OWNER’S MANUAL
CINEMA 3D TV
DM2780D
DM2780A
Please read this manual carefully before operating the
your TV and retain it for future reference.
CINEMA 3D TV MODELS
ENGLISH
background
2
ENGLISH
TABLE OF CONTENTS
CONTENTS
5 LICENSES
6 ASSEMBLING AND
PREPARING
6 Unpacking
8 Partsandbuttons
9 LiftingandmovingtheTV
9 SettinguptheTV
9 - AttachingtheStandBase
10 - DetachingtheStandBaseandBody
10 - Mountingonatable
12 - Tidyingcables
12 - Swivelstand
12 - Mountingonawall
14 REMOTE CONTROL
16 WATCHING TV
16 Connectinganantennaorcable
16 - Connectinganantennaorbasiccable
16 - Connectingwithacablebox
17 AccessingtheTVforthefirsttime
18 WatchingTV
18 Managingprogrammes
18 - Automaticallysettingupprogrammes
21 - Manuallysettingupprogrammes(In
digitalmode)(OnlyDTV)
22 - Manuallysettingupprogrammes(In
analoguemode)
23 - CableDTVSetting(InCablemode
only)(OnlyDTV)
23 - Editingyourprogrammelist
24 - InDTV/RADIOmode(OnlyDTV)
24 - InTVmode(OnlyDTV)
25 - SoftwareUpdate(OnlyDTV)
26 - Diagnostics(OnlyDTV)
26 - CI[Commoninterface]Information
(OnlyDTV)
27 - Selectingtheprogrammelist
27 - Favouriteprogrammesetup
28 Usingadditionaloptions
28 - Adjustingaspectratio
30 - Usingtheinputlist
31 - On-screenmenulanguage/Country
selection(OnlyDTV)
32 - Languageselection(Indigitalmode
only)(OnlyDTV)
33 UsingtheLockoptions
33 - LockingthebuttonsontheTV.
34 - Parentalcontrol(Indigitalmodeonly)
(OnlyDTV)
34 UsingtheQuickmenu
35 EPG (ELECTRONIC
PROGRAMME GUIDE) (IN
DIGITAL MODE) (ONLY DTV)
35 UsingElectronicProgrammeGuide
35 - Switchon/offEPG
35 - Selectaprogramme
36 - ButtonFunctioninNOW/NEXTGuide
Mode
36 - ButtonFunctionin8DayGuideMode
36 - ButtonFunctioninDateChangeMode
37 - ButtonFunctioninExtended
DescriptionBox
37 - ButtonFunctioninRecord/Remind
SettingMode
37 - ButtonFunctioninScheduleListMode
38 CONNECTING TO A PC
38 HDMIconnection
39 DVItoHDMIconnection
39 RGBconnection
40 Adjustingthescreen
40 - Selectinganimagemode
40 - Customizingimageoptions
41 - CustomizingPCdisplayoptions
background
3
ENGLISH
TABLE OF CONTENTS
41 Adjustingthesound
41 - Selectingansoundmode
42 - Customizingsoundoptions
43 ENTERTAINMENT
43 Usingintegratedmediafeatures
43 - ConnectingUSBstoragedevices
45 - Browsingfiles
46 - ViewingPhotos
47 - ListeningtoMusic
49 - ViewingMovies
52 - DivX®VODGuide
53 3D IMAGING
53 3DTechnology
53 Precautionstotakewhenviewing3D
images
54 Whenusing3DGlasses
55 3DImagingViewingRange
56 Viewing3DImaging
57 3DModeSettingOption
58 CUSTOMIZING SETTINGS
58 Accessingmainmenus
59 Customizingsettings
59 - SETUPsettings
60 - PICTUREsettings
63 - AUDIOsettings
66 - TIMEsettings
67 - OPTIONsettings
68 - LOCKsettings
69 - INPUTsettings
69 - USBsettings
70 MAKING CONNECTIONS
70 Connectionoverview
72 ConnectingtoaCamcorder,Camera,HD
receiver,DVD,VCRplayerorGaming
device
72 - HDMIconnection
72 - DVItoHDMIconnection
72 - Componentconnection
73 - Compositeconnection
73 - EuroScartconnection
73 Connectingtoanaudiosystem
73 - Digitalopticalaudioconnection
74 - Headphoneconnection
74 ConnectingtoaUSB
75 TELETEXT
75 SwitchOn/Off
75 SimpleText
75 - Pageselection
75 TopText
75 - Block/Group/PageSelection
75 - DirectPageSelection
76 Fastext
76 - Pageselection
76 SpecialTeletextFunction
76 - TextOption
77 DIGITAL TELETEXT (ONLY
DTV)
77 Teletextwithindigitalservice
77 Teletextindigitalservice
78 MAINTENANCE
78 Screenandframe
78 Cabinetandstand
78 Powercord
background
4
ENGLISH
TABLE OF CONTENTS
79 TROUBLESHOOTING
79 General
80 PCmode
82 TROUBLESHOOTING WHEN
USING 3D MODE
83 SPECIFICATIONS
87 IR CODES
88 EXTERNAL CONTROL DEVICE
SETUP
88 RS-232CSetup
88 Typeofconnector;D-Sub9-PinMale
89 RS-232Cconfigurations
90 CommunicationParameters
90 Commandreferencelist
91 Transmission/Receivingprotocol
background
ENGLISH
5
LICENSES
LICENSES
Supportedlicensesmaydifferbymodel.Formoreinformationofthelicenses,visitwww.lg.com.
ManufacturedunderlicensefromDolbyLaboratories.“Dolby“andthe
double-DsymbolaretrademarksofDolbyLaboratories.
HDMI,theHDMIlogoandHigh-DefinitionMultimediaInterfacearetrademarks
orregisteredtrademarksofHDMILicensingLLC.
ABOUTDIVXVIDEO:DivX®isadigitalvideoformatcreatedbyDivX,LLC,a
subsidiaryofRoviCorporation.ThisisanofficialDivXCertified®devicethat
playsDivXvideo.Visitdivx.comformoreinformationandsoftwaretoolsto
convertyourfilesintoDivXvideos.
ABOUTDIVXVIDEO-ON-DEMAND:ThisDivXCertified®devicemustbe
registeredinordertoplaypurchasedDivXVideo-on-Demand(VOD)movies.
Toobtainyourregistrationcode,locatetheDivXVODsectioninyourdevice
setupmenu.Gotovod.divx.comformoreinformationonhowtocomplete
yourregistration.
DivXCertified®toplayDivX®videouptoHD1080p,includingpremium
content.
DivX®,DivXCertified®andassociatedlogosaretrademarksofRovi
Corporationoritssubsidiariesandareusedunderlicense.
CoveredbyoneormoreofthefollowingU.S.patents:7,295,673;7,460,668;
7,515,710;7,519,274
ImageshownmaydifferfromyouTV.
YourTV'sOSD(OnScreenDisplay)maydifferslightlyfromthatshowninthismanual.
Theavailablemenusandoptionsmaydifferfromtheinputsourceorproductmodelthatyouare
using.
NOTE
background
ENGLISH
6
ASSEMBLING AND PREPARING
ASSEMBLING AND PREPARING
Unpacking
Checkyourproductboxforthefollowingitems.Ifthereareanymissingaccessories,contactthelocal
dealerwhereyoupurchasedyourproduct.Theillustrationsinthismanualmaydifferfromtheactualproduct
andaccessories.
Remote control and Batteries
Stand Base
Power Cord
Cable Tie
CD (Owner's Manual) /
Card
TriDef 3D Game Software CD /
Quick Installation Guide
3D Glasses
(Normaltype)
3D Glasses
(Cliptype)
AC-DC Adapter
RGB Cable
background
ENGLISH
7
ASSEMBLING AND PREPARING
Donotuseanypirateditemstoensurethesafetyandproductlifespan.
Anydamagesorinjuriesbyusingpirateditemsarenotcoveredbythewarranty.
Theaccessoriessuppliedwithyourproductmayvarydependingonthemodel.
Productspecificationsorcontentsinthismanualmaybechangedwithoutpriornoticeduetoupgrade
ofproductfunctions.
CAUTION
NOTE
background
ENGLISH
8
ASSEMBLING AND PREPARING
YoucansetthePowerindicatortoonoroffbyselectingOPTIONinthemainmenus.
NOTE
Parts and buttons
Touch button Description
INPUT Changestheinputsource.
MENU Accessesthemainmenus,orsavesyourinputandexitsthemenus.
OK Selectsthehighlightedmenuoptionorconfirmsaninput.
◄VOL► Adjuststhevolumelevel.
▼PR▲ Scrollsthroughthesavedprogrammes.
/I
Turnsthepoweronoroff.
Allofthebuttonsaretouchsensitiveandcanbeoperatedthroughsimpletouchwithyourfinger.
(MONO)
12
AUDI0
AV IN2
Remote
Control
Sensor
PCMCIA
Card Slot
(ONLY DTV)
Power Indicator
Lighting On: Turned on
Lighting Off: Turned off
Connection panel (Seep.70)
Touch Buttons
background
ENGLISH
9
ASSEMBLING AND PREPARING
Lifting and moving the TV
WhenmovingorliftingtheTV,readthefollowingto
preventtheTVfrombeingscratchedordamaged
andforsavetransportationregardlessofitstype
andsize.
Setting up the TV
Attaching the Stand Base
1
PlacetheTVwiththescreensidedownona
flatandcushionedsurface.
Avoidtouchingthescreenatalltimes,asthis
mayresultindamagetothescreenorsome
ofthepixelsusedtocreateimages.
Layafoammatorsoftprotectivecloth
onthesurfacetoprotectthescreenfrom
damage.
CAUTION
CAUTION
ItisrecommendedtomovetheTVinthe
boxorpackingmaterialthattheTVoriginally
camein.
BeforemovingorliftingtheTV,disconnect
thepowercordandallcables.
HoldthetopandbottomoftheTVframe
firmly.Makesurenottoholdthetransparent
part,speaker,orspeakergrillarea.
WhenholdingtheTV,thescreenshouldface
awayfromyoutopreventthescreenfrom
scratches.
WhentransportingtheTV,donotexposethe
TVtojoltsorexcessivevibration.
WhentransportingtheTV,keeptheTV
upright,neverturntheTVonitsside,ortilt
towardstheleftorright.
2
AttachtheStand Basefromthesetbyturning
thescrewtotherightwithaCoin.
background
ENGLISH
10
ASSEMBLING AND PREPARING
Detaching the Stand Base and Body
1
PlacetheTVwiththescreensidedownona
flatandcushionedsurface.
2
Turnthescrewtotheleft,andthenpulloutthe
Stand BasefromtheStand Body.
Mounting on a table
1
LiftandtilttheTVintoitsuprightpositionona
table.
Leavea10cm(minimum)spacefromthewall
forproperventilation.
2
ConnecttheAC-DC AdapterandPower Cord
toawalloutlet.
10 cm
10 cm
10 cm
10 cm
3
Remove2screwsandpullouttheStand Body
fromtheTV.
background
ENGLISH
11
ASSEMBLING AND PREPARING
Whenyouadjusttheangle,donotholdthe
buttomoftheTVframeasshownonthe
followingillustration,asmayinjureyourfingers.
WARNING
Disconnectthepowercordfirst,andthenmove
orinstalltheTV.Otherwiseelectricshockmay
occur.
CAUTION
Tiltfrom+18to-5degreesupordowntoadjust
theangleoftheTVtosuityourview.
NOTE
Front Rear
18°-5°
Using the Kensington security system
TheKensingtonsecuritysystemconnectoris
locatedatthebackoftheTV.Formoreinformation
ofinstallationandusing,refertothemanual
suppliedwiththeKensingtonsecuritysystemor
visit
http://www.kensington.com
.
ConnecttheKensingtonsecuritysystemcable
betweentheTVandatable.
TheKensingtonsecuritysystemisoptional.
Youcanobtainadditionalaccessoriesfrom
mostelectronicsstores.
NOTE
background
ENGLISH
12
ASSEMBLING AND PREPARING
Swivel stand
Swivel179degreesandadjusttheangleoftheTV
tosuityourview.
Tidying cables
Gatherandbindthecableswiththesupplied
cabletie.
Mounting on a wall
Forproperventilation,allowaclearanceof10
cmoneachsideandfromthewall.Detailed
installationinstructionsareavailablefromyour
dealer,seetheoptionalTiltWallMountingBracket
InstallationandSetupGuide.
IfyouintendtomounttheTVtoawall,attachWall
mountinginterface(optionalparts)tothebackof
theset.
WhenyouinstalltheTVusingthewallmounting
interface(optionalparts),attachitcarefullysoit
willnotdrop.
1
Please,Usethescrewandwallmountinterface
inaccordancewithVESAStandards.
2
Ifyouusescrewlongerthanstandard,theTV
mightbedamagedinternally.
3
Ifyouuseimproperscrew,theproductmightbe
damagedanddropfrommountedposition.In
thiscase,LGElectronicsisnotresponsibleforit.
4
VESAcompatibleonlywithrespecttoscrew
mountinginterfacedimensionsandmounting
screwspecifications.
10 cm
10 cm
10 cm
10 cm
background
ENGLISH
13
ASSEMBLING AND PREPARING
Model
DM2780D
DM2780A
VESA (A x B) 200x100
Standard screw M4
Number of screws 4
Wall mount bracket
(optional)
RW240
5
PleaseuseVESAstandardasbelow.
784.8mm(30.9inch)andunder
*WallMountPadThickness:2.6mm
*Screw:
Φ
4.0mmxPitch0.7mmx
Length10mm
787.4mm(31.0inch)andabove
*PleaseuseVESAstandardwallmountpad
andscrews.
A
B
VESA(AxB)
Disconnectthepowercordfirst,andthen
moveorinstalltheTV.Otherwiseelectric
shockmayoccur.
IfyouinstalltheTVonaceilingorslanted
wall,itmayfallandresultinsevereinjury.
UseanauthorizedLGwallmountand
contactthelocaldealerorqualified
personnel.
Donotovertightenthescrewsasthismay
causedamagetotheTVandvoidyour
warranty.
Usethescrewsandwallmountsthatmeet
theVESAstandard.Anydamagesorinjuries
bymisuseorusinganimproperaccessory
arenotcoveredbythewarranty.
CAUTION
UsethescrewsthatarelistedontheVESA
standardscrewspecifications.
Thewallmountkitincludesaninstallation
manualandnecessaryparts.
Thewallmountbracketisoptional.Youcan
obtainadditionalaccessoriesfromyourlocal
dealer.
Thelengthofscrewsmaydifferdepending
onthewallmount.Besuretousetheproper
length.
Formoreinformation,refertotheinstructions
suppliedwiththewallmount.
NOTE
background
ENGLISH
14
REMOTE CONTROL
REMOTE CONTROL
Thedescriptionsinthismanualarebasedonthebuttonsoftheremotecontrol.
PleasereadthismanualcarefullyandusetheTVcorrectly.
Toreplacebatteries,openthebatterycover,replacebatteries(1.5VAAA)matching
and endstothelabelinsidethecompartment,andclosethebatterycover.
Toremovethebatteries,performtheinstallationactionsinreverse.
MakesuretopointtheremotecontroltotheremotecontrolsensorontheTV.
CAUTION
Donotmixoldandnewbatteries,asthis
maydamagetheremotecontrol.
InAnalogueTVandsomecountries,some
remotecontrolkeysmaynotwork.
P
A
G
E
P
1 2 3
4 5
0
6
7 8 9
LIST
Q.VIEW
TV / PC INPUT
TV/
RAD
ENERGY
SAVING
MARK
3D SETTING
FAV
3D
MUTE
OK
MENU
GUIDE
Q.MENU
BACK
INFO
Auto Config.
EXIT
(POWER)
TurnstheTVonoroff.
ENERGY SAVING(Seep.60)
Adjuststhebrightnessof
thescreentoreduceenergy
consumption.
TV/PC
SelectsTVorPCmode.
LIST(Seep.27)
Displaystheprogramme
table.
INPUT(Seep.30)
Selectstheinputmode.
TV/RAD(Seep.24)
SelectsRadio,TVandDTV
programme.
Number buttons
Entersnumbers.
Q.VIEW
Returnstothepreviously
viewedprogramme.
MARK
Selecttheinputtoapplythe
PictureWizardsettings.
Checkandun-check
programmesintheUSB
menu.
FAV
Displaystheselected
favouriteprogramme.
(
VOLUME)
Adjuststhevolumelevel.
3D (Seep.53)
Usesforviewing3Dvideo.
Programme
Selectsaprogramme.
PAGE
Movestothepreviousornext
screen.
MUTE
Mutesallsounds.
P
A
G
E
P
1 2 3
4 5
0
6
7 8 9
LIST
Q.VIEW
TV / PC INPUTENERGY
SAVING
MARK
FAV
3D
MUTE
OK
MENU
GUIDE
Q.MENU
BACK
INFO
Auto Config.
EXIT
P
A
G
E
P
1
2
3
4
5
0
7
8
9
L
I
S
T
Q
.VIEW
TV / PC INPUTENERGY
SAVING
MARK
FAV
3D
MUT
E
background
ENGLISH
15
REMOTE CONTROL
P
A
G
E
P
1 2 3
4 5
0
6
7 8 9
LIST
Q.VIEW
TV / PC INPUT
TV/
RAD
ENERGY
SAVING
MARK
3D SETTING
FAV
3D
MUTE
OK
MENU
GUIDE
Q.MENU
BACK
INFO
Auto Config.
EXIT
Q.MENU (Seep.34)
Accessesthequickmenus.
3D SETTING(Only 3D Mode)
(Seep.57)
Viewfor3DModesetting.
INFO
ⓘ
Viewstheinformationofthe
currentlyprogramandthe
screen.
EXIT
Clearsallon-screendisplays
andreturnstoTVviewing
fromanymenu.
Coloured buttons
Thesebuttonsareusedfor
teletext(onTELETEXT
modelsonly),Programme
edit.
SUBTITLE
Recallsyourpreferredsubtitle
indigitalmode.
Auto Config.
Automaticallyadjustspicture
positionandminimizes
imageinstability.
MENU (Seep.58)
Accessesthemainmenus
orsavesyourinputandexit
menus.
Navigation buttons
Scrollsthroughmenusor
options.
OK
Selectsmenusoroptionsand
confirmsyourinput.
BACK
Allowstheusertomovereturn
onestepinaninteractive
application,EPGorotheruser
interactionfunction.
Teletext buttons (Seep.75)
Thesebuttonsareusedfor
teletext.Forfurtherdetails,
seethe‘Teletext’section.
USB Menu control
buttons (Seep.43)
USBmenu(PhotoListand
MusicListorMovieList).
P
A
G
E
P
1 2 3
4 5
0
6
7 8 9
LIST
Q.VIEW
TV / PC INPUT
TV/
RAD
ENERGY
SAVING
MARK
FAV
RATIO
MUTE
OK
MENU
GUIDE
Q.MENU
BACK
INFO
Auto Config.
EXIT
OK
M
ENU
GUIDE
Q.MENU
BAC
K
INF
O
E
XIT
Auto Config.
GUIDE (Seep.35)
Showsprogrammeguide.
CAUTION
InAnalogueTVandsomecountries,some
remotecontrolkeysmaynotwork.
background
ENGLISH
16
WATCHING TV
WATCHING TV
Connecting an antenna or
cable
Connectanantenna,cable,orcableboxtowatch
TVreferringtothefollowing.Theillustrationsmay
differfromtheactualaccessoriesandanRFcable
isoptional.
Connecting an antenna or basic
cable
ConnecttheTVtoawallantennasocketwithan
RFcable(75ohm).
Connecting with a cable box
ConnecttheTVtoacableboxandthecablebox
toawallantennasocketwith2RFcables(75
ohm).
Useasignalsplittertousemorethan2TVs.
Iftheimagequalityispoor,installasignal
amplifierproperlytoimprovetheimage
quality.
Iftheimagequalityispoorwithanantenna
connected,aimtheantennatotheproper
direction.
Visit
http://AntennaWeb.org
formore
informationabouttheantennaandcable
connection.
NOTE
Makesurenottobendthecopperwireofthe
RFcable.
Completeallconnectionsinstructions
betweendevices,andthenconnectthe
powercordtothepoweroutlettoprevent
damagestoyourTV.
CAUTION
Copper wire
Wall Antenna
Socket
Outdoor
Antenna
background
ENGLISH
17
WATCHING TV
Accessing the TV for the
first time
WhenyouaccesstheTVforthefirsttime,the
initialsettingscreenappears.Selectalanguage
andcustomizethebasicsettings.
1
Connectthepowercordtoapoweroutlet.
2
Press ontheTVtoturntheTVon.
ThePowerindicatorlightingisturnedon.
YoucanalsoswitchtheTVfromPC
modetoTVmode,pressTV/PC.
YoucanalsoaccessInitial Settingby
accessingOPTION inthemainmenus.
IfyoudonotoperatetheTVwithin
40secondswhenthesettingmenu
screenappears,thesettingmenuswill
disappear.
NOTE
NOTE
NOTE
NOTE
WhentheTVisinPowersavingmode,the
Powerindicatorlightingblinks.
Todisplayimagesinthebestqualityfor
yourhomeenvironment,selectHome
Use mode.
StoreDemomodeissuitablefortheretail
environment.
IfyouselectStore Demo mode,the
previouslycustomizedsettingswillswitch
tothedefaultsettingsofStore Demo
modein2minutes.
Ifyoudonotcompletetheinitialsetting,it
willappearwheneveryouaccesstheTV.
3
Theinitialsettingscreenappearsifyouaccess
theTVforthefirsttime.
4
Followtheon-screeninstructionstocustomize
yourTVaccordingtoyourpreferences.
Language
Mode Setting
Country
Auto Tuning
SelectsHome Usefor
thehomeenvironment.
Selectsacountryto
display.(OnlyDTV)
Selectsalanguagefor
thedisplay.
