www.lg.com
OWNER’S MANUAL
Please read this manual carefully before operating your set and retain
it for future reference.
*MFL68823611*
P/NO : MFL68823611 (1502-REV00)
Printed in Korea
EG96** EF95**
2
ENGLISH
TABLE OF CONTENTS
TABLE OF CONTENTS
3 LICENSES
3 OPEN SOURCE SOFTWARE
NOTICE INFORMATION
4 SAFETY INSTRUCTIONS
11 - Viewing 3D Imaging
(Only 3D models)
13 INSTALLATION PROCEDURE
14 ASSEMBLING AND
PREPARING
14 Unpacking
16 Separate purchase
17 Parts and buttons
18 - Using the joystick button
19 Lifting and moving the TV
20 Setting up the TV
20 - Attaching the stand
24 Mounting on a table
25 Mounting on a wall
26 Tidying cables
27 MAKING CONNECTIONS
27 Antenna connection
28 Satellite dish connection
28 HDMI connection
29 DVI to HDMI connection
30 Component connection
30 Composite connection
31 Headphone connection
31 Audio connection
31 - Digital optical audio connection
32 USB connection
32 CI module connection
33 Euro scart connection
34 MAGIC REMOTE FUNCTIONS
36 Registering magic remote
36 How to use magic remote
36 Precautions to Take when Using the Magic Remote
37 USING THE USER GUIDE
38 MAINTENANCE
38 Cleaning your TV
38 - Screen, frame, cabinet and stand
38 - Power cord
39 TROUBLESHOOTING
39 SPECIFICATIONS
41 REGULATORY
WARNING
If you ignore the warning message, you may be
seriously injured or there is a possibility of accident or
death.
CAUTION
If you ignore the caution message, you may be
slightly injured or the product may be damaged.
NOTE
The note helps you understand and use the product
safely. Please read the note carefully before using the
product.
3
LICENSES / OPEN SOURCE SOFTWARE NOTICE INFORMATION
ENGLISH
LICENSES
Supported licenses may dier by model. For more information about licenses, visit www.lg.com.
OPEN SOURCE SOFTWARE NOTICE INFORMATION
To obtain the source code under GPL, LGPL, MPL, and other open source licenses, that is contained in this product, please
visit http://opensource.lge.com.
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for
download.
LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such
distribution (such as the cost of media, shipping, and handling) upon email request to opensour[email protected]. This oer is
valid for three (3) years from the date on which you purchased the product.
4
ENGLISH
SAFETY INSTRUCTIONS
SAFETY INSTRUCTIONS
Please read these safety precautions carefully before using the product.
WARNING
Do not place the TV and/or remote control in the following environments:
- A location exposed to direct sunlight
- An area with high humidity such as a bathroom
- Near any heat source such as stoves and other devices that produce heat
- Near kitchen counters or humidifiers where they can easily be exposed to steam or oil
- An area exposed to rain or wind
- Near containers of water such as vases
Otherwise, this may result in re, electric shock, malfunction or product deformation.
Do not place the product where it might be exposed to dust.
This may cause a fire hazard.
Mains Plug is the TV connecting/disconnecting device to AC mains electric supply. This plug
must remain readily attached and operable when TV is in use.
Do not touch the power plug with wet hands. Additionally, if the cord pin is wet or covered
with dust, dry the power plug completely or wipe dust off.
You may be electrocuted due to excess moisture.
Make sure to connect Mains cable to compliant AC mains socket with Grounded earth pin.
(Except for devices which are not grounded on earth.) Otherwise possibility you may be
electrocuted or injured.
Insert power cable plug completely into wall socket otherwise if not secured completely into
socket, fire ignition may break out.
Ensure the power cord does not come into contact with hot objects such as a heater.
This may cause a fire or an electric shock hazard.
Do not place a heavy object, or the product itself, on power cables.
Otherwise, this may result in fire or electric shock.
5
ENGLISH
SAFETY INSTRUCTIONS
Bend antenna cable between inside and outside building to prevent rain from flowing in.
This may cause water damaged inside the Product and could give an electric shock.
When mounting TV onto wall make sure to neatly install and isolate cabling from rear of TV as
to not create possibility of electric shock/fire hazard.
Do not plug too many electrical devices into a single multiple electrical outlet.
Otherwise, this may result in fire due to over-heating.
Do not drop the product or let it fall over when connecting external devices.
Otherwise, this may result in injury or damage to the product.
Desiccant
Keep the anti-moisture packing material or vinyl packing out of the reach of children.
Anti-moisture material is harmful if swallowed. If swallowed by mistake, force the patient to
vomit and visit the nearest hospital. Additionally, vinyl packing can cause suffocation. Keep it
out of the reach of children.
Do not let your children climb or cling onto the TV.
Otherwise, the TV may fall over, which may cause serious injury.
Dispose of used batteries carefully to ensure that a small child does not consume them.
Please seek Doctor- Medical Attention immediately if child consumes batteries.
Do not insert any metal objects/conductors (like a metal chopstick/cutlery/screwdriver)
between power cable plug and input Wall Socket while it is connected to the input terminal
on the wall. Additionally, do not touch the power cable right after plugging into the wall
input terminal.
You may be electrocuted.
(Depending on model)
Do not put or store inflammable substances near the product.
There is a danger of combustion/explosion or fire due to careless handling of the inflammable
substances.
Do not drop metallic objects such as coins, hair pins, chopsticks or wire into the product, or
inflammable objects such as paper and matches. Children must pay particular attention.
Electrical shock, fire or injury can occur. If a foreign object is dropped into the product,
unplug the power cord and contact the service centre.
6
ENGLISH
SAFETY INSTRUCTIONS
Do not spray water on the product or scrub with an inflammable substance (thinner or
benzene). Fire or electric shock accident can occur.
Do not allow any impact, shock or any objects to fall into the unit, and do not drop anything
onto the screen.
You may be injured or the product can be damaged.
Never touch this product or antenna during a thunder or lighting storm.
You may be electrocuted.
Never touch the wall outlet when there is leakage of gas, open the windows and ventilate.
It may cause a fire or a burn by a spark.
Do not disassemble, repair or modify the product at your own discretion.
Fire or electric shock accident can occur.
Contact the service centre for check, calibration or repair.
If any of the following occur, unplug the product immediately and contact your local service
centre.
- The product has been impacted by shock
- The product has been damaged
- Foreign objects have entered the product
- The product produced smoke or a strange smell
This may result in fire or electric shock.
Unplug the TV from AC mains wall socket if you do not intend to use the TV for a long period
of time.
Accumulated dust can cause fire hazard and insulation deterioration can cause electric
leakage/shock/fire.
Apparatus shall not be exposed to dripping or splashing and no objects filled with liquids,
such as vases, shall be placed on the apparatus.
