TABLE OF CONTENTS
www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352
All about the
Use & Care
of your Refrigerator
Important Safety Instructions ......................2
Features at a Glance ...................................4
Installation ................................................5
Door Removal Instructions ..........................9
Installing Door Handles .............................11
Connecting Water Supply .......................... 14
Controls ...................................................16
Automatic Ice Maker ................................. 18
242292001 (December 2012)
Storage Features ...................................... 19
Storing Food and Saving Energy ................23
Normal Operating Sounds and Sights ......... 24
Changing the Filter ................................... 25
Care and Cleaning ....................................27
Before you Call .........................................30
Major Appliance Warranty .........................32
2
WARNING
WARNING indicates a potentially hazardous
situation which, if not avoided, could result
in death or serious injury.
IMPORTANT
IMPORTANT indicates installation, operation
or maintenance information which is
important but not hazard-related.
DANGER
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in
death or serious injury.
Denitions
This is the safety alert symbol. It is used to
alert you to potential personal injury hazards.
Obey all safety messages that follow this
symbol to avoid possible injury or death.
Doors
Handles are secure and tight
Door seals completely to cabinet on all
sides
Freezer drawer is level across the top
Leveling
Refrigerator is level, side-to-side and
tilted ¼ inch (6 mm) front-to-back
Toe grille is properly attached to
refrigerator
Cabinet is setting solid on all corners
Electrical Power
House power turned on
Refrigerator plugged in
Ice Maker (select models)
House water supply connected to
refrigerator
No water leaks present at all
connections - recheck in 24 hours
Ice maker is turned ON
Final Checks
Shipping material removed
Fresh food and freezer temperatures set
Crisper humidity controls set
Registration card sent in
Installation Checklist
CAUTION
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in
minor or moderate injury.
IMPORTANT SAFETY INSTRUCTIONS
For your Safety
• DO NOT store or use gasoline, or other
ammableliquidsinthevicinityofthisor
any other appliance. Read product labels
forwarningsregardingammabilityand
other hazards.
• DO NOT operate the refrigerator in the
presence of explosive fumes.
• Avoid contact with any moving parts of
automatic ice maker.
• Remove all staples from the carton. Staples
can cause severe cuts, and also destroy
nishesiftheycomeincontactwithother
appliances or furniture.
WARNING
Please read all instructions before using this
refrigerator.
Child Safety
Destroy or recycle the carton, plastic bags, and
any exterior wrapping material immediately
after the refrigerator is unpacked. Children
should never use these items to play. Cartons
covered with rugs, bedspreads, plastic sheets
or stretch wrap may become airtight chambers,
andcanquicklycausesuffocation.
Proper Disposal of your
Refrigerator or Freezer
Risk of child entrapment
Child entrapment and suffocation are not
problems of the past. Junked or abandoned
refrigerators or freezers are still dangerous
– even if they will sit for “just a few days”. If
you are getting rid of your old refrigerator or
freezer, please follow the instructions below to
help prevent accidents.
3
IMPORTANT SAFETY INSTRUCTIONS
Grounding type wall receptacle
Power cord with
3-prong grounded plug
Do not, under
any circumstances,
cut, remove,
or bypass the
grounding prong.
Electrical information
• The refrigerator must be plugged into its
own dedicated 115 Volt, 60 Hz., 15 Amp,
AC only electrical outlet. The power cord of
theapplianceisequippedwithathree-
prong grounding plug for your protection
against electrical shock hazards. It must be
plugged directly into a properly grounded
three prong receptacle. The receptacle
must be installed in accordance with local
codesandordinances.Consultaqualied
electrician. Avoid connecting refrigerator to
a Ground Fault Interrupter (GFI) circuit. Do
not use an extension cord or adapter plug.
• If the power cord is damaged, it should
be replaced by an authorized service
technician to prevent any risk.
IMPORTANT
Pressing and holding the On/Off button for
three seconds, located on the left side of
the temperature control panel will disable
your refrigerator’s cooling system, but does
not disconnect the power to the light bulb
and other electrical components. To turn off
power to your refrigerator you must unplug
the power cord from the electrical outlet.
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden
temperature change.
• Never unplug the refrigerator by pulling on
thepowercord.Alwaysgriptheplugrmly,
and pull straight out from the receptacle to
prevent damaging the power cord.
• Unplug the refrigerator before cleaning
and before replacing a light bulb to avoid
electrical shock.
• Performance may be affected if the voltage
varies by 10% or more. Operating the
refrigeratorwithinsufcientpowercan
damage the compressor. Such damage is
not covered under your warranty.
• Do not plug the unit into an electrical outlet
controlled by a wall switch or pull cord to
prevent the refrigerator from being turned
off accidentally.
IMPORTANT
CFC/HCFC Disposal
Your old refrigerator may have a
cooling system that used CFCs
orHCFCs(chlorouorocarbonsor
hydrochlorouorocarbons).CFCsandHCFCs
are believed to harm stratospheric ozone if
released to the atmosphere. Other refrigerants
may also cause harm to the environment if
released to the atmosphere.
If you are throwing away your old refrigerator,
make sure the refrigerant is removed for
properdisposalbyaqualiedtechnician.If
you intentionally release refrigerant, you may
besubjecttonesandimprisonmentunder
provisions of environmental legislation.
Proper Disposal of Refrigerators/
Freezers
We strongly encourage responsible appliance
recycling/disposal methods. Check with your utility
company or visit www.energystar.gov/recycle for
more information on recycling your old refrigerator.
Before you throw away your old
refrigerator/freezer:
• Remove doors.
• Leave shelves
in place so
children may
not easily
climb inside.
• Have
refrigerant
removed by
aqualied
service technician.
4
FEATURES AT A GLANCE
*Features may vary according to model
Toe Grille
SpillSafe™ Shelf
Dairy
Compartment
Ice Bin
*Ice Maker
Freezer Baskets
Crisper Drawer
Crisper
Drawer
Water Filter
Adjustable
Hinges
*LED Cluster Light
Door Bin
Flipper Guide
Flipper Mullion
Deli Drawer
Air Filter
*LED Cluster Light
*LED
Cluster Light
Slide Under
Shelf
*LED
Cluster Light
*LED Cluster Light
*LED Cluster Light
IMPORTANT
Features not included with your refrigerator can be purchased at www.frigidaire.com
or by calling 1-800-944-9044.
5
NOTE
If your refrigerator is placed with the door
hinge side against a wall, you may have to
allow additional space so the door can be
opened wider.
INSTALLATION
CAUTION
Do Not install the refrigerator where the
temperature will drop below 55°F (13°C) or
rise above 110°F (43°C). The compressor
will not be able to maintain proper
temperatures inside the refrigerator.
Do Not block the toe grille on the lower front
ofyourrefrigerator.Sufcientaircirculation
is essential for the proper operation of your
refrigerator.
This Use & Care Guide provides general
installation and operating instructions for
your model. We recommend using a service
or kitchen contracting professional to install
your refrigerator. Use the refrigerator only as
instructed in this Use & Care Guide. Before
starting the refrigerator, follow these important
rststeps.
Location
• Choose a place that is near a grounded,
non-GFCI, electrical outlet. Do Not use an
extension cord or an adapter plug.
• If possible, place the refrigerator out of
direct sunlight and away from the range,
dishwasher, or other heat sources.
• Therefrigeratormustbeinstalledonaoor
that is level and strong enough to support
a fully loaded refrigerator.
• Consider water supply availability for
modelsequippedwithanautomaticice
maker.
