User Manual Bosch SMP68M05AU Serie 6 Under Bench Dishwasher

Documents for Bosch SMP68M05AU

User Manual

For SMP68M05AU. Series: Serie 6
Also, The document are for others Bosch models: SM…, SB…

• 8 Intended use2
  • Intended use2
  • ( Safety instructions2
    • Safety instructions2
    • Before you switch ON the appliance2
    • Delivery3
      • 1. Check the packaging and dishwasher immediately for damage caused in transit. Do not switch on a damaged appliance, but contact your supplier.3
      • 2. Please dispose of the packaging material in an environmentally friendly manner.3
      • 3. Do not let children play with packaging and its parts. There is a risk of suffocation from collapsible boxes and film.3
    • Installation3
    • In daily use4
    • Childproof lock (door lock)Door lock *4
    • Damage4
    • Disposal4
      • 1. Make redundant appliances unusable to prevent subsequent accidents.4
      • 2. Dispose of the appliance in a n environmentally friendly manner.4
      • m Warning5
      • Risk of injury!5
      • m Warning5
      • Risk of explosion!5
      • m Warning5
      • Risk of scalding!5
      • m Warning5
      • Risks to children!5
  • 7 Protection of the environment6
    • Protection of the environment6
    • Packaging6
    • Old appliances6
  • * Getting to know your appliance7
    • Getting to know your appliance7
    • Control panel7
    • Appliance interior7
    • Overview of menu7
  • , Rinse aid8
    • Rinse aid8
      • 1. Open the dispenser 1j by pressing and lifting the plate on the cover.8
      • 2. Carefully pour rinse aid up to the max. mark in the filler opening.8
      • 3. Close cover until it clicks shut.8
      • 4. To prevent excessive foam formation during the next rinse cycle, remove any rinse aid which has run over with a cloth.8
    • Setting amount of rinse aid8
      • 1. Open the door.8
      • 2. Switch on ON/OFF switch (.8
      • 3. Hold down programme button # and press START button X until š:‹.... is indicated on the digital display.8
      • 4. Release both buttons.8
      • 5. Press programme button # until the factory set value §:‹† is indicated on the digital display `.8
      • To change the setting:8
        • 1. Press programme button 3.8
        • 2. Press START button X.8
        • 3. Close the door.8
    • Switching off rinse aid refill indicator9
  • - Utensils9
    • Utensils9
    • Not suitable9
    • Glass and utensil damage9
    • Loading the dishwasher9
      • 1. Remove large food remnants. It is not necessary to prerinse utensils under running water.9
      • 2. Place the utensils so that9
    • Unloading the dishwasher10
      • Note10
    • Cups and glasses10
      • Note10
    • Pans10
      • Tip10
      • Tip11
    • Cutlery basket11
    • Cutlery drawer11
    • Folding spikesFolding spikes *12
    • Small accessories holder *Small accessories holder12
    • Adjusting the height of the basket12
      • Appliance height 81.5 cm12
  • 16 cm12
  • 30 cm12
  • 18.5 cm12
  • 27.5 cm12
  • 21 cm12
  • 25 cm12
    • Appliance height 86.5 cm12
  • 18 cm12
  • 33 cm12
  • 20.5 cm12
  • 30.5 cm12
  • 23 cm12
  • 28 cm12
    • 1. Pull out the top basket 12 out.12
    • 2. To lower the basket, press in the left and then the right lever on the outside of the basket. In doing so, hold the sides of the basket along the upper edge to prevent it from suddenly dropping.12
    • 3. To raise the basket, hold the basket on the sides of the upper edge and lift it up.12
    • 4. Before re-inserting the basket again, ensure that it is at the same height on both sides. Otherwise, the appliance door cannot be closed and the upper spray arm will not be connected to the water circuit.12
    • . Detergent13
      • Detergent13
      • Note13
        • m Warning13
      • Adding detergent13
        • 1. If the detergent dispenser 9" is still closed, press the lock 9* to open the detergent dispenser.13
        • 2. Close the cover on the detergent dispenser by sliding it up until the lock engages without difficulty.13
        • Tip14
          • m Warning14
          • m Warning14
        • Notes14
• / Overview of programmes15
  • Overview of programmes15
  • The max. possible number of programmes is illustrated in this overview. The corresponding programmes for your appliance can be found on the fascia. The programme data has been measured in the laboratory according to AS/NSZ 2007.15
    • Type of utensils and soiling15
    • Programm15
    • Programme data15
    • 1.) Duration: hs/ mins15
    • 2.) Energy consumption in kWh15
    • 3.) Water consumption in litres15
