron and other impurities
If your water supply contains large amounts of iron or organic matter,
these minerals can collect inside the appliance and eventually appear as
brown stains. If you experience these problems Rowenta recommends
using bottled spring water.
Never use 100 % pure distilled water.
ALWAYS REMEMBER: Battery water and water containing additives
(such as starch, perfume or fabric conditioner condensed water from
driers) may not be used. Such additives can affect the properties of
the steam and, at high temperatures, can form deposits in the steam
chamber, which will mark the laundry when they are emitted through
the steam vents.
Descaling liquids/agents should not be used.
4 • Filling with Water
- Ensure the iron is unplugged.
- Slide the variable steam control completely to the left.
- Rest the iron on heel and tilt it forward approximately
1 inch.
If the iron is equipped with a covered filling inlet, open
the filling inlet by sliding the cover down.
- Fill with water (containing no additives) to the max
mark on the water tank.
- If equipped with filling inlet cover, slide cover to close.
If you need to add water during ironing, UNPLUG the
iron and follow the steps above. Ensure iron heats back
to temperature afterwards, that means thermostat light
will go out.
5 • Selecting the Temperature
Set the iron temperature to suit the type of material
using the temperature control dial (fig.3).
Check the garment label for appropriate setting. We recommend
using the chart below as a guide.
7
8
IMPORTANT! The iron takes longer to cool down than to heat up.
We recommend that you start with fabrics to be ironed at a low
temperature. For mixed fabrics set the temperature for the most
delicate fabric.
TIP Always spray starch onto the reverse side of the fabric and wait 30
seconds before ironing to allow starch to be absorbed.
6 • Dry Ironing
To iron without steam, slide the variable steam control
lever to the
AUTO
position.
We recommend dry ironing with an empty tank.
Set the temperature for the type of material to be ironed.
7 • Steam Ironing
Steam is only produced when the temperature dial is set to the shaded
area (after
••
setting)
WARNING! Never iron or steam clothes while they are being worn.
Use caution and do not direct soleplate at people, animals, etc.
Before ironing for the first time fill iron and allow to heat.
The iron should be allowed to emit steam for at least 1 minute to
remove any impurities.
Press the burst of steam button a few times prior to ironing. This
should also be done if iron isn’t used regularly.
Synthetic fibers e.g.
viscose, polyester
Silk,
wool
Cotton, linen
Ironing
label
Temperature
control
Fabric
* depending on model
8 • Auto Steam*
For steam output to be automatically adjusted to the
soleplate temperature, turn the steam control to the
AUTO
position.
9 • Burst of Steam
This feature is ideal for removing stubborn wrinkles or
pressing in sharp creases.
When the temperature control is set to a steam setting
(•• or •••) the burst of steam can be used. Press the
button to generate a burst of steam.
Leave an interval of at least four seconds between
bursts.
10 • Vertical Steam
This feature is ideal for hanging clothes, drapes, curtains,
etc.
When the temperature control is set to a steam setting
vertical steam can be used.
To use feature, hold iron vertically with the tip tilted
forward slightly.
Press the burst of steam button repeatedly while moving
iron up the garment from bottom to the top.
If vertical steam output starts to decrease tilt iron
forward to a horizontal position and then back to vertical
to continue.
WARNING ! Never direct steam at persons or animals.
11 • Spray Setting
This feature is ideal for stubborn wrinkles or set in
creases. Ensure there is water in the tank then press the
spray button.
Do not spray silk.
9
* depending on model
10
12 • Anti-Drip System*
In order to produce steam, all irons require a high temperature.
If the soleplate is not hot enough some of the water will not turn to steam
and can spit or leak from the soleplate.
The Anti-Drip system automatically switches off the steam when ironing
at low temperatures to prevent spitting.
13 • 3-Way Smart Automatic Shut-Off*
If your iron is equipped with Auto-Off and
the iron is not moved while plugged in, an internal safety
switch will turn it off.
It will turn off in 8 minutes if left vertically
or in 30 seconds if left on its soleplate or tipped over.
AUTO-OFF IS NOT AN ON/OFF SWITCH.
ALWAYS UNPLUG WHEN NOT IN USE.
14 • Self Clean
WARNING! Do not use descaling agents. They can damage the lining
of the steam chamber.
This feature allows loose mineral deposits and other impurities to be
flushed from the soleplate.
Self Clean should be carried out occasionally and at least once a month.
- Fill the iron with tap water to the max mark on the
water tank.
