EN
1
Before using the appliance carefully read Health and Safety guide.
APPLIANCE
PRODUCT DESCRIPTION
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT.
In order to receive a more complete assistance, please
register your appliance on: www.whirlpool.eu/register
You can download the Safety Instructions and the
Use and Care Guide, by visiting our website
docs.whirlpool.eu and following the Instructions on
the back of this booklet.
1. Upper rack
2. Foldable aps
3. Upper rack height adjuster
4. Upper spray arm
5. Lower rack
6. Power Clean support
7. Cutlery basket
8. Lower spray arm
9. Filter Assembly
10. Salt reservoir
11. Detergent and Rinse Aid dispensers
12. Rating plate
13. Control panel
6
1
2
3
4
5
7
8
10
9
1112
13
0000 000 00000
Service:
1112
4
1
3
2
9 16
14
15
65 7 8 11 12 1310
1. On-O/Reset button with indicator light
2. Program selection button with indicator light
3. Multizone button with indicator light
4. Sani Rinse button with indicator light / Key lock
5. Eco program indicator light
6. Key lock indicator light
7. Display
8. Program number and remaining time indicator
DAILY REFERENCE
GUIDE
CONTROL PANEL
9. Tablet (Tab) indicator light
10. Closed water tap indicator light
11. Rinse Aid rell indicator light
12. Salt rell indicator light
13. Power Clean button with indicator light
14. Tablet (Tab) button with indicator light
15. Delay button with indicator light
16. Start/Pause button with indicator light / Drain out
