Decorator Panel Dimensions and Installation.
Three Panel Method
Routed Raised Panel Method
Refrigerator Door
Routed Area
Front Panel ( 3/4" Max.)
Backing Panel ( 1/4")
Trim Frame
Surrounding Door
Refrigerator Door
Front Panel ( 3/4" Max.)
Backing Panel ( 1/4")
Trim Frame
Surrounding Door
Spacer Panel ( 1/16")
12884405 06/08
Spacer
Panel
16-3/4
(425mm)
43-3/16
(1097mm)
23
(584mm)
34-3/4
(883mm)
1/16
(2mm)
Front
Panel
17-3/4
(451mm)
44-1/8
(1121mm)
24
(610mm)
35-3/4
(908mm)
3/4 max
(19mm)
Backing
Panel*
17-3/8
(441mm)
43-13/16
(1113mm)
23-9/16
(599mm)
35-5/16
(897mm)
1/4
(6mm)
Panel
Type
* For ease of installation cut backer panel corners at
45° - 1 x 1
1" (25.4mm)
Typ.
A
B
C
D
Thickness
Suggested Panel Assembly Methods
WEIGHT REQUIREMENTS FOR PANEL INSERTS
Individual refrigerator door panels should not exceed 15 lbs. (7 kg).
Freezer drawer panel should not exceed 15 lbs. (7 kg).
A
B
C
D