Do not install this product on a wall if it could be exposed to oil or oil mist.
This may damage the product and cause it to fall.
If water enters or comes into contact with TV, AC adapter or power cord please disconnect
the power cord and contact service centre immediately. Otherwise, this may result in electrice
shock or fire.
Only use an authorized AC adapter and power cord approved by LG Electronics. Otherwise,
this may result in fire, electric shock, malfunction or productdeformation.
Never Disassemble the AC adapter or power cord.
This may result in fire or electric shock.
7
ENGLISH
SAFETY INSTRUCTIONS
CAUTION
Install the product where no radio wave occurs.
There should be enough distance between an outside antenna and power lines to keep the
former from touching the latter even when the antenna falls.
This may cause an electric shock.
Do not install the product on places such as unstable shelves or inclined surfaces. Also avoid
places where there is vibration or where the product cannot be fully supported.
Otherwise, the product may fall or flip over, which may cause injury or damage to the
product.
If you install the TV on a stand, you need to take actions to prevent the product from
overturning. Otherwise, the product may fall over, which may cause injury.
If you intend to mount the product to a wall, attach VESA standard mounting interface (optional parts) to the back
of the product. When you install the set to use the wall mounting bracket (optional parts), fix it carefully so as not to
drop.
Only use the attachments / accessories specified by the manufacturer.
When installing the antenna, consult with a qualified service technician. If not installed by a
qualified technician, this may create a fire hazard or an electric shock hazard.
We recommend that you maintain a distance of at least 2 to 7 times the diagonal screen size
when watching TV.
If you watch TV for a long period of time, this may cause blurred vision.
Only use the specified type of battery.
This could cause damage to the remote control.
Do not mix new batteries with old batteries.
This may cause the batteries to overheat and leak.
Batteries should not be exposed to excessive heat. For example, keep away from direct sunlight, open fireplace and
electric heaters .
Do not place non-rechargeable batteries in charging device.
8
ENGLISH
SAFETY INSTRUCTIONS
Make sure there are no objects between the remote control and its sensor.
Signal from Remote Control can be interrupted due to external/internal lighting eg Sunlight,
fluorescent lighting.
If this occurs turn off lighting or darken viewing area.
When connecting external devices such as video game consoles, make sure the connecting
cables are long enough.
Otherwise, the product may fall over, which may cause injury or damage the product.
Do not turn the product On/Off by plugging-in or unplugging the power plug to the wall
outlet. (Do not use the power plug for switch.)
It may cause mechanical failure or could give an electric shock.
Please follow the installation instructions below to prevent the product from overheating.
- The distance between the product and the wall should be more than 10cm.
- Do not install the product in a place with no ventilation (e.g., on a bookshelf or in a
cupboard).
- Do not install the product on a carpet or cushion.
- Make sure the air vent is not blocked by a tablecloth or curtain.
Otherwise, this may result in fire.
Take care not to touch the ventilation openings when watching the TV for long periods as the
ventilation openings may become hot. This does not affect the operation or performance of
the product.
Periodically examine the cord of your appliance, and if its appearance indicates damage or deterioration, unplug
it, discontinue use of the appliance, and have the cord replaced with an exact replacement part by an authorized
servicer.
Prevent dust collecting on the power plug pins or outlet.
This may cause a fire hazard.
Protect the power cord from physical or mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay particular attention to plugs, wall outlets, and
the point where the cord exits the appliance.
Do not press strongly upon the panel with a hand or sharp object such as nail, pencil or pen,
or make a scratch on it, as it may causedamage to screen.
9
ENGLISH
SAFETY INSTRUCTIONS
Avoid touching the screen or holding your finger(s) against it for long periods of time. Doing
so may produce some temporary or permanent distortion/damage to screen.
When cleaning the product and its components, unplug the power first and wipe it with a
soft cloth. Applying excessive force may cause scratches or discolouration. Do not spray with
water or wipe with a wet cloth. Never use glass cleaner, car or industrial shiner, abrasives or
wax, benzene, alcohol etc., which can damage the product and its panel.
Otherwise, this may result in fire, electric shock or product damage (deformation, corrosion
or breakage).
As long as this unit is connected to the AC wall outlet, it is not disconnected from the AC power source even if you
turn off this unit by SWITCH.
When unplugging the cable, grab the plug and unplug it, by pulling at the plug. Don’t pull at
the cord to unplug the power cord from the power board, as this could be hazardous.
When moving the product, make sure you turn the power off first. Then, unplug the power
cables, antenna cables and all connecting cables.
The TV set or power cord may be damaged, which may create a fire hazard or cause electric
shock.
When moving or unpacking the product, work in pairs because the product is heavy.
Otherwise, this may result in injury.
Contact the service centre once a year to clean the internal parts of the product.
Accumulated dust can cause mechanical failure.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
If the product feels cold to the touch, there may be a small “flicker” when it is turned on. This
is normal, there is nothing wrong with product.
The panel is a high technology display product with resolution of two million to six million
pixels. You may see tiny black dots and/or brightly coloured dots (white, red, blue or green)
at a size of 1ppm on the panel. This does not indicate a malfunction and does not affect the
performance and reliability of the product.
This phenomenon also occurs in third-party products and is not subject to exchange or
refund.
10
ENGLISH
SAFETY INSTRUCTIONS
You may find different brightness and colour of the panel depending on your viewing
position(left/right/top/down).
This phenomenon occurs due to the characteristic of the panel.
It is not related with the
product performance, and it is not malfunction.
Displaying a still image (e.g., broadcasting channel logo, on-screen menu, scene from a video game or computer
screen) for a prolonged time may cause damage to the screen, resulting in retention of the image, which is known
as image sticking. It can remain for long time or never disappear. The warranty does not cover the product for image
sticking. Avoid displaying a fixed image on your television’s screen for a prolonged period (1 or more hours for OLED).
Also, if you watch the TV at a ratio of 4:3 for a long time, image sticking may occur on the borders of the panel.
This phenomenon also occurs in third-party products and is not subject to exchange or refund.
Generated Sound
“Cracking” noise: A cracking noise that occurs when watching or turning off the TV is generated by plastic thermal
contraction due to tempera-ture and humidity. This noise is common for products where thermal deformation is
required. Electrical circuit humming/panel buzzing: A low level noise is generated from a high-speed switching
circuit, which supplies a large amount of current to operate a product. It varies depending on the product.
This generated sound does not affect the performance and reliability of the product.
Do not use high voltage electrical goods near the TV(e.g. electric mosquito-swatter). This may result in product
malfunction.
11
ENGLISH
SAFETY INSTRUCTIONS
Viewing 3D Imaging
(Only 3D models)
WARNING
Viewing Environment
Viewing Time
- When watching 3D contents, take 5 - 15 minute breaks every hour. Viewing 3D contents for a long period of time
may cause headache, dizziness, fatigue or eye strain.