• Allow the following clearances for ease
of installation, proper air circulation, and
plumbing and electrical connections:
Sides & Top 3/8 inch (9.5 mm)
Back 1 inch (25.4 mm)
Door opening
Your refrigerator should be positioned to allow
easy access to a counter when removing
food. For best use of refrigerator drawers and
freezer baskets, the refrigerator should be in a
position where both can be fully opened.
Top Hinge
Cover Front
Screw
Top Hinge
Cover Rear
Screw
Lower
Hinge
Screw
Top
Hinge
Screw
Components Provided:
Required Tools
You will need the following tools:
Adjustable
Wrench
3/8" Fixed
Wrench
Phillips Head
or
#2 Square
Drive Head
(OR)
Tools Necessary:
Socket
Wrench Set
Installation
6
INSTALLATION
Toe Grille Must
Fit in Slot on
Anti-tip Bracket
Screw/Washer
Assembly
(3) Retaining Clips
Leveling Freezer Drawer
(if necessary)
To level the cabinet using the front
rollers (select models):
1 Slightly open freezer drawer. Lift the
toe grille and gently pull forward (see
illustration).
2 Youcanraiseorlowereachdoor.Usea⅜
inch socket wrench to turn the adjustment
screws (one per side).
1 Check gasket seal around top, bottom,
and sides of freezer drawer.
2 If gasket is not sealed, open drawer and
slightly loosen four drawer screws (two on
each side) to allow drawer to rotate.
3 Close drawer and recheck the seal on the
gasket (A). Open the drawer grabbing by
the sides in the center (B). Be careful not
to rotate the drawer.
4 Tighten four drawer screws.
5 Recheck gasket seal.
Push
Against
Freezer
Drawer
Grab Drawer
At Center
From Both
Sides Then
Pull Drawer
Out
A B
Remove Hex
Head Drawer
Screw
Remove Hex
Head Drawer
Screw
Do Not Remove
Other Screws
Do Not Remove
Other Screws
Remove Hex
Head Drawer
Screw
Remove Hex
Head Drawer
Screw
Raise
Lower
Anti-tip
Leg
Door
Door
5 Installthetoegrillebyttingintoplace.
Level Refrigerator & Adjust Doors
(if necessary)
Guidelines for nal positioning of your
refrigerator:
• All four corners of the cabinet must rest
rmlyontheoor.
• The sides should tilt ¼ inch (6 mm) from
front to back (to ensure that doors close
and seal properly).
• Doors should align with each other and be
level.
Most of these conditions can be met by raising
or lowering the adjustable front rollers.
To raise: turn adjustment screw clockwise.
To lower: turn adjustment screw
counterclockwise.
3 Ensure both doors are bind-free with their
seals touching the cabinet on all four sides
and that cabinet is stable.
4 After unit is leveled, lower anti-tip leg until
itcontactstheoor.
7
To adjust the door stop:
Door stop is adjustable between 85 to 145
degrees.
1 Open door to provide access to screw.
2 Loosen screw.
3 Adjust door to desired location.
4 Rotate door stop until it makes contact
with the lower hinge.
5 Retighten screw.
Open
Door
90
Degrees
A
B
Loosen or Remove
Screw
Bottom of Door
Loosen/Remove Screw (where applicable)
6 Ensure door stops in desired location
before resuming normal use.
To level the doors using the adjustable
lower hinge (select models):
1 Remove all food items from door bins on
door being adjusted.
2 Open doors to 90 degrees.
3 Loosen or remove screw.
Rotate
Door to Desired
Location
Adjusting Door
Rotate
Door
Stop
Re-tighten
Screw
Retighten Screw
Adjustable Door Stop
Door
Stop
Screw
Lower
Hinge
Min
Open
Max
Open
INSTALLATION
NOTE
View shown is looking up at the bottom of
the refrigerator door.
NOTE
Adjustable hinge should only be used after
doors have been leveled with rollers.
8
Flipper
Mullion
Screw
Flipper
Mullion
Hinge
Adjusting Flipper Mullion Screw
To adjust the ipper mullion:
1 Loosenthescrewlocatedontheipper
mullion hinge.
2 Adjustippermullionheight.Forproper
connectionwiththeippermullionguide,
there should be a separation about the
thickness of a coin (0.060 inches, or
1.5mm)betweentheguideandipper
mullion.
3 Retighten screw.
4 Lift the door while adjusting the washer.
To raise the door, rotate washer clockwise
(when viewed from the bottom). To lower
door, rotate washer counterclockwise
(when viewed from the bottom).
Flipper
Mullion
Mullion
Guide
Thickness
of a Coin
Adjusting Flipper Mullion Height
Lower
Door
Hinge
Washer
Raise
Door
Raising/Lowering Door
INSTALLATION
9
DOOR REMOVAL INSTRUCTIONS
To remove the refrigerator doors:
1 Trace lightly around the door’s top hinges
with a pencil. This makes reinstallation
easier.
2 Disconnect the harness by grasping both
sidesoftheconnectorrmly,depressthe
latch, and pull apart. Remove the two
screws from the top hinge. Lift the door
off of the bottom hinge and set it aside.
Getting through narrow spaces
Ifyourrefrigeratorwillnottthroughan
entrance area, you can remove the doors.
Checkrstbymeasuringtheentrance.
To prepare for removing the doors:
1 Make sure the electrical power cord is
unplugged from the wall outlet.
2 Open the freezer drawer and remove the
toe grille (see “Installation” section).
3 Remove any food from the door shelves
and close the doors.
To remove the top hinge covers:
1 Remove the two screws from each cover
over the top door hinges.
2 Lift inside edge of hinge cover and tilt back.
Rear
Cover
Screw
Front
Cover Screw
Top Hinge
Cover
Hinge
Screws
Two Wire
Cables
Leave
Hinge
With
Door
Top
Hinge
Ground
Screw
NOTE
DO NOT remove the ground screw from
hinge.
Rear
Cover
Screw
Ground
Screw
Top
Hinge
Top Hinge
Cover
Hinge
Screws
Multi-wire
Cables
Leave
Hinge
With
Door
Front
Cover Screw
10
CAUTION
Be sure doors are set aside in a secure
position where they cannot fall and cause
personal injury, or damage to the doors or
handles.
CAUTION
Drawer is heavy. Use caution when lifting.
DOOR REMOVAL INSTRUCTIONS
Once both doors are in place, ensure they are
aligned with each other and level (Please see
the “Installation” section for more details), and
replace the top hinge cover.
Lower Hinge Removal
4 Unscrew the three lower hinge screws and
hinge if necessary.
To reinstall the right door, reverse the above
steps.
Removing Freezer Drawer
1 Open freezer drawer.
2 Remove drawer screws on right and left
sides (two screws on each side).
3 Lift drawer up and out to remove.
Installing Freezer Drawer
1 With lower slides pulled out, hang drawer
onto slide brackets ensuring pins on each
side are fully inserted into slots on each side.
6 Tighten four drawer screws.
7 Recheck gasket seal.
8 Installthetoegrillebyttingintoplace.
2 Reinstall four drawer screws (two per
side), tighten down, and close drawer (C).
Push
Against
Freezer
Drawer
Grab Drawer
At Center
From Both
Sides Then
Pull Drawer
Out
A B
Assembly
Drawer Slides
Pin
Slot
Cabinet
Drawer
Fully Extend
Install Screws
(2) Each Side
3 Check gasket seal around top, bottom,
and sides of freezer drawer.
