Washer Dimensions: Undercounter installation -
washer only:
W10631155B1
03/17
Front-Loading Washer
Recessed or closet installation -
stacked washer and dryer
38
3
/4" - 39
3
/4"
(948 mm - 1010 mm)
27"
(686 mm)
32
15
/16"
(837 mm)
52
15
/16"
(1345 mm)
76
1
/2"
(1943 mm)
5"
(127 mm)
6"
(152 mm)
1"
(25 mm)
24 in.
2
(155 cm
2
)
48 in.
2
(310 cm
2
)
3"
(76 mm)
6"
(152 mm)
3"
(76 mm)
Recessed area or closet installation (washer only):
1"
(25 mm)
24 in.
2
(155 cm
2
)
48 in.
2
(310 cm
2
)
3"
(76 mm)
3"
(76 mm)
4"
(102 mm)
*Add spacing of 1" (25 mm) on all sides of washer.
*Add spacing of 1" (25 mm) on all sides of washer/dryer.
Because Whirlpool Corporation policy includes a continuous commitment to improve Dimensions are for planning purposes only. For complete details, see Installation
our products, we reserve the right to change materials and specications without notice. Instructions packed with product. Specications subject to change without notice.
ELECTRICAL REQUIREMENTS
A 120-volt, 60-Hz., AC only, 15- or 20-amp fused electrical supply is required. A time-delay fuse or circuit breaker is recommended.
It is recommended that a separate circuit serving only this appliance be provided.
Floor drain system requires a Siphon Break Kit (Part Number
285834), 2 Connector Kits (Part Number 285835), and an
Extension Drain Hose (Part Number 285863) that may be
purchased separately. See “Alternate Parts”. Minimum siphon
break height: 28" (710 mm) from bottom of washer. Additional
hoses may be needed.
Minimum diameter for a standpipe drain: 2" (51 mm). Minimum
carry-away capacity: 17 gal. (64 L) per minute. A 1/4" (6 mm)
diameter to 1" (25 mm) diameter Standpipe Adapter Kit is
available (Part Number 3363920). Top of standpipe must be at
least 30" (762 mm) high; install no higher than 96" (2.44 m) from
bottom of washer. If you have an overhead sewer and need to
pump higher than 96" (2.44 m), a sump pump and associated
hardware are needed. See “Alternate Parts”.
Wall standpipe drain system
Laundry tub drain system
Minimum capacity: 20 gal. (76 L). Top of laundry tub must
be at least 30" (762 mm) above oor; install no higher than
96" (2.44 m) from bottom of washer.
4.5"
(114 mm)
Floor standpipe drain system
4.5"
(114 mm)
See requirements for oor standpipe drain system.
30"
(762 mm)
min.
4.5"
(114 mm)
Floor drain system
D
RAIN SYSTEM
Drain system can be installed using a floor drain, wall standpipe, floor standpipe, or laundry tub. Select method you need.
IMPORTANT: To avoid siphoning, only 4.5" (114 mm) of drain hose should be inside standpipe. Always secure drain
hose with a cable tie.
4"
(102 mm)
1"
(25 mm)
7"
(178 mm)
14"
(356 mm)
Custom cabinet installation (washer only):
**Recommended 4" (102 mm), minimum 1.5" (38 mm)
All dimensions show recommended spacing allowed, except for
closet door ventilation openings,
which are the minimum required.
For each arrangement, consider allowing more space for ease of
installation and servicing, spacing for companion appliances, and
clearances for walls, doors, and floor moldings.
Space must be large enough to allow door to fully open.
Add spacing of 1" (25 mm) on all sides of washer to reduce noise
transfer. If a closet door or louvered door is installed, top and
bottom air openings in door are required.