Those that have a photosensitive seizure or chronic illness
Some users may experience a seizure or other abnormal symptoms when they are exposed to a flashing light or
particular pattern from 3D contents.
Do not watch 3D videos if you feel nausea, are pregnant and/ or have a chronic illness such as epilepsy, cardiac disorder,
or blood pressure disease, etc.
3D Contents are not recommended to those who suffer from stereo blindness or stereo anomaly. Double images or
discomfort in viewing may be experienced.
If you have strabismus (cross-eyed), amblyopia (weak eyesight) or astigmatism, you may have trouble sensing depth
and easily feel fatigue due to double images. It is advised to take frequent breaks than the average adult.
If your eyesight varies between your right and left eye, revise your eyesight prior to watching 3D contents.
Symptoms which require discontinuation or refraining from watching 3D contents
Do not watch 3D contents when you feel fatigue from lack of sleep, overwork or drinking.
When these symptoms are experienced, stop using/watching 3D contents and get enough rest until the symptom
subsides.
- Consult your doctor when the symptoms persist. Symptoms may include headache, eyeball pain, dizziness,
nausea, palpitation, blurriness, discomfort, double image, visual inconvenience or fatigue.
12
ENGLISH
SAFETY INSTRUCTIONS
CAUTION
Viewing Environment
Viewing Distance
- Maintain a distance of at least twice the screen diagonal length when watching 3D contents. If you feel discomfort
in viewing 3D contents, move further away from the TV.
Viewing Age
Infants/Children
- Usage/ Viewing 3D contents for children under the age of 6 are prohibited.
- Children under the age of 10 may overreact and become overly excited because their vision is in development (for
example: trying to touch the screen or trying to jump into it. Special monitoring and extra attention is required for
children watching 3D contents.
- Children have greater binocular disparity of 3D presentations than adults because the distance between the eyes
is shorter than one of adults. Therefore they will perceive more stereoscopic depth compared to adults for the
same 3D image.
Teenagers
- Teenagers under the age of 19 may react with sensitivity due to stimulation from light in 3D contents. Advise them
to refrain from watching 3D contens for a long time when they are tired.
Elderly
- The elderly may perceive less 3D effect compared to the youth. Do not sit closer to the TV than the recommended
distance.
Cautions when using the 3D glasses
Make sure to use LG 3D glasses. Otherwise, you may not be able to view 3D videos properly.
Do not use 3D glasses instead of your normal glasses, sunglasses or protective goggles.
Using modified 3D glasses may cause eye strain or image distortion.
Do not keep your 3D glasses in extremely high or low temperatures. It will cause deformation.
The 3D glasses are fragile and are easily scratched. Always use a soft, clean piece of cloth when wiping the lenses. Do
not scratch the lenses of the 3D glasses with sharp objects or clean/wipe them with chemicals.
13
ENGLISH
INSTALLATION PROCEDURE
Image shown may differ from your TV.
Your TV’s OSD (On Screen Display) may differ slightly from that shown in this manual.
The available menus and options may differ from the input source or product model that you are using.
New features may be added to this TV in the future.
The TV can be placed in standby mode in order to reduce the power consumption. And the TV should be turned off
if it will not be watched for some time, as this will reduce energy consumption.
The energy consumed during use can be significantly reduced if the level of brightness of the picture is reduced,
and this will reduce the overall running cost.
NOTE
INSTALLATION PROCEDURE
1 Open the package and make sure all the accessories are included.
2 Attach the stand to the TV set.
3 Connect an external device to the TV set.
4 Make sure the network connection is available. You can use the TV network functions only when the network
connection is made.
* If the TV is turned on for the first time after it was shipped from the factory, initialization of the TV may take a few
minutes.
14
ASSEMBLING AND PREPARING
ENGLISH
ASSEMBLING AND PREPARING
Unpacking
Check your product box for the following items. If there are any missing accessories, contact the local dealer where you
purchased your product. The illustrations in this manual may dier from the actual product and item.
Do not use any unapproved items to ensure the safety and product life span.
Any damages or injuries by using unapproved items are not covered by the warranty.
Some models have a thin film attached on to the screen and this must not be removed.
CAUTION
The items supplied with your product may vary depending on the model.
Product specifications or contents of this manual may be changed without prior notice due to upgrade of product
functions.
For an optimal connection, HDMI cables and USB devices should have bezels less than 10 mm thick and 18 mm
width. Use an extension cable that supports USB 2.0 if the USB cable or USB memory stick does not fit into your TV’s
USB port.
*A
<
=
10 mm
*B
<
=
18 mm
Use a certified cable with the HDMI logo attached.
If you do not use a certified HDMI cable, the screen may not display or a connection error may occur. (Recommended
HDMI Cable Types)
- High-Speed HDMI ® / ™Cable (3m or less)
- High-Speed HDMI® / ™ Cable with Ethernet (3m or less)
NOTE
15
ASSEMBLING AND PREPARING
ENGLISH
Magic remote,
Batteries (AA)
(See p. 34)
Owner’s manual Cinema 3D glasses
The number of 3D glasses
may dier depending on
the model or country.
Cable Holder
(See p. 26)
Component gender cable
(See p. 30)
Composite gender cable
(See p. 30)
Scart gender cable
(Depending on model)
(See p. 33)
Stand Screw
5 EA, M4 x L20
(Only 55EG96**)
8 EA, M4 x L20
(Only 65EG96**)
(See p. 20, 22)
Stand Screw
6 EA, M4 x L14
(Only 55EF95**)
(See p. 23)
Stand Assy
(Stand Body / Stand
Base)
(Only 55EG96**)
(See p. 20)
Stand Assy
(Stand Body / Stand
Base)
(Only 65EG96**)
(See p. 21)
Stand Assy
(Stand Body / Stand
Base)
(Only 55EF95**)
(See p. 23)
16
ASSEMBLING AND PREPARING
ENGLISH
Separate purchase
Separate purchase items can be changed or modied for quality improvement without any notication.
Contact your dealer to buy these items.
These devices only work with certain models.
AG-F***
Cinema 3D Glasses
AN-MR600
Magic Remote
AN-VC550
Smart Camera
AG-F***DP
Dual Play Glasses
LG Audio Device
Compatibility
EG96** EF95**
AG-F***
Cinema 3D Glasses
• •
AN-MR600
Magic Remote
• •
AN-VC550
Smart Camera
• •
AG-F***DP
Dual Play Glasses
• •
LG Audio Device • •
The model name or design may be changed depending on the upgrade of product functions, manufacturer’s circum-
stances or policies.