    • 4.) With Aquasensor15
    • Possible additional options15
    • Programme sequence15
    • Programme selection16
    • Information for test institutes16
    • 0 Additional options17
      • Additional options17
      • Express Wash/ Speed Perfect (VarioSpeed)Ÿ Express Wash/ Speed Perfect/ (VarioSpeed) *17
      • Half load§ Half load *17
      • µ HygienePlus *HygienePlus17
      • Ï Intensive zone *Intensive zone17
      • ¿ Extra drying *Extra drying17
    • 1 Operating the appliance18
      • Operating the appliance18
      • Aqua sensorAqua sensor *18
      • Switching on the appliance18
        • 1. Turn on the tap fully.18
        • 2. Open the door.18
        • 3. Switch on ON/OFF switch (.18
        • 4. Press the START button X.18
        • 5. Close the door.18
      • Optical display while the programme is runningOptical display while the programme is running *18
        • 1. Open the door.18
        • 2. Switch on ON/OFF switch (.18
        • 3. Hold down programme button # and press START button X until š:‹.... is indicated on the digital display.18
        • 4. Release both buttons.18
        • 5. Press programme button # until the factory set value ‚:‹‚ is indicated on the digital display `.18
        • To change the setting:18
          • 1. By pressing the button 3, you can switch the function off ‚:‹‹ or on ‚:‹‚.18
          • 2. Press START button X.18
          • 3. Close the door.18
      • Remaining running time display19
      • Timer programmingTimer programming *19
        • 1. Open the door.19
        • 2. Switch on ON/OFF switch (.19
        • 3. Press button H + until the digital display ` jumps to œ:‹‚.19
        • 4. Press H + or – button until the displayed time corresponds with your requirements.19
        • 5. Press START button X, timer programming is activated.19
        • 6. To delete timer programming, press the H + or – button until ` œ:‹‹ is indicated on the digital display.19
        • 7. Close the door.19
      • End of programme19
        • 1. Open the door.19
        • 2. Switch on ON/OFF switch (.19
        • 3. Hold down programme button # and press START button X until š:‹.... is indicated on the digital display.19
        • 4. Release both buttons.19
        • 5. Press programme button # until the factory set value ›:‹ƒ is indicated on the digital display `.19
        • To change the setting:19
          • 1. Press programme button 3. Each time the button is pressed, the set value increases by one level; when the value of ›:‹„ has been reached, the display jumps back to ›:‹‹ (off).19
          • 2. Press START button X, the set value is saved.19
          • 3. Close the door.19
      • Automatic switch off after end of programme or interior light*Automatic switch off / interior light20
        • 1. Open the door.20
        • 2. Switch on ON/OFF switch (.20
        • 3. Hold down programme button # and press START button X until š:‹... is indicated on the digital display.20
        • 4. Release both buttons.20
        • 5. Keep pressing programme button # until the value ˜:‹... is indicated on the numerical display `.20
        • To change the setting:20
          • 1. Press programme button 3.20
          • 2. Press START button X.20
          • 3. Close the door.20
      • Switching off the appliance20
        • 1. Open the door.20
        • 2. Switch off ON/OFF switch (.20
        • 3. Turn off the tap (not applicable if Aqua-Stop fitted).20
        • 4. Remove the utensils when they have cooled down.20
        • Note20
      • Interrupting the programme21
        • 1. Open the door.21
        • 2. Switch off ON/OFF switch (.21
        • 3. To continue the programme, switch on the ON/OFF switch ( again.21
        • 4. Close the door.21
      • Terminating the programmeTerminating the programme (Reset)21
        • 1. Open the door.21
        • 2. Press START button X for approx. 3 sec.21
        • 3. Close the door.21
        • 4. Open the door.21
        • 5. Switch off ON/OFF switch (.21
        • 6. Close the door.21
      • Changing the programme21
      • Intensive drying21
        • 1. Open the door.21
        • 2. Switch on ON/OFF switch (.21
        • 3. Hold down programme button # and press START button X until š:‹.... is indicated on the digital display.21
        • 4. Release both buttons.21
        • 5. Press programme button # until the factory set value š:‹‹ is indicated on the digital display `.21
        • To change the setting:21
          • 1. Press the button 3 to switch the Intensive drying on š:‹‚ or off š:‹‹.21
          • 2. Press START button X.21
          • 3. Close the door.21