Scansandsaves
availableprogrammes
automatically.
5
Whenthebasicsettingsarecomplete,press
OK.
6
ToturntheTVoff,press ontheTV.
ThePowerIndicatorturnsoff.
Disconnectthepowercordfromthepower
outletwhenyoudonotusetheTVforalong
periodoftime.
CAUTION
background
ENGLISH
18
WATCHING TV
Watching TV
1
Press ontheRemotecontrolor onthe
TVtoturntheTVon.
2
PressINPUTandselectAntenna.
3
ControltheTVusingthefollowingbuttonsand
menuswhileyouarewatchingTV.
Button / Menu Description
P( ) or
PR (
)
Scrollsthroughthesaved
programmes
Numbers Selectsaprogrammeby
enteringnumbers
(+ , -)or
VOL (
)
Adjuststhevolumelevel
MUTE Mutesallsounds
PICTURE Selectsoneofthepresetimage
modes(Seep.60)
AUDIO Selectsoneofthepresetaudio
modes.(Seep.63)
4
ToturntheTVoff,Press ontheRemote
controlor ontheTV.
Managing programmes
Automatically setting up
programmes
For countries other than Finland, Sweden,
Denmark and Norway)
Usethistoautomaticallyfindandstoreallavailable
programmes.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Auto TuningandpressOK.
4
SelectStarttostartautomatictuning.
TheTVscansandsavesavailableprogrammes
automatically.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
NOTE
UseNumberbuttonstoinputa4-digit
passwordinLock System ‘On’.
AutomaticNumbering:Decidewhetherto
usetheprogrammenumbersassentby
broadcastingstationsfortuning.
WhenselectItalyintheCountrymenu,if
thepopupisdisplayedwhentheconflicted
ProgrammeafterAutoTuning,selecta
broadcasterforconflictingprogramme
numbertosolve.
WhenselectUKintheCountrymenu,if
thepopupisdisplayedwhentheconflicted
programmeafterAutoTuning,selecta
regions,countryforconflictingprogramme
numbertosolve.
background
ENGLISH
19
WATCHING TV
Only for Finland, Sweden, Denmark and Norway
DVB-CAutoTuningisamenuforusersin
countriesthatsupportDVBcable.
IfyouwanttoselecttheAntenna
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Auto TuningandpressOK.
4
PresstheNavigationbuttonstoscrollto
AntennaandpressOK.
5
SelectStarttostartautomatictuning.
TheTVscansandsavesavailableprogrammes
automatically.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
NOTE
UseNumberbuttonstoinputa4-digit
passwordinLock System ‘On’.
AutomaticNumbering:Decidewhetherto
usetheprogrammenumbersassentby
broadcastingstationsfortuning.
NOTE
UseNumberbuttonstoinputa4-digit
passwordinLock System ‘On’.
AutomaticNumbering:Decidewhetherto
usetheprogrammenumbersassentby
broadcastingstationsfortuning.
IfyouwanttoselecttheCable
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Auto TuningandpressOK.
4
PresstheNavigationbuttonstoscrollto
CableandpressOK.
5
PresstheNavigationbuttonstoscrollto
Comhem or Other OperatorsandpressOK.
6
PresstheNavigationbuttonstoscrollto
Default, Full or UserandpressOK.
7
PresstheNavigationbuttonsorNumber
buttonstoscrollmakeappropriateadjustments
(ExceptforFullmode)andpressOK.
8
PresstheNavigationbuttonstoscrollto
Close andpressOK.
9
SelectStarttostartautomatictuning.
TheTVscansandsavesavailableprogrammes
automatically.
10
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
ENGLISH
20
WATCHING TV
TowatchDVB-Cinthecountriesexcluding
Finland,Sweden,DenmarkandNorwayselect'--'
astheCountryinOPTION.
YoucanselectUsermodeorFullmodeinAuto
Tuning.
Thecorrespondinghomefrequencyinformation
mayneedtobechangedwhentuningtheUser
mode,andthecorrespondinginformationdepends
ontheCableServiceOperator(SO)inservice.
DuringFullmodetuning,somechannelmaybe
restrictedforsomeCableServiceOperator(SO),
anditmaytakealongtimefortuning.
If you select the “- -” of Country Setting,
(Except for Finland, Sweden, Denmark and
Norway)
NOTE
Yourcableprovidermaychargefortheir
services,orrequireyoutoagreetoitsitems
andconditionsofbusiness.
DVB-CCablemaynotoperatecorrectlywith
somecableproviders.
CompatibilitywithDVB-Cdigitalcable
broadcastsisnotguaranteed.
WhenyouselecttheCable,theCable
Service Operatorselectionscreencandiffer
ornotexistbytheCablesituationofthe
applicablecountry.
ThepopupwindowtoselectbetweenService
Operatorisonlyshowninitiallyforthe3cases
whenyouaccessingtheInitial Settingmenu,
whenyouchangefromAntennatoCableor
whenyouaccessthemenuafterchangingthe
Country.
WhenyouwanttoselectbetweenService
Operatorasidefromtheabove3cases,you
candosobyselectingSETUP→Cable DTV
Setting→Service Operator.
AcquiredcertificationSO:Sweden(Comhem,
CanalDigital),Denmark(YouSee,Canal
Digital,Stofa),Norway(CanalDigital).
IftherearenotanyServiceOperatorthatyou
want,selectOther Operators.
Ifyouselect"OtherOperators",ortheselected
countrysupports"OtherOperators"only,itmay
takesometimetosearchallthechannels,orit
maynotsearchsomeofthechannels.
Ifsomeofthechannelsdonotappear,follow
thestepsbelow.
1.SETUP → Auto Tuning → Cable
2.Inputadditionalvaluessuchasthe
frequency,symbolrate,modulation,and
networkID(Youcanaskyourcableservice
providerfortheaboveinformation).
Thefollowingvaluesareneededinorderto
searchallavailableprogrammesquicklyand
correctly.Thecommonlyusedvaluesare
providedas"default".However,forcorrect
settings,pleaseinquireofthecableservice
provider.WhenrunningAutoTuningin
DVBcablemode,selectingFullwillsearch
throughallfrequenciestofindavailable
channels.Inthecasewhentheprogramme
isnotsearchedbyselectingtheDefault,
performthesearchingbyselectingtheFull.
However,inthecasewhentheprogramme
issearchedbyselectingtheFull,theAuto
Tuningtimecanbetakentoomuch.
»
Frequency:Enterauser-definedfrequency
range.
»
Symbol rate:Enterauser-definedsymbol
rate(Symbolrate:Speedatwhichadevice
suchasmodemsendssymbolstoa
channel).
»
Modulation:Enterauser-defined
modulation.(Modulation:Loadingofaudioor
videosignalsontocarrier).
»
Network ID:Uniqueidentifierallocatedfor
eachuser.
background
ENGLISH
21
WATCHING TV
(When selecting Cable (DVB cable mode) if
Finland, Sweden, Denmark, Norway or “--”
country is chosen)
NOTE
NOTE
UseNumberbuttonstoinputa4-digit
passwordinLockSystem‘On’.
Symbol rate:Enterauser-definedsymbol
rate.(symbolrate:Speedatwhicha
devicesuchasmodemsendssymbolstoa
channel.)
Modulation:Enterauser-defiend
modulation.(Modulation:Loadingofaudioor
videosignalsontocarrier)
Frequency,Symbolrate,andModulation
modeareneededinordertoadda
programmecorrectlyinDVBcablemode.
Pleaseinquireofthecableserviceprovider
aboutthecorrectvalues.
UseNumberbuttonstoinputa4-digit
passwordinLockSystem‘On’.
Manually setting up programmes
(In digital mode)(Only DTV)
ManualTuningletsyoumanuallyaddaprogramme
toyourprogrammelist.
(For countries other than Finland, Sweden,
Denmark and Norway & When selecting
Antenna if Finland, Sweden, Denmark, Norway
or “--”country is chosen)
1
PressMENUtoaccesstheMainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Manual TuningandpressOK.
4
PresstheNavigationbuttonstoscrolltoDTV.
5
PresstheNavigationbuttonsorNumber
buttonstoscrollSelectthedesiredchannel
number,andthenaddprogrammes.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
1
PressMENUtoaccesstheMainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Manual TuningandpressOK.
4
PresstheNavigationbuttonstoscrolltoDTV.
5
PresstheNavigationbuttonsorNumber
buttonstoscrollSelectthedesiredFrequency,
SymbolrateandModulation,andthenadd
programmes.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
ENGLISH
22
WATCHING TV
NOTE
UseNumberbuttonstoinputa4-digit
passwordinLockSystem‘On’.
L:SECAML/L(France)
BG:PALB/G,SECAMB/G(Europe/East
Europe/Asia/NewZealand/M.East/Africa
/Australia)
I: PALI/II(U.K./Ireland/HongKong/South
Africa)
DK:PALD/K,SECAMD/K(EastEurope/
China/Africa/CIS)
Tostoreanotherchannel,repeatsteps4to9.
Manually setting up programmes
(In analogue mode)
ManualTuningletsyoumanuallytuneandarrange
thestationsinwhateverorderyoudesire.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Manual TuningandpressOK.
4
PresstheNavigationbuttonstoscrollto
TVandpressOK.(OnlyDTV)
5
PresstheNavigationbuttonstoscrollto
System.
6
PresstheNavigationbuttonstoscrollto
V/UHF or Cable.
7
PresstheNavigationbuttonsorNumber
buttonstoscrollSelectthedesiredchannel
number.
8
PresstheNavigationbuttonstoscrollto
Commencesearching.
9
PresstheNavigationbuttonstoscrollto
StoreandpressOK
10
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Assigning a station name
Youcanassignastationnamewithfivecharacters
toeachprogrammenumber.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Manual TuningandpressOK.
4
PresstheNavigationbuttonstoscrolltoTV.
(OnlyDTV)
5
PresstheNavigationbuttonstoscrolltoName
andpressOK.
6
PresstheNavigationbuttonstoscrolltoTV
System.
7
PresstheNavigationbuttonstoscrolltoV/UHF
or Cable.
8
PresstheNavigationbuttonstoscrollSelect
thepositionandmakeyourchoiceofthe
secondcharacter,andsoon.Youcanusean
thealphabetAtoZ,thenumber0to9,+/-,and
blankandpressOK
9
PresstheNavigationbuttonstoscrolltoClose
andpressOK.
10
PresstheNavigationbuttonstoscrolltoStore
andpressOK
11
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
ENGLISH
23
WATCHING TV
Editing your programme list
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Programme EditandpressOK.
4
Editprogrammesusingthefollowingbuttons.
Button Description
Highlightstheprogrammetype
Navigation Scrollsthroughprogrammetypes
orprogrammes
OK Selectsaprogrammetoview
P ( )
Movestothepreviousornext
page
NOTE
UseNumberbuttonstoinputa4-digit
passwordinLockSystem‘On’.
NOTE
IfyouselectCable,youcanseeCableDTV
Settingmenu.
WhenChannelAutoUpdateisOn,the
channelinformationwillbeautomatically
updatedwheneverthenetworkinformation
changes.
WhenChannelAutoUpdateisOff,the
channelinformationwillnotbeupdated.
Cable DTV Setting (In Cable
mode only)(Only DTV)
TherangethatausercanselectfromtheService
Operatormenudiffersdependingonnumberof
ServiceOperatorsupportedbyeachcountry,and
ifnumberofsupportedServiceOperatorforeach
countryis1,correspondingfunctionbecomesnon-
activation.
AfterchangingServiceOperator,awarning
windowsayingthatchannelmapwillbedeleted
whenOKbuttonispressedorCloseisselected,
andaAuto-tuningpop-upwindowappearswhen
'YES'isselected.
SETUP
Move OK
Auto Tuning
Manual Tuning
Programme Edit
Software Update : On
Diagnostics
CI Information
Cable DTV Setting ꔉ
1
PressMENUtoaccesstheMainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrolltoCable
DTV SettingandpressOK.
4
PresstheNavigationbuttonstoscrollto
Service Operator or Channel Auto update
andpressOK.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
ENGLISH
24
WATCHING TV
In TV mode (Only DTV)
1
 PresstheNavigationbuttons,scrolltothe
programmenumberyouwishtodelete.
2
 PresstheRedbuttontodeletetheselected
programmenumber.
3
 PresstheBluebuttontorelease.
1
 PresstheNavigationbuttons,scrolltothe
programmenumberyouwishtomove.
2
 PresstheGreenbuttonwiththeprogramme
numberselected,youwishtomove.
3
 Pressthenavigationbuttons,movetowhere
youwishtoplacetheprogrammenumber,and
thenpresstheGreenbuttonagain.
1
PresstheYellowbuttontostartAutoSort.
NOTE
NOTE
Theselectedprogrammeisdeleted,allthe
followingprogrammesareshiftedupone.
AfteractivatingAutoSortonce,youcanno
longereditprogrammes.
Deleting a programme
Moving a programme
Auto Sort
1
 PresstheNavigationbuttons,scrolltothe
programmenumberyouwishtoskip.
2
 PresstheBluebuttontoskiptheselected
programmenumber.
3
 PresstheBluebuttonagaintorelease.
Skipping a programme number
NOTE
Youwillbeunabletoselectaskipped
programmeusingP (
) buttonsduring
watchingTV.
Ifyouwishtowatchaskippedprogramme,
directlyentertheprogrammenumber
usingnumberbuttonsorreleaseitinthe
Programme EditmenuorEPG.
In DTV/RADIO mode (Only DTV)
1
 PresstheNavigationbuttons,scrolltothe
programmenumberyouwishtoskip.
2
 PresstheBluebuttontoskiptheselected
programmenumber.
3
 PresstheBluebuttonagaintorelease.
NOTE
Theskippedprogrammesareshownin
blueontheprogrammelistandthese
programmeswillnotappearonthescreen
whenchangingprogrammesusingP( )
buttonsduringwatchingTV.
Ifyouwishtowatchaskippedprogramme,
directlyentertheprogrammenumber
usingnumberbuttonsorreleaseitinthe
ProgrammeEditmenuorEPG.
Skipping a programme number
background
ENGLISH
25
WATCHING TV
Software Update (Only DTV)
SoftwareUpdatemeanssoftwarecanbe
downloadedthroughthedigitalterrestrial
broadcastingsystem.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
Software UpdateandpressOK.
4
SelectOnorOff.
IfyouselectOn,auserconfirmmessagebox
willbedisplayedtonotifythatnewsoftwareis
found.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
When setting “Software Update”
Occasionally,atransmissionofupdated
digitalsoftwareinformationwillresultinthe
followingmenuontheTVscreen.
SimpleUpdate:forcurrentupdatestream.
ScheduleUpdate:forscheduledupdate
streamWhentheSoftwareUpdatemenu
is"Off",themessagetochangeitto"On"
appears.
Whenthepoweristurnedoff,downloading
starts.Whenthepoweristurnedonwhile
updating,theprogressstatusisdisplayed.
SelecttheYesusingthe < >buttonandyou
willseethefollowingpicture.
AftertheSoftwareUpdateiscomplete,the
Systemrestarts.
Yes
Close
Software update is available.
Would you like to download now?
(approximately 30 Min ~ 2 hours)
Your TV software is updated when you turn off the TV
using the remote control or local key.
Do not unplug!
Yes
Close
A new software update is available at 00/00/0 00:00.
Do you want to update the software when available?
Hide
Stop
Software downloading progress.
Ver. 03.01.00 Ver. 03.02.00
65 %
New Software is successfully installed.
DuringProgressofaSoftwareUpdate,
pleasenotethefollowing
»
TheTVmustnotbeswitchedoff.
»
Theantennamustnotbedisconnected.
»
AfterSoftwareUpdate,youcanconfirmthe
updatedsoftwareversioninDiagnostics
menu.
»
Itmaytakehourstodownloadthesoftware,
somakesurethatthepowerstaysonduring
thedownload.
NOTE
background
ENGLISH
26
WATCHING TV
Diagnostics (Only DTV)
Thisfunctionenablesyoutoviewinformationon
theManufacturer,Model/Type,SerialNumberand
SoftwareVersion.
Thisdisplaystheinformationandsignal
strengthofthetuned*MUX.
Thisdisplaysthesignalinformationand
servicenameoftheselected*MUX.
*MUX:Ahigherdirectoryofchannelsin
digitalbroadcasting(asingleMUXcontains
multiplechannels.)
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
SETUPandpressOK.
3
PresstheNavigationbuttonstoscrollto
DiagnosticsandpressOK.
4
DisplayManufacturer,Model/Type,Serial
NumberandSoftwareVersion.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
CI [Common interface]
Information (Only DTV)
Thisfunctionenablesyoutowatchsomeencrypted
services(payservices).IfyouremovetheCI
Module,youcannotwatchpayservices.
WhenthemoduleisinsertedintotheCIslot,you
canaccessthemodulemenu.Topurchasea
moduleandsmartcard,contactyourdealer.Donot
repeatedlyinsertorremoveaCImodule
fromtheTV.Thismaycauseamalfunction.When
theTVisturnedonafterinsertingaCIModule,you
maynothaveanysoundoutput.
ThismaybeincompatiblewiththeCImoduleand
smartcard.
CI(CommonInterface)functionsmaynotbe
possibledependinguponthecountrybroadcasting
circumstances.
WhenusingaCAM(ConditionalAccessModule),
pleasemakesureitmeetsfullytherequirementsof
eitherDVBCIorCIplus.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoSETUP
andpressOK.
3
PresstheNavigationbuttonstoscrolltoCI
Information.andpressOK.
4
Selectthedesireditem:Moduleinformation,
smartcardinformation,language,orsoftware
downloadetcandpressOK.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
ThisOSDisonlyforillustrationandthemenu
optionsandscreenformatwillvaryaccording
totheDigitalpayservicesprovider.
ItispossibleforyoutochangeCI(Common
Interface)menuscreenandserviceby
consultingyourdealer.
NOTE
background
ENGLISH
27
WATCHING TV
Selecting the programme list
Youcancheckwhichprogrammesarestoredin
thememorybydisplayingtheprogrammelist.
Displaying programme LIST
1
PressLISTtoaccesstheProgrammeList.
2
Whenyouarefinished,pressMENU or EXIT.
NOTE
Youmayfindsomeblueprogrammes.
Thesehavebeensetuptobeskippedby
autoprogrammingorintheprogramme
editmode.
Someprogrammeswiththechannel
numbershownintheprogramme
LISTindicatethereisnostationname
assigned.
Selecting a programme in the programme list
1
PresstheNavigationbuttonstoprogramme.
2
Switchtothechosenprogrammenumberand
pressOK.
NOTE
PressTV/RAD in Digital TV. (Themode
willbeswitchedbetweenTV,DTVand
Radiofromtheprogramyouarecurrently
watching.)
Paging through a programme list
1
PresstheNavigationbuttonstoturnthepages.
2
ReturntonormalTVviewingandPressLIST.
Favourite programme setup
Selecting favourite programme
Favouriteprogrammeisaconvenientfeaturethat
letsyouquiklyscanuptoprogrammesofyour
choicewithouthavingtowaitfortheTVtoscan
throughallthein-betweenprogrammes.
1
Selectyourdesiredprogramme.
2
PressQ.MENUtoaccesstheFavouritemenu.
3
PresstheNavigationbuttons
toscrollto
Favourite.
4
Whenyouarefinished,pressOK or Q.MENU.
NOTE
Thiswillautomaticallyincludethe
selectedprogrammeintoyourfavourite
programmelist.
Displaying the favourite programme list
1
PressFAVtoaccesstheFavouriteProgramme
List.
2
Whenyouarefinished,pressEXIT.
background
ENGLISH
28
WATCHING TV
Using additional options
Adjusting aspect ratio
Resizetheimagetoviewtheimageatitsoptimal
sizebypressingQ.MENU whileyouarewatching
TV.
Ifafixedimagedisplaysonthescreenfora
longperiodoftime,itwillbeimprintedand
becomeapermanentdisfigurementonthe
screen.Thisis“imageburn”or“burn-in”and
notcoveredbythewarranty.
Iftheaspectratioissetto4:3foralong
periodoftime,imageburnmayoccuron
theletterboxedareaofthescreen.
CAUTION
Youcanalsochangetheimagesizeby
pressingQ. MENUoraccessingAspectRatio
inthe PICTUREmenu.
NOTE
-16:9:Thefollowingselectionwillallowyou
toadjustthepicturehorizontally,inlinear
proportion,tofilltheentirescreen(usefulfor
viewing4:3formattedDVDs).
Just Scan
-Just Scan:FollowingSelectionwillleadtoyou
viewthepictureofbestqualitywithoutlossof
originalpictureinhighresolutionimage.
Note:IfthereisnoiseinoriginalPicture,You
canseethenoiseattheedge.
-Original:WhenyourTVreceivesawidescreen
signalitwillautomaticallychangetothepicture
formatbroadcast.
-Full Wide:WhenTVreceivesthewidescreen
signal,itwillleadyoutoadjustthepicture
horizontallyorvertically,inalinearproportion,to
filltheentirescreenfully.
Original
Full Wide
background
ENGLISH
29
WATCHING TV
-4:3:Thefollowingselectionwillallowyoutoview
apicturewithanoriginal4:3aspectratio,gray
barswillappearonboththeleftandrightofthe
screen.
-14:9:Youcanviewapictureformatof14:9ora
generalTVprogrammeinthe14:9mode.The
14:9screenisviewedinthesamewayasin4:3,
butismagnifiedtotheleftandright.
-Zoom:Thefollowingselectionwillallowyouto
viewthepicturewithoutanyalteration,while
fillingtheentirescreen.However,thetopand
bottomofthepicturewillbecropped.
Youcanonlyselect4:3, 16:9 (Wide), 14:9,
Zoom/Cinema ZoominComponentmode.
Youcanonlyselect4:3, Original, 16:9
(Wide), 14:9, Zoom/Cinema ZoominHDMI
mode.