17
ASSEMBLING AND PREPARING
ENGLISH
Parts and buttons
1 Intelligent sensor - Adjusts the image quality and brightness based on the surrounding environment.
2 Joystick Button - This button is located below the TV screen.
You can set the LG Logo Light to on or off by selecting GENERAL in the main menus.
NOTE
Joystick Button
2
Remote Control Sensor
LG Logo Light
Screen
Speakers
Intelligent Sensor
1
(Depending on model)
Joystick Button
2
Remote Control Sensor
LG Logo Light
Screen
Speakers
Intelligent Sensor
1
(Depending on model)
A type : EG96** B type : EF95**
18
ASSEMBLING AND PREPARING
ENGLISH
Using the joystick button
You can simply operate the TV functions, pressing or moving the joystick button up, down, left or right.
Basic Functions
Power On
When the TV is turned o, place your nger on the joystick button
and press it once and release it.
Power O
When the TV is turned on, place your nger on the joystick button
and press it once for a few seconds and release it. All running apps
will close, and any recording in progress will stop.
Volume Control
If you place your nger over the joystick button and move it left or
right, you can adjust the volume level you want.
Programmes Control
If you place your nger over the joystick button and move it up or
down, you can scrolls through the saved programmes you want.
• When your nger over the joystick button and push it to the up, down, left or right, be careful not to press the
joystick button. If you press the joystick button rst, you may not be able to adjust the volume level and saved
programmes.
NOTE
Adjusting the Menu
When the TV is turned on, press the joystick button one time. You can adjust the Menu items moving the joystick button
up, down, left or right.
Turns the power o.
Clears on-screen displays and returns to TV viewing.
Changes the input source.
Accesses the Quick Settings.
19
ASSEMBLING AND PREPARING
ENGLISH
Lifting and moving the TV
Please note the following advice to prevent the TV from
being scratched or damaged and for safe transportation
regardless of its type and size.
Avoid touching the screen at all times, as this may
result in damage to the screen.
CAUTION
It is recommended to move the TV in the box or
packing material that the TV originally came in.
Before moving or lifting the TV, disconnect the power
cord and all cables.
When holding the TV, the screen should face away from
you to avoid damage.
Hold the top and bottom of the TV frame firmly. Make
sure not to hold the transparent part, speaker, or
speaker grill area.
When transporting a large TV, there should be at least 2
people.
When transporting the TV by hand, hold the TV as
shown in the following illustration.
When transporting the TV, do not expose the TV to jolts
or excessive vibration.
When transporting the TV, keep the TV upright, never
turn the TV on its side or tilt towards the left or right.
Do not apply excessive pressure to cause flexing/
bending of frame chassis as it may damage screen.
Be sure to keep your TV upright instead of laying or
tilting it while moving the TV.
When handling the TV, be careful not to damage the
protruding joystick button.
20
ASSEMBLING AND PREPARING
ENGLISH
55EG96**
1
1
1
Stand cover
Protective package
1 When assembling the stand, lay the front screen Protec-
tive package included in the product box on a table or
product box and then place the TV screen face down on
the Protective Package.
Do not lift your TV without the stand. The protrud-
ing Joystick Button may be damaged.
CAUTION
2
Stand assy
3
M4 x L20
5 EA
4
Stand cover
Insert the protruding parts of the Stand Cover into
the holes.
CAUTION
Setting up the TV
Image shown may dier from your TV.
Attaching the stand
21
ASSEMBLING AND PREPARING
ENGLISH
65EG96**
1
Stand cover
1
1
Protective package
1 When assembling the stand, lay the front screen Protec-
tive package included in the product box on a table or
product box and then place the TV screen face down on
the Protective Package.
Do not lift your TV without the stand. The protrud-
ing Joystick Button may be damaged.
CAUTION
2
Stand assy
5
Cover holder
Stand
cover
Insert the Cover Holder of the Stand Cover into the
holes until it clicks. Press the Stand Cover gently so
that the non-woven fabric inside is attached tightly.
CAUTION
22
ASSEMBLING AND PREPARING
ENGLISH
5
Cover holder
Stand
cover
Insert the Cover Holder of the Stand Cover into the
holes until it clicks. Press the Stand Cover gently so
that the non-woven fabric inside is attached tightly.
CAUTION
3
M4 x L20
8 EA
4
Stand cover
Insert the protruding parts of the Stand Cover into
the holes.
CAUTION
23
ASSEMBLING AND PREPARING
ENGLISH
55EF95**
1
Do not lift your TV without the stand. The protrud-
ing Joystick Button may be damaged.
CAUTION
2
Stand Assy
3
M4 x L14
6 EA
4
Stand cover
Insert the protruding parts of the Stand Cover into
the holes.
CAUTION
24
ASSEMBLING AND PREPARING
ENGLISH
Mounting on a table
1 Lift and tilt the TV into its upright position on a table.
- Leave a 10 cm (minimum) space from the wall for
proper ventilation.
10 cm
10 cm
10 cm
10 cm
5 cm
10 cm
2 Connect the power cord to a wall outlet.
Do not place the TV near or on sources of heat, as
this may result in fire or other damage.
CAUTION
5
Cover holder
Stand
cover
Insert the Cover Holder of the Stand Cover into the
holes until it clicks.
CAUTION
Remove the stand before installing the TV on a
wall mount by performing the stand attachment in
reverse.
NOTE
When attaching the stand to the TV set, place the
screen facing down on a cushioned table or flat
surface to protect the screen from scratches.
Make sure that the screws are inserted correctly
and fastened securely. (If they are not fastened
securely enough, the TV may tilt forward after being
installed.)
Do not use too much force and over tighten the
screws; otherwise screw may be damaged and not
tighten correctly.
CAUTION
25
ASSEMBLING AND PREPARING
ENGLISH
Securing the TV to a wall
(This feature is not available for all models.)
To use the desk-type stand safely, make sure to securely
attach it to a wall.
1 Insert and tighten the eye-bolts, or TV brackets and
bolts on the back of the TV.
- If there are bolts inserted at the eye-bolts position,
remove the bolts first.
2 Mount the wall brackets with the bolts to the wall.
Match the location of the wall bracket and the eye-
bolts on the rear of the TV.
3 Connect the eye-bolts and wall brackets tightly with a
sturdy rope.
Make sure to keep the rope horizontal with the at
surface.
Make sure that children do not climb on or hang on
the TV.
CAUTION
Use a platform or cabinet that is strong and large
enough to support the TV securely.
Brackets, bolts and ropes are not provided. You can
obtain additional accessories from your local dealer.
NOTE
Mounting on a wall
Attach an optional wall mount bracket at the rear of the TV
carefully and install the wall mount bracket on a solid wall
perpendicular to the oor. When you attach the TV to other
building materials, please contact qualied personnel.