4 If gasket is not sealed, open drawer and
slightly loosen four drawer screws (two on
each side) to allow drawer to rotate.
5 Close drawer and recheck the seal on the
gasket (A). Open the drawer grabbing by
the sides in the center (B). Be careful not
to rotate the drawer.
NOTE
You will be pulling approximately three
feet of water tube from the back of the
refrigerator.
Remove Hex
Head Drawer
Screw
Remove Hex
Head Drawer
Screw
Do Not Remove
Other Screws
Do Not Remove
Other Screws
Remove Hex
Head Drawer
Screw
Remove Hex
Head Drawer
Screw
11
INSTALLING DOOR HANDLES
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
NOTE
All set screws should be tightened so the screw is below
the surface of the handle. The handles should be drawn
tight to freezer and refrigerator doors with no gaps.
Opening the opposite door while tightening the Allen
screw makes installation easier.
The door handle may loosen over time or if it was
installed improperly. If this happens, tighten the set
screws on the handles.
Door Handle Mounting
Instructions for
Frigidaire
1 Remove handles from carton
and any other protective
packaging.
2 Position fresh food handle
end caps over upper and
lower pre-installed shoulder
bolts (A) that are fastened
into door, ensuring the holes
for the set screws are facing
towards the opposite door.
3 Whileholdinghandlermly
against door, fasten upper
and lower Allen set screws
(B) with supplied Allen
wrench.
4 Repeat steps 2 and 3 to
install opposite handle.
Ensure the holes for the set
screws are facing towards
therstdoor.
5 Position freezer handle end
caps over left and right
pre-installed shoulder bolts
that are fastened to the door,
ensuring the holes for the set
screws are facing down.
6 Whileholdinghandlermly
against door, loosely tighten
right Allen set screw (B) with
supplied Allen wrench until
there is no gap between
handle and door.
7 Stillholdingthehandlermly
tothedoor,rmlytighten
left Allen set screw (B) with
supplied Allen wrench.
8 Return to the right Allen set
screw(B)andrmlytighten
with supplied Allen wrench.
Mounting Freezer Handle
Mounting Refrigerator Handles
12
INSTALLING DOOR HANDLES
Door Handle Mounting
Instructions for
Frigidaire Gallery®
1 Remove handles from carton
and any other protective
packaging.
2 Position fresh food handle
end over upper and lower
pre-installed shoulder bolts
(A) that are fastened into
door, ensuring the holes for
the set screws are facing
towards the opposite door.
3 Whileholdinghandlermly
against door, fasten upper
and lower Allen set screws
(B) with supplied Allen
wrench.
4 Repeat steps 2 and 3 to
install opposite handle.
Ensure the holes for the set
screws are facing towards
therstdoor.
5 Position freezer handle end
over left and right pre-
installed handle mounts that
are fastened to the door,
ensuring the holes for the set
screws are facing down.
6 Whileholdinghandlermly
against door, loosely tighten far
right Allen set screw (B) with
supplied Allen wrench until
there is no gap between handle
and door.
7 Stillholdingthehandlermlyto
thedoor,rmlytightenfarleft
Allen set screw (B) with supplied
Allen wrench.
8 Return to the far right Allen set
screw(B)andrmlytighten
with supplied Allen wrench.
Mounting Refrigerator Handles
Mounting Freezer Handle
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
NOTE
All set screws should be tightened so the screw is below
the surface of the handle. The handles should be drawn
tight to freezer and refrigerator doors with no gaps.
Opening the opposite door while tightening the Allen
screw makes installation easier.
The door handle may loosen over time or if it was
installed improperly. If this happens, tighten the set
screws on the handles.
13
Door Handle
Mounting Instructions
for Frigidaire
Professional®
1 Remove handles from carton
and any other protective
packaging.
2 Position fresh food handle
end over upper and lower
pre-installed shoulder bolts
(A) that are fastened into
door, ensuring the holes for
the set screws are facing
towards the opposite door.
3 Whileholdinghandlermly
against door, fasten upper
and lower Allen set screws
(B) with supplied Allen
wrench.
4 Repeat steps 2 and 3 to
install opposite handle.
Ensure the holes for the set
screws are facing towards
therstdoor.
5 Position freezer handle end
over left and right pre-
installed handle mounts that
are fastened to the door,
ensuring the holes for the set
screws are facing down.
6 Whileholdinghandlermly
against door, loosely tighten
far right Allen set screw (B)
with supplied Allen wrench
until there is no gap between
handle and door.
7 Stillholdingthehandlermlyto
thedoor,rmlytightenfarleft
Allen set screw (B) with supplied
Allen wrench.
8 Return to the far right Allen set
screw(B)andrmlytighten
with supplied Allen wrench.
9 Firmly tighten the inside Allen
set screws.
INSTALLING DOOR HANDLES
Mounting Refrigerator Handles
Mounting Freezer Handle
CAUTION
Wear gloves and safety goggles. Use extreme CAUTION when installing these handles.
NOTE
All set screws should be tightened so the screw is below
the surface of the handle. The handles should be drawn
tight to freezer and refrigerator doors with no gaps.
Opening the opposite door while tightening the Allen
screw makes installation easier.
The door handle may loosen over time or if it was
installed improperly. If this happens, tighten the set
screws on the handles.
14
WARNING
To avoid electric shock, which can cause
death or severe personal injury, disconnect
the refrigerator from electrical power before
connecting a water supply line to the
refrigerator.
NOTE
Check with your local building authority
for recommendations on water lines and
associated materials prior to installing your
new refrigerator. Depending on your local/
state building codes, Frigidaire recommends
for homes with existing valves its Smart
Choice
®
water line kit 5305513409 (with
a 6 ft. Stainless Steel Water Line) and for
homes without an existing valve, Frigidaire
recommends its Smart Choice
®
water line
kit 5305510264 (with a 20 ft. Copper Water
Line with self-tapping saddle valve). Please
refer to www.frigidaire.com/store for more
information.
CAUTION
To Avoid Property Damage:
• Copper or Stainless Steel braided tubing
is recommended for the water supply
line. Water supply tubing made of ¼
inch plastic is not recommended to be
used. Plastic tubing greatly increases
the potential for water leaks, and the
manufacturer will not be responsible for
any damage if plastic tubing is used for
the supply line.
• DO NOT install water supply tubing in
areas where temperatures fall below
freezing.
• Chemicals from a malfunctioning softener
can damage the ice maker. If the ice
maker is connected to soft water, ensure
that the softener is maintained and
working properly.
IMPORTANT
Ensure that your water supply line
connections comply with all local plumbing
codes.
CONNECTING THE WATER SUPPLY
Before Installing The Water Supply Line,
You Will Need:
• Basic Tools:adjustablewrench,at-blade
screwdriver, and Phillips
TM
screwdriver
• Access to a household cold water line with
water pressure between 30 and 100 psi.
• A water supply line made of ¼ inch (6 mm)
OD, copper or stainless steel tubing. To
determine the length of tubing needed,
measure the distance from the ice maker
inlet valve at the back of the refrigerator
to your cold water pipe. Then add
approximately 7 feet (2.1 meters), so the
refrigerator can be moved out for cleaning
(as shown).
• A shutoff valve to connect the water supply
line to your household water system. DO
NOT use a self-piercing type shutoff valve.
• Donotreusecompressionttingoruse
thread seal tape.
• A compression nut and ferrule (sleeve) for
connecting a copper water supply line to the
ice maker inlet valve.
15
To Connect Water Supply Line To Ice
Maker Inlet Valve
1. Disconnect refrigerator from electric power
source.