Youcanonlyselect4:3, 16:9 (Wide) in
RGB-PC, HDMI-PCmodeonly.
InDTV/HDMI/Component(over720p)mode,
Just Scanisavailable.
InAnalogue/AVmode,Full Wideisavailable.
NOTE
-Cinema Zoom:ChooseCinemaZoomwhenyou
wanttoenlargethepictureincorrectproportion.
Note:Whenenlargingorreducingthepicture,
theimagemaybecomedistorted.
< or >
button:Adjustenlargeproportionof
CinemaZoom.Theadjustmentrangeis1to
16.
or
button:Movethescreen.
background
ENGLISH
30
WATCHING TV
NOTE
IfyouwanttouseHDMI-PCmode,you
mustsettheinputlabeltoPCmode.
NOTE
Using the input list
Selecting an input source
1
PressINPUTtoaccesstheinputsourcelist.
-Theconnecteddevicedisplaysoneachinput
source.
2
PresstheNavigationbuttonstoscrolltooneof
theinputsourcesandpressOK.
Input source Description
Antenna or
Cable
WatchTVovertheair,cable,and
digitalcablebroadcast
RGB ViewaPCdisplayonthescreen
AV 1/2 WatchthecontentsinaVCRor
otherexternaldevices
Component WatchthecontentsinaDVDor
otherexternaldevices,orthrough
adigitalset-topbox
HDMI 1/2 WatchcontentsinaPC,DVD
orDigitalsettopboxotherhigh
definitiondevices
Theconnectedinputsourcesdisplayinblack
andthedisconnectedinputsourcesingrey.
-Ifyouaddaninputlabeltoeachinput
sources,youcaneasilyidentifyadevice
connectedtoeachinputsource.
Adding an Input label
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
OPTION andpressOK.
3
PresstheNavigationbuttonstoscrollto
Input LabelandpressOK.
4
PresstheNavigationbuttonstoscrolltooneof
theinputsources.
5
PresstheNavigationbuttonstoscrolltooneof
theinputlabelandpressOK.
6
Whenyouarefinished,press EXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Ifyouselect"Yes"thesizeandimagequality
areoptimisedforyourPC.
Ifyouselect"No"thesizeandimagequality
areoptimisedfortheAVdevice (DVD
player, set-top box, gaming device).
Ifyouselect"Do not show message again"
thismessagedoesnotappearuntiltheTV
isreset.Youcanchangethesetvaluein
MENU ► OPTION ► Input Label.
ThevaluessetforHDMI1/HDMI2aresaved
independently.
TheOSD (On Screen Display)isdisplayed
onthescreenasshownbelow.
»
WhenturningtheproductoninHDMIinput.
»
WhenswitchingtoHDMIinput.
»
WhenconnectinganHDMIcablewithno
signal.
Is the input connected to your PC?
Do not show message again.
Yes No
background
ENGLISH
31
WATCHING TV
On-screen menu language /
Country selection
TheinstallationguidemenuappearsontheTV
screenwhenitisswitchedonforthefirsttime.
1
PresstheNavigationbuttonstoscrollto
Desired Language andpressOK.
2
PresstheNavigationbuttonstoscrollto
Country andpressOK.
If you want to change Language /
Country selection
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
OPTION andpressOK.
3
PresstheNavigationbuttonstoscrollto
Menu Language orCountry andpressOK.
4
PresstheNavigationbuttonstoscrollto
Desired Language orCountry optionyou
wantandpressOK.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Countryselection:OnlyDTVMode
WhenFranceisselectedforCountry,
passwordisnot'0','0','0','0'but'1','2','3',
'4'.
Ifyoudonotfinishtheset-up Installation
GuidebypressingBACKorifyoutime
outontheOSD(OnScreenDisplay)the
installationmenuwillcontinuouslyappear
untilthesetupiscompletedwheneverthe
TVisswitchedon.
Ifyouselectthewronglocalcountry,teletext
maynotappearcorrectlyonthescreenand
someproblemsmayoccurduringteletext
operation.
TheCI(CommonInterface)functionmaynot
beappliedbasedoncountrybroadcasting
circumstances.
DTVmodecontrolbuttonsmaynot
functionbasedoncountrybroadcasting
circumstances.
IncountrythatDigitalbroadcastingregulation
isn’tfixed,someDTVfunctionmaynot
workdependingondigitalbroadcasting
circumstances.
TheCountrySetting"UK"shouldonlybe
activatedinUK.
Ifthecountrysettingissetto"--",European
terrestrial/cabledigitalstandardbroadcasting
programmesareavailable,butsomeDTV
functionsmaynotworkproperly.
NOTE
background
ENGLISH
32
WATCHING TV
Language selection (In digital
mode only)(Only DTV)
TheAudiofunctionallowsselectionofapreferred
language.
Ifaudiodatainaselectedlanguageisnot
broadcast,thedefaultlanguageaudiowillbe
played.
UsetheSubtitlefunctionwhentwoormoresubtitle
languagesarebroadcast.Ifsubtitledataina
selectedlanguageisnotbroadcast,thedefault
languagesubtitlewillbedisplayed.
Whenthelanguagesyouselectedastheprimary
forAudio LanguageandSubtitle Language
arenotsupported,youcanselectlanguagein
secondarycategory.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
OPTION andpressOK.
3
PresstheNavigationbuttonstoscrollto
Audio Language orSubtitle Language and
pressOK.
4
PresstheNavigationbuttonstoscrollto
Desired Language optionyouwantandpress
OK.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Audio Language Selection
Whentwoormoreaudiolanguagesarebroadcast,
youcanselecttheaudiolanguage.
1
PressQ.MENUtoaccessthequickmenu.
2
PresstheNavigationbuttonstoscrolltoAudio.
3
PresstheNavigationbuttonstoscrollto
Audio Language optionyouwantandpress
OK.
4
Whenyouarefinished,pressQ.MENU or
EXIT.
Audio Language OSD Information
Display Status
NotAvailable
MPEGAudio
DolbyDigitalAudio
Audiofor“VisualImpaired”
Audiofor“HearingImpaired”
DolbyDigitalPlusAudio
AACAudio
background
ENGLISH
33
WATCHING TV
Subtitle Language Selection
Whentwoormoresubtitlelanguagesare
broadcast,youcanselectthesubtitlelanguage
withtheSUBTITLEbuttonontheremotecontrol.
PresstheNavigationbuttonstoselectasubtitle
language.
Subtitle Language OSD Information
Display Status
NotAvailable
TeletextSubtitle
Subtitlefor“HardofHearing”
Theaudio/subtitlescanbedisplayedina
simplerformwith1to3charactersbroadcast
bytheserviceprovider.
WhenyouselectsupplementaryAudio(Audio
for“Visual/HearingImpaired”)theTVmay
outputapartoftheMainaudio.
Using the Lock options
Locking the buttons on the TV.
Enterthepassword,press‘0’, ‘0’, ‘0’, ‘0’onthe
remotecontrolhandset.
WhenFranceisselectedforCountry,passwordis
not‘0’, ‘0’, ‘0’, ‘0’but‘1’,’2’,’3’,’4’.
LockthebuttonsontheTVtopreventany
unwantedoperationsoraccidentsbychildren.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoLOCK
andpressOK.
3
PresstheNavigationbuttonstoscrollto
Key LockandpressOK.
4
PresstheNavigationbuttons
toscrolltoOn
andpressOKtoactivatetheKeylockfeature.
-TodeactivatetheKeylockfeature,selectOff.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
TheTVisprogrammedtorememberthelast
settingafteryouturntheTVoff.
IfyouturntheTVoffwhilethekeylock
featureisactivatedandwishtoturnitback
on,pressthe ontheTV.Youcanalso
switchthedeviceonusingtheremote
controlbypressingthe , INPUT ,P or
Numberbuttons.
IfyoupressanybuttonontheTVwiththe
Keylockfeatureactivated, Key Lock On
appearsonthescreen.
NOTE
background
ENGLISH
34
WATCHING TV
Parental control (In digital mode
only) (Only DTV)
Thisfunctionoperatesaccordingtoinformation
fromthebroadcastingstation.Thereforeifthe
signalhasincorrectinformation,thisfunctiondoes
notoperate.
Apasswordisrequiredtogainaccesstothis
menu.
Thissetisprogrammedtorememberwhichoption
itwaslastsettoevenifyouswitchthesetoff.
Preventschildrenfromwatchingcertainadult’sTV
programmes,accordingtotheratingslimitset.
Enterapasswordtowatchablockedprogramme.
Using the Quick menu
Customizethefrequentlyusingmenus.
1
PressQ.MENUtoaccessthequickmenu.
2
PresstheNavigationbuttonstoscrollthrough
thefollowingmenus.
Menu Description
Aspect Ratio
Resizesanimage.(16:9,Just
Scan,Original, Full Wide, 4:3,
14:9, Zoom,CinemaZoom1)
Clear Voice ll
Bydifferentiatingthehuman
soundrangefromothers,it
helpsuserslistentohuman
voicesbetter.
Picture Mode
Selectsoneofthepresetimage
modes(Vivid,Standard,
Cinema,Sport,Game)
Sound Mode
Selectsoneofthesoundmodes
(Standard,Music,Cinema,
Sport,Game)
Audio
Selectsthesoundoutput.
Sleep Timer
Setsthelengthoftimeuntilthe
TVtoturnsoff
Favourite
Selectsthefavourite
programme.
USB Device
Selects“Eject”inordertoeject
USBdevice.
Aspect Ratio
16:9
Theavailablemenusandoptionsmaydiffer
fromtheinputsourcethatyouareusing.
NOTE
3
PresstheNavigationbuttonstoscrolltoan
optionyouwantandpressOK.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoLOCK
andpressOK.
3
PresstheNavigationbuttonstoscrollto
Parental Guidance andpressOK.
4
PresstheNavigationbuttonstoscrollto
MakeappropriateadjustmentsandpressOK.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
(ExceptforFrance)
(OnlyFrance)
Blocking Off ꔓ
10 and above
11 and above
12 and above
13 and above
14 and above
15 and above
16 and above
17 and above
18 and above
Blocking Off : Permits all
programmes
10 and above
11 and above
12 and above
13 and above
14 and above
15 and above
16 and above
17 and above
18 and above
Programmes for 18 and
above will be blocked
18 and above ꔓ
background
ENGLISH
35
EPG (ELECTRONIC PROGRAMME GUIDE) (IN DIGITAL MODE) (ONLY DTV)
EPG (ELECTRONIC PROGRAMME GUIDE) (IN
DIGITAL MODE) (ONLY DTV)
Using Electronic
Programme Guide
ThissystemhasanElectronicProgrammeGuide
(EPG)tohelpyournavigationthroughallthe
possibleviewingoptions.
TheEPGsuppliesinformationsuchasprogramme
listings,startandendtimesforallavailable
services.Inaddition,detailedinformationabout
theprogrammeisoftenavailableintheEPG(the
availabilityandamountoftheseprogrammedetails
willvary,dependingontheparticularbroadcaster).
ThisfunctioncanbeusedonlywhentheEPG
informationisbroadcastbybroadcasting
companies.
TheEPGdisplaystheprogrammedetailsfornext
8days.
1
PressINFO toshowsthepresentscreen
information.
Icon Description
DisplayedwithaDTVProgramme.
DisplayedwithaRadioProgramme.
DisplayedwithaMHEGProgramme.
DisplayedwithaAACProgramme.
Aspectratioofbroadcastingprogramme.
DisplayedwithaTeletextProgramme.
DisplayedwithaSubtitleProgramme.
DisplayedwithaScrambleProgramme.
DisplayedwithaDolbyProgramme.
DisplayedwithaDolbyDigitalPLUS
Programme.
Broadcastedprogrammewiththe
iconmaynotbedisplayedinTVOut
dependingontheinformationofthe
programme.
576i/p,720p,1080i/p:Resolutionof
broadcastingprogramme
NOTE
Switch on/off EPG
1
PressGUIDEtoswitchonoroffEPG.
Select a programme
1
PresstheNavigationbuttonsorPAGE buttons
toselectdesiredprogramme.
2
TheEPGwilldisappearaftermovingtoa
selectedprogram,pressOK.
background
ENGLISH
36
EPG (ELECTRONIC PROGRAMME GUIDE) (IN DIGITAL MODE)
Button Function in Date Change
Mode
Button Description
Green
Button
SwitchoffDatesettingmode.
OK Changetotheselecteddate.
or
Selectadate.
SwitchoffDatesettingmode.
GUIDE SwitchoffEPG.
BACK
EXIT
Button Function in 8 Day Guide
Mode
Button Description
Red Button ChangeEPGmode.
Green
Button
EnterDatesettingmode.
Yellow
Button
EnterTimerRecord/Remindsetting
mode.
Blue Button EnterTimerRecord/Remindlistmode.
OK TheEPGwilldisappearaftermovingto
aselectedprogram.
or
SelectNOWorNEXTProgramme.
or
SelecttheBroadcastProgramme.
PAGE ( , )
PageUp/Down.
GUIDE SwitchoffEPG.
BACK
EXIT
TV/RAD SelectTVorRADIOProgramme.
INFO Detailinformationonoroff
FAV Thisdisplaysthe8DayGuidemodefor
theprogrammeintheFavouriteList.
Programme Guide
ALL
NOW
NEXT
1 YLE TV1
Keno
World Business
2 YLE TV2
4 TV..
Your World Today
Fantomen
Legenen om Den....
Kritiskt
Naturtimmen
ABC
Lyssna
Tänään otsikoissa
Glamour
5 YLE FST
6 CNN
8 YLE24
RADIOPr. Change
▲
Favourite
Mode Schedule Schedule List
Information
That ’70s show
1 YLE TV1
6 Apr. 2007 15:09
▲
Button Function in NOW/NEXT
Guide Mode
Youcanviewaprogrambeingbroadcastedand
onescheduledtofollow.
Button Description
Red Button ChangeEPGmode.
Yellow
Button
EnterTimerRecord/Remindsetting
mode.
Blue Button EnterTimerRecord/Remindlistmode.
OK TheEPGwilldisappearaftermovingto
aselectedprogram.
or
SelectNOWorNEXTProgramme.
or
SelecttheBroadcastProgramme.
PAGE ( , )
PageUp/Down.
GUIDE SwitchoffEPG.
BACK
EXIT
TV/RAD SelectTVorRADIOProgramme.
INFO Detailinformationonoroff
FAV Thisdisplaysthenow/nextmodeforthe
programmeintheFavouriteList.
background
ENGLISH
37
EPG (ELECTRONIC PROGRAMME GUIDE) (IN DIGITAL MODE) (ONLY DTV)
Button Function in Extended
Description Box
Button Description
or
TextUp/Down.
Yellow
Button
EnterTimerRecord/Remindsetting
mode.
INFO Thedetailinformationonoroff.
BACK
GUIDE SwitchoffEPG.
Button Function in Record/
Remind Setting Mode
Setsastartorendtimeforrecording,andsets
onlyastarttimeforthereminder.
Thisfunctionisavailableonlywhenrecording
equipmentthatusepin8recordingsignalinghas
beenconnectedtotheAVterminal,usingaSCART
cable.
Button Description
BACK ChangetoGuideorSchedulemode.
or
SelectRecordorRemind.
Functionsetting.
or
SelectDate,Start/Endtimeor
Programme.
OK SaveTimerRecord/Remind.
Button Function in Schedule List
Mode
Ifyou’vecreatedaschedulelist,ascheduled
programisdisplayedatthescheduledtimeeven
whenyouarewatchingadifferentprogramatthe
time.
OnlytheUp/Down/OK/BACKkeyswillworkwhen
apopupwindowisopen.
Button Description
Red Button AddnewManualRecordingsetting
mode.
Green
Button
AddnewTimerWatchingsettingmode.
Blue Button ChangetoGuidemode.
GUIDE
BACK SwitchoffEPG.
EXIT
OK SelectyourdesiredOption(Modify/
Delete/DeleteAll).
or
SelectScheduleList.
PAGE ( , )
PageUp/Down.
background
ENGLISH
38
USING THE MONITOR SET
CONNECTING TO A PC
YourTVsupportsthePlug&Play*featureand
hasthebuilt-inspeakerswithSurroundXthat
reproducessoundclearlywitharichbass.
*Plug&Play:ThefunctionwhenaPCrecognizes
aconnecteddevicethatusersconnecttoaPC
andturnon,withoutdeviceconfigurationoruser
intervention.
ItisrecommendedtousetheTVwiththe
HDMIconnectionforthebestimagequality.
Ifyouwanttouseanoptionalexternal
speakerinsteadofthebuilt-inspeaker,set
theTVspeakerfeaturetooff
(Seep.63).
UseaHighSpeedHDMI™Cable.
PleasecheckthePCenvironmentifyou
cannothearthesoundinHDMImode.
IfyouwanttouseHDMI-PCmode,youmust
settheinputlabeltoPCmode.
NOTE
NOTE
HDMI connection
Transmitsthedigitalvideoandaudiosignalsfrom
yourPCtotheTV.ConnectthePCandtheTV
withtheHDMIcableasshowninthefollowing
illustrations.YoushouldsetPCasaninput
labeltoconnectthePCtotheTVwithanHDMI
connection.Toaddaninputlabel,seeAddingan
InputlabelonSeep.30.
(
MONO
)
12
AUDI0
AV IN
2
0
HDMI OUT
PC
background
ENGLISH
39
USING THE MONITOR SET
IfyouwanttouseHDMI-PCmode,youmust
settheinputlabeltoPCmode.
Ifyoudonotuseanoptionalexternal
speaker,connectthePCtotheTVwiththe
optionalaudiocable.
IfyouturntheTVonwhenthesetbecomes
cold,thescreenmayflicker.Thisisnormal.
Useashieldedsignalinterfacecable,such
asD-sub15pinsignalcableandDVIto
HDMIcable,withaferritecoretomaintain
standardcompliancefortheproduct.
Somered,green,orbluespotsmayappear
onthescreen.Thisisnormal.
NOTE
DVI to HDMI connection
TransmitsthedigitalvideosignalfromyourPCto
theTV.ConnectthePCandtheTVwiththeDVIto
HDMIcableasshownthefollowingillustrations.To
transmitanaudiosignal,connectanoptionalaudio
cable.
RGB connection
TransmitstheanalogvideosignalfromyourPCto
theTV.ConnectthePCandtheTVwiththeD-sub
15pincableasshownthefollowingillustrations.To
transmitanaudiosignal,connectanoptionalaudio
cable.
PC
RGB OUT (PC) AUDIO OUT
1
2
AV
IN
2
(
MONO
)
A
U
DI
0
PC
AUDIO OUT
DVI OUT
12
(
MONO
)
A
U
DI
0
Connectthesignal
inputcableandtighten
itbyturningthescrews
clockwise.
Donotpressthescreenwithyourfingerfor
alongtimeasthismayresultintemporary
distortiononthescreen.
Avoiddisplayingafixedimageonthescreen
foralongperiodoftimetopreventimage
burn.Useascreensaverifpossible.
CAUTION
background
ENGLISH
40
USING THE MONITOR SET
Adjusting the screen
Selecting an image mode
Displayimagesinitsoptimizedsettingsby
selectingoneofthepresetimagemodes.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
Picture ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoan
imagemodeyouwantandpressOK.
Mode Description
Vivid Adjuststhevideoimageforthe
retailenvironmentbyenhancingthe
Contrast, Brightness, Colour,and
Sharpness.
Standard Adjuststheimageforthenormal
environment.
Cinema Optimizesthevideoimageforthe
cinematiclookandenjoymoviesasif
youareinamovietheater.
Sport Optimizesthevideoimageforhigh
anddynamicactionsbyemphasizing
primaryColourssuchaswhite,grass,
orskyblue.
Game Optimizesthevideoimagefora
fastgamingscreensuchasPCsor
games.
Expert1/2 Adjuststhedetailedvideoimage
settingsforvideoexpertsaswellas
generalviewers.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Customizing image options
Customizebasicandadvancedoptionsofeach
imagemodeforthebestscreenperformance.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
Picture ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoan
imagemodeyouwantandpressOK.
5
Selectandadjustfollowingoptions,andthen
pressOK.
Option Description
Backlight Adjuststhebrightnessofthe
screenbycontrollingtheLCD
backlight.Ifyoudecreasethe
brightnesslevel,thescreen
becomesdarkerandthepower
consumptionwillbereduced
withoutanyvideosignalloss.
Contrast Increasesordecreasesthe
gradientofthevideosignal.
YoumayuseContrastwhen
thebrightpartoftheimageis
saturated.
Brightness Adjuststhebaselevelofthe
signalintheimage.Youmayuse
Brightnesswhenthedarkpartof
theimageissaturated.
Sharpness Adjuststhelevelofcrispnessin
theedgesbetweenthelightand
darkareasofthepicture.The
lowerthelevel,thesofterthe
image.
Colour AdjustsintensityofallColours.
Tint AdjuststhebalancebetweenRed
andGreenlevels.
Colour
Temperature
Settowarmtoenhancehotter
colourssuchasred,orsettocool
tomakepicturebluish.
Advanced
Control
Customizestheadvanced
options.Seemoreinformation
aboutadvancedoptionsSeep.62.
Reset
Restorestheoptionstothe
defaultsetting.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
ENGLISH
41
USING THE MONITOR SET
Customizing PC display options
Customizeoptionsofeachimagemodeforthe
bestimagequality.
Thisfunctionworksinthefollowingmode:
RGB[PC]mode.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
PICTUREandpressOK.
3
PresstheNavigationbuttonstoscrollto
ScreenandpressOK.
4
Selectandadjustfollowingoptions,andthen
pressOK.
Option Description
Resolution MatchtheresolutionofRGBmode.
(ResolutionmenuisEnabledonlyfor
thefollowingresolutionwith60Hz.)