LG recommends that wall mounting be performed by a
qualied professional installer.
We recommend the use of LG’s wall mount bracket.
When you do not use LG’s wall mount bracket,
please use a wall mount bracket where the device is
adequately secured to the wall with enough space to allow
connectivity to external devices.
10 cm
10 cm
10 cm
10 cm
Make sure to use screws and wall mount bracket that
meet the VESA standard. Standard dimensions for the wall
mount kits are described in the following table.
Separate purchase(Wall Mounting Bracket)
Model 55EG96**
65EG96**
55/65EF95**
VESA
(A x B x C)
200 x 339.7 x 195.3
A
C
B
200 x 330 x 120
A
C
B
Standard
screw
M6
Number of
screws
4
Wall mount
bracket
OTW150
26
ENGLISH
ASSEMBLING AND PREPARING
Disconnect the power first, and then move or
install the TV. Otherwise electric shock may occur.
If you install the TV on a ceiling or slanted wall, it
may fall and result in severe injury.
Use an authorized LG wall mount and contact the
local dealer or qualified personnel.
Do not over tighten the screws as this may cause
damage to the TV and void your warranty.
Use the screws and wall mounts that meet the
VESA standard. Any damages or injuries by misuse
or using an improper accessory are not covered by
the warranty.
CAUTION
Use the screws that are listed on the VESA standard
screw specifications.
The wall mount kit includes an installation manual
and necessary parts.
The wall mount bracket is not provided. You can
obtain additional accessories from your local dealer.
The length of screws may differ depending on the
wall mount. Make sure to use the proper length.
For more information, refer to the manual supplied
with the wall mount.
NOTE
Tidying cables
Image shown may dier from your TV.
Gather and bind the cables with the cable holder.
Cable holder
Do not move the TV by holding the cable holder,
as the cable holder may break, and injuries and
damage to the TV may occur.
CAUTION
27
ENGLISH
MAKING CONNECTIONS
MAKING CONNECTIONS
This section on MAKING CONNECTIONS mainly uses
diagrams for the EG9609 models.
Connect various external devices to the TV and switch
input modes to select an external device. For more infor-
mation on external device’s connection, refer to the manual
provided with each device.
Available external devices are: HD receivers, DVD players,
VCRs, audio systems, USB storage devices, PC, gaming
devices, and other external devices.
The external device connection may differ from the
model.
Connect external devices to the TV regardless of the
order of the TV port.
If you record a TV program on a DVD recorder or
VCR, make sure to connect the TV signal input
cable to the TV through a DVD recorder or VCR. For
more information of recording, refer to the manual
provided with the connected device.
Refer to the external equipment’s manual for
operating instructions.
If you connect a gaming device to the TV, use the
cable supplied with the gaming device.
In PC mode, there may be noise associated with the
resolution, vertical pattern, contrast or brightness.
If noise is present, change the PC output to another
resolution, change the refresh rate to another rate or
adjust the brightness and contrast on the PICTURE
menu until the picture is clear.
In PC mode, some resolution settings may not work
properly depending on the graphics card.
If Ultra HD content is played via PC, the video
or audio may have disruptions intermittently
depending on your PC’s performance.
NOTE
Antenna connection
Wall
antenna
socket
(*Not
provided)
Connect the TV to a wall antenna socket with an RF cable
(75 Ω).
The external device connection may differ from the
model.
Use a signal splitter to use more than 2 TVs.
If the image quality is poor, install a signal amplifier
properly to improve the image quality.
If the image quality is poor with an antenna
connected, try to realign the antenna in the correct
direction.
An antenna cable and converter are Not provided.
Supported DTV Audio: MPEG, Dolby Digital, Dolby
Digital Plus, HE-AAC
For a location that is not supported with Ultra
HD broadcasting, this TV cannot receive Ultra HD
broadcasts directly. This TV cannot receive Ultra HD
(3840 x 2160 pixels) broadcasts directly because
the related standards have not been confirmed.
(Depending on model)
NOTE
28
ENGLISH
MAKING CONNECTIONS
Satellite dish connection
(Only satellite models)
Satellite
Dish
(*Not provided)
Connect the TV to a satellite dish to a satellite socket with a
satellite RF cable (75 Ω).
HDMI connection
HDMI
(*Not
Provided)
DVD / Blu-Ray / PC /
HD Cable Box / HD STB
Transmits the digital video and audio signals from an
external device to the TV. Connect the external device and
the TV with the HDMI cable as shown.
➡
➡
➡
➡
HDMI ULTRA HD Deep
Colour :
On - Support 4K @ 50/60 Hz (4:4:4, 4:2:2, 4:2:0)
O - Support 4K @ 50/60 Hz (4:2:0)
If the device connected to Input Port also supports ULTRA
HD Deep Colour, your picture may be clearer.
However, if the device doesn’t support it, it may not work
properly.
In that case, connect the device to a dierent HDMI port or
change the TV’s HDMI ULTRA HD Deep Colour setting to
O. (This feature is available on certain models which are
supported ULTRA HD Deep Colour only. )
29
ENGLISH
MAKING CONNECTIONS
The external device connection may differ from the
model.
It is recommended to use the TV with the HDMI
connection for the best image quality.
Use the latest High Speed HDMI™ Cable with CEC
(Customer Electronics Control) function.
High Speed HDMI™ Cables are tested to carry an
HD signal up to 1080p and higher.
Supported HDMI Audio format : Dolby Digital
(32Khz, 44.1Khz, 48Khz), DTS(44.1Khz, 48Khz), PCM
(32Khz, 44.1Khz, 48Khz, 96Khz, 192Khz)
NOTE
ARC (Audio return channel)
An external audio device that supports SIMPLINK
and ARC must be connected using HDMI(4K @
60 Hz)/DVI IN 2 (ARC) port.
When connected with a high-speed HDMI cable,
the external audio device that supports ARC
outputs optical SPDIF without additional optical
audio cable and supports the SIMPLINK function.
DVI to HDMI connection
AUDIO OUT
DVI OUT
IN
AV2
( Audio in)
(*Not
Provided)
DVD / Blu-Ray / PC /
HD Cable Box / HD STB
Transmits the digital video signal from an external device
to the TV. Connect the external device and the TV with the
DVI-HDMI cable as shown. To transmit an audio signal,
connect an audio cable.
Depending on the graphics card, DOS mode may
not work if a DVI-HDMI cable is in use.
When using the DVI-HDMI cable , Single link is only
supported.
NOTE
30
ENGLISH
MAKING CONNECTIONS
Component connection
IN
COMPONENT
YP
B
AUDIO
AV2
P
R
VIDEO
VIDEO
AUDIO
LR
GREEN
GREEN
BLUE
BLUE
RED
RED
RED
RED
WHITE
WHITE
WHITE
YELLOW
YELLOW
(Use the composite
gender cable provided.)