2. Place end of water supply line into sink or
bucket.TurnONwatersupplyandush
supply line until water is clear. Turn OFF
water supply at shutoff valve.
3. Remove plastic cap from water valve inlet
and discard cap.
4. If you use copper tubing - Slide brass
compression nut, then ferrule (sleeve)
onto water supply line. Push water
supply line into water valve inlet as far
as it will go (¼ inch/6 mm). Slide ferrule
(sleeve)intovalveinletandngertighten
compression nut onto valve. Tighten
another half turn with a wrench; DO NOT
overtighten. See Figure 1.
If you use stainless steel tubing - The
nut and ferrule are already assembled on
the tubing. Slide compression nut onto
valveinletandngertightencompression
nut onto valve. Tighten another half turn
with a wrench; DO NOT overtighten. See
Figure 2.
5. With steel clamp and screw, secure water
supply line (copper tubing only) to rear
panel of refrigerator as shown.
6. Coil excess water supply line (copper
tubing only), about 2½ turns, behind
refrigerator as shown and arrange coils so
they do not vibrate or wear against any
other surface.
7. Turn ON water supply at shutoff valve and
tighten any connections that leak.
8. Reconnect refrigerator to electrical power
source.
Steel
Clamp
Stainless
Steel
water Line
Water Valve
Bracket
Valve Inlet
Water Valve
6 ft. Stainless Steel water line
from household water supply
Plastic Water Tubing
to Ice Maker
Fill Tube
Figure 2
Figure 1
Plastic Water
Tubing to Ice
Maker Fill
Tube
Steel
Clamp
Brass
Compression
Nut
Ferrule
(Sleeve)
Copper
water line
Water Valve
Bracket
Valve Inlet
Water Valve
Copper water line
from household
water supply
(Include enough tubing in loop
to allow moving refrigerator out
for cleaning.)
CONNECTING THE WATER SUPPLY
16
CONTROLS
Options may vary
A red indicator light will be illuminated above most active features.
Touch the icon to activate the options below.
quickice Increasestheproductionofice
waterlter Pressandholdforthreesecondstoresetafterlter
change.
C/F Touch to toggle display from Fahrenheit to Celsius.
default settings Resets all refrigerator settings such as temp, temp
display and tones to their factory default settings.
Power on-off Press and hold for three seconds to turn off the cooling
system to clean the refrigerator. It also turns off the ice
maker. The temperature displays will read OFF.
Energy Saver Keep this switch set on energy saver (light on) for low-
est energy usage. If moisture appears on the cabinet
between the doors, pressing this button will turn the light
off and enable an electric heater used to reduce moisture
on the cabinet between the doors.
Setting cooling temperatures
Press the “∧” or “∨” indicator to adjust the temperature to the
desired setting.
Thetemperaturedisplaywillbegintoblinkwiththersttouch.The
display will time out after 10 seconds and return to the basic display.
Alarms
Door Ajar If the door has been left open for an extended period
of time, an alarm will sound and the door ajar indicator
will display on the bottom display of the control panel.
The alarm is turned off by closing the door. The mute
sounds key will blink to prompt the reset of any active
alarms. Press this key to reset any system alarms.
High Temp In the event of a high temperature condition, the
temperature display will blink and display “HI”. After
20 minutes, the alarm will sound and the high temp
indicator will be red on the bottom of the control panel.
The mute sounds icon will illuminate until pressed,
acknowledging the alarm, at which time the highest
temperature reached will be displayed and the refrigera-
tor will resume normal operation. In case the high temp
alarmisnotacknowledgedattherstalarmsoundtime
out,whenthedoorisrstopened,thealarmsoundwill
be repeated.
Power Fail In the event of a power failure, the power fail alert
will be displayed and the temperature display will blink
until the mute sounds icon is pressed, acknowledging
the alarm. Other modes may be turned off until the
alarm is acknowledged. The power fail alert is turned
off and the refrigerator will resume normal operation.
The high temp alarm may also be illuminated until a
safe operating range temperature has been reached.
IMPORTANT
Pressing the system on-off icon does not turn off power to your
refrigerator. You must unplug the power cord from the wall outlet.
17
CONTROLS
The Sabbath Mode is a feature that disables
portions of the refrigerator and its controls
in accordance with observance of the weekly
Sabbath and religious holidays within the
Orthodox Jewish community.
Sabbath Mode is turned ON and OFF by
pressing and holding both the freezer “∨” and
refrigerator “∧”indicatorsforveseconds.The
display shows “Sb” while in Sabbath mode.
In the Sabbath Mode, the High Temp alarm
(some models) is active for health reasons. If
a high temperature alarm is activated during
this time, for example due to a door left ajar,
the alarm will sound intermittently for about
10 minutes. The alarm will then silence on
its own and a red high temperature icon will
display. The high temp icon will continue to
display, even if the door is closed, until the
Sabbath mode is exited and the icon reset.
The refrigerator will function normally once
the door is closed, without any violation of the
Sabbath/Holidays.
For further assistance, guidelines for proper
usage and a complete list of models
with the Sabbath feature, please visit
the web at http:\\www.star-k.org.
Sabbath Mode
NOTE
While in Sabbath Mode, neither the lights
nor the control panel will work until Sabbath
Mode is deactivated.
Refrigerator stays in Sabbath Mode
after power failure recovery. It must be
deactivated with the buttons on the control
panel.
18
IMPORTANT
Your ice maker is turned on at the factory
so it can work as soon as you install your
refrigerator. If you cannot connect a water
supply, lift the ice maker’s wire signal arm
to turn it off. Otherwise, the ice maker’s
llvalvemaymakealoudchatteringnoise
when it attempts to operate without water.
CAUTION
If the water supply to your refrigerator is
softened, be sure the softener is properly
maintained. Chemicals from a water softener
can damage the ice maker.
CAUTION
NEVER use an ice pick or similar sharp
instrument to break up the ice. This could
damage the ice bin and dispenser mechanism.
To loosen stuck ice, use warm water.
Before replacing the ice bin, make sure it is
completely dry.
AUTOMATIC ICE MAKER (select models)
Ice maker operation & care
After the refrigerator is installed properly, the
ice maker can produce ice within 24 hours. It
cancompletelyllanicebininaboutthree
days.
Whenusingtheicemakerforthersttimeand
in order for the ice maker to work properly, it is
necessarytoclearairfromwaterltertubing.
Once ice maker begins making ice, allow the
buckettollcompletely,thendiscardthe
rstTWOFULLbucketsofice.Itwilltakeat
leasttwodaystocompletelyllthebucketon
regular ice making mode or 1½ days on fast
ice mode.
The ice maker produces approximately four
pounds of ice every 24 hours depending on
usage conditions.
Turning the ice maker on and off
Ice production is controlled by lifting/lowering
the ice maker’s wire signal arm. To gain access
to the ice maker, pull the freezer drawer out. Lift
the wire signal arm to turn the ice maker OFF
and lower the wire signal arm to turn it ON.
Ice maker tips
• If your refrigerator is not connected to a
water supply or the water supply is turned
off, turn off the ice maker by lifting wire
signal arm.
Clean the ice maker and ice bin at regular
intervals, especially prior to vacation or moving.
1 Turn off the ice maker.
2 Remove the ice bin.
3 Empty and carefully clean the ice bin
with mild detergent. Do not use harsh or
abrasive cleaners. Rinse with clean water.
4 Allow the ice bin to dry completely before
replacing in the freezer.
