Quick Reference
Table of Contents:
Pages Before you start
Cutout dimensions
Clearance dimensions
Product dimensions
Tools and materials needed
Parts supplied
Electrical requirements
Gas supply requirements
Venting requirements
Installation steps
Gas conversions
Cooktop removal
Need assistance?
Check your Use and Care Guide for a toll-free number to call, or
call the dealer from whom you purchased the cooktop when you:
Have questions about the cooktop installation or operation.
Need to obtain the name and number of an authorized service
company.
The dealer is listed in the Yellow Pages of your phone directory
under “Appliances — Household — Major — Service and Repair.”
When you call, you will need:
The cooktop model number.
The cooktop serial number.
Both numbers are listed on the model/serial rating plate, located
on the bottom of the right side of the downdraft plenum.
Write both numbers down now before installing cooktop.
Model # Serial #
If removing the cooktop is necessary for
cleaning or maintenance:
1. Shut off gas supply.
2. Disconnect gas and electrical supplies.
3. Disconnect vent system from unit inside
cabinet.
4. Lift cooktop out of countertop to complete
cleaning or maintenance.
Part No. 8101P350-60/8284676
© 2000 Whirlpool Corporation
Benton Harbor, Michigan 49022
Printed in U.S.A.
1
1
1
2
2
2
2
3
34
56
7
Back cover
IMPORTANT:
Read and save these instructions.
Installation Instructions
IMPORTANT:
Installer: Leave Installation Instructions with the homeowner.
Homeowner: Keep Installation Instructions for future reference.
Save Installation Instructions for local electrical inspector's use.
Part No.
8101P350-60/
8284676
If cooktop does not
operate:
Check that circuit breaker is not tripped or
the house fuse blown.
Check that the power supply cord is
plugged into the wall receptacle.
Check that the gas supply valves are
turned to the “ON” position.
See Use and Care Guide for
troubleshooting list.
If you need assistance:
Check your Use and Care Guide for a toll-free
number to call, or call the dealer from whom
you purchased this appliance. The dealer is
listed in the Yellow Pages of your phone
directory under “Appliances — Household —
Major — Service and Repair.”
When you call, you will need the cooktop
model number and serial number. Both
numbers can be found on the model/serial
rating plate located on the bottom of the
burner box.
Cooktop removal
After cleaning and maintenance:
1. Reinstall cooktop in cutout.
2. Check that front edge of cooktop is parallel
to front edge of countertop.
3. Connect gas and electrical supplies.
4. Connect vent system.
30" GAS
Downdraft Cooktop
Modules selected at time of purchase.