GREEN
(Use the component
gender cable provided.)
DVD / Blu-Ray / HD Cable Box
(*Not provided)
Transmits analogue video and audio signals from an exter-
nal device to the TV. Connect the external device and the
TV with a component gender cable as shown.
If cables are not installed correctly, it could cause
this image to display in black and white or with
distorted colours.
NOTE
RED
BLUE
GREEN
RED
Composite connection
VIDEO
MONO
( )
AUDIO
LR
IN
COMPONENT
YP
B
AUDIO
AV2
P
R
VIDEO
RED
RED
RED
WHITE
WHITE
WHITE
YELLOW
YELLOW
YELLOW
YELLOW
(Use the composite gender
cable provided.)
(*Not provided)
DVD / Blu-Ray /
HD Cable Box / VCR
Transmits analog video and audio signals from an external
device to the TV. Connect the external device and the TV
with the composite cable as shown.
31
ENGLISH
MAKING CONNECTIONS
Headphone connection
(*Not provided)
Transmits the headphone signal from the TV to an external
device. Connect the external device and the TV with the
headphone as shown.
AUDIO menu items are disabled when connecting a
headphone.
Optical Digital Audio Out is not available when
connecting a headphone.
Headphone impedance: 16 Ω
Max audio output of headphone: 0.627 mW to 1.334
mW
Headphone jack size: 0.35 cm
NOTE
Audio connection
OPTICAL
AUDIO IN
(*Not provided)
Digital Audio System
You may use an external audio system instead of the built-
in speaker.
Digital optical audio connection
Transmits a digital audio signal from the TV to an external
device. Connect the external device and the TV with the
optical audio cable as shown.
Do not look into the optical output port. Looking at
the laser beam may damage your vision.
Audio with ACP (Audio Copy Protection) function
may block digital audio output.
CAUTION
32
ENGLISH
MAKING CONNECTIONS
USB connection
HDD
(*Not provided)
USB
HUB
(*Not provided)
(*Not provided)
Connect a USB storage device such as a USB ash memory,
external hard drive or a USB memory card reader to the TV
and access the Smart Share menu to use various multime-
dia les.
Some USB Hubs may not work. If a USB device
connected through a USB Hub is not detected,
connect it to the USB IN port on the TV directly.
Connect the external power source if your USB is
needed.
Connecting via USB 3.0 : Some USB device may not
work if it does not meet USB 3.0 standard. In case,
connect it to USB IN 2 or USB IN 3 port.
NOTE
CI module connection
PCMCIA CARD SLOT
(*Not provided)
PCMCIA CARD SLOT
View the encrypted (pay) services in digital TV mode. To
watch pay services, you need to subscribe and get CI/CI+
card from pay TV operator. This feature depends on pay TV
operator.
Check if the CI module is inserted into the PCMCIA
CARD SLOT in the right direction. If the module is
not inserted properly, this can cause damage to the
TV and the PCMCIA CARD SLOT.
If the TV does not display any video and audio when
CI/CI+ CAM is connected, Please contact to pay
service provider which you subscribe.
NOTE
33
ENGLISH
MAKING CONNECTIONS
Euro scart connection
(Use the Scart gender
cable provided
- Depending on model)
(*Not provided)
Transmits the video and audio signals from an external
device to the TV set. Connect the external device and the
TV set with the Scart gender cable as shown.
Output
Type
Current
input mode
AV1
(TV Out
1
)
Digital TV
Digital TV
Analogue TV, AV
Analogue TV
Component
HDMI
1 TV Out : Outputs Analogue TV or Digital TV signals.
Any Euro scart cable used must have a signal shield.
When watching digital TV in 3D imaging mode, only
2D out signals can be output through the SCART
cable.
If you use the Time Machine function on digital TV,
TV out signals cannot be output through the SCART
cable.
NOTE
34
ENGLISH
MAGIC REMOTE FUNCTIONS
MAGIC REMOTE FUNCTIONS
When the message “Magic Remote battery is low. Change the battery.” is displayed, replace the battery.
To replace batteries, open the battery cover, replace batteries (1.5 V AA) matching and ends to the label inside the
compartment, and close the battery cover. Be sure to point the remote control toward the remote control sensor on the TV.
To remove the batteries, perform the installation actions in reverse.
Do not mix old and new batteries, as this may damage the remote control.
CAUTION
6
mno
9
wxyz
3
def
2
abc
1
. @
4
ghi
8
tuv
7
pqrs
0
5
jkl
GUIDE
LIST
INFO
EXIT
TEXT
T.OPT
SUBT.
(POWER) Turns the TV on or o.
(INPUT) Changes the input source.
* Pressing and holding the button displays all the lists of external inputs.
Number buttons Enters numbers.
Accesses the saved programmes list.
(Space) Opens an empty space on the screen keyboard.
Views the information of the current programmes and screen.
Adjusts the volume level.
P Scrolls through the saved programmes.
(MUTE) Mutes all sounds.
* By pressing and holding the button, audio descriptions function will be
enabled. (Depending on model)
(HOME) Accesses the Home menu.
(BACK) Returns to the previous screen.
Clears on-screen displays and returns to Last Input viewing.
35
ENGLISH
MAGIC REMOTE FUNCTIONS
6
mno
9
wxyz
3
def
2
abc
1
. @
4
ghi
8
tuv
7
pqrs
0
5
jkl
GUIDE
LIST
INFO
EXIT
TEXT
T.OPT
SUBT.
Wheel (OK) Press the center of the Wheel button to select a menu. You can
change programmes by using the wheel button.
Navigation buttons (up/down/left/right)
Press the up, down, left or right button to scroll the menu.
If you press buttons while the pointer is in use, the pointer will disappear
from the screen and Magic Remote will operate like a general remote control.
To display the pointer on the screen again, shake Magic Remote to the left and
right.
Shows programme guide.
(Screen Remote) Displays the Screen Remote.
*Accesses the Universal Control Menu. (Depending on model)
Used for viewing 3D video. (Depending on model)
(Voice recognition)
(Depending on model)
Network connection is required to use the voice recognition function.
1. Press the voice recognition button.
2. Speak when the voice display window appears on the left of the TV screen.
Use the Magic Remote no further than 10 cm from your face.
The voice recognition may fail when you speak too fast or too slowly.
The recognition rate may vary depending on the user’s characteristics (voice,
pronunciation, intonation, and speed) and the environment (noise and TV
volume).
(Q. Settings) Accesses the Quick Settings.
* Pressing and holding the button displays the Advanced menu.
Coloured buttons These access special functions in some menus.
( : Red, : Green, : Yellow, : Blue)
TELETEXT buttons( , )
These buttons are used for teletext.