5 Replace the ice bin. Turn the ice maker on.
Remove and empty the ice bin if:
• An extended power failure (one hour or
longer) causes ice cubes in the ice bin to
melt and freeze together.
Remove the ice bin and shake to loosen the
cubes or clean as explained above.
• The following sounds are normal when the
ice maker is operating:
- Motor running
- Ice dropping into ice bin
- Water valve opening or closing
- Running water
• Ice cubes stored too long may develop an
oddavor.Emptytheicebinasexplained
below.
Quick Ice Function
YourrefrigeratorisequippedwithaQuickIce
Function, that increases ice production. This
function terminates automatically.
Cleaning the ice maker
Wire
Signal Arm
19
CAUTION
To avoid personal injury or property
damage, handle tempered glass shelves
carefully. Shelves may break suddenly if
nicked, scratched, or exposed to sudden
temperature change. Allow the glass shelves
to stabilize to room temperature before
cleaning. Do not wash in dishwasher.
STORAGE FEATURES
Your refrigerator includes SpillSafe
TM
glass
shelves that are designed to catch and hold
accidental spills.
You can easily adjust shelf positions in the
fresh food compartments to suit your needs.
The shelves have mounting brackets that
attach to slotted supports at the rear of each
compartment.
To change the position of a shelf:
1 Remove all food from the shelf.
2 Lift the front edge up and pull the shelf
out.
3 Replace by inserting the mounting bracket
hooks into the desired support slots.
4 Lower the shelf and lock into position.
Shelf features
Drawers
Your refrigerator includes a variety of storage
drawers.Thesedrawersarelocatedinxed
positions at the bottom of the fresh food
compartment.
Crispers
Crisper drawers are designed for storing fruits,
vegetables, and other fresh produce.
SpillSafe
TM
Shelf
Opening Crisper Drawer
Slide-Under Shelf
NOTE
Features may vary according to model.
20
STORAGE FEATURES
Deli drawer
Ideal for storage of deli meats and cheese.
Adjustable Door Bin
6 Place bin liner into bin.
Doors
Storage bins
The doors to your fresh food compartment use
a system of modular storage bins. All of these
bins are removable for easy cleaning. Some of
themhavexedpositions,whileotherscanbe
adjusted to your needs.
Door bins are ideal for storing jars, bottles,
cans, and large drink containers. They also
enablequickselectionoffrequentlyused
items.
To change the position of an adjustable
door bin:
1 Remove all food from the door bin.
2 Gripthebinrmlywithbothhandsandlift
it upward.
3 Remove the bin.
4 Place the bin just above desired position.
5 Lower the bin onto supports until locked in
place.
Adjusting Crisper Humidity
Crisper humidity control
Crisper drawers include a sliding control for
adjusting the humidity inside the crisper. Leafy
vegetables keep best when stored with the
Humidity Control set on Higher Humidity. Fresh
fruits keep best when stored with the Humidity
Control set on Lower Humidity.
Removing Crisper Drawer
To remove the Crisper Drawer for cleaning:
1 Pull the drawer out until it stops.
2 Lift the front slightly and remove the drawer.
Vegetables Fruits
Humidity Control
Higher
Humidity
Lower
Humidity
21
Accessories (varies by model)
Dairy compartment
Use the dairy
compartment,
at the top of
the fresh food
compartment
door, for short-
term storage
of cheese,
spreads, or
butter. The dairy
compartment is
designed to be
warmer than the
open area and includes a lift-up cover and a
dairy divider (select models).
Dairy Compartment
STORAGE FEATURES
Freezer Features (varies by model)
To Remove Upper Basket
1 Remove
all items
from
basket.
2 Remove
basket by
pulling
baskets
out to
their full
extension
and lift
out.
To reinstall upper basket, position basket onto
the retainer clips making sure the front of
the basket rests in the retainer clips on the
stabilizer bar.
Basket
Retainer
Removing Lower Basket
NOTE
If basket is not resting on stabilizer bar retainer
clips, the drawer will not close properly.
Two Freezer Baskets
Stabilizer Bar
Basket
Retainer
Clips
Removing Upper Basket
To Remove Lower Basket
1 Remove all items from basket.
2 Remove the basket by tilting it forward
and lifting it from the retainer clips.
To reinstall lower basket, insert basket into
retainer clips.
22
Middle Basket Divider
Basket Divider
Retainers
Stabilizer
Bar
Lower Basket Divider & Spill Guard Tray
Lower Basket
Divider
Dividers Removal
Lift up on the front of the middle divider and
pull out.
Lift up on the rear of the lower divider and pull
out.
NOTE
Spill Guard Tray should be hand washed in
warm water.
STORAGE FEATURES
23
STORING FOOD AND SAVING ENERGY
Ideas for storing foods
Fresh food storage
• Keep the fresh food compartment
between 34° F and 40° F with an optimum
temperature of 37° F.
• Avoid overcrowding the refrigerator
shelves, which reduces air circulation and
causes uneven cooling.
Fruits and vegetables
• Store fruits and vegetables in crisper
drawers, where trapped moisture helps
preservefoodqualityforlongertime
periods.
• Wash items and remove excess water.
• Wrap any items that have strong odors or
high moisture content.
Meat
• Wrap raw meat and poultry separately
and securely to prevent leaks and
contamination of other foods or surfaces.
• Use the deli drawer to store meat/poultry
for short-term storage. Any meat to be
kept longer than two days should be
frozen.
Frozen food storage
• Keep the freezer compartment at 0° F or
lower.
• Afreezeroperatesmostefcientlywhenit
is at least ⅔ full.
Packaging foods for freezing
• Tominimizefooddehydrationandquality
deterioration, use aluminum foil, freezer
wrap, freezer bags, or airtight containers.
Force as much air out of the packages as
possible and seal them tightly. Trapped air
can cause food to dry out, change color,
anddevelopanoff-avor(freezerburn).
• Wrap fresh meats and poultry with suitable
freezer wrap prior to freezing.
• Do not refreeze meat that has completely
thawed.
Loading the freezer
• Prior to grocery shopping, activate
“quickfreeze”sothatonyourreturnyou
can ensure your newly purchased food
designated for the freezer will be preserved
asquicklyaspossible.
• Activating“quickfreeze”alsowillhelp
yourfreezermoreefcientlymaintainthe
selected temperature after placing new
purchases with pre-existing frozen foods.
• Avoid adding too much warm food to the
freezer at one time. This overloads the
freezer, slows the rate of freezing, and can
raise the temperature of frozen foods.
• Leave a space between packages, so cold
air can circulate freely, allowing food to
freezeasquicklyaspossible.
Ideas for saving energy
Installation
• Locate the refrigerator in the coolest part
of the room, out of direct sunlight, and
away from heating ducts or registers.
• Do not place the refrigerator next to heat-
producing appliances such as a range,
oven, or dishwasher. If this is not possible,
a section of cabinetry or an added layer
of insulation between the two appliances
will help the refrigerator operate more
efciently.
• Level the refrigerator so that the doors
close tightly.
Temperature settings
• Refer to the “Controls” section for
procedures on temperature settings.
Food storage
• Avoid overcrowding the refrigerator or
blocking cold air vents. Doing so causes
the refrigerator to run longer and use more
energy.
• Cover foods and wipe containers dry before
placing them in the refrigerator. This cuts
down on moisture build-up inside the unit.
• Organize the refrigerator to reduce door
openings. Remove as many items as
needed at one time and close the door as
soon as possible.
• Do not place a hot container directly on
a cold shelf. Remember, such an extreme
temperature change may damage the
glass.