Vertical resolution : 768
1024 x 768(Default)
1280x768
1360x768
Vertical resolution : 900
1280 x 960(Default)
1440x900
1600x900
Vertical resolution : 1050
1400x1050
1680 x 1050(Default)
Auto
Configure
SetstoadjustthescreenPosition,
SizeandPhaseautomatically.The
displayedimagemaybeunstablefor
afewsecondswhiletheconfiguration
isinprogress.
Position/
Size/Phase
Adjuststheoptionswhenthe
imageisnotclear,especiallywhen
charactersareshaky,aftertheauto
configuration.
Reset Restorestheoptionstothedefault
setting.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Adjusting the sound
Selecting an sound mode
Playthesoundinitsoptimizedsettingsby
selectingoneofthepresetsoundmodes.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
AUDIOandpressOK.
3
PresstheNavigationbuttonstoscrolltoSound
ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoa
soundmodeyouwantandpressOK.
Mode Description
Standard Selectswhenyouwantstandard-
qualitysound.
Music Selectswhenyoulistentomusic.
Cinema Selectswhenyouwatchmovies.
Sport Selectswhenyouwatchsports
events.
Game Selectswhenyouplaygames.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
ENGLISH
42
USING THE MONITOR SET
Customizing sound options
Customizeoptionsofeachsoundmodeforthe
bestsoundquality.
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
AUDIOandpressOK.
3
PresstheNavigationbuttonstoscrolltoSound
ModeandpressOK.
4
PresstheNavigationbuttonstoscrolltoa
soundmodeyouwantandpressOK.
5
Selectandadjustfollowingoptions,andthen
pressOK.
Option Description
Surround X Thisoptionenhancessounddepth
andclaritybymaximizingthe
Surroundeffect.
Treble Controlsthedominantsoundsinthe
output.Whenyouturnupthetreble,
itwillincreasetheoutputtothe
higherfrequencyrange.
Bass Controlsthesoftersoundsinthe
output.Whenyouturnupthebass,
itwillincreasetheoutputtothe
lowerfrequencyrange.
Reset Resetsthesoundmodetothe
defaultsetting.
6
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
background
ENGLISH
43
ENTERTAINMENT
1
2
AV
IN2
(MONO
)
A
U
DI
0
ENTERTAINMENT
Using integrated media
features
Connecting USB storage devices
ConnectUSBstoragedevicessuchasaUSBflash
memory,externalharddrive,orMP3playertothe
TVandusemultimediafeatures(“Browsing files”
Seep.45).
ConnectaUSBflashmemoryorUSBmemory
cardreadertotheTVasshownonthefollowing
illustration.TheUSBscreenappears.
TodisconnectaUSBstoragedevice,makesureto
endtheconnectionproperlytopreventdamagesto
theTVorfiles.
or
1
PressQ.MENUtoaccessthequickmenus.
2
PresstheNavigationbuttonstoscrolltoUSB
DeviceandpressOK.
3
DisconnecttheUSBstoragedeviceonlywhen
themessagesaysthatitissafetoremove.
DonotturntheTVofforremoveaUSB
storagedevicewhiletheUSBstorage
deviceisconnectedtotheTV,asthiscould
resultinlossoffilesordamagetotheUSB
storagedevice.
BackupyourfilessavedonaUSBstorage
devicefrequently,asyoumayloseor
damagethefilesandthismaybenot
coveredbythewarranty.
CAUTION
background
ENGLISH
44
ENTERTAINMENT
Tips for using USB storage devices
OnlyaUSBstoragedeviceisrecognizable.
IftheUSBstoragedeviceisconnected
throughaUSBhub,thedeviceisnot
recognizable.
AUSBstoragedeviceusinganautomatic
recognitionprogrammemaynotbe
recognized.
AUSBstoragedevicewhichusesitsown
drivermaynotberecognized.
TherecognitionspeedofaUSBstorage
devicemaydependoneachdevice.
PleasedonotturnofftheTVorunplug
theUSBdevicewhentheconnectedUSB
storagedeviceisworking.Whensuchdevice
issuddenlyseparatedorunplugged,the
storedfilesortheUSBstoragedevicemay
bedamaged.
PleasedonotconnecttheUSBstorage
devicewhichwasartificiallymaneuveredon
thePC.Thedevicemaycausetheproductto
malfunctionorfailtobeplayed.Neverforget
touseonlyaUSBstoragedevicewhichhas
normalmusicfiles,imagefilesormoviefiles.
PleaseuseonlyaUSBstoragedevicewhich
wasformattedasaFAT,FAT16,FAT32,
NTFSfilesystemprovidedwiththewindows
operatingsystem.Incaseofastoragedevice
formattedasadifferentutilityprogramme
whichisnotsupportedbyWindows,itmay
notberecognized.
PleaseconnectpowertoaUSBstorage
device(over0.5A)whichrequiresanexternal
powersupply.Ifnot,thedevicemaynotbe
recognized.
PleaseconnectaUSBstoragedevicewith
thecableofferedbythedevicemaker.
SomeUSBstoragedevicesmaynotbe
supportedoroperatedsmoothly.
FilealignmentmethodofUSBstoragedevice
issimilartoWindowXPandfilenamecan
recognizeupto100Englishcharacters.
Besuretobackupimportantfilessincedata
storedinaUSBmemorydevicemaybe
damaged.Wewillnotberesponsibleforany
dataloss.
IftheUSBHDDdoesnothaveanexternal
powersource,theUSBdevicemaynotbe
detected.Sobesuretoconnecttheexternal
powersource.
-Pleaseuseapoweradaptorforanexternal
powersource.WedonotguaranteeanUSB
cableforanexternalpowersource.
DatainaUSBstoragedevicecannotbe
deletedintheNTFSfilesystem.
IfyourUSBmemorydevicehasmultiple
partitionsorifyouuseaUSBmulti-card
reader,youcanuseupto4partitionsorUSB
memorydevices.
OnlytheFAT,FAT16,FAT32filesystem
supportsthedeletefunction.
IfaUSBmemorydeviceisconnectedtoa
USBmulti-cardreader,itsvolumedatamay
notbedetected.
IftheUSBmemorydevicedoesnotwork
properly,disconnectandreconnectit.
HowfastaUSBmemorydeviceisdetected
differsfromdevicetodevice.
IftheUSBisconnectedinStandbyMode,
specificharddiskwillautomaticallybeloaded
whentheTVisturnedon.
Therecommendedcapacityis1TBorless
foraUSBexternalharddiskand32GBor
lessforUSBmemory.
Anydevicewithmorethantherecommended
capacitymaynotworkproperly.
IfaUSBexternalharddiskwitha“Energy
Saving”functiondoesnotwork,turnthe
harddiskoffandonagaintomakeitwork
properly.
USBstoragedevicesbelowUSB2.0are
supportedaswell.Buttheymaynotwork
properlyinthemovielist.
WhenabrokenfileisplayedintheUSB
storage,theTVmayturnofforwork
abnormally.
background
ENGLISH
45
ENTERTAINMENT
Browsing files
AccessthePhoto,MusicorMovielistsand
browsefiles.
1
ConnectaUSBstoragedevice.
2
PresstheNavigationbuttonstoscrollto
PHOTO LIST,MUSIC LISTorMOVIE LIST
andpressOK.
3
SelectDrive1toaccesstheconnectedUSB
storagedevice
4
Selectafolderyouwant.
-Toreturntothepreviouslevel,select
Up Folder.
PHOTO LIST
Photo List
Photo List
USB
USB
Up Folder
Up Folder
Drive 1
Drive 1
Drive 1
SG 001 SG 003
SG 002 SG 004
Page 1/1
Page 1/1
No Marked
No Marked
Navigation
Navigation
Popup Menu
Popup Menu
Page Change
Page Change
Mark
Mark
Exit
Exit
0 folder(s), 0 file(s)
0 folder(s), 0 file(s)
MOVIE LISTMUSIC LIST
5
PresstheNavigationbuttonstobrowsefiles.
Thehighlightedfilewilldisplayinthepreview
window.
No. Description
1
Currentpagenumber/totalnumberofpages
2
Thenumberofselectedfiles
3
FileandFoldername
4
Previewwindow
5
Filesize,information.
6
Returntothepreviouslevel
7
Availablebuttonsontheremotecontrol
Supported file format
Type Supported file format
JPG
Availablesize
Baseline:64pixel(W)x64pixel(H)-
15360pixel(W)x8640pixel(H)
Progressive:64pixel(W)x64pixel(H)-
1920pixel(W)x1440pixel(H)
Music
MP3
Bitraterange32Kbps-320Kbps
Samplingrate(SamplingFrequency)
MPEG1layer3:32kHz,44.1kHz,
48kHz
MPEG2layer3:16kHz,22.05kHz,
24kHz
MPEG2.5layer3:8kHz,11.025kHz,
12kHz
* Acopy-protectedfilewillnotplay.
Video
dat,mpg,mpeg,ts,trp,tp,vob,mp4,mkv,
avi,divx
Maxbitrateofplayablemoviefile:
20Mbps(Megabitpersecond)
Bitrateofaudioformat:within32-
320kbps(MP3)
Supportedsubtitleformat:*.smi,*.srt,
*.sub(MicroDVD,SubViewer1.0/2.0),
*.ass,*.ssa,*.txt(TMPlayer),
*.psb(PowerDivx)
Photo List
USB
Up Folder
Drive 1
Up Folder
SG kim 002 10/01/2010 SG kim 003 10/01/2010
SG kim 001 10/01/2010
SG kim 004 10/01/2010 SG kim 005 10/01/2010
SG kim 006 10/01/2010 SG kim 007 10/01/2010
Page 1/1 No Marked
Navigation
Popup Menu
Page Change
Mark
Exit
0 folder(s), 0 file(s)
1
3
4
5
6
7
2
background
ENGLISH
46
ENTERTAINMENT
Viewing Photos
ViewimagefilessavedinaUSBstoragedevice.
Thedisplaysonthescreenmaydifferfromthe
model.
1
PresstheNavigationbuttonstoscrolltoUSB
andpressOK.
2
PresstheNavigationbuttonstoscrolltoPhoto
ListandpressOK.
3
PresstheNavigationbuttonstoselectDrive1
toaccesstheconnectedUSBstoragedevice.
4
PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
5
PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
Apop-upwindowwillappears.
6
Viewphotosbyusingthefollowingmenus.
Menu Description
View Displaystheselectedphotoinafull-
screenview.
Drive:Viewsphotossavedina
USBstoragedrive.
Mark All
or Unmark
All
Selectsallfilesorclearsallofyour
selections
Delete DeletesafilesavedinaUSBstorage
device.
NOTE
Youcannotdeletethefilessaved
inasharedfolderofaPC.
Close Closesthepop-upmenu.
Photo List
Drive 1
Up Folder
SG 001
Up Folder
SG 002
10/01/2010
SG 003
10/01/2010
SG 001
10/01/2010
SG 004
10/01/2010
SG 005
10/01/2010
SG 006
10/01/2010
SG 007
10/01/2010
Page 2/3 No Marked
Navigation
Popup Menu
Page Change
Mark
Exit
1 folder(s),7 file(s)
1366x768, 125KB
View
Mark All
Delete
Close
ꔗ 1/17 ꔃ
Slideshow BGM
Delete
Q.MENU
Option Hide
Using photo options
Usethefollowingoptionswhileviewingphotos.
Number of selected photos
Options
Option Description
Slideshow Startsorstopsaslideshowwithselected
photos.
Iftherearenoselectedphotos,all
photossavedinthecurrentfolder
displayduringaslideshow.
Tosetaslideshowspeed,selectOption.
BGM Turnsthebackgroundmusiconoroff.
Tosetthebackgroundmusicfolder,
selectOption.
(Rotate)
Rotatesphotosclockwise(90°,180°,
270°,360°).
NOTE
Thesupportedphotosizeislimited.
Youcannotrotateaphotoifthe
resolutionoftherotatedwidthis
largerthanthesupportedresolution
size.
Delete Deletesaphoto.
Option
Slide Speed:Selectsaslideshow
speed(Fast, Medium, Slow).
Music Album:Selectsamusicfolder
forthebackgroundmusic.
NOTE
Youcannotchangethemusicfolder
whilethebackgroundmusicis
playing.
Hide Hidestheoptionwindow.
Todisplaytheoptions,press
OK
.
background
ENGLISH
47
ENTERTAINMENT
Q.MENU options for Photo List.
WhenyouselecttheSet Photo View.
1
PressQ. MENUtoaccessthePop-Upmenus.
2
PresstheNavigationbuttonstoscrolltoSlide
Speed or Music Folder.
3
PresstheNavigationbuttons tomake
appropriateadjustmentsandpressOK.
Whenyouselectthe Set Video.
1
PresstheNavigationbuttons tomake
appropriateadjustments.(Seep.61)
WhenyouselecttheSet Audio.
1
PresstheNavigationbuttons
toshowthe
Sound Mode, Auto Volume, Clear Voice II,
Balance.
2
PresstheNavigationbuttons tomake
appropriateadjustments.(Seep.63)
When“Off”isselectedinRepeatmenu,
replaywillstoponcethelastfileinthelist
finishesplaying.But,when“ ”buttonis
pressedwhilethelastfileinthelistisinthe
middleofreplayand“Repeat”isin“Off”
position,thefirstfileinthelistwillbeplay.
NOTE
Choose Options.
Set Photo View.
Set Video.
Set Audio.
ꕉ Previous
1
PressQ. MENUtoaccessthePop-Upmenus.
2
PresstheNavigationbuttons toscrolltoSet
Photo View or Set Video, Set Audioand
PressOK
Listening to Music
1
PresstheNavigationbuttonstoscrolltoUSB
andpressOK.
2
PresstheNavigationbuttonstoscrolltoMusic
ListandpressOK.
3
SelectDrive1toaccesstheconnectedUSB
storagedevice.
4
PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
5
PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
Apop-upwindowwillappears.
6
Playmusicbyusingthefollowingmenus.
Menu Description
Play, Stop
Play, or
Play
Marked
Playsmusic,stopsplayback,orplays
theselectedmusicfile.Ifyouplay
musicwithoutselectingmusicfiles,all
ofthemusicfilessavedinthecurrent
folderwillplay.
The iconwillappearinfrontofthe
durationonthecurrentlyplayingfile.
Drive:Listentomusicfilessavedin
aUSBstoragedrive.
Play with
Displaysphotosduringplayback.
Mark All
or Unmark
All
Selectsallfilesorclearsallofyour
selections
Delete DeletesafilesavedinaUSBstorage
device.
Close Closesthepop-upmenu.
Music List
Music
SG 001
Page 2/3
Title
No Marked
Navigation Popup Menu Page Change
Mark
1 folder(s), 3 file(s)
Up Folder
Up Folder
SG 001.mp3
03:50
SG 002.mp3
03:55
SG 003.mp3
03:35
3945 KB
128 Kbps
Play
Play with Photo
Mark All
Delete
Close
Exit
background
ENGLISH
48
ENTERTAINMENT
Music
S003
0:27 / 3:67
Option
Adamagedorcorruptedfilewillnotplayand
thedurationofthefiledisplayas00:00.
Acopy-protectedfilewillnotplay.
IftheTVisnotinuseforsometime
duringplayback,theinformationboxasa
screensaverwillappeartopreventimage
burn.
ToreturntotheMusiclistscreen,pressOK
orBACK.
NOTE
7
Controlplaybackbyusingthefollowing
buttons.
Button Description
Stopsplayback
Playsamusicfile
Pausesorresumesplayback
Skipstothenextfile
Skipstothepreviousfile
Time elapsed / Duration
Folder name / file name
Q.MENU
Q.MENU options for Music List
1
PressQ. MENUtoaccessthePop-Upmenus.
2
PresstheNavigationbuttonstoscrolltoSet
Audio Play or Set AudioandPressOK.
Whenyouselectthe Set Audio Play.
1
PresstheNavigationbuttonstoshowtheSet
Audio Play.
2
PresstheNavigationbuttonstomake
appropriateadjustments.
WhenyouselecttheSet Audio.
1
PresstheNavigationbuttonsto
toshowthe
Sound Mode, Auto Volume, Clear Voice II,
Balance.
2
PresstheNavigationbuttonsto tomake
appropriateadjustments.(Seep.63)
When“Off”isselectedinRepeatmenu,
replaywillstoponcethelastfileinthelist
finishesplaying.But,when“ ”buttonis
pressedwhilethelastfineinthelistisin
themiddleofreplayand“Repeat”isin“Off”
position,thefirstfileinthelistwillbeplay.
NOTE
Choose Options.
Set Audio Play.
Set Audio.
ꕉ Previous
background
ENGLISH
49
ENTERTAINMENT
Viewing Movies
PlayvideofilesontheTV.YourTVdisplaysallof
thevideofilessavedinaUSBstoragedevice.
Movie(*.dat/*.mpg/*.mpeg/*.ts/*.trp
/*.tp/*.vob/*.mp4/*.mkv/*.avi/*.divx)
supportingfile.
Videoformat:DivX3.11,DivX4.12,DivX5.
x,DivX6,Xvid1.00,Xvid1.01,Xvid1.02,
Xvid1.03,Xvid1.10-beta-1/beta-2,Mpeg-1,
Mpeg-2,Mpeg-4,H.264/AVC
Audioformat:DolbyDigital,AAC,Mpeg,
MP3,LPCM,HE-AAC
Bitrate:within32kbpsto320kbps(MP3)
Subtitleformat:*.smi/*.srt/*.sub(Micro
DVD,SubViewer1.0/2.0)/*.ass/*.ssa/*.txt
(TMPlayer)/*.psb(PowerDivx).
Someuser-createdsubtitlesmaynotwork
properly.
Somespecialcharactersarenotsupported
insubtitles.
HTMLtagsarenotsupportedinsubtitles.
Subtitlesinlanguagesotherthanthe
supportedlanguagesarenotavailable.
Timeinformationinanexternalsubtitlefile
shouldbearrangedinascendingordertobe
played.
Thescreenmaysuffertemporary
interruptions(imagestoppage,faster
playback,etc.)whentheaudiolanguageis
changed.
Adamagedmoviefilemaynotbeplayed
correctly,orsomeplayerfunctionsmaynot
beusable.
Moviefilesproducedwithsomeencoders
maynotbeplayedcorrectly.
Ifthevideoandaudiostructureofrecorded
fileisnotinterleaved,eithervideooraudiois
outputted.
HDvideoswithamaximumof1920x1080
@25/30Por1280x720@50/60Pare
supported,dependingontheframe.
Videoswithresolutionshigherthan1920x
1080@25/30Por1280x720@50/60P
maynotworkproperlydependingonthe
frame.
Moviefilesotherthanthespecifiedtypesand
formatsmaynotworkproperly.
Max bit rate of playable movie file is 20
Mbps.
Wedonotguaranteesmoothplaybackof
profilesencodedlevel4.1orhigherinH.264
/AVC.
DTSAudiocodecisnotsupported.
Amoviefilemorethan30GBinfilesizeisnot
supportedforplayback.
ADivXmoviefileanditssubtitlefilemustbe
locatedinthesamefolder.
Avideofilenameanditssubtitlefilename
mustbeidenticalforittobedisplayed.
PlayingavideoviaaUSBconnectionthat
doesn’tsupporthighspeedmaynotwork
properly.
FilesencodedwithGMC(GlobalMotion
Compensation)maynotbeplayed.
WhenyouarewatchingthemoviebyMovie
Listfunction,youcanadjustanimageby
Energy Savingkeyontheremotecontrol.
Usersetupforeachimagemodedoesnot
operate.
Video Decoder
mpeg, vob: MPEG1,MPEG2
dat: MPEG1
ts,trp,tp: MPEG2,H.264/AVC
mp4: MPEG4SP,MPEG4ASP,Divx3.11,
Dvix4.12,Dvix5.x,Dvix6,Xvid1.00,Xvid
1.01,Xvid1.02,Xvid1.03,Xvid1.10–beta1,
Xvid1.10-beta2,H.264/AVC
avi: MPEG2,MPEG4SP,MPEG4ASP,
Divx3.11,Divx4,Divx5,Divx6,Xvid1.00,
Xvid1.01,Xvid1.02,Xvid1.03,Xvid1.10–
beta1,Xvid1.10–beta2,H.264/AVC
mkv: H.264/AVC,MPEG1,MPEG2,
MPEG4SP,MPEG4ASP
divx: MPEG2,MPEG4SP,MPEG4ASP,
Divx3.11,Divx4,Divx5,Divx6,Xvid1.00,
Xvid1.01,Xvid1.02,Xvid1.03,Xvid1.10–
beta1,Xvid1.10–beta2,H.264/AVC
Audio Codec
mpeg, vob:DolbyDigital,MPEG,MP3,
LPCM
dat:DolbyDigital,MPEG,MP3,LPCM
ts,trp,tp:DolbyDigital,AAC,MPEG
mp4:DolbyDigital,HE-AAC,AAC,MPEG,
MP3,LPCM
avi:DolbyDigital,HE-AAC,AAC,MPEG,
background
ENGLISH
50
ENTERTAINMENT
MP3,LPCM
mkv:DolbyDigital,HE-AAC,AAC,MPEG,
MP3,LPCM
divx:DolbyDigital,HE-AAC,AAC,MPEG,
MP3,LPCM
Max Resolution
1920 x 1080 @ 30p
1
PresstheNavigationbuttonstoscrolltoUSB
andpressOK.
2
PresstheNavigationbuttonstoscrolltoMovie
ListandpressOK.
3
SelectDrive1toaccesstheconnectedUSB
storagedevice.
4
PresstheNavigationbuttonstoscrolltoa
folderyouwantandpressOK.
5
PresstheNavigationbuttonstoscrolltoafile
youwantandpressOK.
Apop-upwindowwillappears.
6
Playvideobyusingthefollowingmenus.
Menu Description
Play or
Play
Marked
Playsamovieorplaystheselected
movie.
Drive:ViewsvideossavedinaUSB
storagedrive.