Recalls your preferred subtitle in digital mode.
36
ENGLISH
MAGIC REMOTE FUNCTIONS
Precautions to Take when
Using the Magic Remote
Use the remote control within the specified range
(within 10 m).
You may experience communication failures when
using the device outside the coverage area or if there
are obstacles within the coverage area.
You may experience communication failures depending
on the accessories.
Devices such as a microwave oven and wireless LAN
operate in the same frequency band (2.4 GHz) as the
Magic Remote. This may cause communication failures.
The Magic Remote may not work properly if a wireless
router (AP) is within 1 meter of the TV.
Your wireless router should be more than 1 m away
from the TV.
Do not disassemble or heat the battery.
Do not drop the battery. Avoid extreme shocks to the
battery.
Inserting the battery in the wrong way may result in
explosion.
Registering magic remote
How to register the magic remote
BACK
HOME
P
MY APPS
(Wheel)
To use the Magic Remote, rst pair it
with your TV.
1 Put batteries into the Magic Remote
and turn the TV on.
2 Point the Magic Remote at your TV
and press the Wheel (OK) on the
remote control.
* If the TV fails to register the Magic
Remote, try again after turning the TV
o and back on.
How to deregister the magic remote
(BACK)
(Home)
Press the (BACK) and (HOME)
buttons at the same time, for ve
seconds, to unpair the Magic Remote
with your TV.
* Pressing and holding the button
will let you cancel and re-register Magic
Remote at once.
How to use magic remote
Shake the Magic Remote slightly
to the right and left or press
(HOME), (INPUT), buttons
to make the pointer appear on the
screen.
(In some TV models, the pointer will
appear when you turn the Wheel
(OK) button.)
If the pointer has not b een used for
a certain period of time or Magic
Remote is placed on a flat surface,
then the pointer will disappear.
If the pointer is not responding
smoothly, you can reset the pointer
by moving it to the edge of the
screen.
The Magic Remote depletes
batteries faster than a normal remote
due to the additional features.
37
ENGLISH
USING THE USER GUIDE
USING THE USER GUIDE
User Guide allows you to more easily access the detailed TV
information.
1 Press the (Home) button to access the Home
menu.
2 Select User Guide and press the Wheel(OK)
button.
38
MAINTENANCE
ENGLISH
MAINTENANCE
Cleaning your TV
Clean your TV regularly to keep the best performance and to extend the product lifespan.
Make sure to turn the power off and disconnect the power cord and all other cables first.
When the TV is left unattended and unused for a long time, disconnect the power cord from the wall outlet to
prevent possible damage from lightning or power surges.
CAUTION
Screen, frame, cabinet and stand
To remove dust or light dirt, wipe the surface with a dry, clean, and soft cloth.
To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild detergent. Then
wipe immediately with a dry cloth.
Avoid touching the screen at all times, as this may result in damage to the screen.
Do not push, rub, or hit the screen surface with your fingernail or a sharp object, as this may result in scratches and
image distortions.
Do not use any chemicals as this may damage the product.
Do not spray liquid onto the surface. If water enters the TV, it may result in fire, electric shock, or malfunction.
CAUTION
Power cord
Remove the accumulated dust or dirt on the power cord regularly.
39
TROUBLESHOOTING / SPECIFICATIONS
ENGLISH
TROUBLESHOOTING
Problem Solution
Cannot control the
TV with the remote
control.
Check the remote control sensor on the product and try again.
Check if there is any obstacle between the product and the remote control.
Check if the batteries are still working and properly installed ( to , to ).
No image display and
no sound is produced.
Check if the product is turned on.
Check if the power cord is connected to a wall outlet.
Check if there is a problem in the wall outlet by connecting other products.
The TV turns o sud-
denly.
Check the power control settings. The power supply may be interrupted.
Check if the Automatic Standby (Depending on model) / Sleep Timer / Timer Power off
feature is activated in the TIMERS settings.
If there is no signal while the TV is on, the TV will turn off automatically after 15 minutes of
inactivity.
When connecting to
the PC (HDMI/DVI),
‘No signal’ or ‘Invalid
Format’ is displayed.
Turn the TV off/on using the remote control.
Reconnect the HDMI cable.
Restart the PC with the TV on.
SPECIFICATIONS
(Only EG96**, EF95**)
Wireless module(LGSBW41)Specications
Wireless LAN Bluetooth
Standard IEEE 802.11a/b/g/n Standard Bluetooth Version 4.0
Frequency Range
2400 to 2483.5MHz
5150 to 5250 MHz
5725 to 5850 MHz(for Non EU)
Frequency Range 2400 to 2483.5MHz
Output Power
(Max.)
802.11a: 13 dBm
802.11b: 15 dBm
802.11g: 14 dBm
802.11n - 2.4GHz: 16 dBm
802.11n - 5GHz: 16 dBm
Output Power
(Max.)
10dBm or Lower
Because band channel used by the country could be different, the user can not change or adjust the operating
frequency and this product is set for the regional frequency table.
This device should be installed and operated with minimum distance 20 cm between the device and your body. And
this phrase is for the general statement for consideration of user environment.
0197
0197
40
ENGLISH
SPECIFICATIONS
Product specications may be changed without prior notice due to upgrade of product functions.
MODELS
EG96**
55EG960V-ZA
55EG9609-ZA
65EG960V-ZA
65EG9609-ZA
Dimensions
Depth(D)
Thickness(T)
Profondità(P)
Spessore(S)
With stand (mm)
(W x H x D)
1226 x 760 x 213 1447 x 884 x 237
Without stand (mm)
(W x H x T(D))
1226 x 719 x 49.9(87.6) 1447 x 842 x 49.9(102.3)
Weight
With stand (kg)
18.9 26.5
Without stand (kg)
15.3 21.3
Power requirement 390 W 500 W
Power consumption AC 100-240 V ~ 50/60 Hz AC 100-240 V ~ 50/60 Hz
MODELS
EF95**
55EF950V-ZA
55EF9509-ZA
65EF950V-ZA
65EF9509-ZA
Dimensions
(W x H x D)
With stand (mm)
1228 x 760 x 215 1450 x 883 x 236
Without stand (mm)
1228 x 718 x 49.9 1450 x 842 x 49.9
Weight
With stand (kg)
17.2 24.5
Without stand (kg)
13.7 19.9
Power requirement
390 W 500 W
Power consumption AC 100-240 V ~ 50/60 Hz AC 100-240 V ~ 50/60 Hz
CI Module Size (W x H x D) 100.0 mm x 55.0 mm x 5.0 mm
Environment
condition
Operating Temperature 0 °C to 40 °C
Operating Humidity Less than 80 %
Storage Temperature -20 °C to 60 °C
Storage Humidity Less than 85 %
Digital TV Analogue TV
Television system
DVB-T/T2*
DVB-C
DVB-S*/S2*
PAL/SECAM B/G/I/D/K
SECAM L/L’
Programme coverage
VHF, UHF
C-Band*, Ku-Band*
VHF: E2 to E12,
UHF : E21 to E69,
CATV: S1 to S20,
HYPER: S21 to S47
Maximum number of storable programmes DVB-S/S2 : 6,000
DVB-T/T2/C & Analogue TV : 1,500
External antenna impedance 75 Ω
*Only DVB-T2/C/S/S2 Support models.