24
Understanding the sounds you
may hear
Yournew,high-efciencyrefrigeratormay
introduce unfamiliar sounds. These sounds
normally indicate your refrigerator is operating
correctly.Somesurfacesonoors,walls,and
kitchen cabinets may make these sounds more
noticeable.
The following is a list of major components
in your refrigerator and the sounds they can
cause:
A Evaporator Refrigerant through the
evaporator may create a boiling or
gurgling sound.
B Evaporator fan You may hear air being
forced through the refrigerator by the
evaporator fan.
C Defrost heater During defrost cycles,
water dripping onto the defrost heater
may cause a hissing or sizzling sound.
After defrosting, a popping sound may
occur.
D Automatic ice maker When ice has
been produced, you will hear ice cubes
falling into the ice bin. Ice maker fan,
water valve activation, and refrigerant gas
uidmaycreatesoundsfromitsoperation.
E Electronic control & automatic
defrost control These parts can produce
a snapping or clicking sound when turning
the cooling system on and off.
F Condenser fan You may hear air being
forced through the condenser.
G CompressorModern,high-efciency
compressors run much faster than older
models. The compressor may have a high-
pitched hum or pulsating sound.
H Water valve Makes a buzzing sound each
timeitopenstolltheicemaker.
I Drain pan (not removable) You may hear
water dripping into the drain pan during
the defrost cycle.
J Condenser May create minimal sounds
from forced air.
M Motorized damper May produce a light
humming during operation.
NORMAL OPERATING SOUNDS AND SIGHTS
NOTE
Energyefcientfoaminyourrefrigeratoris
not a sound insulator.
NOTE
During automatic defrost cycle, a red glow
in the back wall vents of your freezer
compartment is normal.
25
CHANGING THE FILTER
Locating the Filters
Yourrefrigeratorisequippedwithwater
lteringsystem.Thewaterltersystemlters
all dispensed drinking water, as well as the
water used to produce ice.
Water Filter
Thewaterlterislocatedatthetoprightside
of the fresh food compartment.
Ordering Replacement Filters
Toorderyourreplacementlters,pleasevisit
our online store at www.frigidaire.com/store,
by calling toll-free at 877-808-4195, or by
visiting the dealer where you purchased your
refrigerator. Frigidaire recommends that you
orderextralterswhenyourstinstallyour
refrigerator,andthatyoureplaceyourltersat
least once every six months.
Hereistheproductnumbertorequestwhen
ordering:
PureSource Ultra
TM
Water Filter
Part #ULTRAWF
Replacing the Water Filter
In general, you should change the water
ltereverysixmonthstoensurethehighest
possiblewaterquality.TheWater Filter
Status light on the user interface prompts you
toreplacethelterafterastandardamountof
water (200 gallons/757 liters for PureSource
Ultra
TM
)
hasowedthroughthesystem.The
waterlterstatuslightonthismodelisnot
performancetestedorcertiedbyNSF.
If your refrigerator has not been used for a
period of time (during moving for example),
changethelterbeforereinstallingthe
refrigerator.
Filter Cartridge
Do not use with water that is microbiologically
unsafeorofunknownqualitywithoutadequate
disinfection before or after the system. Systems
certiedforcystreductionmaybeusedon
disinfectedwatersthatmaycontainlterablecysts.
Test & certication results:
• Rated Capacity - 200 gallons/757 liters for
PureSource Ultra
TM
iceandwaterlter
• Ratedserviceow-.50gallonsperminute
• Operating Temp.: Min. 33° F, Max. 100° F
• Maximum Rated Pressure - 100 pounds per
squareinch
• Recommended Minimum Operating Pressure:
30poundspersquareinch
To replace your PureSource Ultra
TM
water lter:
It is not necessary to turn the water supply off
tochangethelter.Bereadytowipeupany
smallamountsofwaterreleasedduringthelter
replacement.
1 Turn Off the ice maker by raising the wire
signal arm.
2 Removethelterbypushingontheend/
faceofthelter.
3 Slidetheoldwaterltercartridgestraight
out of the housing and discard it.
4 Unpackagethenewltercartridge.Using
the alignment guide, slide it gently into the
lterhousinguntilitstopsagainstthesnap-in
connector at the back of the housing.
5 Pushrmlyuntilthecartridgesnapsinto
place (you should hear a click as the
cartridge engages the snap-in connector).
6 Turn On the ice maker by lowering the wire
signal arm.
7 Press and hold the Water Filter button on the
Ice & Water Dispenser control panel for three
seconds. When the display changes from Red
to Green, the status has been reset.
8 Afterreplacingthewaterlterandinorderfor
the ice maker to work properly, it is necessary
toclearairfromwaterltertubing.Onceice
maker begins making ice, allow the bucket to
llcompletely,thendiscardtherstTWOFULL
buckets of ice. It will take at least two days
tocompletelyllthebucketonregularice
making mode or 1½ days on fast ice mode.
The PureSource Ultra
TM
ice
andwaterltersystemistested
andcertiedtoNSF/ANSI
Standards 42 and 53 for the
reductionofclaimsspeciedon
the performance data sheet.
More about your Advanced
Water Filter
26
CHANGING THE FILTER
Ordering replacement lters
Ordernewltersbycalling877-808-4195,
online at www.frigidaire.com/store, or through
the dealer where you bought your refrigerator.
Youmaywanttoconsiderorderingextralters
whenyourstinstallyourrefrigerator.
Air Filter Replacement cartridge,
part #PAULTRA
Air lter (select models)
Theairlterislocatedundertheutilitybin.
Replacing your PureAdvantage
TM
air lter
Toensureoptimallteringofrefrigeratorodors,
youshouldchangetheairltereverysixmonths
(thelterstatuslightontheTouchPanelprompts
youtoreplacethelteraftersixmonths).
1 Opentheairlterdoor.
2 Removetheoldlteranddiscardit.
3 Unpackthenewlterandslideitintothe
housing.
4 Toclosetheairlterdoor,pushthetop
and bottom to lock the door closed.
5 Press and hold the Air Filter Reset button
on the control panel for three seconds.
When the display changes from “Replace”
to “Good,” the status has been reset.
6 The Air Filter Reset will turn itself off after
a few seconds.
27
IMPORTANT
If you store or move your refrigerator in freezing temperatures, be sure to completely drain
the water supply system. Failure to do so could result in water leaks when the refrigerator is
put back into service. Contact a service representative to perform this operation.
CAUTION
• Pull the refrigerator straight out to move it. Shifting it from side to side may damage
ooring.Becarefulnottomovetherefrigeratorbeyondtheplumbingconnections.
• Damp objects stick to cold metal surfaces. Do not touch refrigerated surfaces with wet or
damp hands.
NOTE
Donotuseabrasivecleanerssuchaswindowsprays,scouringcleansers,ammableuids,
cleaning waxes, concentrated detergents, bleaches, or cleansers containing petroleum
products on plastic parts, interior doors, gaskets, or cabinet liners. Do not use paper towels,
scouring pads, or other abrasive cleaning materials.
NOTE
If you set your temperature controls to turn off cooling, power to lights and other electrical
components will continue until you unplug the power cord from the wall outlet.
CARE & CLEANING
Protecting your investment
Keeping your refrigerator clean maintains its appearance and prevents odor build-up. Wipe up
any spills immediately and clean the freezer and fresh food compartments at least twice a year.
• Remove adhesive labels by hand. Do not use razor blades or other sharp instruments which
can scratch the appliance surface.