Repeat or
Repeat
Marked
RepeatsamovieorRepeatsthe
selectedmovie.
Mark All
or Unmark
All
Selectsallfilesorclearsallofyour
selections.
Delete or
Delete
marked
DeletesafileformattedontheFAT32
filesystemandsavedinaUSB
storagedevice.
Close Closesthepop-upmenu.
The imageunderthepreviewwindow
willappearifyouselectanon-supported
file.
NOTE
Movie List
Moive
SG 001.avi
Page 2/3
Title Duration
No Marked
Navigation Popup Menu Page Change Mark
Exit
640x480, 720KB
Up Folder
Up Folder
SG 001.avi
03:50
SG 002.avi
03:55
SG 003.avi
03:35
640x480, 720KB
Play
Repeat
Mark All
Delete
Close
7
Controlplaybackbyusingthefollowing
buttons.
Button Description
INFO
Viewstheinformationofthe
currentlyplayingvideo
Stopstheplayback
Playsavideo
Pausesorresumestheplayback
Scansbackwardinafile
Scansforwardinafile
< or > Skipstospecificpointsinafile
duringplayback.Thetimeofa
specificpointwillappearonthe
statusbar.Insomefiles,this
functionmaynotworkproperly.
or
Playsvideosinslowmotion
ENERGY
SAVING
PresstheENERGY SAVING
buttonrepeatedlytoincreasethe
brightnessofyourscreen.
Q.MENU options for Movie List
1
PressQ. MENUtoaccessthePop-Upmenus.
2
PresstheNavigationbuttonandOKtoscroll
toSet Video Play, Set Video or Set Audio.
Choose Options.
Set Video Play.
Set Video.
Set Audio.
ꕉ Previous
background
ENGLISH
51
ENTERTAINMENT
OnlythefilessavedinASCIICODEis
supportedfortheexternalsubtitlesofthe
movie.
Only500alphabetsand500numbersare
supportedforeachlineofthesubtitle.
Only10,000ofsyncblockscanbe
supportedwithinthesubtitlefile.
NOTE
WhenyouselecttheSet Video.
1
PresstheNavigationbutton tomake
appropriateadjustments.(Seep.61)
WhenyouselecttheSet Audio,
1
PresstheNavigationbutton toshowthe
Sound Mode, Auto Volume, Clear Voice II,
Balance.
2
PresstheNavigationbutton tomake
appropriateadjustments.(Seep.63)
Usingtheremotecontrol.
Button Description
Whenplaying,
repeatedly,presstheREW( )button
tospeedup (x2) (x4) (x8)
(x16) (x32).
repeatedly,presstheFF( )button
tospeedup (x2) (x4) (x8)
(x16) (x32).
Pressingthesebuttonsrepeatedly
increasesthefastforward/reverse
speed.
Pause( ) Duringplayback,pressthePause( )
button.
Stillscreenisdisplayed.
Ifnobuttonsarepressedonthe
remotecontrolfor10minutesafter
pausing,theTVreturnstothe
playbackstate.
PressthePause( )buttonand
thenusetheFF( )buttonforslow
motion.
< or > Whenusingthe< or>buttonduring
playbackacursorindicatingthe
positioncanbeviewedonthescreen.
Play( ) PressthePlay( )buttontoreturnto
normalplayback.
ENERGY
SAVING
PresstheENERGY SAVINGbutton
repeatedlytoincreasethebrightness
ofyourscreen.(Seep.60)
When you select the Set Video Play.
Menu Description
Size
Selectsyourdesiredpictureformatduring
movieplay
Audio
Language
or Subtitle
Language
ChangestheLanguageGroupofthe
audio/subtitleduringmovieplay.
Sync Adjuststhetimesynchronisationofthe
subtitlefrom-10secsto+10secsby
stepsof0.5secsduring
movieplay.
Position Changesthepositionofthesubtitleeither
upordownduringmovieplay.
Size SelectsyourdesiredSubtitlesizeduring
movieplay.
1
PresstheNavigationbutton toshowthe
Picture Size, Audio LanguageorSubtitle
Language.
2
PresstheNavigationbutton tomake
appropriateadjustments.
Subtitle
Language
Support Language
Latin1 English,Spanish,French,German,
Italian,Swedish,Finnish,Dutch,
Portuguese,Danish,Romanian,
Norwegian,Albanian,Gaelic,Welsh,
Irish,Catalan,Valencian
Latin2 Bosnian,Polish,Croatian,Czech,
Slovak,Slovenian,Serbian,Hungarian
Latin4 Estonian,Latvian,Lithuanian
Cyrillic Bulgarian,Macedonian,Russian,
Ukrainian,Kazakh
Greek Greek
Turkish Turkish
background
ENGLISH
52
ENTERTAINMENT
DivX® VOD Guide
DivX(R) VOD Registration
InordertoplaypurchasedorrentedDivX®VOD
contents,youshouldregisteryourdevicewith10
digitDivXregistrationcodefromyourdeviceat
www.divx.com/vod.
1
PressMENUtoaccesstheUSBmenus.
2
PresstheNavigationbuttontoscrolltoDivX
Reg. CodeandpressOK.
3
ViewtheregistrationcodeofyourTV.
Whileyouarecheckingtheregistrationcode,
somebuttonsmaynotwork.
IfyouusetheDivXregistrationcodeof
anotherdevice,youcannotplaytherented
orpurchasedDivXfile.Makesuretousethe
DivXregistrationcodeassignedtoyourTV.
Thevideooraudiofilesthatarenot
convertedbythestandardDivXcodecmay
becorruptedornotbeplayed.
TheDivXVODcodeallowsyoutoactivate
upto6devicesunderoneaccount.
Oncethederegistrationisexecuted,youmust
registeryourdeviceagaintoseeDivX®VOD
contents.
NOTE
NOTE
DivX® VOD Deregistration
Youshouldderegisteryourdevicewith8digitDivX
deregistrationcodefromyourdeviceatwww.divx.
com/vod.
1
PressMENUtoaccesstheUSBmenus.
2
PresstheNavigationbuttontoscrollto
DeactivationandpressOK.
3
SelectYestoconfirm.
4
SelectClose.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
DivX(R) Video On Demand
Your registration Code is: xxxxxxxxxx
To learn more visit www.divx.com/vod.
DivX(R) Video On Demand
Do you want to deactivate your device?
DivX(R) Video On Demand
This device is deactivated.
Your deactivation code is: xxxxxxxx
To learn more visit www.divx.com/vod.
Close
Close
NoYes
background
ENGLISH
53
3D IMAGING
3D IMAGING
3D Technology
ThisTVcandisplayin3Dvia3DbroadcastingorwhentheTVisconnectedtoacompatibledevice,such
asaBlu-ray3DPlayer.Theviewermustwearcompatible3Dglassesinordertoseetheseimagesin3D
format.
AfterpoweringontheTV,afewsecondsmaybeneededforyourTVtocalibrate.
WhenwatchingdigitalTVin3Dimagingmode,TVoutsignalscannotbeoutputthroughtheSCART
cable.
Ifyousetthe3DmodetoOnwhileascheduledrecordingisperformedondigitalTV,TVoutsignals
cannotbeoutputthroughtheSCARTcable,andtherecordingcannotbeperformed.
If3DTVbroadcaststandardchangesinthefutureanditisnotsupportedbythisTVset,youmay
needaseparatedevice,suchasaset-topbox.
NOTE
Ifyouview3Dimagesfromtoocloseadistance,youreyesightmaydeteriorate.
Ifyouviewimagesin3Dforalongperiodoftime,youmayfeeldizzyorexperienceblurredvision.
Ifyouarepregnant,elderly,haveheartproblems,experienceseverenauseaorifyouareunderthe
influenceofalcohol,werecommendthatyoudonotview3Dimages.
Thisisbecausethe3Dimagescancausedisorientationandconfusion.
Putfragileorbreakableobjectsawaywhenviewing3Dimages.
Suchobjectsmaybreak,orcausepersonalinjurieswhenyouarestartledbytherealistic3Dimages.
Parentsshouldpreventchildrenwhoare5yearsoryoungerfromwatching3Dimagesbecause
viewing3Dimagescanbeharmfultovisiondevelopment.
Warningaboutphotosensitivityseizures
Someusersmayhaveaseizureorotherabnormalreactionswhentheyareexposedtoaflashinglight
oraparticularpatterninavideogameorfilm.Ifanyoneinyourfamilyhasahistoryofepilepsyorhas
everexperiencedanykindofseizure,pleaseconsultyourdoctorbeforeviewing3Dimages.Ifyou
exhibitanyofthesymptomslistedbelowwhenviewing3Dimages,stopviewingimmediatelyandhave
abreak.
»
Dizziness,blurredvisionorfacialtics,involuntarymovements,twitching,blackouts,confusionand
disorientation.Pleaseconsultyourdoctorifsuchsymptomspersist.
Topreventaphotosensitivityseizure,pleasetakethefollowingprecautions.
»
Havea5-to15-minutebreakeveryhour.
»
Ifyourleftandrighteyesightissignificantlydifferent,correctthesightdifferencefirst.
»
Youshouldbeabletoseeallofthescreenateyelevel.
»
Ifyouexperienceheadaches,fatigueordizziness,stopviewingandhavearest.
»
Donotview3Dimageswhenyouaretiredorill.
Precautions to take when viewing 3D images
WARNING
background
ENGLISH
54
3D IMAGING
When using 3D Glasses
Donotusethe3Dglassestoreplaceyourcorrectiveglasses,sunglassesorprotectivegoggles.
Donotstorethe3Dglassesinhotorcoldlocations.
Donotdropobjectsontothe3Dglasses.Donotdroporbendtheglasses.
Sincethelensesofthe3Dglassesareeasilyscratched,makesuretocleanonlywithasoftcloth.
Shakeoffanydustbeforeusingthecloth
Donotscratchthesurfaceofthelens(Polarizedfilm)of3Dglasseswithasharptoolorwipethelens
withchemicals.
Thelensofthe3Dglassesisdifferentfromthoseofgeneralglasses,andisverythin.Thereforebe
carefulwiththeglassesasthelenscanbepoppedouteasily.
Becarefuloftheedgesoftheglassframewhenputtingonthe3Dglasses.
CAUTION
CAUTION
Parents/guardiansshouldTVchildren’sviewingof3Dimagesbecausetheymaynotbeusedtothe
3Dviewingexperienceandlackknowledgeonhowtohandlepotentialrisks.
background
ENGLISH
55
3D IMAGING
3D Imaging Viewing Range
TVsize,viewingangle&othercircumstancesmaychangetheviewingdistanceandtheangleofview.
Mode Whenviewing3Dimages
Size(Inch) 686mm
Optimal viewing
distance (L)
70cm
Up/Down Optimal
viewing angle (D)
14°
No. Description
1
AdjustyourdistancefromtheTVtoallowyouto
viewimagesfromtheoptimaldistance(L).
2
AdjusttheTVandyourposturetoallowyouto
viewimagesattheoptimalviewingangle(D).
3
Placeyourhandsgentlyonthekeyboard,
keepingyourarmsbentattheelbowsand
horizontallyoutright.
4
AdjustthelocationoftheTVtoavoiditreflecting
light.
1
3
4
2
background
ENGLISH
56
3D IMAGING
Viewing 3D Imaging
1
Playthevideoproducedin3D.
2
Press3D.
3
Wearthe3Dglasses.
4
PresstheNavigationbuttonstoscrolltheOKandpressOK.
5
PresstheNavigationbuttonstoscrolltheshapeandpressOK.
Mode Description
2D 3D Changedfrom2Dimagingto3Dimaging.
2D 3D
Side by Side
Top & Bottom
Checker Board
Frame Sequential
6
 Press3Dbuttontoto2D Offor3D Off.
Mode Description
3D 2D Displaysimagesin2Dwithoutany3Deffects.
2D 3D Displaysimagesin3D.
3D Off Displaysimagesinoriginalformat.
Cancel Closethepop-upwindow.
background
ENGLISH
57
3D IMAGING
3D Mode Setting Option
1
Press3D SETTINGtoaccessthePop-Upmenus.
2
 PresstheNavigationbuttonstoscrolltooneofthe
followingoptionsandpressOK
Somemenusmaynotworkwhileviewing3Dimaging.
The3Dimagingisdisabledautomaticallywhenswitchinginputsource.
Thescreenmaynotbedisplayedproperlyifyouview2Dimagesin3Dimagingmode.
3Deffectcanbeseenwhen3DModeisselectedappropriatelyforthe3Dinputsignalsuppliedtothe
TV.
Whenswitchingchannels,theconversionfrom2Dto3Dismaintained.Ifyoustayonachannelwith
noimagesfor3seconds,itchangesbackto2D.
WhenviewingmultiplephotosstoredontheUSBdevice,theconversionfrom2Dto3Dismaintained.
WhenviewingmultiplevideofilesstoredontheUSBdevice,the3Dmodeisalsomaintained.
Whenwatchinga3DmoviefromtheUSBdevice,PictureModeisnotsupported.
CAUTION
TheImageViewModeoptionisdisabledwhen2Dimagesareconvertedinto3D.
The3DDepthoptionisenabledwhen2Dimagesareconvertedinto3D.
YoucannotentertheMainmenuwhilewatching3Dfiles.
NOTE
3D Mode Setting
Left/Right
Vivid
◄
◄
◄
◄
Close
3D Picture Correction
3D Depth 15
3D Viewpoint 0
Picture Mode
TheavailableProgrammesettingsaredescribedinthefollowing:
Option Description
3D Picture
Correction
SelectLeft/RightorRight/Left.
Selectthescreenwith3Dvideowithbettervisibility.
3D Depth Adjuststhestereoscopiceffectofthe3Dimageconvertedfroma2Dimage.
3D Viewpoint Movesthe3Dimagetothefrontandbacktoadjustthe3Dperspectiveview.
Picture Mode SelectsoneofthepresetimageorcustomizesoptionsineachmodeforthebestTVscreen
performance.Youarealsoabletocustomizeadvancedoptionsofeachmode.
TheavailablepresetpicturemodesvarydependingontheTV.
Mode
Vivid Adjuststhevideoimagefortheretailenvironmentbyenhancingthecontrast,
brightness,Colour,andsharpness.
Standard Adjuststheimageforthenormalenvironment.
Cinema Optimizesthevideoimageforacinematiclooktoenjoymoviesasifyouareina
movietheater.
Sport Optimizesthevideoimageforhighanddynamicactionsbyemphasizingprimary
Colourssuchaswhite,grass,orskyblue.
Game OptimizesthevideoimageforafastgamingscreensuchasPCsorgames.
background
ENGLISH
58
CUSTOMIZING SETTINGS
CUSTOMIZING SETTINGS
Accessing main menus
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltooneofthefollowingmenusand
pressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroptionyouwant
andpressOK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
SETUP
OPTION
LOCK
AUDIO
INPUT
TIME
USB
AUDIO(Seep.63)
Adjuststhesoundquality,
effect,orvolumelevel
PICTURE (Seep.60)
Adjuststheimagesize,
quality,oreffect
TIME(Seep.66)
Setsthetime,dateor
Timerfeature
SETUP(Seep.59)
Setsupandedit
programmes
USB(Seep.69)
Usingintegratedmedia
features
LOCK(Seep.68)
Locksorunlocks
channelsandprograms
INPUT(Seep.69)
Viewstheinputsources
withtheirlabels
OPTION (Seep.67)
Customizesthegeneral
settings
ImageshownmaydifferfromyouTV.
YourTV'sOSD(OnScreenDisplay)maydifferslightlyfromthatshowninthismanual.
Theavailablemenusandoptionsmaydifferfromtheinputsourceorproductmodelthatyouare
using.
NOTE
background
ENGLISH
59
CUSTOMIZING SETTINGS
Customizing settings
SETUP settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoSETUPandpressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroption
youwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
TheavailableProgrammesettingsaredescribedinthefollowing:
Setting Description
Auto Tuning Tunesandstoresallavailableprogrammesthroughantennasorcableinputs(Seep.18).
Manual Tuning Tunesandstorestheprogrammesyouwantmanually(Seep.21to22).
Programme Edit Addsordeletespregrammesontheprogramme(Seep.23).
Software Update ThisautomaticallyupdatesyourTV'ssoftware.(Seep.25).
Diagnostics Thisshowsyouthemanufacturer,modelortypenumber,serialnumberandsoftwareinformation.
(Seep.26).
CI information Enablesyoutowatchsomeencryptedservices(payservices)(Seep.26).
Cable DTV Setting
(In Cable Mode
Only)
Youcanruntheserviceoperatorortheprogrammeautoupdate.(OnlyincountrieswhereDBV-C
issupported).(Seep.23).
SETUP
Move OK
Auto Tuning
Manual Tuning
Programme Edit
Software Update : On
Diagnostics
CI Information
Cable DTV Setting
ImageshownmaydifferfromyourTV.
background
ENGLISH
60
CUSTOMIZING SETTINGS
PICTURE settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoPICTUREand
pressOK.
3
PresstheNavigationbuttonstoscrolltothesettingor
optionyouwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK. 
Theavailablepicturesettingsaredescribedinthefollowing:
Setting Description
Aspect Ratio Changestheimagesizetoviewimagesatitsoptimalsize.(Seep.28)
Picture Wizard Adjuststheimagequalityandcalibratesthescreenbyfollowingtheon-screeninstructions.
ThecustomizedoptionswillbesavedasExpert1inthepicturemodes.
Set 3D Video
(Only 3D
model)
Setsthe3Dimagingoption.(Seep.53)
Energy Saving Setstoautomaticallyadjustthescreenbrightnesscorrespondingtothesurroundings.
Option
Off Thebacklightisoff.
Minimum/
Medium/
Maximum
Selectsthebrightnesslevelofthebacklight.
Screenoff Thescreenturnsoffin3seconds.
Colour
Tint
PictureWizard
Dynamic
Contrast
ColourGain
BlackLevel
Backlight
Colour
Temperature
WhiteLevel
Complete
Horizontal/
Vertical
Sharpness
IfyouusePicture wizard,theEnergysavingfeaturewillturnoffautomatically.
NOTE
Aspect Ratio : 16:9
Picture Wizard
Set 3D Video
ꕊ Energy Saving : Off
Picture Mode : Vivid
ꔈBacklight 100
ꔈContrast 100
ꔈBrightness 70
ꔈSharpness 50
ꔈColour 45
ꔈTint 0
ꔈColour Temperature 0
ꔈAdvanced Control
ꔈPicture Reset
Screen
Move OK
R
G
W
C
ImageshownmaydifferfromyourTV.
background
ENGLISH
61
CUSTOMIZING SETTINGS
Setting Description
Picture Mode SelectsoneofthepresetimageorcustomizesoptionsineachmodeforthebestTVscreen
performance.Youarealsoabletocustomizeadvancedoptionsofeachmode.
TheavailablepresetpicturemodesvarydependingontheTV.
Mode
Vivid Adjuststhevideoimagefortheretailenvironmentbyenhancingthecontrast,
brightness,Colour,andsharpness.
Standard Adjuststheimageforthenormalenvironment.
Cinema Optimizesthevideoimageforacinematiclooktoenjoymoviesasifyouareina
movietheater.
Sport Optimizesthevideoimageforhighanddynamicactionsbyemphasizingprimary
Colourssuchaswhite,grass,orskyblue.
Game OptimizesthevideoimageforafastgamingscreensuchasPCsorgames.
Expert1/2 Adjuststhedetailedvideoimagesettingsforvideoexpertsaswellasgeneral
viewers.
Screen
(In RGB-PC
Mode Only)
CustomizesthePCdisplayoptionsinRGBmode.
Option
Resolution Selectsaproperresolution.See“CustomizingPCdisplayoptions”,p.41
AutoConfigure Setstoadjustthescreenposition,clock,andphaseautomatically.
Thedisplayedimagemaybeunstableforafewsecondswhiletheconfigurationis
inprogress.
Position/Size/
Phase
Adjuststheoptionswhenthepictureisnotclear,especiallywhencharactersare
shaky,aftertheautoconfiguration.
Reset Restorestheoptionstothedefaultsetting.
Basic image options
Setting Description
Backlight AdjuststhebrightnessofthescreenbycontrollingtheLCDbacklight.Ifyoudecreasethe
brightnesslevel,thescreenbecomesdarkerandthepowerconsumptionwillbereduced
withoutanyvideosignalloss.
Contrast Increasesordecreasesthegradientofthevideosignal.YoumayuseContrastwhenthe
brightpartofthepictureissaturated.
Brightness Adjuststhebaselevelofthesignalinthepicture.YoumayuseBrightnesswhenthedark
partofthepictureissaturated.
Sharpness Adjuststhelevelofcrispnessintheedgesbetweenthelightanddarkareasofthepicture.
Thelowerthelevel,thesoftertheimage.
Colour AdjustsintensityofallColours.
Tint Adjuststhebalancebetweenredandgreenlevels.
Colour Temperature Settowarmtoenhancehottercolourssuchasred,orsettocooltomakepicturebluish.
Advanced Control Customizestheadvancedoptions.
Reset Restorestheoptionstothedefaultsetting.
NOTE
YoucannotadjustColourandTintintheRGB-PC/HDMI-PCmode.
WhentheExpert1/2isselected,youcanselectBacklight, Contrast, Brightness, H Sharpness,
V Sharpness, ColourorTint.
background
ENGLISH
62
CUSTOMIZING SETTINGS
Advanced image options
Setting Description
Dynamic Contrast
(Off/Low/High)
Adjuststhecontrasttokeepitatthebestlevelaccordingtothebrightnessofthescreen.The
pictureisimprovedbymakingbrightpartsbrighteranddarkpartsdarker.
Dynamic Colour
(Off/Low/High )
Adjustsscreencolourssothattheylooklivelier,richerandclearer.Thisfeatureenhances
hue,saturationandluminancesothatred,blue,greenandwhitelookmorevivid.