    • 2 Cleaning and maintenance22
      • Cleaning and maintenance22
      • Overall condition of the machine22
        • m Warning22
          • Health hazard22
      • Rinse aid22
      • Filters22
        • 1. After each washing cycle check the filters for residue.22
        • 2. Unscrew filter cylinder as illustrated and take out filter system.22
        • 3. Remove any residue and clean filters under running water.23
        • 4. Re-install filter system in reverse sequence and ensure that the arrow marks are opposite each other after closing the filter system.23
      • Spray arms23
        • 1. Check outlet nozzles on the spray arms for blockages.23
        • 2. Unscrew the upper spray arm 1:.23
        • 3. Remove the lower spray arm 1J upwards.23
        • 4. Clean spray arms under running water.23
        • 5. Re-engage or screw on spray arms.23
    • 3 Fault, what to do?23
      • Fault, what to do?23
      • Note23
        • m Warning23
      • Waste water pump23
        • m Warning23
          • Risk of cuts!23
            • 1. First always disconnect the appliance from the power supply.24
            • 2. Take out top basket 12 and bottom basket 1b.24
            • 3. Remove the filters 1R.24
            • 4. Scoop out water, use a sponge if required.24
            • 5. Prise out the white pump cover (as illustrated) using a spoon. Grip the cover on the crosspiece and lift diagonally inwards. Remove cover completely.24
            • 6. Check impeller wheel and remove any foreign objects.24
            • 7. Place cover in the original position and press down until it engages (click).24
            • 8. Install filters.24
            • 9. Re-insert baskets.24
  • Fault table25
    • Fault25
    • Cause25
    • Remedial action25
    • 4 Customer service32
      • Customer service32
    • 5 Installation and connection32
      • Installation and connection32
        • 1. Checking appliance on delivery32
        • 2. Installing the appliance32
        • 3. Waste water connection32
        • 4. Drinking water connection32
        • 5. Electrical connection32
      • Product package32
      • Safety instructions32
      • Delivery33
      • Technical specifications33
      • Installation33
      • Waste-water connection33
        • 1. The required work sequence can be found in the installation instructions. If required, fit a siphon with an drainage connection.33
        • 2. Connect the waste-water hose to the drainage connection of the siphon with the enclosed parts.33
      • Drinking water connection34
        • 1. Fasten the drinking water connection to the tap according to the installation instructions using the enclosed parts.34
        • 2. When replacing the appliance, always use a new water supply hose.34
      • Warm water connection *Warm water connection34
        • Setting hot water:34
          • 1. Open the door.34
          • 2. Switch on ON/OFF switch (.34
          • 3. Hold down programme button # and press START button X until š:‹... is indicated on the digital display.34
          • 4. Release both buttons.34
          • 5. Press programme button # until the factory set value ‘:‹‹ is indicated on the digital display `.34
        • To change the setting:34
          • 1. By pressing the 3 button, you can switch the hot water setting off ‘:‹‹ or on ‘:‹‚.34
          • 2. Press START button X.34
          • 3. Close the door.34
      • Electrical connection35
      • Removing the appliance35
        • 1. Disconnect the appliance from the power supply.35
        • 2. Turn off the water supply.35
        • 3. Undo the waste water and drinking water connection.35
        • 4. Loosen fastening screws for the furniture parts.35
        • 5. If fitted, remove the base panel.35
        • 6. Pull out the appliance, carefully pulling the hose behind.35
      • Transportation36
        • Drain the appliance according to the following steps:36
          • 1. Turn on the tap.36
          • 2. Open the door.36
          • 3. Switch on ON/OFF switch (.36
          • 4. Select programme with the highest temperature.36
          • 5. Press START button X.36
          • 6. Close the door.36
          • 7. Open door after approx. 4 minutes.36
          • 8. Press START button X until ‹:‹‚ is indicated on the digital display.36
          • 9. Close the door.36
          • 10. Open door after approx. 1 minute.36
          • 11. Switch off ON/OFF switch (.36
          • 12. Turn off the tap, disconnect supply hose and drain water.36
      • Protection against frostProtection against frost (Emptying the appliance)36