• Do not remove the serial plate. Removal of your serial plate voids your warranty.
• Before moving your refrigerator, raise the anti-tip brackets so the rollers will work correctly.
Thiswillpreventtheoorfrombeingdamaged.
Refertotheguideonthenextpagefordetailsoncaringandcleaningspecicareasofyour
refrigerator.
• Never use metallic scouring pads, brushes, abrasive cleaners, or strong alkaline solutions on
any surface.
• Never use CHLORIDE or cleaners with bleach to clean stainless steel.
• Do not wash any removable parts in a dishwasher.
• Always unplug the electrical power cord from the wall outlet before cleaning.
28
CARE & CLEANING
Care and cleaning tips
Vacation and moving tips
Part Cleaning Agents Tips and Precautions
Interior &
Door Liners
• Soap and water
• Baking soda and
water
• Usetwotablespoonsofbakingsodainonequartof
warm water.
• Be sure to wring excess water out of sponge or cloth
before cleaning around controls, light bulb or any
electrical part.
Door
Gaskets
• Soap and water • Wipe gaskets with a clean soft cloth.
Drawers &
Bins
• Soap and water • Use a soft cloth to clean drawer runners and tracks.
• Do not wash any removable items (bins, drawers,
etc.) in dishwasher.
Glass
Shelves
• Soap and water
• Glass cleaner
• Mildliquidsprays
• Allow glass to warm to room temperature before
immersing in warm water.
Toe Grille • Soap and water
• Mildliquidsprays
• Vacuum
• Remove toe grille (see Installation Instructions).
• Vacuum both sides and wipe with sudsy cloth or
sponge. Rinse and dry.
Exterior &
Handles
• Soap and water
• Non abrasive glass
cleaner
• Do not use commercial household cleaners containing
ammonia, bleach or alcohol to clean handles.
• Use a soft cloth to clean smooth handles.
• Do not use a dry cloth to clean smooth doors.
Exterior &
Handles
(Stainless
Steel
Models
Only)
• Soap and water
• Stainless steel
cleaners
• Never use CHLORIDE or cleaners with bleach to clean
stainless steel.
• Clean stainless steel front and handles with non-
abrasive soapy water and a dishcloth. Rinse with
clean water and a soft cloth.
• Use a non-abrasive stainless steel cleaner.
These cleaners can be purchased at most home
improvement or major department stores. Always
follow manufacturer’s instruction. Do not use
household cleaners containing ammonia or bleach.
• NOTE: Always clean, wipe and dry with grain to
prevent scratching.
• Wash the rest of the cabinet with warm water and
mildliquiddetergent.Rinsewellandwipedrywitha
clean soft cloth.
Occasion Tips
Short
Vacations
• Leave refrigerator operating during vacations of three weeks or less.
• Use all perishable items from refrigerator compartment.
• Turn automatic ice maker off and empty ice bucket, even if you will only be
gone a few days.
Long
Vacations
• Remove all food and ice if you will be gone one month or more.
• Turn the cooling system off (see “Controls” section for location of On/Off button)
and disconnect power cord.
• Turn water supply valve to closed position.
• Clean interior thoroughly.
• Leave both doors open to prevent odors and mold build-up. Block doors open if
necessary.
Moving • Remove all food and ice.
• If using a handcart, load from the side.
• Adjust rollers all the way up to protect them during sliding or moving.
• Pad cabinet to avoid scratching surface.
29
NOTE
LED lights are in series so if one is bad or
unplugged, several lights may not light up.
CARE & CLEANING
Replacing LED Lights (select models)
The fresh food compartments of your refrigerator
may have LED lights. Always use Frigidaire parts
for replacement.
To replace LED Lights:
1 Unplug your refrigerator’s power cord.
2 Remove lens cover.
3 Remove LED board.
4 Replace LED board and snap in place
assuring the light is facing in toward the
unit (inside fresh food).
5 Replace lens cover.
LED Light Board Removal
Lens Removal
CAUTION
Wear gloves when replacing incandescent
light bulbs to avoid getting cut.
Ordering Replacement LED Lights
Order new LEDs by calling 877-808-4195, online
at www.frigidaire.com/store, or through the
dealer where you bought the refrigerator. Here is
theproductnumbertorequestwhenordering:
LED Light, Part #242196201
Incandescent Lights (40-watt bulb),
Part #5305514148
Replacing Light Bulbs (select models)
Light
Bulb
Light Sockets
Located Behind
Glass Shelves
Light
Bulb
Refigerator
Light Cover
Refrigerator Light
Light Socket
Located in Upper
Freezer Section
Freezer
Light Cover
Light
Bulb
Light
Bulb
Freezer Light
1 Unplug your refrigerator’s power cord.
2 Wear protective gloves.
3 Remove light cover, if necessary.
4 Unscrew and replace old bulb with an
appliance bulb of the same type and
wattage (normally 40 watts).
5 Replace light cover, if necessary.
6 Plug in the refrigerator’s power cord.
30
BEFORE YOU CALL
Visit our web site at
www.frigidaire.com
1-800-944-9044 (United States)
1-800-265-8352 (Canada)
CONCERN POTENTIAL CAUSE COMMON SOLUTION
AUTOMATIC ICE MAKER
Ice maker is not
making any ice.
• Ice maker power switch
is Off.
• Ice maker has small
cube caught in
mechanism.
• Saddle valve on cold
water pipe is clogged
or restricted by foreign
material.
• Turn power switch to On (“I”) position.
• Remove small cube from ice maker. The ice
andwaterltercartridgemaybeclogged.
Replaceltercartridge.
• Turn off household water line valve. Remove
valve. Ensure that valve is not a self-piercing
saddle valve. Clean valve. Replace valve if
necessary.
Ice maker is not
making enough
ice.
• Ice maker is producing
less ice than you expect.
• Check to see if water
dispenser is dispensing
slower than normal.
• Freezer control is set
too warm (freezer ice
maker).
• The ice maker produces approximately four
pounds of ice every 24 hours depending on
usage conditions.
• Ifitis,replacetheiceandwaterlter
cartridge.
• Set freezer control to colder setting to
improve performance of the ice maker
(freezer ice maker). Allow 24 hours for
temperature to stabilize.
Ice maker will
not stop making
ice.
• Ice maker wire signal arm
is being held down by
some item in the freezer.
• Move item and release wire signal arm.
Remove any ice cubes that are frozen
together over the wire signal arm.
Ice cubes
are freezing
together.
• Ice cubes are not being
usedfrequentlyenough.
• Ice cubes are hollow
(partially frozen cubes
with water inside).
• Freezer control is set too
warm.
• Remove ice container and discard ice from
container. Ice maker will produce fresh supply.
• Theiceandwaterltercartridgemaybe
clogged.Replaceltercartridge.
• Set freezer control to colder setting. Allow
24 hours for temperature to stabilize.
OPENING/CLOSING OF DOORS/DRAWERS
Door(s) will not
close.
• Door was closed too
hard, causing other
door to open slightly.
• Refrigerator is not level.
Itrocksontheoor
when moved slightly.
• Refrigerator is touching
a wall or cabinet.
• Close both doors gently.
• Ensureoorislevelandsolid,andcan
adequatelysupporttherefrigerator.Contacta
carpentertocorrectasaggingorslopingoor.
• Ensureoorislevelandsolid,andcan
adequatelysupporttherefrigerator.
Contact a carpenter to correct a sagging or
slopingoor.
Drawers are
difcult to
move.
• Food is touching shelf
on top of drawer.
• Track that drawers slide
on is dirty.