Noise Reduction
(Off/Low/Medium/
High)
Reducesscreennoisewithoutcompromisingvideoquality.
Gamma
(Low/Medium/High)
Youcanadjustbrightnessofdarkareaandmiddlegraylevelareaofthepicture.
»
Low:Makedarkandmiddlegraylevelareaofthepicturebrighter.
»
Medium:Expressoriginalpicturelevels.
»
High:Makedarkandmiddlegraylevelareaofthepicturedarker.
Black Level
(Low/High/Auto)
»
Low:Thepictureofthescreengetsdarker.
»
High:Thepictureofthescreengetsbrighter.
»
Auto:RealizingtheblacklevelofthescreenandsetittoHighorLowautomatically.
Setblacklevelofthescreentoproperlevel.
Thisfunctionenablestoselect'Low'or'High'inthefollowingmode:AV(NTSC-M),HDMIor
Component.Otherwise,'Blacklevel'issetto'Auto'.
Film Mode
(On/Off)
Youcanwatchacinema-likevideobyeliminatingjuddereffect.
Usethisfunctionwhenyouwatchmovies.
Colour Standard
(SD/HD)
ConvertsthecolourofadifferentvideotoHDcolour.ThisfunctionissetforSDvideo(BT-601)
andHDvideo(BT-709)colourformat.
Expert Pattern
(Off/Expert 1/Expert 2)
Thisisthepatternnecessaryforexpertadjustment.
Thisfunctionisenabledin"PictureMode-Expert"whenyouwatchDTV.
Colour Filter
(Off/Red/Green/Blue)
Thisisthefunctiontofilterthespecificcoloursofthevideo.
YoucanusetheRGBfiltertosetcoloursaturationandhueaccurately.
Colour Temperature
(Medium/Warm/Cool)
Thisisthefunctiontoadjusttheoverallcolourofthescreentothefeelingyouwant.
A
»
Method:2Points
»
Pattern:Inner,Outer
»
Red/Green/BlueContrast,Red/Green/BlueBrightness:
»
Theadjustmentrangeis-50to+50.
B
»
Method:10pointIRE
»
Pattern:Inner/Outer
»
IRE(InstituteofRadioEngineers)istheunittodisplaythesizeofthevideosignaland
canbesetamong10,20,30to100.YoucanadjustRed,GreenorBlueaccordingto
eachsetting.
»
Red/Green/Blue:Theadjustmentrangeis-50to+50.
Colour Management
System
Asthetoolusedbytheexpertstomakeadjustmentsbyusingthetestpatterns,thisdoesnot
affectothercoloursbutcanbeusedtoselectivelyadjustthe6colourareas(Red/Green/Blue/
Cyan/Magenta/Yellow).Colourdifferencemaynotbedistinctiveevenwhenyoumakethe
adjustmentsforthegeneralvideo.
AdjustsRed/Green/Blue/Yellow/Cyan/Magenta.
»
Red/Green/Blue/Yellow/Cyan/MagentaColour:Theadjustmentrangeis-30to+30.
»
Red/Green/Blue/Yellow/Cyan/MagentaTint:Theadjustmentrangeis-30to+30.
ThisfeatureisdisableinRGB-PCandHDMI(PC)mode.
background
ENGLISH
63
CUSTOMIZING SETTINGS
AUDIO settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoAUDIOandpress
OK.
3
PresstheNavigationbuttonstoscrolltothesettingor
optionyouwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Theavailableaudiooptionsaredescribedinthefollowing:
Setting Description
Auto Volume ActivatestheAutoVolumefeaturetokeepthevolumelevelconsistentwheneveryouchange
programmes.Thevolumelevelmaynotbeconsistentduetodifferentsignalconditionsof
broadcastingstations.
Clear Voice ll Bydifferentiatingthehumansoundrangefromothers,ithelpsuserslistentohumanvoicesbetter.
Balance Adjustsbalancebetweentheleftandrightspeakersaccordingtoyourroomenvironment.
Sound Mode Selectsoneofthepresetsoundmodesorcustomizeeachoptionineachmode.
Mode
Standard Selectwhenyouwantstandard-qualitysound.
Music Selectwhenyoulistentomusic.
Cinema Selectwhenyouwatchmovies.
Sport Selectwhenyouwatchsportsevents.
Game Selectwhenyouplaygames.
NOTE
Ifsoundqualityorvolumeisnotatthelevelyouwant,itisrecommendedtouseaseparate
hometheatersystemoramplifiertocopewithdifferentuserenvironments.
Option
SurroundX Providesanenvelopingsurroundsoundwithcleardialogandbassusing
justtwospeakers.SurroundXisapatentedSurroundtechnologythat
solvestheproblemofplaying5.1multichannelcontentsovertwospeakers.
Treble Controlsthedominantsoundsintheoutput.Whenyouturnupthetreble,it
willincreasetheoutputtothehigherfrequencyrange.
Bass Controlsthesoftersoundsintheoutput.Whenyouturnupthebass,itwill
increasetheoutputtothelowerfrequencyrange.
Reset Resetsthesoundmodetothedefaultsetting.
AUDIO
Auto Volume : Off
Clear Voice ll : Off 3
Balance 0
Sound Mode : Music
ꔈSurround X : Off
ꔈTreble 50
ꔈBass 50
ꔈReset
Digital Audio Out : PCM
TV Speaker : On
DTV Audio Setting : Auto
Move OK
L
R
ImageshownmaydifferfromyourTV.
background
ENGLISH
64
CUSTOMIZING SETTINGS
Setting Description
Digital Audio Out ThisfunctionallowsyoutoselectyourpreferredDigitalAudioOutput.
WhenDolbyDigitalisavailable,selectingAutointheDigitalAudioOutmenuwillsetSPDIF(Sony
PhilipsDigitalInterFace)outputtoDolbyDigital.
IfAutoisselectedinthedigitalaudiooutmenuwhenDolbyDigitalisnotavailable,SPDIFoutput
willbePCM(Pulse-codemodulation).
EvenifbothDolbyDigitalandAudiolanguagehavebeensetinachannelwhichbroadcastDolby
DigitalAudio,onlyDolbyDigitalwillbeplayed.
Mode Audio Input Digital Audio output
Auto(SpeakerOn) MPEG
DolbyDigital
DolbyDigitalPlus
HE-AAC
PCM
DolbyDigital
DolbyDigital
PCM
Auto(SpeakerOff) MPEG
DolbyDigital
DolbyDigitalPlus
HE-AAC
PCM
DolbyDigital
DolbyDigital
DolbyDigital
PCM PCM PCM
TV Speaker TurnsontheinternalspeakeroftheTVwhenusinganexternalHi-FiorSRSsystem.Youcanuse
theTVspeakerasanaudiooutputdeviceevenifthereisnovideoinput.
DTV Audio Setting
(In Digital Mode
Only)
Whendifferentaudiotypesexistinaninputsignal,thisfunctionallowsyoutoselecttheaudiotype
youwant.
NOTE
Auto:AutomaticallyoutputsintheorderHE-AAC DolbyDigital MPEG.
HE-AAC,DolbyDigital,MPEG:Allowsuserstoselecttheaudiotypetheywant.
»
IfMPEGisselected,MPEGisalwaysoutputted.
»
IfMPEGisnotsupported,HE-AACandDolbyDigitalareselectedinthatorder.
background
ENGLISH
65
CUSTOMIZING SETTINGS
Stereo/Dual Reception (In Analogue Mode Only)
Whenaprogrammeisselected,thesoundinformationforthestationappearswiththeprogrammenumber
andstationname.
1
PressQ. MENUandpresstheNavigationtoaccesstheAUDIOandpressOK.
2
PresstheNavigationbuttontoscrolltosoundoutput andpressOK.
Broadcast On Screen Display
Mono
Stereo
Dual
MONO
STEREO
DUALI,DUALII,DUALI+II
Mono sound selection
Ifthestereosignalisweakinstereoreception,youcanswitchtomono.Inmonoreception,theclarityof
soundisimproved.
Language selection for dual language broadcast
aprogrammecanbereceivedintwolanguages(duallanguage),youcanswitchtoDUALI,DUALIIor
DUALI+II.
DUAL I Sendstheprimarybroadcastlanguagetotheloudspeakers.
DUAL I I Sendsthesecondarybroadcastlanguagetotheloudspeakers.
DUAL I+I I Sendsaseparatelanguagetoeachloudspeaker.
Stereo/Dual Reception (In Analogue Mode Only)
IftheTVisequippedwithareceiverforNICAMreception,highqualityNICAM(NearInstantaneous
CompandingAudioMultiplex)digitalsoundcanbereceived.
Soundoutputcanbeselectedaccordingtothetypeofbroadcastreceived.
1
WhenNICAMmonoisreceived,youcanselectNICAMMONOorMONO.
2
WhenNICAMstereoisreceived,youcanselectNICAMSTEREOorMONO.
Ifthestereosignalisweak,switchtoMONO.
3
WhenNICAMdualisreceived,youcanselectNICAMDUALI, NICAM DUAL II orNICAM DUAL I+IIor
MONO.
Speaker Sound Output Selection
InAV,Component,RGBandHDMImode,youcanselectoutputsoundfortheleftandrightloudspeakers.
Selectthesoundoutput.
L+R: AudiosignalfromaudioLinputissenttotheleftloudspeakerandaudiosignalfromaudioRinputis
senttotherightloudspeaker.
L+L:AudiosignalfromaudioLinputissenttoleftandrightloudspeakers.
R+R: AudiosignalfromaudioRinputissenttoleftandrightloudspeakers.
background
ENGLISH
66
CUSTOMIZING SETTINGS
TIME settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoTIMEandpressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroptionyou
wantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailabletimesettingsaredescribedinthefollowing:
Setting Description
Clock Setsthetime,date,timezone,anddaylight-savingtimefeature.Thetimewillbesetautomatically
accordingtoadigitalchannelsignalwhichincludestimeinformationprovidedbythebroadcasting
station.Ifnot,setthetimeanddatemanually.
NOTE
Ifyouturnthepoweroffbydisconnectingthepowercord,thecurrenttimesettingwillbe
reset.
Off Time/On Time SetsthetimetoturnonorofftheTVautomatically.Tousethisfunction,youshouldsetthecurrent
timeanddateintheClockmenu.
NOTE
Ifyoudonotpressanybuttonwithin2hoursaftertheTVturnsonbytheOnTime
feature,theTVenterstheStandbymodeautomatically.
IfyousettheOnTimefeatureandturntheTVoffbypressingMainpowerswitch,the
OnTimefeaturewillnotwork.ToactivatetheOnTimefeature,theTVsetmustbein
Standbymode.
IfyousetbothOffTimeandOnTimefeaturestothesametime,theOffTimefunction
overridestheOnTimefeature,whentheTVison.
Sleep Timer SetsthelengthoftimeuntiltheTVtoturnsoff.WhenyouturntheTVoffandturnitonagain,the
SleepTimerwillbesettooff.
Automatic
Standby
IfyoudonotpressanybuttonwhenAutomaticStandbyfunctionison,theTVautomatically
switchestothestandbymode.
NOTE
ThisfunctiondoesnotworkonStore DemomodeorwhileSoftware update.
ThisfunctiondoesnotworkonRGB-PC/HDMI-PCmode.
TIME
Clock
Off Time : Off
On Time : Off
Sleep Timer : Off
Automatic Standby : 4 hour.
Move OK
ImageshownmaydifferfromyourTV.
background
ENGLISH
67
CUSTOMIZING SETTINGS
Setting Description
Language Selectsalanguageforthedisplayoraudio(OnlyDTV)(Seep.32).
Disabled
Assistance
(In Digital Mode)
Audiocommentaryorsubtitlesareprovidedforthosewhoarehardofhearingorvisuallyimpaired
Option
HardofHearing Thisfunctionifforthehearingimpaired.
Ifitissettoon,thesubtitleisdisplayedbydefault.
Audio
Description
Thisfunctionisfortheblind,andprovidesexplanatoryaudiodescribing
thecurrentsituationinaTVprogrammeinadditiontothebasicaudio.
WhenAudioDescriptionOnisselected,basicaudioandAudioDescription
areprovidedonlyforthoseprogrammesthathaveAudioDescriptionincluded.
Volume ChangestheAudioDescriptionvolume
Data Service
(only in Ireland.)
ThisfunctionallowuserstochoosebetweenMHEG(DigitalTeletext)andTeletextifbothexistat
thesametime.(Seep.75to77)
Country Selectsadesiredcountry.(Seep.31)
Input Label Selectsalabelforaninputsourcetoidentifyadeviceconnectedtoeachinputsource.
NOTE
IfyouwanttouseHDMI-PCmode,youmustsettheinputlabeltoPCmode.
Set ID AddsanIDtotheconnecteddevices.(Seep.89)
Power Indicator SetstoturnonoroffthePowerindicatorontheTV.
Demo Mode DisplaytheslideshowtoexplainthevariouslogoofthisTV.
Mode Setting CustomizestheTVsettingstosuityourpreference.Theinitialsetupscreenwillappearwhenyou
turnontheTVforthefirsttime.
Setting
ModeSetting SelectsHome Use modeforthehomeenvironment.
Selects Store Demomodefortheretailenvironment.
Factory Reset Thisfunctioninitializesallsettings.
NOTE
InLock System "On",ifyouforgetyourpassword,press'0', '3', '2', '5'ontheremote
controlhandset.
OPTION settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoOPTIONandpressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroptionyou
wantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableoptionsettingsaredescribedinthefollowing:
OPTION
Menu Language : English
Audio Language : English
Subtitle Language : English
Disabled Assistance
Data Service : MHEG
Country : UK
Input Label
Set ID : 1
Power Indacator : On
Demo Mode : Off
Mode Setting : Home Use
Factory Reset
Move OK
ImageshownmaydifferfromyourTV.
background
ENGLISH
68
CUSTOMIZING SETTINGS
LOCK settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoLOCKandpress
OK.
3
PresstheNavigationbuttonstoscrolltothesettingor
optionyouwantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
Theavailablelocksettingsaredescribedinthefollowing:
Setting Description
Set Password Changesthe4-digitpassword.Thedefaultpasswordis‘0’, ‘0’, ‘0’, ‘0’.
WhenFranceisselectedforCountry,thedefaultpasswordisnot ‘0’, ‘0’, ‘0’, ‘0’ but‘1’,’2’,’3’,’4’.
NOTE
Ifyouforgetthepassword,press'0' '3' '2' '5'andsetthenewpassword.
Lock System Activatesordeactivatesthelocksystem
Rating
Block
Programme
Blocksanyprogrammesthatyoudonotwanttowatchorthatyoudonotwant
yourchildrentowatch.
ThisfunctionisavailableinLock System “On”.
Enterapasswordtowatchablockedprogramme.
Parental
Guidance
Thisfunctionoperatesaccordingtoinformationfromthebroadcastingstation.
Thereforeifthesignalhasincorrectinformation,thisfunctiondoesnotoperate.
(Seep.34)
InputBlock Blockstheinputsources
Key Lock TheTVcanbesetsothattheremotecontrolisrequiredtocontrolit.Thisfeaturecanbeusedto
preventunauthorizedviewing.
NOTE
InKey Lock ‘On’,iftheTVisturnedoff,presstheINPUT, P buttonontheTVor
POWER, INPUT, P , TV/PCorNUMBERbuttonsontheremotecontrolthentheset
willbeturnedon.
WiththeKeyLockOn,thedisplay‘ Key Lock On’appearsonthescreenifany
buttononthefrontpanelispressedwhileviewingtheTV.
LOCK
Set Password
Lock System : Off
ꔈBlock Programme
ꔈParental Guidance
ꔈInput Block
key Lock : Off
MOVE OK
ImageshownmaydifferfromyourTV.
background
ENGLISH
69
CUSTOMIZING SETTINGS
INPUT settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoINPUTandpressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroptionyou
wantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableinputsettingsaredescribedinthefollowing:
Setting Description
Antenna SelectitwhenwatchingtheDTV/TV.(Seep.16).
AV1/2 SelectitwhenwatchingtheVCRorexternalequipment.(Seep.73).
Component SelectitwhenusingtheDVDortheDigitalset-topboxdependsonconnector.(Seep.72).
RGB SelectitwhenusingPCdependsonconnector.(Seep.39).
HDMI1/2 SelectitwhenusingDVD,PCorDigitalset-topboxdependonconnector.(Seep.38or72).
INPUT
Antenna
AV1
AV2
Component
RGB
HDMI 1
HDMI 2
Move OK
USB settings
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrolltoUSBandpressOK.
3
PresstheNavigationbuttonstoscrolltothesettingoroptionyou
wantandpressOK.
-Toreturntothepreviouslevel,pressBACK.
4
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,pressBACK.
Theavailableusbsettingsaredescribedinthefollowing:
Setting Description
Photo List YoucanviewphotofilesonUSBstoragedevice.(Seep.46)
Music List YoucanplaymusicfilesonUSBstoragedevice.(Seep.47)
Movie List YoucanplaymoviefilesonaUSBstoragedevice.(Seep.49)
Divx Reg. Code CheckandregistertheDivXregistrationcodeofyourTVsothatyoucanrentorpurchasethe
latestmoviesat
www.divx.com/vod
.(Seep.52).
Deactivation Thepurposeofdeactivationistoallowdeactivationofdevicesforuserswhohaveactivatedallthe
availabledevicesthroughthewebserverandareblockedfromactivatingmoredevices.(Seep.52)
USB
Photo List
Music List
Movie List
Divx Reg. Code
Deactivation
MOVE OK
ImageshownmaydifferfromyourTV.
ImageshownmaydifferfromyourTV.
background
ENGLISH
70
MAKING CONNECTIONS
ConnectvariousexternaldevicestotheTVandswitchinputmodestoselectanexternaldevice.Formore
informationaboutanexternaldevice’sconnection,refertothemanualsuppliedwitheachdevice.
Availableexternaldevicesare:HDreceivers,DVDplayers,VCRs,audiosystems,USBstoragedevices,
PC,camcordersorcameras,gamingdevices,andotherexternaldevices.
NOTE
IfyourecordaTVprogramonaDVDrecorderorVCR,makesuretoconnecttheTVsignalinput
cabletotheTVthroughaDVDrecorderorVCR.Formoreinformationaboutrecording,refertothe
manualsuppliedwiththeconnecteddevice.
Theexternaldeviceconnectionmaydifferfromthemodel.
ConnectexternaldevicestotheTVbyreferringtothefollowingtable.
Connection overview
Connection type
Video Audio
Digital Analog Digital Analog
HDMI (highly recommended) O - O -
Component - O - -
Composite - O - -
RGB - O - -
Optical audio - - O -
Analog audio - - - O
MAKING CONNECTIONS
background
ENGLISH
71
MAKING CONNECTIONS
ConnectvariousexternaldevicestotheportsontheTV’sbackpanel.
1
FindanexternaldeviceyouwanttoconnecttoyourTVshownonthefollowingillustration.
2
Checktheconnectiontypeoftheexternaldevice.
3
Gototheappropriateillustrationandchecktheconnectiondetails.
NOTE
IfyouconnectagamingdevicetotheTV,usethecablesuppliedwiththegamingdevice.
HDMI – See p.72
DVI – See p.72
Component – See p.72
Composite – See p.73
Euro Scart – See p.73
Digital optical audio
– See p.73
Headphone
– See p.74
HDMI – See p.38
DVI – See p.39
RGB – See p.39
HDMI – See p.72
DVI – See p.72
Component – See p.72
Composite – See p.73
Euro Scart – See p.73
HDMI – See p.72
DVI – See p.72
Component – See p.72
Composite – See p.73
Component – See p.72
Composite – See p.73
Euro Scart – See p.73
Memory storage
– See p.74
Memory card reader
– See p.74
HDMI – See p.72
Component – See p.72
Composite – See p.73
HD Receiver
Speaker
PC Camcorder/Camera Gaming device
DVD VCR
USB
background
ENGLISH
72
MAKING CONNECTIONS
Connecting to a Camcorder,
Camera, HD receiver, DVD,
VCR player or Gaming
device
ConnectaCamcorder,Camera,HDreceiver,DVD,
VCRplayerorGamingdevicetotheTVandselect
anappropriateinputmode.
NOTE
DVI OUT
12
AV
IN
2
(MONO
O
O)
O)
O)
A
U
DI
0
AUDIO OUT
HDMI connection
Transmitsthedigitalvideoandaudiosignalsfrom
anexternaldevicetotheTV.Connecttheexternal
deviceandtheTVwiththeHDMIcableasshown
onthefollowingillustration.
(
MONO
)
12
AUDI0
AV IN
2
0
HDMI OUT
DVI to HDMI connection
Transmitsthedigitalvideosignalfromanexternal
devicetotheTV.Connecttheexternaldeviceand
theTVwiththeDVI-HDMIcableasshowninthe
followingillustration.Totransmitanaudiosignal,
connectanoptionalaudiocable.
UseaHighSpeedHDMI™Cable.
HighSpeedHDMI™Cablesaretestedto
carryanHDsignalupto1080pandhigher.
1
2
AV
IN
2
VIDEO AUDIO
Y P
B
P
R
L R
(
MONO
)
A
U
DI
0
Component connection
Transmitstheanalogvideoandaudiosignalsfrom
anexternaldevicetotheTV.Connecttheexternal
deviceandtheTVwiththecomponentcableas
shownonthefollowingillustration.Todisplay
imagesbyusingprogressivescan,makesureto
usethecomponentcable.
background
ENGLISH
73
MAKING CONNECTIONS
1
2
AV IN2
(MONO)
AUDI0
VIDEO AUDIO(MONO) L R
AUDIO/ VIDEO
1
2
AV
IN
2
(
MONO
)
A
U
DI
0
Composite connection
Transmitstheanalogvideoandaudiosignalsfrom
anexternaldevicetotheTV.Connecttheexternal
deviceandtheTVwiththecompositecableas
shownonthefollowingillustration.