- Be sure that variable steam lever is set to minimum.
- Stand the iron on heel and plug in.
- Set thermostat to (•••) setting.
- Once heated, unplug iron.
- Hold iron horizontally over the sink with the soleplate
pointing away from body.
- Move the variable steam lever completely to the right
and hold in the self clean position for one minute.
WARNING! Doing this will cause steam and hot water to be ejected
from the soleplate. Take all proper precautions and hold iron away
from body.
30 sec. 8 min.
* depending on model
- Move the iron gently back and forth and side to side until all water has
run through plate.
- Carefully wipe all water and material from the soleplate with
an old towel, as the water and minerals can stain the soleplate (although
this has no effect on glide or performance).
WARNING! Iron and soleplate may still be very hot.
Exercise care while wiping.
- Place iron on heel and leave to cool.
Before using iron after self cleaning, test steam and burst of steam on an
old towel or cloth than can be discarded.
15 • Vapodur Valve
To ensure the iron continues to steam efficiently, open and close the
valve a few times after each use. This is done by moving the variable
steam control lever left to right a few times.
16 • Anti-Calc System
- Minerals in water can build up in the steam chamber.
The Anti-Calc system contains a special material that
neutralizes the harmful minerals. This system is designed
to extend and maintain the high steam performance of the iron.
The cartridge is not replaceable.
NOTE: Do not use descaling agents in your iron.
17 • After Use
1. Turn the temperature dial to the min setting. Slide the steam
lever to the no steam position.
2. Unplug the appliance.
3. Place the iron on its heel and allow to cool completely.
4. Empty water from the appliance before storing.
We recommend emptying the iron when not in use.
5. To protect the soleplate, we recommend storing iron on its heel.
18 • Maintenance and Cleaning
Before cleaning ensure that the appliance is unplugged and completely
cooled down.
Never use household cleaners, abrasive cleaning pads or solvents.
11
* depending on model
12
19 • Cleaning the Soleplate
Rowenta soleplates have excellent non-stick properties and can be wiped
clean when cold.
- In normal use a draggy coating may build up on the soleplate (starch,
detergent build-up, burnt synthetic fibers). This can be easily removed by
using the Rowenta Soleplate Cleaning Kit or a quality hot iron soleplate
cleaner available at most stores. The Rowenta kit is also available
through our website: www.rowentausa.com
- To prevent scratching of the soleplate, do not iron over sharp objects
(zippers, etc.). Do not place the iron on rough surfaces, e.g. metal iron
support, which may scratch the soleplate.
20 • Troubleshooting
13
* depending on model
Issues
Iron does not heat.
Not enough steam.
Iron is emitting a brown
or white substance.
Iron is leaking.
Solutions
Set the temperature
control to a higher
temperature.
Check that iron is plugged
in correctly.
Move iron or shake it
gently to reactivate.
Fill the water tank.
See section called
"Steam Ironing”.
Wait for the soleplate to
reach correct temperature.
See section "Water
Recommendations”.
Switch to spring water or
mix tap water with spring
water.
Ensure garment is rinsed
thoroughly to remove any
detergent deposits or
chemicals on new
garments.
Allow more time between
each burst.
See section "Water
Recommendations”.
Switch to spring water or
mix tap water with spring
water.
Do not fill past max line
on tank. Be sure to close
filling inlet.
Possible causes
The temperature control
is set too low.
Not properly plugged in.
Auto-off has engaged*.
There is insufficient water
in the tank.
Iron is not set to a steam
setting.
The Anti-Drip function is
active *.
Water may need to be
changed due to hardness
or organic matter.
Garment has not been
rinsed sufficiently.
Over use of burst button.
Distilled or softened water
being used.
Overfilled.
If troubleshooting does not assist, before consulting the retailer regarding their return/exchange
policy, please telephone consumer service at 781-396-0600.
1103481042-04 - 45/16
: www.rowenta.com
ROWENTA INTERNATIONAL GUARANTEE
Date of purchase: �����������������������������������������������������������������������������������������������������������������������������������
Product reference:����������������������������������������������������������������������������������������������������������������������������������
Retailer name & address: ����������������������������������������������������������������������������������������������������������������������
02/2015
Distributor stamp: ���������������������������������������������������������������������������������������������������������������������������
INTERNATIONAL GUARANTEE: COUNTRY LIST
U.S.A.
Groupe SEB USA - 2121 Eden Road -
Millville, NJ 08332 USA
1 year 800-769-3682