• Remove top layer of items in drawer.
• Ensure drawer is properly installed on track.
• Clean drawer, rollers, and track. See Care
& Cleaning.
31
BEFORE YOU CALL
CONCERN POTENTIAL CAUSE COMMON SOLUTION
RUNNING OF REFRIGERATOR
Compressor
does not run.
• Freezer control is set to
“OF” or “0”.
• Refrigerator is in defrost
cycle.
• Plug at electrical outlet is
disconnected.
• House fuse blown or
tripped circuit breaker.
• Power outage.
• Set freezer control.
• This is normal for a fully automatic defrost
refrigerator. The defrost cycle occurs
periodically, lasting about 30 minutes.
• Ensure plug is tightly pushed into outlet.
• Check/replace fuse with a 15 amp time-delay
fuse. Reset circuit breaker.
• Check house lights. Call local electric company.
Refrigerator
runs too much
or too long.
• Room or outside weather
is hot.
• Doors are opened too
frequentlyortoolong.
• Fresh Food/freezer door
may be slightly open.
• Freezer control is set too
cold.
• Fresh Food/freezer gasket
is dirty, worn, cracked, or
poorlytted.
• Condenser is dirty.
• It’s normal for the refrigerator to work longer
under these conditions.
• Warm air entering the refrigerator causes it
to run more. Open doors less often.
• Ensure refrigerator is level. Keep food and
contains from blocking door. See CONCERN
column OPENING/CLOSING OF DOORS/
DRAWERS.
• Set Fresh Food control to warmer setting
until refrigerator temperature is satisfactory.
Allow 24 hours for temperature to stabilize.
• Clean or change gasket. Leaks in door seal
will cause refrigerator to run longer in order
to maintain desired temperatures.
• Clean condenser. See Care & Cleaning.
Compressor
goes off and on
frequently.
• Thermostat keeps the
refrigerator at a constant
temperature.
• This is normal. Refrigerator goes on and off
to keep temperature constant.
DIGITAL TEMPERATURE DISPLAY
Digital
temperature
displays are
ashing.
• Electronic control
system has detected a
performance problem.
• Call your Frigidaire service representative,
who can interpret any messages or number
codesashingonthedigitaldisplays.
WATER/MOISTURE/FROST INSIDE REFRIGERATOR
Moisture collects
on inside of
refrigerator
walls.
• Weather is hot and
humid.
• Door is slightly open.
• The rate of frost buildup and internal
sweating increases.
• See CONCERN column OPENING/CLOSING
OF DOORS/DRAWERS.
Water collects
on bottom side
of drawer cover.
• Vegetables contain and
give off moisture.
• It is not unusual to have moisture on the
bottom side of the cover.
• Move humidity control (some models) to
lower setting.
Water collects in
bottom of drawer.
• Washed vegetables and fruit
drain while in the drawer.
• Dry items before putting them in the drawer.
Water collecting in bottom of drawer is normal.
WATER/MOISTURE/FROST OUTSIDE REFRIGERATOR
Moisture collects
on outside of
refrigerator or
between doors.
• Weather is humid.
• Door is slightly open,
causing cold air from
inside refrigerator to meet
warm air from outside.
• This is normal in humid weather. Press
Energy Saver icon to reduce exterior
moisture on the cabinet between the doors.
When humidity is lower, the moisture should
disappear and the Energy Saver icon can be
pressed again to turn it off.
• See CONCERN column OPENING/CLOSING
OF DOORS/DRAWERS.
32
MAJOR APPLIANCE WARRANTY
Your appliance is covered by a one year limited warranty. For one year from your original date of
purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove
to be defective in materials or workmanship when such appliance is installed, used and maintained
in accordance with the provided instructions.
Exclusions
If You Need Service
This warranty does not cover the following:
1. Products with original serial numbers that have been removed, altered or cannot be readily determined.
2. Product that has been transferred from its original owner to another party or removed outside
the USA or Canada.
3. Rust on the interior or exterior of the unit.
4. Products purchased “as-is” are not covered by this warranty.
5. Food loss due to any refrigerator or freezer failures.
6. Products used in a commercial setting.
7. Service calls which do not involve malfunction or defects in materials or workmanship, or for appliances
not in ordinary household use or used other than in accordance with the provided instructions.
8. Service calls to correct the installation of your appliance or to instruct you how to use your appliance.
9. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards,
shelves, etc., which are not a part of the appliance when it is shipped from the factory.
10. Servicecallstorepairorreplaceappliancelightbulbs,airlters,waterlters,other
consumables, or knobs, handles, or other cosmetic parts.
11. Surcharges including, but not limited to, any after hour, weekend, or holiday service calls, tolls, ferry
trip charges, or mileage expense for service calls to remote areas, including the state of Alaska.
12. Damagestothenishofapplianceorhomeincurredduringinstallation,includingbutnot
limitedtooors,cabinets,walls,etc.
13. Damages caused by: services performed by unauthorized service companies; use of parts other than
genuine Electrolux parts or parts obtained from persons other than authorized service companies; or
externalcausessuchasabuse,misuse,inadequatepowersupply,accidents,res,oractsofGod.
DISCLAIMER OF IMPLIED WARRANTIES; LIMITATION OF REMEDIES
CUSTOMER’S SOLE AND EXCLUSIVE REMEDY UNDER THIS LIMITED WARRANTY SHALL BE PRODUCT
REPAIR OR REPLACEMENT AS PROVIDED HEREIN. CLAIMS BASED ON IMPLIED WARRANTIES,
INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, ARE
LIMITED TO ONE YEAR OR THE SHORTEST PERIOD ALLOWED BY LAW, BUT NOT LESS THAN ONE
YEAR.ELECTROLUXSHALLNOTBELIABLEFORCONSEQUENTIALORINCIDENTALDAMAGESSUCH
AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING FROM ANY BREACH OF THIS
WRITTEN LIMITED WARRANTY OR ANY IMPLIED WARRANTY. SOME STATES AND PROVINCES DO
NOTALLOWTHEEXCLUSIONORLIMITATIONOFINCIDENTALORCONSEQUENTIALDAMAGES,
OR LIMITATIONS ON THE DURATION OF IMPLIED WARRANTIES, SO THESE LIMITATIONS OR
EXCLUSIONS MAY NOT APPLY TO YOU. THIS WRITTEN WARRANTY GIVES YOU SPECIFIC LEGAL
RIGHTS. YOU MAY ALSO HAVE OTHER RIGHTS THAT VARY FROM STATE TO STATE.
This warranty only applies in the USA and Canada. In the USA, your appliance is warranted
by Electrolux Major Appliances North America, a division of Electrolux Home Products, Inc. In
Canada, your appliance is warranted by Electrolux Canada Corp. Electrolux authorizes no person to
change or add to any obligations under this warranty. Obligations for service and parts under this
warranty must be performed by Electrolux or an authorized service company. Product features or
specicationsasdescribedorillustratedaresubjecttochangewithoutnotice.
Keep your receipt, delivery slip, or some other appropriate payment record to establish the warranty
periodshouldserviceberequired.Ifserviceisperformed,itisinyourbestinteresttoobtainand
keep all receipts. Service under this warranty must be obtained by contacting Electrolux at the
addresses or phone numbers below.
USA
1.800.944.9044
Frigidaire
10200 David Taylor Drive
Charlotte, NC 28262
Canada
1.800.265.8352
Electrolux Canada Corp.
5855 Terry Fox Way
Mississauga, Ontario, Canada
L5V 3E4