Euro Scart connection
Transmitsthevideoandaudiosignalsfroman
externaldevicetotheTV.Connecttheexternal
deviceandtheTVwiththeEuroScartcableas
shownonthefollowingillustration.Todisplay
imagesbyusingprogressivescan,makesureto
usetheEuroScartcable.
Connecting to an audio
system
Useanoptionalexternalaudiosysteminsteadof
thebuilt-inspeaker.
NOTE
Ifyouuseanexternalaudiodeviceinstead
ofthebuilt-inspeaker,settheTVspeaker
featuretooff(Seep.63).
Digital optical audio connection
TransmitsthedigitalaudiosignalfromtheTVtoan
externaldevice.Connecttheexternaldeviceand
theTVwiththeopticalaudiocableasshownon
thefollowingillustration
1
2
AV
IN
2
(MONO)
A
U
DI
0
OPTICAL AUDIO IN
background
ENGLISH
74
MAKING CONNECTIONS
1
2
AV
IN
2
(MONO)
A
U
DI
0
Headphone connection
TransmitstheheadphonesignalfromtheTVto
anexternaldevice.Connecttheexternaldevice
andtheTVwiththeheadphoneasshownonthe
followingillustration.
Connecting to a USB
ConnectaUSBstoragedevicesuchassUSB
flashmemory,externalharddrive,MP3playeror
aUSBmemorycardreadertotheTVandaccess
theUSBmenutousevariousmultimediafiles.
"Connecting USB storage devices"onSeep.43
and“Browsing files”onSeep.45
1
2
AV
IN2
(
MONO
)
A
U
DI
0
or
background
ENGLISH
75
TELETEXT
P
A
G
E
P
1 2 3
4 5
0
6
7 8 9
LIST
Q.VIEW
TV / PC INPUT
TV/
RAD
ENERGY
SAVING
MARK
FAV
3D
MUTE
OK
MENU
GUIDE
Q.MENU
INFO
Auto Config.
EXIT
3D SETTING
TELETEXT
Thisfeatureisnotavailableinallcountries.
TeletextisafreeservicebroadcastbymostTV
stationswhichgivesup-to-the-minuteinformation
onnews,weather,televisionprogrammes,share
pricesandmanyothertopics.Theteletextdecoder
ofthisTVcansupporttheSIMPLE,TOPand
FASTEXTsystems.SIMPLE(standardteletext)
consistsofanumberofpageswhichareselected
bydirectlyenteringthecorrespondingpage
number.TOPandFASTEXTaremoremodern
methodsallowingquickandeasyselectionof
teletextinformation.
Switch On/Off
Simple Text
Page selection
1
Enterthedesiredpagenumberasathree-digit
numberwiththeNumberbuttons.Ifduring
selectionyoupressawrongnumber,youmust
completethethree-digitnumberandthenre-
enterthecorrectpagenumber.
2
TheP
or buttoncanbeusedtoselectthe
previousornextpage.
Top Text
Theuserguidedisplaysfourfields-red,green,
yellowandblueatthebottomofthescreen.The
yellowfielddenotesthenextgroupandtheblue
fieldindicatesthenextblock.
Block / Group / Page Selection
1
WiththeBluebuttonyoucanprogressfrom
blocktoblock.
2
UsetheYellowbuttontoproceedtothenext
groupwithautomaticoverflowtothenextblock.
3
WiththeGreenbuttonyoucanproceedtothe
nextexistingpagewithautomaticoverflowto
thenextgroup.Alternatively,theP button
canbeused.
4
TheRedbuttonpermitsyoutoreturnto
previousselection.Alternatively,theP button
canbeused.
Direct Page Selection
AswithSIMPLEteletextmode,youcanselecta
pagebyenteringitasathreedigitnumberusing
theNumberbuttonsinTOPmode.
PresstheTEXTbuttontoswitchtoteletext.The
initialpageorlastpageappearsonthescreen.
Twopagenumbers,TVstationname,dateand
timearedisplayedonthescreenheadline.The
firstpagenumberindicatesyourselection,while
thesecondshowsthecurrentpagedisplayed.
PresstheTEXTorEXITbuttontoswitchoff
teletext.Thepreviousmodereappears.
background
ENGLISH
76
TELETEXT
Fastext
Theteletextpagesarecolourcodedalongthe
bottomofthescreenandareselectedbypressing
thecorrespondingcolouredbutton.
Page selection
1
PresstheT.OPTbuttonandthenusethe
Navigationbuttontoselect menu.Display
theindexpage.
2
Youcanselectthepageswhicharecolour
codedalongthebottomlinewithcorresponding
colouredbuttons.
3
ASwithSIMPLEteletextmode,youcanselect
apagebyenteringitsthreedigitpagenumber
withtheNUMBERbuttonsinFastextmode.
4
TheP
^
or
v
buttoncanbeusedtoselectthe
precedingorfollowingpage.
Special Teletext Function
Index
Selecttheeachindexpage.
Time
WhenviewingaTVprogramme,selectthis
menutodisplaythetimeatthetoprighthand
cornerofthescreen.
Intheteletextmode,pressthisbuttontoselect
asubpagenumber.Thesubpagenumberis
displayedatthebottomofthescreen.Tohold
orchangethesubpage,presstheRedbuttons
/Greenbuttons,<>orNumberbuttons.
Hold
Stopstheautomaticpagechangewhichwill
occurifateletextpageconsistsof2ormore
subpages.
Thenumberofsubpagesandthesubpage
displayedis,usually,shownonthescreen
belowthetime.Whenthismenuisselectedthe
stopsymbolisdisplayedatthetopleft-hand
cornerofthescreenandtheautomaticpage
changeisinactive.
Reveal
Selectthismenutodisplayconcealed
information,suchassolutionstoriddlesor
puzzles.
Update
DisplaystheTVpictureonthescreenwhile
waitingforanewteletextpage.Thedisplay
willappearatthetoplefthandcornerofthe
screen.Whentheupdatedpageisavailable
thendisplaywillchangetothepagenumber.
Selectthismenuagaintoviewtheupdated
teletextpage.
Index
Time
Hold
Reveal
Update
Close
Text Option
background
ENGLISH
77
DIGITAL TELETEXT (ONLY DTV)
DIGITAL TELETEXT (ONLY DTV)
ThisfunctionworksinUK,Irelandonly.
TheTVgivesyouaccesstodigitalteletextwhichis
greatlyimprovedinvariousaspectssuchastext,
graphicsetc.Thisdigitalteletextcanaccess
specialdigitalteletextservicesandspecific
serviceswhichbroadcastdigitalteletext.
Youshouldselectoffinthesubtitlelanguagemenu
todisplayteletextbypressingtheSUBTITLE
button.
Teletext within digital
service
Teletext in digital service
1
PressthenumericorP
or buttontoselect
adigitalservicewhichbroadcastsdigital
teletext.
2
Followtheindicationsondigitalteletextand
moveontothenextstepbypressingTEXT,
OK, Navigation button, Red button, Green
button, Yellow button, Blue button or
Number buttonsandetc.
3
Tochangedigitalteletextservice,selecta
differentservicebythenumericorP
or 
button.
1
PressthenumericorP
or buttontoselect
acertainservicewhichbroadcastsdigital
teletext.
2
PresstheTEXTorcolouredbuttontoswitchon
teletext.
3
Followtheindicationsondigitalteletextand
moveontothenextstepbypressingOK,
Navigation button, Red button, Green
button, Yellow button, Blue button or
Number buttonsandsoon.
4
PresstheTEXTorcolourbuttontoswitchoff
digitalteletextandreturntoTVviewing.
Someservicesmayallowyoutoaccesstext
servicesbypressingtheRedbutton.
background
ENGLISH
78
MAINTENANCE
MAINTENANCE
CleanyourTVregularlytokeepthebest
performanceandtoextendtheproductlifespan.
CAUTION
Makesuretoturnthepoweroffand
disconnectthepowercordandallother
cablesfirst.
WhentheTVisleftunattendedandunused
foralongtime,disconnectthepowercord
fromthewalloutlettopreventpossible
damagefromlightningorpowersurges.
Screen and frame
Toremovedust,wipethesurfacewithadryand
softcloth.
Toremovemajordirt,wipethesurfacewithasoft
clothdampenedincleanwateroradilutedmild
detergent.Thenwipeimmediatelywithacleanand
drycloth.
CAUTION
Donotpush,rub,orhitthesurfacewith
yourfingernailorasharpobject,asthismay
resultinscratchesonthescreenandimage
distortions.
Donotuseanychemicals,suchaswaxes,
benzene,alcohol,thinners,insecticides,
airfresheners,lubricants,asthesemay
damagethescreen’sfinishandcause
discolorations.
Cabinet and stand
Toremovedust,wipethecabinetwithadryand
softcloth.
Toremovemajordirt,wipethecabinetwitha
softclothdampenedinacleanwaterorwater
containingasmallamountofmilddetergent.
CAUTION
Donotsprayliquidontothesurface.Ifwater
enterstheTV,itmayresultinfire,electric
shock,ormalfunction.
Donotuseanychemicalsasthismay
deterioratethesurface.
Power cord
Removetheaccumulateddustordirtonthepower
cordregularly.
background
ENGLISH
79
TROUBLESHOOTING
TROUBLESHOOTING
General
The operation does not work normally.
Problem Resolution
Theremotecontroldoesn’twork
Checktoseeifthereisanyobjectbetweentheproductandthe
remotecontrolcausingobstruction.Ensureyouarepointingthe
remotecontrol
Ensurethatthebatteriesareinstalledwithcorrectpolarity( to ,
to ).
Ensurethatthecorrectremoteoperatingmodeisset:TV,VCR,etc.
Installnewbatteries.
Powerissuddenlyturnedoff
Isthesleeptimerset?
Checkthepowercontrolsettings.Powerinterrupted.
IftheTVisswitchedonandthereisnoinputsignal,itwillswitchoff
automaticallyafter15minutestosavethepowerconsumption.
WhenabrokenfilewasplayedintheUSBmode,theTVmayturnoff.
Pleasecheckthefileinyourusbstorage.
Exceptthescreenoffmodeoftheenergysavingmenu.
The video function does not work.
Problem Resolution
Nopicture&Nosound
Checkwhethertheproductisturnedon.
Tryanotherchannel.Theproblemmaybewiththebroadcast.
Isthepowercordinsertedintowallpoweroutlet?
Checkyourantennadirectionand/orlocation.
Testthewallpoweroutlet,pluganotherproduct’spowercordintothe
outletwheretheproduct’spowercordwaspluggedin.
Pictureappearsslowlyafter
switchingon
Thisisnormal,theimageismutedduringtheproductstartupprocess.
Pleasecontactyourservicecentre,ifthepicturehasnotappeared
afterfiveminutes.
NoColour,poorcolour,orpoor
AdjustColourinmenuoption.
KeepasufficientdistancebetweentheproductandtheVCR.
Tryanotherchannel.Theproblemmaybewiththebroadcast.
Arethevideocablesinstalledproperly?
Activateanyfunctiontorestorethebrightnessofthepicture.
Horizontal/verticalbarsorpicture
shaking
Checkforlocalinterferencesuchasanelectricalapplianceorpower
tool.
Poorreceptiononsomechannels
Stationorcableproductexperiencingproblems,tunetoanother
station.
Stationsignalisweak,reorientantennatoreceiveweakerstation.
Checkforsourcesofpossibleinterference.
Linesorstreaksinpictures
Checkantenna(Changethedirectionoftheantenna).
background
ENGLISH
80
TROUBLESHOOTING
The audio function does not work.
Problem Resolution
PictureOK&Nosound
Pressthe
(+ , -)
button
or VOL (
,
)
button.
Soundmuted?PressMUTEbutton.
Tryanotherchannel.Theproblemmaybewiththebroadcast.
Aretheaudiocablesinstalledproperly?
Nooutputfromoneofthespeakers
AdjustBalanceinmenuoption.
Unusualsoundfrominsidethe
product
Achangeinambienthumidityortemperaturemayresultinanunusual
noisewhentheproductisturnedonoroffanddoesnotindicatea
problemwiththeproduct.
NosoundwhenconnectingHDMI
orUSB
CheckHDMIcableisHighSpeedHDMICable.
CheckUSBcableoverversion2.0.
IfthesoundisabnormalintheHDMI,checktheaudioformatinyour
externalequipments.
»
AudioSupportedformat:DolbyDigital,PCM
There is a problem with PICTURE settings.
Problem Resolution
Whentheuserchangesthepicture
settings,the
TV
automatically
convertsbacktotheinitialsettings
afteracertainperiodoftime.
ItmeansthattheTViscurrentlysettoStore Demomode.Toswitch
toHomeusemodeyoushoulddothefollowings:FromtheTVMenu,
chooseOPTION→ChooseMode Setting→ChooseHomeuse.
Now,youhavecompletedswitchingtotheHomeusemode.
PC mode
No image is displayed.
Problem Resolution
Powerison,powerindictorisblue
butthescreenappearsextremely
dark.
Adjustbrightnessandcontrastagain.
Doesthe‘Invalidformat’message
appear?
ThesignalfromthePC(Videocard)isoutoftheverticalorhorizontal
frequencyrangeoftheproduct.Adjustthefrequencyrangeby
referringtotheSpecificationsinthisuser’sguide.
Doesthe‘Checksignalcable’
messageappear?
ThesignalcablebetweenPCandproductisnotconnected.Check
thesignalcable.
Pressthe‘INPUT’buttonintheremotecontroltochecktheinput
signal.
Problem Resolution
NopicturewhenconnectingHDMI
CheckthatyourHDMIcableisHighSpeedHDMICable.
IftheHDMIcablesarenotHighSpeedHDMICable,flickeringorno
screendisplaycanresult.PleaseusetheHighSpeedHDMICable.
background
ENGLISH
81
TROUBLESHOOTING
‘Unknown Product’ message appears when the product is connected.
Problem Resolution
Didyouinstallthedriver?
Installtheproductdriver,whichisprovidedwiththeproduct,or
downloaditfromthewebsite.(http://www.lg.com)
Seeiftheplug&playfunctionissupportedbyreferringtothevideo
carduser’sguide.
After-image appears on the product.
Problem Resolution
After-imageappearswhen
theproductisturnedoff.
Ifyouuseafixedimageforalongtime,thepixelsmaybedamaged
quickly.Usethescreensaverfunction.
Screen Colour is abnormal.
Problem Resolution
ScreenhaspoorColourresoluion
(16_Colours).
SetscreenColourresolutiontomorethan24bits(trueColour)Select
controlPane→Display→Settings→ColourTablemenuinWindows.
ScreenColourisunstableormono
Colour.
Checktheconnectionstatusofthesignalcable.
Dobackspotsappearonthe
screen?
Severalpixels(red,green,whiteorblackColour)mayappearonthe
screen,whichcanbeattributabletotheuniquecharacteristicsofthe
LCDpanel.ItisnotamalfunctionoftheLCD.
The screen image looks abnormal.
Problem Resolution
Isthescreenpositionwrong?
AdjustthePositionmenuinOSD.FromtheTVMenu,Choose
PICTURE→ChooseScreen→AdjustsPosition.
ASeeifthevideocardresolutionandfrequencyaresupportedby
theproduct.Ifthefrequencyisoutofrange,settotherecommended
resolutionintheControlPanel→Display→Settingmenu.
Dothinlinesappearonthe
backgroundscreen?
AdjusttheSizemenuinOSD.FromtheTVMenu,ChoosePICTURE
→ChooseScreen→AdjustsSize.
Horizontalnoiseappearsorthe
characterslookblurred.
AdjustthePhasemenuinOSD.FromtheTVMenu,Choose
PICTURE→ChooseScreen→AdjustsPhase.
background
ENGLISH
82
TROUBLESHOOTING WHEN USING 3D MODE
TROUBLESHOOTING WHEN USING 3D MODE
I can see a swirling oil-like pattern on the TV when the TV is turned off.
ThisiscausedbytheinterferenceofexternallightintheairlayerbetweentheLCDsurfaceand3Dfilter.
Thepatternbecomesalmostinvisiblewhenyouturnonthepoweragain.
I cannot see 3D image properly
Problem Resolution
Ifyouarenotusingtheglasses
providedwiththeTV.
Whenyouview3DimageswiththisTV,itisveryimportantthatyouusethe
glassesprovidedwiththeTV.Theglassesaredesignedtocompensateoptically
forthe3DfilterattachedtothesurfaceoftheTV.Ifyouwearthird-partyglasses,
youmaynotsee3DimagesproperlyontheTV.
Ifyouview3Dimagesoutsidethe
optimalviewingangleordistance.
TheoptimalviewingangleofthisTVisbetween14°degrees;theoptimalviewing
distanceisbetween50cmto90cmfromtheTV.Whenyouview3Dimages
outsidetheoptimalviewingangleorviewingdistance,theimagesmaylook
overlappedornotbedisplayedproperlyin3D.
Notes for Viewing 3D Image with 3D Digital Brodcating
*In Analogue Brodcating, 3D Imaging does not work.
Problem Resolution
Whenswitchingthe2Dimage
displaytothe3Dimagedisplay
withthe3Dbuttonontheremote
control,theoverlappedimagemay
bedisplayed.
Disablethe3Dimagingmodewiththe3Dbutton.
The3Dimagingmodeisdisabledautomaticallyifyouchangethechannel.
Ifthescreenisdividedintoleft/right
ortop/bottomwhenyouchangethe
channel

Thischannelsupportsthe3Dimagingmode.Selectthe3Dimagingtype
displayedonthescreenbypressingthe3Dbuttonontheremotecontrol.
Ifyoureyesaresoreorthescreen
looksblurrywhileviewing3D
images.
SelectLeft/RightorRight/Leftoption,whichyoufindbetterforviewing3D
images.
background
ENGLISH
83
SPECIFICATIONS
LCD Panel Screen Type 685.8mmWide(27inch)TFT(ThinFilmTransistor)
LCD(LiquidCrystalDisplay)Panel
Visiblediagonalsize:685.8mm
Pixel Pitch 0.3114mm(H)x0.3114mm(V)
Video Signal Max. Resolution 1920×1080@60Hz
Recommended
Resolution
1920×1080@60Hz
Horizontal Frequency 30kHzto83kHz
Vertical Frequency 56Hzto75Hz
Synchronization Type SeparateSync,Digital
Input Connector TV,D-SubAnalog,SCART,PCAudioIn,Component,
HDMI*2,CVBS
Power Rated Voltage 19V 3.0A
Power Consumption OnMode:47W(typ.)
OffMode 0.5W
AC/DC Adapter Manufacturer:LITE-ON,ModelPA-1650-68
Tilt Tilt Range -5°to18°
Dimensions (Width x Height x Depth)
Weight
644mmx480.6mmx222.8mm
6.0kg
Environmental
conditions
Operating Temperature
Operating Humidity
10°Cto35°C
20%to80%
Storage Temperature
Storage Humidity
-10°Cto60°C
5%to90%
Productspecificationsshownabovemaybechangedwithoutpriornoticeduetoupgradeofproduct
functions.
SPECIFICATIONS
background
ENGLISH
84
RGB (PC) / HDMI (PC) supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x400 31.468 70.080
640x480 31.469 59.940
640x480 37.500 75.000
800x600 37.879 60.317
800x600 46.875 75.000
1024x768 48.363 60.000
1024x768 60.023 75.029
1152x864 67.500 75.000
1280x720 63.981 60.020
1280x800 49.702 59.810
1280x1024 63.981 60.020
1280x1024 79.976 75.025
1400x1050 65.317 59.978
1440x900 55.935 59.887
1600x900 60.000 60.000
1680x1050 64.674 59.883
1680x1050 65.290 59.954
1920x1080 67.500 60.000
Component supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x480 15.730 59.940
720x480 15.750 60.000
720x576 15.625 50.000
720x480 31.470 59.940
720x480 31.500 60.000
720x576 31.250 50.000
1280x720 44.960 59.940
1280x720 45.000 60.000
1280x720 37.500 50.000
1920x1080 33.720 59.940
1920x1080 33.750 60.000
1920x1080 28.125 50.000
1920x1080 56.250 50.000
1920x1080 67.432 59.940
1920x1080 67.500 60.000
Component port connecting informatio
Componentportsonthe
TV
Y P
B
P
R
Videooutputports
onDVDplayer
Y P
B
P
R
Y B-Y R-Y
Y Cb Cr
Y Pb Pr
HDMI (DTV) supported mode
Resolution
Horizontal
Frequency(kHz)
Vertical
Frequency(Hz)
720x480 31.469
31.500
59.940
60.000
720x576 31.250 50.000
1280x720 37.500 50.000
1280x720 44.960
45.000
59.940
60.000
1920x1080 33.720
33.750
59.940
60.000
1920x1080 28.125 50.000
1920x1080 27.000 24.000
1920x1080 33.750 30.000
1920x1080 56.250 50.000
1920x1080 67.430
67.500
59.940
60.000
background
ENGLISH
85
SPECIFICATIONS
NOTE
Avoidkeepingafixedimageontheset’sscreenforprolongedperiodsoftime.Thefixedimagemay
becomepermanentlyimprintedonthescreen.Useascreensaverwhenpossible.
Theremaybeinterferencerelatingtoresolution,verticalpattern,contrastorbrightnessinPCmode.
ChangethePCmodetoanotherresolutionorchangetherefreshratetoanotherrateoradjustthe
brightnessandcontrastonthemenuuntilthepictureisclear.IftherefreshrateofthePCgraphiccard
cannotbechanged,changethePCgraphiccardorconsultthemanufacturerofthePCgraphiccard.
ThesynchronizationinputwaveformforHorizontalandVerticalfrequenciesareseparate.
ConnectthesignalcablefromtheTVoutputportofthePCtotheRGB(PC)portoftheTVorthe
signalcablefromtheHDMIoutputportofthePCtotheHDMI/DVIINportontheTV.