41
ENGLISH
REGULATORY
REGULATORY
LG Recycling Policy (Only EU)
LG Electronics oers a customized e-waste take-back & recycling service that meets local needs and requirements in the
countries where e-waste regulations are in place, and also provides product and packaging take-back & recycling service
voluntarily in some countries. LG Electronics evaluates products’ recyclability at the design step using LG’s recyclability
evaluation tool, with the goal of improving recyclability where practicable. Through these activities, LG seeks to contribute
to conserving natural resources and protecting the environment.
For more information about the LG Recycling Policy, please visit our global site at http://www.lg.com/global/sustainability/
environment/take-back-recycling
Energy Saving
Energy eciency cuts energy consumption and thus saves money by reducing electricity bills. The following indications
allow to reduce power consumption when the television is not being watched:
Turning the television off at its mains supply, or un-plugging it, will cut energy use to zero for all televisions, and is
recommended when the television is not being used for a long time, e.g. when on holiday,
Putting the television into standby mode, will reduce energy consumption, but will still draw some power,
Reducing the brightness of the screen will reduce energy use.
Isolator (Only Sweden, Norway)
“Equipment connected to the protective earthing of the building installation through the mains connection or through
other equipment with a connection to protective earthing - and to a cable distribution system using coaxial cable, may
in some circumstances create a fire hazard. Connection to a cable distribution system has therefore to be provided
through a device providing electrical isolation below a certain frequency range (galvanic isolator, see EN 60728-11)”
“Utrustning som är kopplad till skyddsjord via jordat vägguttag och/eller via annan utrustning och samtidigt är kopplad
till kabel-TV nät kan i vissa fall medföra risk för brand.
För att undvika detta skall vid anslutning av utrustningen till kabel-TV nät galvanisk isolator finnas mellan utrustningen
och kabel-TV nätet.”
“Utstyr som er koplet til beskyttelsesjord via nettplugg og/eller via annet jordtilkoplet utstyr - og er tilkoplet et kabel-
TV nett, kan forårsake brannfare.
For å unngå dette skal det ved tilkopling av utstyret til kabel-TV nettet installeres en galvanisk isolator mellom utstyret
og kabel-TV nettet.”
42
ENGLISH
REGULATORY
EU ecolabel (Only EU ecolabel applied model)
Better for the environment...
High Energy Efficiency
Reduced CO2 emissions
Designed to facilitate repair and recycling
... better for you.
EU Ecolabel : PL/22/004
LGE announced the ‘LG Declaration for a Cleaner Environment ‘in 1994, and this ideal has served as a Guiding managerial
principle ever since. The Declaration is a foundation that has allowed us to undertaike Environmentally friendly activities in
careful consideration of economic, environmental, and social aspects. We promote activities for environmental preserva-
tion, and we specically develop our products to embrace the Concept of environment- friendly through whole process
from getting raw materials, production, transportation, usage and end-of-life. These environmental characteristics are
endorsed by the award of the European Commission as approval of the product environmental status for energy saving.
Facilities for recycling and a host of other features.
The full list of criteria and more information on the eco label can be found at the web-site address : http://www.ecolabel.eu
Restriction of Hazardous Substances (Only Ukraine)
Обмеження України на наявність небезпечних речовин
The equipment complies with requirements of the Technical Regulation, in terms of restrictions for the use of certain
dangerous substances in electrical and electronic equipment.
Устаткування відповідає вимогам технічного регламенту щодо обмеженного використання небезпечних речовин
в електричному і електронному обладнанні.
Packing Information (Only Russia, Kazakhstan, Belarus)
Русский
Символ «не для пищевой продукции» применяется в соответствие с техническим регламентом Таможенного союза
«О безопасности упаковки» 005/2011 и указывает на то, что упаковка данного продукта не предназначена для
повторного использования и подлежит утилизации. Упаковку данного продукта запрещается использовать для
хранения пищевой продукции.
Қазақша
Символ Кедендік одақтың 005/2011 техникалық регламентіне сәйкес қолданылады және осы өнімнің қаптамасын
екінші рет пайдалануға арналмағанын және жоюға жататынын көрсетеді. Осы өнімнің қаптамасын азық-түлік
өнімдерін сақтау үшін пайдалануға тыйым салынады.
Русский
Символ «петля Мебиуса» указывает на возможность утилизации упаковки. Символ может быть дополнен
обозначением материала упаковки в виде цифрового и/или буквенного обозначения.
Қазақша
Символ қаптаманы жою мүмкіндігін көрсетеді. Символ сандық код және/немесе әріп белгілері түріндегі қаптама
материалының белгісімен толықтырылуы мүмкін.
Record the model number and serial number of
the TV.
Refer to the label on the back cover and quote
this information to your dealer when requiring
any service.
MODEL
SERIAL
Please contact LG First.
If you have any inquiries or comments,
please contact LG customer information centre.
LG Customer Information Centre
Country
Service
Country
Service
Österreich 0 810 144 131 Nederland 0900 543 5454
België 015 200 255 Norge 800 187 40
Luxembourg 0032 15 200255 Polska 801 54 54 54
България
07001 54 54 Portugal 808 78 54 54
Česká Rep. 810 555 810 România 031 228 3542
Danmark 8088 5758 Slovensko 0850 111 154
Suomi 0800 0 54 54 España 963 05 05 00
France
3220 dites LG ou tapez 54
Sverige 0770 54 54 54
Deutschland
01806 11 54 11
(0,20€ pro Anruf aus
dem Festnetz der DTAG;
Mobilfunk: max. 0,60€
pro Anruf.)
Schweiz 0848 543 543
Ελλάδα
801 11 200 900,
210 4800 564
United Kingdom
0344 847 5454
Россия
8 800 200 7676
Magyarország
06 40 54 54 54 Eesti 800 9990
Éire 01 686 9454
Украина
0 800 303 000
Italia 199600099
Казахстан
8 8000 805 805,
2255(GSM)
Беларусь
8 820 0071 1111
Latvija 80200201
Узбекистaн
8 800 120 2222
Lietuva 880008081
Кыргызстан
8 0000 710 005
Türkiye
444 6 543
www.lg.com