ConnecttheaudiocablefromthePCtotheAudioinputontheTV.(Audiocablesarenotincludedwith
theTV).
Ifusingasoundcard,adjustPCsoundasrequired.
IfthegraphiccardonthePCdoesnotoutputanalogueanddigitalRGBsimultaneously,connectonly
oneofeitherRGBorHDMI/DVIINtodisplaythePCoutputontheTV.
IfthegraphiccardonthePCdoesoutputanalogueanddigitalRGBsimultaneously,TVtheTVto
eitherRGBorHDMI.(TheothermodeissettoPlugandPlayautomaticallybytheTV.)
DOSmodemaynotworkdependingonthevideocardifyouuseanHDMItoDVIcable.
IfyouusetoolonganRGB-PCcablethatistoolong,theremaybeinterferenceonthescreen.We
recommendusingunder5mofcable.Thisprovidesthebestpicturequality.
background
ENGLISH
86
SPECIFICATIONS
3D video input format supported.
Signal Resolution Horizontal
Frequency
(kHz)
Vertical
Frequency
(Hz)
Playable 3D video format
HDMI
720p 1280x720 45 60 Top&Bottom,SidebySide
89.9
90
59.94
60
HDMIFramePacking
37.5 50 Top&Bottom,SidebySide
75 HDMIFramePacking
1080i 1920x1080 33.75 60 Top&Bottom,SidebySide
28.125 50
1080p 1920x1080 67.50 60 Top&Bottom,SidebySide,
CheckerBoard,SingleFrameSequential
56.250 50 Top&Bottom,SidebySide,
CheckerBoard,SingleFrameSequential
27 24 Top&Bottom,SidebySide,CheckerBoard
53.95
54
23.98
24
HDMIFramePacking
33.75 30 Top&Bottom,SidebySide,CheckerBoard
USB
1080p 1920x1080 33.75 30 Top&Bottom,SidebySide,CheckerBoard
RGB
1080p 1920x1080 66.587 59.93 Top&Bottom,SidebySide
Signal Playable 3D video format
DTV
720p,1080i Top&Bottom,SidebySide
NOTE
IfHDMIinputisreceivedinHDMI3Dformat,imagesareautomaticallyconvertedinto3D.
2D 3Dmodeisavailabletowatchforallsignals.
Ifyouchange2D 3Dmode,theleftandrightedgesofthescreenareclipped.
IfyouselectHDMI3D,3Dmodeisautomaticallyenabled,whichmaycausethedelayofscreen
turningon.
Forsome3Dcontentfiles,ifa3Dfileisconvertedinto2D,theleftandrightedgesofthescreenmay
appeartruncated.
background
ENGLISH
87
IR CODES
IR CODES
Thisfeatureisnotavailableforallmodels.
Code (Hexa) Function Note
95 EnergySaving( ) R/CBUTTON
08
(POWER)
R/CBUTTON(POWERON/OFF)
50 TV/PC R/CBUTTON
0B INPUT R/CBUTTON
DC 3D R/CBUTTON
F0 TV/RAD R/CBUTTON
45 Q.MENU(3DSETTING) R/CBUTTON
43 MENU R/CBUTTON
AB GUIDE R/CBUTTON
40 Up( ) R/CBUTTON
41 Down( ) R/CBUTTON
07 Left(<) R/CBUTTON
06 Right(>) R/CBUTTON
44 OK( ) R/CBUTTON
28
BACK( )
R/CBUTTON
5B EXIT R/CBUTTON
AA INFO R/CBUTTON
02
(+)
R/CBUTTON
03
(-)
R/CBUTTON
1E FAV(MARK) R/CBUTTON
09 MUTE R/CBUTTON
00 P( ) R/CBUTTON
01 P( ) R/CBUTTON
10to19 NumberKey0to9 R/CBUTTON
53 LIST R/CBUTTON
1A Q.VIEW R/CBUTTON
72 RedKey R/CBUTTON
71 GreenKey R/CBUTTON
63 YellowKey R/CBUTTON
61 BlueKey R/CBUTTON
20 TEXT R/CBUTTON
21 T.OPT(T.Option) R/CBUTTON
39 SUBTITLE R/CBUTTON
99 AutoConfig. R/CBUTTON
B1 R/CBUTTON
B0 R/CBUTTON
BA R/CBUTTON
8F R/CBUTTON
8E R/CBUTTON
background
ENGLISH
88
EXTERNAL CONTROL DEVICE SETUP
NOTE
RS-232Conthisunitisintendedtobeused
withthirdpartyRS-232Ccontrolhardwareand
software.Theinstructionsbelowareprovided
tohelpwithprogrammingsoftwareortotest
functionalityusingtelenetsoftware.RS-232C
connectioncablesarenotsuppliedwiththe
product.
EXTERNAL CONTROL DEVICE SETUP
RS-232C Setup
ConnecttheRS-232C(serialport)inputjackto
anexternalcontroldevice(suchasacomputer
oranA/Vcontrolsystem)tocontroltheproduct’s
functionsexternally.
Connecttheserialportofthecontroldevicetothe
RS-232Cjackontheproductbackpanel.
Type of connector; D-Sub
9-Pin Male
1 5
6 9
RS-232C IN
(CONTROL & SERVICE)
No. Pin name
1 Noconnection
2 RXD(Receivedata)
3 TXD(Transmitdata)
4 DTR(DTEsideready)
5 GND
6 DSR(DCEsideready)
7 RTS(Readytosend)
8 CTS(Cleartosend)
9 NoConnection
RS-232C IN
(CONTROL & SERVICE)
background
ENGLISH
89
EXTERNAL CONTROL DEVICE SETUP
Set ID
SetIDnumber."Real Data Mapping"onSeep.95
1
PressMENUtoaccessthemainmenus.
2
PresstheNavigationbuttonstoscrollto
OPTIONandpressOK.
3
PresstheNavigationbuttonstoscrolltoSet ID
andpressOK.
4
ScrollleftorrighttoselectasetIDnumberand
selectClose.Theadjustmentrangeis1-99.
5
Whenyouarefinished,pressEXIT.
Whenyoureturntothepreviousmenu,press
BACK.
RS-232C configurations
7-WireConfiguration
(Serialfemale-femaleNULLmodemcable)
3-WireConfigurations(Notstandard)
PC TV
RXD 2 3 TXD
TXD 3 2 RXD
GND 5 5 GND
DTR 4 6 DSR
DSR 6 4 DTR
RTS 7 8 CTS
CTS 8 7 RTS
D-Sub 9 D-Sub 9
PC TV
RXD 2 3 TXD
TXD 3 2 RXD
GND 5 5 GND
DTR 4 6 DSR
DSR 6 4 DTR
RTS 7 8 CTS
CTS 8 7 RTS
D-Sub 9 D-Sub 9
OPTION
MOVE OK
Menu Language : English
Audio Language : English
Subtitle Language : English
Disabled Assistance
Data Service : MHEG
Country : UK
Input Label
Set ID : 1 ꔉ
Power Indacator : On
Demo Mode : Off
Mode Setting : Home Use
Factory Reset
ImageshownmaydifferfromyourTV.
background
ENGLISH
90
EXTERNAL CONTROL DEVICE SETUP
Command reference list
Communication Parameters
Baudrate:9600bps(UART)
Datalength:8bits
Parity:None
Stopbit:1bit
Communicationcode:ASCIIcode
Useacrossed(reverse)cable.
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01.Power k a 00to01
02.AspectRatio x c Seep.92
03.ScreenMute k d 00to01
04.VolumeMute k e 00to01
05.VolumeControl k f 00to64
06.Contrast k g 00to64
07.Brightness k h 00to64
08.Colour k i 00to64
09.Tint k j 00to64
10.Sharpness k k 00to64
11.OSDSelect k l 00to01
12.Remotecontrollockmode k m 00to01
13.Treble k r 00to64
14.Bass k s 00to64
15.Balance k t 00to64
16.ColourTemperature x u 00to64
17.EnergySaving j q 00to05
18.AutoConfiguration j u 01
19.TuneCommand m a Seep.94
20.ProgrammeAdd/Skip m b 00to01
21.Key m c KeyCode
22.BackLight m g 00to64
23.Inputselect(Main) x b Seep.95
24.3D x t Seep.96
25.Extended3D x v Seep.96
Note:DuringUSBoperationssuchasDvixorEMF,allcommandsexceptPower(ka)andKey(mc)are
notexecutedandtreatedasNG.
background
ENGLISH
91
EXTERNAL CONTROL DEVICE SETUP
Transmission / Receiving protocol
Transmission
[Command1][Command2][ ][Set ID][ ][Data][Cr]
[Command1]:FirstcommandtocontroltheTV.(j,k,morx)
[Command2]:SecondcommandtocontroltheTV.
[SetID]:YoucanadjustthesetIDtochoosedesiredTVIDnumberinoptionmenu.Adjustmentrangeis1
to99.WhenselectingSetID‘0’,everyconnectedsetiscontrolled.SetIDisindicatedasdecimal(1
to99)onmenuandasHexadecimal(0x0to0x63)ontransmission/receivingprotocol.
*[DATA]:Totransmitcommanddata.
Transmit‘FF’datatoreadstatusofcommand.
*[Cr]:CarriageReturn
ASCIIcode‘0x0D’
*[]:ASCIIcode‘space(0x20)’
OK Acknowledgement
[Command2][ ][Set ID][ ][OK][Data][x]
ThesettransmitsACK(acknowledgement)basedonthisformatwhenreceivingnormaldata.Atthistime,
ifthedataisdatareadmode,itindicatespresentstatusdata.Ifthedataisdatawritemode,itreturnsthe
dataofthePCcomputer.
Error Acknowledgement
[Command2][ ][Set ID][ ][NG][Data][x]
*ThesettransmitsACK(acknowledgement)basedonthisformatwhenreceivingabnormaldatafromnon-
viablefunctionsorcommunicationerrors.Data00:IllegalCode
background
ENGLISH
92
EXTERNAL CONTROL DEVICE SETUP
01. Power (Command: k a)
TocontrolPowerOn/Offoftheset.
Transmission
[k][a][][SetID][][Data][Cr]
Data00:PowerOff Data01:PowerOn
Acknowledgement
[a][][SetID][][OK/NG][Data][x]
ToshowPowerOn/Off.
Transmission
[k][a][][SetID][][FF][Cr]
Acknowledgement
[a][][SetID][][OK/NG][Data][x]
*Similarly,ifotherfunctionstransmit‘0xFF’data
basedonthisformat,Acknowledgementdatafeed
backpresentsstatusabouteachfunction.
*OKAck.,ErrorAck.andothermessagemaydisplay
onthescreenwhenTVispowerOn.
02. Aspect Ratio (Command: k c) (Main Picture Size)
Toadjustthescreenformat.(Mainpictureformat)
Youcanalsoadjustthescreenformatusingthe
AspectRatiointheQ.MENU.orPICTUREmenu.
Transmission
[k][c][][SetID][][Data][Cr]
Data01:Normalscreen(4:3)
02:Widescreen(16:9)
04:Zoom
06:Original
07:14:9
09:JustScan
0B:FullWide
10to1F:CinemaZoom1to16
Acknowledgement
[c][][SetID][][OK/NG][Data][x]
*UsingthePCinput,youselecteither16:9or4:3
screenaspectratio.
*InDTV/HDMI(1080i50Hz/60Hz,720p50Hz
/60Hz,1080p24Hz/30Hz/50Hz/60Hz),
Component(720p,1080i,1080p50Hz/60Hz)
mode,JustScanisavailable.
*FullWideissupportedonlyforAnalogue,AV.
03. Screen Mute (Command: k d)
Toselectscreenmuteon/off.
Transmission
[k][d][][SetID][][Data][Cr]
Data00:Screenmuteoff(Pictureon)
Videomuteoff
01:Screenmuteon(Pictureoff)
10:Videomuteon
Acknowledgement
[d][][SetID][][OK/NG][Data][x]
*Incaseofvideomuteononly,TVwilldisplayOn
ScreenDisplay(OSD).But,incaseofScreenmute
on,TVwillnotdisplayOSD.
04. Volume Mute (Command: k e)
Tocontrolvolumemuteon/off.
YoucanalsoadjustmuteusingtheMUTEbuttonon
remotecontrol.
Transmission
[k][e][][SetID][][Data][Cr]
Data00:Volumemuteon(Volumeoff)
01:Volumemuteoff(Volumeon)
Acknowledgement
[e][][SetID][][OK/NG][Data][x]
05. Volume Control (Command: k f)
Toadjustvolume.
YoucanalsoadjustvolumewiththeVOLUME
buttonsonremotecontrol.
Transmission
[k][f][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[f][][SetID][][OK/NG][Data][x]
06. Contrast (Command: k g)
Toadjustscreencontrast.
YoucanalsoadjustcontrastinthePICTUREmenu.
Transmission
[k][g][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[g][][SetID][][OK/NG][Data][x]
background
ENGLISH
93
EXTERNAL CONTROL DEVICE SETUP
07. Brightness (Command: k h)
Toadjustscreenbrightness.
YoucanalsoadjustbrightnessinthePICTURE
menu.
Transmission
[k][h][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[h][][SetID][][OK/NG][Data][x]
08. Colour (Command: k i)
Toadjustthescreencolour.(ExceptPCmode)
YoucanalsoadjustcolourinthePICTUREmenu.
Transmission
[k][i][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[i][][SetID][][OK/NG][Data][x]
09. Tint (Command: k j)
Toadjustthescreentint.(ExceptPCmode)
YoucanalsoadjusttintinthePICTUREmenu.
Transmission
[k][j][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[j][][SetID][][OK/NG][Data][x]
10. Sharpness (Command: k k)
Toadjustthescreensharpness.
YoucanalsoadjustsharpnessinthePICTURE
menu.
Transmission
[k][k][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[k][][SetID][][OK/NG][Data][x]
11. OSD Select (Command: k l)
ToselectOSD(OnScreenDisplay)on/offwhen
controllingremotely.
Transmission
[k][l][][SetID][][Data][Cr]
Data00:OSDoff 01:OSDon
Acknowledgement
[l][][SetID][][OK/NG][Data][x]
12. Remote control lock mode (Command: k m)
TolockthefrontpanelcontrolsontheTVand
remotecontrol.
Transmission
[k][m][][SetID][][Data][Cr]
Data00:Lockoff 01:Lockon
Acknowledgement
[m][][SetID][][OK/NG][Data][x]
*Ifyouarenotusingtheremotecontrol,usethis
mode.Whenmainpowerison/off,externalcontrol
lockisreleased.
*LocalPowerKeywillworkproperly.
13. Treble (Command: k r)
Toadjusttreble.
YoucanalsoadjusttrebleintheAUDIOmenu.
Transmission
[k][r][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[r][][SetID][][OK/NG][Data][x]
14. Bass (Command: k s)
Toadjustbass.
YoucanalsoadjustbassintheAUDIOmenu.
Transmission
[k][s][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[s][][SetID][][OK/NG][Data][x]
background
ENGLISH
94
EXTERNAL CONTROL DEVICE SETUP
15. Balance (Command: k t)
Toadjustbalance.
YoucanalsoadjustbalanceintheAUDIOmenu.
Transmission
[k][t][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[t][][SetID][][OK/NG][Data][x]
16. Colour Temperature (Command: x u)
Toadjustcolourtemperature.Youcanalsoadjust
Colour.
TemperatureinthePICTUREmenu.
Transmission
[x][u][][SetID][][Data][Cr]
DataMin:00toMax:64
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[u][][SetID][][OK/NG][Data][x]
17. Energy Saving (Command: j q)
ToreducethepowerconsumptionoftheTV.You
canalsoadjustEnergySavinginOPTIONmenu.
Transmission
[j][q][][SetID][][Data][Cr]
Power
Saving
Function
Level
Description
7 6 5 4 3 2 1 0
0 0 0 0 LowPower 0 0 0 0 Off
0 0 0 0 LowPower 0 0 0 1 Minimum
0 0 0 0 LowPower 0 0 1 0 Medium
0 0 0 0 LowPower 0 0 1 1 Maximum
0 0 0 0 LowPower 0 1 0 1 ScreenOff
Acknowledgement
[q][][SetID][][OK/NG][Data][x]
18. Auto Configure(Command: j u)
Toadjustpicturepositionandminimizeimage
shakingautomatically.ItworksonlyinRGB(PC)
mode.
Transmission
[j][u][][SetID][][Data][Cr]
Data01:Toset
Acknowledgement
[u][][SetID][][OK/NG][Data][x]
19.Tune Command (Command: m a)
Selectchanneltofollowingphysicalnumber.
Transmission
[m][a][][SetID][][Data0][][Data1][][Data2][Cr]
Data00:Highchanneldata
Data01:Lowchanneldata
ex.No.47->002F(2FH)
No.394->018A(18AH),
DTVNo.0->Don’tcare
Data02:0x00:AnalogueMain
0x10:DTVMain
0x20:Radio
Channeldatarange
Analogue-Min:00toMax:63(0to99)
Digital-Min:00toMax:3E7(0to999)
(ExceptForSweden,Finland,Norway,Denmark,
Ireland)
Digital-Min:00toMax:270F(0to9999)
(OnlySweden,Finland,Norway,Denmark,Ireland)
Acknowledgement
[a][][SetID][][OK/NG][Data][x]
DataMin:00toMax:7DH
background
ENGLISH
95
EXTERNAL CONTROL DEVICE SETUP
20. Programme Add/Skip (Command: m b)
TosetskipstatusforthecurrentProgramme.
Transmission
[m][b][][SetID][][Data][Cr]
Data00:Skip 01:Add
Acknowledgement
[b][][SetID][][OK/NG][Data][x]
Real data mapping
00:Step0 Tint
: Step0:R50
A:Step10(SetID10) :
: Step49:R1
F:Step15(SetID15) Step50:0
10:Step16(SetID16) Step51:G1
: :
64:Step100 Step100:G50
:
6E:Step110 Balance
:
73:Step115
Step0:L50
74:Step116 :
: Step49:L1
CF:Step199 Step50:0
: Step51:R1
FE:Step254 :
FF:Step255 Step100:R50
Colour Temperature
Step0:W50
:
Step49:W1
Step50:0
Step51:C1
:
Step100:C50
21. Key (Command: m c)
TosendIRremotekeycode.
Transmission
[m][c][][SetID][][Data][Cr]
DataMin:00toMax:64
*DataKeycod-Seep.87
Acknowledgement
[c][][SetID][][OK/NG][Data][x]
22. Back Light (Command: m g)
ToControlthebacklight.
Transmission
[m][g][][SetID][][Data][Cr]
Data:dataMin:00toMax:64
Acknowledgement
[g][][SetID][][OK/NG][Data][x]
23. Input select (Command: x b) (Main Picture Input)
Toselectinputsourceformainpicture.
Transmission
[x][b][][SetID][][Data][Cr]
DataStructure
Data00:DTV 40:Component
10:Analogue 60:RGB
20:AV 90:HDMI
Acknowledgement
[b][][SetID][][OK/NG][Data][x]
background
ENGLISH
96
EXTERNAL CONTROL DEVICE SETUP
24. 3D(Command: x t) (only 3D model)
Tochange3DmodeforTV.
Transmission
[x][t][][SetID][][Data01][][Data02][][Data03][]
[Data04][Cr]
Data01
00:3DOn
01:3DOff
02:3Dto2D
03:2Dto3D
Data02
00:TopandBottom
01:SidebySide
02:CheckBoard
03:FrameSequential
Data03
00:RighttoLeft
01:LefttoRight
Data04
3DDepth:Min:0toMax:14
*Referto‘Realdatamapping’.Seep.95
*Ifdata1is00(3DOn),data4hasnomeaning.
*Ifdata1is01(3DOff)or02(3Dto2D),data2,data3
anddata4havenomeaning.
*Ifdata1is03(2Dto3D),data2anddata3haveno
meaning.
Data1 Data2 Data3 Data4
00 O O X
01 X X X
02 X X X
03 X X O
X:don'tcare
Acknowledgement
[t][][OK][Data01][Data02][Data03][Data04][x]
[t][][NG][Data01][x]
25. Extended 3D(Command: x v) (only 3D model)
Tochange3DmodeforTV.
Transmission
[x][v][][SetID][][Data01][][Data02][Cr]
Data01:3Doption
00:3DPictureCorrection
01:3DDepth(2Dto3DOnly)
02:3DViewpoint
Data02Ithasownrangeforeach3Doption
determinedbyData01.
1)WhenData01is00
00:RighttoLeft
01:LefttoRight
2)WhenData01is01
DataMin:0toMax:14
3)WhenData01is02
DataMin:0toMax:14
DataMin:0toMax:06
*Referto‘Realdatamapping’.Seep.95
Acknowledgement
[v][][OK][Data01][Data02][x][v][][NG][Data01][x]
background
UK Only
background
background
background
Make sure to read the Safety Precautions before
using the product.
Keep the Owner’s Manual (CD) in an accessible
place for future reference.
The model and serial number of the TV is
located on the back and one side of the TV.
Record it below should you ever need service.
MODEL
SERIAL

Specifications

Indexed Terms: Monitor, 27 Inch

LG Electronics DM2780D Questions and Answers

Find answers or ask new question.
Questions and Answers

Related Products

No image
LG Electronics E2711T Lg 27 Monitor
2020-11-01 1 docs
No image
LG Electronics M2762DP Lg 27 Monitor
2020-10-28 1 docs
No image
LG Electronics 27GR95UM 27" Gaming Monitor -
2024-02-11 2 docs
Product LG Electronics 27GS50FX B image
LG Electronics 27GS50FX-B - 27" Gaming Monitor UltraGear
2024-10-20 3 docs
Product LG Electronics 27GS93QE B image
LG Electronics 27GS93QE-B 27" Gaming Monitor
2024-10-05 2 docs
